PRACTICAL ANONYMOUS AUTHENTICATION

Designing Anonymous Authentication for Everyday Use

Jan Hajny, Lukas Malina and Vaclav Zeman

Department of Telecommunications, Brno University of Technology, Purkynova 118, Brno, Czech Republic

Keywords:

Anonymity, Privacy, Authentication, Efﬁciency, Responsibility, Smart-cards.

Abstract:

We use authentication services many times a day. Without user authentication, it would be impossible to use e-

mail accounts, discussion boards, e-banking or even electronic communication. On the other hand, we release

a lot of personal information during every authentication process. Our login can be linked to used services and

assets by service providers. The frequency of usage and therefore the map of our behaviour on the Internet

can be created to make more focused advertisement, to track us or even to steal our electronic identity. The

goal of this paper is to state the requirements and provide the initial design for an anonymous authentication

scheme which prevents the leakage of private information. The new scheme, to be widely acceptable, must

be beneﬁcial for both users and service providers, who implement the authentication systems. Therefore we

claim that the new authentication system must provide a feature for revealing dishonest users. These users can

be eventually deanonymized and charged for damages. We provide such a responsibility-protecting feature in

our scheme. We also compare our scheme design with current anonymous authentication schemes and provide

initial performance results from our smart-card implementation.

1 INTRODUCTION

By providing a scheme introduced in this paper, we

would like to encourage Internet service providers to

implement anonymous authentication protocols be-

cause it is no more inconvenient for them. By us-

ing our scheme, they do not loose their ability to

identify attackers and dishonest users. On the other

side, their honest users can be now anonymously ver-

iﬁed as members of the group of valid clients (e.g.,

clients who paid for the service). This can be done

efﬁciently and with the use of hardware available to-

day. To prove this, we provide results from the imple-

mentation on off-the-shelve .NET smart-cards, which

are widely available for purchase. We would like to

stress that we used the smart-cards and the framework

without any modiﬁcation, thus without need for any

changes in standards.

1.1 Related Work

We ﬁnd anonymous authentication systems, e.g., the

scheme by Schaffer and Schartner (Schaffer and

Schartner, 2006), to be the most related systems.

These schemes allow anonymous authentication but

often rely on trusted third parties. The mentioned

scheme is based on a device which must be trusted

not to reveal private information. We would like to

avoid such design. The second common problem is

repeated authentication. Using existing schemes, the

user cannot be authenticated inﬁnitely many times

without re-initialization. Our scheme provides un-

limited number of authentication sessions without the

need to repeatedly connect the smart-card to user’s

PC.

The credential systems, represented by (Lysyan-

skaya, 2001; Camenisch and Lysyanskaya, 2003; Ca-

menisch and Van Herreweghen, 2002; Bichsel et al.,

2009), are also usable for anonymous authentication.

Although these systems can be used in many scenar-

ios for privacy protection, only some of them provide

real identity revelation of dishonest users. Such fea-

ture is provided in theory (Camenisch and Lysyan-

skaya, 2003) but the implementation would be very

inefﬁcient or even impossible on current smart-cards.

1.2 Our Contribution

Our goal is to provide a universal system which will

be convenient for both users and service providers.

As existing work is focused on either users or service

providers, their schemes are often hard to implement

405

Hajny J., Malina L. and Zeman V..

PRACTICAL ANONYMOUS AUTHENTICATION - Designing Anonymous Authentication for Everyday Use.

DOI: 10.5220/0003576404050408

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2011), pages 405-408

ISBN: 978-989-8425-71-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

since they are not acceptable by both groups. In con-

trast to these existing schemes, we provide a scheme

where honest users can anonymouslyaccess restricted

services of service providers while providers can still

de-anonymize dishonest users and make them respon-

sible for their acts. This solution comes at no extra

performance cost in comparison to existing schemes.

In fact, our scheme is more efﬁcient than most com-

mon anonymous authentication solutions and is prac-

tical even on slow devices like smart-cards.

We also focus on the security of the scheme. The

building blocks are based on provable cryptography,

so the scheme can be analysed from the security point

of view and the proofs of security can be given.

In this paper, we propose the initial design of the

scheme and give our preliminary performance results

with the comparison to related work. We also provide

a proof of concept by creating an implementation on

a .NET smart-card. The results of ﬁrst tests are in-

cluded. In this position paper, we do not provide full

cryptographical analysis of the scheme and all proofs,

since these details can be found in the full paper.

2 SCHEME DESCRIPTION

This section is divided into three parts: the statement

of requirements, the description of the communica-

tion pattern and the cryptographic primitives used.

2.1 Requirements

The anonymous authentication scheme, to be accept-

able and implementable in practice, must provide fol-

lowing features.

• Completeness: valid users must be always ac-

cepted.

• Soundness: invalid users must be always rejected.

• Anonymity: honest users cannot be identiﬁed dur-

ing authentication.

• Unlinkability: veriﬁcation sessions must be un-

linkable.

• Responsibility: dishonest users must be identiﬁ-

able.

• Efﬁciency: the scheme must be efﬁciently imple-

mentable even on weak devices like smart-cards.

• Manageability: users can be easily added or re-

moved from the group of valid users.

• Security: the scheme must be provably secure,

based on strong primitives.

User

Public

Authority

Authentication

Server

Registration

(Comm, ZK)

Registration

(ZK, VE)

Token

Smart-card

Authentication

(VE, ZK)

Tracing/Revelation

(Comm, ZK)

Figure 1: Communication Pattern of the Proposed Scheme.

Our system gathers all these requirements in one

scheme, thus provides a universal solution for anony-

mous user authentication.

2.2 Communication Pattern

The scheme we propose in this paper is based on three

players. They are the user, Authentication Server

(AS) and Public Authority (PA). The roles of these

players and their description is following:

• User: the user wants to be anonymously veriﬁed

as a valid user of a service. The example is the

anonymous access to a discussion board, where

only registered users can enter, but where the con-

tent which is read by a particular user cannot be

tracked. The user wants to stay anonymous and

can use a smart-card for authentication.

• AS: the Authentication Server wants to verify

users before it allows them to use its services. The

role of AS is to decide, whether the user is valid

(e.g., registered or paying some fees). AS should

not be able to learn the concrete identity of a user,

only the information whether he is allowed to use

a service.

• PA: the Public Authority is a player who is used

in the case of dispute. Without PA, the AS is un-

able to learn the identity of a user. PA can be dis-

tributed to more entities to lower the trust to a sin-

gle point of failure.

The scheme consists of three protocols. The ﬁrst

protocol is user registration, the second is the authen-

tication protocol and the last one is the revelation pro-

tocol. The purpose of the registration protocol is to

establish an authentication token, which will be stored

on user’s smart-card and later used for authentica-

tion. The registration is done over a computer net-

work (likely Internet) using anonymous routing pro-

tocols like TOR (Dingledine et al., 2004). All three

entities are involved during this phase.

The second protocol is the authentication proto-

col. It runs between the user’s smart-card and AS.

The protocol allows user to provide a proof, that the

SECRYPT 2011 - International Conference on Security and Cryptography

406

token is valid, anonymously, without leaking informa-

tion about his identity or previous uses of the token.

That is why the authentication phase is anonymous

and unlinkable to previous authentication phases. The

provided proof is always randomized, thus the single

token can be used many times without the concern

about its tracing.

The last protocol is the revelation protocol. This

protocol is executed between AS and PA when some

disputes occur in the system. In that case, AS can con-

tact PA and give proofs about disputes, rule breaking

or e.g. some thefts in his systems. The PA then de-

cides, whether proofs are strong enough, and if yes, it

continues in user revelation. The user can be anony-

mously removed from the system, traced in the sys-

tem (but not identiﬁed) or completely identiﬁed. The

level of revelation depends on PA, therefore AS can-

not break users’ privacy without proofs of strong pol-

icy violation.

All described protocols are efﬁcient, their com-

plexity does not depend on the number of users. The

authentication protocol, which will be the most used

protocol, is practical for smart-card implementation.

The whole communication pattern is depicted in Fig-

ure 1. The ﬁgure also includes cryptographic primi-

tives placement, described in Section 2.3.

2.3 Used Primitives

In this section we provide information on our choice

of used cryptographic primitives together with their

placement in the scheme. In the registration protocol,

the discrete logarithm (DL) commitments and proofs

of representation (Camenisch and Stadler, 1997) are

used during the communication with AS. During the

communication with PA, we use proofs of represen-

tation and Bao’s veriﬁable encryption (Bao, 2000).

We also assume the existence of a secure signature

scheme, like RSA.

The registration protocol starts with the user

choosing a random number and creating a DL com-

mitment to it. The knowledge of the secret number

is then proven to AS by running the proof of repre-

sentation on the commitment. AS can therefore link

user identity with the commitment, while user’s secret

number remains hidden. AS stores the commitment

in its database and provides the user with the signa-

ture on the commitment. The user then anonymously

contacts PA and anonymously provides the commit-

ment and AS’s signature. He also has to provide the

proof of knowledge of the secret number in the com-

mitment using (Schnorr, 1991). Based on this infor-

mation, PA creates the token with user’s commitment

inside. The token is unlinkable to user’s secret num-

ber and to his commitment for anyone except PA. The

user then transfers the token to his smart-card.

The authentication phase is a proof of represen-

tation (Camenisch and Stadler, 1997; Schnorr, 1991)

of the token, thus a proof of knowledge of a secret

number chosen by the user and a second secret num-

ber given by PA during the registration. Based on

the proof of representation, AS can be efﬁciently con-

vinced about the right token construction.

The revelation protocol is based on the DL veriﬁ-

able encryption (Bao, 2000). The secret user number

is hidden in a veriﬁable encryption and given to AS

during the authentication protocol. AS can verify the

construction of the encryption, but is unable to de-

crypt. The only entity able to decrypt is PA, therefore

AS can resend the veriﬁable encryption to PA, which

is able to decrypt and either remove the user from the

system or release the real identity of the user to PA.

The removal of the user is done by publishing the DL

commitment of users secret value. Such published

values create a ”blacklist” of removed users, who are

no more able to be successfully authenticated.

The described primitives (the veriﬁable encryp-

tion (VE), commitments (comm) and proofs of rep-

resentation (ZK)) are placed in the scheme as visible

in Figure 1. The detailed description of primitives and

all supporting mechanisms is out of the scope of this

short paper and will be published in the full paper.

3 TESTING SMART-CARD

IMPLEMENTATION

One of our main goals is to provide a scheme efﬁ-

cient enough for a smart-card implementation. The

implementation of modular addition, subtraction or

exponentiation is easy due to low complexity and the

ability to delegate some computations to RSA crypto

co-processor. Multiplication is more difﬁcult to im-

plement since no direct function is available in the

framework. We compared more approaches to mod-

ular multiplication, from paper-and-pencil method,

Comba’s method, Montgomery multiplication to the

trick provided in (Bichsel et al., 2009). From the re-

sults it is obvious that the most efﬁcient method is

the so called RSA tunnel method from (Bichsel et al.,

2009), where multiplication is converted to exponen-

tiation using the binomial formula and then acceler-

ated using the RSA function. This method is intro-

duced for Java smart-cards in (Bichsel et al., 2009).

3.1 Performance Analysis

Based on modular multiplication and exponentiation

PRACTICAL ANONYMOUS AUTHENTICATION - Designing Anonymous Authentication for Everyday Use

407

implemented by us on a .NET smart.card, we cre-

ated a testing implementation of our scheme. We used

the .NET smart-card V2+ platform with no additional

modiﬁcation. The authentication phase, with all fea-

tures presented in this paper, was implemented on the

smart-card. Since the scheme works with modular

arithmetic, we tried several moduli sizes to analyse

the effects on the performance of the system. The de-

pendency of the veriﬁcation time on the size of the

modulus can be seen in Figure 2. The optimal size of

the modulus is 1024 b. The performance loss above

1408 b is given by the implementation of RSA on the

smart-card and the improvement of the performance

for higher moduli is one of our future concerns. The

most related system is the Idemix credential system

(Camenisch and Lysyanskaya, 2003) implemented on

a Java smart-cards (Bichsel et al., 2009).

600 800 1000 1200 1400 1600 1800

Length of Modulo |n| [bit]

[s]

The Time of Verification t

Including the Communication with a Smart−card

Figure 2: The Dependency of the Veriﬁcation Time on the

Modulus Size.

Current implementation provides reasonable ver-

iﬁcation times around 8 s, in comparison to related

implementations on Java smart-card (Bichsel et al.,

2009), which need around 10 s.

4 CONCLUSIONS

The paper introduced a new scheme for anonymous

authentication. Unlike related work, our scheme com-

bines features required by both users and service

providers. Using our scheme, the user can be au-

thenticated without real identity revelation and the

service provider can be sure about the control over

his assets. We provided the communication pattern

of the scheme and identiﬁed cryptographic primitives

used. The scheme is very efﬁcient and implementable

on weak devices like smart-cards. Nevertheless, the

works are still in progress and we expect a signiﬁ-

cant performance improvement. Our goal is to reach

30 % performance advantage over related schemes,

an increase which is achievable based on the theoret-

ical construction of the scheme. Moreover, we are

working on the support of ”attribute authentication”,

where users can prove not only the group membership

but any attribute ownership (e.g., driving licence, age,

citizenship).

ACKNOWLEDGEMENTS

Sponsored under the National Program of Research

II by the Ministry of Education, Youth and Sports of

the Czech Republic in 2C08002 Project - KAAPS Re-

search of Universal and Complex Authentication and

Authorization for Permanent and Mobile Computer

Networks.

REFERENCES

Bao, F. (2000). An efﬁcient veriﬁable encryption scheme

for encryption of discrete logarithms. In Schneier, B.

and Quisquater, J.-J., editors, Smart Card. Research

and Applications, volume 1820 of Lecture Notes in

Computer Science, pages 213–220. Springer.

Bichsel, P., Camenisch, J., Groß, T., and Shoup, V. (2009).

Anonymous credentials on a standard java card. In

Proceedings of the 16th ACM conference on Com-

puter and communications security, CCS ’09, pages

600–610, New York, NY, USA. ACM.

Camenisch, J. and Lysyanskaya, A. (2003). A signature

scheme with efﬁcient protocols. In Proceedings of the

3rd international conference on Security in commu-

nication networks, SCN’02, pages 268–289, Berlin,

Heidelberg. Springer-Verlag.

Camenisch, J. and Stadler, M. (1997). Proof systems for

general statements about discrete logarithms. Techni-

cal report.

Camenisch, J. and Van Herreweghen, E. (2002). Design and

implementation of the idemix anonymous credential

system. In Proceedings of the 9th ACM conference

on Computer and communications security, CCS ’02,

pages 21–30, New York, NY, USA. ACM.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: The second-generation onion router. In In Pro-

ceedings of the 13 th Usenix Security Symposium.

Lysyanskaya, A. (2001). An efﬁcient system for non-

transferable anonymous credentials with optional

anonymity revocation. pages 93–118. Springer.

Schaffer, M. and Schartner, P. (2006). Anonymous authenti-

cation with optional shared anonymity revocation and

linkability. In Smart Card Research and Advanced Ap-

plications, volume 3928 of Lecture Notes in Computer

Science, pages 206–221. Springer Berlin / Heidelberg.

Schnorr, C. P. (1991). Efﬁcient signature generation by

smart cards. Journal of Cryptology, 4:161–174.

SECRYPT 2011 - International Conference on Security and Cryptography

408
