SIDE-CHANNEL ATTACK ON THE HUMANAUTH CAPTCHA

Carlos Javier Hernandez-Castro, Arturo Ribagorda

Security Group, Department of Computer Science, Carlos III University, 28911 Leganes, Madrid, Spain

Yago Saez

EVANNAI Group (Artiﬁcial Neural Networks and Evolutionary Computation)

Carlos III University, Computer Science Department, Madrid, Spain

Keywords:

CAPTCHA, HumanAuth, Image labeling, Watermarking, Automatic classiﬁcation.

Abstract:

We propose a new scheme of attack on the HumanAuth CAPTCHA which represents a signiﬁcant shortcut to

the intended attacking path, as it is not based in any advance in the state of the art on the ﬁeld of image recog-

nition. After analyzing the HumanAuth image database with a new approach based on statistical analysis and

machine learning, we conclude that it cannot fulﬁll the security objectives intended by its authors. Then, we

analyze which of the studied parameters for the image ﬁles seem to disclose the most valuable information for

helping in correct classiﬁcation, arriving at a surprising discovery. We also analyze if the image watermarking

algorithm presented by the HumanAuth authors is able to counter the effect of this new attack. Our attack

represents a completely new approach to breaking image labeling CAPTCHAs, and can be applied to many

of the currently proposed schemes. Lastly, we investigate some measures that could be used to increase the

security of image labeling CAPTCHAs as HumanAuth, but conclude no easy solutions are at hand.

1 INTRODUCTION

The last decade has seen increasing interest in abusing

services provided in the Internet, mainly for economi-

cal reasons. There has been misuse of services like e-

mail account creation for spam sending and phishing,

abuse of sites where anonymous posting is encour-

aged (Wikipedia, blogs comments, news sites, etc.)

for adding links for commercial promotion, harass-

ment or vandalism. There has also been abuse of re-

mote voting mechanisms (Hernandez, 1997). Auto-

matic (script-guide) site wandering has also been de-

scribed as a way to facilitate resource consumption

and thus remote denial-of-service attacks. Anony-

mous abuse of on-line games (Golle and Ducheneaut,

2005), inclusive for commercial promotion, is not

new. Other denial-of-service attacks on public post-

ing sites (like employment listings or CV reception

e-mails addresses) is also possible. Thus, there are

lots of sounding economical reasons to abuse services

provided through the Internet.

The main trend to prevent this automatic abuse has

been to develop the ability to tell humans and com-

puters apart - remotely and through an untrustworthy

channel. Many tests -generically called CAPTCHAs

or HIPs

- have been developed with that aim. Those

tests rely on capacities inherent to the human mind

but supposedly difﬁcult for computers, problems that

have been traditionally hard to solve algorithmically

in computers (as problems that still remain wide open

for Artiﬁcial Intelligence researchers).

Moni Naor seems to have been the ﬁrst (Naor,

1996) to propose theoretical methods of telling apart

computers from humans remotely to preventthe abuse

of web services. In 1997, primitive CAPTCHAs were

developed by Andrei Broder, Martin Abadi, Krishna

Bharat, and Mark Lillibridge to prevent bots from

adding URLs to their search engine (Abadi, 1996).

The term CAPTCHA was coined in 2000 by Luis von

Ahn, Manuel Blum, Nicholas Hopper and John Lang-

ford of Carnegie Mellon University (Ahn et al., 2003).

At the time, they developed the ﬁrst CAPTCHA to be

used by Yahoo. Those earlier designs were mostly

text-based: the computer chose a random sequence

Completely Automated Public Turing test to tell Com-

puters and Humans Apart

Human Interactive Proof

Javier Hernández-Castro C., Ribagorda A. and Saez Y. (2010).

SIDE-CHANNEL ATTACK ON THE HUMANAUTH CAPTCHA.

In Proceedings of the International Conference on Security and Cryptography, pages 59-65

DOI: 10.5220/0002994000590065

 SciTePress

of letters and rendered them in an image after apply-

ing different kinds of distortions. The human chal-

lenger, supposedly far better than a computer in char-

acter recognition, was to identify the characters. But

even after graphic distortion and degradation, some

approaches have been able to “read them and thus

solve the test automatically around 92% of the time

(Mori and Malik, 2003), specially so when it is pos-

sible to divide the graphic into its constituent letters.

Some approaches have focussed on making this divi-

sion (segmentation) harder, typically to the expense

of making it also harder to the human challenger.

Some CAPTCHAs that rely on similar grounds

as text CAPTCHAs may seem slightly stronger, but

are also more difﬁcult for the common user, so can

only be used as special-purpose CAPTCHAs for cer-

tain types of human clients. Among them there

is MAPTCHA, the Mathematical CAPTCHA, that

shows a math formula and asks the user its numeri-

cal solution. Similar CAPTCHAs have been shown to

be easier than expected (Hernandez-Castro and Rib-

agorda, 2009a).

1.1 Image CAPTCHAs

General vision seems to be a harder problem than

character recognition, so more designs have focused

on using pictures instead - even though most of those

CAPTCHAs do not really rely on a “general vision

problem but in a downsized version of categorizing

images.

Figure 1: Results from Google Image Search for “river.

Chew and Tygar (Chew and Tygar, 2004) were

the ﬁrst to use a set of labelled images to produce

CAPTCHAs challenges. For that purpose, they used

the labelled associated with images in Google Im-

age Search. This technique is not well suited for

CAPTCHAs, as Google relates a picture to its de-

scription and its surroundings (ﬁgure 1).

Ahn and Dabbish (von Ahn and Dabbish, 2004)

proposeda new way to label images by embedding the

task as a game, the “ESP game (ﬁgure 2). However, it

has a ﬁxed number of object classes (70) and the im-

age database seems not large enough. The site Hot-

Captcha.com (ﬁgure 3) used a large-scale human la-

beled database provided by the HotOrNot.com web-

Figure 2: The ESP game.

site, a site that invites users to post photos of them-

selves and rate others’ in a numerical scale of “hot-

ness. This proposal is no longer active, as in January

of 2009, HotCaptcha.com was down. Oli Warner had

the idea of using photos of kittens to tell computers

and humans apart (Warner, 2006).

The main trend in image-labeling CAPTCHAs has

been to use already classiﬁed images, either from in-

ternal databases or “crowd computing (typically us-

ing on-line databases) of pictures. The ﬁrst proposal

was KittenAuth, which features nine pictures of ani-

mals, only three of which are feline. Its database of

pictures is small enough (< 100) to manually clas-

sify them, and this limitation seems troublesome even

if we apply new methods involving image distortion.

ASIRRA (Elson et al., 2007) uses a similar approach

but using a giant database of more that 3 million pho-

tos from Petﬁnder.com, a web-site devoted to ﬁnd-

ing homes for homeless pets. It has been later shown

weak against machine learning attacks (Golle, 2008)

and side-channel attacks (Hernandez-Castro et al.,

2009).

HumanAuth, the CAPTCHA that we analyze in

this article, is somewhat related to both KittenAuth

and ASIRRA. It is also a image-labeling CAPTCHA,

that uses an internal database of pictures that depict

items that are either artiﬁcial (a car, a bar, a wheel)

or natural (a bird, a river, etc.). The user has to select

the ones that are natural, that is, depict no artiﬁcial

item. HumanAuth is a very interesting proposal in

many terms: it proposes a picture classiﬁcation prob-

lem that goes well beyond two different types of pic-

tures (as KittenAuth and ASIRRA), thus relying on a

harder (from the AI standpoint) problem, as solving it

using the intended path means understanding what a

picture represents, and then deciding if that item is or

not artiﬁcial. On the other point, it is also one of the

fewCAPTCHAs available for vision impaired people,

as every picture is associated to a description (“green

ﬂowers, “wall paint, etc.). A problem with Huma-

nAuth is that the database of pictures it proposes is

small, although it includes a watermarking algorithm

to difﬁcult indexing (of pictures: not of descriptions).

The attack path we propose here is usable against any

image-labelingCAPTCHA, and we have selected Hu-

manAuth as an example because of the included pic-

ture watermarking algorithm.

SECRYPT 2010 - International Conference on Security and Cryptography

Figure 3: An example of a HotCaptcha challenge.

1.2 Motivation

We know that the problem in which a new CAPTCHA

scheme is based has to be easy for humans, and hard

for machines. But, more than that, it has to be that

way not in a general circumstance, but in the im-

plementation that a particular CAPTCHA proposes -

which is always a subset of a more general problem.

Basically, there are two questions that remain to be

addressed:

1. Is a particular CAPTCHA open to a side-channel

attack? We do not have a clear methodology to

check whether a particular CAPTCHA’s design

and implementation is open to a side-channel at-

tack. A side-channel attack is one that solves the

CAPTCHA but not the artiﬁcial intelligence prob-

lem upon which it is based, therefore not improv-

ing the state-of-the-art of AI. It is named side-

channel, as it solves the problem using a method

that does not follow the intended attacking path.

2. Is the hardness of the underlying AI problem fully

transmitted to the CAPTCHA design? We lack a

method to check if the particular problem that a

CAPTCHA challenge poses is as hard as the un-

derlying AI problem.

Recent CAPTCHA design history is ﬁlled with

failures, which have made them much weaker than

intended. In recent work (Hernandez-Castro and Rib-

agorda, 2009a; Hernandez-Castro et al., 2009; Golle,

2008; Hernandez-Castro and Ribagorda, 2009b), it

has been shown some of security problems of dif-

ferent CAPTCHA schemes. By analyzing those

CAPTCHA proposals we can ﬁnd and classify vari-

ous ﬂaws. That is why it is so interesting to try to

break current CAPTCHAs, especially in a way that

helps to ﬁnd pitfalls in their design, to make the state-

of-the-art advance and get to a point when well known

and tested assumptions give base for more secure de-

signs.

1.3 Organization

The rest of the paper is organized as follows:

In the next section, we introduce the HumanAuth

CAPTCHA in greater detail. After this, in Section

3 we describe the ENT tool, which will be helpful in

the attack against HumanAuth described in Section 4.

Later, we analyze if the watermarking algorithm pro-

posed by HumanAuth is able to counter our attack.

Finally, in Section 5 we extract some conclusions and

propose possible improvements together with future

research lines.

2 THE HumanAuth CAPTCHA

The HumanAuth CAPTCHA

is based on the ability

of humans to distinguish between images with natu-

ral and non-natural contents. The source code of the

HumanAuth application comes with a image reposi-

tory consisting of 45 nature images and 68 non-nature

ones in jpeg format. The idea is quite interesting, and

the CAPTCHA is specially easy for humans and pur-

portedly very difﬁcult for non-humans. The user is

presented with a collection of 9 pictures, and has to

click on the three that represent items that are natural,

that is, no artiﬁcial. HumanAuth also includes a wa-

termarking algorithm (ﬁgure 4) to difﬁcult indexing

of pictures.

Figure 4: HumanAuth CAPTCHA capture with the GigoIt

logo as an example watermark.

The HumanAuth CAPTCHA is implemented in

PHP. The authors are Peter Schmalfeldt and John

Kramlich, working for the GigoIt Inc. association,

who released it under a GNU GPLv2

3 DESCRIPTION OF THE ENT

TOOL

The ENT (Walker, 2008) tool is a program compris-

ing a suite of statistical tests that check for informa-

tion density and randomness in a byte sequence. It ap-

plies various tests to the sequence of bytes and reports

http://sourceforge.net/projects/humanauth/

http://www.gnu.org/licenses/gpl-2.0.html

SIDE-CHANNEL ATTACK ON THE HUMANAUTH CAPTCHA

their numerical results. As these tests evaluate infor-

mation quantity and randomness quality, this results

are of interest for evaluating pseudorandom number

generators, and studying the output of compression

algorithms. In the novel way presented in this paper,

they can also be used for ﬁle/image classiﬁcation. The

tests included in the ENT program are:

• Entropy: information density of the contents of

the ﬁle, expressed as the mean number of bits nec-

essary to represent a character of 8 bits (byte).

• Compression: this test tells us the size shrink (in

percentage) we could obtain if the ﬁle was com-

pressed using a lossless compression algorithm of

the Lempel-Ziv type (one pass).

• Chi-square test: this tests computes the expected

p-value for a distribution with 256 degrees of lib-

erty (dividing the ﬁle in 8 bit chunks of data). This

p-value represents how frequently a uniform dis-

tribution would exceed the computed value.

• Arithmetic mean: this tests computes the mean

value of all the bytes of the input ﬁle.

• Monte-Carlo value for Pi: uses a Monte-Carlo

(probabilistic) algorithm to compute the value of

Pi, using the input ﬁle as the source of randomness

for such algorithm.

• Serial correlation: measures how a byte of the ﬁle

can be approximated by its preceding byte.

For an idea of the results one can expect of the

ENT test, we show the output obtained when applied

to the following input ﬁles:

• An ASCII English version of Don Quijote de

la Mancha, by Miguel de Cervantes, from the

Gutemberg Project

• A BMP non-compressed image

• A WAV non-compressed sound

• A JPEG compressed image from Flickr.com

• The Chase, an MP3 compressed music ﬁle from

the Internet Audio Open Source Archive

The entropy and compression tests (table 1) give

information about data density. The mean and Monte

Carlo Pi tells us about value distribution, the serial

http://www.gutenberg.org/ﬁles/996/996.txt

http://www.lossip.com/wp-content/uploads/marc-


http://amazingsounds.iespana.es/oceanwaves.wav

http://farm4.static.ﬂickr.com/3126/3153559748

b0ee7fd24b o.jpg

http://www.archive.org/download/Green-LiveAt

smallTheAQ/TheChase.mp3

Table 1: Results of the ENT test for different kinds of ﬁles.

test ASCII BMP WAV JPEG MP3

size 2347772 1683594 116904 4914423 2916331

entropy 4.49 7.24 6.16 7.91 7.85

compression 43 % 9 % 22 % 1 % 1 %

chi square 37,346,041 2,796,525 484,762 669,239 1,643,472

chi square p-value < 0.01 < 0.01 < 0.01 < 0.01 < 0.01

mean 88.92 73.21 125.74 137.88 119.89

Monte-Carlo Pi 4.00 3.45 3.97 2.84 3.20

serial correlation 0.016057 0.537042 0.928775 0.004862 0.168447

Figure 5: Distribution of classes for each ENT test result.

correlation about data interrelation (also data redun-

dancy), and the chi square test is the most sensible to

non random data distribution.

4 ATTACK TO HumanAuth

We downloaded the image database of the Huma-

nAuth CAPTCHA, and analyzed all of the jpeg ﬁles

contained herein with the help of the ENT tool, pro-

ducing a formatted output (in ARFF format, so to be

used with Weka (Winiwarter and Kambayashi, 1997))

with its results. As can be seen in ﬁgure 5, although

some of the ENT tests do produce interesting infor-

mation for classiﬁcation, none of them is able of pro-

ducing a good classiﬁer on its own.

Then, we test different classiﬁers for approach-

ing the classiﬁcation of human made (artiﬁcial) vs.

from nature. Even though we are processing the

compressed ﬁle, the best classiﬁer (in this case Ran-

domForest) was able to show an accuracy rate of

77.8761% (table 2), which is signiﬁcantly better than

the

68+45

= 60.177% that a trivial classiﬁer (that al-

ways predicts the larger class) will do.

The information disclosure of the values that ENT

outputs is distributed very evenly, except for the val-

ues of the MonteCarlo estimation of π (table 3), im-

plying that devising measures to difﬁcult side-channel

attacks against this scheme is going to be specially

hard.

Even after completely removing the three most

signiﬁcant attributes for the HumanAuth classiﬁer,

SECRYPT 2010 - International Conference on Security and Cryptography

Table 2: Classiﬁcation of the HumanAuth image database

using a RandomForest classiﬁer.

=== Run information ===

Scheme: weka.classifiers.trees.RandomForest -I 10 -K 0 -S 1

[.....]

Test mode: 10-fold cross-validation

Random forest of 10 trees, constructed considering

4 random features.

=== Summary ===

Correctly Classified Instances 88 77.8761 %

Incorrectly Classified Instances 25 22.1239 %

=== Confusion Matrix ===

a b <-- classified as

34 11 | a = nature

14 54 | b = nonnature

Table 3: Information disclosure of the different values for

classiﬁcation.

=== Run information ===

Evaluator: weka.attributeSelection.ChiSquaredAttributeEval

[.....]

Evaluation mode: 10-fold cross-validation

=== Attribute selection 10 fold cross-validation (stratified),

seed: 1 ===

average merit average rank attribute

38.987 +- 5.975 1.9 +- 1.58 8 corr

34.58 +- 3.872 2.6 +- 1.2 3 compressionrate

32.936 +- 6.025 2.7 +- 0.78 2 size

29.844 +- 4.878 3.9 +- 0.83 1 entropy

29.885 +- 4.57 4.6 +- 1.85 4 chisqstatistic

27.228 +- 1.393 5.3 +- 0.46 5 arithmean

0 +- 0 7.2 +- 0.4 7 errmontepi

0 +- 0 7.8 +- 0.4 6 montepi

that is correlation, compression rate and size, a SMO

algorithm is able of achieving a 75.2212% accuracy.

As table 4 shows, it seems extremely difﬁcult to

protect these set of images against the proposed side-

channel analysis, which seriously casts a doubt over

the security of the derived HumanAuth CAPTCHA.

4.1 HumanAuth CAPTCHA

Watermarking

To prevent easy image library indexing, the authors

of the HumanAuth CAPTCHA decided to randomly

merge a PNG image with the JPG image taken from

the library. It locates the PNG in a random position

into the JPG canvas and merges both using a certain

of transparency, so the PNG appears as a watermark,

not distorting the JPG image as much as to make it

difﬁcult for the human eye to recognize the image.

The HumanAuth source includes one PNG image (a

logo) that can be used for testing.

We have created a set of 20,000 images, 10,000 of

each class (nature and non-nature) (ﬁgure 6) and have

extracted statistical information from them with the

ENT tool, building an ARFF ﬁle for Weka processing.

After analyzing it, we have tried different classi-

ﬁers, obtaining the following results (table 5).

This result can be somewhat expected: with the

Table 4: Different classiﬁcation accuracies by classiﬁer and

parameters allowed.

classiﬁer non-allowed

parameters

parameters used accuracy

RandomForest - all 77.8761 %

SMO correlation,

compression

rate, size

rest 75.2212 %

Figure 6: Distribution of classes for the different ENT tests,

20000 images.

little randomness introduced by merging the logo

in a random position, the precision of the classiﬁer

slightly drops to 72.585 %.

Using a classiﬁcation tree of 481 leaves, J48 is

able to reach almost a 91 % accuracy (table 6). This

is due to the “repetition of images, as we have created

an image set of 20,000 images which are statistically

close (enough) to the 45 original ones. This suggests

that the initial small set of images, when used with

the scheme proposed by the HumanAuth authors of

merging with a watermark, may not be of use against

this type of attack, even though might be enough to

prevent hash-function (like MD5) indexing - which

probably was the intention of the designers. One can

argue that we can chose a different watermark that al-

ters more the original image, but that would be also at

the expense of human visual recognition. It can also

be argued that other possible approach could be ran-

domly using a set of different watermarks, but that

would be at the expense of creating an appropriate

set, so we are just moving/distributing the original

problem (images can be characterized because of a

not enough uniform distribution). As can be expected

when using as a seed such a small set of images, the

classiﬁcation accuracy raises as enough samples are

given to build a good enough decision tree, reaching

its top logarithmically (ﬁgure 7). The ﬁgures given

here (table 7) correspond to another test set of 20000

images we have created:

Other classiﬁcation schemes show even slightly

better results than J48 (table 8). These results (table

9) are still good after the most signiﬁcant attributes

are removed from the classiﬁcation scheme.

SIDE-CHANNEL ATTACK ON THE HUMANAUTH CAPTCHA

Table 5: Classiﬁcation of 20K HumanAuth randomly wa-

termarked images, using a DecisionStump tree classiﬁer.

=== Run information ===

Scheme: weka.classifiers.meta.LogitBoost -P 100 -F 0 -R 1 -L

-1.7976931348623157E308 -H 1.0 -S 1 -I 10 -W

weka.classifiers.trees.DecisionStump

Instances: 20000

[.....]

Test mode: 10-fold cross-validation

=== Classifier model (full training set) ===

LogitBoost: Base classifiers and their weights:

[.....]

=== Summary ===

Correctly Classified Instances 14517 72.585 %

Incorrectly Classified Instances 5483 27.415 %

Kappa statistic 0.4517

Mean absolute error 0.3631

Root mean squared error 0.4229

Relative absolute error 72.6115 %

Root relative squared error 84.5869 %

Total Number of Instances 20000

[.....]

=== Confusion Matrix ===

a b <-- classified as

8093 1907 | a = nature

3576 6424 | b = nonnature

Table 6: Classiﬁcation of 20K HumanAuth randomly wa-

termarked images, using a J48 classiﬁer.

=== Run information ===

Scheme: weka.classifiers.trees.J48 -C 0.25 -M 2

Relation: humanauth

Instances: 20000

Attributes: 9

[.....]

Test mode: 10-fold cross-validation

=== Classifier model (full training set) ===

J48 pruned tree

------------------

[.....]

Number of Leaves : 481

Size of the tree : 961

[.....]

=== Summary ===

Correctly Classified Instances 18187 90.935 %

Incorrectly Classified Instances 1813 9.065 %

Kappa statistic 0.8187

Mean absolute error 0.1113

Root mean squared error 0.2776

Relative absolute error 22.2538 %

Root relative squared error 55.5252 %

Total Number of Instances 20000

[.....]

Figure 7: Increase in accuracy and number of nodes with

images available.

Table 7: Classiﬁcation accuracy for different numbers of

watermarked images.

Images Nodes Accuracy

200 21 71.5 %

500 61 74.4 %

1000 85 78.6 %

2000 159 82.1 %

10000 597 88.8 %

20000 929 89.7 %

Table 8: Classiﬁcation of 20K HumanAuth randomly wa-

termarked images, using a RandomForest classiﬁer.

=== Run information ===

Scheme: weka.classifiers.trees.RandomForest -I 10 -K 0 -S 1

Relation: humanauth

Instances: 20000

Attributes: 9

[.....]

Test mode: 10-fold cross-validation

=== Classifier model (full training set) ===

Random forest of 10 trees, constructed considering 4 random features

=== Summary ===

Correctly Classified Instances 18538 92.69 %

Incorrectly Classified Instances 1462 7.31 %

Kappa statistic 0.8538

Mean absolute error 0.1133

Root mean squared error 0.2327

Relative absolute error 22.658 %

Root relative squared error 46.5399 %

Total Number of Instances 20000

[.....]

5 CONCLUDING REMARKS

We address in the following, Section 5.1, the general-

ity of the presented attack, and later some conclusions

and ideas for future works.

5.1 Attack Generality

Our approach can be used as a very general analy-

sis tool to realistically estimate the security parame-

ters of any image-labeling CAPTCHA proposal, and

we believe it will be advisable to use it in the fu-

ture before similar systems are launched, to have ad-

equate, well-reasoned, and founded security param-

eters and realistic estimations. One of its main ad-

vantages is that it does not depend on the underlying

format (image, sound, video, etc.) or problem, and

that it could be useful for avoiding pitfalls such as

the existence of some trivial and irrelevant parame-

ter values (i.e. size, or byte correlation) leaking too

much class-relevant information. We have used this

approach against other image-labeling CAPTCHAs

with success, and are in the process of improving it

for better image categorization.

SECRYPT 2010 - International Conference on Security and Cryptography

Table 9: Classiﬁcation accuracies for watermarked images,

per classiﬁer and parameters allowed.

classiﬁer non-allowed param-

eters

parameters

used

accuracy

LogitBoost / De-

cisionStump

- all 72.585 %

J48 - all 90.935 %

RandomForest - all 92.69 %

RandomForest correlation, compres-

sion rate, size

rest 82.805 %

5.2 Conclusions and Future Work

HumanAuth is a very interesting image-labeling

CAPTCHA. Its basic idea is theoretically more pow-

erful that that behind KittenAuth or ASIRRA, as

it relies on a broader image recognition and clas-

siﬁcation problem: it delves into many different

types of pictures (much more than KittenAuth and

ASIRRA), thus relying on a harder AI problem. But,

although the HumanAuth, along with many other

image-labeling CAPTCHAs, are very interesting, our

work has shown that their security is not carefully

studied before they are put into use.

With the attack presented here, we are able to suc-

cessfully bypass the HumanAuth challenge 92+% of

occasions, as proposed by its authors (image library

and watermarking image). This is an incredibly suc-

cessful ﬁgure, as normally, CAPTCHAs that are pos-

sible to automatically bypass as low as 5% (or even

less) are considered broken, taking into consideration

that a program can try to bypass the CAPTCHA many

times per second.

The lessons learned in this analysis are useful to

improve other attacks based on more common ap-

proaches -like image processing- or, alternatively, can

be used to improve the security of these CAPTCHA

schemes, and this could be an interesting future work.

One particulary interesting way would be ﬁltering im-

ages taken from image databases, to force then to have

a much similar average size and less standard devia-

tion (among other statistical properties), which could

harden a lot the task of the attacker, without affect-

ing the overall good properties of the CAPTCHA pro-

posal.

REFERENCES

Abadi, M. (1996). Method for selectively restricting access

to computer systems. US Patent no. 6,195,698.

Ahn, L. V., Blum, M., and Langford, J. (2003). Captcha:

Using hard ai problems for security. In Proceedings

of Eurocrypt, pages 294–311. Springer-Verlag.

Chew, M. and Tygar, J. D. (2004). Image recognition

captchas. In Proceedings of the 7th International In-

formation Security Conference, pages 268–279.

Elson, J., Douceur, J. R., Howell, J., and Saul, J. (2007).

Asirra: A captcha that exploits interest-aligned man-

ual image categorization. In Proceedings of 14th ACM

Conference on Computer and Communications Secu-

rity (CCS), Association for Computing Machinery.

Golle, P. (2008). Machine learning attacks against the asirra

captcha. In ACM Conference on Computer and Com-

munications Security, pages 535–542.

Golle, P. and Ducheneaut, N. (2005). Preventing bots from

playing online games. In Proceedings of the ACM

Computers in Entertainment, Vol. 3, No. 3.

Hernandez, J. C. (1997). Compulsive voting. In Proceed-

ings of the 36th Annual 2002 International Carnahan

Conference on Security Technology, pages 124–133.

Hernandez-Castro, C. J. and Ribagorda, A. (2009a). Pit-

falls in captcha design and implementation: the math

captcha, a case study. Computers & Security.

Hernandez-Castro, C. J. and Ribagorda, A. (2009b). Re-

motely telling humans and computers apart: an un-

solved problem. In Proceedings of the iNetSec 2009,

IFIP AICT 309.

Hernandez-Castro, C. J., Ribagorda, A., and Saez, Y.

(2009). Side-channel attacks on labeling captchas.

http://arxiv.org/abs/0908.1185.

Mori, G. and Malik, J. (2003). Recognizing objects in ad-

versarial clutter: Breaking a visual captcha. In Com-

puter Vision and Pattern Recognition CVPR03, pages

134–141.

Naor, M. (1996). Veriﬁcation of a human in the loop or

identiﬁcation via the turing test. Technical report,

Weizmann Institute of Science.

von Ahn, L. and Dabbish, L. (2004). Labeling images with

a computer game. In ACM Conference on Human Fac-

tors in Computing Systems, pages 319–326.

Walker, J. (2008). Ent: A pseudorandom number sequence

test program. http://www.fourmilab.ch/random/.

Warner, O. (2006). Kittenauth.

http://www.thepcspy.com/kittenauth.

Winiwarter, W. and Kambayashi, Y. (1997). Y.: A machine

learning workbench in a dood framework. In Proc. of

the Intl. Conf. on Database and Expert Systems Appli-

cations, pages 452–461.

SIDE-CHANNEL ATTACK ON THE HUMANAUTH CAPTCHA
