CULTIVATING CLOUD COMPUTING

A Performance Evaluation of Virtual Image Propagation & I/O Paravirtualization

Django Armstrong and Karim Djemame

School of Computing, The University of Leeds, Leeds, U.K.

Keywords:

Cloud computing, Performance evaluation, Image propagation, Paravirtualization.

Abstract:

Cloud Computing continues to be a rapidly evolving and prevalent paradigm where Quality of Service has a

pivotal role to play in guaranteeing performance and provisioning of resources on-demand in a timely fashion.

Improvements to the performance of Cloud technology ensure provider proﬁtability and an increased number

of applications that can make use of a Cloud where overheads would have otherwise limited usage. This

paper presents the results of a quantitative evaluation into the performance overheads of propagating Virtual

Machine images to physical resources, at the Infrastructure as a Service layer and then accessing the images,

via a Hypervisor’s virtual block I/O device. Two Virtual Infrastructure Managers are evaluated: Nimbus and

OpenNebula, along side two Virtual Machine Managers: XEN and KVM. Benchmark results demonstrate

Nimbus out of the box outperforming OpenNebula and the performance of XEN exceeding KVM in a greater

number of benchmark tests. Conclusions are drawn from the results on the suitability of these technologies

for data intensive applications and applications requiring highly dynamic resource sets, where making an

uninformed decision on what technology to use could prevent an application reaching its full potential.

1 INTRODUCTION

The prevalence of Cloud Computing as a distributed

paradigm that can deliver economic, automation and

ﬂexibility beneﬁts far beyond more traditional IT in-

frastructure has and continues to thrust Cloud services

into the lime light. Infrastructure as a Service (IaaS)

providers play a pivotal role in the Quality of Service

(QoS) provisioned in the majority of Cloud architec-

tures comprised of an interchangeable multilayer soft-

ware stack (Vouk, 2008). Virtualization, as the fun-

damental resource building block of IaaS, is critical

to maintaining acceptable levels of performance to

prevent breaches in Service Level Agreements (SLA)

and thus increasing the overall proﬁtability of a Cloud

(Xiong and Perros, 2009). This provides primary mo-

tivation for efﬁcient Hypervisor design and remains

a limiting factor in what applications are deployable

and can take full advantage of a Cloud. Although

research on the topic of Virtualization is not new, it

has seen a resurgence of interest in recent years in

the problem domain of Cloud Computing (Jun Zhu

et al., 2010; Imada et al., 2009; Xu et al., 2009). One

such area of interest is Virtual Machine (VM) lifecy-

cle management (Hansen and Jul, 2010; Goiri et al.,

2009), where guarantees that a VM will be on-line

within a certain timeframe are of importance to the

rate at which IaaS can react to changes in demand

(Van et al., 2009). Another area of interst is VM

I/O (Kesavan et al., 2010), which can have adverse

affects on application performance (Dong-Jae Kang

et al., 2008).

E: vm_shutdown

Terminated

Executing

E: image_transferred

image_transferred

vm_stopped

Figure 1: Simpliﬁed life cycle states of a non persistent VM.

In the life cycle of a VM managed by an IaaS,

overhead is associated with transitions of state illus-

trated in Figure 1. IaaS requires time to provision

resources, transfer data and conﬁrm termination. A

trade off exists where at some point reducing these

overheads incurs a penalty associated with polling

and the contention of resources. In this paper, we fo-

cus on analyzing both the overheads of resource ac-

quisition and data access, i.e. propagation of non-

persistent VM images to physical resources and the

use of paravirtualized I/O device drivers to access the

539

Armstrong D. and Djemame K..

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O Paravirtualization.

DOI: 10.5220/0003388305390550

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 539-550

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

data held within an image after propagation. The aim

of our work is to expose the limitation of Cloud tech-

nologies through performance evaluation with results

that provide insight into the rapidly evolving land-

scape of Cloud tools in the context of commodity

hardware.

We compare via benchmarking two Cloud infras-

tructure managers Nimbus: (Kate Keahey et al., 2007)

and OpenNebula (Sotomayor et al., 2009), along-

side the two latest versions of each of the open

source Hypervisors: XEN (Barham et al., 2003) and

KVM (KVM, 2010), using a combination of synthetic

benchmarks. We ﬁnd that Nimbus can boast a reduced

overhead, compared to OpenNebula, when initializ-

ing and terminating VMs and that the additional sup-

port of a Grid transfer protocol in Nimbus can reduce

transfer times by 46%. In addition, we ﬁnd that KVM

guests perform poorly in contrast to XEN in most

benchmark tests regarding the write performance to

a VM image but this has been partially rectiﬁed in a

new release of KVM.

We argue that previous work on the subject of hy-

pervisor I/O performance is now outdated due to the

pace of development surrounding paravirtualized de-

vice drivers. We infer that overheads have the poten-

tial to inﬂuence Cloud performance and thus the us-

age patterns of IaaS providers. If predominant Cloud

technology is not chosen wisely, it can prevent data

intensive applications from reaching their full poten-

tial and applications that require highly dynamic re-

source sets from scaling efﬁciently. We draw the con-

clusion that reducing overheads could lead to an in-

crease in the pace of Cloud adoption. A reduction

in resource acquisition waiting times enables quicker

reaction, by an IaaS, to a changing environment and

reduces operating costs via a similar reduction in the

number of virtual resources needed to be provisioned

for a given quantity of concurrent client requests.

The remainder of the paper has the following

structure. Section 2 and 3 outline the Cloud infras-

tructure managers Nimbus and OpenNebula, and the

Hypervisors XEN and KVM, respectively. Section

4 describes the experimental environment. Section 5

presents and evaluates experimental ﬁndings. Section

6 reviews the contributions of the paper and critiques

related work. Finally, Section 7 presents the conclu-

sion of the paper and future work.

2 VIRTUAL INFRASTRUCTURE

MANAGEMENT

An electrical utility provider needs a system in place

to provision and monitor resources to ensure ser-

vice reliability and performance, keeping pace with

changes in demand so that consumer usage patterns

and high resource contention do not adversely affect

the QoS provided. Cloud IaaS providers are no differ-

ent in that they use Virtual Infrastructure Managers

(VIM). Virtual resources need to be brought on and

off-line as required and monitored to assess status so

that intelligent decisions can be made on how best

to use the underlying physical resources for the busi-

ness objectives of an IaaS provider. VIMs achieve this

through a scheduling component that assigns VMs to

physical resources with feedback gathered from mon-

itoring services for both the physical and virtual in-

frastructure. A scheduling component orchestrates

with others in the system to: i) assess the needs of a

VM, ii) provision a suitable physical resource and iii)

transfer a VM image from a central repository over

the network via an available network protocol. Once

transferred a Hypervisor adapter component is used to

execute the VM image on the physical host machine

and bring the virtual resource on-line.

2.1 OpenNebula & Nimbus

OpenNebula (Sotomayor et al., 2009) is an imple-

mentation of the research being performed and led

by Reservoir (Rochwerger et al., 2009), a European

Union FP7 funded research initiative in virtualized in-

frastructure and Cloud computing. It can be used as

a Virtualization tool for the manipulation of local vir-

tual infrastructure within datacenter clusters for the

creation of private Clouds. Public Cloud support, via

a selection of management interfaces, exposes func-

tionality of a remote provider’s VM, storage and net-

work resources using de facto standards through a lo-

cally accessible portal. Hybrid Clouds, made possible

through the combination of public resources and local

virtual infrastructure, enable highly scalable applica-

tion hosting environments. The design of OpenNeb-

ula efﬁciently manages multiple types of workloads

with emphasis placed on addressing business require-

ments and use cases. A black box approach to design

facilitates the homogeneous management of VM Op-

erating Systems (OS) and services.

Nimbus (Kate Keahey et al., 2007) builds on past

research into Grids by reusing many of the standards

and technologies invented by the Grid community,

particularly those used in the Globus Toolkit. It pro-

vides an upgrade path to the Cloud for organizations

using Grids. This is enabled via the features of Nim-

bus that make use of Grid resources and its integra-

tion with familiar resource schedulers, such as PBS,

to schedule VMs. Development of Nimbus has placed

emphasis on use cases applicable to the needs of the

CLOSER 2011 - International Conference on Cloud Computing and Services Science

540

scientiﬁc community but many non-scientiﬁc appli-

cations are still well suited to the virtual infrastruc-

ture it provides. The components of Nimbus are mod-

ular in design with hypervisor agnostic support en-

abled via Libvirt and support for Amazon EC2 via

a SOAP based API for invocation and securing of

off-site resources. Nimbus also supports a Web Ser-

vice Resource Framework (WSRF) frontend for con-

trolling virtual infrastructure and context broker and

agent components enabling automated contextualiza-

tion of VM images for “one-click” clusters (Keahey

and Freeman, 2008).

3 VIRTUAL MACHINE

MANAGEMENT

A Virtual Machine Manager (VMM) or Hypervisor,

partitions a physical host machine though the use of

three generalized techniques: Full Virtualization, Par-

avirtualization and Hardware Assisted Virtualization

(HVM) and is responsible for controlling the life cy-

cle and resource utilization of local VMs. These

techniques provide a layer of abstraction away from

the underlying physical hardware. The techniques

provide a complete virtual hardware environment in

which a guest OS can execute in isolation and where

resources are multiplexed transparently between con-

currently executing OSs.

Full Virtualization (FV) involves the creation of

hardware devices purely in software to provide an ad-

equate supply of simulated hardware for a guest Oper-

ating System (OS) to run unmodiﬁed. This comes at a

considerable performance penalty due to the interpre-

tation of hardware operations in the guest (Popek and

Goldberg, 1974). Paravirtualization (PV) imitates a

device interface using a far more direct path to handle

devices inside a VM and can achieve better perfor-

mance than FV. A downside of this technique is that it

requires the installation of altered device drivers into

a guest OS. A beneﬁt is that this reduces the amount

of time a guest spends accessing the device by re-

locating execution of critical tasks to its host where

such tasks are more performant. HVM of a guest uti-

lizes the additional hardware capabilities of an under-

lying host and provides the best performance of all

the Virtualization techniques. Currently this takes the

form of Virtual Machine Extensions (VMX) within

the instruction set of a host processor. This acceler-

ates and isolates context switching between processes

running in different VMs, increasing computational

performance as instructions are directly passed to the

host processor without having to be interpreted and

isolated by the VMM. Unfortunately this technique

comes at the expense of limiting the guest to using

the same instruction set as the host. Complete sup-

port for HVM of all computer subsystems, i.e. I/O

peripherals, has yet to be fully realized in commodity

computer hardware. However the performance ben-

eﬁts of HVM I/O have been explored using directed

I/O Virtualization extentions (Dong et al., 2009).

3.1 XEN & KVM

Historically XEN has concentrated on the develop-

ment of PV guests. Recently both VMMs support

multiple Virtualization techniques often referred to

as Hybrid Virtualization (Nakajima and Mallick Asit

K., 2007). Hybrid Virtualization combines the prin-

ciples of both HVM and PV to obtain near native

performance for guest OSs. This however has the

disadvantages of both techniques; altered OS de-

vice drivers are necessary, along with modern VMX

supporting hardware. XEN and KVM both support

FV through the utilization of core components from

QEMU, a “generic and open source machine emula-

tor and virtualizer” (QEMU, 2010) that provides em-

ulation of other devices besides CPU architectures.

When QEMU acts as a machine emulator it provides

emulation of different CPU architectures through bi-

nary translation. When QEMU is used as a virtualizer

in combination with KVM or XEN the features that

enable emulation of other devices besides CPUs can

be used to virtualize an OS when paravirtualized de-

vice drivers do not exist or hardware support for HVM

is limited but this approach has an associated perfor-

mance cost. Before the combination of multiple Vir-

tualization techniques in KVM, the consolidation of

an organization’s current hardware using KVM was

not feasible if its infrastructure did not support the in-

struction set extensions necessary for HVM guests.

KVM conversely provided an excellent foundation for

the creation of new virtual infrastructure through a re-

duction in the number of physical machines required

for peak operating demand and thus lowers hardware

running and setup costs. XEN on the other hand, with

its better support for paravirtualized guests, was more

appropriate for deployment onto older hardware and

still enabled consolidation.

Comparing XEN and KVM further, the lack

of support for fully paravirtualized guests in KVM

across all OSs, such as the closed source and propri-

etary Microsoft Windows, has the potential to reduce

performance. Alternatively the costs of porting par-

avirtualized device drivers (Barham et al., 2003) to

these OSs for XEN do not exist. XEN is a more ma-

ture Virtualization solution and has been developed

for far longer than KVM pertaining to greater stabil-

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O

Paravirtualization

541

ity. However KVM continues to be on the forefront

of implementing new Virtualization techniques and

utilizes the latest research into HVM. This provides

greater performance improvements over the same im-

plementations in software with the downside of re-

quiring state-of-the-art hardware. One such technique

introduced recently was hardware page-table walk-

ers that reduce memory address-translation overheads

and remove the need for shadow page tables at the

memory management unit level, providing memory

savings and performance beneﬁts that were not ini-

tially available in XEN.

Another non-functional comparative advantage of

KVM over XEN is that KVM is less pervasive due

to its hypervisor classiﬁcation. XEN is classiﬁed as a

Type I hypervisor and KVM as a Type II hypervisor

according to (Goldberg, 1972). Type I hypervisors

run directly on the host hardware with the guest OS

running one level above the hypervisor. In the case

of XEN an installed micro-kernel is booted before

the administrative guest “Domain0”, which is used to

conﬁgure other guests. On the other hand, Type II hy-

pervisors run from within a conventional OS, where

the hypervisor operates as a distinct second software

layer and the guests execute above in a third layer.

KVM is comprised of a single module probed into a

standard Linux kernel. The comparative advantage of

this is that a considerably smaller code-base has to

be maintained, which lowers the risks of introducing

bugs and reduces the amount of code to optimize.

3.2 Paravirtualization of Block I/O

Devices

KVM and XEN have different PV architectures for

accessing virtual block devices or virtual Hard Disk

Drives (HDD) within a guest OS. One of the aims of

our work is to evaluate the performance of these de-

vices to ascertain the suitability of virtual infrastruc-

ture for data intensive applications.

KVM has adopted Virtio (Russell, 2008), a Linux

standard for virtual I/O device driver Application Bi-

nary Interfaces (ABI), for PV of block storage. With

Virtio the guest OS is “aware” of the virtual environ-

ment in which it is running, in essence cooperating

with the VMM, attaining higher performance and the

beneﬁts of PV. Virtio uses a layer of abstraction and a

memory ring buffer as a transport for data between a

VM and its host as expressed in Figure 2.

This provides the ability to write generic front-

end virtual device drivers and arbitrary back-ends to

support different device types for different OSs and

VMMs. It removes the need to maintain multiple sets

of virtual device drivers for each brand of VMM avail-

Physical Computer

Guest

Host

Hypervisor Bus

Block Backend

Driver

File

System


File

Host Kernel Device

Control

Daemon

System Call

API

Block Frontend

Driver

Guest Kernel Device

Process

Write System

Call Intercepted

Write

Data

Event Queue

Ring Buffer

Write System Call

Physical Computer

Guest

Host

Hypervisor BusHypervisor Bus

Block Backend

Driver

File

System


File

Host Kernel Device

Control

Daemon

Control

Daemon

Control

Daemon

System Call

API

System Call

API

Block Frontend

Driver

Guest Kernel Device

ProcessProcess

Write System

Call Intercepted

Write

Data

Write

Data

Event Queue

Ring Buffer

Event Queue

Ring Buffer

Write System CallWrite System Call

Figure 2: A simpliﬁcation of virtual block I/O PV.

able. The XEN approach is very similar to that of

KVM as Virtio is based considerably on the works

of the XEN developers. XEN supports block devices

through a “hypercall” ABI that makes use of an al-

tered version of the Linux blkback device, used for

user land access to block devices, named blktap or

“block tap”. The blktap device is used in combination

with a frontend driver embedded in a guest. XEN ver-

sion 4.0.1 introduces blktap2 the successor to the old

blktap1 disk backend driver. Both versions of blk-

tap will be tested to ascertain if there are any per-

formance improvements or regressions from this new

implementation. Two versions of KVM of differing

maturity will also be tested again to see how perfor-

mance has changed over time. Paravirtualized support

for non-modiﬁable OSs, such as Windows, has been

implemented in both KVM and XEN with emulated

PCI devices replacing the ABI in traditional PV. The

performance of these devices has been omitted from

the scope of this paper but will make an interesting

addition in future work.

4 EXPERIMENTAL DESIGN

This section of the paper introduces the testbed archi-

tecture, the benchmarks used to assess performance

and the experimental methodology that discusses the

selection of independent and dependent variables for

each of the benchmarks.

4.1 Testbed Architecture

The experimental testbed was comprised of Dell com-

modity servers. Each server consists of a four core

X3360 Intel Xeon CPU, running at the default clock

speed of 2.83GHz and a total of 4GB of RAM (four

modules of 1GB DDR2 at 800Mhz). In addition, each

server utilized a single 3.5 inch Western Digital RE3

250GB SATA HDD (Model: WD2502ABYS), with

16MB of cache and a spindle speed of 7200 RPM.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

542

The machines connect via Gigabit Ethernet using a

Broadcom PCI-E NIC (Model: BCM95722). The ﬁle

system in use on both the physical machines and the

VMs is EXT3. VMs were not provisioned concur-

rently and each instance used all available hardware

with the exception of half the available RAM (2GB)

of the host. The VM images are contained in raw for-

mat and stored on top of the host ﬁle system. The

OS present on both machines is Centos release 5.4

(Final). The following hypervisor versions are used:

KVM versions 83 and 2.6.32.24; XEN versions 3.4.3

and 4.0.1. Two Centos based Linux Kernel versions

are used to test the older versions of KVM and XEN:

2.6.18-164.15.1.el5 for testing the performance of the

native host and KVM version 83 guests; and 2.6.18-

164.11.1.el5xen for testing the performance of XEN

Dom0 and XEN 3.4.3 guests. The same vanilla Linux

Kernel version 2.6.32.24 is used to test KVM ver-

sion 2.6.32.24 and XEN version 4.0.1. Version 2.6

of Nimbus and version 2.0.1 of OpenNebula are de-

ployed on the testbed. Globus Toolkit version 4.0.8 is

installed enabling support for GSIFTP. The following

versions of the benchmarking software, with justiﬁ-

cations in the next subsection, are used in the exper-

iments: Bandwidth Monitor NG version 0.6 (BWM-

NG, 2010), IOzone version 347 (IOzone, 2010) and

Bonnie++ version 1.03e (Bonnie++, 2010).

4.2 Benchmarks

Three benchmarks were used in the performance eval-

uation. The ﬁrst a bespoke image propagation bench-

mark for reviewing the overheads of transferring a

VM image between two nodes on a Cloud system.

The two other benchmarks were used to expose the

performance of VMM block I/O systems.

The image propagation benchmark integrated

Bandwidth Monitor NG (BWM-NG) as a tool to mea-

sure the input and output of the NIC from where

the VM image repository and VIM were resident, re-

ferred to in this paper as the ‘head node’. The bench-

mark involved the creation of: i) scripts to amalga-

mate the commands necessary for a user to provision

a VM, ii) verify the VM was on-line and executing

and iii) terminate the VM in an automated fashion

so that iterations of the experiment could be repeated

with relative ease. Each action was timed and com-

pared to the start and end of the data transfer recorded

by BWM-NG. This exposed the overheads of each

stage of the image propagation, from the head node

to the destination node where a VM was deployed.

The image propagation benchmark takes a single pa-

rameter; the size of image to be transferred. The

benchmark was wrapped around the three platforms:

OpenNebula using the SCP protocol, Nimbus using

the SCP protocol and Nimbus using GSIFTP.

Two synthetic benchmarks: IOzone and Bon-

nie++, were chosen for the performance evaluation

of virtual block I/O devices. These synthetic bench-

marks try to encompass all possible parameters that

could represent different workloads, such as database

software writing small ﬁles randomly to ﬁle servers

reading large ﬁles sequentially. IOzone is a bench-

mark that generates and measures a selection of ﬁle

operations to analyze the performance of a ﬁle sys-

tem. Bonnie++ is a benchmarking suite with the abil-

ity to perform several tests to assess the performance

of a ﬁle system and underlying HDD. In addition to

monitoring the above, Bonnie++ also monitors the

CPU overhead of a given test which gives a good in-

dication of the efﬁciency of the block I/O implemen-

tation. Two benchmarks were also chosen to enable

the validation of results so that any anomalies can be

ruled out as implementation speciﬁc issues. A test ﬁle

size of twice the amount of available RAM was used

in both to prevent CPU and RAM caches from biasing

the results.

The following IOzone tests, with accompanying

deﬁnitions, were chosen for the experiments: Write –

Measures the performance of writing a new ﬁle, in-

clusive of writing ﬁle metadata; Re-write – Measures

the performance of writing to a ﬁle that already ex-

ists, omitting much of the workload required in writ-

ing metadata; Read – Measures the performance of

reading an existing ﬁle; Re-read – Measures the per-

formance of reading a recently read ﬁle, illustrative of

caching affects that can improve performance as reads

are satisﬁed by cache; Random Read – Measures per-

formance of reading random locations within a ﬁle,

indicative of the performance of cache hierarchy and

seek latency; Random Write – Measures performance

of writing to random locations within a ﬁle, indica-

tive of the performance of cache hierarchy and seek

latency.

The subsequent Bonnie++ tests, with accompany-

ing deﬁnitions, were recorded during the experiment:

Sequential Throughput – The number of blocks of

data that can be read or written adjacent to one another

in respect to the physical medium, in kilobytes per

second; File Operations – The number of sequential

or random, create or delete ﬁle operations per second

illustrative of the overheads associated with manipu-

lating ﬁle metadata in a ﬁle system; Read File Op-

erations – The number of sequential or random read

operations of ﬁle metadata in zero size ﬁles per sec-

ond an indicator of the efﬁciency of a ﬁle system’s

structure.

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O

Paravirtualization

543

4.3 Methodology

The image propagation experiment alters the image

size, in the range 3GB to 21GB, in increments of 3GB

and records time in seconds. It is difﬁcult to gauge

what sizes of image are representative of those used

in the real world as the image size is often depen-

dent on the application. We in part have chosen this

range as it is representative of a Service Oriented Ar-

chitecture pathology application we have deployed on

our testbed that requires large volumes of data be em-

bedded into the VM image. In addition, the chosen

range should provide enough data points for any re-

lationship between the variables to be observed. For

the IOzone and Bonnie++ experiments, the software

stacks on which the benchmarks run are altered. The

software stacks are the native host, KVM hypervisor

deployed on the native host, XEN Domain0 or privi-

leged guest that facilitates XEN VMs and XEN Do-

mainU or XEN guest VM. In addition, the newest sta-

ble releases of KVM and XEN are also introduced.

Depending on which benchmark test is being per-

formed, either the throughput in bytes per second or

the number of operations per second is recorded. The

percentage CPU time, where applicable in the case

of Bonnie++ tests, is also recorded. Ten iterations of

each of the benchmark tests are performed and the

average result, along with the standard deviation, are

presented where possible.

5 EXPERIMENTAL RESULTS

This section dicusses the results of each of the three

benchmarks outlined in the Section 4.2.

5.1 Image Propagation Performance

Analysis

The results of the image propagation benchmark pro-

vide an interesting insight into how the underlying de-

sign and implementation of the image management

supervision processes used in each IaaS manager, im-

pact the time it takes for a single iteration of a VM’s

lifecycle. Figure 3(a) presents these times against an

increasing VM image size.

It is clear that Nimbus using GSIFTP as a transfer

protocol outperforms both Nimbus and OpenNebula

using SCP. Adding appropriate trend lines, interpolat-

ing to an image size of zero and reading the appropri-

ate value from the y-axis intercept, provides an indi-

cation of the overhead created by the implementation

within each IaaS manager, responsible for managing

y = 24.42x + 35.186

= 0.9989

y = 24.511x + 9.9429

= 0.9999

y = 0.0911x

+ 12.604x + 9.6143

= 0.9995

100

200

300

400

500

0 3 6 9 12 15 18 21

Image Size (GByte)

Time (Sec)

OpenNebula SCP Nimbus SCP Nimbus GSIFTP

Linear (OpenNebula SCP) Linear (Nimbus SCP) Poly. (Nimbus GSIFTP)

(a)

y = 24.281x

= 0.9996

y = 24.336x

= 0.9998

y = 0.1396x

+ 10.285x

= 0.9988

y = 8x

= 1

100

200

300

400

500

0 3 6 9 12 15 18 21

Image Size (GByte)

Time (Sec)

OpenNebula SCP Nimbus SCP Nimbus GSIFTP

Theoretical NIC Linear (OpenNebula SCP) Linear (Nimbus SCP)

Poly. (Nimbus GSIFTP) Linear (Theoretical NIC)

(b)

Figure 3: Image propagation: Trends.

the propagation process of a VM. Figure 3(b) illus-

trates the theoretical performance of the NIC which

neither protocol obtains. It also show that on average

GSIFTP transfers data nearly twice as fast or in ∼46%

less time than SCP and when using the SCP protocol

the transfer time is agnostic of the IaaS manager used.

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

3 6 9 12 15 18 21

Image Size (GByte)

Percent of Propagation Time

OpenNebula SCP (Top to Bottom: Terminal Overhead, Data Transfer, Initial Overhead)

Nimbus SCP (Top to Bottom: Terminal Overhead, Data Transfer Time, Initial Overhead)

Nimbus GSIFTP (Top to Bottom: Terminal Overhead, Data Transfer Time, Initial Overhead)

Figure 4: Image propagation: Overheads.

Figure 4 show the results of the time spent wait-

ing to change from one state to another in each of

the platforms tested. It can be seen that the major-

ity of the time is spent in a transferring state, waiting

for the transfer protocol to complete the movement of

CLOSER 2011 - International Conference on Cloud Computing and Services Science

544

data from the image repository to the VM host ma-

chine. On the other hand, when transferring smaller

images the initial and terminal overheads of the IaaS

manager supervising the propagation process become

an increased proportion of the total time spent wait-

ing. When comparing the SCP transfer protocol on

different IaaS managers Nimbus can be seen to out-

perform OpenNebula with a considerable reduction

in the time spent in the initialization and termina-

tion states, speciﬁcally ∼3.5 times faster or in ∼72%

less time, creating less overhead for identical sizes

of image. When Nimbus utilizes the GSIFTP trans-

fer protocol the initialization time remains roughly

proportional to the overall propagation time. This is

in contrast to the other platforms where the percent-

age of time spent in the initialization and termination

states decrease proportionally with an increase in im-

age size, that is the overheads remain constant. This

feature is also illustrated by the polynomial trend line

in Figure 3(a).

5.2 Virtual Block I/O Performance

Analysis

Block I/O devices are incredibly slow in comparison

to the performance of memory and CPU caches in

traditional computer systems, with many millions of

CPU cycles being wasted to service a single I/O re-

quests when a cache miss occurs. Optimization of the

virtual equivalent block I/O, like any leading bottle-

neck within a system, should be of a high priority and

has repercussions for applications that utilize large

datasets. The results in this subsection on the bench-

marks of IOzone and Bonnie++, divulge the perfor-

mance of the VMM block I/O devices and thus re-

veal the state of development, the amount of effort

and time assigned to optimization and an indication

of the maturity of the Virtualization solutions KVM

and XEN.

101

105

103

104

105

108

107

108

100

120

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomU Host 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

MBytes / Sec

Write Re-write Read Re-read Random_Read Random_Write

Figure 5: IOzone - record size: 16MB, ﬁle: 4GB guest;

8GB host.

100

103

106

101

105

107

103

106

113

109

100

120

KVM 2.6.32.24 KVM 2.6.32.24 [cache=none] Xen 4.0.1 DomU

Platform

MBytes / Sec

Write Re-write Read Re-read Random_Read Random_Write

Figure 6: IOzone on 2.6.32.24 - record size: 16MB, ﬁle:

4GB guest.

Figure 5 and 6 illustrates the maximum through-

put of the virtual block I/O devices for a given plat-

form, where a record size of 16Mbyte is used to min-

imize CPU usage. It can be seen that out of the box,

KVM 83 write performance is incredibly poor in con-

trast to XEN 3.4.3. KVM 83 on average across all

write tests exhibited ∼17% of the throughput of XEN

3.4.3. IOzone read tests demonstrate that KVM 83

performs similarly to XEN 3.4.3 in the initial read test

but failed to equal the throughput for the re-read and

random read tests attaining ∼77% of the throughput.

The tests on the newer versions of KVM and XEN are

shown in Figure 6. KVM 2.6.32.24 again shows poor

write performance but is a vast improvement over the

older version by roughly a factor of 3. The perfor-

mance of XEN 4.0.1 is on par with the older version

of XEN 3.4.3.

After further investigation, the bottleneck was

tracked to the caching system of the QEMU back-end

used by KVM. By default a write-through cache is

deployed for consistency to guarantee storage is com-

mitted to the underlying physical device. This has the

effect of increasing the amount of bus trafﬁc and ad-

ditional copy operations needed and consequently re-

duces the performance of write operations. With this

in mind, the benchmarks for KVM were rerun avoid-

ing the use of the cache all together and this demon-

strated far superior performance. This time KVM dis-

played ∼79% of the throughput of XEN. Figure 6

shows the new version of KVM 2.6.32.24 performing

on par with and on occasion better than XEN 4.0.1.

Comparing XEN 3.4.3 with the native host plat-

form and accounting for variance, write throughput

was on par on all tests other than the initial write

test which revealed that XEN 3.4.3 exhibited ∼83%

of the throughput. The results of the XEN 3.4.3 ini-

tial read test demonstrated similar results with ∼71%

of the throughput of the host. The other XEN 3.4.3

read tests were indistinguishable from the host and

the performance of the privileged guest “Domain0”

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O

Paravirtualization

545

14.5864

75.249

67.4364

88.3199

91.5935

17.7138

32.5602

32.4388

38.353

38.1086

81.5269

100.8423

104.3607

101.8657

81.6106

100

120

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomU Host 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

Mbyte / Sec

Sequential Write Sequential Rewrite Sequential Read

Figure 7: Bonnie++ - Throughput MB/Sec.

26.38

40.10

27.76

77.83

93.19

46.32

114.16

109.63

109.95

100

120

KVM 2.6.32.24 KVM 2.6.32.24 [cache=none] Xen 4.0.1 DomU

Platform

Mbyte / Sec

Sequential Write Sequential Rewrite Sequential Read

Figure 8: Bonnie++ on 2.6.32.24 - Throughput MB/Sec.

was equivalent to the native host performance across

all tests.

The results of the Bonnie++ benchmark for se-

quential throughput (Figure 7 and 8) are conﬁrmatory,

showing near identical results to IOzone for the se-

quential write and read tests but oddly show differing

results for the sequential re-write test across all plat-

forms. These results show roughly a 50% reduction in

throughput compared to IOzone. This could indicate

that the sequential re-write test throughput is a formu-

lation of the time to execute two consecutive sequen-

tial write operations and has not been accounted for.

The discrepancy highlights the need for an additional

conﬁrmatory benchmark when running performance

evaluation experiments.

While throughput of the virtual block devices pro-

vides an indication of performance, the number of op-

erations that can be performed per second give further

insight into how efﬁcient the implementations are.

Figure 9 and 10 presents the Bonnie++ benchmark

results for sequential and random deletion and cre-

ation of ﬁles respectively. The results show that KVM

83 performs poorly in all cases, more so in the create

tests where an order of magnitude less operations can

be executed and where turning off the storage cache

in KVM has minimal impact on performance. Inter-

estingly XEN 3.4.3 guests outperform the native host.

2474

3503

33224

19131

18059

700

691

1407

2498

2481

3596

3515

21001

16564

15604

376

367

770

1163

1157

0.0E+00

5.0E+03

1.0E+04

1.5E+04

2.0E+04

2.5E+04

3.0E+04

3.5E+04

4.0E+04

4.5E+04

5.0E+04

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomU Host 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

Operations / Sec

Sequential Create Sequential Delete Random Create Random Delete

Figure 9: Bonnie++ - File operations per second.

3574

630

653

630

3524

335

339

331

4540

3546

4252

3795

0.0E+00

5.0E+02

1.0E+03

1.5E+03

2.0E+03

2.5E+03

3.0E+03

3.5E+03

4.0E+03

4.5E+03

5.0E+03

KVM 2.6.32.24 KVM 2.6.32.24 [cache=none] Xen 4.0.1 DomU

Platform

Operations / Sec

Sequential Create Sequential Delete Random Create Random Delete

Figure 10: Bonnie++ on 2.6.32.24 - File operations per sec-

ond.

Again it can be seen that the performance of KVM

2.6.32.24 is comparable to XEN 3.4.3 and 4.0.1.

Another indicator of efﬁcient design and imple-

mentation is that of CPU usage used when performing

I/O related tasks. Applications using CPU resources

can become starved by OS subsystems such as block

I/O back-ends using excessive CPU time to service re-

quests for accessing I/O devices. Figure 11(a) shows

KVM 83 performing poorly on all sequential oper-

ations using a greater percentage of CPU to service

less requests in comparison to XEN. Interestingly the

XEN 3.4.3 guest performs better than the underlying

XEN Domain0, exhibiting very little CPU usage if the

CPU metric gathered within the XEN guest is to be

trusted. Disabling the storage cache of KVM 83 cre-

ates an increase in the percentage of CPU time used.

In the ﬁle operation tests of Figure 11(b) this per-

formance gap is even more prominent with all tests

exhibiting CPU usage around 80%. At ﬁrst glance

KVM with storage cache seems to outperform XEN

in the percentage of CPU time used to create ﬁles

randomly but performs far less operations per sec-

ond. Figure 12(a) demonstrates another performance

improvement for KVM 2.6.32.24 over KVM 83 and

a slight performance regression from XEN 3.4.3 to

4.0.1. Figure 12(b) reveals a large reduction in CPU

CLOSER 2011 - International Conference on Cloud Computing and Services Science

546

usage across the tests for KVM 2.6.32.24 with and

without cache and a modest improvement for XEN

4.0.1 over XEN 3.4.3.

14.8

29.7

11.8

17.6

5.9

7.1

10.2

0.8

7.8

100

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomU Host 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

CPU %

CPU Usage Write CPU Usage Rewrite CPU Usage Read

(a)

65.2

79.1

91.5

89.9

85.1

1.1

28.4

79.1

77.7

83.8

78.7

13.4

100

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomU Host 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

CPU %

CPU Usage Sequential Create CPU UsageSequential Delete

CPU Usage Random Create CPU Usage Random Delete

(b)

434806

431709

347864

443289

289012

534276

528048

363068

568865

404304

0.E+00

1.E+05

2.E+05

3.E+05

4.E+05

5.E+05

6.E+05

7.E+05

KVM 83 KVM 83

[cache=none]

Xen 3.4.3 DomUHost 2.6.18-

164.11.1.el5

Xen 3.4.3 Dom0

2.6.18-

164.11.1.el5xen

Platform

Operations / Sec

Sequential Read

Random Read

(c)

Figure 11: Bonnie++ - Left-to-Right, Top-to-Bottom: Se-

quential Throughput CPU Usage, File Operations CPU Us-

age & Read File Operations.

Figure 11(c) presents evidence that KVM 83

guests outperform XEN 3.4.3 guests and that the XEN

3.4.3 privileged guest Domain0 performs worse than

the native host when operating on ﬁle metadata. This

indicates that the cause of the write bottleneck of

KVM 83 with storage cache is due to the inefﬁcient

manner in which data is transferred from the host

physical storage to the guest and not due to the han-

dling of ﬁle system metadata. Finally comparing Fig-

ure 11(c) and Figure 12(c) another performance re-

gression is illustrated from XEN 3.4.3 to 4.0.1.

8.4

17.8

58.7

7.4

10.2

4.6

14.5

10.1

100

KVM 2.6.32.24 KVM 2.6.32.24

[cache=none]

Xen 4.0.1 DomU

Platform

CPU %

CPU Usage Write CPU Usage Rewrite CPU Usage Read

(a)

4.7

25.8

0.9

4.6

25.5

2.5

5.8

100

KVM 2.6.32.24 KVM 2.6.32.24

[cache=none]

Xen 4.0.1 DomU

Platform

CPU %

CPU Usage Sequential Create CPU UsageSequential Delete

CPU Usage Random Create CPU Usage Random Delete

(b)

430546

429634

114763

523115

524188

127797

0.E+00

1.E+05

2.E+05

3.E+05

4.E+05

5.E+05

6.E+05

7.E+05

KVM 2.6.32.24 KVM 2.6.32.24

[cache=none]

Xen 4.0.1 DomU

Platform

Operations / Sec

Sequential Read

Random Read

(c)

Figure 12: Bonnie++ on 2.6.32.24 - Left-to-Right, Top-to-

Bottom: Sequential Throughput CPU Usage, File Opera-

tions CPU Usage & Read File Operations.

6 RELATED WORK

The main contribution of this paper lies in the ﬁnd-

ings of a performance evaluation into a speciﬁc as-

pect of Cloud Computing; the management and use

of data at the Virtualisation level. Results are pre-

sented that provide insight into how Cloud technology

can be improved and what technology is best for the

needs of a given application. There have been numer-

ous studies on the performance of hypervisors within

the literature (Kesavan et al., 2010; Padala et al.,

2008; Stantchev, 2009; Yu Liang and Lu, 2008; Xi-

anghua Xu et al., 2008; Jianhua Che et al., 2008; De-

shane et al., 2008) and this paper differentiates from

these by giving a contemporary performance evalua-

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O

Paravirtualization

547

tion within the context of Cloud Computing. We con-

tribute and implement a novel benchmark to evaluate

end to end image propagation overheads of any IaaS.

(Yigitbasi et al., 2009) present a performance analy-

sis framework for the overheads in resource acquisi-

tion and release. However the results of their work

are for resources deployed onto Amazon EC2 with

the framework left untested on other virtual resource

management architectures. (Goiri et al., 2009) de-

scribe a proof-of-concept framework for facilitating

resource management in service providers in which

a performance evaluation of the overhead of creat-

ing a VM image is considered not the time to prop-

agate an already existing VM image to a physical re-

source. (Chen et al., 2009) explore how multicast-

ing ﬁle transfers can reduce image propagation over-

heads.

Previous related works have concentrated on the

performance and scalability of CPU virtualisation

omitting a performance analysis inclusive of I/O

(Padala et al., 2008). An additional publication

(Stantchev, 2009) formulates an approach to perfor-

mance evaluation, using real world workloads on

Amazon EC2 and considers the system as a “black

box” without ﬁnding the root causes of the perfor-

mance bottlenecks. Another creates a methodology

for the collection of virtual I/O metrics (Yu Liang

and Lu, 2008) but evaluates the performance of only

a single hypervisor. Other publications (Xianghua

Xu et al., 2008; Jianhua Che et al., 2008) incorrectly

setup a parameter of the IOzone benchmark using a

64MB test ﬁle instead of twice the size of available

memory, bringing into question the validity of the re-

sults obtained. (Deshane et al., 2008) present results

that KVM outperforms XEN in IOzone tests. Our ex-

periments have been unable to conﬁrm these results

and one can only assume, due to limited informa-

tion from the paper on the experimental environment

used, that again the ﬁle size parameter for the IOzone

benchmark has been set incorrectly.

7 CONCLUSIONS AND FUTURE

WORK

The aspect of performance within QoS has an impor-

tant role to play in the provisioning of resources in

Cloud Computing. This paper presented the ﬁndings

of a performance evaluation into the management and

utilization of data inside an IaaS provider. The im-

plementation of technologies used in virtual infras-

tructure has been highlighted as inﬂuencing the out-

come of resource performance and consequently the

QoS provisioned to end users, the competitiveness of

a provider in the Cloud ecosystem and likely return

on investment of services made available. This subse-

quently makes the selection of technology a decisive

decision for any Cloud provider. The outcome of our

work provides quantitative evidence that can enhance

this decision making process and aid in the prevention

of SLAs breaches.

The results of our experiments illustrate that

OpenNebula and KVM, relative new comers to the

paradigm of distributed systems, perform to a lower

standard than Nimbus and XEN. This is being recti-

ﬁed over time as seen with KVM version 2.6.32.24

but, like XEN 4.0.1, is not currently distributed with

enterprise grade operating systems such as CentOS

5.4. A general theme has reoccurred throughout our

performance analysis: the maturity of a particular

technology heavily inﬂuences performance. There-

fore it could be concluded that the ﬁndings of our

work advocate mature software solutions due to cor-

relation with improved relative performance, but this

is not always the case as seen in XEN version 4.0.1

where a new implementation of the blktap disk back-

end driver in a mature software solution has intro-

duced performance regression. This puts into context

the contemporary feature sets these new technologies

provide, which we argue are more appropriate or spe-

ciﬁc to the usage scenarios of a Cloud environment.

As a consequence this trade off between performance

and feature set should be factored in when making any

decision on whether to use the technology evaluated

here in.

The implications of our results draw attention to

the impact performance overheads have on the adop-

tion of Cloud technology. OpenNebula for exam-

ple has a comparatively limited aptitude to react to

changes in demand in a stochastic and highly dynamic

environment and accordingly Nimbus would be more

appropriate in this scenario. Data management ser-

vices such as Amazon’s S3, when considered not eco-

nomically viable or where the cost of these Cloud ser-

vices are not completely transparent and vary signif-

icantly (Kossmann et al., 2010), could result in data

having to be stored and accessed within a local VM

image. The lack of KVM 83 guests at writing and

reading data could be a limiting factor for applica-

tions that access large quantities of data locally and

conversely XEN 3.4.1 would be an advisable choice

here.

Future work is planned to evaluate the trade off be-

tween the features of enhanced image formats such as

QCOW2, VMware’s VMDK and Microsoft’s VHD

and the performance of raw images. In addition, the

overheads surrounding other popular VIMs, such as

Eucalyptus (Eucalyptus, 2010), will be evaluated.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

548

REFERENCES

Barham, P., Dragovic, B., Fraser, K., Hand, S., Harris, T.,

Ho, A., Neugebauer, R., Pratt, I., and Warﬁeld, A.

(2003). Xen and the art of virtualization. SIGOPS

Oper. Syst. Rev., 37(5):164 – 177.

Bonnie++ (2010). Bonnie++ - Benchmark Suite. Website.

http://www.coker.com.au/bonnie++/.

BWM-NG (2010). Bandwidth Monitor NG. Website.

http://www.gropp.org/?id=projects&sub=bwm-ng.

Chen, Y., Wo, T., and Li, J. (2009). An Efﬁcient Resource

Management System for On-line Virtual Cluster Pro-

vision. In IEEE 2009 International Conference on

Cloud Computing.

Deshane, T., Shepherd, Z., Matthews, J., Ben Yehuda, M.,

Shah, A., and Rao, B. (2008). Quantitative compari-

son of Xen and KVM. In Xen Summit, Berkeley, CA,

USA. USENIX Association.

Dong, Y., Dai, J., Huang, Z., Guan, H., Tian, K., and Jiang,

Y. (2009). Towards high-quality I/O virtualization.

In ACM International Conference Proceeding Series,

pages 12 – 22, Haifa, Israel.

Dong-Jae Kang, Chei-Yol Kim, Kang-Ho Kim, and Sung-

In Jung (2008). Proportional disk I/O bandwidth man-

agement for server virtualization environment. In

2008 International Conference on Computer Science

and Information Technology, pages 647 – 53, Piscat-

away, NJ, USA.

Eucalyptus (2010). Eucalyptus - Elastic Utility Computing

Architecture. Website. http://www.eucalyptus.com/.

Goiri, I., Julia, F., Ejarque, J., de Palol, M., Badia, R.,

Guitart, J., and Torres, J. (2009). Introducing virtual

execution environments for application lifecycle man-

agement and SLA-driven resource distribution within

service providers. In Proceedings 2009 Eighth IEEE

International Symposium on Network Computing and

Applications (NCA), pages 211 – 18, Piscataway, NJ,

USA.

Goldberg, R. (1972). Architectural Principles for Virtual

Computer Systems. PhD thesis, Harvard University,

Cambridge, MA.

Hansen, J. G. and Jul, E. (2010). Lithium: virtual machine

storage for the cloud. In SoCC ’10: Proceedings of

the 1st ACM symposium on Cloud computing, pages

15 – 26, New York, NY, USA. ACM.

Imada, T., Sato, M., and Kimura, H. (2009). Power and QoS

performance characteristics of virtualized servers. In

Proceedings of the 2009 10th IEEE/ACM Interna-

tional Conference on Grid Computing (GRID), pages

232 – 40, Piscataway, NJ, USA.

IOzone (2010). IOzone - Filesystem Benchmark. Website.

http://www.iozone.org/.

Jianhua Che, Qinming He, Qinghua Gao, and Dawei Huang

(2008). Performance measuring and comparing of vir-

tual machine monitors. In 2008 IEEE/IFIP 5th In-

ternational Conference on Embedded and Ubiquitous

Computing. EUC 2008, volume 2, pages 381 – 6, Pis-

cataway, NJ, USA.

Jun Zhu, Wei Dong, Zhefu Jiang, Xiaogang Shi, Zhen Xiao,

and Xiaoming Li (2010). Improving the Performance

of Hypervisor-Based Fault Tolerance. In Proceedings

of the 2010 IEEE International Symposium on Paral-

lel & Distributed Processing (IPDPS), pages 10 – 20,

Piscataway, NJ, USA.

Kate Keahey, Tim Freeman, Jerome Lauret, and Doug Ol-

son (2007). Virtual workspaces for scientiﬁc applica-

tions. In SciDAC 2007 Conference, Boston, MA.

Keahey, K. and Freeman, T. (2008). Contextualization: Pro-

viding One-Click Virtual Clusters. In ESCIENCE ’08:

Proceedings of the 2008 Fourth IEEE International

Conference on eScience, pages 301 – 308, Washing-

ton, DC, USA. IEEE Computer Society.

Kesavan, M., Gavrilovska, A., and Schwan, K. (2010).

Differential virtual time (DVT): rethinking I/O ser-

vice differentiation for virtual machines. In SoCC

’10: Proceedings of the 1st ACM symposium on Cloud

computing, pages 27 – 38, New York, NY, USA.

ACM.

Kossmann, D., Kraska, T., and Loesing, S. (2010). An eval-

uation of alternative architectures for transaction pro-

cessing in the cloud. In SIGMOD ’10: Proceedings of

the 2010 international conference on Management of

data, pages 579 – 590, New York, NY, USA. ACM.

KVM (2010). KVM - Kernel Based Virtual Machine. Web-

site. http://www.linux-kvm.org.

Nakajima, J. and Mallick Asit K. (2007). Hybrid Virtual-

ization - Enhanced Virtualization for Linux. In Pro-

ceedings of the Linux Symposium.

Padala, P., Zhu, X., Wang, Z., Singhal, S., and Shin,

K. G. (2008). Performance Evaluation of Virtualiza-

tion Technologies for Server Consolidation. Technical

report, HP Labs.

Popek, G. and Goldberg, R. (1974). Formal requirements

for virtualizable third generation architectures. Com-

munications of the ACM, 17(7):412 – 21.

QEMU (2010). QEMU - Open Source Processor Emula-

tion. Website. http://www.qemu.org.

Rochwerger, B., Caceres, J., Montero, R., Breitgand, D.,

Elmroth, E., Galis, A., Levy, E., Llorente, I., Nagin,

K., and Wolfstha, Y. (2009). The Reservoir model and

architecture for open federated cloud computing. IBM

Journal of Research and Development, 53(4):Online.

Russell, R. (2008). Virtio: towards a de-facto standard for

virtual I/O devices. SIGOPS Oper. Syst. Rev., 42(5):95

– 103.

Sotomayor, B., Rub

e andn, Llorente, I. M., and Foster,

I. (2009). Virtual Infrastructure Management in Pri-

vate and Hybrid Clouds. Internet Computing, IEEE,

13(5):14 – 22.

Stantchev, V. (2009). Performance evaluation of cloud com-

puting offerings. In Proceedings of the 2009 Third

International Conference on Advanced Engineering

Computing and Applications in Sciences (ADVCOMP

2009), pages 187 – 92, Piscataway, NJ, USA.

Van, H. N., Tran, F. D., and Menaud, J.-M. (2009). SLA-

aware virtual resource management for cloud infras-

tructures. In Proceedings - IEEE 9th International

CULTIVATING CLOUD COMPUTING - A Performance Evaluation of Virtual Image Propagation & I/O

Paravirtualization

549

Conference on Computer and Information Technol-

ogy, CIT 2009, volume 1, pages 357 – 362, Xiamen,

China.

Vouk, M. (2008). Cloud computing - Issues, research and

implementations. In 2008 30th International Con-

ference on Information Technology Interfaces (ITI),

pages 31 – 40, Piscataway, NJ, USA.

Xianghua Xu, Feng Zhou, Jian Wan, and Yucheng Jiang

(2008). Quantifying performance properties of virtual

machine. In Linux;program testing;software perfor-

mance evaluation;systems analysis;virtual machines;,

volume 1, pages 24 – 8, Piscataway, NJ, USA.

Xiong, K. and Perros, H. (2009). Service performance and

analysis in cloud computing. In SERVICES 2009 - 5th

2009 World Congress on Services, pages 693 – 700,

Bangalore, India.

Xu, C., Bai, Y., and Luo, C. (2009). Performance evalua-

tion of parallel programming in virtual machine envi-

ronment. In NPC 2009 - 6th International Conference

on Network and Parallel Computing, pages 140 – 147,

Gold Coast, QLD, Australia.

Yigitbasi, N., Iosup, A., Epema, D., and Ostermann, S.

(2009). C-Meter: A framework for performance anal-

ysis of computing clouds. In 9th IEEE/ACM Interna-

tional Symposium on Cluster Computing and the Grid,

CCGRID 2009, pages 472 – 477, Shanghai, China.

Yu Liang, S. and Lu, X. (2008). An efﬁcient disk I/O

characteristics collection method based on virtual ma-

chine technology. In Proceedings - 10th IEEE Inter-

national Conference on High Performance Computing

and Communications, HPCC 2008, pages 943 – 949,

Dalian, China.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

550
