ONTOLOGY BUILDING

USING PARALLEL ENUMERATIVE STRUCTURES

Mouna Kamel and Bernard Rothenburger

Institut de Recherche en Informatique de Toulouse (IRIT) – CNRS

UPS, 118, Route de Narbonne, 31062 Toulouse Cedex, France

Keywords: Ontology building and enrichment from text, Layout analysis, NLP tools.

Abstract: The semantics of a text is carried by both the natural language it contains and its layout. As ontology

building processes have so far taken only plain text into consideration, our aim is to elicit its textual

structure. We focus here on parallel enumerative structures because they bear implicit or explicit

hierarchical relations, they have salient visual properties, and they are frequently found in corpora. We have

defined a process which identifies them in a text, translates them into ontological structures and finally links

such structures to the concepts of an existing ontology. We have assessed this process on Wikipedia

encyclopaedic articles as they are rich in definitions and statements, and contain many enumerations. The

many ontological structures we have obtained are thus used to enrich an ontology which we had

automatically built from database specification documents.

1 INTRODUCTION

Many approaches have been suggested for the

construction, enrichment or population of ontology

from text. They are based on lexical, syntactical,

semantic or rhetorical aspects of natural language.

They encompass machine learning tools (Nédellec

and Nazarenko, 2003), specific natural language

processing tools (Giuliano et al., 2006), or

combination of both (Giovannetti et al., 2008).

These methods are usually applied on plain texts.

However, a large variety of layouts or structures can

be found in the visual presentation of a text with a

diversity of interpretations for each of them.

Example 1: a structure which carries ontological

knowledge.

Some of these structures implicitly carry

ontological knowledge as shown in the example 1.

The meaning carried by this structure may be

expressed through the example 2:

Example 2: a sentential representation of the example 1.

In both cases, a human being may easily deduce

the following conceptual framework:

Figure 1: Conceptual network corresponding to the

meaning of examples 1 and 2.

In the case of sentence analysis (example 2), the

automatic deduction by a Natural Language

Processing (NLP) tool of its formal counterpart is a

Under IAU definitions, there are eight planets in the Solar

System. In order of increasing distance from the Sun, they are

the four terrestrials, Mercury, Venus, Earth, and Mars, then the

four gas giants, Jupiter, Saturn, Uranus, and Neptune.

Under IAU definitions, in the Solar System and in order of

increasing distance from the Sun, there are eight planets:

• four terrestrials:

- Mercury,

- Venus,

- Earth,

- Mars,

• four gas giants:

- Jupiter,

- Saturn,

- Uranus,

- Neptune.

276

Kamel M. and Rothenburger B..

ONTOLOGY BUILDING USING PARALLEL ENUMERATIVE STRUCTURES .

DOI: 10.5220/0003097602760281

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2010), pages 276-281

ISBN: 978-989-8425-29-4

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

very tricky issue which will necessitate to carry out

non trivial tasks such as the resolution of anaphora

or the design of sophisticated multi-sentence textual

patterns. However for layout structure analysis

(example 1), different parts of the knowledge are

more easily identifiable thanks to lexical or typo-

dispositional marks. We claim that it becomes thus

easier to identify in an automated way the

corresponding conceptual network. The above

meaning-bearing layouts allow a straightforward

identification of ontological relations: often

hyperonymy, sometimes meronymy, and

occasionally other relations.

We focus here on a specific kind of meaning-

bearing layout that we call parallel enumerative

structures (PES). Example 1 is typical of such a

layout. These structures present some regularities

and appear very frequently. Their analysis could be a

relevant contribution to improve knowledge

elicitation from text. Moreover, it would provide

new triggers for the identification of new concepts

or semantic relations, therefore enabling to go

beyond the classical ontology learning approaches

which only consider the plain text.

This paper is organized as follows. Section 2

recalls the role and the importance that the layout

and the structure may have in the textual semantics.

Section 3 gives an analysis of parallel enumerative

structures and details the process we define to

translate a parallel enumerative structure into an

ontological structure. And in section 4 we describe

an application whose aim is to enrich an existing

ontology through applying our translating process

on Wikipedia articles which contain many parallel

enumerative structures, thus evaluating our

translation process. Finally we draw the balance of

our current work and list several future

advancements required to go further.

2 STRUCTURE AS PART OF

TEXTUAL SEMANTICS

When producing a document, a writer may use not

just linguistic skills but also the ability to logically

and physically structure his/her writing. In this

regard the materiality of a text is part of its meaning:

"the overlay of graphics on text is in many ways

equivalent to the overlay of prosody on speech"

(Power et al., 2003). So the document structure, also

termed page layout, has been investigated for

different purposes, essentially for the improvement

of text generation (Mann et al., 1992), (Power et al.,

2003) and text segmentation systems (Hearst, 1997).

On the other hand, as documents are increasingly

available in a digital format, their contents become

easily accessible thanks to the existing mark-up

languages as XML whose tags convey the semantics

of the structure. These tags have been particularly

taken into consideration to improve text

summarization systems, as in (Groza et al., 2007) or

to perform Web pages classification (Shen et al.,

2007). (Auer et al., 2007) transform preformatted

tables into a set of triples (subject, predicate, object)

which are then stored in a database. We have also

already formulated a procedure based on the

semantics of tags and on their nested levels to build

an ontology kernel from a collection of structured

documents (Kamel and Aussenac-Gilles, 2009).

Textual objects are “textual segments that

correspond to a specific metalinguistic formulation

which is highlighted by a specific layout”

(Rebeyrolle and Péry-Woodley, 1998). One textual

object which aroused great interest is the

enumeration because it visually emphasizes

information and encompasses a concept or an idea

which is specified into various elements for a

summarization purpose. Moreover it maintains

relationships between its different components,

presents regularities and occurs quite frequently.

Discursive enumerations (also termed in-line list or

horizontal enumeration) are distinguished from

vertical enumerations by the way they are written.

They are indicated by lexico-syntactic marks which

may induce an ambiguous meaning within the

sentence (example 2). Vertical enumerations are

indicated by salient visual and typo-dispositional

marks which facilitate reading comprehension.

Although the elements of these enumerations are

visually discontinuous, they constitute a whole at the

semantic level (example 1). Their identification and

their interpretation in a text are regular enough to be

automatically computed. Actually, Luc led a study

on enumerations, proving that there is a functionally

equivalence between discursive enumerations and

vertical ones (Luc, 2001).

To our best knowledge, only a few works have

analysed the layout of a document to build linguistic

resources (Jacquemin and Bush, 2000), but none for

the ontology building process. We propose here to

show the benefits we have obtained by the analysis

of the enumerative structures for such a process.

3 THE TRANSLATION PROCESS

An enumeration is a set of items with or without

semantic relations between them. An item is a co-

ONTOLOGY BUILDING USING PARALLEL ENUMERATIVE STRUCTURES

277

enumerated entity which can be discernable by

typographic, dispositional and/or lexico-syntactic

marks. Then we can distinguish:

¾ A parallel enumeration as a paradigmatic

enumeration (i.e. all items are functionally

equivalent, textually or syntactically), visually

homogeneous (i.e. all items are visually

equivalent) and isolated (i.e. no item is linked to

any textual unit which is out of the

enumeration) (fig. 3-a),

¾ A Non-parallel enumeration as an enumeration

missing one or more properties of a parallel

enumeration (fig. 3-e).

An introductory phrase, hereafter called primer, is a

phrase or a sentence which introduces an

enumeration, and which is identifiable by lexico-

syntactic and/or typo-dispositional marks.

Finally, let us call parallel enumerative structure

(PES) a vertical textual structure composed of a

primer and a parallel enumeration.

There are a number of diseases and conditions affecting

the gastrointestinal system, including:

1) Cholera

2) Colorectal cancer

3) Diverticulitis

enumeration

primer

Enumerativestructure

item

ItemMarker

Figure 2: Composition of an enumerative structure.

Broadly speaking, the idea is to translate a PES

into a single ontological structure (i.e. one or two-

level hierarchy) according to the following

principles: (1) the primer contains one father concept

and one semantic relation which links this father

concept to concepts contained in the items, (2) each

item contains one child concept semantically related

to the father concept p the primer, (3) all child

concepts will be considered as belonging to the same

conceptual level. An example of this correspondence

is the structure obtained in Figure 1 from example 1.

The syntactic structure of the primer helps to

identify the father concept and the semantic relation

it contains. We have characterized 3 cases:

Æ The primer is not syntactically correct.

- The primer could be composed of a noun phrase

(fig. 3-b). This noun phrase represents the father

concept and the implicit semantic relation is the

relation is-a.

- The primer could end with a verb phrase at the

active form (fig. 3-a). The semantic class to which

this verb belongs reflects the nature of the relation

and the father concept corresponds to the main term

of the noun phrase which is the subject of this verb.

Æ The primer is complete (fig. 3-c). It contains a

lexical unit taken from a gazetteer or a number

which specifies the number of items. The concept

father is the term which co-occurs with this lexical

marker, and the implicit relation is the relation is-a.

Æ The primer is syntactically correct and not

complete (fig. 3-d). The father concept may be found

in the subject noun phrase or in the object noun

phrase of the main clause and may be eventually

detected thanks to heuristics. The implicit relation is

the relation is-a.

Our method consists in (1) identifying each

enumerative structure and its different components

(primer and items), (2) checking whether the

enumeration is parallel, (3) identifying the father

concept and the nature of the semantic relation, (4)

extracting the child concepts from each item and (5)

building an ontological structure. This fifth step is

based on annotations produced over the four

previous steps.

4 EVALUATION

We carry out an experiment which will estimate the

enrichment ratio of an existing ontology when

exploiting PES from Wikipedia pages.

4.1 Experiment Setup

Within the GEONTO (http://geonto.lri.fr/) project,

ontologies are automatically built from structured

database specifications documents (given in an

XML format). To enrich these ontologies, we use

Wikipedia documents. Wikipedia documents are

encyclopaedic: each article describes a single

concept, and there is a single article for each

concept. This is an interesting feature because it will

avoid having to cope with the problem of polysemy.

These articles contain a lot of definitional statements

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

278

Fig 3-a: article Language cf. Wikipedia. Fig 3-b: article Antihypertensive drug cf. Wikipedia.

Non-spoken forms of communication are :

 Written language

 Sign language

 Whistled language

 Drum language

 Non-verbal language

Aldosterone receptor antagonists:

• Eplerenone

• Spironolactone

Fig 3-c: article Library classification cf. Wikipedia. Fig 3-d: article Flora cf. Wikipedia.

As a result of differences in Notation, history, use of

enumeration, hierarchy, facets, classification

systems can differ in the following ways :

 Type of Notation: Notation can be pure

(consisting of only numerals for

example) or mixed (consisting of letters,

numerals, and other symbols).

Expressiveness: This is the degree in which the

notation can express relationship between concepts

or structure.

Lastly, floras may be subdivided by special

environments:

 Native flora. The native and indigenous flora

of an area.

 Agricultural and garden flora. The plants that

are deliberately grown by humans.

 Weed flora. Traditionally this classification

was applied to plants regarded as undesirable

….

Fig 3-e: article Library classification cf. Wikipedia.

The justifications for this protocol are:

 Children, especially the younger ones, have normally not yet developed the mental capacity to

fully comprehend the hazards

 It is impractical in many cases to avoid children crossing the traveled portions of roadways after

leaving a school bus or to have an adult accompany them.

 The size of a school bus generally limits visibility for both the children and motorists during

loading and unloading.

Figure 3: Examples of enumerative structures.

and properties. Furthermore, articles are written

according to a comprehensive set of editorial and

structural guidelines. For bulleted and numbered

lists, the Manual of Style (http://en.wikipedia.org/

wiki/ Wikipedia:Manual_of_Style). recommends :

"use the same grammatical form for all elements in a

list, and do not mix the use of sentences and

sentence fragments as elements". Actually it thus

advocates the writing of PES. So such texts are a

goldmine for the mining of meaning (Medelyan et

al., 2009). Several others works exploit Wikipedia

documents for information extraction process or

ontology building process. Some of these works are

based on a pattern matching approach improved by

more efficient parsers (Herbelot and Copestake,

2006), selectional restrictions (Wang et al., 2007) or

anaphora resolution (Nguyen et al., 2007). Other

works have essentially focused on the exploitation of

categories to extend taxonomies (Chernov et al.,

2006), and on infoboxes to populate the RDF triples

DBpedia dataset (Auer et al., 2007).

Our approach is different since it takes advantage of

the textual structure of these Wikepedia documents

to improve the ontology building process.

In order to perform the translation process

described in section 4, we have implemented a text

processing chain using the GATE NLP platform

(http://gate.ac.uk). This platform allows the

development of pipeline processes which run a set of

NLP tools and may use linguistic resources. Each

step adds new annotations to the corpus, even

sometimes using annotations previously set. An

annotation steps may also use Java Annotation

Patterns Engine (JAPE) rules. JAPE is a language

which allows to define regular expressions over

annotations.

The experiment reported in this paper concerns

the enrichment of the OntoBDTopo ontology which

was built from the BDTopo database specifications

(one of the database used by GEONTO project).

BDTopo is a frame of reference used to localise

information relating to urbanism, environment and

territorial organisations. It contains both

geographical and real-world concepts. The

OntoBDTopo ontology has 728 concepts.

4.2 Experiment Results

We first leave aside:

- Parallel enumerative structures whose primer

does not end with a colon (these have

specificities which made them out of the scope

of this study),

ONTOLOGY BUILDING USING PARALLEL ENUMERATIVE STRUCTURES

279

Table 1: Experiment results.

Feature Number Comment

Initial concepts (IC) 728

Total Wikepedia pages (TWP) 406 55% of IC lead to a Wikipedia entry

Usable Wikipedia pages (UWP) 283 39% of IC lead to a disambiguated Wikipedia page

Usable pages with PES (UWPES) 182 25% of IC contain at least one PES

PES (PES) 434 The total number of PES present in the 182 UWPES

Usable PES (UPES) 276 64% of PES are relevant for the translation process

Complete PES (CPES) 52 Concern 19% of PES

Correct and non-complete PES (CNCPES) 149 Concern 53% of PES

Non-correct PES (NCPES) 71 Concern 26% of PES

New concepts (NC) 349 48% of IC

New instances (NI) 201 Populate the ontology

- Standard appendices such as "see also", "other

wikimedia projects", etc. which do not bear

ontological structure.

We then obtain 182 disambiguated pages which

contain at least one PES (according to our criteria).

From these 182 articles we exploit 276 PES which

allowed to enrich our ontology with 349 new

concepts and 201 instances which were considered

as relevant by experts and knowledge engineers

involved in OntoBDTopo specification . Table 1

details these results.

4.3 Results Discussion

Ontology quality assessment is a multifaceted

problem. It can be based on quantitative measures

(proximity to another ontology, coverage by a

corpus, quality of search results, etc.) or on

qualitative aspects (logical consistency, conceptual

validity, expert validation, etc.). But there is no

“gold standard” evaluated by experts that could be

used as a reference against the ontology we produce

automatically. Here, we have chosen to estimate the

number of new relevant concepts and relations our

translation process adds to an existing ontology. We

observe than the number of concepts goes up by

50%. Concerning relations and according to the

above typology of primers, we have identified more

than 80% of taxonomic relation and 15% of

meronymic ones. The few remaining ones are other

relations (mainly issued from NCPES) which we can

identify in the primer by NLP tools.

Since the root concept label of an ontological

structure we get is already a label (or includes a

label) of the original ontology, we carry a fusion of

this latter with the new structure. This approach has

the advantage of being fully automatic.

Nevertheless, we are aware that the fusion process in

turn carries specific problems which are out of the

scope of the present article.

5 CONCLUSIONS

The aim of this study is to show that the structure of

a text may play an important role in the ontology

building process. Textual objects such as titles,

enumerative structures, definitions, etc. which own

important visual properties, bear implicit or explicit

semantic relations between the concepts they

contain. We have chosen to analyse parallel

enumerative structures because of their salient visual

properties and because they convey ontological

properties. In fact, they express that a same semantic

relation, expressed in the primer, links one concept

in the primer to one concept in each item. Primer

and items may be identified by typo-dispositional

marks. On the other hand, most writing tools

facilitate the layout, and make it that we increasingly

find, amongst others, enumerative structures in

electronic documents.

After noting that the understanding and the

interpretation of an enumerative structure depends

on the type of the primer (its lexical and syntactic

properties), we have defined strategies

based on the analysis of this primer to translate a

parallel enumerative structure into an ontological

structure. The translation process consists in

exploiting successive annotations set in the text with

the help of the above mentioned NLP tools and

rules.

We decided to assess our method within an

ontology enrichment context. We show that the sole

extraction of the information carried by the parallel

enumerative structures improves significantly an

existing ontology in terms of domain coverage.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

280

In the short-term, the idea is to combine our

approach to the usual ontology learning from text

ones. In this way, so as to better take advantage of

Wikipedia’s articles, it would seem interesting to

complete the approach of (Herbelot and Copestake,

2006) which exploits plain text only. We plan to also

exploit in this context redirect links and homonym

pages to maximise the number of relevant articles.

On the other hand we want to improve the analysis

of enumerative structures by going beyond simple

parsing, particularly regarding the primer. Authors

may use complex grammatical constructions or

linguistic variations in their writing, even within the

enumerative structures. We then face problems of

anaphora resolution, ellipses, apposition,

extraposition and rhetorical forms, etc. (fig. 1.).

Also, discourse analysis must be carried out to

process non-parallel enumerative structures.

REFERENCES

Auer, S., Bizer, C., Lehmann, J., Kobilarov, G., Cyganiac,

R., Ives, Z., 2007. DBpedia : a nucleus for a web of

open data. In: Proceedings of the Sixth International

Semantic Web Conference and Second Asian Semantic

Web Conference (ISWC/ASWC2007), Busan, South

Korea, vol. 4825, pp 715-728

Chernov, S., Iofciu, T., Nejdl, W., Zhou, X. , 2006.

Extracting semantic relationships between Wikipedia

categories. In: Proceedings of the First International

Workshop : SemWiki’06 - From Wiki to Semantics.

Co-located with the Third Annual European Semantic

Web Conference ESWC’06 in Budva, Montenegro

Giovannetti, E., Marchi, S., Montemagni, S.: Combining

Statistical Techniques and Lexico-syntactic Patterns

for Semantic Relation Extraction from Text. Fifth

workshop on Semantic Web Applications and

Perspectives, FA0-UN, Roma, Italy (2008)

Groza, T., Handschuh, S., Möller K., Decker, S., 2007.

SALT - Semantically Annotated LaTeX for scientific

publications. In: Proceedings of the 4th European

Semantic Web Conference (ESWC 2007). Innsbruck,

Austria

Giuliano, C., Lavelli, A., Romano, L.: Exploiting Shallow

Linguistic Information for Relation Extraction from

Biomedical Literature. In Proc. EACL (2006)

Hearst M. A.: TextTiling, 1997. Segmenting Text into

Multi-paragraph Subtopic Passages. Computational

Linguistics, volume 23, Number 1

Herbelot, A., Copestake, A., 2006: Acquiring ontological

relationships from Wikipedia using RMRS. In:

Proceedings of the International Semantic Web

Conference 2006. Workshop on Web Content Mining

with Human Language Technologies, Athens, GA

Jacquemin C., Bush C., 2000. Fouille du Web pour la

collecte d’Entités Nommées. In : E. Wehrli (Ed.),

TALN 2000, Lausanne

Kamel, M., Aussenac-Gilles, N., 2009. How can document

structure improve ontology learning? (regular paper).

In: Semantic Authoring, Annotation and Knowledge

Markup Workshop - collocated with K-CAP 2009

(SAAKM 2009), Redondo Beach, California (USA),

Siegfried Handschuh, Michael Sintek (Eds.), CEUR

Workshop Proceedings, p. 1-8

Luc, C., 2001. Une typologie des énumérations basée sur

les structures rhétoriques et architecturales du texte.

TALN2001, Université de Tours, p. 263-272

Mann, W. C., Matthiessen, C. M., Thompson, S. A., 1992.

Rhetorical structure theory and text analysis. In:

Mann, W. C. and Thompson, S. A., editors, Discourse

Description, Diverse Linguistic Analyses of a Fund-

Raising Text, pp. 39-78. John Benjamins publishing

Compagny, Amsterdam/Philadelphia

Medelyan O., Milne D., Legg C., Witten I.H., 2009.

Mining meaning from Wikipedia. International

Journal of Human-Computer studies. Volume 67,

Issue 9, pp.716-754

Nédellec, C., Nazarenko, A.: Ontology and Information

Extraction. in S. Staab & R. Studer (eds.) Handbook

on Ontologies in Information Systems, Springer (2003)

Nguyen, D.P.T., Matsuo, Y., Ishizuka, M., 2007. Relation

extraction from Wikipedia using subtree mining. In:

Proceedings of the AAAI’07 Conference, Vancouver,

Canada, July 2007, pp. 1414-1420

Power, R., Scott, D., Bouayad-Agua, N., 2003. Document

Structure. Computational linguistics, 29:4, pp. 211-

260

Rebeyrolle, J, Péry-Woodley M.-P, 1998. Repérage

d’objets textuels fonctionnels pour le filtrage

d’information : le cas de la définition. In: Rencontre

Internationale sur l’Extraction et le Filtrage et le

Résumé Automatique, Sfax, Tunisie, pp19-30

Shen, D., Yang, Q., Chen, Z., 2007. Noise reduction

through summarization for Web-page classification.

Information Processing and Management, volume 43,

issue 6, pp. 1735-1747

Wang, G., Zhang, H., Wang, H., Yu, Y., 2007. Enhancing

relation extraction by eliciting selectional constraint

features from Wikipedia. In : Proceedings of the

Natural Language Processing and Information

Systems Conference, pp. 329-340

ONTOLOGY BUILDING USING PARALLEL ENUMERATIVE STRUCTURES

281
