TOWARDS A COMMON BODY OF KNOWLEDGE

FOR ENGINEERING SECURE SOFTWARE AND SERVICES

∗

Widura Schwittek, Holger Schmidt, Stefan Eicker and Maritta Heisel

paluno: The Ruhr Institute for Software Technology, University of Duisburg-Essen, Duisburg and Essen, Germany

Keywords:

Common body of knowledge, Knowledge management, Software engineering, Security engineering, Services

computing, Interdisciplinary.

Abstract:

Interdisciplinary communities involve people and knowledge from different disciplines in addressing a com-

mon challenge. Differing perspectives, processes, methods, tools, vocabularies, and standards are problems

that arise in this context. We present an approach to support bringing together disciplines based on a com-

mon body of knowledge (CBK), in which knowledge from different disciplines is collected, integrated, and

structured. The novelty of our approach is twofold: ﬁrst, it introduces a CBK ontology, which allows one to

semantically enrich contents in order to be able to query the CBK in a more elaborate way afterwards. Second,

it heavily relies on user participation in building up a CBK, making use of the Semantic MediaWiki as a plat-

form to support collaborative writing. The CBK ontology is backed by a conceptual framework, consisting of

concepts to structure the knowledge, to provide access options to it, and to build up a common terminology. To

ensure a high quality of the provided contents and to sustain the community’s commitment, we further present

organizational means as part of our approach. We demonstrate our work using the example of a Network of

Excellence EU project, which aims at bringing together researchers and practitioners from services computing,

security and software engineering.

1 INTRODUCTION

Software engineering (SE) can be considered as an

“umbrella discipline”: typical SE tasks involve in-

terdisciplinary knowledge about processes, methods,

tools, and standards. Consequently, new types of SE

sub-disciplines have emerged bringing together SE

and other disciplines. For example, the ﬁeld of secu-

rity engineering, which “is about building systems to

remain dependable in the face of malice, error, or mis-

chance” (Anderson, 2001), has been combined with

SE, and is referred to as secure software engineering.

Bringing together different disciplines harbors a

number of problems, such as bringing together dif-

fering perspectives, vocabularies, and approaches.

Moreover, these problems have to be considered with

respect to multiple dimensions such as research and

practice, which further complicates the situation.

We present in this paper an approach to over-

come the aforementioned problems based on a com-

∗

This research was partially supported by the EU project

Network of Excellence on Engineering Secure Future Inter-

net Software Services and Systems (NESSoS, ICT-2009.1.4

Trustworthy ICT, Grant No. 256980).

mon body of knowledge (CBK). While existing bod-

ies of knowledge (BOKs) like the Software Engineer-

ing Body of Knowledge (SWEBOK) (Bourque and

Dupuis, 2005) solely rely on books or hypertext sys-

tems as a medium, our CBK provides several advan-

tages such as improved ﬂexibility and access possi-

bilities for its users. In fact, the CBK introduces

an ontology that allows users to semantically enrich

content. The CBK ontology is backed by a concep-

tual framework consisting of three main pillars: The

structuring of knowledge from different disciplines

that the CBK collects and integrates, such as speciﬁc

tools, methods, and notations constitutes the ﬁrst pil-

lar. To consolidate an interdisciplinary community,

we need a common understanding of the key con-

cepts as well as a common vocabulary of the differ-

ent disciplines. The CBK introduces a common ter-

minology, i.e., necessary basic notions and relations

between them. The common terminology is the sec-

ond pillar, and it allows us to create a mapping be-

tween discipline-speciﬁc terminology and the notions

of the common terminology. The last pillar comprises

means to group knowledge in order to provide a va-

riety of access options to the knowledge for a wide

369

Schwittek W., Schmidt H., Eicker S. and Heisel M..

TOWARDS A COMMON BODY OF KNOWLEDGE FOR ENGINEERING SECURE SOFTWARE AND SERVICES.

DOI: 10.5220/0003666303690374

In Proceedings of the International Conference on Knowledge Management and Information Sharing (KMIS-2011), pages 369-374

ISBN: 978-989-8425-81-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

range of different target groups. Since the CBK’s

content is semantically enriched, it can be precisely

queried in order to, e.g., ﬁnd appropriate methods to

analyze and solve a given problem. Moreover, the

CBK can be used to contribute to identifying possible

research gaps, weaknesses, and interesting directions

for future research.

Another difference to existing BOKs is that our

CBK heavily relies on user participation supported

by the wiki platform Semantic MediaWiki

with ad-

ditional extensions (SMW+). Consequently, the CBK

supports collaborative writing and provides mecha-

nisms to build up and update the CBK. Since the CBK

will be opened for the public, our approach is comple-

mented by organizational means considering aspects

such as quality assurance to ensure a high quality of

content.

We demonstrate our work using the example of

the EU project Network of Excellence (NoE) on Engi-

neering Secure Future Internet Software Services and

Systems (NESSoS)

, which aims at bringing together

researchers and practitioners from security engineer-

ing, service computing, and SE. One of the main

goals of the NESSoS project is to create a long-lasting

research community on engineering secure software

services and systems. Our approach for creating a

CBK presented in this paper is our contribution to this

goal.

The paper is organized as follows: we brieﬂy

present our case study, the NESSoS EU project, and

outline use cases for the CBK in Sect. 2. In Sect. 3,

we present the concepts and an ontology underlying

our CBK. Section 4 introduces organizational mea-

sures of the CBK. We present related work in Sect. 5.

Finally, we conclude and raise ideas for future work

in Sect. 6.

2 SCOPE AND FUNCTIONALITY

The major goal of NESSoS is to lay the foundation

for a long-lasting research community on engineer-

ing secure software-based Future Internet services

and systems within a funding period of 42 months.

Thus, partners from different ﬁelds coming from both

academia and industry are re-addressing, harmoniz-

ing and integrating research activities. This interdis-

ciplinary and international research setting has a high

demand in transferring knowledge from research into

practice and triggering research from practical chal-

lenges. An impact on training and education activities

http://www.semantic-mediawiki.org

http://www.nessos-project.eu/

in Europe is expected as well. Within this overall ef-

fort of building a long-lasting research community the

CBK plays an integral part. It supports the commu-

nity to integrate and structure overlapping knowledge

areas (e.g. SE, security engineering, services comput-

ing). Having in mind that the CBK should serve as a

ﬂexible computer-based handbook, we identiﬁed sev-

eral roles and use cases in order to sketch the function-

ality and the scope of the CBK. We identiﬁed the re-

searcher, practitioner, administrator and quality agent

as typical roles. Each role has different aims when

using the CBK, which have to be considered when

deﬁning the use cases. We ﬁnally came up with two

groups of use cases. In the ﬁrst group, use cases are

deﬁned concerning the management of contents such

as adding and editing. In the second group, use cases

deﬁne different views on the same contents for dif-

ferent target groups and purposes. Two examples for

the second group of use cases are ”Overview of a spe-

ciﬁc knowledge area” and ”Comparison of different

knowledge entities of the same type”. Based on the

uses cases sketched in this section, we have identiﬁed

four key concepts for a CBK, which we present in the

next section.

3 KNOWLEDGE BASE

STRUCTURE

The basic idea behind the structural concept of the

CBK is to be able to link arbitrary content classes

with each other and to allow users to browse con-

tent along the links. Furthermore, the aim is to pro-

vide several access possibilities to the CBK, each cus-

tomized to the target audiences and use cases the CBK

addresses. In the following, we introduce a concep-

tual framework that consists of four basic concepts:

knowledge objects, knowledge areas, learning trails,

and the common terminology. All these concepts can

be considered as the building blocks of the CBK.

We formalize these CBK concepts using a spe-

cial CBK ontology. Ontologies are used to capture

knowledge about some domain of interest. We use

the OWL (Web Ontology Language)

terminology in

the following. An ontology describes concepts and

relations between them. In OWL, a concept is spec-

iﬁed in terms of a class, i.e., a set of individuals. An

individual represents a concrete object in the domain

in which we are interested. In general, in OWL a re-

lation is speciﬁed as a property, which represents a

binary relation between individuals.

We partially present the current ontology under-

http://www.w3.org/TR/owl2-overview/

KMIS 2011 - International Conference on Knowledge Management and Information Sharing

370

Tool

HasToolTechnicalReq.

...

Method

...

«enumeration»

KnowledgeArea

SoftwareRequirements

SoftwareDesign

...

CommonTerm

...

LearningTrail

...

0..*

HasReferenceToKO

0..n

Pattern

...

KnowledgeObject

HasKOProblemDescription

HasKOSolutionDescription

...

Notation

...

HasToolSupportFor

0..*

LearningTrailStep

...

KOTerm

...

0..*

HasKOTerm

HasLearningTrailStepKA

HasKAParent

0..1 0..*

HasKOKA

HasMethodSupportFor

0..*

HasToolUses

0..*

HasMethodSubMethod

HasMethodPredecessor

0..*

HasMethodNotation

0..*

HasL.T.S.Successor

HasFirstLearningTrailStep

HasL.T.S.Predecessor

HasKONarrowerTerm

HasKOSynonymTerm

HasKOBroaderTerm

0..*0..*0..*

Figure 1: CBK ontology (excerpt).

lying the NESSoS CBK in Fig. 1. We describe the

CBK concepts as well as their representation as part

of the CBK ontology in more detail in the following

subsections.

3.1 Knowledge Objects

A knowledge object (KO) is a fundamental entity of

the CBK. The content of a KO is structured around

the problem and solution description (see exemplary

properties of KO class in Fig. 1) based on the pattern

approach prevalent in SE, such as design and architec-

tural patterns). Each KO can be linked to other KOs,

resulting in a network of KOs, which as a whole can

be considered as a representation of a body of knowl-

edge of a certain discipline. For the initial version of

the CBK, we derived four KO types, which we con-

sider as typical types of contributions to a body of

knowledge of an engineering discipline, engineering

secure software and services in particular. These KO

types are methods, tools, patterns, and notations (see

Fig. 1). We consider them as a starting point, open

for extensions in the future. Methods deﬁne a set of

activities, which in combination with a notation or a

number of notations are used to tackle problems in en-

gineering secure software and services in a systematic

way. Tools support a software engineer in achieving a

development goal in an (at least partially) automated

way. Patterns provide a form through which knowl-

edge about recurring development tasks is codiﬁed.

A notation deﬁnes symbols, a syntax, and semantics

to express relevant artifacts.

3.2 Knowledge Areas

We adopt the concept of knowledge areas (KA) from

the SWEBOK (Bourque and Dupuis, 2005) for our

CBK. KAs span the research ﬁeld as a whole, divid-

ing it into smaller parts and providing an easier ac-

cess to subjects of interest. The SWEBOK was cre-

ated in a long process from 1998 to 2003, involving

approximately 500 reviewers from 42 countries in a

ﬁrst phase and over 120 reviewers from 21 countries

in a second phase. One main result is the world-

wide accepted common understanding of what is to-

day viewed as SE. This includes the differentiation of

the ﬁeld into a number of KAs on which we want to

base our KAs, e.g., software requirements and soft-

ware design (see exemplary properties of KA class in

Fig. 1). We took this decision because we regard the

ﬁeld of engineering secure software and services as

a supplement of SE and therefore concerning all SE

KAs. In addition, we introduce KAs speciﬁc to the

ﬁelds of security and services based on standard liter-

ature. For example, we introduce the KAs risk anal-

ysis and privacy as presented in Anderson’s Security

Engineering book (Anderson, 2001).

Each KA consists of a description providing an

overview of the KA and its scope, as well as relation-

ships to other KAs. KAs are detailed further into sub-

areas, topics and sub-topics. Each topic or sub-topic

contains the following three items: A short state-of-

the-art description of the topic/sub-topic, links to KOs

supporting the topic/sub-topic and a list of the most

relevant publications for further reading.

TOWARDS A COMMON BODY OF KNOWLEDGE FOR ENGINEERING SECURE SOFTWARE AND SERVICES

371

3.3 Learning Trails

Learning trails are a structuring element meant to pro-

vide access to the common body of knowledge on

engineering secure software and services for differ-

ent target groups. This idea is based on the fact that

content has to be prepared in accordance with the

background of the reader. An expert in a topic area

expects more detailed information, whereas a non-

expert needs more contextual information in order to

be able to understand. Learning trails are therefore

written and categorized along different expert lev-

els indicating, e.g., what prior knowledge is required

to understand the content. Another differentiation is

made concerning the reader’s background: if (s)he is

from research or from practice. Learning trails are

realized by moderated tours, which guide the reader

through a set of KOs, which are considered to be part

of a certain topic. Each step builds upon the previous

step and gives a successive introduction into a topic

with respect to the reader’s expert level and back-

ground (see classes LearningTrail and LearningTrail-

Step in Fig. 1). The overall aim of this approach is

to provide access to the CBK for a broad spectrum of

people, regardless of whether the reader is a student,

an experienced expert, a practitioner, or a researcher.

3.4 Common Terminology

The aim of a common terminology is to enable a com-

munity to speak the same language; or at least to sim-

plify the translation of a term to another domain with

the help of a common reference or common term as

we want to call it in the following (see Fig. 1). A

common term is a term with a meaning on which an

agreement was reached within the community. With

the common terminology, we therefore introduce an

instrument for deﬁning a common term with a certain

meaning and for relating different terms with the same

or a similar meaning to this common term. In the

opposite direction, the common terminology serves

the purpose of a dictionary from which synonyms and

translations can be queried. A term does not always

have the same exact meaning of another similar term,

so that deviations to the meaning of the common term

must be made explicit. In the CBK, this is realized by

three different relationship types. A term’s meaning

is either synonymical, broader or narrower in relation

to another term’s meaning (see relationships between

CommonTerm and KOTerm in Fig. 1).

The core CBK team initially creates an ontology

of terms of the domain “engineering secure software

and services” on basis of the existing CBK content

and term usage after a certain period of time. It is

then proposed to the community and reﬁned within

regular feedback cycles.

4 ORGANIZATIONAL

MEASURES

Formulating a body of knowledge for a new discipline

is not a task which is accomplished by an individual.

It is a highly collaborative effort with many people

involved comprising many activities, such as having

discussions about what the core of the discipline is,

what common terminology to agree upon, and what

the state-of-the-art is constituted by, to name just a

few. It should also be realized collaboratively, be-

cause codifying the knowledge into words and sen-

tences or at least referencing existing knowledge like

books and papers means a lot of work. Since the work

is never ﬁnished, regarding of all new research results

contributing to the body of knowledge every day, col-

laboration is the only feasible way to keep the CBK

up-to-date. We acknowledge this by choosing a col-

laborative approach backed by SMW+ to build up a

CBK for engineering secure software and services re-

lying explicitly on user participation.

A CBK has the greatest beneﬁt, if it is complete,

up-to-date, and valid. Especially in the beginning of

such a project this is not the case, leading to low ac-

ceptance and low user participation, if launched for

the public too early. We therefore conceived three

phases, each with a different focus and participation

style in order to work against this effect. Furthermore,

the CBK content has to be revised on a regular basis

to ensure a high quality, which can be summed up by

the question: How is content provisioning and quality

assurance supported best while relying on user partic-

ipation?

We present the three phases in Sect. 4.1, and we

introduce quality assurance means in Sect. 4.2.

4.1 Three Phases

The ﬁrst phase is a planning phase, in which all dis-

cussed aspects are considered while preparing the ini-

tial CBK structure and planning.

During an inception phase, content is provided

by a closed user group, consisting of experts from

different areas within the secure software develop-

ment ﬁeld. These experts are mainly researchers from

NESSoS, where we proﬁt from the opportunity of

having so many researchers linked together through

the NoE. The writing process is managed by a central

coordinator, who creates the initial CBK structure, de-

ﬁnes clear writing responsibilities, watches deadlines,

KMIS 2011 - International Conference on Knowledge Management and Information Sharing

372

and ensures quality (see Sect. 4.2). At the end of this

phase, the result is a sound CBK content base pro-

viding a complete, up-to-date, and validated state-of-

the-art of this interdisciplinary research ﬁeld. A high

beneﬁt of this work is expected for researchers from

service, security, and software engineering. But also

practitioners will ﬁnd it interesting to get a glimpse

on what current research has to offer.

The run phase is marked by the launch of the CBK

for the general public in terms of reading and writ-

ing. At this point in time, the CBK should provide

a complete overview of the research ﬁeld of secure

software development. To launch the CBK with a

sound content base, which has mostly been created by

the community itself, increases the attraction of the

CBK for other people that we considered in the use

cases (see Sect. 2). Especially for practitioners and

for stakeholders other than researchers, learning trails

will guide through the vast amount of research results,

with respect to their expert level (see Sect. 3.3).

4.2 Quality Assurance

The SMW+ supports quality assurance tasks in dif-

ferent ways. Authors are notiﬁed via e-mail, when

other people have modiﬁed their KO. In the case of

vandalism or wrong information, it is possible to re-

vert the changes back to a previous state, making use

of the versioning functionality of SMW+. If provided

information is controversial, the system allows users

to have discussions for each knowledge object on the

same page. If new attributes are introduced into the

ontology, it is usually the case that these attributes

lack of values for existing individuals. SMW+ pro-

vides a mechanism to gather information about miss-

ing attribute values and allows us to notify the respec-

tive author. Furthermore, SMW+ provides an elabo-

rate access control mechanism, which makes it possi-

ble to deﬁne groups and assign read and write access

rights. We make use of this mechanism in order to

introduce roles, each with different access rights for,

e.g., KOs, KAs or administrative functions of SMW+.

Depending on the project phase, quality is assured

in different ways.

In the inception phase, quality is assured by a re-

strictive access control, allowing only partners of the

network to have full access to the CBK. Additionally,

a central quality assurance (QA) team will start their

work having a regular qualitative review on the con-

tents of the CBK, ﬂagging them with a marker indi-

cating when a KO needs to be revised due to a low

content quality. But not only the QA team is able to

ﬂag KOs. Everyone is allowed to ﬂag an article if

vandalism is detected.

While the inception phase is characterized by

a controlled environment through a closed user

group, the run phase takes a more decentralized and

community-driven approach. Since we assume that

we will reach a critical mass of users during a short

period after going public, content contribution will in-

crease and self-regulation will become realistic. Thus,

quality assurance is incrementally shifted over to the

user, because the QA task is no more feasible to be ex-

ercised by a few experts. Instead, experts will rather

be assigned responsibilities along the knowledge ar-

eas, taking a more moderating role.

As already mentioned, the underlying SMW+

platform supports both approaches, providing ade-

quate collaboration functionality such as feedback

and access control mechanisms.

5 RELATED WORK

The concept of a codiﬁed BOK is not new and can be

found in many different disciplines. Compared to our

CBK, they all differ in how they were created and in

how knowledge is codiﬁed.

All of the BOKs presented in the following were

created top-down. By this we mean that an expert

team was formed or authors were chosen to write ar-

ticles. Our approach comprises a top-down phase, but

also a bottom-up phase in which the CBK is opened

to the public in terms of reading and writing (see

Sect. 4). This is comparable to the shift from the cre-

ation of the Encyclopedia Britannica to the creation of

Wikipedia, acknowledging the fact that new knowl-

edge is generated very fast and by many people these

days.

A BOK mentioned before is the “Software

Engineering Body of Knowledge” aka SWEBOK

(Bourque and Dupuis, 2005), the most prominent

among all other BOKs within the SE discipline. The

Computer Engineering Body of Knowledge (Com-

puting Curricula 2005) (Div. Auth., 2006) and the

Software Engineering Education Knowledge (SEEK)

(part of (Div. Auth., 2004)) have a special focus on SE

education. The Project Management Body of Knowl-

edge (PMBOK) (Project Management Institute, 2008)

is also well-known and covers project management

knowledge in general. In the security ﬁeld, BOKs do

exist with different focuses promoted by both indus-

try and governments such as the Information Tech-

nology Security Essential Body of Knowledge (U.S.

Department of Homeland SecurityOfﬁce of Cyberse-

curity and Communications National Cyber Security

Division, 2008).

A more collaborative approach is taken by the two

TOWARDS A COMMON BODY OF KNOWLEDGE FOR ENGINEERING SECURE SOFTWARE AND SERVICES

373

BOK projects Usability BOK

and Build Security In

by the U.S. Department of Homeland Security, both

also fostering user participation to provide content

following a bottom-up approach.

All of the BOKs presented so far do not allow

to be queried elaborately. Many BOKs only exist

as a book with access possibilities given by the ta-

ble of contents or a key word index, while others also

provide a hypertext system, allowing one to browse

content along links, such as the online version of the

SWEBOK

, the IEEE Body of Knowledge on Services

Computing

or the Guide to the Systems Engineer-

ing Body of Knowledge (G2SEBoK)

. We go one step

further and allow more elaborate queries through our

CBK ontology with which we are able to semantically

enrich all CBK contents.

The need for deﬁning a common terminology for

different interdisciplinary communities led to a large

number of publications in this area, e.g., the work by

Fabian et al. (Fabian et al., 2010) for SE and security.

Similar to our common terminology concept, their ap-

proach deﬁnes a taxonomy relating fundamental no-

tions across the different disciplines, and they spec-

ify to what extent notions from one discipline can be

translated into notions of the other discipline. The

main difference to our work is that Fabian et al. do

not complement their results by further concepts such

as KAs, learning trails, etc. to create a CBK.

6 CONCLUSIONS

In this paper, we presented a conceptual approach to

support bringing together disciplines based on a CBK.

We demonstrated our approach using the NESSoS EU

project and the interdisciplinary ﬁeld of engineering

secure software and services.

Our approach comprises the following main con-

tributions to consolidate interdisciplinary communi-

ties:

• KOs allows users to structure knowledge such as

best practices and research results according to

their type. Provided content is semantically en-

riched in an automated manner. This allows users

to browse, compare, and run complex queries on

the CBK.

• The CBK introduces a mechanism to group

knowledge into KAs. This provides access to the

http://www.usabilitybok.org

https://buildsecurityin.us-cert.gov

http://www.computer.org/portal/web/swebok

http://www.servicescomputing.tv

http://g2sebok.incose.org

CBK via a hierarchical taxonomy and represents

a valuable instrument to discover gaps in practice

and research.

• The common terminology helps the community

to ﬁnd a common language of the different dis-

ciplines, and to deﬁne and use translations.

• Learning trails provide access to the CBK for a

broader audience, practitioners and researchers in

particular.

• The ontology which underlies the whole CBK

supports several representations of the CBK, in-

cluding known ones like books and hyper texts. It

provides the ﬂexibility to create customized rep-

resentations.

• User participation is supported by adequate pro-

cesses and by the chosen SMW+, which might

lead to a more up-to-date, a more comprehensive,

and a sustainable CBK.

• The realization of the CBK through SMW+ pro-

vides a smart means to allow collaborative cre-

ation and editing since SMW+ is fully integrated

with the design of the ontology.

In the future, we plan to elaborate more on us-

ing the ontology properties for speciﬁc use cases such

as identifying gaps in research areas. Moreover, we

want to include user rating mechanisms in our CBK

concept.

REFERENCES

Anderson, R. (2001). Security Engineering. Wiley.

Bourque, P. and Dupuis, R., editors (2005). SWEBOK –

Guide to the Software Engineering Body of Knowl-

edge. IEEE Computer Society.

Div. Auth. (2004). Software engineering 2004: Curriculum

guidelines for undergraduate degree programs in soft-

ware engineering.

Div. Auth. (2006). Computing Curricula 2005: The

Overview Report: A volume of the Computing Curric-

ula Series. Computing Curricula Series. Association

for Computing Machinery and Association for Infor-

mation Systems and IEEE Computer Society.

Fabian, B., G

urses, S., Heisel, M., Santen, T., and Schmidt,

H. (2010). A comparison of security requirements en-

gineering methods. Special Issue on Security Require-

ments Engineering, 15(1):7–40.

Project Management Institute (2008). A Guide to the

Project Management Body of Knowledge (PMBOK

Guide). Project Management Institute, 4th edition.

U.S. Department of Homeland SecurityOfﬁce of Cyberse-

curity and Communications National Cyber Security

Division (2008). Information technology (IT) secu-

rity essential body of knowledge (EBK): A compe-

tency and functional framework for it security work-

force development.

KMIS 2011 - International Conference on Knowledge Management and Information Sharing

374
