MITIGATION OF LARGE-SCALE RDF DATA LOADING WITH

THE EMPLOYMENT OF A CLOUD COMPUTING SERVICE

Hyun Namgoong

, Harshit Kumar

1,2

and Hong-Gee Kim

Biomedical Knowledge Engineering Lab, Seoul National University, Seoul, Korea

Department of Computer Science, University of Suwon, Hwaseong, Korea

Keywords: RDF data store, Data warehouse, Cloud computing service, Sesame.

Abstract: An expanding need for interoperability and structuralization of web data has made use of RDF (Resource

Description Framework) plentiful. To guarantee a common usage of the data within various applications,

several RDF stores providing data management services have been developed. Here, we represent a

systematic approach to solve a late latency problem of data loading of the stores. It enables a fast loading

performance for very large size of RDF data, and it is proven with an existing RDF store. This approach

employs a cloud computing service and delegates preparation works to the machines which are temporarily

borrowed at little payment. Our implementation for a native version of the Sesame RDF Repository was

tested on LUBM 1000 University data (138 million triples), and it showed a local store loading time of 16.2

minutes with additional preparation time on a cloud service taking approximately an hour, which can be

reduced by adding supplemental machines to the cluster.

1 INTRODUCTION

As a key technology in representing interlinking data

with heterogeneity, RDF (Resource Description

Framework) is becoming a common way to publish

structured data throughout the web (Bizer, 2007).

Although there are difficulty and inefficiency in

RDF data processes, the efforts for expansion of

uses of the data expression formats are still evolving.

The possibility of interoperability and inference are

competitive edges of RDF data.

Providing an interactive querying service on

RDF data has been a huge research issue in the

Semantic Web research area. Several RDF stores

have been developed during past years (Erling,

2007)(Broekstra, 2002)(Liu 2005). The stores

evaluating a SPARQL query by retrieving stored

triples recently met a scalability issue with an

expansion of RDF data.

The point of this paper is focused on bulk data

loading in the RDF data stores. Loading a large

amount of data is an essential task that stores usually

meet at the initial time. Preparation works like

assigning unique IDs for each unique value and

building index systems, e.g., B tree and Bitmap

precedes in the stores to boost data access speed

during querying. Those works are time consuming

process and it is hard to coordinate with multiple

machines. Therefore, a scaled loading capability

within a reasonable time is one of the issues for the

improvement of RDF store, because, their poor

performance obstructs the use of web-scale

knowledge bases such as conspicuously evolving

linked data (Bizer, 2007).

This paper introduces a systematic approach

employing a cloud computing service which takes a

local store’s preparation works for mitigating bulk

data loading. This paper depicts how the loading

preparation works can be translated to a series of

batch processes to be handled in a MapReduce

cluster which can be easily usable with computing

resources of cloud computing service.

2 RELATED WORKS

There are several RDF stores developed by semantic

web research groups being widely employed for

handling RDF data. Representative systems like

Sesame, Virtuoso, and Jena provide RDF data

management services with their own data storing

schema. The performances of a repository are

measurable with test data sets and sample queries of

widely known Semantic web repository benchmarks

489

Namgoong H., Kumar H. and Kim H..

MITIGATION OF LARGE-SCALE RDF DATA LOADING WITH THE EMPLOYMENT OF A CLOUD COMPUTING SERVICE.

DOI: 10.5220/0003142204890492

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2010), pages 489-492

ISBN: 978-989-8425-29-4

 2010 SCITEPRESS (Science and Technology Publications, Lda.)

like LUBM (Guo, 2005) and SP2B (Schmidt, 2008).

Current benchmarks show a many number of queries

can be dealt with in nearly real time with some

heuristic methods like query optimizations (Schmidt,

2008). However, in a point of data loading, the

stores are still suffering from insufficient

performance which is a great bottleneck in use of

RDF stores. It is involved with even several

gigabytes data. and, it is getting worse in a linier

scale with increasing size of data

Cloud Computing Services are a recent trend

which introduced the concept of the borrowing of

computing resources from the web. Web based

service sites like Amazon and Google opened their

idle resources to public users. A service user can

borrow some of their computing resources to process

a large-scale data that recalls a massive amount of

computation.

By adapting a cloud computing service for

helping a part of data loading process, the proposed

system makes the RDF stores relieved from a burden

of the data loading. The borrowed machines in the

cloud computing service handle the preparation

works, and they hand over the pre-processed RDF

data to the RDF stores, so that, the store can load it

easily. This paper explains an implementation of

those preparation works using MapReduce

framework which provides black box interface for

archiving a batch data processing work with the

multiple machines network-wired.

MapReduce (Dean, 2008) is a programming

model and an associated implementation for

processing and generating large data sets. Users

specify a map function that processes a key/value

pair to generate a set of intermediate key/value pairs,

and a reduce function which merges all intermediate

values associated with the same intermediate key.

The computation takes a set of input key/value pairs,

and produces a set of output key/value pairs.

3 SACE

We implemented ‘with Cloud Version’ of Sesame

Native Store named SACE (Sesame Sail with a

Cloud Computing Environment). The

implementation consists of a realization of multi-

machine works of a cluster constructed on the

Amazon Web Service and a simple manipulation on

Sesame as a local store.

The multi-machine work is designed as a serial

execution of five steps. An execution of such

processes prepares four internal data files for a

Sesame local store, three value encoding related files

explained above plus a namespace file. Sorted triple

files corresponding to the sequences of triple indexes

are also provided after the final step.

Figure 1: Designed Processed on a Cloud Computing.

Figure 1 describes those five steps for the

preparation helping Sesame’s loading process. Each

step is executed by the rented machines from a cloud

computing service that is depicted as squares. The

whole processes are done with three MapReduce

(M-R) works, single machine work and a multi-peer

work.

 Step #1. Parsing & Splitting Input RDF Files

RDF Parsing does not play a huge part from the

viewpoint of time consumption. Less than 1 percent

from the whole overload occupied by the job as

described previously. Although, this work does help

the loading process of a local server, it is still

required to perform the other jobs in a cloud service.

This work is designed as a type of M-R

programming. The mappers charging the distribution

of data to the reducers are equipped with a Jena RDF

parser. Each mapper parses a series of input files

shared by a master peer and splits them into triples

in parallel to be sent to the reducers. A random

integer is made to evenly distribute those triples to

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

490

multiple numbers of reducers. The reducers deliver a

single file including whole triples. The namespaces

of each are specially gathered using a specified key

value to be sent to a specific reducer.

 Step #2. Unique Value Identification

At Step 2 all values occurring in a whole triple from

Step 1 are extracted as unique values. Execution of

this step can be archived with a characteristic of M-

R. When a value is assigned as a key for the M-R

process, the value is sent to a reducer which only

deals with the same values as that value. The only

code executed in reducers is omitting its key once

disregard values. A list of unique values is the

output of this step.

 Step #3. Unique ID Assignment

Step 3 is need for the preservation of the ID of the

decoding files. This process is designed to be

handled by a single computing machine so as not to

suffer the problems of multiple peer synchronization

during the assignment of an ID for each value. Three

decoding files, the value data, hash-id, value-id files

and the namespace file are provided with unique

values from the previous step during this step. The

unique value hash-id is also made, so that, triples

can be translated into a set of IDs. Hash code based

on segmentation of these data is required for quick

access to them.

 Step #4. Triple Translation

All triples should be translated into ID based

triples to be provided as a sorted triple set

corresponding to triples index options. To archive

translation work in the multiple peers in parallel, the

value hash-id file is delivered to the machine

involved in this step. Using the hash-id pair file,

every triple is rewritten as a set of IDs.

 Step #5. Triple sorting

The final step is the sorting that arranges ID based

triples in sequential order. This step works similarly

to the second step. The different selections of a key

value were added to make diversely sorted triples

corresponding to the triple index sequences.

4 EXPERIMENTAL RESULT

This section describes two experimental results 1)

expected times for the execution of designed M-R

processes. 2) loading time in a local store with pre-

processed RDF data.

There is a trade-off between cost and performance,

in M-R processes. Because, the time spents of these

processes are also dependent on the number of

machines employed from the cloud computing

service. We try to describe a brief benchmark result

that includes the overall tendencies rather than a

definitive benchmarking of the processes which is

not much critical issues. Therefore, some

unrespectable and short times for operation transfers,

as well as machine configuration and data

transmission times are omitted, and the time spent

for each step is described.

The elapsed times for each step are depicted in

Figure 2. The graph shows the result of step 1, step 2,

step 4, and step 4, respectively. It is tested for the

following numbers of nodes, 5, 10, 20, 40, and 80.

With 80 nodes of computing machines for LUBM

1000 univ data, step 1 takes about 35 minutes, 2.5

minutes for step 2, a minute for step 4, and 9

minutes for step 5. Step 4 handled by a single

machine takes about 17 minutes for the data. The

process of step 4, sorting encoded triples, requires

several executions for each distinct order, so, this

step takes relatively much more time than step 2.

2. A 2. B

2.C 2.D

Figure 2: Benchmark Times for Steps 1, 2, 4, and 5.

Also, a payment for the use of the cloud

computing service is a criterion to judge the

practical usefulness of this approach. For each size

of data (500 univ, 1000 univ), about 8$ and 16$ are

charged, respectively. The payment was calculated

with the multiplication of a standard cost for a

medium size of High-CPU On-Demand Instances

($0.20 per hour and a number of marked machines

plus one for a master. An employment of many

machines shows a sustained scale by the

enlargement of the number of nodes because of

decreasing whole data process time.

As described, after the process at the cloud

computing service, the rests of loading process need

MITIGATION OF LARGE-SCALE RDF DATA LOADING WITH THE EMPLOYMENT OF A CLOUD COMPUTING

SERVICE

491

be archived at the local store. In the provided

implementation with Sesame, the construction of the

B tree needs to be archived at the local store. As we

described, ordered triples data will help the

construction task fast.

To get the experimental results of the local RDF

store’s work, we made a revision on the Native

version of Sesame. The revised Sesame reads value

storing files handed over by a master node of the

M/R cluster. Then, it executes pre-processing on

behalf of the store.

The environment is as follows:

Ubuntu 2.24.1 of Linux, CPU: Intel quad core 2.8GH,

Memory: 3.5GB Samsung, HDD: 500GB S-ATAII

(7200 rpm) with single partition, Java SDK 1.6 version,

JVM Heap Size: Minimum 1024 MB, Maximum 2048

MB.

Figure 3: Benchmark Times in Local Store.

The result in the Figure 3 shows very fast

loading time on the data set from LUBM 50 univ ~

1000 univ. It only takes about 16 minutes for 138

million triples (1000 univ) with higher TPS rates.

Also, for extremely large sized data sets which

include non realistic numbers of triples, it also

shows a reasonable loading time. A passable process

time on a cloud computing service for those sizes of

data could be archived similarly with the computing

times we have shown.

Figure 4: Very Large-Scale Benchmarks in Local Store.

5 CONCLUSIONS

We presented the practical approaches to

dynamically reduce large-scale RDF data loading

with the aid of a cloud computing service.

Experimental results giving insight on the overall

time spent are also provided a conversion from a

single machine-based job to multiple machine work.

For such conversions, M-R programming and simple

parallel processing are embodied. The

implementation for a native version of Sesame RDF

Repository delivers a very fast loading time marked

a local store loading time of 16.2 minutes with

additional preparation time on a cloud service,

which can be lessened by adding supplemental

machines.

ACKNOWLEDGEMENTS

This work was supported in part by MKE & KEIT

through the Development of Independent

Component based Service-Oriented Peta-Scale

Computing Platform Project.

REFERENCES

Bizer, C., Cyganiak, R., Heath, T., 2008. How to Publish

Linked Data on the Web, Available at:

http://www4.wiwiss.fu-berlin.de/bizer/pub/

LinkedData Tutorial/20070727/.

Broekstra, J., Kampman, A., Harmelen., F., 2002.

Sesame: A Generic Architecture for Storing and

Querying RDF and RDF Schema, International

Semantic Web Conference (ISWC 2002).

Guo, Y., Pan, Z., Heflin., J., 2005. LUBM: A Benchmark

for OWL Knowledge Base Systems, Journal of Web

Semantics3.

Schmidt, M., Hornung, T., Küchlin, N., Lausen, G.,

Pinkel, C., 2008. An Experimental Comparison of

RDF Data Management Approaches in a SPARQL

Benchmark Scenario, International Semantic Web

Conference (ISWC 2008).

Schmidt, M., Hornung , T., Küchlin, N., Lausen, G.,

Pinkel, C., 2008. An Experimental Comparison of

RDF Data Management Approaches in a SPARQL

Benchmark Scenario, International Semantic Web

Conference (ISWC 2008).

Liu, B., Hu, B., 2005. An evaluation of RDF storage

systems for large data applications, In Proceedings of

the First International Conference on Semantics,

Knowledge and Grid.

Erling, O., and Mikhailov, I., Towards Web-Scale RDF,

Available at: http://virtuoso.openlinksw.com/

dataspace/dav/ wiki/Main/VOSArticleWebScaleRDF.

Dean, J., Ghemawat, S., 2008. MapReduce: simplified

data processing on large clusters, Communications of

the ACM, v.51.

KEOD 2010 - International Conference on Knowledge Engineering and Ontology Development

492
