SECURITY IN FUTURE MOBILE SENSOR NETWORKS

Issues and Challenges

Eliana Stavrou, Andreas Pitsillides

Department of Computer Science, University of Cyprus, P.O. Box 20537, Nicosia, Cyprus

George Hadjichristofi, Christoforos Hadjicostis

Department of Electrical and Computer Engineering, University of Cyprus, P.O. Box 20537, Nicosia, Cyprus

Keywords: Sensor networks, Security, Routing, Key management, Trust management.

Abstract: Existing security research in wireless sensor networks is based on specific assumptions about the nodes and

the network environment that are tied to specific usage scenarios. Typical scenarios consider sensor nodes

that are immobile and have pre-defined communication patterns. We argue that node mobility is a realistic

characteristic of sensor nodes that needs to be taken into consideration in future sensor networks. Mobility

capabilities can address the objective challenges raised in mission-critical applications, such as in disaster

relief, where their environment characteristics fluctuate over time. It is imperative to investigate the way

security is affected in mobile sensor networks and identify the challenges that will need to be addressed in

future security protocol design. We present our vision for future sensor networks

through a realistic scenario and discuss security gaps that are present in existing research for next generation

sensor networks.

1 INTRODUCTION

Wireless Sensor Networks (WSNs) have emerged in

a number of mission-critical application domains

(Garcia-Hernandez, Ibarguengoytia-Gonzalez and

Perez-Diaz, 2007), such as in healthcare, military

surveillance, and disaster mitigation and response.

The data sensitivity and the variability of attacks

(Chan and Perrig, 2003; Karlof and Wagner, 2003;

Wood and Stankovic, 2002, 2004) that can be

launched against a WSN have led researchers into

investigating a number of security aspects in WSNs

and proposing appropriate security protocols. So far,

research has been focused on investigating security

aspects in static WSNs. However, a radical shift in

the way WSNs are studied, designed, and deployed

is expected, since mobility features are starting to

emerge. For example, in large deployment areas, it is

often expensive to deploy sensor nodes to cover the

entire monitoring area. Similarly, in mission-critical

applications a number of attributes are required to be

monitored. For such reasons, (and due to the sensor

nodes’ constraints), having a node monitor all

required attributes is not be feasible. Instead, it is

preferable to deploy sensor nodes with different

sensing capabilities that can go mobile under

specific conditions providing in this way dynamic

monitoring coverage.

Mobility is not an unrealistic or undesirable

characteristic of sensor nodes as it can address the

objective challenges raised in mission-critical

applications. For example, disaster mitigation and

response (DMR) applications, e.g. fire monitoring,

aim to effectively and efficiently prevent hazards or

reduce the effect of disasters when they occur. The

mobilization of sensor nodes in DMR can support

the proactive and reactive emergency services and

also the communication of the emergency crew.

New challenges that have not yet been investigated

in the literature arise due to a number of reasons

such as: 1) the nature of disasters, e.g., fires, which

include a number of parameters that need to be taken

into consideration when implementing DMR

applications, and 2) these parameters can

dynamically drive the spread and impact of disaster

in unpredictable ways. Thus, realistic mobility-based

scenarios with WSNs need to be taken into

consideration in order to address these challenges

278

Stavrou E., Pitsillides A., Hadjichristoﬁ G. and Hadjicostis C. (2010).

SECURITY IN FUTURE MOBILE SENSOR NETWORKS - Issues and Challenges.

In Proceedings of the International Conference on Security and Cryptography, pages 278-286

DOI: 10.5220/0002987302780286

 SciTePress

and also to investigate the way security is being

formed/affected in sensor networks where nodes go

mobile.

This research work identifies a new mobility-

based fire monitoring scenario, utilizes it to study

security issues and requirements that arise due to

node mobility, and provides directions for future

security protocol designs in WSNs.

2 SYSTEM REQUIREMENTS

In this section we discuss our vision for the

requirements of next generation WSNs through a

real life scenario. WSNs have been successfully

deployed in a number of environmental applications.

A potential (realistic) forest fire-monitoring scenario

considers both fixed and mobile nodes to help the

user visualize the application domain.

A WSN-based forest fire-monitoring application

has a number of objectives that must be supported

by the sensor nodes operation and collaboration,

such as detecting and reacting to a fire in a timely

manner, effectively controlling the damage,

detecting arsonists, and promoting the emergency

team’s safety and collaboration.

In our scenario, we consider multiple sensor

nodes that move around in an area to collect specific

information regarding the environment and support

the application’s objectives. In Figure 1, we depict

the WSN forest fire-monitoring application where

the sensor nodes are categorized according to their

capabilities/functionality. Sensors of type 1 which

monitor temperature and humidity, and can detect

smoke, are deployed around the forest edge. Sensors

of type 2 monitor wind speed and direction and are

spread within the deployment area. Sensors of type 3

monitor motion and are equipped with cameras.

Sensors of type 4 are deployed on the helmets of the

emergency team and have type 1 and 2 sensing

capabilities. Sensors of type 5 are coordinators,

supporting connectivity between sensor nodes. The

data collected by a sensor of a specific type can

drive the moving patterns and behaviour of other

nodes. For example, when smoke is detected by type

1 nodes, sensors of type 3 are queried to send a

picture to the sink. If type 3 sensors are not in the

area, they are instructed to move towards the

infected areas.

Each node maintains routing paths to a control

centre, called the Base Station (BS) or sink, where

the observations are been forwarded for further

processing and decision making. Initially, the sensor

nodes move to predetermined locations based on

their sensing capabilities, where specific

observations are required. We assume that the

emergency team studies the deployment area and

plans how the sensor nodes of specific type are

spread to cover the area as required and support the

aforementioned application objectives.

After the network is deployed and sensor nodes

have moved to their initial location defined by the

emergency team, communication is established

among the nodes to support their activities. Nodes

must then have the capability to patrol the area and

collect the various data as well as adjust to possible

changes in the coverage area, such as in the case of a

falling tree (see Figure 1). Thus, compared to

previously studied scenarios, the network is

reformed dynamically based on the observations and

event detections. This reformation implies that the

WSN establishes a number of communication

patterns to support the collaboration of nodes that

are listed under the same or different category.

Summarizing, based on our aforementioned

scenario, we envision the existence of mobile sensor

networks that will utilize more complicated

communications patterns compared to the typical

source to BS communication. Moreover, they will be

required to adjust to changing areas of coverage

while being constrained by energy. Our focus in this

paper is on security aspects.

Figure 1: A forest fire-monitoring WSN application.

3 SECURITY CHALLENGES

Security (Djenouri, Khelladi and Badache, 2005;

Wang, Attebury and Ramamurthy, 2006; Walters,

Liang, Shi and Chaudhary, 2006) is a key factor in

protecting sensitive applications and data

communications. Challenges arise as emerging

applications evolve to support mobility, required in

I I

Falling

Tree

Sensornode

Type1:temperature,humidity,andsmoke

Type2:wind

Type3:video

Type4:type1and2

Type5:coordinators

BS:BaseStation

SECURITY IN FUTURE MOBILE SENSOR NETWORKS - Issues and Challenges

279

more dynamic environments. Mobility in WSNs

creates a new security paradigm as communication

patterns are dynamically formed and therefore

investigations must be made to identify ways in

which security is affected in such dynamic

environments. Currently, one of the biggest concerns

is that existing security mechanisms in static WSNs

may not be capable of supporting security

requirements in dynamic mobile environments.

Therefore, we need to investigate if existing security

mechanisms can be applied/adopted to the new

application paradigm and also if new security

challenges dictate the creation of new security

mechanisms.

Connectivity is one of the most important

attributes that mobile sensor nodes must establish to

support network communication. In this paper we

investigate the routing operation (Akyildiz, Su,

Sankarasubramaniam, Cayirci, 2002; Al-Karaki and

Kamal, 2004) as it is one of the fundamental

operations in WSNs that facilitates the establishment

of communication links between sensor nodes and

packet delivery. Securing the routing operation

involves two main aspects: (i) protecting the

confidentiality and integrity of the control and data

packets that are routed to the intended destination,

and (ii) establishing routing paths to the destination

in a way that promotes a highly available and

reliable environment. For each aspect, an

appropriate security area can be considered and

supports specific security requirements (Carman,

Kruus and Matt, 2000; Wang, Attebury and

Ramamurthy, 2006; Walters, Liang, Shi and

Chaudhary, 2006). The main security requirements

in a mobile environment are: (i) network reliability,

availability, and resiliency; (ii) authentication of

nodes; (iii) data integrity; and (iv) data

confidentiality.

These requirements are provided through a

number of functionalities that introduce security in

the network. Key management schemes can be used

to establish security associations (SAs) between

communicating parties and protect the routing path

establishment procedures and the data forwarding

operations against attacks launched by malicious

nodes. Trust management schemes can be used to

aid sensors to select the next-hop node based on its

reputation. Multipath routing support can enhance

the packet reliability (Ganesan, Govindan, Shenker

and Estrin 2002; Ye, Zhong, Lu, Zhang 2005). All

the aforementioned security areas have been

substantially investigated in fixed WSN

environments. However, security issues and

challenges in mobile WSNs have not been given

much attention. Next, we briefly analyze the

approach taken in each security area and then

identify the security challenges raised due to the

nodes’ mobility.

3.1 Key Management

Authentication is required prior to the deployment of

any security mechanism as it facilitates the

establishment of SAs. SAs imply some level of trust

among nodes as partners verify each other’s identity.

A Key Management System (KMS) creates,

distributes, and manages these identification

credentials used in the establishment of SAs. The

challenges with key management increase in future

sensor networks since sensor nodes do not only have

limited battery power and computation capability

but they now require more complicated and dynamic

SA establishments. Furthermore, solutions need to

be able to address scalability as future sensor

networks will be comprised of thousands of sensor

nodes.

Key management in sensor networks typically

uses Key encryption keys (KEKs) that are in turn

used to (re-)distribute session keys and secure

communication among nodes by establishing SAs.

Mobility of sensor nodes requires that session keys

be changed more frequently to assure resilience

against attacks and to accommodate changes in the

characteristics of the networks, such as topology,

number of nodes, and their individual role (e.g.,

cluster head).

In the near future, we envision that sensor nodes

will continue to use symmetric keys since they have

lower computational requirements than asymmetric

keys. It may still, however, be helpful to harness

some of the benefits of asymmetric cryptography

(such as lower key distribution overhead) to

initialize the configuration of symmetric keys on the

nodes. At present the overhead of calculating an

ECC point multiplication for public key

cryptography in a sensor device is not high [ Aranha,

Oliveira, Lopez, and Dahab, 2009.]. Previous

analysis of static scenarios assumed that the

connectivity patterns are limited from source to BS.

In our aforementioned scenario we require more

complicated communication patterns, which may

imply a relatively larger number of SAs. Even

though research in (Mizanur Rahman, Nasser and

Saleh, 2008) focused on minimizing the generation

of keys based on the traffic patterns in the network,

they did not take into account the existence of large

sensor networks. Scalability issues need to be

addressed more aggressively. It is also important to

mention that if nodes utilize symmetric keys then the

management complexity increases towards a

SECRYPT 2010 - International Conference on Security and Cryptography

280

maximum n(n-1)/2 keys, when shifting towards a

mesh type of connectivity in terms of SAs (i.e., all

the nodes in the network trust one another).

Previous solutions in the literature that utilized a

network wide symmetric key for all the nodes no

longer constitute solutions for key management.

Even if the network-wide symmetric key is used to

establish new keys per pair this strategy leads to

problems with synchronization during periodic

updates of keys in the face of mobility.

Furthermore, solutions that suggest the deletion of

the network-wide key for added security do not

generally work as they imply the existence of a

closed system that does not accept new sensor

nodes.

Another aspect that has not been taken into

account is the trustworthiness of a BS or the

inference of the existence of SAs between the BS

and all the sensor nodes. This approach does not

scale and raises issues of security in terms of the BS

being a centralized point of attack. One potential

solution is to introduce multiple BSs in WSNs, but

this has to be investigated carefully as multiple BSs

increase the complexity in terms of data flow

directions and introduce extra key management

overhead (the relationship between SAs and BSs

becomes many-to-many).

A common approach for key management is

through the use of a random key pre-distribution

protocol (Eschenauer and Gligor, 2002;Chan, Perrig

and Song, 2003; Liu and Ning, 2005; Liu, Ning and

Du, 2005; Guorui, Jingsha and Yingfang, 2006;

Ting, Shiyong and Yiping, 2007). (An investigation

of the resilience of key management for random key

pre-distribution is offered in (Yulong, Jianfeng and

Qingqi, 2007)). Each node has a subset of symmetric

keys that is randomly selected from a large pool of

keys and communicates with nodes that have a

similar key pool. The limitation of these KMSs is

that they do not dynamically adjust to accommodate

new nodes or changing environment conditions in

the network, such as battery limitations,

heterogeneous nodes, topology changes, or coverage

area changes. Thus, it is difficult to establish the

required number of SAs by discovering common

keys. Moreover, an attacker, can take advantage of

mobility and more easily compromise enough nodes

to obtain a large number of symmetric keys and thus

break the security of the system. The authors in (Liu,

Ning and Du, 2005) and (Du, Deng, Han, Chen

Sand and Varshney, 2004) have alleviated the

limitation of building SAs in a changing

environment by ensuring that nodes that are closer

together have more common keys. This solution

took advantage of pre-deployment knowledge prior

to the network deployment. However, this

assumption does not fully accommodate the scenario

of mobile sensors and dynamically changing sensing

areas, such as in the case of a falling tree (see Figure

1). A promising solution that avoids pre-deployment

knowledge of sensor nodes and accommodates an

open system was proposed by Anjum (2007). He

proposed a scheme that utilized anchor nodes with

higher radio range, which execute location

dependent key management. Even though this

solution might be applicable to future sensor

networks it requires careful deployment of anchor

nodes, which makes it less flexible. In addition, it

needs to be augmented to take care of certain

limitations. More specifically, nodes that are

inserted start with the same initial network key and

the anchor nodes transmit the same nonces for key

negotiations. This feature prevents any network-

wide rekeying of the sensor nodes, which makes the

network more vulnerable to attacks. The anchor

nodes would also need to be made mobile and their

movements would need to be carefully selected to

provide full coverage of the network and maximize

the availability of the key management service in the

WSN. Thus, the scenario in Figure 1 would need to

take into account a hybrid network of mobile ad hoc

(represented by the anchor nodes) and sensor

networks, where one network helps with the

deployment of the other one. A new hybrid KMS

solution must be designed that will accommodate a

higher key management complexity.

Another aspect that would need more

investigation with regards to key management is

energy in light of nodes that utilize the active/sleep

state (Riaz, Ali, Kim, Ahmad and Suguri, 2006).

Such a scheme can not apply in our scenario as it

assumes the existence of densely deployed WSNs,

which may not necessarily be the case in the future

since mobility may be used to provide full coverage

of a dynamically changing environment.

Furthermore, this methodology creates

complications for key management for cases where

nodes are allowed to enter sleep mode. In addition,

this scheme needs to be augmented as it suffers from

the design of having one non-changing initial

network/global key.

A challenge that has not been given a lot of

attention in sensor networks with regards to key

management is revocation. A centralized solution

for revocation is not applicable as the BS that

broadcasts such revocations needs to be able to

communicate with all the mobile sensor nodes. In

addition, it is not clear how the BS will acquire the

information, such as bad behaviour, required to

guide revocation decisions. Thus, such a solution is

SECURITY IN FUTURE MOBILE SENSOR NETWORKS - Issues and Challenges

281

not feasible. A distributed revocation scheme has

been proposed in (Eschenauer and Gligor, 2002) and

enables the neighbours of a compromised node to

revoke it. This approach still suffers from the

limitations of broadcast communication, which

makes it slower in terms of response and increases

the overhead in the network as all the nodes need to

remember the grading of their peers. Furthermore, it

is not clear how this grading can be amended when

mistakenly taking a node to be malicious. An

effective revocation needs to be more responsive,

execute localized revocation, and be flexible in

terms of its assessments. This needs to allow for the

remuneration of a node’s reputation when its

behaviour is improving and for harsher measures if

its behaviour switches to very bad. Basically, this

approach needs to take into account a node’s

cooperation over time. This is a topic that has been

investigated in more depth through social

networking and game theory. It is important to note

that the authors in (Chan, Gligor, Perrig and

Muralidharan, 2005) have investigated revocation

within time bounds to address the notion of stale

votes that may lead to erroneous revocation of

nodes. They used hop-limited local broadcast of

reputation information nodes but allowed only one

network-wide broadcast when the final revocation

decision is taken. Thus, the network overhead was

kept at a minimum and communication was

successful assuming there was connectivity. These

solutions form a good basis for revocation, but need

to be extended to accommodate more dynamic

scenarios where mobility coupled with energy

constraints introduces new challenges.

Summarizing, key management should be

carefully studied in the context of future networks as

it lies at the heart of the network defences. To

support secure routing, key management will need to

supply the necessary keys to enable point-to-point,

point-to-cluster, intra-cluster communication, etc.

These modes of communication must be supported

to a large scale and in multiple directions between

the network nodes. This is a paradigm that is

different compared to existing sensor networks.

Inferring pre-deployment knowledge and random

key pre-distribution to aid key management is not

always feasible as the area of coverage change and

nodes move in different direction. Other aspects that

need careful study are revocation and the impact of

key management on energy schemes or the reverse

(i.e., how energy schemes affect the operation of the

key management system).

3.2 Multipath Routing Support

In mission-critical applications, what values the

most is observation data that indicates if a critical

event has occurred. Therefore, establishing network

reliability and resiliency can support the timely

detection of critical events and decision making. A

reliable and resilient routing operation means that

the data is delivered to the intended destination, even

in the face of attacks. The common practice in

resource-constrained WSNs is to deploy single path

routing. Approaches in multipath routing apply to

single path routing; thus, we only focus on multipath

routing in our investigation. Generally, failure of

nodes along the path would mean failure of the path

and loss of data. This is unacceptable in mission-

critical applications that rely on the timely delivery

of observations to support application objectives.

Currently, a number of WSN-based multipath

routing protocols integrated with security

mechanisms have been proposed in the literature

(Deng, Han and Mishra, 2002; Lou and Kwon, 2006;

Ouadjaout, Challal, Lasla and Bagaa, 2008; Stavrou

and Pitsillides, 2010; Ma, Xing and Michel, 2007),

considering fixed sensor nodes. In these protocols, a

source node discovers its neighbouring nodes and

deploys multipath routing to forward packets to the

intended destination, supporting a reliable and

resilient environment.

In a mobile WSN environment, a number of

challenges are raised regarding multipath routing:

a) Routing does not converge to a stable state due

to frequent node movements. The main concern is

that the route discovery process needs to be initiated

frequently to discover new routes to the destination.

b) Multipath routing is by default a costly

operation in terms of communication and energy

consumption. Mobility further increases a node’s

energy consumption and so does the usage of

cryptographic mechanisms by the routing protocol

due to the frequent updates. Furthermore, end-to-end

versus hop-to-hop security should be considered in

the routing protocol design in order to minimize the

SAs established between sensor nodes and the usage

of cryptographic algorithms, and conserve nodes’

resources. In addition, mobile routing protocols in

WSNs should be designed such that mobile nodes

provide different multipath levels (in terms of the

path number) based on the packet content in order to

balance the required packet reliability e.g., handle

differently smoke data and temperature data in our

scenario.

c) Moving nodes contributing in multipath routing

do not know their surrounding nodes and therefore

SECRYPT 2010 - International Conference on Security and Cryptography

282

do not know which nodes to trust for collaboration.

The challenge here is to distinguish between trusted

and untrusted nodes in order to forward packets

through trusted nodes and increase the possibility for

a successful packet delivery. Trust management is

treated in the following subsection.

3.3 Reputation - based Trust

Management

Reputation-based trust schemes, add another layer of

security that goes beyond the capabilities of the

utilized cryptographic mechanisms. The idea is to

evaluate the behaviour of nodes over time in order to

guide collaboration in the network. For example,

sensor nodes may decide which paths to use based

on the reputation ratings of their peers.

Reputation metrics may involve the capability of

correct packet forwarding of sensors, intrusion

detection results, recommendations from neighbour

nodes, etc. A number of reputation-based trust

schemes have been proposed in the literature. For

example, (Marti, Giuli, Lai and Baker, 2000)

proposed a reputation-based scheme composed of a

watchdog and a pathrater module in order to

determine if intermediate nodes are indeed

forwarding the received packets. The watchdog node

overhears the communication to verify whether its

neighbouring node has forwarded the packet. Based

on the result, the pathrater rates each path and

chooses a path to avoid misbehaving nodes. The

concept of monitoring and rating forms the basic

functionality of a reputation trust-based framework

that is applied according to the aspects that need to

be evaluated. In (Tanachaiwiwat, Dave, Bhindwale

and Helmy, 2003; Yao, Kim, Lee, Kim and Jang,

2005) authors define reputation metrics related to

cryptographic operation, availability of nodes to

provide service, and nodes behaviour that can

indicate malicious activity. In (Crosby, Pissinou and

Gadze, 2006), authors follow a similar trust

evaluation approach to aid the election of

trustworthy cluster heads. Another approach is taken

by (Liu, Abu-Ghazaleh and Kang, 2007) where they

not only favour well behaving nodes for each

successful packet forwarding, but also penalize

suspicious nodes that lie about their contribution to

routing.

The existing trust management schemes cannot

be fully applied in mobile WSNs application

because due to mobility it is difficult to monitor the

behaviour of mobile nodes in order to compute their

reputation value. The idea of partitioning the

network in clusters such as in (Crosby, Pissinou,

Gadze and 2006) aids trust management by allowing

cluster nodes to check for malicious behaviour and

verify falsified information. Clustering has been

promoted due to its energy saving capabilities within

the network. However, clustering cannot always

exist in future scenarios due to mobility, and due to

the fact that changes in the sensing area may require

that clusters be reformed dynamically. Thus, the

underlying difficulty in terms of mobile sensors is to

designate monitoring nodes in a mobile environment

such that they can effectively record the behaviour

of all the nodes in the network. In addition, the

reputation metrics of a mobile node need to be

globally trusted so that if it needs to cooperate with

other nodes while moving around its reputation will

be trusted by its peers. The trust management

scheme should provide different trust levels such as

in (Yao, Kim, Lee, Kim, Jang, 2005), but at the

same time create semantics for the various trust

levels so that they can match specific functionalities

within the networks. For example, different levels

of trust may indicate authorization to forward a

packet or authorization to accept sensing

observations for a particular metric. Also, for the

case where packets need to be forwarded through

nodes with low reputation values (due to lack of

trusted nodes), there needs to be integration with

security mechanisms such that security

enhancements are utilized. Reputation-based trust

management schemes can be very useful, but the

trade-off between reliability, compromization risk,

and performance needs to be balanced.

4 SECURITY AND ENERGY

EFFICIENCY

Energy is the most important resource in WSNs due

to the limited resources of sensor nodes (Akyildiz,

Su, Sankarasubramaniam and Cayirci, 2002).

Usually, sensor nodes use batteries as their main

energy source and it is not always feasible to replace

them when depleted. There are several sources of

energy consumption in sensor networks, such as

when communicating, sensing and processing

information, with the former being the most energy

demanding operation. By adding extra functionality

in a sensor network, it further contributes to the

overall energy consumption. A potential energy

depletion of some of the sensor nodes can greatly

affect the survivability of the network, since it can

cause the degradation of the routing operation. This

depletion can eventually lead to network partitions

SECURITY IN FUTURE MOBILE SENSOR NETWORKS - Issues and Challenges

283

prohibiting observations on a specific area and

affecting the successful operation of the application.

The challenge is even greater when mobility is

introduced in the network. Mobile nodes require

energy to be able to move. The amount of energy

being consumed is dependent on the movement

frequency and the distance that sensor nodes have to

cover.

In terms of key management, a mobile node has

to establish SAs with other nodes along the motion

path. This task requires extra energy due to the

communication and processing required, that is

dependent on the number of SAs that need to be

negotiated and established. The challenge for mobile

nodes is to establish the minimum required number

of SAs that utilize cryptographic schemes for secure

communication taking into account paths that

change dynamically, and still supporting an

acceptable security level, adequate to protect the

network environment.

In terms of supporting reliable and resilient routing,

multipath routing is typically recommended to be

deployed. However, in multipath routing, more than

one path is established to forward a packet from

source to destination. This redundancy means that

communication overhead is increased as the number

of alternative paths increases, leading to extra

energy consumption. Node mobility leads to a

dynamic environment, where communication links

change according to nodes motion. Since mobile

nodes are not aware of their surrounding

environment, they have to re-initiate the route

discovery procedure in order to discover different

routes to the destination. This is a costly operation in

terms of energy consumption that greatly affects the

lifetime of mobile sensor nodes.

In terms of trust management, node mobility

leads to uncertainty about trust in the surrounding

environment. Reputation-based information should

be requested from other nodes/entities to aid mobile

nodes decide which nodes to trust and use for

forwarding packets. This uncertainty about trust also

applies in the opposite direction. That is, when a

mobile node moves to a new area and requests to

establish communication with a neighbouring node,

that neighbouring node is not certain about the

mobile node’s trustworthiness. It has to request

reputation-based information from another entity.

All these actions to support trust management in a

mobile environment require again extra

communication between sensor nodes, which lead to

increased energy consumption.

A trade-off between security and energy

efficiency in mobile WSNs can only be achieved if

we have a clear understanding of the environment

and the application’s security needs and objectives.

It is clear that mobile sensor nodes consume much

more energy than static nodes. Therefore, to promote

the survivability of the network, nodes with

heterogeneous resources should be considered.

Investigations should focus on how heterogeneity

can aid sensors mobility and permit the

implementation of resource-aware security

mechanisms.

5 CONCLUSIONS

This paper investigated security issues and

challenges in next generation mobile sensor

networks. State of the art in security in sensor

networks has focused on fixed sensor networks with

pre-defined communication patterns over fixed

areas. We argued that changing deployment areas,

heterogeneous sensors, and dynamic communication

patterns driven by mobility and varying sensing

requirements would be required in next generation

sensor networks. We have presented a realistic fire

scenario with multiple sensors that motivated such a

future direction. Based on our investigation with

regards to key management, routing, trust

management, and energy, we identified issues that

reveal the inflexibility of systems and functionalities

due to the inherent built-in assumptions about the

environment, the nodes, their roles, the data, and the

communication patterns. It is clear that we need

solutions that can be dynamically adjusted based on

the requirements of the data flows that may depend

on the communication of heterogeneous sensor

nodes, which may have varying roles in the network.

In addition, these solutions will need to be robust in

the face of mobility, energy limitations, and

changing or unknown coverage areas.

ACKNOWLEGEMENTS

This research work is supported by ASPIDA

(KINHT/0506/03) and by the TRUST project,

funded by Cyprus Research Promotion Foundation

(ΤΠΕ/ΠΛΗΡΟ/0308(ΒΕ)/10).

REFERENCES

Akyildiz I. F., Su W., Sankarasubramaniam Y. and Cayirci

E., (2002), Wireless Sensor Networks: A Survey,

SECRYPT 2010 - International Conference on Security and Cryptography

284

Computer Networks, Elsevier Journal, 38(4), 393-422.

Al-Karaki, J. N. and Kamal, A. E., (2004). Routing

techniques in wireless sensor networks: a survey,

IEEE Wireless Communications, 11(6), 6-28.

Anjum F. (2007). Location dependent key management in

sensor networks without using deployment

knowledge. 2nd International Conference on

Communication Systems Software and Middleware, 1-

10.

Aranha D., Oliveira L. B., Lopez J., Dahab R. (2009).

NanoPBC: Implementing Cryptographic Pairings on

an 8-bit Platform. CHILE.

Carman D. W., Kruus P. S. and Matt B. J., (2000).

Constraints and approaches for distributed sensor

network security, NAI Labs Technical Report #00-010

Chan, H., Perrig, A., 2003, Security and Privacy in Sensor

Networks, IEEE Computer Magazine, pp. 103-105

Chan H., Perrig A. and Song, D. ( 2003). Random Key

Predistribution Schemes for Sensor Networks. IEEE

Security and Privacy Symposium, 197–213.

Chan H., Gligor V.D., Perrig A. and Muralidharan G.,

(2005 July-September). On the distribution and

revocation of cryptographic keys in sensor networks.

IEEE Transactions on Dependable and Secure

Computing, 2(3), 233- 247.

Crosby G. V., Pissinou N. and Gadze J. (2006). A

Framework for Trust-based Cluster Head Election in

Wireless Sensor Networks, Proceedings of the Second

IEEE Workshop on Dependability and Security in

Sensor Networks and Systems

Deng J., Han R. and Mishra S., (2002). INSENS:

Intrusion-Tolerant Routing in Wireless Sensor

Networks, Technical Report CUCS-939-02,

Department of Computer Science, University of

Colorado

Djenouri, D., Khelladi, L., Badache, A.N., (2005). A

survey of security issues in mobile ad hoc and sensor

networks, IEEE Communications Surveys & Tutorials,

7(4), 2- 28.

Du W., Deng J., Han Y S., Chen Sand Varshney, P. K.

(2004 April). A key management scheme for wireless

sensor networks using deployment knowledge.

INFOCOM.

Eschenauer L. and Gligor V. ( 2002 November). A Key

Management Scheme for Distributed Sensor

Networks. 9th ACM Conference. Computer. and

Communications Security, 41-47.

Ganesan D., Govindan R., Shenker S. and Estrin D.,

(2002). Highly-Resilient Energy-Efficient Multipath

Routing in Wireless Sensor Networks, ACM Mobile

Computing and Communication Review (MC2R), 1(2).

Garcia-Hernandez C. F., Ibarguengoytia-Gonzalez P. H.,

Garcia-Hernandez J. and Perez-Diaz J. A. (2007).

Wireless sensor networks and application: a survey,

International Journal of Computer Science and

Network Security (IJCSNS), 7(3).

Guorui L., Jingsha H. and Yingfang F. (2006). A hexagon-

based key predistribution scheme in sensor networks.

International Conference on Parallel Processing

Workshops, 180.

Karlof C. and Wagner D. (2003). Secure routing in

wireless sensor networks: Attacks and

Countermeasures, IEEE International Workshop on

Sensor Network Protocols and Applications, 113-127.

Liu K., Abu-Ghazaleh N. and Kang K. (2007). Location

verification and trust management for resilient

geographic routing, Location verification and trust

management for resilient geographic routing, 67(2),

215-228.

Liu D., Ning P. and Du W. (2005, September). Group-

Based Key Pre-Distribution in Wireless Sensor

Networks. ACM Workshop on Wireless Security

(WiSe ), 11–20.

Liu D. and Ning P. (2005). Improving Key Pre-

Distribution with Deployment Knowledge in Static

Sensor Networks. ACM Trans. Sensor Networks, 204–

39.

Lou W., Kwon Y., (2006). H-SPREAD: a hybrid

multipath scheme for secure and reliable data

collection in wireless sensor networks. IEEE

Transactions on Vehicular Technology, 55(4), 1320 –

1330.

Mizanur Rahman Sk. Md., Nasser N. and Saleh K. (2008).

Identity and Pairing- Based Secure Key Management

Scheme for Heterogeneous Sensor Networks. IEEE

International Conference on Wireless and Mobile

Computing, Networking and Communication, 423-

428.

Ma R., Xing L. and Michel H. E., (2007, May). A New

Mechanism for Achieving Secure and Reliable Data

Transmission in Wireless Sensor Networks. The 2007

IEEE Conference on Technologies for Homeland

Security, 274-279.

Marti S., Giuli T., Lai K., and Baker M., (2000).

Mitigating routing misbehavior in mobile ad hoc

networks, In Proceedings of MOBICOM

Ouadjaout A., Challal Y., Lasla N. andBagaa, M., (2008

March) SEIF: Secure and Efficient Intrusion-Fault

Tolerant Routing Protocol for Wireless Sensor

Networks, Third International Conference on

Availability, Reliability and Security (ARES), 503-

508.

Riaz R., Ali A. Kim K. Ahmad H. F. and Suguri, H,

(2006). Secure Dynamic Key Management for Sensor

Networks. Innovations in Information Technology, 1-

Stavrou E., Pitsillides A., (2010), A survey on secure

multipath routing protocols in WSNs, accepted for

publication, Computer Networks, Elsevier Journal,

http://www.netrl.cs.ucy.ac.cy/index.php?option=com_

jombib&Itemid=60

Tanachaiwiwat S., Dave P., Bhindwale R., Helmy A.,

(2003). Secure Locations: Routing on Trust and

Isolating Compromised Sensors in Location-aware

Sensor Networks. The First ACM Conference on

Embedded Networked Sensor Systems (SenSys).

Ting Y.,Shiyong Z. and Yiping Z. (2007). A Matrix-Based

Random Key Predistribution Scheme for Wireless

Sensor Networks. IEEE International Conference on

Computer and Information Technology, 991-996.

SECURITY IN FUTURE MOBILE SENSOR NETWORKS - Issues and Challenges

285

Walters J. P., Liang Z., Shi W. and Chaudhary V., (2006).

Wireless Sensor Networks Security: A Survey,

Security In Distributed, Grid and Pervasive

Computing, CRC Press

Wang Y., Attebury G. and Ramamurthy B. (2006). A

survey of security issues in wireless sensor networks,

IEEE Communications Surveys & Tutorials, 8, (2), 2 –

23.

Wood A. D. and Stankovic J. A., (2002). Denial of Service

in Sensor Networks, IEEE Computer, 35(10), 54-62.

Wood A. D. and Stankovic J. A. (2004). A Taxonomy for

Denial-of-Service Attacks in Wireless Sensor

Networks, Handbook of Sensor Networks: Compact

Wireless and Wired Sensing Systems, CRC Press

Ye F., Zhong G., Lu S. and Zhang L.,( 2005). GRAdient

broadcast: A robust data delivery protocol for large

scale sensor networks, In ACM Wireless Networks

(WINET), 11(2).

Yao Z., Kim D., Lee I., Kim K. and Jang J., (2005). A

Security Framework with Trust Management for

Sensor Networks, Workshop of the 1st International

Conference on Security and Privacy for Emerging

Areas in Communication Networks,190-198.

Yulong S., Jianfeng M. and Qingqi P. (2007). Research on

the Resilience of Key Management in Sensor

Networks. International Conference on Computational

Intelligence and Security,716-720.

SECRYPT 2010 - International Conference on Security and Cryptography

286
