OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS

Andres Garc´ıa-Garc´ıa, Carlos de Alfonso and Vicente Hern´andez

Instituto I3M, Universitat Polit`ecnica de Val`encia, Camino de Vera s/n, Valencia, Spain

Keywords:

Cloud computing, PaaS platform, Platform-as-a-service, Web services.

Abstract:

The development of Cloud Computing has paid attention mainly to the virtualization of hardware components,

under a scheme of Infrastructure-as-a-Service (IaaS). Most of Cloud vendors offer solutions based in IaaS to

offer virtual services and applications, instead of developing a proper Platform-as-a-Service (PaaS) solution.

This paper analyzes some existing commercial PaaS clouds, identifying in what degree they meet some essen-

tial requirements. These requirements are also argued, and guidelines for addressing them using an academic

approach in a PaaS solution are provided.

1 INTRODUCTION

Cloud Computing technologies have been tradition-

ally associated with business environments. There-

fore they have been used and promoted by enterprises

to build their business models around that technology

and its applications. This situation has caused enter-

prises to be the ones leading the development of this

technology, putting commercial interests before sci-

entiﬁc or academic interests and making researchers

to follow trends leaving some problems inherent to

the technology unattended.

Enterprises who have built their business model

around Cloud Computing try to offer competitive so-

lutions as soon as possible. Many of these solutions

are not correct or formal solutions, and would require

a deeperand elaborated research process, typical from

academic environments. The need of having a prod-

uct in the market has made commercial solutions to

ignore some features which may have been consid-

ered useful when applied to this technology.

One of the ignored developments has been the

Platform-as-a-Service (PaaS) level of Cloud Comput-

ing (Vaquero et al., 2009). Most of Cloud vendors

just offer solutions based in the Infrastructure-as-a-

Service (IaaS) level, providing virtual hardware re-

sources in the form of virtual machines. This same

concept has been used to offer virtual services, in-

cluding preconﬁgured services, packaged in a virtual

machine image which are deployed into IaaS solu-

tions. This approach is easy and immediate to im-

plement since it uses existing Cloud infrastructures,

but it also encompasses some drawbacks as the waste

of resources or a loss of control over direct services

management.

In this context, it is interesting to follow an ap-

proach to PaaS level based in building a platform from

the scratch with the aim of addressing service virtual-

ization directly, not by means of machine virtualiza-

tion. In order to build this platform, a set of features

are needed to be deﬁned, to build a correct, reliable

and robust system.

This paper performs a comparative analysis be-

tween currently available commercial PaaS solutions.

After this comparative, some features that these so-

lutions do not address are stated, detailing for each

one how the platforms implement them, and why are

considered incorrect. Also some guidelines to open

research lines in these features are offered, providing

researchers with a broad specter of ﬁelds to provide

further developments.

2 PaaS PLATFORMS ANALYSIS

In order to detect open problems and unattended fea-

tures in commercial PaaS Cloud solutions, a com-

parison has been made between four currently avail-

able commercial PaaS platforms: Windows Azure

(Microsoft Corporation, 2010c), Google App Engine

(Google Inc., 2010a), Heroku (HerokuInc., 2010)and

Engine Yard (Engine Yard, Inc., 2010). These plat-

forms are well known examples of commercial PaaS

Clouds, and the most representative part of the state-

of-the-artof PaaS platforms. All four solutions have a

clear web application orientation, although each one

368

García-García A., de Alfonso C. and Hernández V..

OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS.

DOI: 10.5220/0003604703680376

In Proceedings of the 6th International Conference on Software and Database Technologies (IWCCTA-2011), pages 368-376

ISBN: 978-989-8425-76-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

takes a different approach.

• Windows Azure is Microsoft’s major product for

the Cloud Computing market. It offers a general

computingruntime for .NET, PHP, Ruby, Java and

Python languages, achieving the highest quantity

of supported languages from all four solutions.

Azure offers an SDK integrated with Visual Stu-

dio for .NET and SDK and Eclipse plug-ins for

other languages, assisting developers with appli-

cation templates and auto deployment capabili-

ties.

The platformhosts two application roles, Web and

Worker, where Web role acts as the user interface,

and as the front end for the applications, while

Worker role does background calculations. Both

roles communicate by exchanging messages, us-

ing a built-in message queue. Applications can

use several interfaces such as databases, blob stor-

age, authentication, etc. for extra functionality.

Azure uses two billing approaches, either a

monthly payment or a pay-as-you-go schema.

Using monthly payment, developers purchase a

quantity of resources to use along a month for a

ﬁxed price. In the pay-as-you-go schema, billing

is done monthly based in the amount of resources

used in that time frame.

• Google App Engine is Google’s PaaS solution.

It supports Java and Python languages, and runs

applications in a “safe sandboxed environment”.

Runtimes for both languages have been modi-

ﬁed to impose restrictions over the capabilities of

hosted applications. Speciﬁcally, this sandbox en-

vironment prevents applications from:

– Writing to the ﬁlesystem.

– Opening a socket or access another host di-

rectly.

– Spawning a sub-process or thread.

– Making other kinds of system calls.

– Only classes in a whitelist can be accessed from

the Java standard library.

These limitations are oriented towards guarantee-

ing the correct behavior of applications and the

safety of the system. There exist additional limi-

tations, such as the 30 second limit for an appli-

cation to send a response from a request, that are

intended to improve the platform performance.

Google App Engine includes an extensive mon-

itoring system which provides detailed statistics

and metrics about the applications performance,

including resources usage (CPU, bandwidth, stor-

age), number of requests received, number of API

calls, etc. These values, or quotas, are used as

a measure for the payment for the service. Ser-

vice hosting is free under some values for each

quota, but it is set unavailable when these quo-

tas are exceeded. If billing is enabled, it switches

to a pay-as-you-go model for quotas over the free

limit. Developers are able to specify a budget

which limits the quantity of resources to hire from

the platform. Each quota resets its value in a 24

hours period, and has a max value that cannot be

overcome even using the payment model.

• Heroku is a company founded in 2007 which fo-

cuses in offering a PaaS platform for Ruby ap-

plications. Developer’s applications are hosted

in a software stack (named Dyno) which in-

clude frameworks (Rails (Hansson, 2010b),

Sinatra (Mizerany, 2010)), middlewares (Rack

(Neukirchen, 2010), Rails Metal (Hansson,

2010a)) and a VM (MRI (Matsumoto, 2010)) for

the Ruby language, wrapped in virtual machine

images that are deployed in an IaaS infrastruc-

ture (speciﬁcally in Amazon EC2 (Amazon.com

Inc., 2010)). These Dynos are organized in a

pool of applications which receive requests from

users. A reverse proxy and a HTTP cache manage

external requests serving applications via a rout-

ing mesh, which acts as a load balancer between

dynos. Storage (either persistent or not) is pro-

vided by means of a database system or a memory

cache system.

Heroku offers two roles: dynos (equivalent to a

web role in Azure) and workers. Dynos process

HTTP requestsfrom users, while workers perform

background tasks and transmit messages via mes-

sage queue. Developers can choose dynamically

the number of dynos and workers that they want

to hire, with a minimum of 1 dyno and a maxi-

mum of 24 for both. Databases plans offer access

to a databases system with different capacity or

performance level. The user is able to choose be-

tween shared or dedicated databases and the num-

ber of cpu units.

Finally, an add-on system provides extra function-

alities to hosted applications, for instance, capac-

ity to use SSL, a cron process, custom domains,

etc. Databases and add-ons are provided in a

monthly fee basis, while dynos and workers are

billed hourly, based in the number of units hired.

• Engine Yard is a company founded in 2006

which provides a Ruby Cloud, using an underly-

ing IaaS infrastructure (Amazon EC2) very sim-

ilar to Heroku. Engine Yard however focuses its

business model around the technical support and

consultative services, instead of application host-

ing.

OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS

369

Engine Yard cloud is built over Amazon EC2 and

Amazon S3, and it provide wrapped ruby environ-

ments as virtual machines. Customers are able to

purchase different sizes of these instances and add

additional features like a dedicated database or a

load balancing cluster. Once some instances have

been purchased, developers can deploy and man-

age their applications from a web interface within

Engine Yard website. That interface acts as a front

end for the platform and includes different man-

aging operations. Billing is based in the instances

hired, the number of hours running, storage and

data transfer.

Recently Engine Yard has divided their Cloud of-

fering in two branches, one named AppCloud,

which offers the described standard features, and

another “Enterprise Grade Cloud” named xCloud.

xCloud offers a set of extra features not available

in public AppClouds, like the provision of an au-

ditable infrastructure. The solution offers plans

such as a fractional cluster offer, which includes

dedicated database and disk storage, or a dedi-

cated cluster, an exclusive solution where the in-

frastructure is reserved just for one customer. Ad-

ditional features includeconsultativeservices, ori-

ented to help enterprises to migrate their appli-

cations to the cloud, providing extensive analysis

about the application needs, and a customized so-

lution in the Engine Yard platform, while a pre-

mium support system extends standard support

to 24x7 availability for critical issues, proactive

monitoring of applications, etc.

The following features have been analyzed for

these platforms.

• Underlying architecture: This feature speciﬁes

which software architecture supports the solution.

• Status: This topic states whether the solution is

available for the users for creating private clouds

or it is proprietary.

• Use of standards: It is also analyzed whether the

solution makes use of standards for three main op-

erations: authentication mechanisms to access the

platform, access to databases for built-in storage

support and communication protocols to interact

with the platform.

• Interoperability: States whether the platform is

able to interoperate with other clouds or it is iso-

lated

• Versioning: Refers to the support of the platform

to software versioning.

• Migration: This topic states whether the solution

supports service migration.

• Catalog: It refers to whether the platformprovides

some sort of information services, that would in-

clude any kind of useful information about the

platform or the services.

• SLA: This feature is related to the mechanisms

included in the platform for deﬁning the obli-

gations, warranties, compensations or pricing of

the resources in the terms of the service between

provider and customers. These mechanisms may

be offered in several options and features:

– Text document SLA: The provider uses a

legally binding document which acts as a con-

tract between the company and the customers.

– Purchasing options: The user is able to pur-

chase different business plans which offer spe-

ciﬁc functionalities for a fee (e.g. ﬁxed size

monthly plans, additional support, etc.).

– Conﬁguration options: Users can specify re-

strictions over their services using conﬁgura-

tion options (e.g. geographical deployment

constraints).

– Pay-as-you-go: Payment is decided dynami-

cally over the quantity of resources used and

the options that have been purchased.

The comparison shown in Table 1 highlights that

there are some topics which are not supported by the

platforms analyzed. In the following section, based

in the data gathered from the analysis of the commer-

cial platform, a set of open problems in PaaS Cloud

solutions is exposed.

3 OPEN PROBLEMS IN PaaS

CLOUD PLATFORMS

This section reviews features that are interesting to be

provided by PaaS platforms, and are widely provided

by the current available PaaS solutions analyzed. The

proposed features are the result of the comparison

with the characteristics of Cloud concepts introduced

by the generalization of IaaS platforms (Armbrust

et al., 2009), and others identiﬁed by the community.

For each of the topics an explanation of the approach

of the commercial platforms is provided, and the ex-

planation of its inadequacy from an academic point

of view. Some guidelines to address the problems de-

rived by that approach are also provided.

3.1 Pure PaaS Architecture

In general terms, details about the underlying ar-

chitecture of the commercial PaaS solutions are not

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

370

Table 1: Comparison of commercial PaaS platforms.

Name Windows Azure Google App Engine Heroku Engine Yard

Underlying architecture Not disclosed Not disclosed IaaS IaaS

Status Proprietary Proprietary Proprietary Proprietary

Use of standards SQL language for SQL language for Keypair authentication. Keypair authentication.

databases. databases.

SQL language for SQL language for

databases. databases.

Interoperability No No No No

Versioning No Yes No No

Migration No No No No

Catalog Service marketplace

Service marketplace

No Dashboard with

“Codename Dallas”. “Google App service statistics.

Marketplace”.

Dashboard with

service statistics.

SLA Text document SLA. Text document SLA.

Purchasing options. Text document SLA.

Purchasing options. Pay-as-you-go. Purchasing options.

Pay-as-you-go. Pay-as-you-go.

Conﬁguration options.

known, but from what is shown, in most cases there

does not exists any speciﬁc PaaS oriented architecture

which supports each solution. The major difference

between IaaS solutions and PaaS solutions is that IaaS

virtualizes machines while PaaS virtualizes services.

The architecture of some platforms, such as

Heroku, are based in an underlying IaaS solution

without any speciﬁc consideration about services vir-

tualization. The approach of building a PaaS solution

over an IaaS solution is easy and fast, because both

share many features as a starting point. According to

that premise, the PaaS platform may be conﬁdent in

the fact that the IaaS platform will provide some of

the “cloud” characteristics (e.g. load balancing, isola-

tion, migration, multitenancy, etc.).

However, while machine virtualization ﬁts per-

fectly in an IaaS environment, it misses the aim of

service virtualization. In a PaaS solution, the virtu-

alized resource which is offered to clients is the run-

time where services run, but some solutions (Heroku,

Engine Yard) wrap this runtime inside a virtual ma-

chine image, instead of addressing virtual services di-

rectly. A PaaS architecture built over an IaaS archi-

tecture will take proﬁt from the solutions to the prob-

lems found for IaaS architectures, but it should still

address PaaS speciﬁc problems. As a result, the solu-

tion will not be able to solve some problems related

with a PaaS platform or will do so in a less efﬁcient

manner, due to a biased vision of the PaaS solution.

This approach implies a high overload and a less

direct management of the services. On one side, if a

whole virtual machine is used, instead of just a vir-

tual service, extra memory, storage and processor re-

quirements are added to those that the service needs.

Moreover the management of the services becomes

more complicated, as it is necessary to work at ma-

chine level instead of service level.

Other platforms, like Google App Engine, seem

to be based in an original PaaS architecture, although

no details are revealed about it. This approach intro-

duces new considerations about the management of

services, like imposing limitations in the service be-

havior, but also provides several beneﬁts like a ver-

sioning system or detailed statistics reports.

While the typical approach is to embed the run-

time in a virtual machine and use it as a building

block, the proposed approach is to virtualize the run-

time itself, and use it as a building block. Using run-

time virtualization (or virtual containers) researchers

are able to design a pure PaaS architecture. Also this

approach bring new needs, problems and features that

must be addressed, which are missed when virtual

machines and IaaS solutions are used as a base. Ser-

vice virtualization offer new models for monitoring

and billing, SLA terms, interoperability features, se-

curity concerns, etc. Furthermore, runtime virtualiza-

tion increases the ﬂexibility of the system, since vir-

tualized runtimes can be placed into virtual machines,

and a PaaS solution can be built using either IaaS so-

lutions, physical machines directly, or even applying

mixed schemes.

New research lines opened by this feature include

deﬁning the requirements of a PaaS platform and the

speciﬁcation and design of a PaaS oriented architec-

ture.

Introduced in App Engine for Business beta, in May

2010.

Service Marketplace are web portals where developers

and business publish they applications and users buy sub-

scriptions for them.

OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS

371

3.2 Tools for the Development of Private

PaaS Clouds

In order to use an IaaS cloud, users can adopt solution

offered by IaaS vendors or build a private cloud us-

ing their own resources and a cloud software (Nurmi

et al., 2008)(Sotomayor et al., 2009). When consid-

ering PaaS level, there are few vendors who offer pri-

vate PaaS solutions, and even less tools that enable

users to build their own private PaaS cloud, like (Uni-

versity of California, Santa Barbara, 2010).

Using a cloud from a vendor means the outsourc-

ing of management and maintenance operations and

leverages the transition between traditional datacen-

ters and cloud computing for enterprises. This is of-

ten considered as a desirable feature since developers

just use the resources without additional management

cost such as physical machine hosting, cooling sys-

tems, network access, etc. However, sometimes pri-

vate cloud solutions meet the requirements of users

better than public clouds.

One of the major concerns about outsourcinghost-

ing services is the security and privacy requirements.

Enterprises have the responsibility of hosting services

that have a high value (known as mission critical ser-

vices) and storing information which contains sensi-

ble data (e.g. clients personal information) in order to

keep their compromise with customers and maintain

their business model. When services are outsourced

to external companies, enterprises require from ven-

dors guarantees that are compatible with those that

they offer to their customers. Also outsourcing im-

plies a loss of control over services and data, which

force enterprises to rely in third party hardware and

staff to run and manage their assets.

When building a private PaaS cloud, developers

are able to host mission critical services and sensible

data in house, avoiding security concerns and keeping

direct control over software and resources. Also, the

user takes proﬁt from all the other beneﬁts provided

by cloud computing such as resource optimization or

easier management.

Furthermore, hybrid clouds solutions may be

built, where privateclouds interact with public clouds.

In such solution, private clouds manage sensitive data

and services, while public clouds provide extra capac-

ity to the system.

Under the scope of IaaS, there are several initia-

tives such as Eucalyptus or others, which are derived

from the usage and the concepts introduced by Ama-

zon WS. Unfortunately, there are few PaaS initiatives,

and that is probably why most of the concepts are still

under development.

Tools for the development and deployment of

PaaS solutions would allow users to build their own

private clouds and taking advantage of its beneﬁts.

Using an open and free tool, administrators are able

to deploy PaaS solutions, conﬁguring and adapting

the software to their needs. Therefore, the design and

implementation of an open tool for the deployment of

PaaS infrastructure remains as an open research line

itself.

3.3 Use of Standards

As it occurs with any emerging technology, Cloud

Computing yet lacks its own solid standards for many

operations. However, that void has become a chance

for some companies to use technology of theirown in-

terest in parts where some standards could have been

applied (e.g. LiveID (Microsoft Corporation, 2010b)

authentication of Windows Azure, Google App En-

gine using GQL (Google Inc., 2010c) for databases).

Cloud Computing has been deﬁned as the new

model for Utility Computing. One of its most impor-

tant features is that anyone can plug their systems to

“the cloud” and use computing power, storage or net-

work as a commodity. However, if standards are not

used, the purpose of a true Utility Computing is lost,

since the developed systems cannot be used in any but

just their target cloud.

The lack of standards produces vendor lock-in

and it also difﬁcult interoperability between clouds.

While the deﬁnition of standards for the cloud as a

whole is a work in progress (Open Cloud Consortium

(OCC), 2010), the usage of standards for key opera-

tions (communications, authentication) should be en-

couraged. A system with a highly modular design

would provide a good basis to adopt standards and

would enable the upgrade of them to new versions (or

new standards).

An open research line in this ﬁeld consists in iden-

tifying key components where standards can be used,

and design protocolsand procedures which are part of

the state of the art speciﬁcations for those operations,

helping the joint effort for the deﬁnition of cloud stan-

dards.

3.4 Platform Utilities

The paradigm shift between IaaS and PaaS consist on

the provisioning of a platform for the deployment and

management of services, instead of the provisioning

of virtualized hardware. However a platform not only

encompasses the deployment and execution of soft-

ware, but to give support to the whole development

cycle, from implementation to debugging.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

372

A complete PaaS solution should provide a set of

Platform Utilities that effectively realize a higher ab-

straction levelthan the IaaS solutions. A PaaS product

that only stores and executes services does not pro-

vide many advantages over an IaaS solution that pro-

vides on-premise virtual machines conﬁgured to exe-

cute services.

The generic term Platform Utilities includes a set

of features that the platform offers to developers and

hosted services in order to integrate the Cloud de-

ployment in the software development cycle. Some

of these utilities are described below.

• IDE integration. One of the aims of PaaS solu-

tions is to integrate the cloud deploymentwith the

software developing process. The underlying idea

is that the whole development procedure should

be cloud-aware, to enable developers to create

cloud applications and not applications that run

in the cloud, adapting the development cycle to

the cloud. For achieving this integration is neces-

sary to provide an IDE that communicates with

the Cloud and allow testing applications before

deployment, automaticallydeploying applications

in the Cloud and using other Platform Utilities. In

this ﬁeld, Microsoft offers Azure Tools for Visual

Studio, an add-on to the Visual Studio IDE which

allows local testing of Cloud services in a simula-

tion environment, the usage of the Azure libraries

and automatic deployment of applications in the

Azure Cloud. Google offers the Google App En-

gine SDK (for Python and for Java), as a set of

tools with similar functionalities, and the Google

Plugin for Eclipse, which allows the usage of the

SDK in an IDE.

• Communication System. As in any distributed

system, applications may have the need to com-

municate between them. Some software solu-

tions, such as a master-slave execution schema,

make heavy use of inter-service communication,

and therefore a built-in efﬁcient solution leverages

the load of the system and improves the develop-

ment cycle. In this ﬁeld, Microsoft Azure includes

the Service Bus utility, which allows clients and

services to exchange messages or data.

• State Replication System. One of the principles of

the Cloud is the scalability of services by means

of multiple services instances, load balancing and

stateless interactions. The principle of stateless

interactions says that in order to properly serve a

petition, a service must not rely on previous in-

teractions, and therefore the same petition may

be served by different instances, producing the

same return value. However many applications

need the management of some kind of state, that

must be consistent between instances of a ser-

vice. This requirement is dealt with the usage of

Cloud Storage, which typically incurs in compu-

tation overhead and economic cost. The usage of

state replicating mechanisms would allow devel-

opers to keep the state of their services consistent

using built-in platform mechanisms and without

the need of Cloud Storage.

• Versioning. This feature allows developers to

maintain an incremental development cycle, and

enables testing and upgrading applications. De-

velopers are able to keep long-term services and

add new functionalities incrementally, and testing

the new software versions in the target environ-

ment before they are released. Developers would

be able to deploy stable versions of software in

the cloud, and concurrently deploy beta versions

for testing purposes. Once beta versions have

been debugged and became stable, the deployed

instances would be able to be update on the ﬂy,

providing users with stable and updated services

transparently. Most of current PaaS solutions don

not take into account the software versions, and

developers must manually manage those concepts

in a non-transparent manner. Google App Engine

is the only analyzed platform which integrates the

concept of versioning, allowing developers to de-

ﬁne service versions, deploy several at the same

time and deﬁne one of them as default, which will

be the one publicly available.

• Debugging Mechanisms. Debugging of dis-

tributed software is a challenging issue and a ﬁeld

of study itself, and it becomes even more complex

when the developers are not the owners, nor have

direct access to the platform executing the code.

Local testing of services may solve some errors

before the service becomes publicly available, but

only when the software to test becomes used in

a real world scenario, all possible issues become

noticeable. Since developers do not have direct

access to the virtual runtimes, the platform itself

must provide mechanisms to debug deployed ser-

vices. In this ﬁeld, Google App Engine provides a

logging service that allows developers to log error

or warning systems, and these messages are re-

trieved by the platform and displayed in the dash-

board, where developers can check them. Heroku

offers the Exceptional add-on, with two subscrip-

tion levels (regular and premium), a system which

stores and make real-time notiﬁcation to develop-

ers when an exception arise in a running applica-

tion.

The inclusion of Platform Utilities provides a

clear differentiation in terms of abstraction level be-

OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS

373

tween the IaaS and PaaS solutions. A PaaS solu-

tion that provides Platform Utilities allows building

Cloud-aware applications, that actively make use of

its features for their advantage.

The cited Platform Utilities, amongother that may

be formulated for different use cases, represent an

open research line in this ﬁeld.

3.5 Service Migration

Live migration is a concept associated to distributed

systems, speciﬁcally SOA (Service Oriented Archi-

tecture), although the popularization of virtualization

technologies has recently associated the term to vir-

tual machine migration. Live migration is deﬁned as

the movement of a runningpiece of software from one

physical host to another one without any disruption

of service or perception of downtime from the users

point of view (Clark et al., 2005). The major advan-

tages of live migration are the following:

• Software can be moved from one machine to an-

other, making its execution independent from the

original machine. This ability allows administra-

tors to interact with the original machine without

affecting the application. For instance, if a ma-

chine needs to be shutdown for maintenance, live

migration would enable services hosted in it to

keep runningin other host machine with no down-

time associated.

• Services can be migrated between resources, ap-

plying load balancing algorithms. If a machine is

overloaded and other has spare capacity, moving

services between both of them would optimize re-

source usage and improve performance.

• Live migration is done without disrupting ser-

vices. Users can keep using services without

noticing that they have been moved to another

physical machine

• Using interoperability and live migration, devel-

opers can change its cloud provider automatically

and without disrupting its customers.

• Autoscaling (up and down) becomes easier and

more efﬁcient. When scaling up, load can be re-

distributed among new nodes using live migra-

tion, while when scaling down, services from ma-

chines that will be stopped can be moved to the

remaining ones.

Among the platforms analyzed, only Heroku ex-

plicitly apply some sort of migration in order to load

balance resources, while the others totally ignore this

concept, or hides it from users. Heroku is built on top

of an IaaS infrastructure and it migrates its compo-

nents (dynos and workers) between nodes in order to

improve performance transparently to users. The mi-

gration consists in moving the virtual machine which

hosts the service from a node to another.

Live migration of running instances has been seen

as a desirable feature also for IaaS solutions, since it

provides load balancing and better management of re-

sources. As well as IaaS platforms continue working

on offering virtual machine live migration, PaaS plat-

forms should offer virtual services live migration.

Live migration, which is a ﬁeld of study itself, can

be achieved using a migration protocol. Those pro-

tocols often include three basic steps: deploy a new

instance, redirect clients from the old instance to the

new one and undeploy the old instance. This protocol

works properly when services are RESTful (Fielding,

2000), speciﬁcally if they are stateless. However, if

services keep some kind of state (either as local stor-

age or as in-memorydata) thisprotocolmust includea

state transfer step, which increases the complexity of

the process. Therefore live migration involving state

transfer opens new lines of research along with the

service migration protocols.

3.6 Digital SLA

In a cloud environment, SLA becomes the contract

that specify the terms of the agreement between the

vendor and the user at a software level, specifying

obligations, warranties and compensations.

Nowadays cloud vendors offer a very basic vision

of SLA for their solutions. They provide a plain text

document that speciﬁes obligations in terms of up-

time, stating that vendors will offer x% uptime (mea-

sured along a certain amount of time), and the com-

pensation in case of violation of the terms, commonly

formulated as a discount in the next charge to the

client. Other candidate options to be part of the SLA

(geographic constraints, CPU, memory requirements)

are left out as conﬁgurationoptions, or totally ignored

in some cases.

In order to offer a complex SLA system which can

handle service restrictions, conﬁguration, user infor-

mation, etc., platforms need to incorporate the con-

cept of ‘Digital SLA’ and a SLA framework to al-

low administrators to deﬁne their own SLA terms and

management rules. This concept has been included

in the work lines of other projects such as Reservoir

(Rochwerger et al., 2009) which deﬁnes the inclu-

sion of SLA metadata in the manifest of the services,

and is the key topic in the SLA@SOI project (The

SLA@SOI consortium, 2010), whose aim is to pro-

vide a business-oriented Service Oriente Infrastruc-

ture (SOI) which allow the management of the busi-

ness processes by means of Digital SLAs.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

374

Digital SLAs would be the binary representation

of the documents which deﬁne the terms of the ser-

vice between provider and users. Those terms should

include every element that deﬁnes the agreement be-

tween both parts:

• Resources required by the user (CPU, memory,

storage).

• User restrictions over services (e. g. geographical

constraints).

• Price of the elements, which could be speciﬁed

individually for each instance or service.

• Conﬁguration options over services at platform

level (e. g. elasticity rules, list of developers al-

lowed to manage a service, number of replicas for

stored data).

• Warranties offered by the provider (maximum re-

sponse time, security constraints, etc.).

• Compensation terms (compensationto users when

SLA is violated). It would be interesting to spec-

ify them individually for each element, depending

of the ‘severity’ of the issue.

This Digital SLA, unlike traditional SLA con-

tracts expressed as plaintext documents,can be stored

and automatically managed by the platform, enabling

to deal with it in an automated manner. A platform

managing Digital SLA would be able to automati-

cally perform operations to correct or prevent SLA

violations, report the incident to administrators and

developers, and take corrective actions and compen-

sate users as required.

New open research lines derived from this ﬁeld in-

cludes the deﬁnition of the terms of the SLA, deﬁni-

tion of a languageto represent SLA, creation of proto-

cols for SLA manipulation, interaction of SLA with a

PaaS platform components, deﬁnition of mechanisms

to enforce SLA, prevent their violation, take correc-

tive actions and compensation to users in case of vio-

lation, etc.

3.7 Information Services

Some of the features of PaaS Cloud platforms need a

system to store and retrieve different kinds of infor-

mation, such as monitoring information, metadata for

services and users, etc. In a Cloud solution, informa-

tion is generated everywhere in the system, either by

the platform components or by external users interact-

ing with them. Some of this information must be re-

trieved and stored for further processing (for instance

the CPU load of a service for SLA monitoring), and

therefore arise the need of such a system.

In the ﬁeld of distributed systems, this concept is

realized as InformationServices, or Catalogs. A Cata-

log is a semi-centralized system which store and man-

age information, and provides an API for every com-

ponent to add or retrieve data from it.

Current PaaS solutions have made a particular in-

terpretation of the Catalog concept. Google and Mi-

crosoft offer Google Apps Marketplace (Google Inc.,

2010b) and Microsoft codename Dallas (Microsoft

Corporation, 2010a) services. Both products are web

portals where developers can register their applica-

tions hosted in the cloud and offer them for a fee,

and consumers can browse for and subscribe to them.

These services offer a commercial trade point for de-

velopers and consumers, but do not offer the features

of a Catalog.

Besides the App Marketplace, Google App En-

gine includes an integrated dashboard where develop-

ers can check statistics and metrics about their ser-

vices, as well as an API to allow hosted services

to check some monitoring information about them-

selves. This concept comes closer to an Information

Service, as deﬁned in (Czajkowski et al., 2001), but

yet lacks the global nature of such system.

Open research lines in this ﬁeld comprise deﬁn-

ing an organization of a catalog for a Cloud solution,

deﬁning what information is included in it, how the

information is stored and managed, deﬁne replication

and distribution mechanisms, deﬁne the access proto-

cols and API for the addition, modiﬁcation, deletion

and retrieval of information, etc.

4 CONCLUSIONS

The lack of research in the Platform-as-a-Service

level of cloud computing have produced an absence

of detailed analysis about its features, needs and chal-

lenges. The state of the art in PaaS clouds have been

mainly carriedout by enterprises,which havereleased

PaaS solutions guided by commercial interests and

not by scientiﬁc or academic considerations. Their

main aim usually is to deliver solutions to their cus-

tomers in a short time, in order to gain advantage over

their competitors. This business model has caused the

release of platforms constrained by the limitations of

the model established by each provider.

Although the reviewed platforms conform a rep-

resentative sample of the current state of the art in

commercial PaaS Cloud, not every platform provides

the same set of features. In order to provide efﬁcient,

reliable and robust products, a description of the ba-

sic characteristics needed to build a PaaS solution has

been made, by means of an analysis of the state of the

OVERVIEW OF CURRENT COMMERCIAL PAAS PLATFORMS

375

art of Cloud Computing, but also incorporatingpart of

the expertise of Grid Computing and IaaS solutions.

This paper highlighs each one of these selected

features, and explains its motivation and importance.

Also it deﬁnes the degree of compliance of each plat-

form for each feature, and includes a brief description

of the challenges associated with them.

Future works includes further research in PaaS so-

lutions requirements in order to provide more fea-

tures and reﬁne the deﬁnition of the ones included

in this work. For each one of these features identi-

ﬁed, a set of open problems or research lines provide

a broad range of new developments that not only con-

cern PaaS Cloud, but all levels of Cloud Computingas

a whole. Some of these research lines include but are

not limited to the design of live migration procedures,

speciﬁcation of a SLAs, speciﬁcation of a Cloud Cat-

alog, etc.

ACKNOWLEDGEMENTS

The authors wish to thank the ﬁnancial support re-

ceived from the Spanish Ministry of Education and

Science to develop the project “ngGrid - New Gen-

eration Components for the Efﬁcient Exploitation of

eScience Infrastructures”, with reference TIN2006-

12890. This work has been partially supported by

the Structural Funds of the European Regional De-

velopment Fund (ERDF). This work has been devel-

oped under the support of the program “Formaci´on

de Personal Investigador de Car´acter Predoctoral”

(grant number BFPI/2009/103), from the “Conselle-

ria d‘Educaci´o” of the “Generalitat Valenciana”.

REFERENCES

Amazon.com Inc. (2010). Amazon EC2 (Elastic Com-

pute Cloud). http://aws.amazon.com/ec2/ [Online; ac-

cessed 01-03-2011].

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., and Zaharia, M. (2009). Above the Clouds:

A Berkeley View of Cloud Computing. Technical re-

port.

Clark, C., Fraser, K., Hand, S., Hansen, J. G., Jul, E.,

Limpach, C., Pratt, I., and Warﬁeld, A. (2005). Live

migration of virtual machines. In NSDI’05: Pro-

ceedings of the 2nd conference on Symposium on

Networked Systems Design & Implementation, pages

273–286, Berkeley, CA, USA. USENIX Association.

Czajkowski, K., Fitzgerald, S., Foster, I., and Kesselman,

C. (2001). Grid information services for distributed

resource sharing.

Engine Yard, Inc. (2010). Engine Yard Cloud. http://www.

engineyard.com/ [Online; accessed 01-03-2011].

Fielding, R. T. (2000). Architectural styles and the design

of network-based software architectures. PhD thesis.

Chair-Taylor, Richard N.

Google Inc. (2010a). Google App Engine. http://

code.google.com/appengine/ [Online; accessed 01-

03-2011].

Google Inc. (2010b). Google App Marketplace.

http:// www.google.com/enterprise/marketplace/ [On-

line; accessed 01-03-2011].

Google Inc. (2010c). GQL. http://code.google.com/

appengine/docs/python/datastore/gqlreference.html

[Online; accessed 01-03-2011].

Hansson, D. H. (2010a). Introducing Rails Metal.

http://weblog.rubyonrails.org/2008/12/17/introducing-

rails-metal [Online; accessed 01-03-2011].

Hansson, D. H. (2010b). Ruby on Rails. http://

rubyonrails.org/ [Online; accessed 01-03-2011].

Heroku Inc. (2010). Heroku. http://heroku.com/ [Online;

accessed 01-03-2011].

Matsumoto, Y. (2010). Matz’s Ruby Interpreter. http://

www.ruby-lang.org/ [Online; accessed 01-03-2011].

Microsoft Corporation (2010a). Codename “Dallas”.

http://www.microsoft.com/windowsazure/dallas/

[Online; accessed 01-03-2011].

Microsoft Corporation (2010b). LiveID. https:// accountser-

vices.passport.net/ [Online; accessed 01-03-2011].

Microsoft Corporation (2010c). Windows Azure.

http:// www.microsoft.com/windowsazure/ [Online;

accessed 01-03-2011].

Mizerany, B. (2010). Sinatra. http://www.sinatrarb.com/

[Online; accessed 01-03-2011].

Neukirchen, C. (2010). Rack: a Ruby Webserver Inter-

face. http://rack.rubyforge.org/ [Online; accessed 01-

03-2011].

Nurmi, D., Wolski, R., Grzegorczyk, C., Obertelli, G., So-

man, S., Youseff, L., and Zagorodnov, D. (2008).

The Eucalyptus Open-source Cloud-computing Sys-

tem. In Proceedings of Cloud Computing and Its Ap-

plications.

Open Cloud Consortium (OCC) (2010). Open Cloud Con-

sortium (OCC). http://opencloudconsortium.org/ [On-

line; accessed 01-03-2011].

Rochwerger, B., Breitgand, D., Levy, E., Galis, A., Nagin,

K., Llorente, I. M., Montero, R., Wolfsthal, Y., Elm-

roth, E., Caceres, J., Ben-Yehuda, M., Emmerich, W.,

and Galan, F. (2009). The RESERVOIR Model and

Architecture for Open Federated Cloud Computing.

IBM Journal of Research and Development, 53(4).

Sotomayor, B., Montero, R. S., Llorente, I. M., and Foster,

I. (2009). Capacity Leasing in Cloud Systems using

the OpenNebula Engine. Cloud Computing and Ap-

plications 2008 (CCA08).

The SLA@SOI consortium (2010). SLA@SOI. http://

sla-at-soi.eu/ [Online; accessed 01-03-2011].

University of California, Santa Barbara (2010). AppScale.

http://appscale.cs.ucsb.edu/ [Online; accessed 01-03-

2011].

Vaquero, L. M., Rodero-Merino, L., Caceres, J., and Lind-

ner, M. (2009). A break in the clouds: towards a

cloud deﬁnition. SIGCOMM Comput. Commun. Rev.,

39(1):50–55.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

376
