CLUSTERING OF HETEROGENEOUSLY TYPED DATA
WITH SOFT COMPUTING
Angel Kuri-Morales
1
, Luis Enrique Cortes-Berrueco
2
and Daniel Trejo-Baños
2
1
Instituto Tecnológico Autónomo de México, Río Hondo No. 1 México D.F., Mexico
2
Universidad Nacional Autónoma de México, Apartado Postal 70-600, Ciudad Universitaria, México D.F., Mexico
Keywords: Clustering, Categorical variables, Soft computing, Data mining.
Abstract: The problem of finding clusters in arbitrary sets of data has been attempted using different approaches. In
most cases, the use of metrics in order to determine the adequateness of the said clusters is assumed. That is,
the criteria yielding a measure of quality of the clusters depends on the distance between the elements of
each cluster. Typically, one considers a cluster to be adequately characterized if the elements within a
cluster are close to one another while, simultaneously, they appear to be far from those of different clusters.
This intuitive approach fails if the variables of the elements of a cluster are not amenable to distance
measurements, i.e., if the vectors of such elements cannot be quantified. This case arises frequently in real
world applications where several variables correspond to categories. The usual tendency is to assign
arbitrary numbers to every category: to encode the categories. This, however, may result in spurious
patterns: relationships between the variables which are not really there at the offset. It is evident that there is
no truly valid assignment which may ensure a universally valid numerical value to this kind of variables.
But there is a strategy which guarantees that the encoding will, in general, not bias the results. In this paper
we explore such strategy. We discuss the theoretical foundations of our approach and prove that this is the
best strategy in terms of the statistical behaviour of the sampled data. We also show that, when applied to a
complex real world problem, it allows us to generalize soft computing methods to find the number and
characteristics of a set of clusters.
1 INTRODUCTION
Clustering can be considered the most important
unsupervised learning problem. As every other
problem of this kind, it deals with finding a structure
in a collection of unlabeled data. In this particular
case it is of relevance because we attempt to
characterize sets of data trying not to start from
preconceived measures of what makes a set of
characteristics relevant.
When the similarity criterion is distance: two or
more objects belong to the same cluster if they are
“close” according to a given distance (in this case, as
will be discussed, geometrical distance). This is
called distance-based clustering.
An important component of a clustering
algorithm is the distance measure between data
points.
Regardless of the distance we select it is clear
that it implies handling of exclusively numerical
vectors. To illustrate this fact we mention four of the
most used metric clustering algorithms:
K-means
Fuzzy C-means
Hierarchical clustering
Neural Networks (Self Organizing Maps)
K-means is an exclusive clustering algorithm, Fuzzy
C-means is an overlapping clustering algorithm,
Hierarchical clustering is obvious and, lastly, SOMs
are based on the connectionist paradigm.
The mentioned methods are conceptually
different. These methods are all, however, metric. It
is clear, that all of the metric algorithms are rendered
useless when one or more of the variables is non-
numeric. And this underlines the importance of
being able to encode categorical variables. As stated
before, we focus on finding an adequate encoding. A
natural alternative, of course, is to abandon metric
algorithms and there have been many attempts to do
so (Shyam, 2008).
499
Kuri-Morales A., Cortes-Berrueco L. and Trejo-Baños D..
CLUSTERING OF HETEROGENEOUSLY TYPED DATA WITH SOFT COMPUTING.
DOI: 10.5220/0003690304910494
In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 491-494
ISBN: 978-989-8425-79-9
Copyright
c
2011 SCITEPRESS (Science and Technology Publications, Lda.)
2 UNBIASED ENCODING OF
CATEGORICAL VARIABLES
We introduce an alternative which allows the
generalization of numerical algorithms to encompass
categorical variables. Our concern is that such
encoding:
a) Does not induce spurious patterns
b) Preserves legal patters, i.e. those present in the
original data.
By "spurious" patterns we mean those which may
arise by the artificial distance induced by any
encoding. On the other hand, we do not wish to filter
out those patterns which are present in the
categories. If there is an association pattern in the
original data, we want to preserve this association
and, furthermore, we wish to preserve it in the same
way as it presents itself in the original data. The
basic idea is simple: "Find the encoding which best
preserves a measure of similarity between all
numerical and categorical variables".
In order to do this we start by selecting Pearson's
correlation as a measure of linear dependence
between two variables. Higher order dependencies
will be hopefully found by the clustering algorithms.
This is one of several possible alternatives. Its
advantage is that it offers a simple way to detect
simple linear relations between two variables. Its
calculation yields "r", Pearson's correlation, as
follows:
 


2
Y
2
YN
2
X
2
XN
YXXYN
r
(1)
Where variables X and Y are analyzed to search
their correlation, i.e. the way in which one of the
variables changes (linearly) with relation to the
other. The values of "r" in (1) satisfy
11
r
.
What we shall do is to search for an encoding for
categorical variable “A” so that the correlation
calculated from such encoding does not yield a
significant difference with any of the possible
encodings of all other categorical or numerical
variables.
2.1 The Algorithm
We define the i-th instance of a categorical variable
V
X
as one possible value of variable X. We denote
the number of variables in the data as V. Further, we
denote with r
ik
Pearson's correlation between
variables i and k. We would like to a) Find the mean
μ of the correlation's probability distribution for all
categorical variables by analyzing all possible
combinations of codes assignable to the categorical
variables plus the original (numerical) values of all
non-categorical variables. b) Select the codes for the
categorical variables which yield the closest value to
μ. The rationale is that the absolute typical value of
μ is the one devoid of spurious patterns and the one
preserving the legal patterns. In the algorithm to be
discussed next the following notation applies:
N number of elements in the data
V number of categorical variables
V[i] the i-th variable
Ni
number of instances of V[i]
r
j
the mean of the j-th sample
S sample size of a mean
r
mean of the correlation's
distribution of means
r
standard deviation of the
correlation's distribution of means
Algorithm A1. Optimal Code Assignment for Categorical
Variables.
01 for i=1 to V
02 j 0
03 do while
j
r
is not distri-
buted normally
04 for k=1 to S
05 Assign a code for variable
V[i]
06 Store this code
07
integer random number
(1 V; i)
08 if variable V[ ] is cate-
gorical
09 Assign a code for
variable V[
]
10 endif
11





2
2
2
2
YYNXXN
YXXYN
r
k
12 endfor
13 Calculate
S
k
kj
r
S
r
1
1
14 j j+1
15 enddo
16
r
; the mean of the
correlation's distribution
17
r
ss
; the std. dev. of the
correlation's distribution
18 Select the code for V[i] which
yields the
r
k
closest to
μ
19 endfor
For simplicity, in the formula of line (11), X stands
for variable V[i] and Y stands for variable V[
]. Of
KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval
500
course it is impossible to consider all codes, let
alone all possible combinations of such codes.
Therefore, in algorithm A1 we set a more modest
goal and adopt the convention that to Assign a Code
[as in lines (05) and (09)] means that we restrict
ourselves to the combinations of integers between 1
and Ni (recall that Ni is the number different values
of variable i in the data). Still, there are Ni! possible
ways to assign a code to categorical variable i and
Ni! x Nj! possible encodings of two categorical
variables i and j. An exhaustive search is, in general,
out of the question. Instead, we take advantage of
the fact that, regardless of the way a random variable
distributes (here the value of the random encoding of
variables i and j results in correlation r
ij
which is a
random variable itself) the means of sufficiently
large samples very closely approach a normal
distribution(Feller, 1966). Furthermore, the mean
value of a sample of means
r
μ and its standard
deviation
r
σ are related to the mean μ and standard
deviation σ of the original distribution by
r
μμ
and
r
σSSσ . What a sufficiently large sample
means is a matter of convention and here we made
S=25 which is a reasonable choice. Therefore, the
loop between lines (03) and (15) is guaranteed to
end. In our implementation we split the area under
the normal curve in deciles and then used a
goodness-of-fit test with p=0.05 to determine that
normality has been achieved. This approach is
directed to avoid arbitrary assumptions regarding the
correlation's distribution and, therefore, not selecting
a sample size to establish the reliability of our
results. Rather, the algorithm determines at what
point the proper value of μ has been reached.
Furthermore, from Chebyshev's theorem, we know
that:
2
1
1)(
k
kXkP
(2)
If we make k=3 and assume a symmetrical
distribution, the probability of being within three σ's
of the mean is roughly 0.95.
Three other issues remain to be clarified.
1) To Assign a code to V[i] means that we generate
a sequence of numbers between 1 and Ni and then
randomly assign a one of these numbers to every
different instance of V[i].
2) To Store the code [as in line (06)] means NOT
that we store the assigned code (for this would imply
storing a large set of sequences). Rather, we store
the value of the calculated correlation along with the
root of the pseudo random number generator from
which the assignment was derived.
3) Thereafter, selecting the best code (i.e. the one
yielding a correlation whose value is closest to μ) as
in line (18) is a simple matter of recovering the root
of the pseudo random number generator and
regenerating the original random sequence from it.
3 CASE STUDY: PROFILE OF
CAUSES OF DEATH IN A
LARGE HUMAN POPULATION
In order to illustrate our method we analyzed a data
base corresponding to the life span and cause of
death of 50,000 individuals between the years of
1900 and 2007. The confidentiality of the data has
been preserved by changing the locations and
regions involved. Otherwise data are a faithful
replica of the original.
The database contains 50,000 tuples consisting
of 11 fields: BirthYear, LivingIn, DeathPlace,
DeathYear, DeathMonth, DeathCause, Region, Sex,
AgeGroup, AilmentGroup and InterestGroup.
Therefore, our working data base has 10 dimensions
since the last variable (InterestGroup) corresponds to
interest groups identified by human healthcare
experts in this particular case and was not
considered. This last field corresponds to a heuristic
clustering of the data and could be used for the final
comparative analysis of resulting clusters as the
comparative analysis between the expert’s clusters
and the resulting clusters. We will explore this line
in future works.
Once the data were encoded, we proceeded to
use an unsupervised learning method for the
clustering process. First we needed to determine the
number of clusters in which we would group our
sample.
We applied the fuzzy c-means algorithm to our
coded sample. To determine the number of clusters
we experimented with 17 different possibilities
(assuming from 2 to 18 clusters). In each step we
calculated the partition coefficient and classification
entropy of the clustered data.
We applied the fuzzy c-means algorithm to our
coded sample. To determine the number of clusters
we experimented with 17 different possibilities
(assuming from 2 to 18 clusters). In each step we
calculated the partition coefficient (pc) and
classification entropy (pe) of the clustered data, see
(Lee, 2005); (Shannon, 1949); (Vinh, 2009). Plotting
CLUSTERING OF HETEROGENEOUSLY TYPED DATA WITH SOFT COMPUTING
501
the values of pc and pe against the number of
clusters we got a graph.
To determine the number of clusters, we used the
elbow criterion, see (Ganti, 1999), which indicates
that we should use the value where the change in
tendency is the most notable, in this case this
occurred with 3 and 4 clusters. For clarity, we
picked 3 clusters for this experiment.
Then we proceeded to apply Kohonen´s SOM to
the data. As all data is now in numerical form, the
algorithm was applicable without alterations over
the set of variables. Therefore, after running the
algorithm our data was classified in three clusters
depending on the neuron which was closer to a
specific data field. We interpreted the results
according to the values of the mean of each variable
on each cluster. We rounded the said values for
BirthYear and DeathCause and obtained the
following decoded values:
For cluster 1 the decoded values of the mean for
BirthYear and DeathCause correspond to “1960”
and cancer.
In cluster 2 the values are “1919” and
Pneumonia.
In cluster 3 the values are “1923” and Heart
stroke.
These logical backward results attest to their
validity which, we emphasize, are obtained from an
unbiased numerical encoding. Therefore we can
infer that legal patterns are preserved and,
furthermore, that such patterns (adequately encoded)
allow a numerical method to find the patterns in
spite of the fact that no unique valid metric does, in
general, exist.
4 CONCLUSIONS
We have shown that we are able to find meaningful
results by applying numerically oriented non-
supervised clustering algorithms to categorical data
by properly encoding the instances of the categories.
We were able to determine the number of clusters
arising from the data encoding according to our
algorithm and, furthermore, to interpret the clusters
in a meaningful way. Rather than a priori accepting
essential limitations in numerical methods when
applied to sets of categorical variables, we have
adopted the point of view that machine learning
techniques allow a broader scope of interpretation
which are not marred by limitations of processing
capabilities.
At any rate, the proposed encoding does allow us
to tackle complex problems without limitation due to
the non-numerical characteristics of the data. It is
also a scalable method and independent of the set of
data. Much work remains to be done, but we are
confident that these is the first of a series of
significant applications.
REFERENCES
V. Ganti, J. Gehrke, and R. Ramakrishnan. Cactus-
Clustering categorical data using summaries. In KDD
'99: Proceedings of the fifth ACM SIGKDD
International Conference on Knowledge Discovery
and Data Mining, pages 73-83, New York, NY, USA,
1999. ACM.
Lee, Y., and Choi, S., Minimum entropy, k-means,
spectral clustering, Neural Networks, 2004.
Proceedings IEEE International Joint Conference on,
volume 1, 2005.
Shannon, C. E., and Weaver, W., The Mathematical
Theory of Communication, Scientific American, July
1949.
Shyam Boriah, Varun Chandola, and Vipin Kumar.
Similarity measures for categorical data: A
comparative evaluation. In SDM, pages 243-254,
2008.
Vinh, N. X., Epps, J., and Bailey, J., Information theoretic
measures for clusterings comparison: is a correction
for chance necessary?
Feller, William, An introduction to probability theory and
its applications. Vol. II., Oxford, England: Wiley.
(1966).
KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval
502
