MODELLING A BACKGROUND FOR BACKGROUND
SUBTRACTION FROM A SEQUENCE OF IMAGES
Formulation of Probability Distribution of Pixel Positions
Suil Son, Young-Woon Cha and Suk I. Yoo
School of Computer Science and Engineering, Seoul National University, 599 Gwanak-ro, Seoul, Korea
Keywords: Background subtraction, Foreground detection, Probability distribution of pixel positions, Intensity clusters,
Kernel density estimation.
Abstract: This paper presents a new background subtraction approach to identifying the various changes of objects in
a sequence of images. A background is modelled as the probability distribution of pixel positions given
intensity clusters, which is constructed from a given sequence of images. Each pixel position in a new image
is then identified with either a background or a foreground, depending on its value from probability
distribution of pixel positions representing a background. The presented approach is illustrated using two
examples. As compared to traditional intensity-based approaches, this approach is shown to be robust to
dynamic textures and various changes of illumination.
1 INTRODUCTION
Detecting a meaningful foreground from a sequence
of images, known as background subtraction, has
been studied intensively due to its wide area of
application such as tracking, identification and
surveillance. Two issues in developing background
subtraction methods are how to resolve the change
of illumination due to noise or light and how to
manage dynamic textures such as swaying tree or
flow of water.
To manage the change of illumination, most of
background subtraction methods have used intensity
distributions (Wren, Darrelll and Pentland, 1997,
Stauffer and Grimson, 1999, Elgammal, Harwood,
and Davis, 2000, Power and Schoonees, 2002,
Zivkovic and Heijden, 2006, Dalley, Migdal, and
Grimson, 2008). Using intensity distributions,
however, does not work very well when there is the
large change of illumination in all pixels on the
image. To resolve dynamic textures, a mixture of
Gaussian (Stauffer and Grimson, 1999, Power and
Schoonees, 2002, Zivkovic and Heijden, 2006,
Dalley et al, 2008) and the kernel density estimation
(Elgammal et al, 2000, Mittal and Paragios, 2004)
have been suggested. To recognize the background
having small motion correctly, spatial information of
objects is necessary. A window formed with
neighbours of a pixel may be used to reflect such
spatial information (Elgammal et al, 2000, Dalley et
al, 2008). Although the approach using windows
reduces false detection of foreground for dynamic
textures, it is not easy to define the exact size of a
window in advance. Sheikh and Shah (2005)
suggested joint distribution of positions and
intensities to reflect the spatial information. Since
this joint representation of image pixels reflects the
local spatial structure, it works well on motion of
background objects. However, it has a difficulty
with the curse of dimensionality from its high
dimensional data representation.
This paper presents a new approach to relaxing
those difficulties of the traditional background
subtraction methods: A background is modelled as
the probability distribution of pixel positions given
intensity clusters. An image in a given sequence is
assumed to have M intensity sources. From the
image having M intensity sources, M intesity
clusters can be formulated. Although it is not easy to
figure out the optimal number of M from a given
image, specially when the image is complex with
various objects, the value of M is assumed to be not
larger than six in general due to the range of grey
level from 0 to 255.
For each of the M intensity clusters, the distribu-
tion of pixel positions is then computed from the
sequence of images. The computed distribution of
545
Son S., Cha Y. and Yoo S..
MODELLING A BACKGROUND FOR BACKGROUND SUBTRACTION FROM A SEQUENCE OF IMAGES - Formulation of Probability Distribution of
Pixel Positions.
DOI: 10.5220/0003141105450551
In Proceedings of the 3rd International Conference on Agents and Artificial Intelligence (ICAART-2011), pages 545-551
ISBN: 978-989-8425-40-9
Copyright
c
2011 SCITEPRESS (Science and Technology Publications, Lda.)
pixel positions, however, suffers from the disconti-
nuity between pixels due to the limited number of
images in the sequence. By smoothing this disconti-
nuity using kernel density estimation, the probability
distribution of pixel positions modelling a back-
ground is finally constructed. Each pixel position in
the new image is then identified with either a
foreground or a background, depending on its value
from the probability distribution constructed.
In the following section related previous works
are visited. In section 3, generation of a probability
distribution of pixel positions given intensity
clusters from a sequence of images is described. The
process to identify each pixel position in a new
image with either a background or a foreground is
explained in section 4. Finally the presented
approach is illustrated and compared to the intensity-
based approach in section 5.
2 RELATED WORKS
Most of traditional background subtraction models
estimate intensity distributions for each pixel
position (Paccardi, 2004).
Stauffer and Grimson (1999) have modelled the
value of each pixel as a mixture of M Gaussian
distributions in order to represent intensity variations
caused by small motion of objects in the background
like swaying trees or flow of water. The probability
that a pixel position x has an intensity x
t
at time t is
estimated as
1
1
1
22
1
()()
2
1
()
(2 ) | |
T
tj jtj
j
d
j
M
j
xx
t
w
P
xe

(1)
where w
j
is the weight for each Gaussian distribution,
μ
j
is the mean and Σ
j
=σ
2
I is the covariance of the jth
Gaussian distribution, and M is the number of
Gaussians. The M is selected from 3 to 5. This
model assumes that the intensity value may result
from some candidate sources each of which is
modelled as a Gaussian. Therefore, an intensity
value has several distributions where it may come
from. This model can adapt to small change of
intensity or shape in background but in the case
where the background has slightly large variations, it
fails to achieve correct identification.
Dalley et al. (2008) have proposed a model
modified from the Stauffer and Grimson(1999)’s
one. In this model, a set of mixture components that
lie at the local spatial neighbourhood of a pixel are
suggested rather a mixture that lies at the same pixel.
The probability that a pixel position i has an
intensity c
i
is estimated as
()
() (| , )
j
j Neighbour
iijj
i
P wNcc
(2)
where μ
j
is the mean, Σ
j
is the covariance of
Gaussian distribution N at a pixel position j, and w
j
is a mixture weight of a neighbour j. This model
considers intensity distributions at neighbours of a
pixel simultaneously. Therefore, intensity variations
caused by small motion of objects in background
can be correctly identified with a background.
However, the background subtraction result of this
model is dependent on the size of a window applied
to include neighbours but the optimal window size is
hardly obtained.
Elgammal et al (2000) suggested the kernel
density estimation to model intensity distribution
with multimodality. When there are n samples of
intensities, the true distribution of these intensities
may be dense where the samples are closely located
and may be sparse where the samples are scattered.
These characteristics are modelled as a sum of many
kernels centred at each sample. Since this model is a
data driven approach, the multimodality of
distribution for these data is naturally reflected
without any assumption of the number of modes.
This model for intensity distribution of a pixel can
be represented as follows
1
1
() ( )K
n
i
tti
P
n
x
xx
(3)
where x
t
and x
i
are intensities of a pixel x at time t
and i ,respectively, n is the number of samples, and
K is a kernel function. The Gaussian function is
usually used for the kernel function K. This model
can handle situations where the background of
scenes contains small motion but it still suffers from
large motion and illumination changes. To overcome
this difficulty, this model proposed additional policy
considering the displacement probability P
Neighbour
.
()
() max ( | )
Neighbour
y Neighbour x
ytt
PPBxx
(4)
where B
y
is a background sample for a pixel y. This
approach significantly reduced false detection of a
background but it still has a difficulty in selecting
optimal neighbours.
All approaches discussed above are same in
considering distribution of intensities for a given
pixel position. In this framework, motion of objects
in background was modelled as variations of
intensities and neighbours of a pixel are introduced
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
546
to reflect more spatial variations. These approaches
may be regarded as an indirect approach to handle
spatial variations. In this paper, we model spatial
variations directly using distribution of pixel
positions given intensity values.
3 MODELLING A BACKGROUND
In this section we first describe how to generate M
intensity clusters from a given image and then
construct from a sequence of images the probability
distribution of pixel positions for each of M intensity
clusters modelling a background.
3.1 Generation of M Intensity Clusters
When a given image has M intensity sources with
background, it is assumed that the image can be
characterized with M different intensity clusters. The
k-means algorithm (Bishop, 2006) is then used to
generate the M intensity clusters:
Let μ
i
be a mean of intensity values of those
pixels forming the i
th cluster C
i
where i=1, …, M.
and let I
xy
be an intensity value of a pixel at location
(x,y) of the image I with height of H and width of W.
The k-means algorithm defines the membership
value r
xyi
of the intensity value I
xy
with respect to the
cluster C
i
where x=1,2,…,W and y=1,2,…,H, to be
2
1, argmin| |
0,
x
yj
j
xyi
if i I
r
otherwise

(5)
where j=1,2,…,M.
The value of μ
i
is initially set to a small value
and the r
xyi
is computed by (5). With the computed
value of r
xyi
, the μ
i
is then updated by (6). This
process is repeated until there is no change in the
values of μ
i
and r
xyi
. The value of r
xyi
indicates
whether or not the pixel at (x,y) is associated with
the cluster C
i
.
11
11
HW
HW
x
yi xy
yx
i
x
yi
yx
rI
r




(6)
For example, the image with two objects,
rectangle and circle, is characterized with three
intensity clusters as shown in Fig. 1.
(a) (b)
(c) (d)
Figure 1: Three intensity clusters, (b), (c), and (d), shown
as white areas, from a given image of (a).
3.2 Probability Distribution of Pixel
Positions for Intensity Clusters
When M intensity clusters are generated from one
image, the same number of clusters can be generated
from each of images in a sequence. Once we obtain
the same number of clusters from all images in the
sequence, we can count the number of occurrence of
each pixel position with respect to each of the M
clusters. The occurrence of pixel positions for a
given cluster may then represent statistical data for
the intensity value associated with that cluster.
Let
l
be the lth image, l=1,2,…,N, from a
sequence of N images. The histogram h
N
(x,y;C
i
),
defined to be the number of times from the N images
that each position (x,y) is located in the cluster C
i
, is
then
( , ; ) | { : 1, 1, 2,..., } |
l
N xyi
i
hxyC lr l N
(7)
where
l
x
yi
r
is the value of
x
yi
r
in the lth image
l
I
.
Since each pixel considered as a background in a
new image has its intensity value similar to those of
the associated pixels in all of the N images in a
sequence, its h value becomes large for one of M
clusters. Each pixel considered as a foreground,
however, has its intensity value different from those
of the associated pixels in all the N images so that its
h value becomes small for the associated cluster. A
foreground comes from an unusual event and objects
formed with those pixels considered as foregrounds
may be observed in a few of the N images.
MODELLING A BACKGROUND FOR BACKGROUND SUBTRACTION FROM A SEQUENCE OF IMAGES -
Formulation of Probability Distribution of Pixel Positions
547
(a)
(b-1) (b-2)
(c-1)
(c-2)
(d-1)
(d-2)
Figure 2: Histograms and Probability distributions of
positions for each intensity cluster constructed from for a
sequence of 30 images of (a): (b-1) h
N
(x,y;C
1
), (b-2)
P(x,y|C
1
), (c-1) h
N
(x,y;C
2
), (c-2) P(x,y|C
2
), (d-1) h
N
(x,y;C
3
),
and (d-2) P(x,y|C
3
).
Since the histogram reflects the direct result from
a given sequence of images, it suffers from its
discontinuity for small motion of objects due to the
limited number of images in the sequence. To
overcome such difficulty, the kernel density estima-
tion is suggested to smooth the discontinuity.
The kernel density estimation (KDE) is one of
well-known nonparametric density estimation
methods (Elgammal et al, 2000, Bishop 2006). The
KDE has many kernels centred at each data point so
as to construct a probability distribution of the data.
The KDE has the property to relax discontinuity of
data and make smooth change between data. Thus
we propose a kernel density estimation weighted by
the histogram to obtain the smooth and continuous
distribution of pixel positions.
When there is a histogram h
N
(x,y;C
i
) of an
intensity cluster C
i
, the position distribution for the
cluster C
i
, P(x,y|C
i
), is given by the following kernel
density estimation.
11
11
(, | )
(, ) ( , )
(, )
;
;
K
HW
N
HW
N
pq
pq
i
qpi q p
qpi
Pxy C
hxy xxy y
hxy
C
C





(8)
where K is a two dimensional kernel function. The
Gaussian kernel is usually used for the kernel
function as follows:


22
2
2
1
2
11
(,) exp
2
2
uv u v
b
b
K
(9)
where b is a bandwidth of the kernel function.
As one example, suppose that a sequence of 30
images shown in Fig. 2 (a) is given where each
image has three intensity sources. Three intensity
clusters can then be generated. For each of three
intensity clusters, the histogram and the associated
probability distribution of pixel positions are
computed as shown in Fig. 2 (b-1), (b-2), (c-1), (c-2),
(d-1), and (d-2). As compared to each of histograms,
the associated probability distribution is smoother
and normalized.
4 DETECTING A FOREGROUND
Once the pixel position distribution for each of
intensity clusters is constructed, the identification of
each pixel position in a new image as a background
or a foreground is achieved by labelling it as
follows:
Let the new image be I
N+1
. The
1N
x
yi
r
, the cluster
membership value for I
N+1
, is computed using the
k-means algorithm described in section 2. Each pixel
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
548
position (x,y) on the I
N+1
is then labelled with L(x,y)
defined to be

1
1
(, ) (, | )
N
M
Txyi
i
i
Lxy f Pxy C r

(10)
(a) (b)
Figure 3: (a) A given new image and (b) a detected
foreground shown as a white area.
where f
T
is a threshold function given by
1,
()
0,
T
if z T
fz
otherwise
(11)
with a predefined value T.
Suppose that a given pixel position (x,y) on the
new image I
N+1
is one of them forming the jth
intensity cluster. Then the value of
1N
x
yi
r
becomes 1
only when i=j. If its value from
P(x,y|C
j
) is less than
T, then it is detected as a foreground. Otherwise, it is
a background.
For example, given a sequence of thirty images
in Fig. 2 (a), if a new image in Fig. 3 (a) is given,
those pixels forming triangle shown in Fig. 3 (b) are
detected as a foreground.
5 EXAMPLES
Our approach is illustrated using two examples
having dynamic textures and large change of
illumination, respectively. It is also compared to the
intensity-based approach using KDE (IBA-KDE)
(Elgammal et al, 2000) and to the intensity-based
approach using Gaussian Mixture Model (IBA-
GMM) (Dalley et al, 2008).
As the first example having dynamic textures, a
sequence of 30 images shown in Fig. 4 and four new
images shown in Fig. 5 are assumed. From each
image in the sequence where four intensity sources
are assumed, four intensity clusters are generated.
For each of the four intensity clusters, the proba-
bility distribution of pixel positions is then computed
from 30 images in the sequence.
Figure 4: A sequence of 30 images.
(a)
(b)
(c)
(d)
Figure 5: Four new images with different shapes of a
walking man.
(a-1)
(a-2)
(a-3)
(b-1)
(b-2)
(b-3)
(c-1)
(c-2)
(c-3)
(d-1)
(d-2)
(d-3)
Figure 6: Results from images in Fig. 5 by ours, IBA-KDE,
and IBA-GMM.
From the first new image in Fig. 5(a), the result by
our approach is shown in Fig. 6(a-1), the result by
the IBA-KDE is in Fig. 6(a-2), and the result by the
MODELLING A BACKGROUND FOR BACKGROUND SUBTRACTION FROM A SEQUENCE OF IMAGES -
Formulation of Probability Distribution of Pixel Positions
549
(a)
(b)
(c)
(d)
(e)
Figure 7: Five new images with different illumination.
(a-1)
(b-1)
(c-1)
(d-1)
(e-1)
(a-2)
(b-2)
(c-2)
(d-2)
(e-2)
(a-3)
(b-3)
(c-3)
(d-3)
(e-3)
Figure 8: Results from images in Fig. 7 by ours, IBA-KDE, and IBA-GMM.
IBA-GMM is in Fig. 6(a-3). Similarly, from the next
three new images in Fig. 5(b), 5(c), 5(d), the result
by ours is in Fig. 6(b-1), 6(c-1), 6(d-1), the result by
the IBA-KDE in Fig. 6(b-2), 6(c-2), 6(d-2), and the
result by the IBA-GMM in Fig. 6(b-3), 6(c-3), 6(d-
3). As noticed by comparing three results in Fig. 6,
our approach detected the foreground successfully
but the IBA-KDE and the IBA-GMM did not.
As the second example having large change of
illumination, a sequence of 30 images in Fig. 4 and
five new images in Fig. 7 are assumed. All of the
five new images represent the same scene with
different illumination where the image in (a) is an
original image and others in (b), (c), (d), and (e) are
modified in their intensities with +10, +30, -10, and
-30, respectively. The same probability distribution
of pixel positions computed in the first example is
then used for detecting a foreground from the five
new images.
From Fig. 7(a), the result by ours is in Fig. 8(a-1),
the result by the IBA-KDE is in Fig. 8(a-2), and the
result by the IBA-GMM is in Fig. 8(a-3). Similarly,
from Fig. 7(b), 7(c), 7(d), 7(e), the result by ours is
in Fig. 8(b-1), 8(c-1), 8(d-1), 8(e-1), the result by
IBA-KDE in Fig. 8(b-2), 8(c-2), 8(d-2), and the
result by the IBA-GMM in Fig. 8(b-3), 8(c-3), 8(d-
3), 8(e-3). As shown in Fig. 8, our approach detected
a foreground successfully from four of the five
images except (c) with a little false detection.
However, both of the IBA-KDE and the IBA-GMM
failed to detect a foreground from each of (c) and (e).
Further the IBA-GMM results in false detection
from both of (b) and (d).
From these two examples, our approach is shown
to be robust to dynamic textures and also large
change of illumination as compared to the IBA-KDE
and the IBA-GMM.
Finally, the results from using five different
values of threshold with four different numbers of
clusters are shown in Fig. 9 where as the number of
clusters gets larger, the smaller value of threshold
becomes more appropriate. Note however that the
number of clusters is closely related to the number
of intensity sources in the given image.
6 CONCLUSIONS
For modelling a background from a sequence of
images, we presented the probability distribution of
pixel positions for intensity clusters. To detect a
foreground from a given new image, probability of
each pixel position is obtained from the probability
ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence
550
M=3
M=4
M=5
M=6
T=0.00000025 T=0.0000005 T=0.000001 T=0.000002 T=0.000004
Figure 9: Results from an image in Fig. 7-(a) using different values of threshold with different numbers of clusters.
distribution. If it is less than some predefined
threshold, it is detected as a foreground. Otherwise,
it is a background. Our approach is illustrated to be
not to suffer from dynamic textures and large change
of illumination, as compared to the intensity-based
approaches. Finally the work to find the general
formula to find the optimal number of intensity
sources from a given image is left as the future work.
ACKNOWLEDGEMENTS
The ICT at Seoul National University provides
research facilities for this study.
REFERENCES
Bishop, C. M., 2006, Pattern recognition and machine
learning, Springer, 1
st
edition.
Dalley, G., Migdal, J., and Grimson, W. E. L., 2008,
Background subtraction for temporally irregular
dynamic textures, IEEE Workshop on Applications of
Computer Vision.
Elgammal, A., Harwood, D., and Davis L., 2000, Non-
parametric model for background subtraction,
European Conference on Computer Vision.
Mittal, A., and Paragios, N., 2004, Motion-based
background subtraction using adaptive kernel density
estimation, IEEE Computer Vision and Pattern
Recognition.
Piccardi, M., 2004, Background subtraction techniques: a
review, IEEE International Conference on Systems,
Man and Cybernetics.
Power, P. W., and Schoonees, J. A., 2002, Understanding
background mixture models for foreground
segmentation, Proceedings Image and Vision
Computing New Zealand.
Sheikh, Y., and Shah, M., 2005, Bayesian modelling of
dynamic scenes for objects detection, IEEE
Transaction on Pattern Analysis and Machine
Intelligence.
Stauffer, C., Grimson, W. E. L., 1999, Adaptive
background mixture models for real-time tracking,
IEEE Computer Vision and Pattern Recognition.
Wren, C., Azarbayejani, A. Darrel, T., and Pentland, A. P.,
1997, Pfinder: real-time tracking of the human body,
IEEE Transaction on Pattern Analysis and Machine
Intelligence.
Zivkovic, Z., and Heijden, F. V. D., 2006, Efficient
adaptive density estimation per image pixel for the
task of background subtraction, Pattern Recognition
Letters.
MODELLING A BACKGROUND FOR BACKGROUND SUBTRACTION FROM A SEQUENCE OF IMAGES -
Formulation of Probability Distribution of Pixel Positions
551
