A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN

XML-IR FOR CONTENT AND STRUCTURE QUERIES

Luis M. de Campos, Juan M. Fern

andez-Luna, Juan F. Huete and Carlos Mart

ın-Dancausa

Departamento de Ciencias de la Computaci

on e Inteligencia Artiﬁcial

E.T.S.I. Inform

atica y de Telecomunicaci

on, CITIC-UGR, Universidad de Granada, 18071 Granada, Spain

Keywords:

Relevance Feedback, Information Retrieval, XML.

Abstract:

The use of structured documents following XML representation allows us to create content and structure

(CAS) queries which are more speciﬁc for the user’s needs. In this paper we are going to study how to enrich

this kind of queries with the user feedback in order to get results closer to their needs. More formally, we

are considering how to perform Relevance Feedback (RF) for CAS queries in XML Information Retrieval.

Our approach maintains the same structural constraints but expands the content of the queries by adding new

keywords to the original CAS query. These new terms are selected by considering their presence/absence in

the jugded units. This RF method is integrated in a XML-based search engine and evaluated with the INEX

2006 and INEX 2007 collections.

1 INTRODUCTION

Relevance Feedback (RF) is a very well-known iter-

ative technique to enhance the retrieval performance

of a search engine given a query formulated by a user

(Ruthven and Lalmas, 2003). When a user formulates

a query, the Information Retrieval System (IRS) gives

as a result a ranking of documents sorted decreasingly

by their relevance degree. Then the user inspects this

list and makes assessments with respect to the rele-

vance or non-relevance of the given documents con-

sidering her underlying information need. Then the

IRS is able to formulate a new query automatically

starting from the original query, integrating informa-

tion from the content of these assessed texts. This

new query, as it is based on the user’s direct opinion,

is supposed to be closer to the user’s requirements and

helps to enhance the performance of the system. Typ-

ically, this process is iterative and could be stopped

when the user is satisﬁed with the material returned

by the system in the different feedback steps.

XML-IR (Lalmas, 2009) is the IR ﬁeld dealing

with structured documents, i.e. those which are in-

ternally organized in a well deﬁned structure. In an

XML-IR search engine the internal structure of the

documents in the collection is exploited to give a fo-

cused access, i.e. the system could return any type of

element that it considers closer to the query (a para-

graph, a section or even the whole document).

Also, the internal structure can be exploited when

formulating the queries. In this case, the user is able

to express which document parts she is interested in,

and where the XML IRS has to search in order to

ﬁnd these relevant units. Broadly speaking, the user

may represent her information needs in two different

ways: by means of the classic keyword-based queries

composed of a sequence of keywords, known as Con-

tent Only queries (CO queries), or using Content And

Structure queries (CAS queries), which also take into

account this internal organization giving structural

hints about what XML elements to retrieve and where

to look for.

In order to show the differences between CO and

CAS queries we can consider the following queries:

• CO Query: ’I would like to read something about

the global warming in Asia.’ The output of the

system will be the list of the best structural ele-

ments (which might include some sections, sub-

sections, paragraphs or whole documents) satis-

fying this query.

• CAS Query: ’I would like to read sections about

Asia in articles dealing with global warming’.

The output of the system will be the list of sec-

tions (and only sections) matching this query.

Taking up again the RF subject, but now in the con-

text of XML-IR, the user is presented a list of docu-

ment elements sorted by their relevance degree. Then

she makes the corresponding decisions about the rele-

vance of some of them. The XML IRS may consider,

418

de Campos L., Fernández-Luna J., Huete J. and Martín-Dancausa C..

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE QUERIES.

DOI: 10.5220/0003080104180427

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 418-427

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

not only the content information of the judged ele-

ments, but also the type of element, in order to formu-

late a new query. Therefore, we could say that there

are three main types of RF, according to the type of

the original and resulting queries:

T1: CO – CO: The original query and the ex-

panded query are only composed of keywords.

New terms are usually added to the original

query and term weights (re)computed.

T2: CO – CAS: The original query is only com-

posed of keywords but the expanded query

generated by the RF method contains (new)

terms, and their corresponding weights, com-

plemented with structural restrictions ex-

tracted from the analysis of the assessments.

T3: CAS – CAS: Both queries are composed of

terms and structural restrictions. In this case,

there are two possibilities:

T3.1: Not to modify the structural restrictions

expressed in the original query but only

adding new terms to the underlying CO

queries.

T3.2: In addition to new terms, to modify the ex-

isting strutural restrictions or including new

ones.

Although, both CO–XX and CAS – CAS RF have

the same inputs, i.e. the triplet (Q,E,J) being Q the

original query, E a list of documents’ elements and

J a set of relevance judgments given to E, there ex-

ist some particularities that make the CAS-based RF

a different problem: Firstly, the way in which a sys-

tem must deal with CAS queries differs and secondly

the relevant judgments will have a different interpre-

tation. Thus, whereas the relevant judgments are well

deﬁned for CO queries

, this situation does not nec-

essarily hold for CAS queries. For example, in the

previous CAS query example, the user only judges a

list of sections (the output of the system). Thus, when

he/she considers a section as relevant we can assume

that it satisﬁes all the user’s requirements (it is about

Asia in a article dealing with global warming). But,

when the user judges a section as non-relevant it could

be because only one of the requirements are not ful-

ﬁlled (it might talk about Asia but the article does not

deal with global warming) or because both of them

are not relevant to the query.

RF of T1 and T2 types has been studied in the lit-

erature (see Section 3.4), but there exists few papers

dealing with T3 type. In this paper we will present

a content-oriented approach to solve the CAS–CAS

RF problem, particularly the T3.1 case. In this ap-

The user assesses whether the content of this element

E is relevant (or not) to Q.

proach we will study how the original query can be

expanded, i.e. including new terms (expansion terms)

in Q, in order to better capture the user information

needs. Some problems will be considered as how

many terms and in which parts of the query (structural

restrictions) they might be included. Therefore, the

main contribution of this paper is a content-oriented

CAS–CAS RF method, where terms are selected for

expansion not only from the assessed target elements

but also for the context elements, which are not ex-

plicitly judged to the users.

In order to describe the RF technique, this paper

is organized as follows: Next section introduces the

NEXI query language and how it was modiﬁed to al-

low the inclusion of new terms in the RF process.

Then, Section 3 presents our approach to RF when

using CAS queries and also the related works. In or-

der to evaluate the feasibility of our approach, Section

4 is devoted to the experimentation. Finally, Section 5

presents the concluding remarks and points out some

future research tasks.

2 PRELIMINARIES

In order to give the corresponding background to

understand the method presented in this paper, we

shall brieﬂy introduce the NEXI language to formu-

late CAS queries, as this is the starting point of our

CAS – CAS RF method.

To allow queries combining content and structure

(Content And Structure Queries, CAS queries) to be

speciﬁed, the NEXI language (Trotman et al., 2005)

was designed. It is a simpliﬁed XPath containing only

the descendant operator (//) in a tag path and also an

extended XPath containing the about function.

The kind of structured CAS query considered by

NEXI can take two possible forms:

• //C[D]: Returns C units that fulﬁll the condi-

tion D.

• //A[B]//C[D]: Returns C descendants of A

where A fulﬁlls the condition B and C fulﬁlls

the condition D.

A and C are paths (sequences of elements or struc-

tural units), specifying structural restrictions, whereas

B and D are ﬁlters, which specify content restrictions,

and // is the descendant operator (A//C, where C is a

descendant, though not necessarily a direct one of A).

C is the target path (the last structural unit in C is the

one that we want to retrieve) and path A is the con-

text. Each content restriction (as B or D) will include

one or several about clauses, connected by either and

or or operators; each about clause contains a text (a

sequence of words or terms) together with a relative

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE

QUERIES

419

path, from the structural unit which is the container of

the clause to the structural unit contained in it where

this text should be located. The about clause is the

IR counterpart of the classical contains clause used

in XPath (which requires an exact matching between

the textual content of the clause and a part of the

text in the structural element being evaluated). How-

ever, about does not demand such a strict matching

but states, vaguely, that a relevant element should sat-

isfy the information need expressed by means of the

text contained in the clause. The wildcard symbol ’*’

matches any tag and can be used to formulate key-

word queries in NEXI. Note that when using ’*’ we

are relegating to the search engine the decision about

which structural elements might be retrieved. Exam-

ples of NEXI queries are:

• Find sections about Asia in articles dealing with

global warming:

Q1=“//article[about(.,global

warming)//section[about(., Asia)]”

• Find any structural unit that contains a paragraph

dealing with NEXI in articles about information

retrieval:

Q2=“//article[about(.,information

retrieval)//*[about(//p, NEXI)]”

• Retrieve bibliography units containing text3,

which must be in chapter units with a text1-related

title and contain a section about text2:

Q3 = “//chapter[about(.//title, text1)

and about(.//section,

text2)]//bibliography[about(., text3)]”

Measuring the Importance of the Terms in XML-

RF After assessing the relevance status of the re-

trieved elements, a content-based XML-RF will se-

lect those terms used to expand the query. In order to

select these terms it is necessary to have a measure of

the relevance of each term to the query. For example,

whenever a term t

indexes an element judged relevant

by the user, perhaps we should increase the belief sup-

porting the relevance of t

; similarly, if a term t

only

appears in units which are not relevant, we should de-

crease its relevance belief. Therefore, it seems natural

that the relevance of a term will depend on its distri-

bution in relevant and non-relevant units.

In order to include this information in the new

query we propose to extend NEXI language with the

capability of managing weighted terms: For each

term in any about clause we include a weight in the

interval [0,1], expressing the importance of the term

in the query, being 1 very important and 0 not impor-

tant at all

(in Section 3.3 we will discuss how these

weights are computed). For instance, the previous

query including term weights could be the following

//article[about(.,0.9*information

1.0*retrieval)//*[about(//p,0.9*NEXI)].

3 THE CONTENT-ORIENTED RF

METHOD FOR CAS QUERIES

In this section we are going to present our CAS–CAS

RF approach. In general terms, our proposal focuses

on creating a new expanded CAS query keeping the

same structural restrictions as the original but expand-

ing the different content sub-queries of the context

and target parts (the content queries included in each

about clause of the NEXI query). This is one of the

main diferences between our proposal and those in the

literature (see Section 3.4).

3.1 Managing CAS Queries in XML

Systems

With the aim of offering a background to well under-

stand the approach presented in this paper, we have to

brieﬂy outline a typical scheme to solve CAS queries

in XML systems. Let us imagine that the previous

Q3 query has been submitted to the system (query of

type //A[B]//C[D]). In this query, the structural re-

strictions are represented by means of the target ele-

ments, which are the bibliography units and the con-

text which are chapter units.

The basic idea is to decompose the original CAS

query in several simple CAS sub-queries, i.e. a CAS

query having only one structural restriction on the tar-

get element. The content of each query corresponds

to the content part of the related about clauses. In our

example, the sub-queries are:

1 = //chapter[about(.//title,text1)]

2 = //chapter[about(.//section,text2)]

3 =//chapter[about(.//bibliography,

text3)]

These sub-queries are submitted to the IRS in-

dependently and, for each one, a list of relevant

elements satisfying the structural restrictions is re-

trieved, ordered by the Relevance Status Value

(RSV). In the example, the system would re-

trieve //chapter//title, //chapter//section and //chap-

ter//bibliography, for each respective sub-query.

Note that a weight equal to zero does not mean that the

structural units that contain the term have to be excluded.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

420

The next step is to compute an aggregated

RSV for structural units of the same type for

the context and the target (RSV ((//chapter)

,B)

and RSV ((//chapter//bibliography)

,D), respec-

tively

. Finally, it is necessary to combine

these units and their relevance values to obtain

the ﬁnal relevance degree of each bibliography

unit in relation to the complete structured query,

RSV ((//chapter//bibliography)

|Q).

3.2 RF and CAS Queries

Once the whole CAS query is submitted to the IRS the

user inspects the ranking and makes the correspond-

ing relevance assessments (explicitly or implicitly).

In our approach, the system will analyze the judged

elements and extracts new terms which will be used

to expand the query considering both, target and the

context, structural restrictions.

In order to do that, the system must be able to

reﬁne the existing simple sub-queries independently

on their location in the CAS query. When expanding

the target sub-queries there is no problem because we

know the relevance values of related elements, but this

situation does not hold for the rest of the structural re-

strictions, i.e. context restrictions. This is because the

units that might be considered to extract the terms for

these sub-queries are usually different to the type of

the target unit, and therefore the user did not directly

assess relevance judgments on these units.

The problem is how to ﬁnd those appropriate

structural elements from where to select the expan-

sion terms. In order to tackle this problem, in this

paper we are going to consider the following assump-

tions:

• Relevance Assumption: If a user judges a target

element as relevant, then all the context elements

used to generate the ﬁnal RSV are considered also

relevant.

• Non-Relevance Assumption (Hard): If a user

judges a target element as non-relevant, then all

the context elements used to generate the ﬁnal

RSV are considered also non-relevant.

This last assumption can be considered very restric-

tive, so we propose also to consider a light version.

• Non-Relevance Assumption (Soft): If a user

judges a target element as non-relevant, then we

can not infer any relevance value about the con-

text units used.

With the subindex l we mean any of the units compati-

ble with the context and targets XPaths.

By means of these assumptions we can infer the

relevance value for other different units that the ones

the user inspects. Therefore, to perform term expan-

sion in CAS – CAS RF we have to keep track of the

units used to compute the relevance degree for each

element presented to the user. These units will be used

to select the most useful terms to expand the content

sub-queries, and to compute their weights represent-

ing their importance.

In order to illustrate this process we will consider

the following example where the target is any section

included in an article:

Find those sections having a paragraph about

NEXI in a article dealing with information re-

trieval.

//article[about(.,information

retrieval)//section[about(//p, NEXI)]

Left hand side of Figure 1 shows three results pre-

sented to the user and the assessed relevance judg-

ments. According to the method sketched in Section

3.1 to solve CAS queries, these results have to be ob-

tained by the combination of the different units re-

trieved after submitting to the system the set of sim-

ple subqueries. Thus, if we denote by R(Q,k) the k

result for query Q, we have that

R(Q,k) = ⊗

i=1

being Q

,..., Q

the set of simple sub-

queries and R

) each one of the interme-

diate results. In our example, we have two

simple CAS subqueries Q1 = //article[

about(., information retrieval)] and Q2 =

//article//section[about(//p, NEXI)]. The

ﬁrst one returns a set of articles and the second one a

set of paragraphs in a section.

Let us focus on R

) since they will have an

special role in our CAS–CAS RF approach. In this

case, it is also possible that there exist several units

in the subquery playing a role in the creation of this

result, and as consequence they are candidate units

from where we might extract the expansion terms.

We named these units the set of generators, G

, i.e.

relevant units in a subquery satisfying at the same

time the structural restrictions. Let us follow with

our example by focusing on R

(Q2), i.e. the re-

sults of Q2 involved in the ﬁrst judged result of

Q. In this case it is possible to have several para-

graphs including the term NEXI in the same sec-

tion. Particularly, looking at right hand side of Fig-

ure 1 (the format is: RSV * unit XPath * XML ﬁle

to which it belongs and the sub-query that they sat-

isfy) we found that the paragraphs p[2] and p[4]

in /article[1]/chapter[3]/section[4] satisfy

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE

QUERIES

421

CAS Query: //article[about(.,Information Retrieval)]//section[about(//p,NEXI)]

Information stored in the Final Ranking

List of Judged Results

Units combined to get the Final Results

/article[1]/chapter[3]/section[4]

(Relevant)

0.6*/article[1]*1.xml (from subquery 1)

0.7*/article[1]/chapter[3]/section[4]/p[2]*2.xml (from subquery 2)

0.3*/article[1]/chapter[3]/section[4]/p[4]*2.xml (from subquery 2)

/article[1]/appendix[5]/section[1]

(Non-Relevant)

0.7*/article[1]*1.xml (from subquery 1)

0.3*/article[1]/appendix[5]/section[1]/p[3]*2.xml (from subquery 2)

/article[1]/chapter[2]/section[2]

(Relevant)

0.4*/article[1]*1.xml (from subquery 1)

0.4*/article[1]/chapter[2]/section[2]/p[7]*2.xml (from subquery 2)

Figure 1: Assessed elements with their corresponding set of generators.

this property, and they are the set of generators for

(Q2).

In order to speed up the query expansion process,

for each set of generators only one unit (the one hav-

ing the highest RSV) is considered as a candidate to

extract the expansion terms. Thus,

) = arg

u∈G

maxRSV (u,Q

Then, the union of these elements for all the n

judged results are the units satisfying the structural

restrictions associated to each sub-query, named the

set of sub-query expansion units (SEU):

SEU(Q

) = ∪

r=1

R(Q

,r)

In our example we have the following set of sub-

query expansion units:

• SEU (Q

): /article[1]

• SEU (Q

/article[1]/chapter[3]/section[4]/p[2]

/article[1]/appendix[5]/section[1]/p[3]

/article[1]/chapter[2]/section[2]/p[7]

3.3 Selecting the Expansion Terms

Each subquery Q

will be expanded by selecting the

terms from SEU (Q

). This is one of the differences

from the diferent approaches for CO–CO RF where

the terms were selected from those judged units. In

this process there are two different, but related, prob-

lems: Which are the expansion terms and what are the

weights associated to them.

In order to deal with the ﬁrst problem in this paper

we are going to assume that only those terms belong-

ing to relevant elements in SEU (Q

) but not belong-

ing to any non relevant elements in SEU(Q

) can be

considered as candidates for the expansion of the sub-

query Q

. In other words, a term in an non relevant el-

ement can not be an expansion term. This is because

we are assuming that the content of these elements,

which have a great literal similarity with the query, is

not related to the query intention.

Therefore, by taking up again the assumptions

in Section 3.2 the candidate terms for a sub-

query Q

will be determined. Nevertheless, de-

pending on the type of the non-relevance assump-

tion (soft or hard) considered, the set of candidate

terms might differ. In our example, focusing on

the subquery Q

, a term t

that belongs to both,

/article[1]/chapter[3]/section[4]/p[2] and

/article[1]/appendix[5]/section[1]/p[3] is

a valid candidate if we use the soft non-relevance as-

sumption, whereas this term can not be a valid candi-

date when considering the hard version.

Once we know the candidate terms, the second

step will be to select the best ones. In order to deal

with this problem we will use a weight measuring

the importance of each term. Then, those k candi-

date terms with the highest importance weights ex-

pand the corresponding subquery. Particularly, for a

given subquery Q

, we assume that the importance of

a candidate term t depends on the number of relevant

elements in SEU(Q

) in which it appears. Then it is

computed according to the following expression:

w(t) =

, (1)

where n

denotes the number of relevant elements

of the set SEU(Q

) that contain t, and n

denotes the

total number of relevant elements of that set.

Finally, the expanded CAS query can be formed

by adding the k top-weighted terms to the original

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

422

query. In this new query the original query terms are

weighted with 1.0 and the expanded terms with their

corresponding importance weights.

3.4 Related Work

RF has been the objective of many researchers as a

mean of improving retrieval effectiveness in XML-IR.

Firstly, we can start studying the Rocchio algorithm

(Rocchio, 1971) in which most of the works under-

taken in content RF in structured IR are based on. It

consists of extracting the expressive terms from the

elements judged relevant by the user. Each element

is seen as a retrieved unit, and elements are therefore

considered to be independent from each others, even

though they appear in the same document. Ruthven

and Lalmas (Ruthven and Lalmas, 2003) have stud-

ied different RF techniques (automatic and interac-

tive techniques), speciﬁc interfaces to RF systems and

characteristics of searches that can affect the use and

access of RF systems.

After that, we shall describe some works concen-

trated on query expansion based on the content of el-

ements with known relevance: The works of Y. Mass

(Mass and Mandelbrod, 2004) and C. Crouch (Crouch

et al., 2005) are very similar, the only difference be-

tween them is in the way of evaluating the queries (au-

thors use respectively distinct indexes with the vec-

tor space model or a relevance propagation method).

In (Sigurbj

ornsson et al., 2004), the authors investi-

gate the effectiveness of blind (“pseudo”) feedback

and Pan et al. (Pan et al., 2004) apply user feedback to

recompute similarities in the ontology used for query

evaluation.

On the other hand, several papers have considered

structural query expansion which is the objective of

this paper: The ﬁrst work is developed by Mihajlovic

et al. (Mihajlovic et al., 2004) to extend their database

approach. They assume that knowledge of component

relevance provides “implicit structural hints” which

may be used to improve performance. Their imple-

mentation is based ﬁrst on “extracting the structural

relevance” of the top-ranked elements and then re-

structuring the query and tuning the system based on

RF information. They argue that the document names

of the relevant components are used to model struc-

tural relevance because these documents are apt to

contain similar information. Using the structural in-

formation and assessments associated with the rele-

vant elements, the query is rewritten and evaluated.

The second approach, proposed by Schenkel and

Theobald (Schenkel and Theobald, 2006), consists of

extracting classes of features for each relevant ele-

ment. These classes of features are: the ancestor

class, the descendant class and the content class. For

example, for a given relevant element section, arti-

cle and body elements are added to the ancestor class,

paragraph and subsection elements are added to the

descendant class, and terms of the section element are

added to the content class.

A third approach has been proposed in (de Cam-

pos et al., 2009). The main contribution of this ap-

proach is that the system automatically selects the

best part of the document to be retrieved. Particu-

larly, they consider the expected utility of retrieving

each element or structural unit of the documents in a

XML collection. Then, after analyzes the retrieved

elements the expansion terms are obtained and a new

query was submitted to the system.

Fourati et al. (Fourati et al., 2009) propose an ap-

proach where they take the original CAS query and

the fragments judged as relevant by the user. Then,

they create a representation of the original query and

relevant fragments under a matrix form. After some

processing and calculations on the obtained matrix

and after some analysis they have been able to identify

the most relevant nodes and their relationships that

connect them. These are used to modify the structure

of the new query but keeping the same content.

Finally, L. Hlaoua et al. (Hlaoua et al., 2006) pro-

pose to add structural constraints to the initial key-

word query. Their approach ﬁrst seeks to identify the

generic structure shared by the largest number of rel-

evant elements and then they use this information to

incorporate in the expanded query.

4 EXPERIMENTATION

In this section, we shall describe the framework of the

experimentation in order to validate our RF approach,

as well as discuss the corresponding results. First, we

have to highlight the fact that this CAS – CAS RF

approach could be used to expand CAS queries for

any XML IRS where terms could be weighted.

In general, a CAS query retrieval process can be

implemented by means of several modules which are

external to the base XML IRS in order to work with

NEXI queries but in our case, and in order to evaluate

its performance, it has been used on the top of the

Garnata IRS (de Campos et al., 2006), an Information

Retrieval System, designed to work with structured

documents in XML.

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE

QUERIES

423

Table 2: Results of the experiments for context expansion.

Context Exp (Hard). Context Exp (Soft).

k iP[0.01] iP[0.05] iP[0.10] AiP iP[0.01] iP[0.05] iP[0.10] AiP

Without RF 0.3460 0.2589 0.2214 0.0831 0.3460 0.2589 0.2214 0.0831

1 0.3539 0.2729 0.2427 0.0848 0,3323- 0,2624- 0,2213- 0,0833-

2 0.3144 0.2652 0.2346 0.0822 0,3148+ 0,2754+† 0,2326- 0,0842+

3 0.2998 0.2499 0.2292 0.0799 0,3044+ 0,2709+ 0,2376+ 0,0848+

4 0.2990 0.2555 0.2319 0.0806 0,2907- 0,2667+ 0,2373+ 0,0838+

5 0.3131 0.2650 0.2382 0.0816 0,2939- 0,2717+ 0,2444+† 0,0841+

6 0.3078 0.2639 0.2366 0.0802 0,3010- 0,2768+† 0,2526+† 0,0849+†

7 0.3147 0.2634 0.2338 0.0802 0,2956- 0,2719+ 0,2484+† 0,0848+

8 0.3064 0.2642 0.2337 0.0794 0,3047- 0,2793+† 0,2369+ 0,0826+

9 0.3143 0.2645 0.2315 0.0790 0,2920- 0,2666+ 0,2326+ 0,0832+

10 0.3167 0.2696 0.2287 0.0792 0,2948- 0,2617- 0,2267- 0,0825+

Table 1: Query statistics.

Year n(Q

) n(Q

) l(Q

)

2006 1.24 1.03 2.32 2.12

2007 1.39 1.12 1.73 1.94

4.1 Data Set and Evaluation Measures

We have performed several experiments with the col-

lections and CAS queries at INEX 2006

and INEX

2007

in order to validate our proposal. The XML

document collection considered in the experimenta-

tion is the one used in the last editions of the INEX

Conference, namely Wikipedia (an XML version of

the English Wikipedia), at the beginning of 2006 (De-

noyer and Gallinari, 2006) with its 659388 articles

(around 4600 Megabytes in size).

In terms of the queries (and the corresponding rel-

evance assessments) used in our experiments, we have

used a subset of the queries developed for INEX’2006

(34 CAS queries) and INEX’2007 (36 CAS queries).

Particularly, we consider those queries having CAS

restricctions. Table 1 shows some statistics of these

queries. Second and third columns show the mean

number of subqueries for the target and context com-

ponent, and fourth and ﬁfth present the mean lengths

of the queries.

In those queries where there is no structural re-

strictions, as for example the case of “ﬁnd any struc-

tural unit that contains a paragraph dealing with

term”

, we have considered the focused task of INEX

Ad-hoc track (Kamps et al., 2008). The objective is

to retrieve the most relevant parts of the documents,

without overlapping. Therefore, if a chapter is re-

http://inex.is.informatik.uni-duisburg.de/2006/

http://inex.is.informatik.uni-duisburg.de/2007/

In NEXI language, queries having the wildcard symbol

* as for example “//*[about(//p, term)]“.

trieved, and therefore, considered the most appropri-

ate type of element that matches the query, none of its

sections should be retrieved.

The measures of retrieval effectiveness are those

used in the focused task of the INEX’2007 ad hoc

track, namely the interpolated precision (iP) at se-

lected recall levels (iP[0.01], iP[0.05] and iP[0.10])

and the average interpolated precision (AiP), all of

them averaged across the 70 queries.

4.2 Evaluation Methodology

The objective is to compare the results returned by the

search engine for the original and expanded queries,

which are generated after knowing the relevance of

the ﬁrst 10 structural units of the result list (this rele-

vance information is obtained from the relevance as-

sessments of INEX), so we can test if the expansion

of CAS queries with our approach is interesting.

This comparison is not an easy task because the

results from the expanded query could apparently be

very positive due to the fact that the elements judged

as relevant will probably appear in the ﬁrst posi-

tions of the result list of the expanded query (this

fact is called ranking effect). The use of this data

for the training in the evaluation has an overﬁtting

effect which artiﬁcially improves the results. For

this reason, there are different techniques to evaluate

RF methodologies like residual collection or freezing

(Chang et al., 1971).

In our case, we will use the residual collection

method, but it has been adapted for structured docu-

ments (because we must take into account that if one

unit has been judged as relevant, then we have rele-

vance information about other units which could ap-

pear in the result list being ancestors or descendants of

it) and the focused task. Therefore, the method works

as follows:

• Original query: We consider the original ranking

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

424

of the system, after removing the ﬁrst 10 judged

structural units. This ranking will be considered

the baseline.

• Expanded query: The system runs the new ex-

panded query and then all the structural units

overlaping with the ﬁrst 10 judged elements are

removed.

Then, these two retrieval lists could be compared

in order to measure the impact of RF, computing a

percentage of change in the performance measures.

4.3 Experimental Results

The ﬁrst experiments that we have designed and run

under this evaluation framework, are based on the ex-

pansion of the sub-queries using different number of

terms and the expansion in different parts of the orig-

inal query. With the ﬁrst parameter, we would like to

know the impact in the query performance when the

number of terms increases. With respect to the part of

the CAS query to be expanded, we are interested in

knowing which part of the query is more appropriate

for expansion. The number of terms used for the ex-

pansion is ranged from 1 to 10 and the expanded parts

are:

• Full expansion: All the sub-queries of the struc-

tural query are expanded.

• Context expansion: The sub-queries of the con-

text part are expanded. In this case we will con-

sider both the soft and hard version of the non-

relevance assumption.

• Target expansion: The sub-queries of the target

part are expanded.

The results of these experiments are summarized

in Tables 2 and 3. They display in the ﬁrst row the

corresponding effectiveness measures for the baseline

(Original query) and for each one of the experimental

settings.

Focusing on the context subqueries (Table 2) we

use bold face to indicate the best results for each mea-

sure. Also, in those columns associated with the soft

non-relevance assumption (right hand side of the ta-

ble), we denote by the symblol + (or −) when un-

der the same number of expansion terms the soft ver-

sion is better (worse) than the hard one and we use the

symbol † to indicate that this option is better than the

best results obtained using the best expansion for the

hard version, i.e. to use only one expansion term.

From Table 2 some conclusions might be ob-

tained, ﬁrst that by expanding only the context sub-

queries we can obtain minors improvements with re-

spect to the baseline (even in some cases the ex-

pansion of only the context part is not a good solu-

tion). Thus, the best results obtained for each mea-

sure achieve the following improvements: 2.30% for

iP[0.01], 7.88% for iP[0.05], 14.09% for iP[0.10] and

2.16% for AiP. Second, me might say that the perfor-

mance of the soft version outperforms the results of

the hard version when, under the same circumstances,

we compare 1-to-1, but soft version barely outper-

forms the best results of the hard version, obtained

when adding only one expansion term. As general

conclusion we can say that it is better to consider the

hard version for the non-relevance assumption. This

is because the soft version, which best results seem to

be obtained using 6 expansion terms, does not get, in

mean, better results than the best hard version. There-

fore, in the rest of the paper we will only consider the

hard version.

Focusing on Table 3, we present the results ob-

tained by expanding only the target subqueries and

also when expanding both subqueries, target and con-

text (in its hard version), named full expansion. In the

case of full expansion we have used the same number

of expansion terms in all the subqueries. In this table

we highlight with bold face the best results obtained

for each measure.

The ﬁrst conclusion that can be obtained is that the

results obtained in this table are much better than the

ones obtained using context expansion. Comparing

full and target expansions, the ﬁrst one, in general, ob-

tains better results in all the measures with signiﬁcant

differences although it is smaller in the AiP measure.

With respect to the number of expansion terms, using

from 3 to 5 terms for every sub-query is the best so-

lution because the improvements we can achieve go

from 19.57% to 23.57% for the AiP measure in the

full expansion and from 19.77% to 22% in the target

expansion, but these improvements are higher if we

consider other measures like the ip[0.10], where the

percentages are ranging from a minimum of 39.92%

to a maximum of 43.90% in the full expansion and

from a minimum of 28.57% to a maximum of 33.48%

in the target expansion.

We believe that this best performance for these

numbers of terms is due to the short length of the sub-

queries (around two terms in average, with a maxi-

mum of four terms). So, if we consider fewer terms

(1-2) we can also get some improvements but they are

not so signiﬁcant, and the use of more than 6 terms

provokes the decreasing of performance because we

could be introducing non representative terms in the

expanded sub-queries, thus changing the focus of the

original query and hence generating worse results.

Another important conclusion is that context and

target expansion reinforce each other. In most of the

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE

QUERIES

425

Table 3: Results of the experiments for full and target expansion.

Full Exp. Target Exp.

k iP[0.01] iP[0.05] iP[0.10] AiP iP[0.01] iP[0.05] iP[0.10] AiP

Without RF 0.3460 0.2589 0.2214 0.0831 0.3460 0.2589 0.2214 0.0831

1 0.4239 0.3267 0.2848 0.0920 0.4080 0.3196 0.2716 0.0911

2 0.4361 0.3439 0.2923 0.0939 0.4107 0.3349 0.2744 0.0943

3 0.4433 0.3558 0.2984 0.0952 0.4177 0.3343 0.2730 0.0959

4 0.4356 0.3648 0.3186 0.1028 0.4312 0.3392 0.2955 0.1013

5 0.4407 0.3604 0.3116 0.0993 0.4294 0.3437 0.2895 0.0995

6 0.4137 0.3530 0.3098 0.0998 0.4063 0.3255 0.2847 0.0995

7 0.4245 0.3488 0.3111 0.0986 0.4147 0.3230 0.2784 0.0982

8 0.4158 0.3444 0.3106 0.0984 0.3907 0.3092 0.2790 0.0975

9 0.4188 0.3454 0.3059 0.0976 0.4008 0.3091 0.2733 0.0971

10 0.4283 0.3505 0.3078 0.1006 0.3938 0.3036 0.2707 0.0982

Table 4: Results of the experiments varying the number of expansion terms (k) in context sub-queries and ﬁxed to 4 in target

sub-queries.

k iP[0.01] iP[0.05] iP[0.10] AiP

Without RF 0.3460 0.2589 0.2214 0.0831

1 0.4355 0.3591 0.3121 0.1035

2 0.4427 0.3700 0.3164 0.1040

3 0.4349 0.3643 0.3159 0.1019

4 0.4356 0.3648 0.3186 0.1028

5 0.4401 0.3681 0.3202 0.1015

6 0.4326 0.3633 0.3196 0.1004

7 0.4345 0.3626 0.3178 0.0995

8 0.4313 0.3568 0.3160 0.0994

9 0.4229 0.3461 0.3067 0.0972

10 0.4269 0.3510 0.3122 0.0979

experiments we have that the measure’s values of the

full expansion are strictly greater than the ones ob-

tained by expanding context or target isolately. More-

over, the improvement’s percentages obtained with a

full expansion are greater than the sum of the im-

provements obtained by context and target expansion.

Once we know that full expansion is the most ap-

propriate approach to expand CAS queries, we could

wonder how a different number of expansion terms in

the context and targets sub-queries could affect the re-

trieval performance. In order to answer this question

we have designed the following experiment: Firstly,

we ﬁx to 4 the number of expansion terms for the tar-

get subquery (we assume that a good performance is

achieved with this conﬁguration). Then, a new exper-

iment has been run by varying the number of expan-

sion terms in the context subqueries from 1 until 10.

Table 4 shows the absolute results obtained (in bold-

face the best results for each measure).

Observing this table, we could conclude that the

consideration of a different number of terms used to

expand in both parts of the CAS query is relevant in

terms of retrieval performance. In general, the best

overall results are obtained by using a different num-

ber of terms: four in the target (ﬁxed) and two terms

in the context, although it represents a minor improve-

ment (around 1%) with respect to using four terms

also in the context. These results agree with the ones

obtained expanding only context in the original query,

as a large number of expansion terms in the context

seems to worse the performance. It seems more ef-

fective to leave the original context sub-queries un-

changed since, for retrieval purposes, they are less im-

portant than the target sub-queries.

5 CONCLUDING REMARKS

AND FUTURE RESEARCH

We present in this paper a new relevance feedback

framework for content and structure (CAS) queries.

This approach modiﬁes the original queries keeping

the same structural restrictions but expanding the key-

word sub-queries with a best top weighted terms. This

framework has been evaluated with INEX 2006 and

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

426

INEX 2007 collections.

Our future work will be concentrated on determin-

ing different rules for the expansion of sub-queries

studying different features of the original one with

the objective of getting the best number of terms for

the expansion of the sub-query. This process should

be automatic adapting the query to the user’s needs.

Also it is interesting to study how to apply negative

feddback in this framework, i.e. how to use the terms

in the non relevant units in order to best capture the

real intention of the user query.

Another interesting issue could be to modify

structural constraints (only in the context) in the

new expanded query. The objective part should not

be changed because this indicates the structural unit

which the user is interested in, so it must be the same

in both original and expanded queries but it could be

interesting to change, in some cases, the context re-

strictions.

ACKNOWLEDGEMENTS

This paper has been supported by the Consejer

ıa de

Innovaci

on, Ciencia y Empresa de la Junta de An-

daluc

ıa and the Spanish Ministerio de Ciencia de In-

novaci

on by means of the projects P09-TIC-4526 and

TIN2008-06566-C04-01, respectively.

REFERENCES

Chang, Y., Cirillo, C., and Razon, J. (1971). Evaluation

of feedback retrieval using modiﬁed freezing, residual

collection & test and control groups. The SMART Re-

trieval System: Experiments in Automatic Document

Processing, chapter 17, pages 355–370.

Crouch, C. J., Mahajan, A., and Bellamkonda, A. (2005).

Flexible XML retrieval based on the extended vector

model. In N. Fuhr, M. Lalmas, S. M. and Szl

avik, Z.,

editors, INEX 2004. Lecture Notes in Computer Sci-

ence, volume 3493, pages 292–302. Springer, Heidel-

berg.

de Campos, L. M., Fern

andez-Luna, J. M., Huete, J., and

Romero, A. (2006). Garnata: An information retrieval

system for structured documents based on probabilis-

tic graphical models. In Proceedings of the IMPU’06

conference, pages 1024–1031.

de Campos, L. M., Fern

andez-Luna, J. M., Huete, J. F., and

Mart

ın-Dancausa, C. (2009). Content-oriented rele-

vance feedback in XML-ir using the Garnata Infor-

mation Retrieval system. FQAS 2009, Lecture Notes

in Artiﬁcial Intelligence, 5822:617–628.

Denoyer, L. and Gallinari, P. (2006). The wikipedia XML

corpus. SIGIR Forum, 40:64–69.

Fourati, I., Tmar, M., and Hamadou, A. (2009). Structural

relevance feedback in XML retrieval. FQAS 2009.

Lecture Notes in Artiﬁcial Intelligence, 5822:168–

178.

Hlaoua, L., Sauvagnat, K., and Boughanem, M. (2006).

Structure-oriented relevance feedback in XML re-

trieval. In Proceedings of the 15th ACM international

conference on Information and knowledge manage-

ment, pages 780–781. ACM.

Kamps, J., Pehcevski, J., Kazai, G., Lalmas, M., and

Robertson, S. (2008). INEX 2007 evaluation mea-

sures. INEX 2007. Lecture Notes in Computer Sci-

ence, 4862:24–33.

Lalmas, M. (2009). XML Retrieval. Morgan&Claypool.

Mass, Y. and Mandelbrod, M. (2004). Relevance feedback

for XML retrieval. In INEX 2004 Workshop, pages

154–157.

Mihajlovic, V., Ramirez, G., de Vries, A. P., Hiemstra, D.,

and Blok, H. E. (2004). Tijah at inex 2004 model-

ing phrases and relevance feedback. pages 276–291.

INEX 2004 Workshop Proceedings.

Pan, H., Theobald, A., and Schenkel, R. (2004). Query

reﬁnement by relevance feedback in an XML retrieval

system. pages 854–855. ER 2004.

Rocchio, J. J. (1971). Relevance feedback in information

retrieval. The SMART retrieval system-experiments in

automatic document processing, pages 313–323.

Ruthven, I. and Lalmas, M. (2003). A survey on the use

of relevance feedback for information access systems.

Knowledge Engineering Review, 18(2):95–145.

Schenkel, R. and Theobald, M. (2006). Structural feedback

for keyword-based XML retrieval. In Lalmas, M., ed-

itor, In Advances in Information Retrieval. 28th Euro-

pean Conference on IR Research (ECIR 2006) Lecture

Notes in Computer Science, volume 3936, pages 326–

337. Springer.

Sigurbj

ornsson, B., Kamps, J., and de Rijke, M. (2004). The

university of amsterdam at inex 2004. pages 104–109.

INEX 2004 Workshop.

Trotman, A., Sigurbj

ornsson, B., Fuhr, N., Lalmas, M., Ma-

lik, S., and Szlvik, Z. (2005). Narrowed extended

XPath i (NEXI). In Lecture Notes in Computer Sci-

ence, volume 3493, page 1640. Springer Verlag, Hei-

delberg.

A CONTENT-BASED APPROACH TO RELEVANCE FEEDBACK IN XML-IR FOR CONTENT AND STRUCTURE

QUERIES

427
