EFFECTIVE DATABASE MIGRATION STRATEGY - THE NEED

FOR ADDRESSING DATABASE MIGRATION CHALLENGES

OF TODAY, TOMORROW AND BEYOND

Prabin R. Sahoo

Tata Consultancy Services, Performance Engineering Research Center

Yantra Park, Thane, Maharashtra, India

Keywords: Database, Migration, Transformation, Parallel, Load, SQL, Partitions, Performance, Assessments.

Abstract: Database migration is considered to be a least priority activity in software industry. This is a wrong

perception as database migration in reality becomes a nightmare to many who have experienced it. As the

migration process starts to the new target system, migration issues crop up which pile up gradually and

become unmanageable during the migration process. That is why to eliminate the migration issues require

highly effective database migration strategies. There are several papers where migration strategies have

been mentioned, and there are a number of tools those have been developed for successful database

migration, yet database migration issues still persists and organizations find it difficult to adapt an effective

migration strategy. Organizations spend enough in purchasing tools to do the migration. By the time one

realizes that the business is suffering after the post migration, it is too late. A huge amount is spent in the

repair process. This is not because of lack of migration strategy, rather lack of effective migration strategy.

For example: Using a migration tool can be a strategy, however before that an assessment is required to find

out how much percentage of tool can do and how much percentage required to build in-house tools, how

would the database behave after migration etc? Such analysis are lacking in today’s migration strategy. This

paper proposes an effective approach towards database migration to address migration assessments, the

migration issues, also improvising reusability.

1 INTRODUCTION

There are several reasons why database migration is

required. We will discuss here the top requirements

such as: the existing technology has become

obsolete, cost of maintenance has been increased for

a vendor, there are no proper service supports

available, merger and acquisition that leads to

consolidation of business functionalities leading

towards having a single database, growth limitation,

limited database features, future bets for latest

technology adoption, mission critical needs,

conversion from batch processing application to real

time etc.

No matter how big is the organization, database

migration no doubt is a must. Though there are tools,

strategies available but those are not widely usable

because of a number of reasons such as i)

commercials tools are expensive ii) tools unable to

handle complex migrations iii) too many manual

interventions iv) improper assessments v) complex

dependencies vi) inadequate strategies vii) increased

downtime viii) reliability issues and so on.

We have done literature review in section 2, section

3 we have shown the model, section 4 describes the

strategies, and section 5 contains case study, and

section 6 is having the conclusion.

2 LITERATURE REVIEW

In (EMC, 2007) author has mentioned steps for

database migration process. It is similar to the

methodologies followed for IT projects. There are

five phases that defines the step by step procedures.

The initial phase which is known as assessment

phase followed by planning and design, change

control, migration execution, post-migration review.

These strategies are helpful while planning for

migration. This also indicates that database

335

R. Sahoo P..

EFFECTIVE DATABASE MIGRATION STRATEGY - THE NEED FOR ADDRESSING DATABASE MIGRATION CHALLENGES OF TODAY, TOMORROW

AND BEYOND.

DOI: 10.5220/0003418103350338

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 335-338

ISBN: 978-989-8425-53-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

migration is not just a tool driven approach, it is a

project like other regular IT project. In (Joseph R.

Hudicka, 1998) the author has mentioned 7 phases

of database migrations. The author emphasizes on

having a devoted team with a clearly defined project

plan, automated tools where applicable as the

formula to success. The author has also mentioned in

this paper that database migration can be a project or

it can be an ongoing process. We will be focusing

here database migration as a project which mostly

needed migration from legacy system. In (Gints

Plivna, 1997) the author points out that though there

are several articles written about database

migrations, but most of those lack the technical

information about database migration and the author

tries to fill this gap through his paper. The author has

mentioned some of the techniques which can be

helpful for database migration from small and

middle sized database migration project. In (Premier

International Enterprises, 2004) the author has

mentioned the need of database migration and the

cause of cost overrun and demonstrates a new

approach which mitigates the risk of Code, Load and

Explode. In (Philip Howard, 2007) the author has

described the extra cost that has been expended for

database migration because of the lack of best

practices in database migration domain. In

(Christopher Burry, David Mancusi, Avanade, 2004)

the authors have discussed how to plan for database

migration. In (Todd Murihead, Dave Jaffe, Paul Rad,

2005) Dell Power Solution demonstrates the

database migration best practices involving oracle

10g

(R)

from Sun servers to Dell

PowerEdge

Though all the available approaches are relevant to

database migration it is difficult to choose which one

is best and which one is second best and so on.

Instead of finding the shortcomings in each of these,

we would like to adopt some of the best strategies

and propose on the top of it a new strategy that

would eliminate further migration issues, problems

and deficiencies.

3 MODEL AND ARCHITECTURE

There are five components as shown in figure 1.0

i.e. legacy application, legacy database, new

application and new database, separated by a

transformation layer. The transformation layer plays

a major role in the migration process.

Transformation layer is the tricky part. It has 2

parts. First part deals with database transformation,

and the second part deals with application

transformation.

Figure 1: Model.

3.1 Database Transformation Layer

The database transformation layer is responsible for

transforming the legacy data layout to new data

layout.

Figure 2: Database Transformer Layer.

Figure 2.0 represents the high level view of

database transformation layer. For each source

database there is one corresponding transformer.

3.1.1 Transformers

Layout Transformations

The layout transformer takes care of the layout of

the database which includes creation of partition

group, buffer pool, tablespace, table structure

including data type conversions.

Object Transformation

Object transformation involves stored procedures,

triggers, views etc. This part is where the most of

the issues occur. It requires mostly manual

LegacyDB

NewDB

Legacy

Application

New

Application

Transformation

Source DB

Target DB

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

336

intervention specially the stored procedures, no tool

can completely transform without complexity and

performance compromise. Care must be taken here

to eliminate complex stored procedure, and instead

convert the stored procedure to a method in the

calling application. For example: let say a stored

procedure “ComputePayroll()” is invoked, the

procedure selects the employees and compute

payroll for each employee. Such type of stored

procedure can be offloaded from the database

system and should be handled at application level. In

general, legacy system may have stored procedure

like this one, but during migration this needs to be

converted into an object oriented framework at

application level for reusability.

Payroll.Initialize();

For(int i=0; i<SIZE;i++){

Employee eobj = Payroll[i];

eobj->process();

}

With this approach next time if another migration is

required, there is no changes required at the

processing level. The only change required at all is

at the database layer.

Data Transformation

This step helps in improving the performance during

migration. For example the SQL insertion is time

consuming process as it creates logs on insertion for

each transaction. In addition it requires DBMS for

carrying out the insertion. The import in local

database format is faster than DBMS insertions. The

source data must be converted to the target database

format for the target loader to understand. Let us

assume that we need to migrate a table Trade as in

source database to target. A script can be developed,

which can query the source database and insert it

into target database using SQL insertion command.

But this would take a lot of time if we are trying to

insert 50 millions of trade records. However, by

converting to the local formats like given below, and

loading it through load command we are able to

achieve tremendous performance.

Loader Format

0,20091120,"2009-11-20-11.06.21.000000","2009-11-20-

11.06.21.000000","XYZ",200000,0,0,100.50,300,0,"0",00

00030150.00

3.2 Application Transformation Layer

Application transformation layer is the crucial part

of the database migration. The application

transformation portion deals with how the new data

layout needs to be handled. It also deals with

connectivity for connecting to database and

retrieving the data. For example: DB2 has its own

driver programming API, Oracle, MySQL etc have

their own and so on.

4 MIGRATION STRATEGY

Database migration requires a suitable strategy.

Migration modelling helps easier migration and

improves the reusability. Migration may not be a

onetime activity. The business environment is very

dynamic, technologies changes are inevitable, and

the endless demand would make any application

system to migrate from one system to another with

respect to the change in business environment.

Scalable, reusable strategies are needed for today,

tomorrow and future. We define our strategy is this

paper is as follows.

1. Assessments

2. Build a target development environment

3. Model the target database

4. Model the target application

5. Transform legacy application/database

6. Build the application

7. Testing

8. Benchmark

9. Back out plan

10. Implementation

11. Monitoring and Control

5 CASE STUDY

In our case study we have conducted a migration

using tool vs. using our strategy and have done the

assessment on tool.

5.1 Results

Figure 3.0 shows the comparison of times using

inbuilt MySQL migration toolkit vs. using user

loader program.

EFFECTIVE DATABASE MIGRATION STRATEGY - THE NEED FOR ADDRESSING DATABASE MIGRATION

CHALLENGES OF TODAY, TOMORROW AND BEYOND

337

Figure 3: Table migration using load utility from Oracle to

MYSQL.

The loader program takes 4 hours compared to

migration toolkit which takes 7.5 hours for

migrating 50 millions of trade. So the tables with

high volume of data can be migrated using loader

utility, and tables with lesser volumes of data can be

easily migrated through MySQL migration toolkit.

Table 1: Comparison of Query Execution of source DB

and Target DB.

Query No.

Oracle

[Query Time

in Seconds]

MySQL

[Query Time in

Seconds]

1 1.83

6.86

2 0.58

8.07

3 3.70

300

4 2.07

6.98

5 1.49

155.26

6 1.50

312.72

Table 2: Calculation of Degree of complexity.

Type

No of Tables /

indexes/ stored

Procs / Time

required

No. of

entities

cannot be

migrated

Degree of

complexity

Max

Partition

10 1 10% 100

Indexes

10 0 0 100

Stored

Procs

20 5

(5/20*100)

25%

100

Data

volume

4 hrs 7.5 hrs 100% 100

6 CONCLUSIONS

We observed in our experiment that database

migration is a complex activity; not just a tool driven

activity. It is evident that before going for a database

migration, a thorough assessment is required which

would help to determine the degree of complexities.

In our case study, Table-2 shows the degree of

complexity involved in our database under

consideration. The first column shows type of

database objects, data volumes, and second column

denotes the total number of objects and total time

required for migration. Column 3 shows the number

of objects did not get migrated properly, and the

amount of time it took for migration to complete.

Column 4 denotes the degree of complexity

calculated (column-3 /column-2 * 100). Column 5

indicates the maximum percentage. Therefore

percentage of migration that cannot be done for the

above database using a standard tool in our case

MYSQL toolkit is (100+25+0+10)/400 * 100 = 33.7

~= 34%. Since we know now that 34% we cannot do

through tool, an analyst could easily find out what

percentage a tool can help and what percentage

manually or in-house tool development strategy is

required. Determination of degree of complexity is

lacking in today’s migration strategy. This paper

tries to show a simple way how to determine degree

of complexity which can be used for cost estimation

associated with the migration in terms of tools vs.

strategy. We can see in Table-1 how application

performance could be impacted without a proper

strategy. Migration is like a new system

development, and it should be handled with an

effective strategy as described in this paper, which

can address issues of today, tomorrow and beyond.

REFERENCES

EMC, 2007. Data Migration Considerations: A customer

Engineering Residency.

Joseph R. Hudicka, 1998. An overview of Data Migration

Methodology, http://www.dulcian.com/Articles/Over

view_Data_Migration_Methodology.htm.

Gints Plivna, 1997. Data Migration from old to new

application: an experience, Oracle.

Premier International Enterprises, 2004. Inc. Rapid

Application Development for Data Migration, 221

North LaSalle, Chicago.

Philip Howard, 2007. Data Migration, TOWCESTOR, UK

Christopher Burry, David Mancusi, Avanade, 2004. How

to plan for data migration, http://www.computerworld.

com/s/article/93284/How_to_plan_for_data_migration

?ta..

Todd Muirhead, Dave Jaffe, Paul Rad, 2005. Migrating

Oracle Database 10g from Sun server to Dell Servers,

Dell Power Solution.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

338
