WASABIBEANS

Web Application Services and Business Integration

Jonas Schulte

Heinz-Nixdorf-Institute, University of Paderborn, Fuerstenallee 11, 33102 Paderborn, Germany

Keywords:

Cooperation, Framework, Integration, Knowledge, Management, Services, SOA, WasabiBeans.

Abstract:

Albert Einstein, a German physicist borne in 1879, said: “Progress requires exchange of knowledge”. This

sentence is more relevant than ever, since projects in economy and research become increasingly complex. Due

to the information ﬂood and the growing complexity scientists all over the world do research on knowledge

management and organization. This article outlines the particular position of CSCW systems for knowledge

organization, since involving people in the process of data structuring and organization is crucial to support

(work) process and information retrieval. Furthermore, a framework will be presented to demonstrate some

innovative concepts for collaborative knowledge organization and work. The focus is on presenting the pow-

erful authentication and authorization infrastructure and means of ﬂexible user-driven repository integration

to build up complex knowledge networks.

1 INTRODUCTION

Business data of a company, latest research results

of an university or learning content in education –

these are just some of many possible examples to il-

lustrate that knowledge is the key factor in modern

society. Knowledge is created by people, managed

and shared. One contribution of computer science to

support these knowledge processes is the research on

computer supported cooperative work (CSCW) and

knowledge management (KM). Both, CSCW and KM

are very interdisciplinary and novel ﬁelds of research.

CSCW has been substantially shaped by Paul Cash-

man and Irene Greif through the ﬁrst conference on

CSCW in 1986 (Greif, 1988). In the same year the

term knowledge management was mentioned for the

ﬁrst time by Karl Wiig (Liebowitz, 1999).

Collaborative work environments are supposed to

support the coordination as well as the teamwork of

people in different places. This is mandatory to work

efﬁcient on common projects in spatially divided

teams. In (Hampel, 2001) basic (media) functions for

collaborative work environments are given. Further-

more, the author presents a basic structure to estab-

lish work environments in the digital media: the vir-

tual knowledge spaces (VKS). Using the metaphor of

a space in which knowledge is stored, structured, and

cooperatively generated, virtual knowledge spaces are

not only an implementation of the basic functions, but

also an intuitive understanding and use of the collab-

orative work environment by the user. Hence, virtual

knowledge spaces are a central concept for building

collaborative work environments for everyday use.

The concept of virtual knowledge spaces is most

helpful to the organization of knowledge in dis-

tributed environments and whenever knowledge ex-

change takes place in asynchronous work processes.

Since, asynchronous work processes can effectively

be supported by a CSCW system, it is important to

design ﬂexible cooperation support systems that ad-

dress both collaboration among people and knowl-

edge management. When considering these two re-

search ﬁelds, it is important to distinguish between

data and knowledge. Data does not make any state-

ment about its interpretation, but knowledge is the

ability to interpret the data correct (Dengel, 1994).

Justin Hibbard gave the following deﬁnition of KM

in 1997: “Knowledge Management is the process of

capturing a company’s collective expertise wherever

it resides – in databases, on paper, or in people’s

heads – and distributing it to wherever it can help pro-

duce the biggest payoff.” (Hibbard, 1997).

However, classic CSCW focus on working with

data instead of knowledge. The intention of the Wa-

saibBeans framework, presented in this article, is to

support collaborative knowledge and information or-

ganization in distributed environments. This is rel-

evant to the fact that people are knowledge carriers

348

Schulte J..

WASABIBEANS - Web Application Services and Business Integration.

DOI: 10.5220/0003509903480357

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 348-357

ISBN: 978-989-8425-56-0

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

and new knowledge is mainly produced in team work.

WasabiBeans is an implementation of the concept of

virtual knowledge spaces and bases on latest Java EE

technologies. Furthermore, the framework considers

the deep inﬂuences of the Web 2.0 on CSCW. Wasabi-

Beans does not offer a complete cooperative work en-

vironment, instead it provides functions to work with

virtual knowledge spaces. As a service-oriented ar-

chitecture (SOA) with a micro-kernel, WasabiBeans is

highly expendable and can be customized to different

ﬁelds of application. Thereby, knowledge processes

and especially the externalization of knowledge (see

Figure 1) can be facilitated. Problematic is the trans-

formation of explicit to tacit knowledge, since tacit

knowledge can not be digitalized and made persistent.

Socialization Externalization

Internalization Combination

tacit explicit

tacit

explicit

From

Figure 1: Knowledge Processes by Nonaka and Takeuchi.

To prevent this transformation of knowledge com-

puter science particularly develops solutions to sup-

port the externalization of knowledge. Externaliza-

tion means that the knowledge is extracted from the

peoples’ head and permanently stored in databases,

knowledge management systems or the like. The “de-

struction” of explicit knowledge occurs when autom-

atizing (work) processes. For example step-by-step

instructions may be unnecessary after an automatiza-

tion. The intention of the WasabiBeans framework is

to integrate various systems and applications to em-

bed efﬁcient KM into existing workﬂows.

In practice, there are numerous systems for knowl-

edge management. Often these systems are mono-

lithic and require a fundamentally restructuring of the

business processes and they are not optimized for col-

laboration and team work. The WasabiBeans frame-

work tries to ﬁll the gap between cooperation support

and knowledge organization by providing functions

for cooperation support as well as solutions for ﬂex-

ible integration of “arbitrary” (knowledge) databases

and repositories.

This article is structures as follows. In Section 2

the concept of virtual knowledge spaces is introduced.

Java Enterprise Edition, a widely used platform for

server programming in the Java programming language.

Online available: http://www.oracle.com/technetwork/java/

javaee/overview/index.html

Based on this concept the architecture of the Wasabi-

Beans framework is described in section 3. To dis-

cuss the framework more detailed section 4 will focus

on the authentication and authorization infrastructure

of WasabiBeans and section 5 explains WasabiPipes.

WasabiPipes is a pipes and ﬁlter (PaF) architecture

to connect different repositories and web applications

with the framework. This is very important for co-

operative work, since it allows the integration of all

necessary knowledge and data repositories. Finally,

the results are summarized and discussed in section 6.

2 KNOWLEDGE SPACES

Virtual knowledge spaces are a key concept to create

dynamic and ﬂexible cooperative work and learning

environments. It allows to structure the data unre-

strictedly and provides means for generating multiple

views on the same data collection (see section 2.2).

Thus, it is possible to adjust the environment exactly

to the users’ needs, without having redundancy of the

underlying data. The concept of virtual knowledge

spaces has been proven for several years and in vari-

ous ﬁelds of application (Eßmann et al., 2006). The

following section 2.1 describes the class hierarchy for

setting up virtual knowledge spaces. After that we

show how to create different views of a data collec-

tion (section 2.2).

2.1 Data Model of Knowledge Spaces

Knowledge spaces are our concept for the represen-

tation and the structuring of information within a co-

operative work process. This the concept has been

applied to various ﬁelds of application and is well-

proven due to almost ten years experience of soft-

ware development in the scope of CSCW.(Hampel

and Keil-Slawik, 2001)

The basic object structure of virtual knowl-

edge spaces is quite easy. We distinguish between

the following objects: Room

, Container, Document,

Attribute, Link, Group and User. A Room is the rep-

resentation of a real room, whereas Container can

be compared with a folder. The intention behind the

Room-object is having an object, that stands for a place

where uses can meet each other and cooperate with

each other. Furthermore spaces are intended to as-

sure awareness. Awareness is indispensable for suc-

cessful CSCW applications (Licht et al., 2003; Prinz

and Gross, 2001). Besides, the Container-object is

In the object model a Room stands for a virtual knowl-

edge space.

WASABIBEANS - Web Application Services and Business Integration

349

a lightweight construct to organize information and

correlate data. Objects of the type Document are used

as a wrapper around the real content (e.g. a picture,

a PDF ﬁle, . . . ). There is a fundamental difference

between on the one hand storing content and link-

ing it with additional information and on the other

hand combined data object that wrap content, anno-

tations, comments, access rights, and further informa-

tion. The ﬁrst option links different data to each other,

whereas the second and preferred option builds up

a common space of action. Working with combined

data object might have different advantages. For in-

stance, when creating versions of an object it is a lot

easier to generate a coherent version object of a com-

bined data object instead of creating equivalent ver-

sions of all related objects that match the combined

data object. The data model of WasabiBeans allows

free attributes at any type of object, thus the model

is highly customizable to the requirements of the cur-

rent application area. Group-, User- and Link-objects

are self-explanatory. It is mentionable, that we use

Group-objects not only for grouping users, but also

to describe roles. The concept of virtual knowledge

spaces allows to group and structure combined data

objects on a higher level. Our model allows free at-

tributes at any type of object; in this way users keep

track of their information. The WasabiBeans frame-

work is a modern service-oriented architecture imple-

menting the concept of virtual knowledge spaces.

2.2 Multiple Views on a Data Collection

Different applications require different types of data

representation. Often each application comes with its

own repository containing the related data. In this ar-

ticle the understanding of handling information in co-

operative work environments is different. An ideal

concept would be to work with one data repository

and make these data available in different ﬁeld of ap-

plication. Several reasons argue for the use of one

data collection instead of creating data redundancies.

In order to avoid problems as updating different data

collections or the distribution of changes among var-

ious repositories, the use of a common data space is

essential. When setting up an uniform data collection,

it is important to provide different interfaces. There-

fore, the concept of virtual knowledge spaces is com-

plemented with free attributes. Free attributes may be

used to store application speciﬁc values, e.g. the ob-

jects’ positions for a shared whiteboard application.

Unique and creative concepts, e.g. the pyramid

discussion for decision-making processes desire to-

tally different views and representation types (Ham-

pel and Heckmann, 2005). But even the presentation

of miscellaneous ﬁle formats beneﬁt from different

views. Image ﬁles might be displayed as a picture

gallery, whereas documents are listed alphabetically.

There are boundless possibilities to display a data col-

lection or a set of a data collection. It is obvious, that

different views are meaningful. Making one data col-

lection available in different applications requires a

sophisticated rights management (see section 4).

WasabiBeans, as an implementation of the con-

cept of VKS, intends to be a ﬂexible and adjustable

framework. In addition, it provides various interfaces

as Remote Method Invocation (RMI) or Web services

to access the data. In the following these interfaces

and the famework’s architecture are discussed.

3 ARCHITECTURAL CONCEPT

In this section the framework’s architecture is de-

scribed in general. Afterwards, section 4 describes the

authentication and authorization infrastructure and

section 5 describes WasabiBeans’ extension Wasabi-

Pipes to integrate multiple repositories.

Mail

LTM Laboratory

Modules

JCR Impl.

Internal Core

Internal Methods

WasabiPipes

Service-Consumer

MySQL Database JRC Repository

Services

Remote &

Local Interfaces

Webservices / RMI

WasabiBeans

...

EMS

AAI

Figure 2: Overview of WasabiBeans’ Architecture

Figure 2 gives an overview of WasabiBeans’ ar-

chitecture, which consists of four consecutive layers:

internal core, internal methods, services, and the re-

mote and local interfaces.

1. The internal core consists of an implementation

of the Java Content Repository (JCR)

. Accord-

ingly, the core provides all functions speciﬁed by

JCR and is responsible for data storage. Each

http://jcp.org/en/jsr/detail?id=283

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

350

Wasabi object is represented by a speciﬁc JCR

node (compare section 2.1).

2. The internal methods are implemented as static

methods have two tasks. For one thing they are

responsible for basic manipulation of the Wasabi

objects, and for another thing for the integration

of alternative data sources. More speciﬁcally, in-

ternal methods work on JCR nodes of the inter-

nal core. In addition to the internal methods for

retrieval, creation, deletion, and modiﬁcation of

Wasabi objects, there are methods for the trans-

action management, (section 3.2), the event man-

agement (section 3.3) and the version control.

3. The services layer consist of stateless session

beans. Methods of these stateless session beans

supply functions for clients to work with Wasabi

objects. For that purpose they use and combine

internal methods.

4. The fourth layer remote & local interfaces pro-

vides interfaces of stateless session beans of the

service layer. Thereby, the distinction between lo-

cal clients

and remote clients can be made.

The WasabiBeans framework is an implementation of

the concept of virtual knowledge spaces, hence a hi-

erarchical data model is necessary. In consequence of

this requirement WasabiBeans uses a JCR implemen-

tation rather than the Java Persistence API (JPA)

. In

this implementation Apache Jackrabbit

was the ﬁrst

choice, since it is an open source implementation and

fully support the JCR standard.

The technology used for managing distributed

systems with the WasabiBeans framework server is

the JBoss Application Server (JBoss AS)

, which is

an open-source technology for building, deploying,

and hosting enterprise Java applications and services.

Since the JBoss AS provides extended enterprise ser-

vices including clustering, caching, and persistence,

it forms a good base for managing distributed sys-

tems. In particular the clustering enables to use mul-

tiple WasabiBeans framework for one collaborative

system and accordingly to perform load-balancing.

JBoss AS is founded on a service-oriented micro-

kernel architecture that ensures all services are ac-

cessed, managed, and integrated in a uniﬁed and con-

sistent manner. This functionality is essential for the

WasabiBeans framework in order to fulﬁll the design

paradigm of service-oriented architectures and thus

being adaptable for various ﬁeld of application.

Local clients are deployed together with the the

WasabiBeans framework in one runtime environment.

http://www.jcp.org/en/jsr/detail?id=317

http://jackrabbit.apache.org/

http://www.jboss.org/jbossas

3.1 Main Service Methods

The main service methods provide all functions for

clients to operate on the data model. More precisely,

these methods allow to work with Data Transfer Ob-

jects (DTOs). WasabiBeans has four types of DTOs:

object, value, version, and pipeline DTOs. Object

DTOs represent Wasabi objects. Value DTOs rep-

resent the attributes as well as links. These DTOs

are also important for optimistic locking (see sec-

tion 3.2). Version DTOs stand for a version of a

version-able Wasabi object. Pipeline DTOs represent

WasabiPipelines (see section 5). Roughly, main ser-

vice methods can be divided into read and write meth-

ods. The structure of write methods is more complex,

since they have to consider locks, events, and concur-

rent writing operations that may lead to failures. The

following method invocation of the create method

of the AttributeService shows exemplary how to

generate a DTO.

WasabiAttributeDTO attributeDTO =

attributeProxy.create(<"name">, <"value">,

<dtoOfAffiliation>);

A main service method (in this example create) can

be invoked via a proxy object of the actual service. In

the sample above the proxy object is attributeProxy

of the AttributeService. This proxy object can be

created by means of a JNDI

lookup.

3.2 Transactions

Transactions are absolutely necessary for multi-user

systems. Thus, each service method is executed

by default within a Container Managed Transac-

tion (CMT). To avoid excessive transaction handling,

WasabiBeans can re-use transactions when calling a

service method within an already existing transaction.

Thereby, existing transactions can be re-used and sev-

eral service methods may be combined to a single

transaction. The following code sample illustrates

how a user can combine three method invocations to

a single transaction.

UserTransaction utx = (UserTransaction)

jndiContext.lookup("UserTransaction");

utx.begin();

try {

documentService.create("doc1", roomDTO);

documentService.create("doc2", roomDTO);

documentService.create("doc3", roomDTO);

utx.commit();

} catch (Exception e) {

utx.rollback();

}

Java Naming and Directory Interface (JNDI).

WASABIBEANS - Web Application Services and Business Integration

351

The object to control the transactions has to be re-

quested from the Java EE server via a JNDI lookup.

By means of this object the Java EE server can be in-

structed to begin, commit, or rollback a transaction.

All invocations of service methods are performed as

part of a single transaction. It should be mentioned

that WasabiBeans supports both optimistic and pes-

simistic locking mechanisms. By default it uses opti-

mistic locking.

3.3 Events

Another key feature of WasabiBeans is the event sys-

tem. A ﬂexible event system is very important for col-

laboration and cooperative knowledge management.

Users may request a notiﬁcation if a team member

changes a certain ﬁle or creates a new document. To

create, send, and receive events WasabiBeans uses an

Enterprise Message Service (EMS). The current im-

plementation allows the following events:

• REMOVED: A Wasabi object was deleted.

• CREATED: A Wasabi object was created.

• MOVED: An existing Wasabi object was moved

within the hierarchical structure.

• PROPERTY CHANGED: An attribute was

changed.

• ROOM ENTERED: An user entered a room.

• ROOM LEFT: An user left a room.

• MEMBER ADDED: An user joined a group.

• MEMBER REMOVED: An user left a group.

WasabiBeans uses JBoss HornetQ

as EMS respec-

tively as Message-oriented Middleware (MoM). The

main challenge was to ensure data privacy for the

event system. JMS lack in possibilities to deﬁne user

speciﬁc ﬁlters on global JMS queues or topics, yet

this is mandatory to prevent users from reading events

of others. The obvious solution might be the deﬁni-

tion of individual queues for each user. Actually, this

would be a secure option, but when specifying event

queues for all users (even though they are not logged

in), the application server has to manage too many

queues. This will deﬁnitely lead to performance prob-

lems. Figure 3 shows the event system of Wasabi-

Beans. Instead of deﬁning individual queues for each

user, there is a MessageDispatcher in WasabiBeans,

which divides the messages from a global queue to

temporal queues (TempDest). To receive change no-

tiﬁcations of an object three logical steps are neces-

sary. Firstly, a temporal JMS destination has to be

created. Secondly, the new JMS destination has to be

http://www.jboss.org/hornetq

WasabiBeans Framework

Message-

Dispatcher

Queue

TempDest

...

Client 1

Client 2

Client n

Services

Figure 3: Structure of the Event System in WasabiBeans.

registered in the WasabiBeans framework. Thirdly,

the user has to be registered as receiver of events for

a given Wasabi object. The second and third step are

done by means of a stateless session bean.

The advantage of this implementation is that the

number of JMS queues can be reduced to a minimum

without loosing security. Temporal queues are created

if a user logs in and subscribes to events of at least one

Wasabi object.

4 AAI-INFRASTRUCTURE

Especially for applications in the area of Computer

Supported Cooperative Work it is essential to ensure

data security. This aspect becomes even more impor-

tant if the CSCW application is used for safety critical

business areas, e.g. knowledge management.

4.1 Characteristics of Access Rights

There exist seven different kinds of permissions in

WasabiBeans: VIEW, READ, EXECUTE, COM-

MENT, INSERT, WRITE, and GRANT. A permis-

sion alone does not have any impact, instead it is a

property of a complete right. Due to this fact, Wasabi-

Beans uses discretionary access control lists. Every

right should have at least the following properties:

• allocation to a speciﬁc subject;

• kind of permission;

• allocation to a speciﬁc object

;

This basic structure may be extended. As an addi-

tional property, we can consider the following one:

• type of right (allowance or forbiddance);

Here a forbiddance is deﬁned to be more powerful

than an allowance. Resulting from this, a forbid-

dance may overlap an allowance, since more than

one relevant right for a speciﬁc relation of Subject–

Permission–Object can be deﬁned. This may occur

In WasabiBeans, the rights are stored directly in the ob-

jects they are allocated to.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

352

when setting group rights. In this manner, the prop-

erty

• status of hierarchy;

is also important. If the authorization function dis-

covers more than one relevant right, the system has to

decide which right is preferred.

There is the rule that a forbiddance is preferred to

an allowance when belonging to the same hierarchy

level. Assuming the levels forbiddance and allowance

constitute their own hierarchy, this implicates the ef-

fective number of hierarchy levels is twice compared

to the number of explicit ones. It should be obvious,

that without forbiddance the generation of different

hierarchy levels is needless. Resulting a right may

have three different conditions: It can be either an al-

lowance, a forbiddance, or not speciﬁed.

As an additional property a time interval can be

speciﬁed for rights in WasabiBeans. Section 4.4 ex-

plains the consequences to the authorization infras-

tructure that are accompanied by temporal access

rights. In the following, different criteria that have

to be interpreted for the validation of an access right

are discusses.

4.2 User Access Rights

An access right always refers to a speciﬁc WasabiUser

object. It assesses an operation for which the user is

authorised on the speciﬁc data object or for which he

is forbidden. Because of the fact that a WasabiBeans

environment may contain plenty of different users, it

is not practicable to allocate each conceivable right as

a user right. To simplify the right allocation, Wasabi-

Beans offers to specify group rights (see section 4.3).

4.3 Group Access Rights

Within its function, a group right is similar to a user

right, with the difference that it is not granted to a

speciﬁc user, but a whole group of users. Because of

this fact, it is sufﬁcient to be a member of the spe-

ciﬁc group or the corresponding subgroups to gain

all associated allowances and forbiddances. Further-

more, there must be a mechanism or rules, that specify

which access right is prioritized. This problem may

happen in various situations, e.g. if a user is member

of two different groups. As a member of group A the

user may get an allowance for a certain document, but

as member of group B the user may get a forbiddance

for the same document. To solve this problem there

is a hierarchy (or rules) that specify which right type

has to be prioritized. Figure 4 illustrated the eight dif-

ferent right types in WasabiBeans.

Time Right

Unlimited Right

User Right

Group Right

Forbiddance

Allowance

Explicit

Tacit

Period of Validity Realm Right Type Ancestry

High

Low

Figure 4: Hierarchy of Access Rights.

By the concept of group rights it is possible to de-

ﬁne special ﬁelds of responsibility. For example, a

group can be created whose members may access on

special parts of the object tree to perform well deﬁned

operations there. If we want to allocate some users

for this ﬁeld of responsibility, we only need to assign

them to this group. A declaration of additional user

rights is not necessary.

4.4 Time-based Access Rights

As a difference to the common inﬁnite rights, a time

based right is only valid for a certain interval. This

means, it is similar to a common right which is ex-

panded by a starting point and an ending point. These

two points in time are expressed in the number of mil-

liseconds, which are elapsed since the ﬁrst January

1970. Referring to this, a time right gets in use if

the actual computer time is inside this interval. In a

regular case, interferences with other time rights are

always avoided by the system. This means, if a new

time right is granted, whose interval overlaps at least

one of another relevant time right, this interval may

be shortened. In an extreme case, it may also be split

in two other time rights or totally annulled.

If we abstain from the concept of time rights,

a temporary allowance or forbiddance must always

be initiated by the administrator to the designated

point of time and annulled at another point of time.

Thereby, the administrative effort would be elevated

and the ﬂexibility of the system would be decreased.

4.4.1 Overlapping Access Rights

As it was already mentioned in this section 4.4, by

the initiation of new time rights, there may occur in-

consistencies to other time rights which already ex-

ist. These inconsistencies are dissolved by preferring

the new time right. This means, it may overlap ex-

isting rights. To ensure this, before the initiation the

system must check every available time right which

contains the same user or group name and the same

allocated object. Now the interval of the new right

becomes compared with the one of the old right. It

is N = (N

, N

) the interval of the new time right

and O = (O

, O

) the interval of the old time right.

There is the condition N

≤ N

and O

≤ O

. Now

WASABIBEANS - Web Application Services and Business Integration

353

we can divide between the following cases (the above

cases exclude the below cases, the system works in

sequence during the check):

1. N

< O

or N

> O

→ There are no difﬁculties

because the two intervals do not interfere.

2. N

≤ O

and N

≥ O

→ The old time right be-

comes replaced by the new one.

3. N

≤ O

and N

< O

→ The old time right is

shortened on (N

+ 1, O

4. N

> O

and N

< O

→ The old time right has

to be split in two sub-rights with the intervals

, N

− 1) and (N

+ 1, O

5. N

> O

and N

≥ O

→ The old time right be-

comes shortened on (O

, N

− 1).

4.5 Unlimited Access Rights

An unlimited right has got the same function as a time

right with the difference, that there is given no inter-

val. Of course there is the possibility to abstain from

unlimited rights and to generate each right as a time

right. By this case, an unlimited right would be a time

right with the highest possible interval. But such a de-

cision leads to a problem: If we generate a new time

right, an old, virtual unlimited right which collides

with it, has to be split in two sub-rights (see 4.4.1).

From this, the following disadvantages result:

• The old, once unlimited right should be deleted →

Now we have to delete two sub-rights.

• The new time right should be deleted → This re-

sults in a gap.

As a consequence, we generate two different layers

for the differentiation of time rights and clearly un-

limited rights. The time based layer should be above

the unlimited one, because it can be considered as

more special. The ﬁgure 5 should illustrate this con-

cept. Another advantage of it results from the fact that

we always have the possibility of a clearly abdication

from time based rights.

Unlimited Right

Time Right 1

Time Right 2

Time graded access trials

Figure 5: Time-based Access Rights.

4.6 Inherited Access Rights

The adjustment of data inside a tree structure suggests

that access rights may be passed from a high into a ju-

nior instance, which can be considered as inheritance.

If we abstain from this possibility, it is necessary to

grant explicit rights for each single data object which

increases the administrative effort. In addition to this,

on ordinary scenarios we often have got the case, that

all objects inside a junior structure have the same or

at least very similar rights. The possibility of inheri-

tance should support this.

Basically, we have got the principle that with two

or more relevant rights within the same triple relation-

ship (subject, permission, object), always the right

which is nearer to the target object has got priority.

This means, if there are for example two containers

above a WasabiDocument, in which is in each case

indicated a right for the same user, the right of the

lower container is preferred. If there is even a colli-

sion of an inherited right with an explicit right, the in-

heritance may not occur. For time rights, there again

is the principle that the rights with the shorter distance

to the speciﬁc object may shorten, occlude or divide

the intervals of the rights with the larger distance.

The concept of inheritance together with hierarchy

for access rights allows to modify rights without high

administrative effort.

5 WASABIPIPES: A PIPELINE

EDITOR FOR WASABIBEANS

This section describes WasabiPipes, a dynamic and

adjustable solution to integrate various repositories.

WasabiPipes bases an the Pipes and Filter (PaF) ar-

chitectural pattern that divides the tasks of a system

into several sequential processing steps. A common

deﬁnition for this pattern is given by Buschmann et al.

“The Pipes and Filter architectural pattern provides

a structure for systems that process a stream of data.

Each processing step is encapsulated in a ﬁlter com-

ponent. Data is passed through pipes between ad-

jacent ﬁlters. Recombining ﬁlters allows you to

build families of related systems.” (Buschmann et al.,

1996).

Inspired by Yahoo Pipes, a service that is normally

used to assemble RSS

feeds, WasabiPipes is imple-

mented as an extension of the WasabiBeans frame-

work. Nevertheless, this concept to integrate differ-

ent repositories is not limited to WasabiBeans and

RSS 2.0 Speciﬁcation: http://www.rssboard.org/rss-

speciﬁcation

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

354

can easily be adapted to other purposes and infras-

tructures. Yahoo Pipes allows to handle (information)

sources, mix them up, and modify the data using ﬁl-

ters. It does not only support the connection of ﬁl-

ter modules but also the connection of single ﬁelds of

ﬁlter modules. Therefore, very complex and ﬂexible

pipelines can be assembled. Thus, Yahoo Pipes is a

powerful composition tool to aggregate, manipulate,

and mashup content from around the web (Yahoo!,

2010). Exactly this understanding of aggregating and

connecting information goes along with the intention

to integrate different repositories in a complex IT in-

frastructure to set up a powerful cooperative work and

learning environment. Similar to the Web 2.0 mashup

concept

, the intention is to aggregate various repos-

itories to a new high-level collection of information.

The current implementation of WasabiPipes in-

cludes the binding of seven different repository types.

So far Apache Jackrabbit, Amazon web services

Google Docs, Flickr, YouTube, common ﬁle systems,

and databases can be connected using via the PaF ar-

chitecture. Basically, ﬁlters are mapped in Wasabi-

Pipes through the abstract class Filter, the interfaces

Source, Sink, ContentStore, and the classes Wire,

Sink.Input, Source.Output.

• Source: All ﬁlters that deliver data have to im-

plement the Source interface, which procures

the method void connect (Source.Output output,

Sink.Input input).

• Sink: All classes that deﬁne inputs; have to im-

plement the Sink interface. The method ﬁlter will

be invoked by the previous ﬁlter and is responsi-

ble for the processing logic.

• ContentStore: A ContentStore offers a method

to retrieve stored data.

• Sink.Input: An input of a ﬁlter is deﬁned by the

Sink.Input class. This class contains a reference

to both, the ﬁlter and the name of the input.

• Source.Output: Analog to the class Sink.Input,

the class Source.Output procures an output.

• Wire: The class Wire connects an output with an

input.

• Filter: The abstract class Filter includes basic

functions. The method forward can be invoked

by any subclass. Afterwards it invokes all de-

pendent ﬁlters that are connected with the out-

put speciﬁed via the parameter. This class is also

A Web 2.0 mashup is a (re-)combination of existing

services to an aggregated new service that provides ad-

ditional functions by combining the functionalities of the

original services.

checks whether the execution is synchronous or

asynchronous.

• ConcreteSource: This class has an output and

invokes the method ﬁllPipeline, thus the pipeline

can be ﬁlled data. After completion this method

invokes the forward method of the superclass to

forward the data within the pipeline.

• ConcreteFilter: This class deﬁnes two inputs and

two outputs. Within the ﬁlter method data are for-

warded from input1 to output2 and from input2

to output1. The inputs and outputs are crossover

connected.

• ConcreteSink: Finally, this class dumps the data

of both inputs. Additionally, it reports which input

passed the data.

For the implementation of WasabiPipes the JavaScript

library WireIt

was used. WireIt allows to store

the wiring states in the JavaScript Object Notation

(JSON)

format. A sample JSON description of a

MIME type ﬁlter is given in section 5.3.

5.1 Concrete Filter Implementations

To create a better understanding of ﬁlter implemen-

tations, the MimeFilter and the YouTubeSink are dis-

cussed exemplarily below.

The MimeFilter consists of one input, two outputs

(MATCH and NOMATCH), and a ﬁeld to specify the

MIME type. The method ﬁlter compares the MIME

type of the document and the one deﬁned as ﬁlter pa-

rameter. In case of a matching MIME type the data

are forwarded to the MATCH output, otherwise to the

NOMATCH output. Afterwards, the method forward

of the super class Filter is invoked to notify all depen-

dent ﬁlters about the result.

The YouTubeSink allows uploading videos directly

from WasabiBeans to YouTube. However, the upload

isn’t straightforward and needs some special param-

eters. For authentication purpose YouTube requires

a developerKey, a consumerKey, and a correspond-

ing consumerSecret (a private key). The keys can

be requested on the Google website. In addition an

accessToken with a matching accessTokenSecret for

the user is mandatory. YouTube provides an OAuth

service to afford this token. Unfortunately, YouTube

offers read access only; hence the content is not di-

rectly accessible through WasabiBeans. Accordingly,

the getContent method is not implemented yet. Other

repositories, such as the Amazon web services

don’t lack of a method to retrieve the content. In that

http://javascript.neyric.com/wireit

JSON is a lightweight data-interchange format. Online

available: http://www.json.org/

WASABIBEANS - Web Application Services and Business Integration

355

Figure 6: The Pipeline-Editor.

case we can request the data directly from the inte-

grated repository and show it within WasabiBeans’

GUI.

5.2 A Graphical User Interface to

Connect Repositories

WasabiPipes is accessible via the WasabiBeans ad-

ministration GUI. Figure 5.2 shows the editor, that al-

lows creating and managing pipes for specifying the

data ﬂow. The WasabiPipes editor consists of ﬁve

main parts.

1. A toolbar to create, load, save, and delete pipes.

Additionally the interface supports a help button

for unpracticed users.

2. In the left area the modules are available. Modules

are ﬁlters, data storages, embedded, and start/end

components. Users can reuse these modules via

simple drag-and-drop action. It should be men-

tioned, that it is possible to save pre-deﬁned pipes

as embedded modules and use them in more com-

plex conﬁgurations. Thereby, different pipes can

be nested and a clear overview of the entire con-

ﬁguration can be guaranteed.

3. This is the main working area to arrange the com-

ponents and specify the sources, ﬁlters, and sinks.

4. In this area users can add some additional meta

data, e.g. title and description to the designed

pipe.

5. To ensure a clear overview of large pipes we also

offer a mini map, marked with 5.

5.3 JSON Description of MimeFilter

{

"name": "MimeFilter",

"category": null,

"container": {

"xtype":"WireIt.InOutFormContainer",

"inputs":[{"name":"INPUT"}],

"outputs":[{"name":"MATCH"},

{"name":"NOMATCH"}],

"field":[{"type":"string",

"inputParams":{

"label":"mimeType",

"name":"mimeType",

"required":true,

"value":null

}},{

"type":"boolean",

"inputParams":{

"label":"asynchronous",

"name":"asynchronous",

"required":false,

"value":false

}}

]

}

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

356

6 CONCLUSIONS

Since collaborative activities are very similar in var-

ious ﬁelds of application, a CSCW system should

be ﬂexible and adaptable for the usage in differ-

ent ﬁelds of application. Although there are com-

mon CSCW tools (e.g. Blackboard

and Moodle

)

there is a demand for integrating existing applica-

tions to achieve system convergences (Papazoglou

and van den Heuvel, 2007). WasabiBeans is a ﬂexible

framework to maintain the implementation of cooper-

ation support environments by integrating existing ap-

plicaitons. In addition, WasabiBeans provides func-

tions to work efﬁcient in virtual knowledge spaces.

Due to the ﬂexible SOA, WasabiBeans is ready for

the next generation of CSCW applications. The ob-

ject model with free annotations is optimized for ad-

justable knowledge management.

Web 2.0 evolutions have placed a new focus on

current CSCW developments. New technologies (e.g.

RSS feeds, tagging, etc.) have to be integrated in an

existing architecture to serve the demands of semantic

knowledge structuring. The presented WasabiBeans

framework is able to adapt multiple Web 2.0 services

and systems in ﬂexible and scalable manner. Beyond,

the extension WasabiPipes, a pipes and ﬁlter architec-

ture, allows the integration of heterogeneous reposito-

ries. By means of encapsulated functionality and iso-

lated ﬁlters it was possible to provide highly parallel

operations and data transfer. In particular, when in-

tegrating external services this is beneﬁcial. Thereby,

the execution of further ﬁlters is enabled, even if the

system is waiting for the completion of an upload.

During the Web 2.0 era more and more services were

offered and APIs are ubiquitous in the Internet. The

most prominent sample is Google with its services

(YouTube, Google Docs, . . . ), which can interact by

way of using the common interface gdata. Coopera-

tion and knowledge management supporting systems

have to meet the challenge of integrating this wide

range of different repositories, since knowledge man-

agement bases on information sharing and a common

persistent data repository.

REFERENCES

Buschmann, F., Meunier, R., Rohnert, H., Sommerlad, P.,

and Stal, M. (1996). Pattern-oriented Software Archi-

tecture - A System of Patterns. John Wiley & Sons,

Chichester.

http://www.blackboard.com/

Moodle is a Learning Management System (LMS),

http://moodle.org/.

Dengel, A. (1994). K

unstliche Intelligenz - Allgemeine

Prinzipien und Modelle. BI-Taschenbuchverlag,

Mannheim.

Eßmann, B., Hampel, T., Goetz, F., and Elsner, A. (2006).

Embedding collaborative visualizations into virtual

knowledge spaces. In 7th International Conference

on the Design of Cooperative Systems, page 3340,

France, Provence.

Greif, I. (1988). Computer-Supported Cooperative Work:

A Book of Readings. Morgan Kaufmann Publishers,

Inc., Santa Mateo, CA, USA.

Hampel, T. (2001). Virtuelle Wissensr

aume - Ein Ansatz

ur die kooperative Wissensorganisation. Dissertation,

Universit

at Paderborn.

Hampel, T. and Heckmann, P. (2005). Deliberative han-

dling of knowledge diversity the pyramid discussion

and position-comentary-response methods as speciﬁc

views of collaborative virtual knowledge spaces. In

Proceedings of Society for Information Technology

and Teacher Education, 16th International Confer-

ence Annual, SITE 2005, Arizona, USA.

Hampel, T. and Keil-Slawik, R. (2001). sTeam - designing

an integrative infrastructure for web-based computer-

supported cooperative learning. In Proceedings of the

10th International Conference on World Wide Web,

pages 76–85.

Hibbard, J. (1997). Knowing What We Know. Information-

Week - The Business Value of Technology.

Licht, T., Schmidt, L., and Luczak, H. (2003). Goal

awareness in distributed cooperative work settings. In

Luczak, H. and Zink, K. J., editors, Human Factors in

Organizational Design and Management VII (Aachen

2003), pages 329–334, Santa Monica. IEA Press.

Liebowitz, J., editor (1999). Knowledge Management

Handbook. Boca Raton, Adelphi, USA.

Papazoglou, M. P. and van den Heuvel, W.-J. (2007). Ser-

vice oriented architectures: Approaches, technolo-

gies and research issues. Very Large Data Bases,

16(3):389–415.

Prinz, W. and Gross, T. (2001). Ubiquitous awareness of co-

operative activities in a theatre of work. In Bode, A.

and Karl, W., editors, Fachtagung Arbeitsplatzcom-

puter: Pervasive Ubiquitous Computing, pages 135–

144. APC.

Yahoo! (2010). Yahoo! pipes – http://pipes.yahoo.com/

pipes.

WASABIBEANS - Web Application Services and Business Integration

357
