OPTIMAL SAMPLE SELECTION FOR BATCH-MODE
REINFORCEMENT LEARNING
Emmanuel Rachelson, Franc¸ois Schnitzler, Louis Wehenkel and Damien Ernst
Montefiore Institute, University of Li
`
ege, B-4000 Li
`
ege, Belgium
Keywords:
Stochastic optimal control, Sample control, Reinforcement learning.
Abstract:
We introduce the Optimal Sample Selection (OSS) meta-algorithm for solving discrete-time Optimal Control
problems. This meta-algorithm maps the problem of finding a near-optimal closed-loop policy to the iden-
tification of a small set of one-step system transitions, leading to high-quality policies when used as input
of a batch-mode Reinforcement Learning (RL) algorithm. We detail a particular instance of this OSS meta-
algorithm that uses tree-based Fitted Q-Iteration as a batch-mode RL algorithm and Cross Entropy search as a
method for navigating efficiently in the space of sample sets. The results show that this particular instance of
OSS algorithms is able to identify rapidly small sample sets leading to high-quality policies.
1 INTRODUCTION
Many problems in the fields of Finance, Engineer-
ing or Medicine can be cast as discrete-time Optimal
Control problems. Such problems feature a dynamic
system that evolves over several time steps and re-
ceives various rewards along the way, depending on
how well it performs. Solving these problems con-
sists in generating a sequence of appropriate control
inputs, in order for the system to follow a trajectory
providing an optimal cumulated reward. In the gen-
eral case, this resolution rapidly becomes very chal-
lenging as the problem’s size grows. Optimal Control
problems have been studied by various communities
(e.g., Artificial Intelligence, Control Systems, Opera-
tions Research, or Machine Learning), each using dif-
ferent assumptions and formalisms to design algorith-
mic solutions.
Reinforcement Learning (RL) (Sutton and Barto,
1998) is a subfield of Machine Learning where one
tries to infer a good closed-loop control policy from
the sole knowledge of an observed set of one-step sys-
tem transitions and their associated rewards. Such a
set results from the sampling of the system’s under-
lying dynamics and rewards. When this set of sam-
ples is given at once, as an input of the learning al-
gorithm, one talks of batch-mode RL. In recent years,
batch-mode RL algorithms, such as the tree-based Fit-
ted Q-Iteration (FQI) (Ernst et al., 2005) or the Least
Squares Policy Iteration (Lagoudakis and Parr, 2003a)
algorithms, proved successful in tackling large Opti-
mal Control problems. These methods relied on ap-
propriate approximation architectures to efficiently
generalize information throughout the state space. We
now wish to understand how they could be used for
solving large-scale problems when one has some free-
dom in the sample set input. In other words, we break
free from the standard batch-mode RL hypothesis of
a fixed, imposed sample set, and suppose that a gen-
erative model is available, providing an unconstrained
way of picking new sample sets. Suppressing the con-
straint of a fixed, unquestionable input sample set,
and allowing this input to be considered as a prob-
lem’s variable, raises the question of identifying a set
of one-step transitions which maximizes the learning
algorithm’s output, while keeping the number of such
one-step transitions low, so as to extract good policies
from the sample set in a reasonable amount of time.
An immediate approach at answering this question
would be to collect experience uniformly and exten-
sively over the problem’s state-action space, as finely
as necessary to provide a good representation of the
system. But for large scale problems, as the dimen-
sion of this state-action space grows, such a sample
set becomes so large that processing it becomes in-
creasingly difficult (as reported in (Ernst, 2005) for
instance). Hence, the problem we address in this con-
text consists in identifying a training set of one-step
transitions which both has a limited size, and max-
imizes the algorithm’s output. For this purpose, we
concentrate on the question of finding the input sam-
ple set of size N that will generate the best possible
41
Rachelson E., Schnitzler F., Wehenkel L. and Ernst D..
OPTIMAL SAMPLE SELECTION FOR BATCH-MODE REINFORCEMENT LEARNING.
DOI: 10.5220/0003133500410050
In Proceedings of the 3rd International Conference on Agents and Artificial Intelligence (ICAART-2011), pages 41-50
ISBN: 978-989-8425-40-9
Copyright
c
2011 SCITEPRESS (Science and Technology Publications, Lda.)
output policy, for a given batch-mode RL algorithm
and a predefined sample set size N.
After recalling, in Section 2, the main notions
of discrete-time Optimal Control and Reinforcement
Learning, we formulate the search for an optimal
fixed-size sample set as an optimization problem and
discuss its properties in Section 3. This leads to the
definition of the general Optimal Sample Selection
(OSS) meta-algorithm for solving Optimal Control
problems. Section 4 details a particular instance of
OSS, using the tree-based FQI algorithm and Cross-
Entropy search. Section 5 reports the method’s re-
sults on the “car on the hill” domain, empirically il-
lustrating the fact that small optimized sample sets
can lead to high quality policies. Building on these
optimization results, Section 6 discusses some more
general properties of OSS methods, highlighting their
strengths, weaknesses and perspectives. We particu-
larly emphasize their potential for solving large scale
Optimal Control problems. We finally summarize our
contribution and conclude in Section 7.
2 OPTIMAL CONTROL AND
REINFORCEMENT LEARNING
The framework of discrete-time Optimal Control
(Bertsekas and Shreve, 1996) covers decision prob-
lems where one tries to control a system, character-
ized by its state x X, through the application of a
sequence of discrete-time commands (u
t
)
tN
,u
t
U,
in order to optimize a criterion based on the system’s
trajectory. Formally, such problems are described by
a four-tuple hX ,U, f ,ri, where X is the state space in
which the system evolves, U is the set of all possi-
ble commands (or actions), f and r are respectively a
transition and a reward model as illustrated on Figure
1. In the deterministic case, at time step t, if command
u is applied while the system is in state x, a transition
is triggered to the next state x
0
= f (x, u). For this tran-
sition, a reward r(x, u) is gained.
In the general case of stochastic Optimal Control,
the (stationary) transition model is actually stochas-
tic: f (x, u) is a distribution over the possible next
states x
0
, and one writes x
0
f (x,u). The reward func-
tion then corresponds to the expected one-step reward
for the considered state-action pair. For the sake of
simplicity, we will consider deterministic problems in
Sections 3 to 5 and will extend our approach to the
stochastic case in Section 6.
A (stationary) closed-loop controller, or decision
policy, for a discrete-time Optimal Control problem
is a function µ : X U (µ F (X,U)), mapping each
state x to an action u to undertake. The criterion J
µ
we
t
x
t + 1
x
= f (x, u)
r(x, u)
reward:
state:
time:
Figure 1: Transition and reward models of a discrete-time
control problem.
will consider in order to discriminate between policies
and define optimality is the standard, infinite horizon,
γ-discounted criterion. It maps each state x to the sum
of the γ-discounted successive rewards obtained when
applying policy µ from x, for an infinite number of
steps: x X,
J
µ
(x) =
t=0
γ
t
r(x
t
,µ(x
t
)) with
x
0
= x and
x
t+1
= f (x
t
,µ(x
t
))
Then, a policy µ
is said to be optimal if:
x X ,µ F (X,U), J
µ
(x) J
µ
(x)
The J
µ
function of a policy µ is called its value
function. One writes J
the value function of any op-
timal policy.
RL algorithms aim at finding the best control pol-
icy when the transition and reward models of the pro-
cess are unknown. Instead, they rely on the collec-
tion of one-step transition samples from this under-
lying model. Each sample describes a one-step tran-
sition as a four-tuple (x, u,r, x
0
). These samples can
be obtained either from interaction with the physical
system or from a generative model. Hence, the stan-
dard input of any batch-mode RL algorithm is a set
of samples D = {(x,u,r,x
0
)}, approximating the tran-
sition and reward models, from which the algorithm
infers a policy µ
D
.
Since many applications of RL have very large
or multi-dimensional, continuous state spaces, find-
ing an exact representation of the optimal policy or
value function is often a very difficult task. Conse-
quently, there is a need for approximation methods
that are able to solve the policy inference problem in
a compact and efficient fashion (Bus¸oniu et al., 2010).
In order to overcome this difficulty, different value
function and policy approximation architectures have
been proposed in the literature, such as combinations
of linear features (Boyan, 1999), kernel methods (Or-
moneit and Sen, 2002), forests of trees (Ernst et al.,
2005) or classifiers (Lagoudakis and Parr, 2003b). All
these methods have greatly contributed to extending
the practical applicability of RL.
3 OPTIMIZING SAMPLE SETS
The general goal of batch-mode RL is, given a sam-
ple set D as input, to compute a policy µ
D
which is as
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
42
θ
sample(·)
D
policy inference(·)
µ
D
score(·)
M (θ)
Figure 2: Score of a sampling scheme.
close as possible to an optimal policy for the system
the samples were gathered from. The RL literature
provides a whole span of efficient methods to com-
pute such a µ
D
.
Consider the context where a generative model of
the system is available. Such a model outputs a one-
step transition (x,u, r,x
0
) when presented with a state x
and an action u. In many Optimal Control problems,
such a model is often available. Since we have this
generative model, the input sample set D is no longer
imposed to us. The Optimal Control practitioner will-
ing to exploit batch-mode RL methods then needs to
answer the simple question of how to generate a good
sample set, prior to running his favourite algorithm.
The generic question of collecting data for batch-
mode RL algorithms has received little attention in
the literature, as this problem is usually tackled from
a problem-specific point of view (e.g., (Neumann and
Peters, 2009; Riedmiller, 2005; Ernst et al., 2006)).
We investigate a way to tackle this problem from a
generic, problem-independent, point of view.
3.1 Optimal Sample Selection
We consider the framework where the sample set’s
size is fixed and the batch-mode RL algorithm is
chosen, and, in this context, we introduce a meta-
algorithm
1
for generating good sample sets D.
Consider a sample set D =
{
(x,u, r,x
0
)
}
and let us
introduce the set θ =
{
(x,u)
}
which we call the sam-
pling scheme leading to D. Although, in the determin-
istic case, there is a complete equivalence between θ
and D, this distinction will appear necessary when we
extend this contribution to stochastic systems in Sec-
tion 6. Suppose also that, for convenience, we ordered
the different elements
2
in D and θ:
D =

x
i
,u
i
,r
i
,x
0
i

i[1;N]
θ =
{
(x
i
,u
i
)
}
i[1;N]
Let sample(·) be the operator that computes D
from θ, using the generative model. Let also
policy inference(·) denote the batch-mode RL algo-
rithm used, taking a set D as input, and outputting a
1
We refer to it as “meta” because it considers a generic
batch-mode RL algorithm among its inputs.
2
For the sake of simplicity, in the remainder of the pa-
per, we will make a slight notation abuse and will refer to θ
indifferently as the set
{
(x,u)
}
or as the vector of variables
describing the elements of this set.
policy µ
D
, which is optimal (or quasi-optimal) with
respect to an implicit, approximate problem, implied
by D. Let us finally assume there exists a generic cri-
terion score(µ), allowing to evaluate the actual quality
of a policy µ, when applied to the domain at hand.
Then we propose to identify a good training set by
formulating the following optimization problem (il-
lustrated on Fig 2):
θ
argmax
θ(X×U)
N
M(θ) (1)
M(θ) = (score policy inference sample) (θ)
Hence, given an Optimal Control problem’s gen-
erative model, a batch-mode RL algorithm, and a size
N of sample sets, we call Optimal Sample Selection
method of parameter N (OSS(N)), an optimization
method searching for this optimal sampling scheme
θ
and returning µ
= policy inference(sample(θ
)),
as shown in Algorithm 1.
Algorithm 1: General layout of the OSS (N) meta-
algorithm.
Input: Batch-mode RL alg. policy inference(·), ;
Policy evaluation method score(·),;
Generative model sample(·).;
Define M(θ) as in Equation (1). ;
Compute θ
= argmax
θ
M(θ). ;
Return policy inference(sample(θ
)).
3.2 Creating Instances of OSS(N)
The performance and behaviour of an OSS(N) in-
stance will depend on the choices made for score(·)
and policy inference(·), but also on the value of N
and on the optimization method used to solve prob-
lem 1. We provide hereafter some elements that may
help make these choices.
Score Function. The score function should be cho-
sen in order to guarantee that a policy which max-
imises this score is indeed a policy which, when used
to control the real system, leads to high cumulated re-
wards. If the initial states from which the policy will
have to drive the real system are known, a suitable
choice for the score(·) function could be for exam-
ple the average return of the policy over these initial
states. These returns can be evaluated through Monte-
Carlo simulations, using the generative model.
Batch-mode RL Algorithm. Most efficient batch-
mode RL algorithms rely on value function or policy
approximation architectures. A necessary condition
for the OSS algorithm to work well is that there must
OPTIMAL SAMPLE SELECTION FOR BATCH-MODE REINFORCEMENT LEARNING
43
exist a sampling scheme leading to high-performance
policies, which implies that these architectures need
to be able to represent accurately (at least) the optimal
policy. In general, this necessary condition is more
likely to be verified if the RL algorithm relies on a
rich, versatile approximation architecture. Note also
that from one RL algorithm / approximation method
to the other, the optimal sampling scheme θ
might
vary.
Choosing N. Picking N is a compromise between
policy quality and computation time. Larger N in-
crease the chance to find good policies, since the do-
main dynamics are captured more finely, but also re-
sult in increased computation burden. As Section
4 will illustrate, the main source of complexity of
finding an optimal θ comes from the dependency of
policy inference(·)s complexity on N. Hence, look-
ing for very small sample sets seems desirable. On the
other hand, below a certain threshold on N, the search
space (X ×U)
N
might not contain any element able to
generate a policy leading to an optimal score. When
N increases, there may exist more and more elements
in this search space that lead to policies having near-
optimal scores, and hence, finding such elements in
the resolution of problem 1 can be easier. Therefore,
the choice of N needs to balance the need for fine do-
mains representation with the processing abilities of
policy inference(·). In very large domains, the former
constraint will prevail.
Optimization Algorithm. Computing or evaluat-
ing the gradient
M
∂θ
, or any subgradient of M(·) may
reveal itself very difficult in the general case. In
some very specific cases of RL algorithms, approx-
imation architectures, and criteria used for M, an an-
alytic formulation might be found, but we concen-
trate on the general case where such a gradient is
not available. As a matter of consequence, we need
to carefully choose the optimization method we will
use in order to find θ
. Since we cannot use any
derivative of the M function, our resolution method
needs to be of “order zero”. These methods corre-
spond to gradient-free optimization methods (such as
EDA optimization, simulated annealing or genetic al-
gorithms). However, such methods require numerous
computations of M(·), each of them being costly in
terms of calculation resources because each implies
performing all the steps of the RL algorithm for which
the problem is defined. While the reduced number of
variables in θ helps leveraging this computational bur-
den, experience dictates it cannot make it negligible.
So this second constraint of Ms evaluation cost must
be carefully taken into account when choosing the op-
timization method.
4 OSS(N), TREE-BASED FQI AND
CROSS-ENTROPY SEARCH
In this section, we define an instance of OSS(N) by
using tree-based FQI as policy inference(·), Monte-
Carlo simulation as score(·), and Cross-Entropy
search as the optimization technique.
A simple and efficient way of searching for a func-
tion’s maximum when computing its gradient is
not possible consists in transforming this deter-
ministic problem into a so-called associated stochas-
tic problem
3
(Kroese et al., 2006). Cross-Entropy
(CE) search (Rubinstein and Kroese, 2004) is one of
the methods that proved successful in this framework.
The key idea of CE search, applied to our RL set-
ting, is to let a distribution on (X ×U)
N
converge to-
wards the best sample set, with respect to M(θ). Al-
gorithm 2 presents, in a nutshell, the CE optimization-
based OSS method applied to the computation of an
optimal policy with the tree-based FQI
4
algorithm.
Algorithm 2: OSS(N) with FQI and CE search.
Input: policy inference(D) = tree-based FQI
p
FQI
, ;
score(µ) = Monte-Carlo evaluation of µ on a ;
set of representative initial states,;
sample(θ) = the generative model.;
CE param.: initial distrib. d on (X ×U)
N
, N
T S
, ρ
CE
. ;
repeat
T =
/
0 ;
for i = 1 to N
T S
do
θ
i
= draw a sampling scheme according to d ;
T T
{
θ
i
}
;
foreach sampling scheme θ
i
T do
D = sample(θ
i
) ;
µ
i
= policy inference(D) ;
M(θ
i
) = score(µ
i
);
S = sort
{
(θ,M(θ))
}
according to M(θ). ;
M
CE
= (1 ρ
CE
)-quantile of S. ;
S
0
= elements of T having scores above M
CE
. ;
d maximum likelihood distribution over S
0
.
until no more improvement in M
CE
;
θ
= draw a sampling scheme according to d ;
return policy inference(sample(θ
))
3
The deterministic optimization problem is transformed
into a rare event estimation problem, which is then tackled
using an adaptive density estimation algorithm.
4
For the sake of simplicity, we do not recall the details
on the tree-based FQI method and refer the interested reader
to (Ernst et al., 2005) for that purpose. The few parame-
ters this algorithm requires (number of iterations and tree-
related parameters) are generically denoted p
FQI
hereafter.
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
44
The algorithm starts with an initial distribution d
over the (X ×U)
N
search space. A family T of N
T S
small sample sets is drawn from d, and for each sam-
ple set, the optimal policy is computed and evaluated.
This provides a set S of (θ, M(θ)) pairs, ordered by in-
creasing value of M(θ). Then, according to the impor-
tance sampling method of CE-optimization, the ρ
CE
best θ values are selected out of the initial S set; this
provides the S
0
set and d is updated to fit the distribu-
tion of the sample vectors in S
0
.
In the particular case of continuous states and dis-
crete actions, we chose to represent d as a product
of Gaussian densities on the continuous X space (of
dimension d
X
), and Bernoulli distributions on the dis-
crete U space (of size d
U
). More specifically, d uses a
Gaussian model for each of the Nd
X
continuous vari-
ables of θ and a categorical distribution for each of the
Nd
U
actions (which boils down to a Bernoulli distri-
bution when there are only two actions). We made the
hypothesis that all continuous variables in θ were in-
dependent, hence the covariance matrix of the global
Gaussian distribution on X
N
is diagonal. Although
this hypothesis can seem too naive, it still provided
good results as Section 5 will illustrate.
The main advantage of such a simple distribu-
tion model over (X ×U)
N
is the simplicity of its up-
date phase. According to the importance sampling
foundations of CE optimization, each Gaussian and
Bernoulli model in d is updated to fit the maximum
likelihood distribution of its corresponding variable in
S
0
. Updating the Gaussian distributions on the contin-
uous variables of θ corresponds to finding the average
and the standard deviation for the associated variable
in S
0
. Similarly, updating the distributions over the
discrete variables (the actions) corresponds to com-
puting the new thresholds of the Bernoulli distribu-
tions, by counting the occurrences of each action in
S
0
.
Similarly, N
T S
(and ρ
CE
) should be chosen by
keeping in mind that ρ
CE
·N
T S
elements of S will be
kept in order to update the distribution d. Hence, these
ρ
CE
·N
T S
should be informative enough to approxi-
mate a sufficient statistics for the new value of d.
For domains where some previous information
(about reachability for instance) is available, the ini-
tial value of d can be designed to incorporate such
domain-specific, prior knowledge. Namely, in large
domains, random or ε-greedy initial walks can help
initialize d to non-zero values only in reachable re-
gions of the X ×U space.
The complexity of an iteration of the above
OSS(N) instance can be analyzed as follows. The
sampling phase is O(NN
T S
) and, since we train N
T S
p
u
0.2
0.2
0.4
1. .5 0.0 0.5 1.
Resistance
mg
Hill(p)
Figure 3: Car on the hill.
policies on sets of N samples with tree-based FQI
5
,
the policy training part is O(N
T S
N log(N)). Finally,
the density update phase is O(N
T S
N). So the over-
all time complexity of this OSS(N) algorithm is
O(N
T S
N log(N)).
5 EXPERIMENTS
5.1 Experimental Protocol
The “Car on the Hill” Domain. In order to il-
lustrate how the previous section’s OSS(N) method
performs in practice, and to visualize graphically
the sample set’s evolution in a two-dimensional state
space, we report optimization results on the “car on
the hill” domain. In this domain, an under-powered
car tries to reach the top of a hill, in order to escape
from a valley as illustrated on Figure 3. A positive re-
ward is gained when the car exits from the right hand
side of the domain. If the car goes too fast or exits
from the left-hand side, it receives a negative feed-
back. Otherwise, zero rewards are obtained.
The action space is composed of the two ±4N”
forces: U = {−4, 4}. The discrete-time dynamics are
obtained from the integration of the car’s law of mo-
tion, over time intervals of 0.1s. We chose to use a
γ factor of 0.95 as in (Ernst et al., 2005). With p the
horizontal position of the car, H(p) the hill’s equa-
tion, and g the gravitational constant, the continuous
time dynamics of the system are:
H(p) =
(
p
2
+ p if p < 0
p
1+5p
2
if p 0
¨p =
u gH
0
(p) ˙p
2
H
0
(p)H
00
(p)
1 + H
0
(p)
2
The state space of the system is spanned by the
two variables (p, ˙p) and is bounded: X = [1; 1] ×
[3;3]
{
x
}
. The additional state x
is an abstract
5
Which has time complexity of O(N log(N)).
OPTIMAL SAMPLE SELECTION FOR BATCH-MODE REINFORCEMENT LEARNING
45
absorbing state, entered only when the car’s dynamics
let it escape the domain’s bounds (either in speed or
position). The only non-zero rewards received in this
domain are for the transition to x
:
r(x
t
,u
t
) =
1 if p
t+1
> 1 and | ˙p
t+1
| 3
1 if p
t+1
< 1 or | ˙p
t+1
| > 3
0 otherwise
Initializing d. We initialized the distribution d by
using a regular paving with N Gaussian elements in
the state space and by drawing all actions at random
(Bernoulli distribution with a 0.5 threshold), as illus-
trated in Figure 5(a), in order to promote sample di-
versity. Note however that many other choices for the
initial d were possible, even the blind initialization of
all Gaussian distributions to the same value.
Choosing N, N
T S
and ρ
CE
. Recall that the first pur-
pose of OSS is to use batch-mode RL algorithms in
order to tackle large state-action spaces. We illustrate
its properties on small domains, in order to show one
can obtain optimal policies with small sample sets,
but the real use of OSS(N) for RL practitioners lies
in the case where the state-action space is too large to
be uniformly partitioned and where N is strongly con-
strained by the available computational resources. In
order to illustrate the ability of OSS to find efficient
policies with few samples, we report experimental re-
sults with N = 20. Note that similar results were ob-
tained with even lower values of N. We chose a value
of 500 for N
T S
with a ρ
CE
of 0.1.
Parameters of Tree-based FQI. Tree-based FQI
presents the advantage of requiring only few param-
eters to tune. In our case, each Q-function is rep-
resented with a mixture of 200 fully-developed ex-
tremely randomized trees and 30 iterations of FQI are
performed to obtain an estimate of the Q
function.
Scoring Function. We chose to evaluate a policy’s
quality by using a set of initial states corresponding
to different initial values of p and to a null initial ve-
locity. The policy’s score is the average of the ini-
tial states’ values, estimated by performing rollouts.
These initial states are seven regularly dispatched po-
sitions on the hill, with zero velocity (the small bullets
on the horizontal axis of Figures 5(a) to 5(i)).
5.2 Results
Figure 4 reports the evolution of the policy scores
throughout the algorithm’s iterations. The lowest
curve represents the evolution of the worse sample
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0 5 10 15 20 25 30 35 40
score
iteration
(a) M
min
, M
CE
and M
max
.
0.2
0.25
0.3
0.35
0.4
0.45
0.5
0 5 10 15 20 25 30 35 40
score
iteration
(b) M
CE
.
Figure 4: Evolution of the scores throughout the iterations.
set’s (among the set T ) value M
min
. The middle one is
the evolution of M
CE
and the top one corresponds to
the value M
max
of the best sample set of T . The most
significant result of this figure is the steady evolution
of the (1 ρ
CE
)-quantile M
CE
since both M
min
and
M
max
can be due to lucky outliers. As expected, all
three scores increase with the number of iterations,
with a larger variance for M
max
and M
min
. One can
note the steady increase of M
CE
towards the optimal
value for this domain (0.49).
An interesting property can be noted if one allows
for a slight modification of Algorithm 2. If, instead
of returning policy inference(sample(θ)) in the end,
one stores offline the best policy obtained at each it-
eration, then, because M
max
s high variance allows it
to reach some optimal values very early in the iter-
ations, a close-to-optimal policy can be found much
before M
CE
converges to the optimal score. This adds
very little overhead to the algorithm since it only re-
quires one disk writing operation per iteration and can
be beneficial in an anytime setting: the best policy
is stored on disk and always available for retrieval
if needed, and the probability of finding even better
policies increases with the iterations (until asymptotic
convergence of M
CE
).
Figure 5 reports the graphical evolution of the
Gaussian densities of d, describing where the crucial
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
46
samples concentrate in the state space. The triangles
in these figures represent the samples the distributions
are computed from. Hence, in a single figure, there
are ρ
CE
·N
T S
·N = 0.1 ·500 ·20 = 1000 samples. A
triangle oriented to the left (resp. right) stands for
a 4 (resp. +4) action. Since we chose the naive
model of uncorrelated variables, all the ellipses repre-
sented have their principal directions along the state
space’s axes. A richer covariance model might allow
for a better sample set description at the cost of a more
complex distribution parameter update phase.
The main conclusion one can draw from these re-
sults is that, by comparing the influence of different
sample sets on the optimal policy computed by FQI,
and by using a probability density-based optimiza-
tion method, we were able to identify a distribution
on the sampling scheme (Figure 5(i)) which induces
very good policies with as little as 20 samples. In
contrast, the original paper on tree-based FQI (Ernst
et al., 2005) suggests that, in average, it is necessary
to collect tens of thousands of samples via random
walk in the state space, before an optimal policy can
be found. The generalization of this experimental re-
sult indicates that instead of an ever-refining process
for the sample set, batch-mode RL algorithms can
take advantage of sample set optimization, through
OSS(N) algorithms, in order to reach optimal policies
with a low number of samples.
6 DISCUSSION
6.1 Time and Space Efficiency
When the state-action space’s dimension becomes
large, processing times for batch-mode RL algorithms
increase dramatically, since the sample complexity
of these algorithms is often worse than linear (e.g.,
O(Nlog(N)) for tree-based FQI). At a certain point,
it might become preferable to run N
T S
sample col-
lections and policy optimizations for small policies
based on sample sets of size N, than one large compu-
tation on the very large equivalent sample set of size
N
T S
·N (if this computation is at all possible). More
formally, this is supported by the complexity estimate
of Section 4, which illustrates an O(N
T S
N log(N))
time per OSS iteration which can be advantageously
compared to the O(N
T S
N log(N
T S
N)) time complex-
ity of applying tree-based FQI to the huge set of N
T S
N
samples (recall N
T S
is the large value here, N being
fixed to a small value by the user).
On the space complexity side, both approaches re-
quire O(N
T S
N) space to store the trees and the sample
sets. However, OSS can benefit easily from possible
disk storage since all the sample sets are used inde-
pendently and at different times. If one allows disk
storage, then the space complexity of OSS boils down
to O(N) since an iteration of OSS(N) only requires
keeping and processing one set of size N at once.
Furthermore, it is interesting to point out that com-
puting the score of a given θ is fully independent of
any other score computation. Hence OSS methods
can be easily adapted to a setting of distributed com-
putation on several small computers and can thus take
advantage of parallel architectures, distributing the
computational burden into small light-weight tasks.
6.2 Stochastic RL Algorithms
One of the possible caveat of using a forest of ex-
tremely randomized trees for the regressor in FQI is
related to the possible variance in the results and the
associated variance in policy quality. So far, all RL al-
gorithms are implicitly supposed to be deterministic,
ie. given a fixed sample set as input, they always out-
put the same result. This is not true for extremely ran-
domized trees. Their use in the general case of FQI is
still relevant because the variance in the results tends
to zero when the number of samples grows. But in
our case, since we voluntarily kept the samples num-
ber very low, we witnessed a very large variance in the
policies generated from a given set of 20 samples. To
avoid such a variance, a simple option is to increase
the number of trees in the forest, since the variance
also tends to zero with a large number of trees. Al-
though the 200 trees used per Q-function in the previ-
ous experiment were already a large forest compared
to the one reported in (Ernst et al., 2005) (which only
had 50 trees), we tried to run the OSS meta-algorithm
on FQI with even larger numbers of trees (up to 1000)
and observed the same behaviour as reported in Sec-
tion 5.2. Obviously, when using a non-deterministic
algorithm such as tree-based FQI, one cannot guar-
antee anymore that OSS will converge to a sample set
providing the optimal policy every time, but instead, it
will lead to a training set θ
that provides the optimal
policy with high probability. For the case where the
variance in the results tends to zero (with a very large
number of trees or with a deterministic algorithm such
as LSPI), then this probability should tend to one.
It is also interesting to note that variance in the al-
gorithm’s output policies might actually be desirable,
since it extends the set of policies which are “reach-
able” from an N-sized sample set. Then, by allowing
the storage of the best found policies along the way,
good policies can be found early in the search process
(as Figure 4 illustrates).
These experiments highlighted an interesting (un-
OPTIMAL SAMPLE SELECTION FOR BATCH-MODE REINFORCEMENT LEARNING
47
(a) Initial distribution. (b) Iteration 1. (c) Iteration 3.
(d) Iteration 5. (e) Iteration 11. (f) Iteration 16.
(g) Iteration 21. (h) Iteration 26. (i) Iteration 40.
Figure 5: Evolution of the distribution density with the iterations.
expected) property of variance reduction for OSS(20).
During the first iterations, if several policies are
trained from a given sample set, we observe a large
variance in the output
6
. However, as the iteration
number grows and the distribution d concentrates on
crucial samples, we observe both an increase in the
expected value of M(θ) and a strong reduction in the
output policy’s variance: at iteration 40, when one
trains several policies using a single sample set drawn
6
The statistical relevance of the S
0
set is still insured be-
cause the large number N
T S
of sample sets averages out this
variance for the update of d.
from d, those policies both perform much better and
are much closer to each other than the ones of itera-
tion 1 were.
6.3 Dealing with Stochastic Problems
Algorithm 2 can be applied to stochastic problems
without any change. However, the results need to be
interpreted slightly differently. In stochastic domains,
the equivalence between (x,u) and (x, u,r, x
0
) does not
hold anymore and, thus, one needs to emphasize the
difference between the sets θ and D. As stated in Sec-
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
48
tion 3, θ defines a sample collection scheme. Then,
finding the optimal θ consists in finding the sample
collection scheme that will lead to the best expected
policy, with respect to the transition model’s distribu-
tions.
Indeed, in Section 3, we did not focus explicitly
on the sample collection phase since a single θ al-
ways induced the same D set in the deterministic set-
ting. But, in the stochastic case, one cannot make use
of such a shortcut and one should note that we do not
compute µ
θ
anymore, but an optimal policy ˆµ
θ
for one
possible training set D, drawn according to θ, among
many others. This clarification raises the question of
sampling several D from θ to assess the true value of
M(θ). But, as for the variance reduction property of
the previous section, we argue one does not need to do
so and, instead, can rely on the large number of θ val-
ues drawn from d to average out the different possible
D sets. This question remains open nevertheless and
should be addressed in more detail in future research.
6.4 Related Work
In order to collect relevant sample sets for batch-mode
RL algorithms, the naive approach of uniform grid
sampling across the state-action space does not scale
to high-dimensional domains since the RL algorithms
become very slow (if able at all) at processing this ex-
ponentially increasing amount of data. We mentioned
earlier the domain-specific approaches of (Neumann
and Peters, 2009; Riedmiller, 2005; Ernst et al., 2006;
Kalyanakrishnan and Stone, 2007). In the latter, the
authors alternate a policy computation and a sample
gathering phase, where the sample gathering is a care-
fully tuned ε-greedy exploration, with respect to the
last computed policy, regularly reset to the start state.
All the discovered samples are then added to the sam-
ple set and the optimal policy is recomputed. Such
data collection schemes rely on Monte-Carlo explo-
ration methods and present similarities with online-
RL approaches, which provide reachability guaran-
tees while incrementally extending the sample set.
In general, these methods suffer from two defaults,
which come in contrast with the OSS approach:
They often require a lot of domain specific hand-
tuning to be efficient.
They keep on enriching the sample set, letting it
grow up to a point where its size becomes again
problematic for the batch-mode RL method.
The work of (Ernst, 2005) presents a method to select
concise sets of samples for the same tree-based FQI
algorithm than the present work. But their goal and
approach was very different: instead of searching for
the best possible fixed-size set of samples, they started
with a very large constrained sample set and tried to
extract a subset that would still provide policies with
good performances, without requiring any extra sam-
pling from a generative model. They based their ap-
proach on a Bellman error criterion and illustrated a
pathological case where the subset found critically
concentrates samples around Q-function discontinu-
ities. It is also interesting to note that the reported
original motivation of their paper confirms ours: their
goal being to “lighten the computational burden of
running the fitted Q-iteration algorithm on the whole
set of four-tuples”.
Finally, Cross Entropy methods, such as the one
used in our experiment, have been quite widely used
in recent years in the RL literature, for instance for
the task of refining policies for Tetris (Szita and
L
¨
orincz, 2006), or for adapting feature functions for
linear architectures (Menache et al., 2005), or to opti-
mize fuzzy state space partitions for fuzzy Q-iteration
(Bus¸oniu et al., 2008). An interesting parallel can be
made between the latter approach and the present one:
they define fuzzy partitions for the value function, im-
plicitly identifying specific areas in the X ×U space,
similar to the areas of interest defined for samples by
our density-based optimization method. Although CE
search is not an imperative choice for OSS (other op-
timization methods are available), it seems to be well
suited to handle the large dimensional, gradient-less
optimization problems that arise in RL.
7 CONCLUSIONS
We introduced the Optimal Sample Selection meta-
algorithm, in order to generate optimal policies for
large sequential control problems. This approach con-
sists in looking directly for a set of training exam-
ples that given a batch-mode RL algorithm
will induce an optimal policy for the domain at hand.
More specifically, an OSS(N) algorithm takes as in-
put a generative model, a batch-mode RL algorithm,
an evaluation procedure, then defines the search for
an optimal set of N training examples as an optimiza-
tion problem, and finally solves it using a stochastic
optimization method. The instance of OSS we tested
uses tree-based fitted Q-iteration as the batch-mode
RL algorithm, evaluates a policy by generating trajec-
tories to compute its average return over a set of ini-
tial states and optimizes the sample set by using Cross
Entropy search. We studied this instance’s properties
under various simulation conditions. One remarkable
property of OSS(N) is that a very small set of 20 care-
fully chosen samples was sufficient to generate a near-
OPTIMAL SAMPLE SELECTION FOR BATCH-MODE REINFORCEMENT LEARNING
49
optimal policy.
Based on these results and on other experiments
not reported in this paper, we conjecture that for
many Optimal Control problems, there exist sam-
ple sets of “acceptable size” which can lead to near-
optimal policies when used as input of batch-mode
RL algorithms and that finding these sets is compu-
tationally feasible. This leads us to believe that this
OSS meta-algorithm may perform well, where other
sampling/discretization-based resolution schemes in
Optimal Control fail, due to limitations in the size of
the sample sets that can be manipulated in a reason-
able time by a computer.
ACKNOWLEDGEMENTS
Emmanuel Rachelson acknowledges the support of
the Belgian Network DYSCO, IAP Programme.
Franc¸ois Schnitzler is supported by FRIA. Damien
Ernst is a research associate of the FRS-FNRS. The
scientific responsibility rests with the authors.
REFERENCES
Bertsekas, D. P. and Shreve, S. E. (1996). Stochastic Opti-
mal Control: The Discrete-Time Case. Athena Scien-
tific.
Boyan, J. (1999). Least-squares temporal difference learn-
ing. In Int. Conf. Machine Learning, pages 49–56.
Bus¸oniu, L., Babu
ˇ
ska, R., Schutter, B. D., and Ernst, D.
(2010). Reinforcement Learning and Dynamic Pro-
gramming using Function Approximators. Taylor &
Francis.
Bus¸oniu, L., Ernst, D., Schutter, B. D., and Babu
ˇ
ska, R.
(2008). Fuzzy partition optimization for approximate
fuzzy Q-iteration. In IFAC World Congress.
Ernst, D. (2005). Selecting concise sets of samples for a re-
inforcement learning agent. In Int. Conf. on Compu-
tational Intelligence, Robotics and Autonomous Sys-
tems.
Ernst, D., Geurts, P., and Wehenkel, L. (2005). Tree-based
batch mode reinforcement learning. Journal of Ma-
chine Learning Research, 6:503–556.
Ernst, D., Stan, G. B., Goncalves, J., and Wehenkel, L.
(2006). Clinical data based optimal STI strategies
for HIV: a reinforcement learning approach. In IEEE
Conference on Decision and Control.
Kalyanakrishnan, S. and Stone, P. (2007). Batch reinforce-
ment learning in a complex domain. In AAMAS, pages
650–657.
Kroese, D. P., Rubinstein, R. Y., and Porotsky, S. (2006).
The cross-entropy method for continuous multiex-
tremal optimization. Meth. and Comp. in App. Prob.,
8:383–407.
Lagoudakis, M. and Parr, R. (2003a). Least-squares pol-
icy iteration. Journal of Machine Learning Research,
4:1107–1149.
Lagoudakis, M. G. and Parr, R. (2003b). Reinforcement
learning as classification: Leveraging modern classi-
fiers. In 20th Int. Conf. on Machine Learning, pages
424–431.
Menache, A., Mannor, S., and Shimkin, N. (2005). Ba-
sis function adaptation in temporal difference rein-
forcement learning. Annals of Operations Research,
134(1):215–238.
Neumann, G. and Peters, J. (2009). Fitted Q-iteration by
advantage weighted regression. In Neural Information
Processing Systems.
Ormoneit, D. and Sen, S. (2002). Kernel-based reinforce-
ment learning. Machine Learning Journal, 49:161–
178.
Riedmiller, M. (2005). Neural fitted Q-iteration - first ex-
periences with a data efficient neural reinforcement
learning method. In 16th European Conference on
Machine Learning, pages 317–328.
Rubinstein, R. Y. and Kroese, D. P. (2004). The Cross-
Entropy Method: a Unified Approach to Monte Carlo
Simulation, Randomized Optimization and Machine
Learning. Springer Verlag.
Sutton, R. S. and Barto, A. G. (1998). Reinforcement Learn-
ing: An Introduction. The MIT Press, Cambridge.
Szita, I. and L
¨
orincz, A. (2006). Learning tetris using the
noisy cross-entropy method. Neural Computation,
18(12):2936–2941.
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
50
