PRIVACY PROTECTION FOR USER AUTHENTICATION

Jan Hajny, Tomas Pelka and Vaclav Zeman

Department of Telecommunications, Faculty of Electrical Engineering and Communication

Brno University of Technology, Purkynova 118, Brno, Czech Republic

Keywords:

Privacy, Anonymity, Security, Protocol, Authentication, Identity.

Abstract:

The paper deals with Internet user privacy. We focus on the protection of user identity during an Internet

service use. We start with an overview of systems for the anonymous channel creation. Such channels are

necessary as any solution for the identity protection will have to work with the TCP/IP protocols used in the

Internet. In the second part of the paper we argue about the need for an anonymous authentication introduction.

Such a service is almost missing in the current Internet. We show how the concept of anonymous authentication

could improve privacy and identity protection. Finally we introduce our concept for anonymous authentication

with the feature of a malicious user detection.

1 PRIVACY AND IDENTITY

PROTECTION

The problem of privacy protection is not limited to the

Internet environment only. We use many electronic

services every day. It is important to realize that ev-

ery time we use a service we release some information

about us. The examples include employee IDs, library

cards, canteen cards and any personal web services

like an email, Internet discussions or social sites. It

is obvious that more and more services can be used

electronically and that the Internet is becoming to be

a more powerful environment than any time before.

The analysis of current use of authentication can be

found e.g. here (Hajny et al., 2009).We leave traces

of our Internet behavior and there are many reasons

why we should care about how much information we

release. The obvious problem is identity theft. In that

case someone else misuses released information to act

as us on the Internet. We can imagine how serious

damage it could cause in the case of Internet banking

or the communication with public authorities or em-

ployers. The other example of a threat on our digital

identity is a behavior scanning. We can see that every

time we use a search engine or some e-shop appli-

cation we get customized results based on a previous

usage. It means that our search or buying history is

stored somewhere and analyzed for further purposes.

But do we really care about more focused advertise-

ments, behavior scanning or movement tracking? Are

we too paranoid when thinking about someone ana-

lyzing what we do on the Internet? Obviously these

questions are appealing for more researchers as many

solutions for anonymous surﬁng emerge.

The paper organization is as follows. We identify

and analyze available tools for anonymous routing in

the Section 2. The overview includes all practical so-

lutions, namely anonymizer proxies, Crowds, MIXes,

Onion Routing and TOR. The concept of anonymous

authentication is deﬁned in the Section 3. The Section

4 includes an overview of our approach for anony-

mous authentication with current results. The Section

5 contains the conclusion with future plans.

2 ANONYMOUS ROUTING

There are many solutions to anonymous routing in

TCP/IP available. We included the practical ones,

which can be used in practice, to our analysis.

2.1 Proxies

The anonymizer proxies are the simplest solu-

tions. The whole group can be represented by the

Anonymizer Internet service (www.anonymizer.com)

which works with the mechanism of a proxy server.

A client wants to communicate with a server without

revealing his identity. That is why he contacts a proxy

through a private channel ﬁrst. All data he sends are

encrypted in such a way that only a proxy can de-

crypt. All requests for the server are sent to the proxy

Hajny J., Pelka T. and Zeman V. (2010).

PRIVACY PROTECTION FOR USER AUTHENTICATION.

In Proceedings of the International Conference on Security and Cryptography, pages 90-93

DOI: 10.5220/0002981300900093

 SciTePress

server which initiates a new connection to the server

and resends all data with proxy’s source address. The

server receives requests but is unable to distinguish

the original initiator as the only address he can see is

proxy’s address. That is why he sends the reply to the

proxy. The proxy creates a private channel with the

client and resends data from the server to the client.

The whole method is described by Figure 1.

ProxySender Receiver

WWW Request

WWW Response

Encrypted channel

Figure 1: Anonymizer proxy design.

Security of the above described design depends on the

proxy entity. It works as a kind of mediator of the

communication who resends data between a sender

and receiver to keep them separated thus anonymous.

On the other hand the proxy must be a trusted service

because it is able to link communicating entities to-

gether and break privacy. That is the reason why this

approach cannot be used in more advanced systems

as it is unacceptable to give such a power to a single

entity.

2.2 Crowds

A different approach is used by another service called

Crowds (Reiter and Rubin, 1998). Security is based

on the idea of a ”hiding in a crowd” in this case. Traf-

ﬁc traverses through a probabilistic path created by a

number of users from the sender to the receiver. The

mechanism is based on the alliance of many users of

the Crowds service. The sender has a list of partici-

pating users available. All users can be used as a relay

to resend other’s trafﬁc to a receiver. All users send

trafﬁc directly to the receiver with a probability of p.

With the remaining probability 1 − p the user sends

trafﬁc to a random user of Crowds. That is why data

sent by the sender do not go directly to the receiver

but to a random Crowds user with probability 1 − p.

The random user then sends data to the receiver with

p probability and to another random Crowd user with

probability 1 − p. That is why a random path through

the crowd is generated. No one who intercepts trafﬁc

is able to distinguish whether the source address of

a captured packet belongs to an original sender or to

just a randomly chosen relay. The mechanism can be

illustrated by Figure 2. In the picture the requests go

as follows: user 1-6-4-receiver2, user 5-2-7-receiver

3 and third request directly from the user 3 to the re-

ceiver 1.

1 2 3

5 6 7

Receiver 1

Receiver 2

Receiver 3

Crowd

Figure 2: Crowds design.

Crowds use symmetric cryptography and are resistant

to the attack of a malicious subgroup of users. Like

all solutions in our overview, also Crowds are not re-

sistant to the global adversary who is able to intercept

all trafﬁc. Security depends on the average number

of nodes between the sender and receiver thus on the

parameter p. The more relays are put between the

sender and receiver the higher is the probability that

a malicious user intercepts a packet with an original

sender address inside. Of course there is the price of

communication overhead because data must be sent

k-times in the case of k + 1 users in a path. The main

advantage to the anonymizer proxies is that users do

not have to trust a single entity.

2.3 Web MIXes

Web MIXes (Berthold et al., 2001) is a system

based on the mixes mechanism introduced in (Chaum,

1981). The topology is different from the previous

examples but combines them to some extent. It is not

a peer-to-peer network where all users use all other

users like in the Crowds example but it is not a cen-

tralized system like anonymizer proxies either. In

this case the sender contacts a given structure of enti-

ties called MIXes which scrambles and reorders traf-

ﬁc and sends it to the receiver. The idea is that the

MIX structure consists of many MIX entities admin-

istered by different organizations. These MIXes are

not under a centralized control and the whole system

works if at least one MIX scrambles honestly. The

assumption is that the attacker is able to control n − 1

MIXes at most. The system works with a program in-

stalled on sender’s computer which intercepts all (but

not limited to) http trafﬁc like a proxy server. These

data are encrypted and sent in constant size chunks

to the ﬁrst MIX. The MIX receives, decrypts and re-

orders data from all senders. After the reorder the

MIX resends to another MIX and the process contin-

ues as long as data go through all mixes. The last

MIX sends data to the receiver. The process can be

depicted by Figure 3.

Security of the approach is based on the impossi-

bility of linking the output of MIXes to inputs. This is

due to the encryption - data come to MIXes encrypted

and are released decrypted and reordered. The sys-

PRIVACY PROTECTION FOR USER AUTHENTICATION

MIX

Sender 1

Receiver 1

Request 1

Request

Sender 2

Sender 3

Request 2

Request 3

MIX

Receiver 2

Receiver 3

Request

Request 1

Request 2

Request 3

MIXnet

Figure 3: Web MIXes design.

tem needs several layers of encryption as data go

through more mixes. To make trafﬁc analysis difﬁ-

cult the system must generate a dummy trafﬁc from

all senders for the attacker to be unable to distinguish

who is actually sending data and who is quiet. For

the future usability it is also very important that Web-

MIXes are already implemented and used in practice

(https://anonymous-proxy-servers.net/en/).

2.4 Onion Routing and TOR

A similar mechanism is used by Onion Routing (Reed

et al., 1998). The sender does not contact the receiver

directly but through a proxy software on his computer

which sends data through a network of entities called

Onion Routers (Fig. 4).

Sender Receiver

Onion Routing network

Figure 4: Onion routing design.

Asymmetric cryptography is used to protect data from

eavesdropping by malicious Onion Routers. All pack-

ets sent by the proxy are encrypted by public keys VK

of all routers on the path. The encryption must in-

clude next hop headers (hdr) - the encryption for a

three router situation is described by Equation 1.

packet = E

V K

(hdr + E

V K

(hdr + E

V K

(req))) (1)

Every router then peels off a layer of encryption as

the packet goes through it. It learns a next hop IP

and an encrypted payload to send. That is the reason

why routers know only its predecessor and successor

because all IP addresses of remote routers on the path

are encrypted. Security of Onion Routing is based

on used asymmetric cryptography and randomness of

the path. The routers must be chosen randomly and at

least one of them must be honest.

TOR. The practical implementation of Onion Rout-

ing is called TOR (Dingledine, 2009). It uses the

same principle to choose a random path through

routers and to encrypt data with an encryption layer

for every router. The difference is in cryptography as

TOR uses symmetric cryptography for data encryp-

tion and asymmetric cryptography for key establish-

ing. Before actual data are sent through a random path

the proxy establishes a symmetric key using a Difﬁe-

Hellman protocol with every router on the path. Then

the proxy encrypts data with the established key in

a similar fashion as described in the Onion Routing

section and sends to the ﬁrst router. The peeling pro-

cedure is the same as for original Onion Routing. The

difference is in efﬁciency as symmetric encryption

is much faster in a practical implementation. Secu-

rity depends on the same factors as in Onion routing,

namely cryptography security and at least some hon-

est routers. The TOR design can be used for any pro-

tocol and thanks to efﬁciency and low latencies it is a

one of most popular solutions. In our more advanced

structures we chose TOR as a solution for anonymous

channels.

3 ANONYMOUS

AUTHENTICATION

The mentioned solutions provide mechanisms for

anonymous routing. We would like to add the fea-

ture of anonymous authentication. We introduce a

concept which keeps all properties required by ser-

vice providers but adds anonymity features for ser-

vice users. Our goal is to keep clients responsible

for their acts but reveal their identity only in the case

of rule violations. Using our concept the users stay

anonymous as far as they obey system rules. On the

other hand if they break system rules they can be

uniquely identiﬁed. The concept with such properties

is called Anonymous Authentication and has follow-

ing requirements:

• Completeness: a valid user must be always ac-

cepted.

• Soundness: an other than valid user must be al-

ways rejected.

• Anonymity: the veriﬁcation protocol must release

no information about user identity.

• Spread traceability: the user identity must be re-

leased but only in the case of rule breaking.

The concept of anonymous authentication can be eas-

ily imagined as a group authentication where the

group includes all valid users of the system. The

veriﬁer is able to check the membership in a group

(therefore user’s right to use the system) but concrete

SECRYPT 2010 - International Conference on Security and Cryptography

identity stays hidden. The traceability is required

for a user responsibility. It is in a direct contrast to

anonymity and that is why we want it to be spread

among more entities which must cooperate to reveal a

malicious user identity. Our assumption is that more

entities must agree to break anonymity thus the trace-

ability is available only in justiﬁed cases.

4 OUR CONTRIBUTION

We decided to use e-cash systems to provide anony-

mous authentication. We ﬁnd the ability to create an

anonymous e-coin spendable at the e-shop very useful

for authentication. There is also a very important fea-

ture of double-spender detection available at e-cash

systems. It provides the bank with the possibility to

reveal identity of a user who spent an e-coin twice.

That is why the bank is always sure that the user ei-

ther used the coin only once or the bank is able to

learn his identity in the case of multiple spending.

Our approach uses an e-coin as an authentication

token. The user must provide the veriﬁer with a valid

e-coin (token) and the knowledge of its construction.

If everything is accepted by the veriﬁer the user is suc-

cessfully authenticated because the token is valid thus

released by the administrator of tokens who release

tokens only to valid users (similarly the bank releases

coins only to users with bank accounts). The com-

pleteness and soundness features are directly fulﬁlled

by e-cash system properties. No user identity is re-

leased as the e-coin (token) is unlinkable to the user.

The only problem is with the spread traceability. We

solved the problem by using the double spender de-

tection feature. The user uses the e-coin (token) at a

newly deﬁned public authority entity which signs the

token. Then the user uses the token for authentica-

tion for the second time. That is why he is a double

spender so his identity can be revealed but only if the

public authority and the veriﬁer cooperate. Neither

the veriﬁer nor public authority is able to break user

anonymity alone.

Currently we are working on a scheme described in

this paper. We use Σ-protocols (Cramer, 1996) as

cryptographic primitives and that is why we get very

good efﬁciency. We expect the authentication proto-

col to be able to run in a smartcard environment.

5 CONCLUSIONS

The purpose of this paper is to point out to insufﬁ-

cient privacy in the Internet and to introduce tools

for improving user privacy. We distinguished two

steps for providing user anonymity. The ﬁrst one is

anonymous routing which give users the possibility to

anonymously communicate. There are practical tools

to use. We expect the TOR protocol to be the choice

for most implementations as it is both secure and us-

able for multipurpose trafﬁc. The second step for pro-

viding anonymity is unsolved yet. We propose the

concept of anonymous authentication which allows

users to use not only open services but also services

which require some form of user authorization. Ac-

cording to our future plans we would like to imple-

ment more features to our anonymous authentication

scheme. Our goal is to provide provable security on a

smartcard platform.

ACKNOWLEDGEMENTS

Sponsored under the National Program of Research

II by the Ministry of Education, Youth and Sports of

the Czech Republic in 2C08002 Project - KAAPS Re-

search of Universal and Complex Authentication and

Authorization for Permanent and Mobile Computer

Networks.

Jan Hajny is a holder of the Brno Stipend for Tal-

ented Doctoral Students.

REFERENCES

Berthold, O., Federrath, H., and K

opsell, S. (2001). Web

mixes. In International workshop on Designing pri-

vacy enhancing technologies, pages 115–129, New

York, NY, USA. Springer-Verlag New York, Inc.

Chaum, D. L. (1981). Untraceable electronic mail, return

addresses, and digital pseudonyms. Commun. ACM,

24(2):84–90.

Cramer, R. (1996). Modular Design of Secure, yet Practical

Cryptographic Protocols. PhD thesis, University of

Amsterdam.

Dingledine, R. (2009). Tor: anonymity online. World Wide

Web electronic publication.

Hajny, J., Pelka, T., and Lambertova, P. (2009). Flexi-

ble Authentication Framework. In 2009 INTERNA-

TIONAL CONFERENCE ON NETWORK AND SER-

VICE SECURITY, pages 29–33. IEEE.

Reed, M. G., Syverson, P. F., and Goldschlag, D. M.

(1998). Anonymous connections and onion routing.

IEEE Journal on Selected Areas in Communications,

16:482–494.

Reiter, M. K. and Rubin, A. D. (1998). Crowds: anonymity

for web transactions. ACM Trans. Inf. Syst. Secur.,

1(1):66–92.

PRIVACY PROTECTION FOR USER AUTHENTICATION
