BROADER PERCEPTION FOR LOCAL COMMUNITY

IDENTIFICATION

F. T. W. (Frank) Koopmans and Th. P. (Theo) van der Weide

Institute for Computing and Information Sciences, Radboud University, Nijmegen, The Netherlands

Keywords:

Networks, Communities, Clustering, Local.

Abstract:

A local community identiﬁcation algorithm can identify the network community of a given start node without

knowledge of the entire network. Such algorithms only consider nodes within or directly adjacent to the

local community. Therefore a local algorithm is more effective than an algorithm that partitions the entire

network when only a small portion of a large network is of interest or when it is difﬁcult to obtain information

about the network (such as the world wide web). However, local algorithms cannot deliver the same quality

as their global counterparts that use the entire network. We propose an improvement to local community

identiﬁcation algorithms that will decrease the gap between relevant network knowledge of global and local

methods. Benchmarks on synthetic networks show our approach increases the quality of locally identiﬁed

communities in general and a decrease of the dependency on speciﬁc source nodes.

1 INTRODUCTION

The science of complex systems is a popular interdis-

ciplinary ﬁeld of research. Using a network to repre-

sent the elements and interactions in a complex net-

work is a commonly used tool to study complex sys-

tem phenomena (Strogatz, 2001; Albert and Barabasi,

2002). Such analysis is done (among others) on pro-

tein networks, social networks and (parts of) the in-

ternet (Newman, 2003; Palla et al., 2007).

Complex systems, and thus their representation as

a network, often exhibit an a-priori unknown struc-

ture of building blocks with varying functions. These

blocks are represented in the network as sets of nodes

that are densely connected and have relatively few

connections to the rest of the network. Such build-

ing blocks are referred to as modules, communities or

clusters. Identifying and observing such communities

may lead to a greater understanding of the structure

and functioning of a complex system. Many different

techniques for identifying all communities within a

network, with varying computational costs and accu-

racy, have been developed (Danon et al., 2005; Lan-

cichinetti and Fortunato, 2009).

In some cases one would rather identify a speciﬁc

community instead of all communities in the entire

network in order to reduce the amount of information

that needs to be processed or acquired. For example,

ﬁnding the community around a given website on the

internet or ﬁnding all friends of a speciﬁc person in a

social network. In such cases there should be no need

to process the entire network. A local community is a

community in the network identiﬁed by starting from

a start node and using only information from the con-

text of the local community to identify local commu-

nity members. Thus no knowledge of the entire net-

work is required.

There are many different approaches to local com-

munity identiﬁcation (Clauset, 2005; Schaeffer, 2005;

Chen et al., 2009). But local approaches have a lack-

ing quality compared to approaches that cluster entire

networks and they are overly dependant on a well cho-

sen start node (Bagrow, 2008).

In this paper we focus on improving local com-

munity identiﬁcation algorithms in order to increase

their overall quality and reduce the dependency on the

start node. First we discuss local community struc-

ture, then we propose an improvement to local algo-

rithms and ﬁnally we present benchmark results and

discussion thereof.

400

Koopmans F. and van der Weide T..

BROADER PERCEPTION FOR LOCAL COMMUNITY IDENTIFICATION.

DOI: 10.5220/0003069204000403

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 400-403

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

2 LOCAL COMMUNITY

IDENTIFICATION

A local community is considered from the perspec-

tive of a start node from which that community can

be generated. As a consequence, each node in the lo-

cal community has a special relation with this start

node and the local community as a whole is a reg-

ular community in the network. Local communities

are a soft clustering, where each node can be a mem-

ber of multiple communities, of a part of a network

thus overlap may occur. The ideal local community

for some start node v would be the community with

the highest quality that contains v. Let the quality of a

community C ⊆ N be quantiﬁed by community quality

measure µ(C).

A community is denoted as the set of nodes it con-

sist of. We deﬁne the universe of a community C, de-

noted as U(C), as all nodes that are outside of C and

adjacent to any node within C.

U(C) =



v ∈ N −C



∃

u∈C

[u → v]



(1)

The boundary of C, denoted as B(C), consists of

the nodes within the local community that have a re-

lation with nodes outside that community.

B(C) =



u ∈ C



∃

v∈U(C)

[u → v]



(2)

We introduce node relation ϕ(C, u, v) to indicate

that in community C node u is related to node v. This

relation is expressed by a path from u to v within that

community:

ϕ(C, u, v) ≡ u → v ∨ ∃

x∈C

[u → x ∧ ϕ(C, x, v)] (3)

where u → v denotes that there is an edge from u to v.

A local community C from the perspective of start

node v is a proper community, denoted as Φ(C, v), if

all its nodes are related to the start node:

Φ(C, v) = v ∈ C ∧ ∀

x∈C−v

[ϕ(C, v, x)] (4)

In that case, we refer to v as a proper generator of C.

A local community C may have different generators.

Furthermore, a node may be the generator of different

communities.

We will assume that the communities that can be

properly generated from the same start node can be

ordered hierarchically according to the subset rela-

tion:

Φ(C

, v) ∧ Φ(C

, v) =⇒ (5)

∃

[Φ(C, v) ∧C ⊆ C

∧C ⊆ C

]

We will call C a root community from node v, de-

noted as Φ

(C, v), if C is a minimal community that

can be properly generated from v:

(C, v) ≡ ∀

[Φ(X, v) ∧ X ⊆ C =⇒ X = C] (6)

Lemma 1. Let Φ

(C, v), then C =





Φ(X, v)



Note that Φ is not related to community quality.

The ideal local community for some start node v will

be a local community properly generated by v with

a maximal µ-score. We introduce argmax

x∈X

f (x) to

indicate that x ∈ X yields a result for f (x) that is not

surpassed by any value in X:

argmax

x∈X

f (x) =



x ∈ X



∀

y∈X

[ f (y) ≤ f (x)]



(7)

Let the set of communities where v is a proper

generator, denoted as ζ(v), be deﬁned as:

ζ(v) =



C ⊆ N



Φ(C, v)



(8)

then the set of ideal communities for start node v, de-

noted as I(v), is deﬁned as:

I(v) = argmax

C∈ζ(v)

µ(C) (9)

where multiple ideal local communities imply there

are different local community compositions for start

node v that yield the same µ-score, which is the max-

imum.

The computation of these ideal communities is not

feasible in practise because of the time complexity of

this measure. While we cannot use this concept in

practise it does provide insight in the desired result

from a local algorithm. It sets a goal, ﬁnd the best

local community around a given start node.

3 BROADENING THE LOCAL

SCOPE

A strong advantage of global community identiﬁca-

tion algorithms over their local counterparts is knowl-

edge of the entire network. For a local algorithm there

is no way of telling what lies beyond the universe of

the community it is building. There may be knowl-

edge about general network characteristics, but node

speciﬁc information is not available. This shortsight-

edness has a negative impact on the quality of the

resulting local community because local algorithms

tend to halt at every sign of community quality de-

cline, they cannot see possible improvement beyond.

A related and common problem for local algo-

rithms is their dependence on a well chosen start

node. Direct neighbors of a start node may not seem

like good building blocks for a community. A com-

monly applied band-aid solution to the start node de-

pendency is to make the local algorithm ignore its

stopping criterion until hitting a predetermined size or

quality to discourage preemptive stopping. But this

method relies on a preset threshold and thus priori

knowledge of the expected community size and struc-

ture. Also, after this preset threshold has been reached

BROADER PERCEPTION FOR LOCAL COMMUNITY IDENTIFICATION

401

the algorithm will still fail to see beyond minor barri-

ers.

We suggest the improvement of local community

identiﬁcation algorithms in general by adding more

contextual information to their selection criteria. By

making a local algorithm look ahead further than one

edge from the community we decrease the shortsight-

edness of this approach and allow for a more informed

and balanced judgement on community membership,

at the cost of higher computational and situational

crawling complexity. This improvement can be ap-

plied to any local algorithm.

We propose the following example application

where we extend the algorithm its network knowledge

by offering nodes one step beyond the universe. Be-

sides the universe node itself, we also investigate the

addition of that a node together with any combination

of its neighbors. This will provide insight into pos-

sible local community structure, and quality, that lies

beyond the community universe. The set of possible

addition sets for community C at distance 2, denoted

as A(C), is deﬁned as follows:

A(C) =

[

u∈U(C)



X ∪{u}



X ∈ ℘(b(u))



(10)

where b(u) =





u → v



is the set of nodes that can

be reached from u in one step. Then we are interested

in:

argmax

∈A(C)

µ(C ∪C

) (11)

Note that the computational complexity will in-

crease rapidly as the lookahead distance k is in-

creased, especially in dense networks. Further re-

search should consider different distances for the

lookahead approach, consider the quality and com-

putational complexity tradeoff and determine an opti-

mum (if any).

4 VALIDATION

Our improvement to local community identiﬁcation

algorithms as proposed in section three is validated

by a series of tests on synthetic networks. Since we

aim to verify the improvement of local identiﬁcation

algorithms in the area where these often struggle we

will generate networks with a low average degree (4,

5 and 8). This will result in networks that contain a

lot of potentially troublesome start nodes. We will

run four tests on every node in the network, varying

the algorithm (regular or improved) and the commu-

nity measure. We measure community quality by the

widely known local modularity (Clauset, 2005) and

relative density (Schaeffer, 2005; Lancichinetti et al.,

2009) deﬁnitions.

For our test we generate an undirected network

according to the Barabsi–Albert model (Albert and

Barabasi, 2002) and rewire it to create a ﬂat commu-

nity structure as proposed by Bagrow (Bagrow, 2008).

The rewiring is done by creating k sets of nodes (rep-

resenting the communities) in the network and then

rewiring inter-community edges to intra-community

edges while preserving the degree distribution. Our

benchmark networks contain 128 nodes equally di-

vided amongst 4 communities.

The quality of a community identiﬁcation algo-

rithm is evaluated by quantifying the similarity be-

tween the algorithm output and the synthetic commu-

nity structure. We will adopt the Jaccard Similarity

Coefﬁcient (JSC) which is deﬁned as the commonal-

ity of both sets divided by their generality:

JSC(X,Y ) =

|X ∩Y |

|X ∪Y |

(12)

4.1 Results

Running these tests on 50 generated networks yields

the plot of the JSC score frequency shown in Figure

1. In the networks with an average degree of 4 and

5 we observe a signiﬁcant increase in high similar-

ity and decrease of outliers for both quality measures

when our algorithm improvement is applied. There

is a relatively low gain for the more dense networks

with average degree 8. The plots also show that the re-

sult, while strongly improved, is not perfect yet. We

observe a couple of reasons why even the improved

algorithm is struggling for some start nodes.

First of all, when the boundaries of two communi-

ties are not very sharp and the start node is a bound-

ary node (as deﬁned by the synthetic graph structure)

the algorithm may start of in the wrong direction and

identify the wrong community. Suppose we start with

node v that is a member of community C according

to the synthetic structure. If the algorithm identiﬁes

∪ v where C

is another community deﬁned by the

synthetic structure, then the result of the algorithm

may be a quite strong community. But the similar-

ity measure will yield a bad result because there is

very little overlap between the reference community

and the found community.

Also, the local algorithm may ﬁnd a strong com-

munity that is a subset of the community it is sup-

posed to ﬁnd. The gap between the found commu-

nity and agglomerating until the algorithm identiﬁes

a larger and stronger community may be too large for

the lookahead algorithm to recognize. There lies a

tradeoff between the time complexity of the looka-

head algorithm and the effectiveness of identifying

improvement beyond the universe candidates.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

402

LM LM2 RD RD2

avgdeg 4

Jaccard Similarity Coefficient

frequency

0 1000 2000 3000 4000

LM LM2 RD RD2

avgdeg 5

Jaccard Similarity Coefficient

frequency

0 1000 3000 5000 7000

LM LM2 RD RD2

avgdeg 8

Jaccard Similarity Coefficient

frequency

0 2000 4000 6000 8000

Figure 1: This barplot illustrates the amount of times a test resulted in a score in the range of [0..1] for all four tests. A higher

frequency of high scores indicates a better result. LM2 and RD2 show the results when the improved algorithm is applied and

the community quality is measured by Local Modularity and Relative Density respectively.

Finally, the use of the synthetic network structure

while measuring quality is not ideal. When the goal

of a local algorithm is to identify the strongest com-

munity around a start node (as is the case in this pa-

per) that synthetic reference community may not be

the strongest community thus we may not compare

the algorithm output with the ideal community.

5 CONCLUSIONS

Local community identiﬁcation is particularly useful

in large networks where only a small part of the net-

work is of interest. However, the quality of local

identiﬁcation algorithms is lacking when compared to

their global counterparts. In this paper we suggest the

addition of contextual information beyond the direct

neighbors of a local community when evaluating lo-

cal community candidates. By decreasing the gap be-

tween relevant network knowledge of global and local

methods we improve the quality of local community

identiﬁcation algorithms in general.

Our experiments on synthetic networks have

shown promising results. Extending generic local

community identiﬁcation algorithms such that they

consider nodes one step beyond their universe will

lead to a signiﬁcant increase in quality and decrease

on start node dependency.

After deriving this approach from theory and

showing a proof of concept in this paper we are in-

terested in further research on several aspects. Firstly,

as suggested in section three, one should consider sev-

eral distances k where k > 1. Secondly, an analysis of

the computational complexity of this approach is re-

quired (while also considering varying network den-

sities). This should lead to an improved experiment

using both synthetic and real world datasets to deter-

mine the appropriate tradeoff between computational

complexity and quality.

REFERENCES

Albert, R. and Barabasi, A.-L. (2002). Statistical mechanics

of complex networks. Reviews of Modern Physics,

74:47–97.

Bagrow, J. (2008). Evaluating local community methods in

networks. J. Stat. Mech., page P05001.

Chen, J., Zaane, O., and Goebel, R. (2009). Local com-

munity identiﬁcation in social networks. ASONAM,

pages 237–242.

Clauset, A. (2005). Finding local community structure in

networks. Phys. Rev. E, 72:026132.

Danon, L., Duch, J., Diaz-Guilera, A., and Arenas, A.

(2005). Comparing community structure identiﬁca-

tion. J. Stat. Mech., page P09008.

Lancichinetti, A. and Fortunato, S. (2009). Community de-

tection algorithms: a comparative analysis. Phys. Rev.

E, 80:056117.

Lancichinetti, A., Fortunato, S., and Kertesz, J. (2009).

Detecting the overlapping and hierarchical commu-

nity structure of complex networks. New Journal of

Physics, 11:033015.

Newman, M. (2003). The structure and function of complex

networks. SIAM Review, 45:167–256.

Palla, G., Barabasi, A.-L., and Vicsek, T. (2007). Quantify-

ing social group evolution. Nature, 446:664–667.

Schaeffer, S. (2005). Stochastic local clustering for mas-

sive graphs. Lecture Notes in Artiﬁcial Intelligence,

3518:354360.

Strogatz, S. (2001). Exploring complex networks. Nature,

410:268–276.

BROADER PERCEPTION FOR LOCAL COMMUNITY IDENTIFICATION

403
