RANKING CLASSES OF SEARCH ENGINE RESULTS

Zheng Zhu, Mark Levene

Department of Computer Science and Information Systems, Birkbeck College, University of London

Malet Street , London, U.K.

Ingemar Cox

Department of Computer Science, University College London, Gower Street, London, U.K.

Keywords:

Ranking, Classiﬁcation.

Abstract:

Ranking search results is an ongoing research topic in information retrieval. The traditional models are the

vector space, probabilistic and language models, and more recently machine learning has been deployed in an

effort to learn how to rank search results. Categorization of search results has also been studied as a means to

organize the results, and hence to improve users search experience. However there is little research to-date on

ranking categories of results in comparison to ranking the results themselves.

In this paper, we propose a probabilistic ranking model that includes categories in addition to a ranked results

list, and derive six ranking methods from the model. These ranking methods utilize the following features: the

class probability distribution based on query classiﬁcation, the lowest ranked document within each class and

the class size.

An empirical study was carried out to compare these methods with the traditional ranked-list approach in terms

of rank positions of click-through documents and experimental results show that there is no simpler winner in

all cases. Better performance is attained by class size or a combination of the class probability distribution of

the queries and the rank of the document with the lowest list rank within the class.

1 INTRODUCTION

Existing search engines such as Google, Bing and Ya-

hoo return a list of retrieved documents based on each

document’s relevance to a user’s query. Web users

scroll through the result set to ﬁnd a document that

satisﬁes their information need. Since documents are

only organized based on their relevance score, it is

not uncommon for documents on one topic to be scat-

tered throughout the result list. Thus, for example, a

search on the keyword, “jaguar” will produce results

in two topic areas, cars and animals, but all the doc-

uments on the topic of cars will not come before, or

after, documents on animals.

Several researchers have proposed grouping to-

gether documents with a common theme. The ratio-

nale for this is the hypothesis that users should be able

to quickly identify the topic area related to their query,

and thereby avoid the need to look at documents in

other topic areas.

There are two broad approaches to grouping. The

ﬁrst is based on clustering, while the other is based

on classiﬁcation. A key distinction between the two

approaches is how groups are labeled. In clustering, a

retrieved set of documents, the result set, is clustered

into a set of groups based on a clustering algorithm.

Each group is then assigned a labeled to describe its

associated topic area. This label is automatically de-

rived from the documents contained within the group.

Not only might these labels be unfamiliar to a user,

but the same topic area may be assigned different la-

bels depending on the documents in the group. A

recent survey of clustering of search results can be

found in (Carpineto et al., 2009).

The classiﬁcation approach has a predeﬁned

(Chen and Dumais, 2000; Zeng et al., 2004; Zhu et al.,

2008) set of groups/topic areas, typically derivedfrom

an ontology. Thus, the label for a group/class is prede-

ﬁned and is independent of the documents contained

within it. Of course, these labels may also be unfamil-

iar to a user. However, since the label for a class does

not change, (i) users have an opportunity to learn the

meaning, and (ii) the labels can be carefully chosen to

help users understand what the class represents.

294

Zhu Z., Levene M. and Cox I..

RANKING CLASSES OF SEARCH ENGINE RESULTS.

DOI: 10.5220/0003100902940301

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 294-301

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

There has been considerable work on document

categorization, which is discussed in Section 2. How-

ever, this is not the main focus of our work.

Once a document result set has been categorized,

the users is ﬁrst presented with a list of the categories

represented by documents. The user then selects a

category and the documents within this class are then

presented. In such an arrangement, it is necessary

to rank classes presented to the user. However, de-

spite the fact that document ranking remains one of

the most active research areas in information retrieval,

there has been surprisingly little research on ranking

classes.

In this paper, we investigate various approaches

to ranking classes and how such rankings affect the

number of classes and documents a user must inspect

prior to ﬁnding a documents satisfying his or her in-

formation need. Section 3 describes the details of the

class rankings we consider. Section 4 then describes

our experimental methodology, and Section 5 sum-

marizes our experimental results. Finally, Section 6

provides a discussion of the results.

2 RELATED WORK

There has been signiﬁcant work on clustering and

classiﬁcation of search results (Carpineto et al., 2009;

Chen and Dumais, 2000; Zeng et al., 2004; Zhu et al.,

2008). Our interest is speciﬁc to how previous re-

search ranked classes. There are two main approaches

to doing so.

The ﬁrst approach (Chen and Dumais, 2000) ranks

classes based on their size, i.e. the top-ranked class

contains more documents than the other classes. This

approach is simple and assumes that a class’s rele-

vance is purely a function of the number of documents

it contains.

The second approach (Zamir and Etzioni, 1999;

Zeng et al., 2004) ranks classes based on various

properties associated with the documents in each

class. For example, in (Zamir and Etzioni, 1999) the

authors ordered the clusters by their “estimated co-

herence”, deﬁned as a function of the number of doc-

uments each phrase contains and the number of words

that make up its phrase. And in (Zeng et al., 2004),

all n-gram (n ≤ 3) were ﬁrst extracted from search

results as candidate phrases, and salient scores were

calculated from a regression model trained from man-

ually labeled data. The features included phrase fre-

quency/inverted document frequency, phrase length,

intra-cluster similarity, cluster entropy and phrase in-

dependence. The salient scores are used to rank the

clusters.

A second important consideration is how docu-

ments are ranked within a class. Several alterna-

tives have been proposed. However, in the work de-

scribed here, the relative ranking of documents within

a class is the same as their relative ranking in the

original result set. We believe that this is an impor-

tant experimental design consideration. In particular,

if the ranking of documents in altered within a class,

then it is very difﬁcult to determine whether any im-

provement is due to (i) the class ranking, (ii) the new

document ranking, or (iii) a combination of (i) and

(ii). Thus, in order to eliminate this potential ambigu-

ity, we maintained relative document rankings within

classes. Thus, any improvement must only be due to

the class ranking.

3 CLASS-BASED RANKING

METHOD

Before we discuss the various class ranking algo-

rithms we examined, it is useful to ﬁrst describe how

we evaluated performance. For a conventional sys-

tem, in which the result set is displayed as a ranked

list of documents, i.e. we have a list of documents

, d

, ···d

}, if the k-th document is the desired

document, then the user must look at k documents

···d

). We refer to k as the “list rank” of the doc-

ument, since it was ranked k in a one-dimensional list

of retrieved documents. Clearly, the lower the list

rank, the quicker the user will ﬁnd the desired doc-

ument.

The performance of a classiﬁcation-based system

is slightly more complicated to deﬁne. Consider the

case where the user is looking for document, d

i, j

where i denotes the rank of the class the document is

contained in, and j is the document’s rank within this

class. Thus, a user must look at i class labels and then

j document snippets in order to ﬁnd document, d

i, j

a total of (i + j) classes and documents. We refer to

(i+ j) as the “classiﬁcation rank” (CR) of document

i, j

For any classiﬁcation-based system, we compare

a document’s classiﬁcation rank to its original, corre-

sponding list rank, k. We say that the classiﬁcation-

based system outperforms the list-based system if

i+ j < k, i.e., the user looks as few classes and docu-

ments.

Note that we have implicitly assumed that (i) doc-

uments are correctly assigned to classes, and (ii) that

users always choose the correct class. In practice,

this will not always be the case. However, the as-

sumption simpliﬁes our analysis and permits us to de-

termine the best-case performance of class-based re-

RANKING CLASSES OF SEARCH ENGINE RESULTS

295

trieval systems. The reader is directed to (Zhu et al.,

2008) for more discussion of when this assumption

does not hold.

Given an initial retrieval set, D = {d

···D

|D|

that has been grouped into a set of classes, C =

···c

|C|

}, we now wish to determine the relative

ranking of each class. The information we have avail-

able is the query, q, and the documents, D. We take

a straightforward Bayesian approach, i.e. we wish to

estimate the probability, P(c

|q), that class, c

is rele-

vant, conditioned on the query, q,

P(c|q) ≈ P(c)P(q|c). (1)

We now consider how each of these two terms

might be estimated.

3.1 Query-dependent Classiﬁcation

The probability, P(q|c), is the likelihood that class c

generates query q. It is related to solving the query

classiﬁcation problem (Shen et al., 2006). This prob-

lem has received signiﬁcant recent attention (Broder

et al., 2007; Cao et al., 2009) since the 2005 KDD

Cup competition (Li and Zheng, 2005). Solutions to

this problem typically enrich the query terms using

keywords from the top-ranked documents in the re-

sult set

For a test query, the class probability distribution

is given by

P(q|c) ≈

1+ exp(−(w

x+ b))

, (2)

where, x is term vector containing the query and en-

richment terms, and the weights w

and intercept b are

derived from L2-regularized logistic regression (Lin

et al., 2007), based on a set of labeled examples. Al-

ternative estimates for P(q|c) are possible, but are not

considered in this paper.

3.1.1 Query-based Rank (QR)

If each class is only ranked based on Equation (2),

i.e. we ignore the query-independent term, P(c), in

Equation (1), we refer to it as query-based rank (QR).

3.2 Query-independent Classiﬁcation

To estimate P(c), we make use of the available docu-

ments in retrieved result set.

We further assume that

The implicit assumption, shared with pseudo-relevance

feedback, is that the top-ranked documents are relevant.

Note that we can estimate P(c) based on the class dis-

tribution of the collection, but this is beyond our scope and

it is not as accurate as the retrieved result set.

only documents contained in the class, D

, affect the

probability of the class, i.e.

P(c) ≈ P(c|D

). (3)

We believe this assumption is reasonable as the class

probability is mainly determined by the information

within the class, not by the other classes. Thus, Equa-

tion (1) becomes

P(c|q) ≈ P(c|D

)P(q|c). (4)

We now considered several ways to estimate the con-

ditional probability P(c|D

)

3.2.1 Document-based Rank (DR)

One approach to estimating P(c

) is to base the

probability on the top-ranked document in the class,

. The reader is reminded that the original rank or-

der of documents in the result set is retained within a

class.

The j-th ranked document in class, c

, is denoted

i, j

. The document’s corresponding list rank, i.e.

its rank prior to classiﬁcation, is denoted s(d

i, j

) =

s(d

) = k.

We then deﬁne the conditional probability,

P(c|D

) as

P(c|D

) = f(s(d

i,1

)), (5)

where c = c

, and s(d

i,1

) is the list rank of the top

document in class c

. The function, f(x), can be any

monotonically decreasing function in the value x. In

this paper we consider the inverse function deﬁned by

f(x) =

(6)

and the logistic function deﬁned by

f(x) =

1+ exp(x)

. (7)

If we only rank classes based on the query-

independent factor of Equation (1), then both func-

tions, f(x), will rank the classes in the same order. In

the subsequent experiments, we therefore only con-

sider the inverse function, and rank classes according

P(c|D

) =

s(d

i,1

)

(8)

We refer to this as the document-based rank (DR).

More precisely, we presents functions to approximate

the likelihood of the class c to be examined rather than prob-

ability, as the results do not sum to 1.

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

296

3.2.2 Size Rank (SR)

In contrast to ranking classes based on the top-ranked

document in the class, we also consider the case

where the conditional probability P(c|D

) is based on

the class size. That is, the bigger the class, i.e. the

more documents assigned to the class, the more im-

portant the class is considered to be. Thus, we have

P(c) ≈ P(c|D

) =

|c|

∑

, (9)

where |c| is the number of elements in the class c, and

the denominator is the size of result set.

Again, if we only rank classes based on the query-

independent factor of Equation (1), and the class

ranks are based on the size of the classes, as deﬁned

in Equation (9), then we refer to this as the Size Rank

(SR).

3.3 Additional Class Ranking Models

From Equation (2) and the deﬁnitions for P(q|c) and

P(c), we can now deﬁne a variety of different models

for ranking classes based on both the query-dependent

and query-independent probabilities..

3.3.1 Query/ Inverse Rank (QD

If the class ranking is determined by the product of

Equations (2) and (6), then we obtain

P(c|q)

≈

1+ exp(−(w

x+ b))

s(d

c,1

)

. (10)

We call this rank the Query/Inverse Rank(QD

R).

3.3.2 Query/Logistic Rank (QD

The Query/Logistic Rank (QD

R) is correspondingly

deﬁned as

P(c|q)

≈

1+ exp(−(w

x+ b))

1+ exp(s(d

c,1

))

. (11)

3.3.3 Query/Size Rank (QSR)

Similarly, if the class ranking is determined by the

product of Equations (2) and (9), then we have

P(c|q) ≈

1+ exp(−(w

x+ b))

|c|

∑

. (12)

We call this rank the Query/Size Rank (QSR).

3.3.4 Summary of Ranks

We distinguish the methods for estimating P(c|q) ≈

P(q|c)P(c|D

) accordingto the different methods pre-

sented above. The list rank (LR) is the original rank of

a document in the result set, i.e. before any classiﬁca-

tion. We then consider two query-independent meth-

ods of ranking classes, based on (i) the class size, i.e.

size rank (SR), and (ii) the top-ranked document in

each class, i.e. document rank (DR). We also consider

ranking classes based only of the query-dependent

term, i.e. the query-based rank (QR). Finally, we

consider ranking classes based on a combination of

query-dependent and query-independent terms. In

all these cases, the query-dependent term is based

on Equation (2), and we vary the query-independent

term. Speciﬁcally, we consider (i) query/size rank

(QSR) in which the conditional probability, P(c|D

)

is based on the size of a class, and (ii) query inverse

rank (QD

R) and query logistic rank (QD

R), both of

which are based on a function of the top-ranked doc-

ument in each class, and where this function is the

inverse function or the logistic function, respectively.

The various methods are summarized in Table 1.

Table 1: The summary of the ranks.

Notation Meaning

LR List Rank, the rank of the results returned by

the search engine.

SR Size-based Rank computed according to

(Equation (9))

DR Document-based Rank computed according

to (Equation (6)).

QR Query-Based Rank computed according to

(Equation (2))

QSR Query/Size Rank computed according to

(Equation (12))

R Query/Inverse Rank computed according to

(Equation (10)).

R Query/Logistic Rank computed according to

(Equation (11)).

4 EXPERIMENTAL SET UP AND

DATA

Evaluation of information retrieval systems requires

knowledge of a document’s relevance with respect

to a query. One indirect source of such informa-

tion is query logs. These logs consist of queries

together with associated click-through data. Previ-

ous research (Liu et al., 2007) showed that retrieval

evaluation based on query logs yields similar per-

formance to retrieval evaluation based on traditional

RANKING CLASSES OF SEARCH ENGINE RESULTS

297

human assessors. We used a subset (the RFP 2006

dataset) of an MSN query log, collected in spring

2006. The log contains approximately 15 millions

queries. Each query has associated with it either (i) no

click-through data (no-clicks), (ii) one click-through

data (one-click), or (iii) multiple click-through data

(multiple-click).

We ignore queries for which there is no associ-

ated click-through data (approximately 6.1 million

queries). For one-click queries, of which there are

approximately 7.2 million, we assume the query was

satisﬁed by the document clicked on. For multiple-

click queries, of which there are approximately 1.6

million, we assume that the query was satisﬁed by the

last document clicked on. We realize that this will not

always be true, but assume that it is true sufﬁciently

often to provide us with reliable results. Note that

this assumption has been partially justiﬁed by other

researchers (Joachims et al., 2005), in the context of

multiple-click queries.

The query log does not include information de-

scribing the result set returned in response to the

query. Rather, the click-through data only identiﬁes

those documents in the result set that the user clicked

on. Of course, in order to evaluate the various classiﬁ-

cation based systems, we need access to the complete

result set. We acquired this information by issuing

the query to a search engine, speciﬁcally Microsoft

Live Search on May 2009, which was subsequently

replaced by Bing. Note that for some queries, the

url’s clicked on in the query log are not returned by

the search engine, either because its rank is beyond

our retrieved result set or the url is no longer avail-

able. We discarded such queries. In the case where

the url is returned in the result set, we assume the

the result set returned by Live Search is similar to the

result set observed by the user during the collection

of the log. We acknowledge that this is a major as-

sumption, which cannot be veriﬁed, and future work

is needed to repeat these experiments on a more recent

data set.

We now describe our experimental methodology.

The total number of unique queries which have a

click-through is 3,545,500. Among them, there are

658,000 multiple-click queries whose top-20 search

results have been downloaded by us before Microsoft

upgraded Live to Bing. We took a random sam-

ple of 20,000 one-click queries and 20,000 multiple-

click queries, whose click-through occurred both in

the query log and in our retrieved data set.

For each query, the list rank of the relevant doc-

ument (i.e. the document clicked on for one-click or

the ﬁnal document clicked on for multiple-click) were

recorded. Next, the documents in the result set were

classiﬁed into one of 27 classes; these classes are enu-

merated in the appendix; see (Bar-Ilan et al., 2009) for

more detail about this ontology.

In order to classify the documents we compute

P(c|q) from Equation (2), using logistic regression.

The training data is obtained from two manually clas-

siﬁed subsets of an AOL search log (Beitzel et al.,

2005). The ﬁrst one contains 9,913 manually classi-

ﬁed queries, resulting from a Master’s level Informa-

tion Science class assignment at Bar-Ilan University

during 2007 (Bar-Ilan et al., 2009). The second one

is a labeled log ﬁle from AOL’s research lab. We en-

riched the query with the top-10 snippets in the result

set, the titles of the top-10 documents and their urls to

form the vector x. Then for the test query, we enriched

the query with the same information and predict the

probability via Equation (2).

To keep our data consistent, for a given query, we

record the list rank of the given click-through in the

result set, as it may be different from the one recorded

in the log data. Then query classiﬁcation is carried

out by enriching the query with the top-10 results. In

this manner we attain the class probability distribu-

tion. After that we assign each result into its class.

5 EXPERIMENTAL RESULTS

In Section 5.1, we present the results for multiple-

click queries (m-clicks). The results for one-click

queries (1-click) are presented in Section 5.2.

5.1 Results for Multiple-click Queries

Each target document has an original list rank from

1 to 20. Table 2 shows for each list rank, the mean

value of the corresponding classiﬁcation rank. Col-

umn 1 of Table 2 provides the list rank of the target

documents for the top-10 documents, i.e., there is no

classiﬁcation, only a traditional list of retrieved docu-

ments. Column 2-7 provide the equivalent classiﬁca-

tion ranks (CR), i.e., the total number of classes and

documents a user must examine in order to ﬁnd the

target document. If the CR is less than the LR, then

the classiﬁcation based system outperforms a tradi-

tional system. The smallest value indicates the least

number of documents that a user must inspect before

ﬁnding the desired document. Columns 8-14 provide

the same data for list ranks between 11 and 20.

We can see that for list ranks between 1 and 4, all

CR values in the corresponding row are greater than

the list rank. For a list rank of 5 and higher, there is

always a CR that is less than the corresponding list

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

298

Table 2: The comparison of class based rank for the last click through according to list rank(m-clicks).

LR QR DR SR QSR QD

R QD

R LR QR DR SR QSR QD

R QD

1 3.00 2.00 2.88 2.79 2.08 2.13 11 7.46 7.69 7.16 7.18 7.60 7.57

2 3.55 3.00 3.39 3.32 2.93 3.01 12 7.89 8.07 7.52 7.59 8.01 7.93

3 3.95 3.64 3.73 3.68 3.58 3.63 13 8.38 8.58 7.99 8.05 8.50 8.41

4 4.45 4.23 4.20 4.20 4.15 4.18 14 8.41 8.66 8.07 8.13 8.57 8.50

5 4.81 4.80 4.63 4.58 4.71 4.70 15 8.99 9.17 8.56 8.68 9.10 9.05

6 5.28 5.26 4.95 4.99 5.19 5.18 16 9.55 9.84 9.25 9.32 9.74 9.64

7 5.65 5.86 5.41 5.42 5.74 5.68 17 9.64 10.03 9.23 9.29 9.94 9.83

8 6.11 6.24 5.86 5.85 6.15 6.12 18 10.50 10.82 10.12 10.17 10.72 10.63

9 6.37 6.58 6.13 6.13 6.49 6.44 19 10.69 10.95 10.27 10.36 10.88 10.80

10 6.83 7.05 6.54 6.56 6.97 6.89 20 11.27 11.52 10.98 10.95 11.41 11.32

rank. However, it is not the case that a single partic-

ular classiﬁcation-based system is superior, although

in most cases, ranking classes by class size (SR) has

best performance.

One reason why the classiﬁcation-based rankings

do not yield an improvementfor list ranks of 5 or less,

is that classiﬁcation ranks introduce a small overhead,

i.e. an extra click to examine the class the result is

in. Thus, if the desired document is ranked ﬁrst, i.e.

its list rank is 1, and, for classiﬁcation-based ranking,

this document is the ﬁrst document in the ﬁrst class,

the user must examine one class and one document,

thereby incurring a cost of 2.

It is interesting to note that for an initial list rank

of 5 or less, the best classiﬁcation-based methods

are provided by document-based ranking methods,

speciﬁcally DR and QD

R. However, for list ranks

greater than 5, classiﬁcation methods based on class

size perform best. For an initial list ranks between 5

and 10, we observe that SR and QSR are the best, and

for an initial list rank greater than 10, SR most usually

performs best. This might be due to the fact that for

list ranks greater than 10, the initial query is, by deﬁ-

nition, poor, and therefore ranking classes based only

on the query-independent component is usually supe-

rior. However, the difference in performance between

the two methods is actually quite small.

Figure 1 shows the cumulative distribution of tar-

get documents for each method. We see that for list

rank, approximately 25% of target documents are at

list rank of 1, and 35% have a list rank less than or

equal to 2. No class rank system has a class rank of 1

because of the overhead it introduces. Approximately

25% of clicked document have a classiﬁcation rank of

2. The list rank and classiﬁcation rank cross at rank 4.

Approximate 50% of documents have a rank of 4 or

less for all systems. Conversely, 50% of clicked doc-

uments have a rank greater than 4, and in those cases,

a class based system performs better.

Figure 1: The cumulative distribution of the rank of target

documents for m-clicks queries.

5.2 Results for One-click Queries

The performance for one-click queries is very similar

to the multiple-click queries.

Table 3 shows the mean value of the respective

classiﬁcation rank for each list rank. Column 1 of Ta-

ble 3 provides the list rank of the clicked document in

the list-ranked results set. We can see that all classi-

ﬁcation ranks perform worse than the list rank when

list rank is less than or equal to 4, which is similar to

the results in Table 2. The classiﬁcation rank outper-

forms the list rank when the list rank is greater than 4.

In those cases, once again, ranking classes based on

class size, i,e, SR and QSR, exhibit best results.

Figure 2 shows the cumulative distribution of tar-

get documents for each method, for 1-click queries.

Compared to the Figure 1, the list rank more

strongly dominates the top ranks, i.e., approximate

47% of target documents are at list rank of 1 and

about 70% of target documents are at ranks of three or

less. As before, ranking classes based on a document-

based ranking provides the best performance for the

classiﬁcation methods when the list rank is less than

If the initial query is good, i.e. the target docu-

RANKING CLASSES OF SEARCH ENGINE RESULTS

299

Table 3: The comparison of class based rank for the one click through according to list rank(1-click).

LR QR DR SR QSR QD

R QD

R LR QR DR SR QSR QD

R QD

1 3.11 2.00 2.85 2.79 2.08 2.14 11 8.03 8.06 7.54 7.67 8.03 8.03

2 3.57 3.00 3.32 3.28 2.94 3.04 12 7.95 8.03 7.38 7.47 7.98 7.93

3 4.13 3.68 3.74 3.76 3.61 3.68 13 8.23 8.25 7.78 7.78 8.17 8.14

4 4.56 4.25 4.20 4.21 4.18 4.22 14 8.71 8.67 8.28 8.29 8.60 8.56

5 4.98 4.78 4.62 4.65 4.71 4.73 15 9.04 9.18 8.61 8.67 9.13 9.10

6 5.40 5.31 5.04 5.05 5.25 5.24 16 9.55 9.85 9.28 9.26 9.72 9.57

7 5.87 5.85 5.51 5.52 5.77 5.74 17 10.05 10.37 9.81 9.79 10.31 10.17

8 6.22 6.16 5.88 5.92 6.06 6.06 18 9.88 10.14 9.65 9.60 10.09 9.91

9 6.40 6.51 6.05 6.09 6.43 6.36 19 10.95 11.12 10.38 10.60 11.05 11.01

10 7.01 7.11 6.63 6.64 7.04 7.01 20 10.95 11.17 10.51 10.58 11.14 11.03

Figure 2: The cumulative distribution of the rank of target

documents for 1-click queries.

ment has a list rank less than 5, then displaying re-

sults as a traditional one-dimensional list is superior.

However, for queries where the initial list rank is 5

or more, classiﬁcation based ranking offers better re-

sults. It would therefore be interesting to investigate a

hybrid method for displaying the result set, in which

the top-ranked document is displayed ﬁrst, followed

by categorized results.

6 CONCLUDING REMARKS

We proposed a probabilistic model for ranking

classes, and derived six ranking functions from

this model. Two models, SR and DR, were

query-independent, and one model, QR, was query-

dependent. A combination of these resulted in the

models QSR, and QD

R and QD

Within each class, the rank order of documents

was identical to that in the original list rank. We be-

lieve this is an important experimental control in or-

der to be certain that any improvements in ranking are

solely due to the classiﬁcation methods under investi-

gation.

We examined a subset of queries derived from an

MSN log recorded in Spring 2006. This subset con-

sisted of 20,000 queries for which 1-click was asso-

ciated with each query, and 20,000 queries for which

multiple-clicks were associated with each query. The

two data sets were examined independently, but ex-

perimental results are consistent across both. In par-

ticular, we observed that for target documents with

an initial list rank less than 5, the classiﬁcation-based

methods offered no advantage. This is partly due to

the fact that these methods introduce a small over-

head, i.e. to even examine the ﬁrst document in the

ﬁrst class requires two, rather than one click. How-

ever, for target documents with an initial list rank of

5 or more, classiﬁcation methods are better. Of the

six methods examined, the two based on class size,

SR and QSR, performed best. The difference between

these two methods is also small.

For the case where the target document has an ini-

tial scroll rank of 5 or less, the document-based classi-

ﬁcation methods performed best. However, they were

inferior to traditional list rank, i.e. no classiﬁcation.

The fact that traditional list rank performs well

for good queries, i.e. where the initial rank of target

documents is less than 5, while classiﬁcation-based

methods perform well for poorer queries, i.e. where

the initial rank of target documents is greater than

4, suggests that some form of hybrid method should

be investigated. For example, one could display the

top-ranked document followed by categorized results.

This would be an interesting line of future investiga-

tion.

A key assumption of our experimental results is

that the retrieved results obtained using Live Search

are similar to those observed by users at the time the

query log was collected in Spring 2006. It is not pos-

sible to verify this assumption, and it would be inter-

esting to repeat our experiments on more recent data.

In our work, we also assume that classiﬁcation is

perfect, i.e. that documents are correctly classiﬁed

and that users correctly identify the target class. In

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

300

practice, this will not be the case, and our experimen-

tal results must be considered a best case. Neverthe-

less, we are optimistic that classiﬁcation errors can be

kept small. In particular, documents could be clas-

siﬁed during indexing, when considerably more in-

formation than just the result set is available. And,

over time, users are likely to learn the classiﬁcation

ontology and increase the frequency of choosing the

correct class.

REFERENCES

Bar-Ilan, J., Zhu, Z., and Levene, M. (2009). Topic-speciﬁc

analysis of search queries. In WSCD ’09: Proceed-

ings of the 2009 workshop on Web Search Click Data,

pages 35–42, New York, NY, USA. ACM.

Beitzel, S. M., Jensen, E. C., Frieder, O., Grossman, D.,

Lewis, D. D., Chowdhury, A., and Kolcz, A. (2005).

Automatic web query classiﬁcation using labeled and

unlabeled training data. In SIGIR ’05: Proceedings

of the 28th annual international ACM SIGIR confer-

ence on Research and development in information re-

trieval, pages 581–582, New York, NY, USA. ACM.

Broder, A. Z., Fontoura, M., Gabrilovich, E., Joshi, A., Josi-

fovski, V., and Zhang, T. (2007). Robust classiﬁcation

of rare queries using web knowledge. In SIGIR ’07:

Proceedings of the 30th annual international ACM SI-

GIR conference on Research and development in in-

formation retrieval, pages 231–238, New York, NY,

USA. ACM.

Cao, H., Hu, D. H., Shen, D., Jiang, D., Sun, J.-T., Chen,

E., and Yang, Q. (2009). Context-aware query classi-

ﬁcation. In SIGIR ’09: Proceedings of the 32nd inter-

national ACM SIGIR conference on Research and de-

velopment in information retrieval, pages 3–10, New

York, NY, USA. ACM.

Carpineto, C., Osi´nski, S., Romano, G., and Weiss, D.

(2009). A survey of web clustering engines. ACM

Comput. Surv., 41(3):1–38.

Chen, H. and Dumais, S. (2000). Bring order to the web:

Automatically categorizing search results. In CHI ’00:

Proceedings of the SIGCHI conference on Human fac-

tors in computing systems, pages 145–152, New York,

NY, USA. ACM Press.

Joachims, T., Granka, L., Pan, B., Hembrooke, H., and Gay,

G. (2005). Accurately interpreting clickthrough data

as implicit feedback. In SIGIR ’05: Proceedings of the

28th annual international ACM SIGIR conference on

Research and development in information retrieval,

pages 154–161, New York, NY, USA. ACM.

Li, Y. and Zheng, Z. (2005). Kdd cup 2005. Online at

http://www.acm.org/sigs/sigkdd/kdd2005/kddcup.html.

Lin, C.-J., Weng, R. C., and Keerthi, S. S. (2007). Trust

region newton methods for large-scale logistic regres-

sion. In ICML ’07: Proceedings of the 24th inter-

national conference on Machine learning, pages 561–

568, New York, NY, USA. ACM.

Liu, Y., Fu, Y., Zhang, M., Ma, S., and Ru, L. (2007).

Automatic search engine performance evaluation with

click-through data analysis. In WWW ’07: Proceed-

ings of the 16th international conference on World

Wide Web, pages 1133–1134, New York, NY, USA.

ACM.

Shen, D., Pan, R., Sun, J.-T., Pan, J. J., Wu, K., Yin, J., and

Yang, Q. (2006). Query enrichment for web-query

classiﬁcation. ACM Trans. Inf. Syst., 24(3):320–352.

Zamir, O. and Etzioni, O. (1999). Grouper: A dynamic

clustering interface to web search results. Computer

Networks, pages 1361–1374.

Zeng, H. J., He, Q. C., Chen, Z., Ma, W. Y., and Ma, J. W.

(2004). Learning to cluster web search results. In SI-

GIR ’04: Proceedings of the 27th annual international

ACM SIGIR conference on Research and development

in information retrieval, pages 210–217, New York,

USA. ACM Press.

Zhu, Z., Cox, I. J., and Levene, M. (2008). Ranked-listed or

categorized results in ir: 2 is better than 1. In NLDB

’08: Proceedings of the 13th international conference

on Natural Language and Information Systems, pages

111–123, Berlin, Heidelberg. Springer-Verlag.

APPENDIX

The list of classes, See below:

[Art, Auto, Companies & Business, Computing, Di-

rectories, Education, Employment, Entertainment, Fi-

nance & Economy, Food & Drink, Games, Gov-

ernment Organization, Health & Medicine, Holiday,

Home, Law & Legislation, Nature, News, People,

Places, Pornography, Religion, Science, Shopping,

Society & Community, Sports, Technology]

RANKING CLASSES OF SEARCH ENGINE RESULTS

301
