ADAPTATION OF MATHEMATICAL DOCUMENTS

Exploring Document Structures, Metadata, and Context for the Generation

of User-speciﬁc Documents

Christine M¨uller

Computer Science Dept., Jacobs University Bremen, Bremen, Germany

BSgroup Technology Innovation AG, Z¨urich, Switzerland

Keywords:

User-speciﬁc adaptation, Mathematics, Contexts, Narrative documents, Content planning.

Abstract:

The paper proposes a framework that explores document structures, metadata, and context to adapt mathe-

matical documents on three layers - the content, structure, and presentation layer. On the presentation layer

mathematical expressions are rendered according to a user context (deﬁning, e.g., the users’ preferred conven-

tion, language or discipline). On the content layer, appropriate paragraphs of texts are selected that best suit

the users’ individual information need as well as narrative and semantic context. On the structure layer, these

content parts are arranged appropriately, while taking semantic and narrative interdependencies between parts

into account. Technically, the framework models documents as dependency graphs, where nodes correspond

to any addressable part of a document and edges denote narrative and semantic dependencies. To allow for the

adaptation on all three document layers, these dependency graphs are enriched with presentational, content,

and structure variants. Finally, the enriched graphs are processed to generate a user-speciﬁc document. Users

can guide this adaptation process by prioritising their individual constraints, narrative or semantic context.

1 INTRODUCTION

Information technologies have transformed our

present era into an information age, in which individ-

uals can freely transfer information and have instant

access to data that was formerly difﬁcult or impos-

sible to access. Today, users are surrounded by an

ever increasing number ofdocuments, such as product

descriptions or advertisements. Using modern web

technologies users can create and exchange such doc-

uments but seem to lack time to enhance these doc-

uments if they are missing details, to ﬁlter redundan-

cies and irrelevant content from these documents or

to rewrite documents in new contexts.

Why can computers not relieve us from these bur-

dens? For example, consider user manuals. Be-

sides that hardly any user is willing to read a 1000-

page long document, users also have different tech-

nical skills. Some need more illustrations and oth-

ers less explanations and details. Alternatively, think

of a product description. Wouldn’t it be convenient

if we could automatically generate advertisements by

simply deﬁning a context, e.g., in terms of price and

quality constraints? This work aims at providing such

kind of services by adapting documents to a user con-

text. User context is a commonly known term that

deﬁnes a set of context parameters like speciﬁc pref-

erences, needs, skills, environmental constraints, etc.

The author claims that adaptation can take place

on any document layer. On the content layer we can

substitute document parts, e.g., to adapt a document

to different backgrounds. On the structure layer we

can rearrange document parts, e.g., to adapt docu-

ments to different learning styles. One user might pre-

fer to see illustrations ﬁrst, while another might like

to study abstract concepts and generalizations before

that. On the presentation layer we can change the ap-

pearance of documents without changing content and

structure. The presentation of documents is relatively

solved. For example, standards like CSS help us to

specify the layout of web documents in separation to

content and structure. This work thus focuses on con-

tent planning services, which are adaptation services

on the content and structure layer of documents.

The most important prerequisite for adaptation

services is a representation of documents, which

makes the three document layers comprehensible to

a computer system. Such machine-processable repre-

sentations are developed in the scope of the seman-

tic web, which postulates annotations (or metadata)

143

Müller C..

ADAPTATION OF MATHEMATICAL DOCUMENTS - Exploring Document Structures, Metadata, and Context for the Generation of User-speciﬁc

Documents.

DOI: 10.5220/0003065601430148

In Proceedings of the International Conference on Knowledge Management and Information Sharing (KMIS-2010), pages 143-148

ISBN: 978-989-8425-30-0

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

to classify and describe resources. Document for-

mats that embed annotations are called markup lan-

guages. This work can be applied to any document

that is representable in an XML-based markup lan-

guage

. The richer the markup language, the better

the adaptation results. However, one also needs effec-

tive adaptation algorithms, which are one major con-

tribution of this work.

We can distinguish two paradigms to author docu-

ments. The document-centered approach (or nar-

rative approach) creates documents that are well

suited to be read by humans but which are also very

hard to adapt. They include multiple cross-references

and narrative transitions that improve the coherence

of the text: all parts are neatly connected and the

narrative ﬂow of the text guides the reader through

the writing. However, though transitions and cross-

references improve the coherence of documents they

also hamper us to reuse parts. This is particularly crit-

ical for the content planning during which documents

have to be modularised in order to substitute parts and

to arrange them according to user preferences.

The topic-oriented paradigm is based on princi-

ples of reuse and modularization and was originally

developed to manage technical writings like manu-

als, product descriptions or software documentations.

Topic-oriented documents consists of self-contained

units and can be easily modularised. Their adaptation

has been well-researched in, e.g., the eLearning do-

main

. However, topic-oriented documents omit nar-

rative transitions and thus lack coherence.

Neither topic-oriented nor document-centered

paradigm lead to an adaptation infrastructure, which

supports modularization and coherence. To address

this challenge, this work proposes to bridge the two

paradigms: It starts with one way and applies the

topic-oriented principles of reuse and modularization

to the narrative world.

To illustrate and evaluate the proposed adaptation

services, mathematical documents are used. The un-

derstanding of mathematical documents helps us to

better model documents from other domains. The au-

thor thus expects that her ﬁndings can be applied to

other domains and a wide range of documents.

Nevertheless, having selected mathematical docu-

ments requires us to take another aspect into account:

the adaptation of mathematical notations, a service on

the presentation layer of documents.

(M¨uller, 2010) analyzes a list of document markup lan-

guages, such as DITA and DOCBOOK. Here we use the

mathematical document format OMDOC (Kohlhase, 2006).

(M¨uller, 2010) analyzes respective adaptation systems.

2 RENDERING NOTATIONS

Mathematics is a mixture of natural language text,

symbols, and formulae. Symbols and formulae can

be presented with different notations, which underlie

cultural conventions and individual preferences. For

example, the notations for the binomial coefﬁcient

vary in different language: C

is used in French/Rus-

sian and





in German/English. Alternatively, i is

used in mathematics to denote the imaginary unit,

while j is used in physics to avoid confusion with

the notation I for electronic current. When planning

content and structure of documents, notations have to

be adapted as well. In particular when applying con-

tent planning to multi-authored document collections,

adaptation of notations becomes a central issues and

helps to avoid notational inconsistencies.

To adapt notations we need a machine-processable

representation of mathematical expressions and their

notations. Fortunately, we can build on two widely-

used standards OPENMATH (Buswell et al., 2004)

and MATHML (Ausbrooks et al., 2008). They pro-

vide a markup of the functional structure of mathe-

matical expressions (called content markup) and a

markup of the two-dimensional layout of notations

(called presentation markup).

<OMA>

<OMS cd="combinat"

name="binomial"/>

</OMA>

<mrow>

</mfrac>

</mrow>

Figure 1: Content/Presentation Markup for Binomial Coeff.

Figure 1 illustrates the respective markups for the

binomial coefﬁcient. The content markup to the left

speciﬁes the meaning of the expression. The pre-

sentation markup to the right the layout of the Ger-

man notation, which can be interpreted by most web

browsers to display





But how do we get from content markup to pre-

sentation markup? There has been a long tradition in

mathematical knowledge management to support this

transformation. For example, we can hard-code the

transformation process, which has widely been done

Alternatively, we can encode the notation practice of

mathematiciansand use it to guide the transformation.

This work builds on the speciﬁcation of notation def-

initions as proposed by (Kohlhase et al., 2008). No-

tation deﬁnitions can be seen as a declarative speciﬁ-

(M¨uller, 2010) analyzes such transformation workﬂows

in proof assistants.

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

144

cation of rules that bridge the translation from con-

tent markup to presentation markup. The author’s

contribution is an extension of the initial rendering

workﬂow that allows us to deal with different con-

texts to, e.g., select appropriate notations for speciﬁc

languages or disciplines. Dealing with such contexts

is the focus of this section, details on how notation

deﬁnitions work are omitted (Kohlhase et al., 2008).

<om:OMA><om:OMS cd="combinat1" name="binomial" />

</prototype>

<m:mrow><m:mo>(</m:mo><m:mfrac linethickness="0">

</m:mfrac><m:mo>)</m:mo></m:mrow>

</rendering>

<m:msubsup><m:mi>C</m:mi>

</rendering>

</notation>

Figure 2: XML-Encoding of Transformation rules.

Notation deﬁnitions consist of prototypes (pat-

terns that are matched against the content markup

of expressions) and renderings (that are used to

construct corresponding presentation markup). Fig-

ure 2 presents a notation deﬁnition, which prototype

matches with the content markup for the binomial co-

efﬁcient. It includes two renderings. The ﬁrst one

generates the German notation





and the second the

the French notation C

To support a context-aware selection between

these two renderings, the author proposes a context

model with two components: an extensional context

and an intensional context speciﬁcation. The exten-

sional context consists of references to documents,

notation deﬁnitions, and rendering elements, which

are resolved to collect notation deﬁnitions from var-

ious documents. The intensional context is used to

guide the adaptation intensionally by providing a set

of context parameters. These are matched against the

metadata of renderings to prioritize these renderings.

In our example, an intensional context is encoded as

attribute. It deﬁnes that the content markup should

be transformed into a German notation, thus, the ﬁrst

rendering element is selected.

The rendering workﬂow for the adaptation of

mathematical documents has ﬁve core components.

The renderer receives a document (doc), a document

database (db), an extensional context (ec

∗

), and an

intensional context (ic

∗

). The contexts encode how

the user wants to guide the rendering workﬂow, the

database includes all documents referenced by the

user, the document includes content markup for all

expressions. For each content expression (expr) in the

document, the renderer ﬁrst calls the notation collec-

tor to resolve the extensional context references (ec

∗

The notation collector returns the list of notation def-

initions (ntn

∗

) that the users wants to consider dur-

ing the adaptation. The renderer then calls the context

collector to resolve the intensional context parame-

ters (ic

∗

) that describe how the expression should be

rendered. The context collector returns the effective

intensional context (ic) for the expression. Finally,

the pattern matcher is called to select an appropriate

rendering (rnd). It ﬁrst matches the content markup

with the collected notation deﬁnitions (ntn

∗

) and then

passes the rendering elements (rnd

∗

) from these nota-

tion deﬁnitions to the rendering grabber. The render-

ing grabber uses the intensional context options (ic)

to rank the renderings. The ﬁrst one (rnd) is used

to generate the presentation markup for the content

expression (expr). The renderer returns a document

(doc

∆

), in which each content markup expression is

replaced with a user-preferred presentation markup.

The context-sensitive extension of the initial ren-

dering algorithm has been implemented as central

part of the JOMDOC library, the reference imple-

mentation of the OMDOC format (JOMDoc, 2010).

Having speciﬁed and implemented the initial frame-

work, several services can now be provided. Par-

tially these have been implemented by other research

projects. For example, the explanation of a formula’s

structure is supported by the JOBAD project that of-

fers ﬂexible elision and folding of sub-terms (Giceva

et al., 2009). The change of notations on-the-ﬂy while

reading a document is demonstrated by the document

reader

panta rhei

(M¨uller, 2010).

Several issues remain for the future. One of them

is a thorough evaluation whether (and when) adap-

tation of notations is beneﬁcial. After all authors

spend much time and consideration to select appro-

priate notations. Moreover,when adapting documents

with notations we also need to plan its content, which

brings us back to the initial intention of this work.

The following section extends the notation framework

for the content planning of documents. We will see

that we can reuse the speciﬁcation of extensional and

intensional contexts as well as the core adaptation

mechanisms.

ADAPTATION OF MATHEMATICAL DOCUMENTS - Exploring Document Structures, Metadata, and Context for the

Generation of User-specific Documents

145

3 CONTENT PLANNING

The previous section introduced the notation service,

a service on the presentation layer of mathematical

documents. This section focuses on two content plan-

ning services: The substitution replaces content with

alternative, user-speciﬁc content (a service on the

content layer) and the reordering rearranges content

(a service on the structure layer). Both services re-

quire the adaptability of structure and content layer.

This is supported by enriching content with alterna-

tive/variant content, by separating reusable from non-

reusable content, and by enriching structure with nar-

rative variations.

3.1 Variation on the Content Layer

This work deﬁnes two document parts as variants if

they are interchangeable though different in speciﬁc

properties. Some relations between document parts

like ‘translates’ or ‘formalizes’ indicate variant re-

lations: They express an equivalence and a difference

between two parts. Other relations like ‘more difﬁcult

than’ solely express a difference. Document parts re-

lated in such a relations can become variants if they

are essentially equal in certain properties, e.g., if they

share the same goal. For example, two proofs are goal

equivalent if they prove the same theorem.

Again to process variants, we need to make them

understandable to a computer system. For a machine-

processable representation of variants we can draw on

approaches such as conditional markup in DITA or

the markup of formal variants in OPENMATH. Un-

fortunately, neither approach is general and extensi-

ble enough for our purposes. Thus, two new markups

are proposed: A grouping of document parts into a

variants

environment and the annotation of variant

relations.

variants

<proof xml:id="p1" for="#lemma1"

ic="

difficulty:high

">...</proof>

<proof xml:id="p2" for="#lemma1"

ic="

difficulty:medium

">...</proof>

variants

Figure 3: XML-Encoding for Variant Groupings.

Figure 3 illustrates the grouping of three

proof

elements as variants. The

ref

element supports the

transclusion of the third proof from another part of

the document. The

attribute is used to encode the

difference of the three text paragraphs: They have dif-

ferent levels of difﬁculty.

Figure 4 presents the annotation of variant rela-

tions between the three proofs. We use the new meta-

data syntax for OMDOC (Lange and Kohlhase, 2009),

<proof xml:id="p1" for="#lemma1"

xmlns:cc="http://omdoc.org/var.ctxt?" >

<link rel="

cc:more difficult than

" href="#p2"/>

</metadata> ...

</proof>

Figure 4: XML-Encoding of Variant Relation Markup.

which uses RDFA to mark properties and relations.

The namespace declaration introduces the preﬁx

which points to a content dictionary. In OPEN-

MATH, such content dictionaries are used to deﬁne

the meaning of mathematical symbols. Here they are

used as background ontology for context metadata

and variant relations.

3.2 Variation on the Structure Layer

In addition to variants on the content layer, the pro-

posed content planning of mathematical documents

requires an adaptability on the structure layer. Hav-

ing selected mathematical documents turned out to

be very beneﬁcial: (1) Mathematical documents are

very explicit about relations. (2) Markup formats

like OMDOC already thoroughly mark the seman-

tic context of documents. Based on this, mathemati-

cal documents can be easily modularized into depen-

dency graphs, where nodes correspond to address-

able document parts and edges denote their dependen-

cies (which are inferred from relations like ‘proves’ or

‘illustrates’).

If we solely consider semantic aspects, the topic-

oriented approach is very natural for mathematical

documents. Respective adaptation routines have been

well elaborated. Nevertheless, mathematical formats

solely focus on semantic aspects and do not yet con-

sider the narrative ﬂow of texts. For example, para-

graph C in Figure 5 has to be placed before E as indi-

cated by the transitional text ‘see Pascal’s triangle be-

low’. Such transitions improve the coherence of doc-

uments but also reduce the reusability of their parts

in the adaptation. But we need a variation on content

and structure layer to support content planning!

E Pascal’s triangle is a geometric arrangement

of the binomial coefﬁcient in a triangle.

Row number n contains the numbers





for k = 0, ..., n.

C The notation





was introduced by An-

dreas von Ettingshausen in 1826, although

the numbers were already known centuries

before that (see Pascal’s triangle below).

Figure 5: Content of Paragraph E and C.

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

146

To address this problem, this work proposes an

extension of markup languages with a markup for

narrative variations. In a ﬁrst step, authors have

to mark all transitional words and phrases to allow

machines to separate them from the reusable parts of

documents. In a second step, authors have to mark

narrative dependencies between their document parts

and associate these with the transition texts. Finally,

authors can enrich their documents with alternative

narrative dependencies and transition texts.

With this extension, we can now distinguish se-

mantic dependencies (which are inferred from se-

mantic relations as deﬁned by formats like OM-

DOC) and narrative dependencies (which are added

to support narrative variations). In the terminology

of the content planning, these dependencies are re-

ferred to as transitions. They are traversed in or-

der to arrange document parts. Again to process

transitions they have to be represented in a machine-

processable form (M¨uller, 2010). With the machine-

processable representations of transition texts, such

texts no longer reduce the reusability of document

parts but can be ﬂexibly hidden or displayed. The

narrative context of documents, which is formed

by coherent transitions between document parts, has

been dynamized while preserving the coherence of

the adaptation results.

3.3 Modularising Narrative Documents

Most adaptation approaches focus on topic-oriented

documents. If we want to apply these approaches

to narrative documents, we ﬁrst need to modularize

them into self-contained, independent units. The new

markup for transition texts allows machine to distin-

guish narrative from reusable content and to extract

self-contained units. However, even if we could sim-

ply decompose narrative documents into topics, a co-

herent assembly into narrative documents is no longer

possible as topics omit transitional words and phrases.

Consequently, we need a new adaptation model.

This work proposes to modularize narrative doc-

uments into information units (called infoms) for

which all transition texts are preserved and narrative

and semantic dependencies are marked. These are

modelled as dependency graphs and processed dur-

ing the content planning. To increase the variation on

the content layer, variant infoms and variant relations

are identiﬁed. To increase the variation on the struc-

ture layer, alternative transitional texts and narrative

dependencies are marked.

This work is novel in that it distinguishes the se-

mantic context of document parts, the narrative con-

text of the document, and the user context. Users can

prioritize semantic, narrative or their individual con-

straints to guide the substitution and reordering – the

two content planning services addressed by this work.

In the following, both workﬂows are introduced.

3.4 The Substitution Service

The substitution is implemented as two-stage process.

In the ﬁrst stage, the document is abstracted, i.e., cer-

tain parts are made adaptable. In particular, these

parts are replaced with holes. The term ‘hole’ is used

to denote a representation of document parts without

substance, which has to be substituted with a con-

crete, user-speciﬁc document part. Thus, holes are the

content planning correspondent for content markup in

the rendering algorithm.

In the second stage, the abstract document (d2c)

is converted into a user-speciﬁc, concrete document

(doc

∆

) by substituting each hole with an appropriate

document part according to the user’s extensional and

intensional context speciﬁcation (ec

∗

and ic

∗

One contribution of this work is the ﬁnding that

there is a strong correlation between the render-

ing workﬂow for notations and the content planning

methods. Consequently, the substitution algorithm is

speciﬁed as generalization of the rendering algorithm:

The notation collector is replaced by the general in-

fom collector and the rendering grabber is substituted

with a variant sorter. Instead of iterating the subrou-

tines for each mathematical expression, the substitu-

tion is performed on each hole (2). The infom col-

lector returns a set of infoms (var

∗

) rather than no-

tation deﬁnitions. These infoms and the effective in-

tensional context (ic) are passed to the variant sorter.

The variant sorter ranks these infoms according to

how well their metadata matches with the user’s con-

text parameters (ic) and eventually returns the most

appropriate infom (var), which replaces (or ﬁlls) the

hole. The substitution returns a concrete document

(doc

∆

) in which each hole has been substituted with

user-speciﬁc content.

The substitution workﬂow has been implemented

as abstract document module of the JOMDOC library.

The

panta rhei

system has integrated JOMDOC to

demonstrate the generation of exams: Teaching assis-

tants can simply point to collections of exercises and

specify the context of the new exam (e.g., in terms of

language and difﬁculty level) and initiate the system

to generate an exam. An application to a big exer-

cise corpus is currently addressed in the TNTBASE

project (Zholudev and Kohlhase, 2010).

ADAPTATION OF MATHEMATICAL DOCUMENTS - Exploring Document Structures, Metadata, and Context for the

Generation of User-specific Documents

147

3.5 The Reordering Service

The reordering service preserves the grouping of in-

foms in coarse-grained document parts like chapters,

section, subsections, etc. It solely permutes the con-

stituents of these parts.

The reordering service allows users to choose be-

tween three ordering strategies. The context order-

ing orders the infoms according to how well their

metadata matches with the user context. It reuse the

functionality of the variant sorter of the substitution

algorithm and only provides a primitive solution that

should be used as fallback. Semantic and narrative

ordering process the dependency graph, where nodes

correspond to the collected constituents of sortable

document parts and edges denote their dependencies.

The semantic ordering arranges infoms according to

semantic transitions. The narrative ordering consid-

ers narrative transitions between infoms.

The reordering algorithm has been implemented

in the adaptor library (Adaptor, 2010), which was in-

tegrated in the

panta rhei

system to demonstrate the

ordering of the lecture notes of a theoretical computer

science course. So far the workﬂow has only been

applied to a small corpus, an application to a bigger

document collection remains for future research.

4 ADAPTATION IN PRACTICE

The proposed workﬂows have been implemented and

tested in several libraries (JOMDoc, 2010; Adaptor,

2010) and systems (Zholudev and Kohlhase, 2010;

Giceva et al., 2009). One of these systems is

panta

rhei

, a collaborative document reader and discussion

platform that has been used as supplement to a the-

oretical computer science lecture at Jacobs Univer-

sity. The system integrates the Java library JOMDOC

to support the adaptation of mathematical notations

as well as the substitution of document parts and the

adaptor library for the reordering.

5 CONCLUSIONS

This work has addressed the adaptation of narra-

tive documents, by applying the topic-oriented prin-

ciples of modularization and reuse to the narrative

world. Narrative documents are modelled as depen-

dency graphs, which are enriched by narrative varia-

tions and content variants. The novelty of this work is

the distinction of narrative context, semantic context,

and user context.

Mathematics is used as test tube, which required

us to specify the rendering of notations. A general-

ized/extended form of the notation framework now

supports the adaptation on all document layers. It em-

powers users to guide any step of the adaptation:(1)

Which document parts should be adapted/remain un-

changed, (2) the collection of adaptation objects (no-

tation deﬁnitions, infoms, context parameters), and

(3) the user-speciﬁc selection of the most appropriate

object to be applied.

Future research will focus on the thorough evalua-

tion of whether (and when) adaptation is beneﬁcial as

well as on the improvements of the adaptation meth-

ods, libraries, and systems.

REFERENCES

Adaptor (2010). The Adaptor Library. Retrieved from

https://trac.kwarc.info/panta-rhei/wiki/adaptor on

February 28, 2010.

Ausbrooks, R. et al. (2008). Mathematical Markup Lan-

guage 3.0. W3C Working Draft, W3C.

Buswell, S. et al. (2004). The OPENMATH Standard 2.0.

Technical report, The Open Math Society.

Giceva, J., Lange, C., and Rabe, F. (2009). Integrating

Web Services into Active Mathematical Documents.

In Carette, J. et al., editors, Conference on Intelli-

gent Computer Mathematics, LNAI 5625, pp. 279–

293. Springer.

JOMDoc (2010). JOMDoc — a Java Library for OMDoc

documents. Retrieved from http://jomdoc.omdoc.org

on May 28, 2010.

Kohlhase, M. (2006). OMDOC – An open markup for-

mat for mathematical documents [Version 1.2], LNAI

4180. Springer.

Kohlhase, M., M¨uller, C., and Rabe, F. (2008). Notations

for Living Mathematical Documents. In Autexier, S.

et al., editors, Proceedings of the Conference on Intel-

ligent Computer Mathematics, LNAI 5144, pp. 504–

519. Springer.

Lange, C. and Kohlhase, M. (2009). A Mathematical Ap-

proach to Ontology Authoring and Documentation.

In Carette, J. et al., editors, Conference on Intelli-

gent Computer Mathematics, LNAI 5625, pp. 389–

404. Springer.

M¨uller, C. (2010). Adaptation of Mathematical Documents.

PhD thesis, Jacobs University Bremen.

Zholudev, V. and Kohlhase, M. (2010). Scripting Docu-

ments with XQuery: Virtual Documents in TNTBase.

In Proceedings of Balisage Markup Conference 2010,

Montr´eal, CA. in press.

KMIS 2010 - International Conference on Knowledge Management and Information Sharing

148
