DOES CAPITALIZATION MATTER IN WEB SEARCH?

Silviu Cucerzan

Microsoft Research, 1 Microsoft Way, Redmond, U.S.A

Keywords: Web search, Queries, Capitalization, Truecasing, Ranking.

Abstract: We investigate the capitalization features of queries submitted to Web search engines and the relation

between capitalization information, either as received from users or as hypothesized based on Web

statistics, and search relevance. We observe that users tend to lowercase words in their queries significantly

more often than as predicted from Web data. More importantly, we determine that document relevance is

strongly correlated with the matching in capitalization between the instances of query tokens in the target

document and the tokens of the truecased form of the query as obtained by using Web n-gram data.

1 INTRODUCTION AND

RELATED WORK

Case is an orthographic feature present in Indo-

European languages, most of which employ the

Latin alphabet. The vast majority of such languages

capitalize the first letter of words in proper nouns

and the first letter of the first word in a sentence.

Additionally, there exist many language dependent

and/or stylistic capitalization rules; for example, the

names of days are capitalized in English (e.g.,

“Thursday”), while they are written in lowercase in

French (e.g., “jeudi”); words’ capitalization may

depend on whether they appear in titles and headings

or in running text; etc. In English – the language on

which we focus in this study – case information is

very useful in disambiguating or reducing the

ambiguity of a large number of polysemous words,

such as “apple”, “bush”, “turkey”, and “us”, and a

very useful feature for several language processing

tasks, as shown by Liţă et al. (2003).

Web data, as captured in the Google 1T 5-gram

corpus (Brants and Franz, 2006), shows a large

variety of capitalizations for almost all English

words. More than 81% of the 137,000 words in a

large English thesaurus are seen in the Google

unigram data set with at least two capitalization

forms, as shown in Figure 1. For example, the word

“friends” has 31 different capitalizations with at

least 200 occurrences: 69 million instances of the

Figure 1: Percentages of words in an English thesaurus

seen with various numbers of distinct capitalizations on

the Web.

form “friends”, 39 million of the form “Friends”, 2

million of “FRIENDS”, and over 35 thousands of

various mixed-cased versions. The fact that 9,438

words (e.g., “abandonees” and “carbonizations”) did

not appear with any capitalization in the Google

unigram set is likely due to the 200 cut-off employed

for unigram statistics.

Despite the rich capitalization diversity on the

Web, or possibly because of it, all major commercial

Web search engines in current use (Google, Yahoo,

Bing, and Ask) employ case-insensitive strategies

for retrieving Web search results for user queries.

This means that differently cased queries, such as

“best buy motorcycles” and “Best Buy

motorcycles”, which may refer to different topics

(best reviewed motorcycles and the retailer’s recent

6,9%

11,8%

17,2%

46,7%

10,0%

2,9%

1,3%

.8%

1,4%

.2%

.5%

10%

20%

30%

40%

50%

012345678910>10

Number of capitalization forms with at least 200

occurences

Number of queries

302

Cucerzan S..

DOES CAPITALIZATION MATTER IN WEB SEARCH?.

DOI: 10.5220/0003102503020306

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2010), pages 302-306

ISBN: 978-989-8425-28-7

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

announcement about selling electric motorcycles,

respectively), return the same sets of search results.

Moreover, query logs show that a large

percentage of the queries submitted by users contain

case information, possibly for multiple reasons:

users employ the orthography they typically use in

document editing, they perceive the use of uppercase

as appropriate when querying for people or geo-

political entities, they try to enforce a certain

disambiguation of a queried term, they copy and

paste substrings from properly-cased documents, or

simply by mistake.

Previous research on truecasing has mainly

investigated text corpora truecasing, with focus on

language processing tasks such as named entity

recognition and machine translation (Liţă et al.,

2003), speech transcription (Chelba and Acero,

2004), sentence boundary detection and casing of

words that start sentences (Mikev, 1999), and

language dynamics (Batista et. al, 2008). Cucerzan

(2010) showed that the capitalization information

from Web search snippets can be employed for

cross-corpus case normalization. However, the

findings of Church (1995) on the effects of text

normalization in information retrieval, including

case-sensitive search, were inconclusive.

2 DATA COLLECTION

To determine whether capitalization could be an

informative ranking feature, we started with a set of

10k distinct queries sampled at random by frequency

from the logs of a major search engine, for which

relevance judgments on a scale from 0 to 5 were

available. We kept for our experiments only the

9,810 queries that include at least one character of

the English alphabet (a–z or A–Z). These queries

contain a total number of 13,904 word types

accounting for 29,388 tokens (average of 3 tokens

per query). The longest query has 34 tokens. Most

queries have 2 tokens. Figure 2 shows a histogram

of the number of tokens per query for the whole set.

The most frequent words in the set are “of” and “in”,

with 324 and 316 occurrences, respectively, each

seen with three capitalization forms in our query set.

21,973 of the query tokens in our set are all

lowercase, 3,103 tokens are in mixed case, and

1,794 tokens are in all uppercase, while 477 tokens

are numbers. The other 2,041 tokens contain at least

one non-English letter or punctuation sign or are a

mixture of letters and numbers.

Figure 2: Histogram of query length in tokens.

3 EXPERIMENTS AND

FINDINGS

We first investigate how well the capitalization

employed by users for the queries in our sample set

matches the capitalization statistics of the Web data

crawled by Google. To do so, we ignore the tokens

that are numbers or contain non-English letters and

focus only on the 26,870 query tokens formed

exclusively of English letters (referred to as literal

tokens henceforth). An interesting finding is that

only 85.4% of these literal tokens are present in the

large English thesaurus employed. The relatively

high out-of-vocabulary rate is due to proper nouns

(such as “myspace” and “Millau”), foreign words

(e.g., “palangoje” and “Konzert”), and misspellings

(e.g., “Geroge” and “helecopter”). However, no

fewer than 26,311 literal tokens (or 97.9% of the

literal tokens in our set) are present with at least one

capitalization form in the Google unigram list. On

average, Google’s unigram data contains 6.9 distinct

capitalizations per literal token from our query set.

For those literal tokens present in the Google

unigram set, the users’ capitalization matches the

most frequent capitalization form on the Web 47.2%

of the time. The matching percentage increases to

54.8% when the literal token contains at least one

uppercase letter, but even this number does not seem

to indicate reliable signal in the users’ capitalization

of queries. Overall, in 84.4% of the capitalization

mismatches, the query token was in lowercase, while

the most frequent capitalization form had a different

capitalization form: upper case in 8% of those

instances, the first letter only in uppercase 74.6% of

the time, or another mixed case form in 17.4% of the

cases. These findings seem to point out that a large

number of Web search users tend to write queries in

lowercase (thus, matching the case-insensitive

models of the Web search engines), which is not

surprising. More unexpected is that even when the

1.865

2.899

2.191

1.287

725

343

226

124

500

1.000

1.500

2.000

2.500

3.000

12345678910>10

Query length in tokens

DOES CAPITALIZATION MATTER IN WEB SEARCH?

303

Web search engine users employ uppercase letters in

their queries, their capitalization matches the most

frequent form on the Web rather randomly.

However, since word capitalization is highly

dependent on the context in which a word is used,

we must also employ higher order n-gram statistics.

For each token w

in a query q = w

…w

i-2

i+1

i+2

…w

, we examine the statistics for all

possible bigrams (left: w

i-1

and right: w

i+1

) and

trigrams (left: w

i-2

i-1

, middle: w

i-1

i+1

, and

right: w

i+1

i+2

) that contain it (obviously, some of

these are undefined for values of n ≤ 2 or i Є {0, 1,

n-1, n}, and thus, cannot be accounted for). 86.8%

of the bigrams and 59.8% of the trigrams present in

our queries appear in the corresponding Google n-

gram sets with at least one capitalization.

To compute the most likely capitalization of a

token in a given n-gram based on Google’s Web

data, we aggregate the Google n-gram counts by

folding the case of all other tokens in the n-gram.

We find that at bigram level, capitalization of literal

tokens in our query set matches the most frequent

capitalization in the Google set 53.6% of the time

for left bigrams and 55.8% for right bigrams. The

matching improves to 59.4% for left trigrams, 64.8%

for middles trigrams, and 62.1% for right trigrams.

Nonetheless, these numbers are all significantly

lower than those obtained by hypothesizing that the

capitalization of all tokens is lowercase (mid to high

60s). This indicates that users favour lowercase

forms in queries to a higher degree than as predicted

by employing Web-based n-gram capitalization

statistics.

We now investigate whether capitalization

information may be useful for ranking, either as

submitted by users or as predicted based on Web n-

gram data. For the latter, we employ a system that

truecases each query token by using aggregate

capitalization counts for all trigrams that contain it,

with back-off to the bigrams, and finally to unigrams

when higher-order n-grams are undefined or

statistics for those n-grams are not available in the

Google data. Explicitly, for queries with only one

token, we choose the most frequent capitalization of

the token in the Google unigram data. For queries

with two tokens, the system predicts for each token

the most likely capitalization obtained through the

process of case folding of the other token and

aggregation described above. We back-off to

unigram statistics when the bigram does not appear

in the Google data set. Similarly, for each token in

queries of length 3 or more, the system combines the

counts obtained using the case-folding and aggrega-

tion process for each possible position of the token

in a trigram (left, middle, and right), with back-off to

bigrams and unigrams.

Table 1: Capitalization inter-agreement ratios at query

level (i.e., the capitalization of all tokens in a query

matches).

Annotator 1 Annotator 2 Original System

Annotator 1 80% 36% 54%

Annotator 2 80% 33% 48%

Original 36% 33% 28%

System 54% 48% 28%

Table 2: Capitalization inter-agreement ratios at query

token level.

Annotator 1 Annotator 2 Original System

Annotator 1 85.5% 61.7% 73.9%

Annotator 2 85.5% 54.5% 70.0%

Original 61.7% 54.5% 49.2%

System 73.9% 70.0% 49.2%

To estimate how well this truecasing system

works, we selected 100 queries at random from our

set (Appendix 1), stripped the case information, and

asked two annotators to truecase them according to

their best guess of the original query intent. Tables 1

and 2 summarize the annotator inter-agreement, as

well the matching with the original capitalization

and the system-predicted capitalization at query

level and token level, respectively. Evidently,

percentages are much higher when agreement is

computed at token level, as for two queries to match

we require that the capitalizations of all component

tokens match.

An important observation is that the truecasing

system based on the Google n-gram data agrees with

the annotators to a much higher degree than its

agreement with the original casing of the query, as

well as the agreement observed between the

annotators’ capitalizations and the original

capitalization of the queries. We also note that this

system predicts a higher number of tokens as

starting in uppercase than the human annotators

(64.9% and 78.5% of the disagreements with the two

annotators at token-level are of this type), which

may indicate a Web bias towards capitalized forms.

Finally, we measure the correlation between

relevance and the matching of capitalization in

queries and documents. For every query and

document pair, we compute the percentage of time

the capitalization of tokens in the query matches the

capitalization forms of the tokens in the text of the

document, then we macro-average the obtained

values, first at query-document level, and then for all

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

304

query-document pairs in each of the given relevance

categories (from 0 – very bad to 5 – excellent).

Table 3: Matching percentages between capitalization of

tokens in queries and documents for each relevance

category, as well as the correlation coefficients between

the relevance labels/values and these percentages.

Capitalization

Type

Relevance Label

Corr.

0 1 2 3 4 5

All low

29.0% 28.5% 26.7% 26.3% 20.3% 18.7% -.94

Original

48.3% 33.6% 33.8% 33.8% 28.0% 23.2% -.90

Annot. 1

53.9% 60.8% 61.9% 61.8% 61.9% 64.4% .83

Annot. 2

53.9% 60.5% 61.5% 62.6% 65.5% 62.7% .82

System

46.8% 66.3% 67.4% 68.1% 71.5% 71.9% .81

The capitalization hypothesized by the system

trained on Google n-gram data matched overall the

best the capitalization in the documents in our set, as

shown in Table 3. This is not surprising under the

assumption that the documents in our set follow the

overall capitalization distributions on the Web.

However, more importantly and less expected is the

very strong positive correlation (0.81) between

document relevance labels and capitalization

matching for the queries truecased by the system.

Similar correlation coefficients (0.82 and 0.83) are

also seen when using the annotators’ cased versions

of the queries. On the opposite, the matching of the

original user capitalization is strongly negatively

correlated (-0.9) with the relevance values, which

may explain at least to some degree why query

capitalization is typically perceived as inadequate in

Web search ranking (to the best of our knowledge).

Moreover, the strong negative correlation (-0.94)

between the all-lowercase query form and document

relevance provides another empirical confirmation to

the fact that documents in which the query words are

capitalized (possibly because they are in titles or

headings) tend to be more relevant for the target

query.

4 DISCUSSION

To determine the concrete impact of using query

truecasing and capitalization features in Web search,

more costly actual ranking experiments are needed.

However, the strong correlation observed in our

experiments between the quality of candidate Web

documents for a query and the matching of the

capitalization of the query tokens in the truecased

from of the query and in the candidate documents

indicates that capitalization information could be

very important for ranking, and warrants such

ranking experiments.

While case-sensitive indexing of Web pages

would present numerous implementation disadvan-

tages and could also lower recall to a substantial

degree, the implementation of a system as suggested

in this paper requires only modifying the data

structures of the inverted index of the search engine

to store for each word instance two additional bits

that encode the capitalization of that instance in the

indexed document (lower case, all uppercase, first

uppercase, or other mixed casing) and would have

no impact on recall.

5 CONCLUSIONS

We analyzed the capitalization of a random sample

of queries submitted by users of a major commercial

Web search engine. As expected, we observed that

users tend to lowercase their queries significantly

more often than as predicted from Web n-gram data.

We also showed that by employing Web n-gram

statistics to truecase the user queries, we obtain

query forms for which query-document

capitalization matching is strongly positively

correlated with document relevance for the target

query. This result indicates that capitalization

features could be employed beneficially in Web

search ranking.

REFERENCES

Batista, F., Marmede, N., and Trancoso, I. 2008. Language

Dynamics and Capitalization using Maximum

Entropy. In Proceedings of ACL 2008: HLT

Companion volume, pages 1-4.

Brants, T. and Franz, G. 2006. Web 1T 5-gram Version 1.

Linguistic Data Consortium, Catalog ID:

LDC2006T13.

Chelba, C. and Acero, A. 2004. Adaptation of Maximum

Entropy Capitalizer: Little Data Can Help a Lot. In

Proceedings of EMNLP 2004, pages 285-292.

Church, K. 1995. One Term or Two? In Proceedings of

SIGIR 1995, pages 310-318.

Cucerzan, S. 2010. A Case Study of Using Web Search

Statistics: Case Restoration. In Proceedings of

CICLing 2010, LNCS 6008, pages 199-211.

Liţă, L. V., Ittycheriah, A., Roukos, S., and Kambhatla, N.

2003. tRuEcasIng. In Proceedings of ACL 2003, pages

152–159.

Mikev, A. 1999. A Knowledge-free Method for

Capitalized Word Disambiguation. In Proceedings of

ACL 1999, pages 159–166.

DOES CAPITALIZATION MATTER IN WEB SEARCH?

305

APPENDIX

Appendix 1: Random sample of 100 queries on which inter-agreement and matching statistics are reported. The queries

are shown with the original capitalization submitted by users. Original spelling was preserved; s

ace and punctuation were

normalized. Two queries (marked with ***) were anonymized for privacy reasons by changing the last names originally

present in the queries, but preserving the case information.

windows down loads ronald reagan

University of Miami , Ohio pregnancy safe hair color

buy bigger house or stay wayne doe ***

chaminade university john doe , England ***

tony stewart wallpaper furniture auctions

food lion auto fair time zones in the united states

easports msn music

handmade paper " elephant " crossword puzzles

hacienda puerto rico tax return onofrio dog shows

I485 form embryonic stem cell & diabetes

j and r staplescenter

BELGIUM HORSE MILK FIRST TIME HOME BUYERS PROGRAM MISSISSIPPI

M & T " India and Africa "

quest medical lab nj GASTROENTERITIS

what channel is hammy the hamster on in the usa 6 week makeover

cesar quintero lonestar steakhouse

youth football helments celeste

childrenplace esp hobby

idaho springs iowa sex offender registry

metabolism online casino with lots of slots free

HP Hard Drive anxiety overview

free quick budget tools ramsey " masha kirilenko "

Retroflex lateral flap 1973 4 speed cutlass

usa postal codes fighter aircraft of vietnam

forty - five seconds inside a tornado ontario tourism

keystone FAT ATTACK COMBO

Jenny Saville art pa lottery

cork strip HELL ANGELS MC

enolmatic Powassan virus

laptop memory Eastbay coupons

whitworth council Naruto music mp3s

news in south florida General Bandages

volvo c30 digging for the truth roanoke the lost colony

listen to grillz judge judy

bank one power acoustics amplifiers

anchorage hotel ogunquit google finance

contra costa county animal servies hip replacement recovery

neo pharm crate and barrel

tonic you wanted more lyrics hotwheels

robbins brothers jewerly wa state national guard

kdka truck trader on line

Communist diggers find hell coast guard

Peoria Illinois Doppler Radar abercrombie

classification of conflicts fertility calculator

trinity alps Oscar predictions Foreign Language Film

willard brothers auto sales Six Flags over Texas

aquarium fish anime

JPA dogpile

weatherchannel halmoon ny sherrif department

aim stuffing envelopes at home

KDIR 2010 - International Conference on Knowledge Discovery and Information Retrieval

306
