A SCALA-BASED DOMAIN SPECIFIC LANGUAGE FOR

STRUCTURED DATA REPRESENTATION

Kazuaki Maeda

Department of Business Administration and Information Science, Chubu University, 1200 Matsumoto, Kasugai, Aichi, Japan

Keywords:

Data representation, Structured data, Domain speciﬁc languages, Scala, Java.

Abstract:

This paper describes Sibon, a new representation written in a text-based data format using Scala syntax. The

design principle of Sibon is good readability and simplicity of structured data representation. An important

feature of Sibon is an executable representation. Once Sibon-related deﬁnitions are loaded, the representation

can be executed corresponding to the deﬁnitions. A program generator was developed to create Scala and Java

programs from Sibon deﬁnitions. In the author’s experience, productivity was improved in the design and

implementation of programs that manipulate structured data.

1 INTRODUCTION

A domain-speciﬁc language (DSL) is a program-

ming language tailored to a speciﬁc application do-

main(Mernik et al., 2005). It is a special-purpose, and

not general-purpose, programming language.

Fowler has explained the difference between ex-

ternal and internal DSLs(Fowler, 2009). An external

DSL (e.g., an XML conﬁguration ﬁle) is a special-

purpose language with a syntax that is different from

existing programming languages. In case of an ex-

ternal DSL, the DSL developer has to reuse or build

a parser for the domain-speciﬁc description. On the

other hand, an internal DSL uses the constructs of an

existing programming language (called a “host” lan-

guage) to deﬁne the DSL. In case of an internal DSL,

the designer extends the host language to the domain

speciﬁc description, which can improve the develop-

ment time for building a DSL processor to execute the

description.

Scala is a hybrid functional and object-oriented

language(Martin Odersky, 2008). It is a simple but

powerful programming language. Scala plays an im-

portant role as a host language for an internal DSL.

One of Scala’s appealing features is the fact that

parentheses for arguments of methods are optional for

inﬁx operator notation; therefore, the descriptions are

easier to read and understand than ones in other pro-

gramming languages.

Another feature is implicit conversion methods. It

is used in Scala to extend existing libraries. We can

use method calls, for example, capitalize and reverse,

to String objects, but these methods are not deﬁned

in the String class. A special class RichString in the

Scala library wraps the String class, and the Scala

compiler converts the String implicitly using the im-

plicit conversion methods.

One more feature in Scala is that functions can be

passed as arguments of the methods. It represents a

group of program statements; it can be an argument of

a method in Scala. It is powerful in its representation

of structured data.

This paper describes Sibon

, an internal DSL for

structured data representation in a text-based data for-

mat using Scala syntax(Martin Odersky, 2008). An

important feature of Sibon is that it is based on Scala

and the representation is executable. If Sibon-related

deﬁnitions are loaded, the representation can be ex-

ecuted corresponding to the deﬁnitions. This is use-

ful for Java programs in reconstructing Java objects

or for traversing the structured data. Moreover, the

author believes that good readability and simplicity

of structured data representation are important for all

developers.

Section 2 explains structured data representation

and Sibon, and Section 3 summarizes this paper.

Sibon stands for Scala Instructions Becoming Object

Notation.

296

Maeda K. (2010).

A SCALA-BASED DOMAIN SPECIFIC LANGUAGE FOR STRUCTURED DATA REPRESENTATION.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 296-299

DOI: 10.5220/0003010502960299

 SciTePress

2 REPRESENTATION AND

MANIPULATION OF

STRUCTURED DATA

2.1 Structured Data Representation and

XML

Structured data has been widely used in many soft-

ware development projects. In the case of compiler

development, compiler front-ends build abstract syn-

tax trees (ASTs), which represent structured syntactic

information of source code(Aho et al., 2006). A va-

riety of representations for structured data have been

developedto date(Snodgrass,1989; Franz and Kistler,

1997; Wilson et al., 1994).

An attractive alternative is XML-based struc-

tured data representation. JavaML(Badros, 2000)

is a typical XML-based source code representa-

tion for ASTs, providing syntactic and semantic in-

formation after parsing Java source code. Once

software tools are implemented using the JavaML

representation, they can easily obtain information

about Java source code without the need for anal-

ysis. XSDML(Katsuhisa Maruyama, 2004) and sr-

cML(Jonathan I. Maletic and Kagdi, 2004) are other

representations in XML that support the represen-

tation of formatting information, including white

spaces and comments, in addition to ASTs. There-

fore, the original source code is restored from the

XML representation using the formatting information

in XSDML or srcML.

An XML representation is just static data, while

the representation in Sibon is dynamic, executable

code. Once a representation in Sibon is successfully

loaded, the parsing of the data is already done and the

representation can be executed. It is useful in recon-

structing Java objects from the representation.

2.2 Sibon as an Object Notation

The representation of structured data in Sibon is com-

posed of several elements. Each element has a value

and a name. Basically, one element ends with semi-

colon at the end of line, according to Scala syntax.

For example,

"April 1" .date;

which represents the value as “April 1” and the name

of the element as date. The element is not just a data

representation, but internally, it is also an executable

method invocation without parentheses in Scala. The

method data can be executed using implicit conver-

sion methods.

In Sibon, a structure is represented using func-

tions as arguments. For example, Figure 1 shows that

the conﬁg without the value has three child elements:

time, drink, and place. The time element’s value is

“programming,” the drink element’s value is “coffee,”

and the place element’s value is “coffee stand.”

We can use multiple elements in one line. This

action is not recommended, however, since the author

believes that simplicity is very important in represent-

ing structured data in Sibon.

config {

"programming" .time;

"coffee" .drink;

"coffee stand" .place;

}

Figure 1: An element with three child elements.

config {

pay {

340 .price;

0.05 .tax;

true .togo;

"April 1" .date;

}

"programming" .time;

"coffee" .drink;

"coffee stand" .place;

options {

"grande" .option;

"hot" .option;

"double-shot" .option;

}

Figure 2: Elements including primitive data types and a col-

lection.

Sibon supports nine primitive data types: byte,

char, short, int, long, ﬂoat, double, boolean, and

string. For example, Figure 2 shows that the pay el-

ement has four child elements: price, tax, togo, and

date. The price element has an integer value 340, the

tax element has a ﬂoat value 0.05, the togo element

has a boolean value true, and the date element has a

string value “April 1.”

Basically, an element in Sibon cannot have more

than one child element with the same name. Recall

that a Java class has no more than one ﬁeld with the

same name. An element in Sibon is a similar con-

struct as a Java class. In comparison, an element to

represent a collection can have more than one element

with the same name. In Figure 2, the options element

A SCALA-BASED DOMAIN SPECIFIC LANGUAGE FOR STRUCTURED DATA REPRESENTATION

297

has three child elements with the name option. The

ﬁrst option element’s value is “grande,” the second

option element’s value is “hot,” and that of the last is

“double-shot.”

If we need to represent an element linked to an-

other element across the structure, a unique iden-

tiﬁer is given to the element, and another element

refers to the element using the identiﬁer. Fig-

ure 3 shows that a uuid element with the identiﬁer

u1da16a5e c767 ddc7b5077855 is given to the place

element. The identiﬁer in the ﬁgure is calculated us-

ing java.util.UUID, which is represented using a sym-

bol in Scala; the place element has a reference to

the unique identiﬁer. This means that Sibon supports

graph-structured data. In the case that a Java pro-

gram writes graph-structured data to a ﬁle, after an-

other Java program reads the data from the ﬁle and

it constructs a graph data structure, both place ele-

ments become only one Java object. The value of the

uuid element can be freely modiﬁed using a prede-

ﬁned method.

shops {

place {

’u1da16a5e_c767_ddc7b5077855 .uuid;

"Seattle, Washington" .location;

}

config {

"programming" .time;

"coffee" .drink;

’u1da16a5e_c767_ddc7b5077855 .place;

}

Figure 3: Elements including a uuid and the reference.

2.3 Deﬁnition of Structured Data

Structured data is deﬁned using symbols in Scala and

predeﬁned keywords as shown in Table 1. Figure 4

shows the deﬁnitions of the representation in Figure 2.

The deﬁnitions are as follows:

• conﬁg element has ﬁve child elements: pay, time,

drink, place, and options.

• options element is a collection of option elements

• pay element has four child elements: price, tax,

togo, and date

• price element has an integer value

• tax element has a ﬂoat value

• togo element has a boolean value

• date element has a string value

Table 1: Keywords to deﬁne structured data.

keyword meaning of the keyword

is child of composition of elements

is element in seq collection of elements

is a specialization of an element

is type of primitive data type

(int, ﬂoat, bool, string, et al.)

(’pay,’time,’drink,’place,’options)

.is_child_of ’config;

’option .is_element_in_seq ’options;

(’price,’togo,’tax,’date)

.is_child_of ’pay;

’int .is_type_of ’price;

’float .is_type_of ’tax;

’bool .is_type_of ’togo;

’string .is_type_of ’date;

Figure 4: An example of Sibon deﬁnitions.

2.4 Program Generation for Scala and

Java

Sibgen reads a Sibon deﬁnition, and it generates a

Scala program and Java programs. Figure 5 shows

the speciﬁcation as follows;

is java package speciﬁes the path “test.sibon” for

the Java package

is java preﬁx speciﬁes addition of a preﬁx “Sbn” at

the beginning of the Java class name

is generated speciﬁes generation of a programming

language

is generated sibonsetup speciﬁes generation

of Sibon-related programs to the ﬁle name

“setup.scala”

is generated diagram speciﬁes generation of a

class diagram for generated Java classes to the ﬁle

name “mydiagram.dot”

"test.sibon" .is_java_package;

"Sbn" .is_java_prefix;

"java" .is_generated;

"setup.scala" .is_generated_sibonsetup;

"mydiagram.dot" .is_generated_diagram;

Figure 5: Speciﬁcation to generate Scala and Java pro-

grams.

Sibon is designed to map the representation to

Java classes. The SbnBase class is a base class for all

classes generated by Sibgen; it provides three ﬁelds:

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

298

value, name and uuid. The Sibon representation and

related programs can be compiled and executed. The

Scala programs trigger instantiation one after another

and instantiate all Java objects.

2.5 Current Implementation

The implementation work has been performed on an

Apple MacBook with Mac OS X 10.6.3, Scala 2.7.7,

and Java 1.6.0 17. The program generator Sibgen is

written in Scala. It reads a Sibon deﬁnition ﬁle, gen-

erates a Scala program to set up, and generates Java

classes corresponding to all elements.

The Sibon representation changes to graph-

structured data using unique identiﬁers and refer-

ences. When a Java program, using Sibon APIs,

writes graph-structured objects to a ﬁle, the objects

with cyclic paths need only be written once. Sibon

APIs correctly serialize and deserialize them using the

algorithm mentioned in the paper(Birrell et al., 1993).

3 SUMMARY

This paper describes the development of Sibon, a new

data representation for graph data structures that uses

Scala syntax. One of its important features is that

the representation is executable. A program gener-

ator Sibgen for Sibon was also developed to create

programs from data deﬁnitions. It is useful for the

development of Java programs to read/write Java ob-

jects from/to persistent storage media, or to traverse

the structured data.

In the author’s experience, Sibon improves pro-

ductivity in the design and implementation of pro-

grams that manipulate graph data structures. Sibon

and its related tools are now being used for the devel-

opment of commercial products, including a compiler

front end. Research and development of Sibon will

continue to support creation other commercial soft-

ware products. The results will be published in a fu-

ture paper.

ACKNOWLEDGEMENTS

This research has been supported by the Kayamori

Foundation of Informational Science Advancement.

REFERENCES

Aho, A. V., Lam, M. S., et al. (2006). Compilers : Princi-

ples, Techniques, and Tools. Pearson Education, 2nd

edition.

Badros, G. (2000). JavaML: A Markup Language

for Java Source Code. In 9th International

World 9th International Wide Web Conference,

http://www9.org/w9cdrom/index.html.

Birrell, A., Nelson, G., et al. (1993). Network objects. In

14th ACM Symposium on Operating Systems Princi-

ples, pages 217–230.

Fowler, M. (2009). MF Bloki: Domain Speciﬁc Language.

http://martinfowler.com/dslwip/.

Franz, M. and Kistler, T. (1997). Slim Binaries. Communi-

cations of the ACM, 40(12):87–94.

Jonathan I. Maletic, M. C. and Kagdi, H. (2004). Lever-

aging XML Technologies in Developinging Program

Analysis Tools. In 4th International Workshop on

Source Code Analysis and Manipulation, pages 80–

85.

Katsuhisa Maruyama, S. Y. (2004). A CASE Tool Platform

Using an XML Representation A CASE Tool Platform

Using an XML Representation of Java Source Code.

In 4th International Workshop on Source Code Analy-

sis and Manipulation, pages 158–167.

Martin Odersky, Lex Spoon, B. V. (2008). Programming in

Scala: A Comprehensive Step-by-step Guide. Artima.

Mernik, M., Heering, J., and Sloane, A. M. (2005). When

and How to Develop Domain-Speciﬁc Languages.

ACM Computing Surveys, 37(4):316–344.

Snodgrass, R. (1989). The Interface Description Language:

Deﬁnition and Use. Computer Science Press.

Wilson, R. P., French, R. S., et al. (1994). SUIF: an Infras-

tructure for Research on Parallelizing and Optimizing

Compilers. SIGPLAN Notices, 29(12):31–37.

A SCALA-BASED DOMAIN SPECIFIC LANGUAGE FOR STRUCTURED DATA REPRESENTATION

299
