QOS AND SECURITY IN ENERGY-HARVESTING

WIRELESS SENSOR NETWORKS

Antonio Vincenzo Taddeo, Marcello Mura and Alberto Ferrante

ALaRI, Faculty of Informatics, University of Lugano, via G. Bufﬁ 13, Lugano, Switzerland

Keywords:

Security, priority, Wireless sensor networks, Quality of services, Energy harvesting.

Abstract:

Wireless sensor networks are composed of small nodes that might be used for a variety of purposes. Nodes

communicate together through a wireless connection that might be subject to different attacks when the net-

work is placed in hostile environments. Furthermore, the nodes are usually equipped with very small batteries

providing limited battery life, therefore limited power consumption is of utmost importance for nodes. This

is in clear opposition with the requirement of providing security to communications as security might be very

expensive from the power consumption stand point. Energy harvesting methods can be used to recharge bat-

teries, but, in most of the cases the recharge proﬁle cannot be known in advance. Therefore, nodes might face

periods of time in which no recharge is available and the battery level is low.

In this paper we introduce an optimization mechanism that allows the system to change the communication se-

curity settings at runtime with the goal of improving node lifetime, yet providing a suitable security level. The

optimization mechanism further improves energy consumption by putting in place a quality of service mech-

anism: when energy is scarce, the system tends to send only essential packets. As shown by the simulations

presented in this paper, this mechanism optimizes the energy consumption among different recharges.

1 INTRODUCTION

Wireless Sensor Networks (WSN) are composed of

a large number of nodes with sensing, processing,

and data communication capabilities. Recent im-

provements in microelectronic technologies provide

the ability to create small and inexpensive nodes with

limited power consumption. In a typical applica-

tion scenario, nodes are provided with a local power

source which is usually limited and non-replaceable;

thus, power consumption requirements represent the

utmost constraint for most WSN nodes (Akyildiz

et al., 2002). Typically, sensor nodes proper commu-

nicate over limited distances with a “sink” - usually

acting as gateway to some remote system - which may

have less stringent power requirements as it might be

equipped with better power sources.

Recently, in (Alippi et al., 2008) it was observed

that, in real usage scenarios in which WSN are used

for monitoring the environment, nodes cannot be

powered just by using small batteries. Energy Har-

vesting becomes an essential feature in this as well as

in other contexts where small batteries cannot provide

the required power for the required time. Different

techniques have been explored to harvest energy from

the environment (Roundy et al., 2004); so far, solar

energy has been the most exploited energy harvest-

ing resource as the technology is sufﬁciently mature

to provide a suitable quantity of energy for wireless

applications. Though, the use of solar energy intro-

duces a further level of uncertainty in the amount of

energy available to the system. Energy consumption

is, in any WSN, partially deterministic and partially

non-deterministic (e.g. due to random components

of the wireless protocol and asynchronous alarms).

The recharge rate given by a solar source superposes

a natural deterministic feature (i.e. day/night, sea-

sons) to a dominant non-deterministic stochastic na-

ture (weather conditions) as well noted in (Moser

et al., 2007a). In particular, the length of the peri-

ods in which the insulation is insufﬁcient to guarantee

nodes operation is not known. For this reasons, deﬁn-

ing strategies to optimize network operations in such

conditions is of primary importance research ﬁeld.

Another fundamental factor inﬂuencing the design

and performance of sensor networks concerns secu-

rity of their communications. Security services such

as authentication, conﬁdentiality, and availability be-

comes especially critical for WSNs operating in hos-

tile environments and managing potentially sensible

241

Vincenzo Taddeo A., Mura M. and Ferrante A. (2010).

QOS AND SECURITY IN ENERGY-HARVESTING WIRELESS SENSOR NETWORKS.

In Proceedings of the International Conference on Security and Cryptography, pages 241-250

DOI: 10.5220/0002982202410250

 SciTePress

data. Generally, in order to enforce communication

security, additional computational resources are re-

quired (Chandramouli et al., 2006): typically, packet

header sizes are incremented, thus inducing a signiﬁ-

cant increase in the energy spent for communications

(Mura et al., 2008). Traditional security solutions are

ciﬁc protection against certain attacks. However, they

rely on the assumption that the operative environment

is well-known and essentially static. Moreover, some

of these technologies have not been speciﬁcally de-

veloped for embedded systems; in many cases, their

adoption in the pervasive world would be impossi-

ble due to high hardware resources requirements (Fer-

rante et al., 2005).

In practice, when designing secure systems, the

worst case scenario is considered: the system has to

guarantee adequate protection against the strongest

possible security attacks. This is generally in contrast

with the typical requirements of resource-constrained

devices: mobility, ﬂexibility, real-time conﬁgura-

tion, open and dynamic operative environment (Keer-

atiwintakorn and Krishnamurthy, 2006; Großsch¨adl

et al., 2007). In the work presented in this paper we

adopted a new approach to security by relating it to

the current system conditions. The best possible se-

curity solution, speciﬁed within a range of possible

choices, is chosen dynamically to optimize both se-

curity and lifetime of the system. As discussed in

(Chigan et al., 2005; Lighfoot et al., 2007), evaluating

run-time the trade-offbetween security and consumed

energy is not straightforward.

Furthermore, in some scenarios, nodes might re-

quire the ability to guarantee the delivery of criti-

cal data packets even in presence of scarce resources.

For this purpose, a network Quality of Service (QoS)

mechanism may be implemented in the nodes. In our

case, the scarce resource is not network bandwidth as

in the largemajority of cases in which QoS is adopted.

Instead, in this context, the scarce resource is energy:

when available energy is low, only essential packets

should be delivered to preserve the system main func-

tionalities, in case a solar recharge is not available.

To this goal, we associate with each packet a prior-

ity level and propose a run-time mechanism to man-

age security and QoS inside WSN nodes equipped

with solar panels. The mechanism proposed in our

approach provides the unique ability to optimize the

trade-off between consumed powerand security while

providing support for QoS. In our approach, security

is being adapted to the energy conditions of the sys-

tem. At the same time, high-priority packets are pro-

cessed faster and with higher security.

In Section 2, the related works are presented and

the innovation of our work is highlighted. We intro-

duce the main parameters that we considered in the

design of our solution and provide details regarding

the trade-off mechanism in Section 3. A case study

to prove the validity of our approach as well as the

simulations results are outlined in Section 4.

2 RELATED WORK

This study targets the problem of deciding which level

of service should be guaranteed by a WSN under en-

ergy recharging conditions. Various task scheduling

policies suitable for energy harvesting WSNs nodes

were studied in (Moser et al., 2007a; Moser et al.,

2007b); in (Moser et al., 2008) algorithms for max-

imizing a function of merit of the devices are pro-

posed. Appropriate voltage/frequency levels selec-

tion depending on the available energy is studied in

(Liu et al., 2008) and in (Liu et al., 2009). Adaptiv-

ity by means of setting different reliability levels de-

pending on the available energy is presented in (Wang

et al., 2009). Most current studies discuss this subject

with the classical approach used for scheduling tasks

on a microprocessor: packets are considered as tasks

and their schedulability is evaluated by substituting

energy to CPU time.

We modify this classical approach by introduc-

ing a QoS management mechanism (Sean Convery,

2004) similar to the ones commonly used in conven-

tional networks. Packets might be subdividedinto dif-

ferent categories, each one with a different “impor-

tance”. More critical packets (i.e., the ones classiﬁed

with high priority) are prioritized over the others, thus

guaranteeing to them an higher probability of being

delivered even in presence of scarce resources (i.e., a

low battery level).

Concerning security aspects, the problem of opti-

mizing resources used for security, yet providing an

adequate level of protection, is an hot topic at the mo-

ment (Ravi et al., 2004). In particular, the trade-off

between energy and performance requirements of se-

curity solutions is of utmost relevance for embedded

systems (Chandramouli et al., 2006). Each adopted

security solution should be a good compromise be-

tween factors that are conﬂicting in nature such as,

for example, power consumption and performances.

This optimization is a complex task, especially when

performed at run-time (Chigan et al., 2005; Lighfoot

et al., 2007). With respect the classical approaches for

securing WSNs, our solution is able to dynamically

adapt the security settings based on current node en-

ergy conditions and according to speciﬁc security re-

quirements. Furthermore, it provides the highest se-

SECRYPT 2010 - International Conference on Security and Cryptography

242

curity for high-priority packets.

3 SECURITY AND QOS

MANAGEMENT

In this paper we considered a WSN in which nodes

periodically send packets to a sink destination. Pack-

ets to be delivered may have security requirements

that, depending on the operative context, the system

might or might not be able to satisfy. For example, the

battery level might be too low to use certain security

settings. Therefore, in order to assure a high number

of packets transmitted, a change in the security pro-

vided has to be applied. Moreover, delivery of critical

packets has to be guaranteed: a priority value is used

to mark each packet and to provide such a QoS. Prior-

ities should be carefully assigned to packets at system

conﬁguration time: packets that are essential for the

network, for example, should be associated to highest

priority levels as low-priority packets may be delayed

indeﬁnitely.

Our adaptation mechanism manages QoS and

changes the security settings dynamically to maxi-

mize the trade-off between the number of packets sent

(with priority precedence) and their security. Such op-

timizations require to estimate the energy consump-

tion connected with the security processing and the

transmission of packets. The security and QoS man-

agement process that we propose is based on a set of

optimization strategies. The optimizations to be ap-

plied depend on a set of parameters related both to the

system status and to the characteristics of data packets

to be transmitted.

In this section we ﬁrst describe the considered pa-

rameters; then we introduce the optimization process

that we have designed.

3.1 Parameters

The system parameter considered is the available en-

ergy E

available

; it includes the contribution of the en-

ergy recharge E

harv

due to the harvesting system.

The characteristics of data packet considered are

both related to intrinsic packet characteristics (e.g.,

their length) and to associated parameters such as

their importance (expressed as a priority level) and

their required security.

3.1.1 Energy Model

Energy consumption data can be collected only after

the corresponding activity happens. Therefore, we in-

troduce a prediction model that gives an indication of

the foreseen power costs for packet transmission. The

actual consumption is collected after corresponding

packets have been sent and is used to have a more

precise estimate of available energy.

In most networking protocols a boundary on the

amount of time and energy necessary to ensure that a

given packet is transmitted does not exist. For exam-

ple, by using a CSMA algorithm, there may be cases

in which the access to the channel cannot be obtained

due to channel jamming. For this reason, an average

energy for transmitting the packet should be consid-

ered instead of the worst case one. The penalty for

transmitting multiple times a packet because of errors

on the channel is very strong. For this reason our av-

erage takes into consideration a number of retrials that

depends on the state of the network.

We model the energy needed to process a packet

as:

packet

= E

+ E

errors

(1)

where, E

is the energy required to transmit a packet

assuming that the channel is always free. Instead,

errors

takes into account the energy spent for multiple

executions of the CSMA algorithm that are necessary

when the channel is found to be busy or when packets

need to be retransmitted due to collisions. E

is com-

posed of: the energy consumed by the CSMA algo-

rithm, E

csma

; the energy spent for sending the packet,

considered as the sum of the energies necessary to

send the header of the packet (i.e. E

header

), the possi-

ble increase in the overhead of the packet due to secu-

rity (i.e. E

ovhsec

) and the energy necessary for sending

the payload E

payload

. That is:



csma

+ E

header

+ E

ovhsec

+ E

payload



(2)

In Table 2 is reported the security overhead consid-

ered (Mura et al., 2007). E

header

, as well as E

ovhsec

and E

payload

depend on the size of the correspond-

ing parts of the packet and on the energy per byte e

(i.e. transmission power/throughput in bytes). Our

methodology does not involve any modiﬁcation of

the header different than that modeled by the secu-

rity component. As a matter of fact, depending on the

architectural choices for the node platform, there may

also be a relevant contribution to energy budget due

to execution of encryption/authentication algorithms

as shown in (Mura et al., 2008). In this paper, we

refer to node platforms that process security through

HW co-processors in which such contribution is neg-

ligible.

Following the analysis of the 802.15.4 algorithm

done in (Mura et al., 2007) the other contributions can

be reﬁned as:

csma

= mode∗ (E

idle2rx

+ E

cca

) + E

twait

(3)

QOS AND SECURITY IN ENERGY-HARVESTING WIRELESS SENSOR NETWORKS

243

Therefore, E

csma

can be decomposed into the sum of

the energies to switch the radio from the idle to the

receiving mode (E

idle2rx

) and the energy consumed

while receiving the CCA (E

cca

). These operations are

executed once in beaconless mode (mode = 1) and

twice when beacons are used (mode = 2). E

twait

the energy consumed, in idle state, while waiting the

random time before performing the CCA; we used the

worst case value for this parameter.

errors

is composed of two factors:

errors

= E

busy

+ E

re tx

= (4)



busy

∗ E

csma

+ N

re tx

∗ E



sent

(5)

the ﬁrst is the energy spent for executing multiple

times the CSMA procedure when the CCA reports

that the channel is busy, hence it equals K

busy

times

the energy of a CSMA algorithm. The latter is the

energy consumed for retransmitting the entire packet

due to channel collisions, that is N

re tx

times E

. Val-

ues are meant by the number of packets successfully

sent M

sent

in a transmission time slot. Values of these

parameters, K

busy

, N

re tx

and M

sent

has to be computed

based on the applicative scenario. They can assume a

constant value, if the channel behavior is quite static;

or can be computed at run-time, for example, by mon-

itoring the channel conditions and updating proper

counters.

Every time a packet is processed and transmit-

ted, the corresponding energy consumption E

packet

drawn from the available energy E

available

Finally, we introduce an energy constraint E

frame

which is a discrete time derivative of the current en-

ergy consumption E

available

frame

= E

available

(t) − E

available

(t − 1) (6)

This constraint is used to assures that, for each trans-

mission time slot, the variation of the energy required

to process a certain number of packets is below the

speciﬁed threshold E

frame

. Thus, it is a hard con-

straint in the maximum energy consumption allowed

in a transmission slot. The value for E

frame

can be

either constant, (and, therefore, assigned statically at

design time) or computed dynamically as a function

of the energycurrently available. In general, the value

assumed by this parameter should be tuned according

to the considered scenario.

3.1.2 Packet Characteristics

In our system each packet, with a given payload size,

is labeled with an identiﬁer P

, it is associated to secu-

rity requirements as well as to a priority level. These

pieces of information are only used by the optimiza-

tion mechanism and they do not cause any network

Table 1: Packet schema.

Packet # 102 SecReq

Size Priority SecSuite ActiveSuite

[bytes] [0, 3] (8bit) [0, 7]

50 3 [1,0,1,0,1,1,0] 5

overhead as they are local parameters. An example is

shown in Table 1.

Network messages can have different importance,

ranging from essential information, either for network

maintenance or application scope, to low-signiﬁcance

information that can be dropped with limited impact.

A priority ρ can have values between 1 and 4 (the

higher the number, the higher the priority). As men-

tioned earlier, when energy is scarce, our system will

favour high-priority packets. Low priority packets

will be delayed indeﬁnitely or discarded if the mem-

ory becomes full. The aim of this approach is to pre-

serve as much energy as possible to send necessary

packets. Non-essential packets might be sent later

when harvesting allows the system to recover the bat-

tery level.

Security requirements associated to packets are a

central parameter in our trade-off mechanism. The se-

curity level chosen for each packet impacts both on

the associated consumed energy and on the associ-

ated computational and network latencies. A secure

packet, due to longer packet header and security pro-

cessing, consumes more energy and takes more time

to be managed by the network then a non-secure one

(Mura et al., 2008). While some packets have manda-

tory security requirements, others may have softer re-

quirements. Therefore security of such packets can be

decided at runtime depending on the current status of

the system.

We deﬁned a security requirements, SecReq, as

composed of:

SecReq = hSecSuite; ActiveSuitei (7)

SecSuites is a list of security suites that may be used

for the particular packet. SecSuites is a bitstream in

which every bit corresponds to a different security

suite supported by the transmission protocol, the bit

is set to 1 if it is possible to use that suite for the par-

ticular packet. For example, if we refer to the security

suites of the IEEE 802.15.4 wireless standard (Sastry

and Wagner, 2004), as reported in Table 2, we need 8

bits to model the entire set.

ActiveSuite identiﬁes the security suite to be used

for processing the given packet. If a change in

the security provided is required, the ActiveSuite is

updated to the new security suite ID. Changes in

ActiveSuite are allowed within the packet security

suites bitstream. Therefore, to have a ﬁxed secu-

rity suite only one bit should be set in SecSuites

SECRYPT 2010 - International Conference on Security and Cryptography

244

Table 2: Security suites supported by IEEE Std 802.15.4

and their packets overhead (Mura et al., 2008).

Security Suites

SuiteID Description Service

Overhead

[byte]

0 Null No Security 0

1 AES-CBC-MAC-32

Authentication

2 AES-CBC-MAC-64 13

3 AES-CBC-MAC-128 21

4 AES-CTR Encryption (only) 5

5 AES-CCM-32

Authentication and

Encryption

6 AES-CCM-64 13

7 AES-CCM-128 21

list. This corresponds to a mandatory security re-

quirement given by, for example, the following tu-

ple: hSecSuite = [0, 0, 0, 1, 0, 0, 0]; ActiveSuite = 4i.

ActiveSuite is the index of the 8 bit array of SecSuite.

An example of deﬁnition of softer packet SecReq

is shown in Table 1; the packet with label 102 has a

priority value 3 and may support different suites for

data protection: 0, 2, 4 and 5. The current active

suite is the number 5, that is the suite AES-CCM-

32 of Table 2. If an adaptation is needed, the sys-

tem may decide to use a different security suite (e.g.

ActiveSuite = 4) to save energy (because of lower

header size overhead).

3.2 Optimization Process

By using the aforementioned parameters our man-

agement algorithm optimizes the security of pack-

ets while managing QoS and optimizing energy con-

sumption. An optimization strategy is applied by the

optimization mechanism to obtain these results.

3.2.1 Optimization Strategies

Different optimization strategies can be deﬁned for

different system conditions. An optimization strat-

egy (℘) can be deﬁned as a composition of actions to

be performed in order to meet the energy constraint

given by E

frame

We designed the strategies with two goals in mind:

to maximize the number of high-priority packets that

are delivered and to ensure that security requirements

of each packet are satisﬁed. These strategies are op-

timized to provide to each packet the safest possible

suite among the ones speciﬁed in SecSuite.

We identify the following actions that can be com-

bined within a strategy℘:

• change the ActiveSuite security suite used to pro-

tect the considered packet, according to the suites

speciﬁed in SecSuite;

• either drop or delay the packet transmission to the

next communication slot, according to the priority

of the considered packet;

• limit the number of packets to be sent. Such a

limitation can be imposed both on predetermined

priorities levels or globally on all packets.

QoS may be provided through one of the well known

approaches listed in (Sean Convery, 2004), for exam-

ple by applying Weighted Fair Queueing (WFQ) and

Priority Queueing (PQ).

By combining the aforementioned actions in a

strategy, the system can directly change the energy

consumption needed to process the packets that are in

the send queue with the goal of satisfying the energy

constraint given by E

frame

For example, a possible strategy to meet such a

constraint may be as follows:

• low priority packets are delayed to successive

communication slots;

• other, less energy hungry, security suites are cho-

sen for the remaining packets in queue;

• other packets may be selected for being delayed.

3.2.2 Optimization Mechanism

An adaptation is required when the amount of energy

required to transmit λ packets is above the threshold

frame

. The adaptation is performed by enforcing a

certain strategy℘. The process has been designed by

following the Monitor-Controller-Adapter loop (De-

rin et al., 2009). In the monitoring phase, the avail-

able energy capacity E

available

and the λ packets to

be delivered to a sink node are measured every trans-

mission time slot. The available energy includes the

contributions of the harvested energy E

harv

obtained

through solar cells. Depending on the current energy

conditions, it exists a given energy constraint E

frame

to be respected. Moreover, network conditions are

monitored by updating the counters of the Equation

4 (N

ri tx

, K

busy

and M

sent

) at each transmission time

slot.

All these monitored information are propagated to

the controller module that decides which packets to

send and their associated security suites. These infor-

mation are then propagated to the adapter that orga-

nizes packet transmission according to what decided

by the controller. Packets are then sent by using con-

ventional network stack.

The controller uses the energy model introduced

in Section 3.1.1 to estimate the energy per packet

packet

, and the total energy consumptionof the candi-

date packets. This estimation is used to select packets

according to a strategy℘.

QOS AND SECURITY IN ENERGY-HARVESTING WIRELESS SENSOR NETWORKS

245

A further constraint on the candidate packet selec-

tion might be imposed by the current network condi-

tions: for example, it can be set an higher bound for

the number of packets that can be transmitted.

In Algorithm 1 we show an example of a selec-

tion mechanism used within the controller module to

select the optimal packets.

3.3 Security Considerations

Aim of our frameworkis to provide an adaptive mech-

anism to satisfy system energy constraints, yet provid-

ing adequate protection to the applications. The use

of multiple cryptographic algorithms may lower the

security of applications. In particular, when weak-

est algorithms are used the transmitted data are more

exposed to attacks. Though, our approach tries to

provide a reasonable solution for those situations in

which device constraints would not give the possibil-

ity to provide any (or little) security to applications.

Aim of our self-adaptation mechanism is to pro-

vide the highest possible security level in any instant

of time. Degradation of security is only performed

if the energy constraints of the system cannot be sat-

isﬁed. In this particular context, lowering the secu-

rity of the communication increases the potential of

attacks only for a limited quantity of data (i.e., just

the ones that are being transmitted in those periods of

time).

Possible attacks in which the system can be forced

to decrease the security level of applications may also

affect our security degradation method. For exam-

ple, multiple communications requests can be used to

drain the battery, thus forcing the system to degrade

security. Though, we should consider that our frame-

work performs adaptation of security level based on

application security requirements. Therefore, appli-

cations are always guaranteed to have the minimum

level of protection that they require.

Similar attacks can be used to cause a denial of

service by totally draining the battery. Our manage-

ment of security allows the system to stand longer to

these attacks, even though it does not provide a spe-

ciﬁc protection for them. The best defense against

this kinds of attacks would be to have an intrusion

detection system installed on the nodes. Though, run-

ning such a system, even if simpliﬁed, would be too

expensive in terms of computational power, memory,

and consumed energy.

4 EXPERIMENTAL RESULTS

To evaluate the optimization method described in this

paper we considered a case study and simulated it.

The case study represents a simple yet realistic case

and allows evaluating performance of our optimiza-

tion algorithm.

In this section we provide a description of the con-

sidered case study; we then describe the simulations

we have performed and we show the results we have

obtained.

4.1 Case Study

We consider as a case study a wireless sensor network

composed of 7 nodes. The optimization algorithm is

applied at node level, thus, its efﬁciency does not de-

pend on the number of nodes. Each node is equipped

with a digital camera, and it acquires an image every

30s and sends it to the central point. Every picture

is composed of 160 packets of 90 bytes. Though, it

should be noticed that the actual dimension of pack-

ets depends on the security suite adopted. The appli-

cation is data intensivefor a WSN, having a global ap-

plication throughput of about 35kbps. This is a clas-

sical scenario in many application ﬁelds (e.g. surveil-

lance, trafﬁc monitoring, environment monitoring).

Information are usually uniformly spread in pic-

tures. For this reason we divided each picture into

ﬁve segments. Data of each segment are subdivided

into network packets. All the packets belonging to

the same segment share the same priority level. Pri-

orities are assigned to each segment by following an

uniform distribution. Moreover, each packet may then

have different security requirements depending on its

importance. Security requirements of packets (i.e.,

SecSuite bitstream) are taken from a binomial distri-

bution. Consumption of the packets to be delivered

is estimated according to the model speciﬁed in Sec-

tion 3.1.1. In particular, by considering data collected

during previous simulations, we estimate a value of

busy

= 64, N

re tx

= 32 and M

sent

= 160 packets for

the parameters of Equation 4.

In this scenario, we considered the IEEE 802.15.4

protocol in Beaconed Mode (i.e., mode = 2 in Equa-

tion 3). We simulated a star topology, therefore every

communication passes through the coordinator. We

assume that the coordinator is connected to a power

line; the other nodes have limited energy capacity

and they are able to harvest solar energy. Consid-

ering the fact that charge/discharge cycles are harm-

ful for chemical batteries, we suppose to use a super-

capacitor instead of the battery. While this improves

time-invariance of the power section, the energy con-

SECRYPT 2010 - International Conference on Security and Cryptography

246

tained in the ultra-capacitor is about one order of mag-

nitude less than the one of a commercial battery. We

considered our power section made of a small so-

lar cell that produces at peak about 300mA, and a

super-capacitor of 310Farad with slightly more than

400.000mAs available. This correspond, for exam-

ple, to the adoption of a Maxwell BCAP0350 E270

T9 SuperCap. The consumption of the digital cam-

era was considered to be 25mAs per picture. E

frame

has been considered to be a constant value of 3.5mAs

plus a percentage (0.09%) of the total energy capacity,

meant by the number of frames. This value has been

chosen to provide a system lifetime, between battery

recharge, of roughly 4 days.

Considering the above scenario, in conditions

of peak solar power, the super-capacitor is fully

recharged in less than half an hour.

4.2 Simulations

The case study discussed above has been simulated

to verify the effectiveness of our approach. Results

show that, while our method does not allow for an

absolute decrease of consumed energy, it allows for

an optimization of the trade-off among consumed en-

ergy, importance of the packets sent, and their security

level.

In our case study we adopted the optimization

algorithm shown in Algorithm 1. We assumed an

approach to QoS similar to Priority Queueing (PQ).

With PQ, higher-priority packets are transmitted be-

fore lower-priority ones, thus guaranteeing that an

higher number of high-priority packets are delivered

even in conditions of scarce energy. We considered

the following optimization strategy℘: by default, the

active security suite for all packets is the SuiteID = #0

(i.e. NULL); when the energy consumption of the

high-priority packets is below the threshold, their se-

curity is increased according to packet security re-

quirements. After the security upgrade, the remaining

packets in queue are analyzed in order to consume the

residual energy. Instead, if the energy consumption of

the high-priority packets is above threshold, the most

energy-hungry packets are removed from the list of

candidates.

When solar cells are active our optimization al-

gorithm is set to work as if the batteries were fully

charged. In this condition our algorithm is at least not

worse than any static setting for security. In fact, in

this condition, our optimization algorithm will select

the highest security algorithm speciﬁed for each class

of packets. For this reason in the simulations we fo-

cused only on a scenario in which there is no solar

recharge for a long period of time, for example due to

Algorithm 1. sel pos = SELECTOR( E

frame

, sub set).

Require: An energy constraint E

frame

≥ 0.

Require: Set of packets (indexes) to analyze, sub set 6= 0.

Ensure: The optimal set of packets (indexes) to send

sel pos.

1: pri pos = HIGHPRICANDIDATES(queue,sub set)

2: E

packet

= GETPACKETSENERGY(queue, pri pos)

3: E

residual

= E

frame

4: E

consumption

∑

packet

5: sel pos = [ ]

6: if min



packet



> E

frame

| sel pos == [ ] then

7: return sel pos

8: else

9: if E

consumption

< E

frame

then

10: sel pos = pri pos

11: E

residual

= E

residual

− E

consumption

12: if CHECKSECUPGRADE(E

residual

, pri pos)

then

13: E

residual

= UPGRADESEC(pri pos)

14: end if

15: sel trail = SELECTOR(E

residual

, TRAIL(pri pos))

16: return sel pos = sel pos+ sel trail

17: else

18: new pos = REMOVEMAXENERGY(pri pos)

19: sel pos = SELECTOR(E

residual

, new pos)

20: end if

21: return sel pos

22: end if

clouds.

4.2.1 Simulation Environment

The case study has been simulated by using the

SystemC network simulator described in (Mura and

Sami, 2008). This simulator is capable of emulat-

ing node and network operations as well as annotating

with µs precision the corresponding power consump-

tion for all the nodes involved. Furthermore, the sim-

ulator is capable of managing channel contention and

to repeat transmissions when interferences occur.

The simulator is based on an implementation in-

dependent model (Mura et al., 2007) that can be

later characterized for practical implementations. The

characterization includes the substitution of the ac-

tual consumption values for the different activities of

the node (e.g., reception and transmission). In (Mura

et al., 2007) it is shown that the power consump-

tion obtained with the simulator is few percent dif-

ferent from the actual data of consumption gathered

from real nodes through an oscilloscope. In order to

characterize our implementation independent model,

we considered that the devices are equipped with the

CC2420 radio with a 0dBm transmission power and

that they use corresponding power levels.

QOS AND SECURITY IN ENERGY-HARVESTING WIRELESS SENSOR NETWORKS

247

100

110

pri

% of packets sent

Priority Level

Opt

Base-maxsec

Base-minsec

Base-sec0

Base-sec2

Base-sec4

Base-sec7

Figure 1: Comparison of average percentage of packets sent

for each priority value.

sec

% of packets sent

Security Suite

Opt

Base-maxsec

Base-minsec

Figure 2: Comparison of average percentage of packets sent

for each security suite.

4.2.2 Results

The impact of our optimization method is highlighted

by comparing the same scenarios with and without

applying the optimizations. In case of no limitations

on energy consumption and with no optimization, the

system has an operative lifetime of about three days

-6

-4

-2

System

% of energy per byte

Opt vs maxsec

Opt vs minsec

Opt vs sec0

Opt vs sec2

Opt vs sec4

Opt vs sec7

Figure 3: Comparison of percentage variation of energy per

byte consumed by the optimal system w.r.t the Base System.

-6

-4

-2

System

% of packets sent

Opt vs maxsec

Opt vs minsec

Opt vs sec0

Opt vs sec2

Opt vs sec4

Opt vs sec7

Figure 4: Comparison among the number of packet sent

during the simulation time by the optimal system with the

ones sent by the non-optimal systems.

when non energy harvesting is possible. When proper

constraints on the consumed power are set (E

frame

Equation 6), the lifetime in the same conditions is in-

creased to four days. In this paragraph we focus on

the comparativeanalysis of various cases in which en-

ergy constraints are set.

Six different conﬁgurations have been simulated

for comparing different possible situations, one of

them in which the optimization methodology was

used (Opt), and the other ﬁve (Base-*) in which it was

not. The last ﬁve considered cases are as follows:

• security is the maximum in the SecSuite range

speciﬁed for each packet (Base-maxsec);

• security is the minimum in the SecSuite range

speciﬁed for each packet (Base-minsec);

• security is at level 0 for all packets (Base-sec0);

• security is at level 2 for all packets (Base-sec2);

• security is at level 4 for all packets (Base-sec4);

• security is at level 7 for all packets (Base-sec7);

Figure 1 shows the percentage of packets of each

priority level that the node have been able to send

(remaining packets are discarded so to respect en-

ergy constraints) in the simulation period when dif-

ferent system conﬁguration are considered. The ﬁg-

ure shows that, while a non-optimized node does not

guarantee any privilege to high-priority packets, the

optimized node does. When no QoS is considered,

each packet has the same possibility of being dis-

carded (about 30-40% depending on the case consid-

ered). When QoS is used, instead, the probability to

be delivered for each packet is proportional to its pri-

ority. Highest priority packets are delivered more than

90% of the times; lowest priority packets are deliv-

ered about 35% of the times. Obviously, the adoption

of a QoS mechanism does not change the total num-

ber of packets that are sent, it only changes the dis-

SECRYPT 2010 - International Conference on Security and Cryptography

248

tribution of these packets among the different priority

levels.

Figure 2 compares the number of packets sent for

each security level when the optimized system and the

Base-maxsec and Base-minsec cases are considered.

As it can be seen from the ﬁgure, the optimized node

tends to maximize the number of packets that are pro-

cessed by using the security suites number 3 and 7

which are to be considered the most secure ones avail-

able. Thus, our optimization system tends to guaran-

tee an higher security level to the packets.

Figure 3 compares the energy per byte spent by

the optimized system with the energy spent in all the

cases in which the optimization is not used. The op-

timization allows the system to spend less energy per

byte then in the Base-maxsec case. It also provides

the ability of saving energy with respect to the cases

in which security level 2 and security level 7 are al-

ways selected (Base-sec2 and Base-sec7). The Base-

minsec case is of course less energy hungry, but, at the

same time, it provides, in average, a lower level of se-

curity to packets. The same applies to the Base-sec4

case.

Figure 4 compares the number of packets sent by

the optimized system during the simulation period

with the ones sent by the non-optimized systems. The

optimized system is able to send an highest number

of packets with respect to more energy hungry modes.

Obviously, less energy hungry modes are able to send

more packets before ﬁnishing the battery.

Summarizing, the results show how our optimiza-

tion method provides QoS management while obtain-

ing the highest possible level of security that is com-

patible with the current system parameters.

It should be noticed that our results report the en-

ergy consumption of the whole node, even including

the sensing part. It is well known that, in these con-

ditions, the energy spent for transmission is not the

predominant part of the total energy consumption. In-

deed, the portion of energy devoted to communication

(not considering the energy used by the infrastructure)

is about 10% of the total consumed energy. For this

reason the differences in performances among differ-

ent cases might appear limited, even if they are not. In

fact, they are signiﬁcant if we focus our analysis only

to energy related to data transmission.

5 CONCLUSIONS AND FUTURE

WORK

In this paper we proposed a novel adaptation mecha-

nism to deal with secure and priority-based transmis-

sion of packets in WSNs. This optimization mech-

anism allows the system to survive long periods in

which the energy harvesting adopted might not be

able to provide energy. The algorithm, by perform-

ing QoS management, provides the ability to privilege

important (i.e., high priority) packets when the energy

available is scarce. Security settings are changed dy-

namically to provide the best security compatible with

the current system conditions.

Future work include reﬁnement and extension of

the methodologyproposed and, in particular,the addi-

tion of new capabilities such as, for example, chang-

ing dynamically the duty cycle of the network and/or

the monitoring period.

ACKNOWLEDGEMENTS

This work was partially supported and funded by

the Hasler Foundation under the Project AETHER+

(Grant No. 09083-2043-021). The paper reﬂects only

the view of the authors; the Hasler Foundation is not

liable for any use that may be made of the information

contained herein.

REFERENCES

Akyildiz, I. F., Su, W., Sankarasubramaniam, Y., and

Cayirci, E. (2002). Wireless sensor networks: a sur-

vey. Computer Networks, 38(4):393–422.

Alippi, C., Camplani, R., Galperti, C., and Roveri, M.

(2008). Effective design of wsns: From the lab to the

real world. In Sensing Technology, 2008. ICST 2008.

3rd International Conference on, pages 1–9.

Chandramouli, R., Bapatla, S., Subbalakshmi, K. P., and

Uma, R. N. (2006). Battery power-aware encryption.

ACM Trans. Inf. Syst. Secur., 9(2):162–180.

Chigan, C., Li, L., and Ye, Y. (2005). Resource-aware

self-adaptive security provisioning in mobile ad hoc

networks. In Wireless Communications and Network-

ing Conference, 2005 IEEE, volume 4, pages 2118–

2124Vol.4.

Derin, O., Ferrante, A., and Taddeo, A. V. (2009). Coor-

dinated management of hardware and software self-

adaptivity. Journal of Systems Architecture, 55(3):170

– 179. Challenges in self-adaptive computing (Se-

lected papers from the Aether-Morpheus 2007 work-

shop).

Ferrante, A., Piuri, V., and Owen, J. (2005). IPSec Hard-

ware Resource Requirements Evaluation. In NGI

2005, Rome, Italy. EuroNGI.

Großsch¨adl, J., Szekely, A., and Tillich, S. (2007). The en-

ergy cost of cryptographic key establishment in wire-

less sensor networks. In ASIACCS ’07: Proceedings

of the 2nd ACM symposium on Information, computer

and communications security, pages 380–382, New

York, NY, USA. ACM.

QOS AND SECURITY IN ENERGY-HARVESTING WIRELESS SENSOR NETWORKS

249

Keeratiwintakorn, P. and Krishnamurthy, P. (2006). Energy

efﬁcient security services for limited wireless devices.

In Proc. 1st International Symposium on Wireless Per-

vasive Computing, pages 1–6.

Lighfoot, L., Ren, J., and Li, T. (2007). An energy efﬁ-

cient link-layer security protocol for wireless sensor

networks. In Electro/Information Technology, 2007

IEEE International Conference on, pages 233–238.

Liu, S., Qiu, Q., and Wu, Q. (2008). Energy aware dynamic

voltage and frequency selection for real-time systems

with energy harvesting. In DATE ’08: Proceedings

of the conference on Design, automation and test in

Europe, pages 236–241, New York, NY, USA. ACM.

Liu, S., Wu, Q., and Qiu, Q. (2009). An adaptive schedul-

ing and voltage/frequency selection algorithm for real-

time energy harvesting systems. In DAC ’09: Pro-

ceedings of the Design and Automation Conference,

pages 782–787.

Moser, C., Brunelli, D., Thiele, L., and Benini, L. (2007a).

Real-time scheduling for energy harvesting sensor

nodes. Real-Time Syst., 37(3):233–260.

Moser, C., Chen, J.-J., and Thiele, L. (2008). Reward max-

imization for embedded systems with renewable ener-

gies. In Embedded and Real-Time Computing Systems

and Applications, 2008. RTCSA ’08. 14th IEEE Inter-

national Conference on, pages 247–256.

Moser, C., Thiele, L., Brunelli, D., and Benini, L. (2007b).

Adaptive power management in energy harvesting

systems. In DATE ’07: Proceedings of the confer-

ence on Design, automation and test in Europe, pages

773–778, San Jose, CA, USA. EDA Consortium.

Mura, M., Fabbri, F., and Sami, M. (2008). Modelling the

power cost of security in wireless sensor networks: the

case of 802.15.4. In Proceedings of IEEE ICT08, Saint

Petersburg, Russia.

Mura, M., Paolieri, M., Negri, L., Fabri, F., and Sami, M.

(2007). Power modeling and power analysis for ieee

802.15.4: a concurrent state machine approach. In

Proceedings of CCNC 2007, Las Vegas, USA.

Mura, M. and Sami, M. (2008). Code generation from stat-

echarts: Simulation of wireless sensor networks. In

Proceedings of DSD08, Parma, Italy.

Ravi, S., Raghunathan, A., Kocher, P., and Hattangady,

S. (2004). Security in embedded systems: Design

challenges. Trans. on Embedded Computing Sys.,

3(3):461–491.

Roundy, S., Steingart, D., Frechette, L., Wright, P., and

Rabaey, J. (2004). Power sources for wireless sensor

networks. In Wireless Sensor Networks, volume 2920

of Lecture Notes in Computer Science, pages 1–17.

Springer Berlin / Heidelberg.

Sastry, N. and Wagner, D. (2004). Security considerations

for ieee 802.15.4 networks. In WiSe ’04: Proceedings

of the 3rd ACM workshop on Wireless security, pages

32–42, New York, NY, USA. ACM.

Sean Convery (2004). Internetworking Technologies Hand-

book, chapter 49, pages 49–1 – 49–32. Cisco Press.

Wang, L., Yang, Y., Noh, D. K., Le, H., Abdelzaher, T., and

Ward, M. (2009). Adaptsens: An adaptive data col-

lection and storage service for solar-powered sensor

networks. In Proceedings of RTSS 2009.

SECRYPT 2010 - International Conference on Security and Cryptography

250
