APPLYING ASPECT ORIENTED PROGRAMMING

IN USABILITY ENGINEERING PROCESSES

On the Example of Tracking Usage Information for Remote Usability Testing

Andreas Holzinger, Martin Brugger

Research Unit Human–Computer Interaction, Institute for Medical Informatics, Medical University Graz, Graz, Austria

Wolfgang Slany

Institute for Software Technology, Graz University of Technology, Styria, Austria

Keywords: Aspect oriented programming, Usability engineering, Remote usability testing.

Abstract: Usability Engineering can be seen as a crosscutting concern within the software development process.

Aspect Oriented Programming (AOP) on the other hand is a technology to support separation of concerns in

software engineering. Therefore it stands to reason to support usability engineering by applying a

technology designed to handle distinct concerns in one single application. Remote usability testing has been

proven to deliver good results and AOP is the technology that can be used to streamline the process of

testing various software products without mixing concerns by separating the generation of test data from

program execution. In this paper we present a sample application, discuss our practical experiences with this

approach, and provide recommendations for further development.

1 INTRODUCTION

The concept of Aspect Oriented Programming

(AOP) describes a development methodology for

separating crosscutting concerns during software

development (Kiczales et al., 1997), (Furfaro et al.,

2004) and has been applied in business applications

(Di Francescomarino and Tonella, 2009).

In contrast to Object-oriented programming

(OOP), where the common functionality is pushed

up in the hierarchy tree, AOP separately defines

such aspects and uses an AOP environment to

manage the correct composition to a single

executable program. (Elrad et al., 2001) distinguish

aspects from high-level concerns such as security

and quality of service down to low-level concerns

similar to caching and buffering. The separation of

concerns can lead to a cleaner system design and

implementation.

Usage logging for remote asynchronous usability

testing is a typical application for AOP allowing

easy integration into existing software systems

(Tarby et al., 2007).

Due to the transparent invocation of aspects no

additional complexity has to be added during regular

development of a software program. Depending on

the software development language, AOP can even

be applied to black-box systems.

Figure 1 shows a good example of shared

concerns across independent OOP classes on the

example of a medical application (shaded area).

Figure 1: Example from healthcare: Three classes included

in a patient record system along with some of the core

methods for managing patient information: shaded areas

show the methods required to implement the secondary

statistics concern (Sommerville, 2010).

2 RELATED WORK

Originally, (Kiczales et al., 1997) found in their

Holzinger A., Brugger M. and Slany W..

APPLYING ASPECT ORIENTED PROGRAMMING IN USABILITY ENGINEERING PROCESSES - On the Example of Tracking Usage Information for

Remote Usability Testing.

DOI: 10.5220/0003523800530056

In Proceedings of the International Conference on e-Business (ICE-B-2011), pages 53-56

ISBN: 978-989-8425-70-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

work many programming problems for which

neither procedural nor object-oriented programming

techniques were sufficient in capturing design

decisions, resulting in “tangled” program code

which is difficult to maintain. Kiczales et al.

presented an analysis of why certain design

decisions are so difficult to capture in actual code

and called these properties “aspects”. They showed

that the reason they have been hard to capture is that

they cross-cut the system's basic functionality.

Consequently, they developed a new programming

technique, called AOP, which makes it possible to

clearly express programs involving such aspects,

including appropriate isolation, composition, and

reuse of the aspect code.

Object-oriented programming (OOP) proved to

be a well-established and modern technology to

model real domain problems. Some problems

demand difficult design decisions as their nature do

not fit well the OOP approach. The programming

technique of AOP supports the problem nature of

cross-cutting concerns as an extension to OOP.

(Tarby et al., 2007) report, concerning the types

of application, that the AOP approach currently can

trace any application written in Java and supporting

AspectJ, where traced applications are today mainly

interactive applications (WIMP – windows, icons,

menu, pointing).

(Kojarski and Lorenz, 2007) present a practical

composition framework, called AWESOME, for

constructing a multi-extension weaver by plugging

together independently developed aspect

mechanisms. Their framework has a component-

based and aspect-oriented architecture that facilitates

the development and integration of aspect weavers.

In a practical implementation they demonstrated the

construction of a weaver for a multi-extension AOP

language that combines COOL and AspectJ;

however, the composition method is not exclusive to

COOL and AspectJ – it can be applied to combine

any comparable reactive aspect mechanisms.

3 REMOTE ASYNCHRONOUS

USABILITY EVALUATION

Good usability is meanwhile accepted as a key

factor for success of every application whether it is a

typical e-Business application (Calisir et al., 2010)

or a safety critical application in e-Health where it is

clearly demonstrated that bad usability can cause

serious problems (Rolleke, 2009), (Nielsen, 2005).

Usability is most often defined as the ease of use

and acceptability of a system for a particular class of

users carrying out specific tasks in a specific

environment; whereas ease of use affects the end

users' performance and satisfaction, acceptability

affects whether the product is used or not. One of the

basic lessons we have learned in human-computer

interaction (HCI) is that usability must be considered

before prototyping takes place. The earlier critical

design flaws are detected, the more likely they can

be corrected. Thus, user interface design should

more properly be called user interface development,

analogous to software development, since design

usually focuses on the synthesis stages, and user

interface components include metaphors, mental

models, navigation, interaction, appearance, and

usability (Holzinger, 2005).

Still the process of usability engineering and its

iterative approach is often costly and time

consuming. Using automation to decrease time and

costs of usability evaluations therefore directly

impacts the economic success of products. The

process of usability evaluation can described by the

activities following activities (Ivory & Hearst,

2001):

• Capture: collecting usability data

• Analysis: interpreting usability data

• Critique: suggesting solutions

Using AOP the “capture” phase is directly

influenced as the effort to collect information can be

drastically reduced while the quality of usability data

can be increased and easily customized. Therefore

also the other activities benefit of AOP indirectly.

Collecting Usage Information

In Usability Engineering the task of automatic

capturing of usability data can be greatly enhanced

by the usage of AOP. Within the scope of this work

the application of AOP does not cover a whole

usability engineering process. The technology can be

applied across several usability evaluation methods

during the “Capture” automation type mentioned in

(Ivory and Hearst, 2001). Also the distinction of

WIMP (windows, icons, pointer, and mouse) and

Web interfaces applies to this contribution as we

focus on current client technologies. The current

progress in web technologies mitigates this

distinction as modern Javascript powered web

applications also allow powerful client-side

applications where AOP could be applied to collect

usage information.

4 SAMPLE IMPLEMENTATION

Using AOP to collect usage information is the

ICE-B 2011 - International Conference on e-Business

main focus of this work. Therefore a sample

application has been developed taking advantage of

AOP. Given the current popularity of Objective-C

(OBJC) because of the iOS platform and the lack of

a maintained and publicly available AOP

implementation, the sample application was

implemented using the MacOS/iOS platform and

Objective-C 2.0. The OBJC runtime allows easy

integration of AOP with minimal changes to the

original program, which is very important to allow

an easy integration into existing projects.

Nevertheless this concept can be transferred to other

platforms without difficulties.

4.1 Sample Application

The sample application was developed to evaluate

different input methods in an application for script

breakdown. Pre-selection heuristics (PSH) were

used to enhance the tedious task of text selection.

Another mechanism to speed up script breakdown is

Auto-advancing short-key (AAS) tagging which was

the main focus to be tested. AAS automatically

advances the selection to the next text passage after

classification of a text component identified by the

PSH. Within the test the acceptance of these

technologies should be validated.

As the software is targeted at a very specific

audience a standard laboratory usability test would

not have been able to be performed within a

reasonable time frame. For this specific test a self

contained software package has been developed to

be distributed among the target group. The

invitations to the test were distributed as personal

invitation via email, the results were automatically

transmitted by the test software. Several domain

experts across Europe were invited to participate in

the test. The self contained test setup allowed the

test to be performed in the natural working

environment of the target group. Each test consisted

of a background information form for gathering

statistical data, a tutorial document presenting the

different input methods, the actual test and a SUS

feedback questionnaire.

Aspects have been implemented to track

interface events of keyboard input (AAS), context

menus, and drag and drop actions. A centralized

logging facility was used to persistently store log

output. A custom plain text format was used for

better readability of the log output. For automated

processing an XML format could easily be created

by exchanging the Logger class. Within the logged

data the quality of AAS could be measured by

identifying user corrections to the proposed

selections by the AAS mechanism.

4.2 Definition and Implementation of

Aspects

Adding aspects to the given object hierarchy was

achieved using a technology called “method

swizzling” offered by the OBJC runtime. Aspect

functionality was achieved by implementing

categories to existing classes. Categories allow the

extension of existing classes without inheritance and

knowledge of the original class source-code

providing access to the internal state of an object.

Therefore this technology suits the AOP approach

very well, separating the original functionality from

aspect behavior. For weaving aspects to the existing

OOP model, the OBJC runtime exchanges all calls

to methods defined in a configuration, with aspect

code altering the actual execution of the program.

The configuration is defined in the property list

format using dictionaries and arrays to define

aspects for selected classes.

Figure 2: Sample configuration for adding aspects to

existing classes.

4.3 Application Design

OBJC emerges to support the implementation to

AOP very well. Only one additional class is

necessary for reading the aspect configuration and

managing the aspect weaving. Using the provided

configuration aspect methods are exchanged with

the original methods at runtime. The aspect is also

responsible for calling the original method. This can

easily break the original application behaviour, still

allowing alteration of the program execution.

Implementing an alternate approach only allowing

pre- and post-method invocations should also be

taken into consideration. To the original Application

the addition of AOP is completely transparent. The

second class used as AOP infrastructure is the logger

itself. It is not directly AOP related but an essential

addition to the original application. Three aspects

are necessary to identify all necessary user interface

events. In a blackbox system aspects can be attached

APPLYING ASPECT ORIENTED PROGRAMMING IN USABILITY ENGINEERING PROCESSES - On the Example

of Tracking Usage Information for Remote Usability Testing

to known base classes to log information on a low

level. If additional information about the application

design exists, customized aspects can be developed.

OBJC has several tools for analyzing binary

applications at runtime. F-Script is a well-known

tool revealing enough information about almost any

application to allow easy integration of AOP into

existing applications.

5 CONCLUSIONS

As in the definition of AOP, the term cross cutting

concern can be perfectly applied to usability

engineering interests. The concept of AOP therefore

is perfectly suitable for adding data collection

facilities to existing applications for usability testing.

AOP is also easily portable to other programming

languages and the application within this paper just a

sample for how easy it is to reduce the effort for

usability testing. A best case scenario reduces code

to a single implementation of a shared concern

across all relevant classes without increasing code

complexity. Still the evaluation of the gathered data

is a challenging task. Automatic processing of

collected data is essential as large volumes can

easily be gathered. Several usage patterns like

repetitive operations on a single element were

identified hinting at usability issues. Also the

detection of heavily used features can be used to

further increase the user satisfaction by optimizing

these workflows and every change can be evaluated

afterwards for its effectiveness. A downside of the

easy application of AOP is related to privacy

concerns. Collected data should always be

anonymized and the least amount of sensitive

information should be recorded. A user notification

and opt-in mechanism is mandatory, in order to

avoid negative user experiences.

ACKNOWLEDGEMENTS

We thank Karl Heinz Struggl for the technical

support in implementation of the sample application.

REFERENCES

Calisir, F., Bayraktaroglu, A. E., Gumussoy, C. A., Topcu,

Y. I. & Mutlu, T. (2010) The relative importance of

usability and functionality factors for online auction

and shopping web sites. Online Information Review,

34, 3, 420-439.

Di Francescomarino, C. & Tonella, P. (2009) Cooperative

Aspect Oriented Programming for Executable

Business Processes. New York, IEEE.

Elrad, T., Filman, R. E. & Bader, A. (2001) Aspect-

oriented programming - Introduction. Communications

of the ACM, 44, 10, 28-32.

Furfaro, A., Nigro, L. & Pupo, F. (2004) Multimedia

synchronization based on aspect oriented

programming. Microprocessors and Microsystems, 28,

2, 47-56.

Holzinger, A. (2005) Usability engineering methods for

software developers. Communications of the ACM, 48,

1, 71-74.

Ivory, M. Y. & Hearst, M. A. (2001) The state of the art in

automating usability evaluation of user interfaces.

ACM Computing Surveys (CSUR), 33, 4, 470-516.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C., Loingtier, J. M. & Irwin, J. (1997) Aspect-

oriented programming. In: Aksit, M. & Matsuoka, S.

(Eds.) Ecoop'97: Object-Oriented Programming.

Berlin 33, Springer-Verlag Berlin, 220-242.

Kojarski, S. & Lorenz, D. H. (2007) AWESOME: An

aspect co-weaving system for composing multiple

aspect-oriented extensions. ACM Sigplan Notices, 42,

10, 515-534.

Nielsen, J. (2005), Medical Usability: How to Kill Patients

Through Bad Design In: Jakob Nielsen's Alertbox,

April 11. Online available: http://www.useit.com/alert

box/20050411.html, last access: 2011-01-13

Rolleke, T. (2009) Incident reports to BfArM support the

importance of usability for patient safety. In: Dossel,

O. & Schlegel, W. C. (Eds.) World Congress on

Medical Physics and Biomedical Engineering, Vol 25,

Pt 12. New York, Springer, 298-300.

Sommerville, I. (2010) Software Engineering 9. New

York, Addison-Wesley.

Tarby, J. C., Ezzedine, H., Rouillard, J., Tran, C. D.,

Laporte, P. & Kolski, C. (2007) Traces using aspect

oriented programming and interactive agent-based

architecture for early usability evaluation: Basic

principles and comparison. In: Jacko, J. A. (Ed.)

Human-Computer Interaction, Part 1, Interaction

Design and Usability. Berlin, Springer-Verlag Berlin,

632-641.

ICE-B 2011 - International Conference on e-Business
