A LIGHTWEIGHT ELEMENT MATCHING METHOD FOR

INDUSTRIAL TERMINOLOGY HARMONIZATION

Exploiting Minimal Semantics based on Naming Conventions

Pekka Aarnio, Seppo Sierla and Kari Koskinen

Department of Automation and Systems Technology, Aalto University, Otaniementie 17, Espoo, Finland

Keywords: Industrial terminology standards, Standard harmonization, Ontology matching, Concept naming rules.

Abstract: Harmonization of terminologies used in industrial standards has been widely understood to be necessary for

better interoperability of industrial information systems. Partial automation of the terminology comparison

and matching phases of this process is necessary, in order to reduce the workload of human experts.

Terminology dictionaries have been developed by various national or international organizations and for

different contexts, so their taxonomy structure and lexical content can be very different. Further, because

they cannot be considered as true ontologies, advanced ontology matching techniques are not directly

applicable. The goal of our research was to develop a lightweight element matching approach based on

structural similarities of concept names. This approach is applicable, when similar naming conventions and

rules have been applied during the development of both terminology dictionaries. In this paper, we present a

new ElemMatcher method and demonstrate its application to the harmonization of PSK standards with ISO

15926-4. PSK Standardisation is an association of Finnish industry.

1 INTRODUCTION

Interoperability of industrial systems and

applications during the entire lifecycle of a plant is a

fundamental issue when targeting internal and

external efficiency, reliability and flexibility of

production and high quality products and services.

One of its main aspects concerns information

integration and data exchange between internal and

external applications. The benefits of better

interoperability are obvious and widely understood,

and several industrial standards have been developed

to manage these issues.

Several national and international plant model or

product model standards with overlapping context

exist, yet they use their own terminology

dictionaries, resulting in interoperability problems.

Industrial terminology (dictionary) standards

provide terminology for product model standards.

They identify and specify names of classes and

properties and meaning in definitions, descriptions

and remarks. Terminology standards are often

extended as classification standards, i.e. taxonomies.

The harmonization of several overlapping standards

as deeply as possible and selecting a wide scope

international terminology dictionary standard as a

common shared integration standard has been

proposed as a solution by the European industrial

network Orchid (CEN Orchid Roadmap).

Our research goal is to develop a lightweight

matching method ElemMatcher (EM) for industrial

cases, in which source and target terminology

standards are very dissimilar and contain very little

semantic information that could be exploited by

advanced ontology matchers. As a proof of concept,

EM was applied to the harmonization of Finnish

national PSK standards (PSK Standardisation) with

ISO 15926-4, Reference data, (ISO 15926-4). This

harmonization process has been started, following

Orchid roadmap (CEN Orchid Roadmap) guidelines,

in PSK Standardisation, which is an association of

Finnish industry closely co-operating with the

official Finnish Standards Association SFS.

The EM matching method applies structuring

rules derived from the general naming principles and

rules specified in two terminology work standards

(ISO 860:2007), (ISO 704:2000) and in a metadata

registries standard (ISO/IEC 11179-5:2010).

Terminology work standards document

principles that should be followed in the formation

of concept names. The main idea behind the EM

390

Aarnio P., Sierla S. and Koskinen K..

A LIGHTWEIGHT ELEMENT MATCHING METHOD FOR INDUSTRIAL TERMINOLOGY HARMONIZATION - Exploiting Minimal Semantics based on

Naming Conventions.

DOI: 10.5220/0003640803900395

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2011), pages 390-395

ISBN: 978-989-8425-80-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

approach has been crystallized by the transparency

principle: “a concept name (designation) is

considered transparent when the concept it

designates can be inferred, at least partially, without

a definition or an explanation. In other words, the

meaning of a name can be deduced from its parts.”

(ISO 704:2000)

In the ISO/IEC 11179-5 “Naming and

identification principles” standard (ISO/IEC 11179-

5:2010), naming convention has been defined as a

set of rules for creating names and their associations.

Prescriptive conventions should be documented by

semantic, syntactic, lexical and uniqueness rules.

This standard defines also the basic general structure

and different term parts of a concept name.

The rest of the paper is organized as follows.

Section 2 presents briefly different ontology

matching techniques and related work. Section 3

describes the EM approach. The results of a

matching case are presented in Section 4 and Section

5 reports some conclusions.

2 RELATED WORK

A harmonization process includes a comparison and

matching phase that can be at least partially

automated. Several different methods have been

developed for entity matching originating from

database schema matching techniques. Today, state-

of-the-art technology is called ontology matching.

The goal of ontology matching is to find the

relationships between entities expressed in different

ontologies (Euzenat 2007).

Most matching approaches exploit at least

element-level lexical information and calculate

string distances of entity (concept or property)

labels. Structural methods try to extract similarity

features from hierarchy structures (taxonomies) or

from the attribute structures of concepts (product

models). In addition, advanced approaches exist that

can exploit also other kinds of common semantic

information. Language based methods can be

applied, if textual data is available. Extrinsic

methods exploit some external knowledge base (e.g.

WordNet) in order to reveal additional semantic

information concerning the entities to be matched.

Extensional methods try to find similarities between

instance data. A survey of several matching

approaches is presented in (Rahm & Bernstein,

2001), (Shvaiko & Euzenat, 2005).

Semantic techniques are perhaps the most recent

direction of matching approaches. It requires that

concept systems to be matched are true ontologies or

that semantics have been represented formally.

Examples of state-of-the-art approaches that include

semantic methods in their method suite are ASMOV

(Jean-Marya, 2009) and S-Match (Giunchiglia,

2007). S-Match has been categorized as a schema-

based semantic matching approach. It can apply

element level string-based methods, structural

methods and extrinsic methods that can exploit

external dictionaries. As a result, it is applicable not

only for ontology but also for lightweight ontology

and schema matching (Giunchiglia, et.al. 2009).

Applications of ontology matching techniques in

industry are still uncommon. One of the main

reasons for this might be that “there is no integrated

solution that is clear success, which is robust

enough to be the basis for future development, and

which is usable by non expert users” (Shvaiko 2008,

p. 1165). Furthermore, studies made by (Lauser, et.

al. 2008) reveal that the success of matching

techniques is largely case dependent.

Recent research on industrial applications of

ontology matching (Uslar & Rohjans, 2009),

(Fiorentini, et. al. 2009), (Zan, et. al. 2010) targets

industrial standards in ontology form or information

and product model standards for which ontology

matching techniques are applicable, whereas our

goal is the harmonization of industrial terminology

standards.

3 THE EM APPROACH

The EM approach exploits the minimal common

semantic information hidden in the structure of

concept names. This implicit information, when

decoded, can provide a hint of the relative position

of a concept in a generic hierarchy, which further

enables to infer possible relations between different

concepts. The EM matching process includes five

main steps:

1. Normalization

2. Quasi-synonymization

3. Equivalence matching

4. Name structuring

5. Hierarchy relationship search

3.1 Normalization

Before actual matching algorithms can be applied,

some pre-processing is needed. In this case,

hierarchy structures need to be first reduced into a

flat list of concept names followed by a

normalization phase. The purpose of the

A LIGHTWEIGHT ELEMENT MATCHING METHOD FOR INDUSTRIAL TERMINOLOGY HARMONIZATION -

Exploiting Minimal Semantics based on Naming Conventions

391

normalization phase is to transform the entity strings

into a common normal form in order to eliminate

syntactic differences between entities in different

lists. The other normalization operations applied are

a combination of those proposed in (Euzenat 2007)

and (Leukal 2006).

3.2 Quasi-synonymization

The next processing step is quasi-synonymization

(q-syn). A term word of a source name can be

replaced with its q-syn, after which this modified

copy of the name element is added into the source

list. The prefix quasi has been used, because these

common term word pairs are only potential

synonyms in an industrial context. The look-up table

of q-syn term pairs is filled beforehand in an ad-hoc

manner. For instance, this table contained the

following term pairs: maximum – upper limit; size –

diameter; operation – operating; electrical –

electric.

3.3 Equivalence Matching

The actual matching phase begins with a search of

equivalence relationships between source and target

concepts. The most obvious argument supporting

entity equivalence is the full string equality of their

names. A simple string-based matching method was

adequate in this case, since only full similarity of

strings was accepted as proof of concept

equivalence. The produced alignment set is labelled

with “A=B”.

3.4 Name Structuring

In order to find hierarchy relationships between

entity names, the EM method analyzes the inherent

structure of the names. The applied naming

conventions determine this structure. According to

the general naming rules that have been defined in

terminology work standards (see Chapter 2), the

names of class and property concepts can be

composed of more than one term word.

The most important name part is the root term

carrying the main meaning of the concept. When the

target concept is an equipment class, the root term is

of type object class term and in the case of an

equipment property concept it is of type property

term. Besides, the root term can be preceded by, one

or more qualifier terms that specialize or constrain

the basic meaning declared by the root term. In

addition, a representation term is a word, or a

combination of words, that semantically represent

the data type (value domain) of a data element.

(ISO/IEC 11179-5:2010)

One extra category has been defined for the EM

method. The names of properties can have an

additional object class term that represents a

constraint for the domain scope of that property. If

such a term is the last term in a name phrase,

separated from the root term by one of predefined

prepositions, it is categorized as a scope qualifier

term. Altogether, five term part categories are

considered by EM method:

1. object class terms

2. property terms

3. qualifier terms

4. scope terms

5. representation terms

The following list contains some examples of

concept name structuring. The first two are

equipment class names and the last two are property

names. Qualifier terms have been separated by curly

brackets and representation terms by square

brackets. A slash separates the preposition and scope

qualifiers from the root term (underlined).

1. {Tube heat} exchanger

2. {Piston} compressor

3. {Bearing inlet} pressure

/of oil

4. {Manufacturer

} [name]

3.5 Hierarchy Relationships

A necessary condition for finding any

correspondence relations is that both names under

comparison have the same root term, i.e. root term

equality. If this condition is true, the type of the

found correspondence relationship can be defined

based on the structuring information of the both

entity names. The following rules were applied (the

source and target names are assumed to be otherwise

similar, apart from the differences stated by the

rules):

 If the source name has one preceding qualifier

more than the target name, the target entity is a

direct super class of the source entity (label “A<B”).

 If the source name has one preceding qualifier

less than the target name, the target entity is a direct

sub-class of the source entity (label “A>B”) .

 If the names differ only in their scope term

(representation term) parts, an equality with scope

(equality with representation) relationship will be

assumed (label: “As=B”, “Ar=B).

 If both names have the same number of qualifier

terms, but the first terms are different, a sibling rela-

KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development

392

tionship is assumed (label “A--B”).

Figure 1 presents three different correspondence

relations that can be found for the source concept

“centrifugal pump” applying equality matching and

the simple rules above. Table 1 lists some

relationships found for property concepts using the

above rules.

Figure 1: A concept name structuring and three possible

semantic correspondence relations.

Table 1: Correspondence relations between properties.

4 MATCHING RESULTS

At the beginning of the harmonization process, two

PSK standards were selected to be harmonized with

the initial set of ISO 15926-4 Reference Data

(2010). The first of them, PSK5965 Equipment

Classes and Subclasses, (321) was matched against

the equipment class sets of ISO 15926-4 (5465) and

the second standard, PSK5980 Data Element

Dictionary, (353properties) against the property sets

of ISO 15926-4 (1986).

The source and target entity sets have many

differences. ISO 15926-4 (target set) contains in

total ten times more entities than the PSK standards,

and those entities have been categorized into several

context collections. The taxonomy structure is also

different. ISO 15926-4 has a deep generalization

hierarchy at least up to eight levels, whereas the

number of levels in the PSK5965 standard has been

limited to two (main class – subclass). Furthermore,

only ISO 15926-4 includes textual descriptions for

equipment classes and properties.

4.1 Comparing Alignment Results

The matching tasks were first carried out using the

EM tool. In addition, the S-Match tool (S-M) was

used for the same tasks, in order to evaluate the

capabilities of an extrinsic method using general

language WordNet dictionary (WordNet) and a

structural method in this special case. The S-M

approach applies a name structuring algorithm, in

which it represents a concept node as a logical

expression of the meanings of its term words. The

local meaning of an atomic concept is its natural

language meaning defined in WordNet (Giunchiglia,

et. al. 2007).

Figure 2: Number of PSK equipment classes (equip) and

properties (prop) for which an equality match with ISO

15926-4 was found by EM and S-M tools.

4.1.1 Equality Relations

Figure 2 presents the number of source (PSK)

concepts that were found to have an equality (eq)

relation with at least one target (ISO) concept. It

indicates that all matches (100;39) found by the EM

tool were correct ones, i.e. true positives (dark and

light green solid). S-M tool found only a few more

correct matches (compared with the EM method

without q-syn step) by browsing WordNet synsets;

in total for (89;36) PSK entities.

However, the S-M tool found also several false

positives. Post-analysis of the results revealed that

about one half of those mismatches were actually

close synonyms (blue texture dashed) in a natural

language context (WordNet), but cannot be

considered equal in an industrial context.

Furthermore, there were a large set of source

classes (40;6) for which S-M found matches that

were clearly incorrect (white dashed). Some of these

false positive results are related to the internal

representation of the concepts as logical expressions.

The order of the term words in a multiword concept

does not have any impact on interpretation of this

expression. In contrast, the algorithm used in EM

takes into account the order of the term words in a

concept name so that this kind of mismatch is not

possible.

PSK:Property Rel. ISO:Property

Diameterofdrum As=B Diameter

Frequencyofvibrator As=B Frequency

Bearinginletpressureofoil As<B Inletpressure

Manufacturer A=Br Manufacturername

100

120

140

160

180

EMEquip S‐MEguip EMProp S‐MProp

PSKentitiesinequalityrelationwithISO15926‐4

false

falsesyn

truesyn

true

A LIGHTWEIGHT ELEMENT MATCHING METHOD FOR INDUSTRIAL TERMINOLOGY HARMONIZATION -

Exploiting Minimal Semantics based on Naming Conventions

393

4.1.2 Matching Quality Measures

Matching quality can be indicated by quality

measures. The discovered alignment sets are

compared against a reference set containing all the

correct correspondence relations. In this case, the

reference set is the final refined matching set

produced by the industrial expert group. The

matching correctness measure is precision, defined

as the percentage of discovered correct

correspondences in the entire extracted alignment

set. The completeness measure of matching is recall,

defined as the percentage of discovered correct

correspondences in the reference alignment set. The

F-measure is computed as a harmonic mean of

precision and recall. All these measures vary in the

[0,1] range. (Euzenat, 2007).

Figure 3: Matching quality measures of the equality

alignment sets produced by EM method (EM-A), EM

method without q-syn (EM-B) and S-M method (S-M).

These quality measures for equality alignment

sets are presented in Figure 3. The results of S-M

tool should be compared with the EM results

without the ad-hoc q-syn step (EM-B). This

comparison reveals that the recall measures (middle

bar) are almost the same (0.65; 0.67), but the

precision (left bar) of the S-M method is much lower

(1.0; 0.38).

A separate test case was generated for evaluating

the feasibility of a structural method for a case, in

which the hierarchy structures are very different.

The S-M tool was used in matching the source file

(PSK5965) with one of the target category files (ISO

Rotating), both in their full hierarchy format. The

quality measures of this test case (S-M Hier) are

presented in Figure 4, together with flat structure test

cases (EM B, S-M Flat). These results indicate that

the extra structural information did not provide any

advantage in this special case. On the contrary, the

recall measure was notably decreased.

Figure 4: Matching quality measures of the equality

alignment sets produced by EM method (EM-B), S-M

method with flat hierarchy (S-M flat) and S-M method

with full hierarchy (S-M Hier).

4.1.3 Super Class and Subclass Relations

The primary purpose of the EM name structuring

algorithm is to find hierarchy correspondence

relations with good precision. These relations

include direct super class (A<B), direct sub-class

(A>B) and sibling class (A- -B) relations. The

following Table 2 lists the total number of some of

these correspondence relations (alignments).

Table 2: Total numbers of alignments found by the EM

method and S-M method.

The results of the EM tool are compared with

those produced by S-M tool. The S-M approach

deduces semantic relations between entities by

logical inference. Therefore, these relations are:

equivalence (A=B), more general (A<<<B), more

specific (A>>>B) and disjoint (⊥) (Giunchiglia,

et.al., 2007).

These alignment sets have not been fully

checked for validity by the industrial expert group.

However, a partial analysis indicated that the spot

checked alignments found by EM are true positives,

whereas S-M has also found many clearly incorrect

ones. The main reason for the high precision of the

EM alignment sets is due to the fact that the name

structuring rules comply with the naming

conventions applied during terminology

development.

0,00

0,20

0,40

0,60

0,80

1,00

1,20

EM‐AEM‐BS‐M

PSK5965‐ ISO15926‐4

precision

recall

F0.5‐meas.

0,00

0,20

0,40

0,60

0,80

1,00

1,20

EM‐BS‐MFlat S‐MHie

PSK5965‐ ISORotating

precision

recall

F0.5‐ meas.

A=B A<B A>B A‐‐B

ElemMatch 100 174 361 922

A=B A<<<B A>>>B

S‐Match 226 2651 8281 ‐

PSK5965‐ISO15926‐4AlignmentSets

KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development

394

5 CONCLUSIONS

The harmonization of terminologies used in

industrial standards has been widely understood to

be necessary for better interoperability of industrial

information systems. Partial automation of the

comparison and matching phases of the

harmonization process is considered necessary, in

order to reduce the workload of human experts and

to speed up the process. However, advanced

ontology matching methods are not directly

applicable, because terminology dictionaries are not

true ontologies and may differ greatly in their

taxonomy structure and lexical content. We have

developed a lightweight element level matching

approach to address this problem. It is based on

general concept name structuring rules defined in

terminology work standards. This approach is

applicable, when similar naming conventions have

been applied.

This ElemMatcher approach was applied to an

industrial terminology matching case in the first

phase of the PSK - ISO 15926-4 harmonization

process. The matching results indicate high

matching precision for the equality alignment set

and good precision of the other alignment sets.

Additional experiments using advanced structural

and extrinsic methods that exploit only general

purpose dictionaries showed that no advantage was

gained in this case study of industrial terminology

standards harmonization.

REFERENCES

CEN Orchid Roadmap – Standardising information in the

plant engineering supply chain. Parts 1-3. [referenced

2011-04-15]. Available at: http://www.cen.eu/CEN/

sectors/sectors/isss/workshops/Pages/workshop orchi

d.aspx).

Euzenat, J. Shvaiko, P., 2007. Ontology Alignment.

Springer. ISBN 978-3-540-49611-3.

Fiorentini, X., Rachuri, S., Ray, S., Sriram, R., 2009.

Towards a method for harmonizing information

standards. 5th Annual IEEE Conference on

Automation Science and Engineering. Bangalore,

India, August 22-25, 2009.

Giunchiglia, F., Yatskevich, M., Shvaiko, P., 2007.

Semantic Matching: Algorithms and Implementation.

Technical Report # DIT-07-001, Department of

Information and communication Technology,

University of Trento.

Giunchiglia, F., Dutta, B., and Maltese, V., 2009. Faceted

Lightweight Ontologies. Conceptual Modeling:

Foundations and Applications. Alex Borgida, Vinay

Chaudhri, Paolo Giorgini, Eric Yu (Eds.) LNCS,Vol.

5600, Springer, pp 36-51.

ISO 704:2000,Terminology work — Principles and

methods. [referenced 2011-04-15]. Available at:

http://www.iso.org/iso/store.htm

ISO 860:2007 Terminology work – Harmonization of

concepts and terms. [referenced 2011-04-15].

Available at: http://www.iso.org/iso/store.htm

ISO 15926:2007, Industrial automation systems and

integration — Integration of life-cycle data for process

plants including oil and gas production facilities.

[referenced 2011-04-15]. Available at: http://www.iso.

org/iso/iso_catalogue/catalogue_tc

ISO 15926-4:2010, Industrial automation systems and

integration — Integration of life-cycle data for process

plants including oil and gas production facilities - Part

4: Initial reference data. [referenced 2011-04-15]. (ed1

files available at: http://ng.tc184-sc4.org/index.cfm?

PID=804&FID=56498&r=/)

ISO/IEC 11179-5:2010 Information technology -

Metadata registries. Part 5: Naming and identification

principles. [referenced 2011-04-15]. Available at:

http://metadata-stds.org/11179/

Jean-Marya, Y., Shironoshitaa, E., Kabuka, M., 2009.

Ontology matching with semantic veriﬁcation. Web

Semantics: Science, Services and Agents on the

WorldWideWeb 7. Elsevier. 235–251

Lauser, B., et al., (2008), ‘Comparing human and

automatic thesaurus mapping approaches in the

agricultural domain’. In Proceedings of the 2008

International Conference on Dublin Core and

Metadata Applications, pp. 43–53.

Leukel, J., 2006. Controlling Property Growth in Product

Classification Schemes: A data management

Approach. Enterprise Information Systems: 8th

International Conference, ICEIS 2006.

PSK Standardisation. [website]. [referenced 2011-04-15].

Available at: http://www.psk-standardisointi.fi/

Rahm, E., Bernstein, P., 2001. A survey of approaches to

automatic schema matching. T.he VLDB Journal 10,

Springer. pp. 334–350

Shvaiko, P., Euzenat, J. 2005. A Survey of Schema-Based

Matching Approaches LNCS 3730, Springer. pp. 146–

171.

Shvaiko, P., Euzenat, J., 2008. Ten Challenges for

Ontology Matching. LNCS 5332, Springer. pp. 1164–

1182.

Uslar, M., Rohjans, S., 2009. Ontology-based Integration

of the Heterogeneous Standards IEC 61970 and

61850. In: Proceedings of International ETG-

Kongress 2009. VDE Verlag Gmbh. Paper 1.59.

WordNet - A Lexical Database for English. Princeton

University. [referenced 2011-04-15] http://wordnet.

princeton.edu/

Zhan, P., Jayaram, U., Kim, O., Zhu, L., 2010. Knowledge

Representation and Ontology Mapping Methods for

Product Data in Engineering Applications. Journal of

Computing and Information Science in Engineering.

June 2010, Vol. 10.

A LIGHTWEIGHT ELEMENT MATCHING METHOD FOR INDUSTRIAL TERMINOLOGY HARMONIZATION -

Exploiting Minimal Semantics based on Naming Conventions

395
