MODEL-BASED FEATURE EXTRACTION FOR ASSESSMENT OF

DRIVER-RELATED FATIGUE

Dami

an Alvarez,

Alvaro Orozco

Grupo de Investigaci

on en Control e Instrumentaci

on, Universidad Tecnol

ogica de Pereira, La Julita, Pereira, Colombia

Augusto Salazar

Grupo de Investigaci

on en Percepci

on y Control Inteligente, Universidad Nacional Sede Manizales

La Nubia, Manizales, Colombia

Keywords:

Driver fatigue.

Abstract:

One of the most major causes of road crashes is the fatigue. In this paper it is shown a methodology for Driver

Fatigue assessment based on computer vision (CV). CV is used to characterize different visual responses of

the driver while driving and suffering from fatigue. Some of the visual responses are the eyelid and lips

movements. The proposed Methodology uses an active appereance model (AAM) to adjust the facial model

Candide3 from images sequences where spatial measures can be computed. These measures include the eye

closeness and the mouth openness. Results show that with the measures computed it’s possible efﬁciently

extract some discriminant parameters related to driver fatigue state. For example, the PERCLOS, the AECS,

and the YawnFrec. Finally, an experimental framework is designed in order to compare the performance of

the proposed method with psychological signal-based methods.

1 INTRODUCTION

Driving for long periods of time can decrease alert

and performance of the driver who could start to suf-

fer from fatigue (Ting et al., 2008). Fatigue and lack

of sleep have been identiﬁed as the most frequent

causes of trafﬁc accidents in the road. For instance,

the driver who is under these conditions is risking

not only his/her own life but also other people lives.

In order to prevent these kind of accidents, in the

last decades a huge effort has been made to develop

of monitoring systems that detects the fatigue in the

driver and warned him/her by using different tech-

niques. However, an efﬁciently system for fatigue as-

sessment is still being an important issue to solve.

2 THEORETICAL BACKGROUND

Fatigue. Is the state of alteration in both the aware-

ness level and the perception level of the person, this

state affects psychomotor processes, such as speed of

reaction, attention level, and making decisions that

are crucial for the safe development of an activity. Fa-

tigue is not the same as sleep, but induction of sleep

could occur with fatigue. Fatigue can be caused by

physical effort, emotional stress, lack of sleep, or an

unspeciﬁed disorder.

Driver Fatigue. Is a state of reduced mental alert-

ness, which impairs performance of a range of cogni-

tive and psychomotor tasks, including driving (Saroj

and Lal, 2001). The driver fatigue can be sub-divided

into two groups: related to sleep and related to tasks.

The ﬁrst one, is caused by lack of sleep (this is the

category select in this work), while the second one is

caused by distracting tasks while driving.

Candide Model. It is a parameterized facial mask,

that has been speciﬁcally developed for model-based

coding of human faces. Different versions of this

mask has been developed, the most current version

is the third, which has been implemented mainly to

simplify the animation of MPEG-4 facial animation

parameters (Ahlberg, 2001).

2.1 Psychological Test for Attention

Measurement

Works that deal with the assessment of driver-related

fatigue require experimental frameworks where the

methodology can be contrasted and validated. For ex-

295

Alvarez D., Orozco

A. and Salazar A. (2010).

MODEL-BASED FEATURE EXTRACTION FOR ASSESSMENT OF DRIVER-RELATED FATIGUE.

In Proceedings of the 7th International Conference on Informatics in Control, Automation and Robotics, pages 295-298

 SciTePress

ample, attention test (such as interviews or computer

based test), which are basically monitoring task that

required psychomotor reactions. One test of attention

most commonly used in drivers is the test of atten-

tion variables TOVA. It’s considered the gold standard

within this kind of tests. It consists in 22-minutes of

psychomotor tasks where a subject needs to hold the

attention and respond to a random stimulus. Another

example, is the PVT test (psychomotor vigilance test),

that measures the visual reaction time (RT) by mean

of portable devices. This test is another common tool

of measuring the fatigue in performance and lack of

sleep studies. The PVT is a 10 minutes length test,

like the TOVA test requires responding to a stimulus

as fast as possible.

Anothers examples of tests that can be used in

these kind of studies are those tests that aim to evalu-

ate the ability to focus the attention. One example of

such test is the Stroop task. In general any test that

measures the RT is useful in these studies, because

the sleep restriction and deprivation can be the main

cause of an increase in the RT.

2.2 Classiﬁcation of Driver Monitoring

Systems

In order to reduce road crashes, enormous efforts

have been done to develop driver monitoring systems.

These systems can be classify in three classes (Vural

et al., 2007). 1) Studies that analyze measures of the

driver’s performance. In this kind of systems the car

is equipped with measurement devices that indicate

if the person is driving as usual or not. These sys-

tems has the drawback that cannot be adapted to the

driver habits. 2) Work that are related to the measure-

ment of physiological signals. These methods pro-

vide good indicators of fatigue. However, these are

invasive methods that could interfere with the driving

task. 3) Works focus on detection of visual responses

that present the driver based on CV. The CV based

methods can be successful in order to assess fatigue

states. However, so far just one visual response has

been used and that could be the main drawback in the

CV based methods (Zhu et al., 2004).

Measurement of fatigue indicators is a signiﬁcant

problem due to the absence of direct measures, which

are not directly relate to the fatigue but to the ef-

fects of fatigue. The only direct measure is the self

report. However there are problems related with its

use because the emotional inﬂuence in the person

(Wang et al., 2006). In the literature there are different

studies related with the measurement of performance,

physiological, of perception, among others. Although

the technologies applied to fatigue assessment have

evolve, the search for a ﬁable fatigue indicator still

ahead (Saroj and Lal, 2001).

2.3 Visual Responses and

Fatigue-Related Parameters

In order to detect driver fatigue it is required to mea-

sure different visual responses. Simultaneous mea-

sures will provide a less ambiguous scenary that just

one measure. Some of the visual responses are: the

eyelids, the head pose, and the facial expressions.

From these visual responses fatigue-related param-

eters are computed. For example, head-position-

dependent parameters and head-position-independent

parameters. the last will be used in this work, more

speciﬁcally are computed: the percentage of eye clos-

ening in time (PERCLOS), the eye closening average

speed (AECS), and the yawning frequency in time

(YawnFrec) (Zhu et al., 2004).

PERCLOS and AECS. These measures are charac-

teristic of the eyelid movement. The PERCLOS has

been already validated and it has been found that is

the most appropriated parameters to assess the driver-

related fatigue (Dinges et al., 1998). The AECS is a

good indicator of fatigue. This parameter is deﬁned as

the time taken to completely close the eyes. The eye

openess is characterized by pupil’s shape. It can be

measure by taking the ellipse axis relationship. This

feature over the time is used to computed the PERC-

LOS (Zhu et al., 2004). In (Ji and Yang, 2002), it has

been shown that the AECS in a tired person is deﬁ-

nitely different from a rested person.

YawnFrec. A tired person is characterized by ex-

pressing less facial expressions because there is min-

imal activity of facial muscles, but it also show more

open mouth. The mouth openness can be measure

by detecting the lips movements whether the features

around it deviate from its closed conﬁguration. The

mouth openess is characterized by the proportion be-

tween the height and width to computed the Yawn-

Freq (Zhu et al., 2004).

3 FATIGUE ASSESSMENT BASED

ON COMPUTER VISION

People in a state of fatigue show some visual re-

sponses that are easily observable from changes in

their facial features like eyes and mouth. CV has

different non-invasive techniques for monitoring of

drivers (Wang et al., 2006). As Zhang (Zhang and

Zhang, 2006) reported, the CV-based systems for

monitoring drivers are the most promising commer-

ICINCO 2010 - 7th International Conference on Informatics in Control, Automation and Robotics

296

cial application for assessment of driver-related fa-

tigue (Zhang and Zhang, 2006), (Dong and Wu,

2005), (Saeed et al., 2007), (Zhu et al., 2004), (Ji and

Yang, 2002). However, CV is a challenging research

area due to the different factors such as: facial expres-

sions complexity, fast eye and head movements, and

changes in illumination conditions, etc. These factors

difﬁcult the development of robust and real time im-

plementations of these kind of systems.

Basic Requiremets for A CV-Based System. Ac-

cording to (Dong and Wu, 2005), and (Smith et al.,

2003) a monitoring system to detect fatigue should

fulﬁll the following requirements: 1) fully automatic.

2) to be based on only quantitative features, such as,

the eye openness and closeness rate. 3) to work under

changing illumination conditions. 4) to work under

occlusion conditions that are frequent when head is

moved from the reference point. 5) real-time. 6) non-

invasive, without physical contact of the driver. 7)

before an accident it should detect and warn the early

occurrence of sleep.

Steps in A Visual System for Detection of Fatigue.

First, near infrared image sequences were acquired.

Second, mathematical morphology is used to improve

the images quality and the success rate in the follow-

ing steps. Third, the Haar algorithm is used to detect

the face and then the Gabor algorithm is used to de-

tect the person’s eyes. Then the distance between the

eyes is used reference to adjust the Candide model to

the person’s face. Fourth the AAM technique is used

to track the movements of the face. Finally the feature

extraction stage is performed using a model.

4 CHARACTERIZATION OF

FACE MOVEMENTS

The most important points to characterize a face de-

pend on the application and the facial model. In this

work the movements of the eyes and mouth are con-

sidered. In these sense, a whole face model is used in-

stead of a partial model of the eyes, as used in (Saeed

et al., 2007).

In order to get a quite realistic ﬁtting of model

and detect the driver fatigue it’s need to deﬁne the ad-

justable vertices of the model Candide. These vertices

belong to the eyes and mouth ROIs where the parame-

ters PERCLOS, AECS, and YawnFrec are computed.

Additionally it is desirable that the movements of se-

lected vertices are controlled by facial action units,

these movements are part of the list of changes that

are presented when there is a movement of the ROI

encoded in terms of AUVs (Ahlberg, 2001).

Facial Motion Tracking. Previous to the computa-

tion of the parameters of fatigue the AAM models

are used to adjust the face model to different subject

faces. The AAM models are adjusted by machine

learning algorithms from available features (Cootes

et al., 1995). Then an alignment process is run to

adjust the AAM model (vertices update) to the input

images. To train the AMM an graphical user inter-

face (GUI) was developed, were the following steps

are done. 1) Scaling of the model to the face based

on the inter-eye distance, 2) Rotations in axes X, Y,

and Z to locate the model in the subject position,

3) Shape changes of the model regions are evaluated

(control by shaped units) or movements in regions of

the model (with vector control units of action, focus-

ing on the mouth openness AUV11 and eye closeness

AUV6) are evaluated too. 4) Points in the boundary

of the face and eyes and mouth are reviewed and re-

located. 5) The positions of the vertices of the ﬁt-

ted model are stored for each image in the sequence.

Once the training algorithm is completed, a ﬁtting al-

gorithm is used to adjust the AAM to minimize the

ﬁtting error. For example, the decreasing gradient op-

timization can be used as described in Eq. 1, with the

model A

and the input image I(x). Once the model

is adjusted the extraction of fatigue features can start.

FittingError =

∑

[I(x) − A

(x)]

(1)

Eyelid and Lips Movements Characterization. To

compute the PERCLOS and AECS in (Ji and Yang,

2002) is proposed to continually track the pupil and

measure the eye closeness cumulatively over time, us-

ing the ratio of the vertices of the pupil ellipse. A sin-

gle eye closure is deﬁned as the difference between

two periods of time in which the pupil size is 20% or

less of the normal size. The closing eye speed is de-

ﬁned as the time period in which the pupil size is be-

tween 80% and 20% of the nominal size of the pupil.

In order to computed these two parameters more

accurately, an average time is used of all measure-

ments taken on a deﬁned range (Ji and Yang, 2002).

To make these measures it is apply the method-

ology described in (Ji and Yang, 2002), but differ-

ent from this, eye closeness is computed using the

eye vertices which are deﬁned in the model Candide

3. Speciﬁcally, we used some vertices of the eyelids.

Thus, the eye closeness is calculated as:

d (v

− v

100

) + d (v

− v

) + d (v

106

− v

108

)

(2)

d (v

105

− v

107

) + d (v

− v

) + d (v

− v

)

(3)

MODEL-BASED FEATURE EXTRACTION FOR ASSESSMENT OF DRIVER-RELATED FATIGUE

297

From Eq. 2 and 3, when the eye closeness is less than

or equal to 20% of the maximum distance between

eyelids is considered that the eyes are closed. Accord-

ing to the work developed in (Dong and Wu, 2005) if

the eyes are closed for 5 consecutive frames it can be

considered that the driver is falling asleep.

In order to compute the rate of mouth opening, it

is necessary to know the degree of the mouth open-

ness, which is represented by the relation between the

mouth’s height and width. The graphical represen-

tation of the mouth openness in a period of time is

know as YawnFrec. To compute the mouth openness

the vertices (right, left, upper, lower), of the mouth

in the model Candide 3 are used. In this sense, the

mouth openness is computed as follows:

OpenMouth =

d (v

− v

)

d (v

− v

)

(4)

5 EXPERIMENTAL

FRAMEWORK

Two different videos were acquired with 320x340 res-

olution. The subjects were instructed to blink and

yawn in different head positions range from 45

◦

y −

◦

. The subject 1 blinked 35 times and yawned 5

times. The subject 2 blinked 24 and yawned 4 times.

The system was able to identiﬁed the total numbers

of yawns and blinks for each subject. This means

a 100% accuracy in detection of eye closeness and

mouth openness. Indeed the parameters PERCLOS,

AECS, and Yawnfrec could be determined every time.

In order to validate the presented methodology, an ex-

perimental framework is proposed. First, a commer-

cial driving simulator is going to be used and three

diferent physiological test will be set up (the PVT test,

the Stroop test, and the RT test). These tests are em-

bedded in the software PEBL (Open source Psychol-

ogy Software), available at “http://pebl.sf.net”. From

these tests some basic measures will be made, in sim-

ilar ambiental and physical conditions to those pre-

sented in the computer-vision-based methodology in

order to compare results and validate the parameters.

6 CONCLUSIONS

In this paper was proposed a characterization method-

ology based on models to assess fatigue. Two vari-

ables are measured by means of computer vision. The

eye closening range and the mouth opening range.

These measures are the base to calculate the param-

eters PERCLOS, AECS y YawnFrec. It has been

found that the proposed methodology is practical and

reliable whithin the previously described conditions.

Also an experimental framework based on psycholog-

ical measures was deﬁned in order to validate the pro-

posed methodology. As future work, it is proposed to

complement the above methodology with estimation

of head’s position in order to compute additional pa-

rameters. This will provide more information to the

assessment of the driver fatigue.

REFERENCES

Ahlberg, J. (2001.). Candide-3 an updated parameterized

face. Report No. LiTH-ISY-R-2326, Dept. of Electri-

cal Engineering, Linkping University, Sweden.

Cootes, T. F., Taylor, C. J., Cooper, D. H., and Graham, J.

(1995). Active shape models-their training and appli-

cation. Comput. Vis. Image Underst., 61(1):38–59.

Dinges, D. F., Mallis, M., Maislin, G., and Powell, J. W.

(1998). Evaluation of techniques for ocular measure-

ment as an index of fatigue and the basis for alertness

management.

Dong, W. and Wu, X. (2005). Driver fatigue detection based

on the distance of eyelid. IEEE Int. Workshop VLSI

Design and Video Tech Suzhou, pp 365-368.

Ji, Q. and Yang, X. (2002). Real-time eye, gaze, and face

pose tracking for monitoring driver vigilance. Real-

Time Imaging, 8(5):357–377.

Saeed, I., Wang, A., Senaratne, R., and Halgamuge, S.

(2007). Using the active appearance model to detect

driver fatigue. In Information and Automation for Sus-

tainability, 2007. ICIAFS 2007. Third International

Conference on, pages 124 –128.

Saroj, K. and Lal, A. (2001.). A critical review of the psy-

chophysiology of driver fatigue. Biological Psychol-

ogy 55 173194.

Smith, P., Shah, M., and Vitoria, N. (2003.). Determining

driver visual attention with one camera. Trans. on In-

telligent Transportation Systems, 4(4):205–218.

Ting, P., Hwang, J., Doong, J., and Jeng, M. (2008.). Driver

fatigue and highway driving: A simulator study. Phys-

iology and Behavior 94 448-453.

Vural, E., Cetin, M., Ercil, A., Littlewort, G., Bartlett, M.,

and Movellan, J. (2007). Drowsy driver detection

through facial movement analysis. pages 6–18.

Wang, Q., Yang, J., Ren, M., and Zheng, Y. (2006). Driver

fatigue detection: A survey. Proceedings 6th World

Congr. Intell. Control Autom., Dalian, China, pp.

8587-8591.

Zhang, Z. and Zhang, J. (2006). Driver fatigue detection

based intelligent vehicle control. In ICPR ’06: Pro-

ceedings of the 18th International Conference on Pat-

tern Recognition, pages 1262–1265.

Zhu, Z., Ji, Q., and Lan, P. (2004). Real time non-intrusive

monitoring and prediction of driver fatigue. IEEE

Trans. Veh. Technol, 53:1052–1068.

ICINCO 2010 - 7th International Conference on Informatics in Control, Automation and Robotics

298
