AN ANTI-DOS AUTHENTICATION

SYSTEM IN M-COMMERCE *

Liang Wang and Runtong Zhang

School of Publishing Communication and Management, Beijing Institute of Graphic Communication

Institute of Information System, Beijing Jiaotong University, Beijing, China

Keywords: M-Commerce, Identity Authorization, Anti-DoS, S/Key OTP.

Abstract: This paper analyzed the shortages under DoS attack of S/KEY OTP system in m-commerce identity

authentication and suggested an improved one-time password system based on bidirectional virtual

authorization in m-commerce systems. On one hand, this suggestion can reduce the calculation stress of

both client and server, accordingly increases the efficiency of authorization and withstands the DoS attack.

On the other hand, the suggestion can implement the bidirectional authorization and reduce the possibility

of fishing attack.

1 BACKGROUND

1.1 One-Time Password

The idea of OTP (One-Time Password) was first

suggested by American scientist Leslie Lamport

(Lamport, 1981) in early 1980s of the 20th century.

The principle of OTP is adding some uncertain

factors in the procedure of authorization. Every time

user logins, the information transmitted on network

is different, thus the security is improved (Wang,

2007).

1.2 The S/KEY OTP System

(Haller, 1995)

Based on the idea of OTP system, Bellcore produced

S/KEY OTP system in 1991. An S/KEY OTP

system client passes the user's secret pass-phrase

through multiple applications of a secure hash

function to produce a one-time password. On each

use, the number of applications is reduced by one.

Thus a unique sequence of passwords is generated.

The S/KEY OTP system host verifies the one-time

password by making one pass though the secure

hash function and comparing the result with the

previous one-time password (Haller, 1995). In

S/KEY OTP system, the secret pass-phase stores in

neither client nor server. And only an irreversible

one-time password transmitted on the network, the

secret pass-phase doesn’t be transmitted at any time,

so this system can counter replay-attacks effectively.

Figure 1 outlines the procedures of S/KEY OTP

system.

The S/KEY OTP system is a simple mechanism

and does not need a notarization by the third part. So

it is suitable for some low performance system like

mobile devices. Thus the S/KEY OTP system can be

used in mobile commerce identity authentication.

Client

Server

Send a login request

Send S and N

Generate a seed

(S) and an iterative

number (N)

Compare

Hash(PW

) with the

latest stored PW

N+1

If the authorization is

successful, Store

and N=N-1

Send PW

Send the result

Input the pass-

phrase (PP) and

Calculate

=Hash(PP+S)

Figure 1: The authorization procedure of S/KEY OTP

system.

252

Zhang R. and Wang L.

AN ANTI-DOS AUTHENTICATION SYSTEM IN M-COMMERCE.

DOI: 10.5220/0003268702520256

In Proceedings of the Twelfth International Conference on Informatics and Semiotics in Organisations (ICISO 2010), page

ISBN: 978-989-8425-26-3

2 SHORTAGES OF S/KEY OTP

SYSTEM IN MOBILE

APPLICATION

There are a lot of advantages of S/KEY OTP

System, such as serviceability, flexibility and

dynamism. But in the environment of mobile

commerce identity authentication, some shortages

appear.

1) The S/KEY OTP system will launch

multiple calculation whenever it receive a legal of

illegal requests., Hackers may utilize this shortage to

make a mass of illegal requests to implement a DoS

attack. The authorization server makes huge amount

of calculation for the illegal requests until crashed.

2) The S/KEY OTP system only implement

one side authentication, Hackers may utilize this

shortage to make an imitated server to implement a

fishing attack.

3 BIDIRECTIONAL VIRTUAL

AUTHORIZATION

To solve the problems, two tasks must be achieved.

One is to cut down the amount of calculation to the

full. The other is to let the client verify the identity

of the server.

So we suggest the model of “Bidirectional

Virtual Authorization”, the following content tells

the procedure of this model. Figure 2 outlines the

physical architecture of the improved system.



Client Mobile Device

Data Files

Mobile Communication Network

Authorization Server Database ServerApplication Server

Figure 2: The physical architecture of the improved

system.

3.1 The Procedure of Registration

Step 1: The client generates a request of

registration;

Step 2: The server generates a response to establish a

connection;

Step 3: The client inputs user’s id (UID) and

pass-phrase (PP);

Step 4: The server checks the existence of UID.

If UID has existed, return the error message and

finish the registration. Else return the success

message.

Step 5: If UID does not exist, the server

generates a seed (S) and an initial iterative number

(N0) and sends S and N0 to the client.

Step 6: The server calculates the initial server-

side password (PWS0) and saves it as current server-

side password (PWS), at the same time, save the

current iterative number (N) using the initial

iterative number subtracts 2:

= PW

= Hash (PP + S)

(1)

N = N

– 2 (2)

Step 7: The client calculates the initial client-side

password (PWC0) and saves it as current client-side

password (PW

= PW

= Hash (PP + S)

–

(3)

The procedure of registration completes. See

figure 3.



Client

Server

Step 1

Step 5

Step 4

Step 2

Step 3

Step 6Step 7

Figure 3: The registration procedure of the improved

system.

3.2 The Procedure of Authorization

Step 1: The client generates a request of

authorization;

Step 2: The server generates a response to

establish a connection with the seed (S), current

iterative number (N) and current server-side

password (PWS);

Step 3: The client get S, N and PWS, then

calculates Hash (PWC). If PWS = Hash (PWC), the

AN ANTI-DOS AUTHENTICATION SYSTEM IN M-COMMERCE

253

server’s identity is authorized, Else the client will

finish the authorization. In this step, we have

established the server-client authorization

successfully.

Step 4: After verifying the server, the client

calculates Hash (PP+S) N-1 and compares it with

PWC stored locally, if PWC ≠Hash (Hash (PP+S)

N-1) 2, the client should ask the user to re-input the

pass-phrase without notifying the server. In this step,

we have established the virtual authorization on

client-side successfully.

Step 5: The client sends the value of Hash

(PP+S) N to the server.

Step 6: The server get the value of Hash (PP+S)

N sent by client, then calculates Hash (Hash (PP+S)

N) 2 and compares it with PWS stored locally, if

PWS ≠Hash (Hash (PP+S) N) 2, the server should

send an error message to the client.

Step 7: After complete an authorization

successfully, the server should update the current

server-side password (PWS) with the value of Hash

(PP+S) N, at the same time, the iterative number (N)

subtracts 2:

= Hash (PP+S)

(4)

Step 8: After complete an authorization

successfully, the client should update the current

client-side password (PWC) with the value of Hash

(PP+S) N-1.

The procedure of authorization completes. See

figure 4.

Client

Server

Step 1

Step 2

Step 3

Step 6

Step 8

Step 3

Step 4

Step 5

Step 7

Figure 4: The authorization procedure of the improved

system.

3.3 The Procedure of Synchronization

When the iterative number goes to zero or the client

reinstall the system, the system must reset the

iterative number (N). In these situations, the

procedure of authorization occurred first. After

complete the authorization successfully, the server

generates a new initial iterative number (N0) and

sends N0 to the client. To solve the two problems

above, two tasks must be achieved. The

communication should be under secure environment.

4 SYSTEMS SIMULATION

4.1 Running Environment of the

Simulation

Platform: Intel(R) Core2 E7500 with 2G Memory

Operating System: Microsoft Windows Server 2003

Develop Environment: Microsoft Visual Studio

2008

Application Server: Microsoft IIS 7

Analysis Toolkits: NS2, Gnuplot and Xgraph Tools.

4.2 Simulation Approach

According to the authorization procedures analyzed

above, we developed a simulation system. This

system executes the authorization procedures several

times and records the network traffic and delay

using NS2 software and the Gnuplot and Xgraph

toolkits.

The wireless model essentially consists of the

mobile node at the core, with additional supporting

features that allows simulations of mobile networks.

The mobile node object is a split object. The C++

class mobile node is derived from parent class Node.

A mobile node thus is the basic node object with

added functionalities of a wireless and mobile node

like ability to move within a given topology, ability

to receive and transmit signals to and from a

wireless channel etc. In this paper we described the

internals of mobile node, its routing mechanisms, the

routing protocols, creation of network stack allowing

channel access in mobile node, brief description of

each stack component, and trace support and

movement/traffic scenario generation for wireless

simulations), see figure 5.

Figure 5: The simulation approach of the improved

system.

ICISO 2010 - International Conference on Informatics and Semiotics in Organisations

254

4.3 Simulation Results

Table 1: Average network traffics simulation result data of

the original and improved system in common situation.

Nodes

Avg. Traffics of

Original Solution

(Bytes/ms)

Avg. Traffics of

Improved Solution

(Bytes/ms)

10 2417.6 2433.8

20 3515.1 3601.2

30 8262.5 8266.1

40 13866.3 14011.2

50 17662.3 17710.1

According to the data form Table 1, we get the

chart below.

Figure 6: Average network traffics comparison between

the original and improved system in common situation.

Table 2: Average network traffics simulation result data of

the original and improved system in DoS attack simulation

situation.

Nodes

Avg. Traffics of

Original Solution

(Bytes/ms)

Avg. Traffics of

Improved Solution

(Bytes/ms)

10 3756 2455.3

20 6899.1 3811.5

30 15176.3 8512.2

40 24701.8 15227

50 32833.3 18216.5

According to the data form Table 2, we get the

chart below.

Figure 7: Average network traffics comparison between

the original and improved system in DoS Attack

Simulation Situation.

5 THE COMPARISON BETWEEN

THE IMPROVED AND THE

ORIGINAL SYSTEM

Comparing with the Original S/KEY OTP system,

the improved system changes the digression factors

to 2 from 1, and stores the values of N times and N-1

times iterative on server and client respectively.

With this method, the bidirectional virtual

authorization is established. The advantages of the

improved system have shown in the following

factors.

5.1 Portability

When the client of improved system meets wrong

locally without notifying the server, then the stress

of the server is reduced greatly and the server can

resist the DoS attack to a certain extent.

5.2 Bidirectional Authorization

When an authorization request is generated, the

client asks the server to send the information that

stored in server latest and verifies it. If the

verification failed, the authorization procedure will

be interrupted. Thus the client can resist the fishing

attack to a certain extent.

6 CONCLUSIONS

In this paper, we analyzed the characteristics of

mobile commerce, suggested the shortages of

S/KEY OTP system in mobile commerce

applications. Then we proposed an improved One-

Time Password system model. According to our

discussion, our One-Time Password system model

inherited the advantages of S/KEY OTP system, and

improved it in portability and security. The

improved system model is more suitable for the

authorization of mobile commerce.

REFERENCES

Lamport. L., 1981. Password Authentication with Insecure

Communication. In Communications of the ACM

24.11, pp.770-772.

Haller. N., 1995. The S/KEY One-Time Password System.

In Bell Communications Research and Naval

Research Laboratory.

AN ANTI-DOS AUTHENTICATION SYSTEM IN M-COMMERCE

255

Hongying Wang, 2007. Research and Design on Identity

Authentication System in Mobile-Commerce. In

Beijing Jiaotong University, pp. 18–50.

Haller. N., and R. Atkinson, 1994. On Internet

Authentication. In Bell Communications Research and

Naval Research Laboratory.

ICISO 2010 - International Conference on Informatics and Semiotics in Organisations

256
