A PROBABILISTIC METHOD FOR PREDICTION OF

MICRORNA-TARGET INTERACTIONS

Hasan Oğul

, Sinan U. Umu

2,3

, Y. Yener Tuncel

and Mahinur S. Akkaya

Department of Computer Engineering, Başkent University, Ankara, Turkey

Department of Chemistry, Middle East Technical University, Ankara, Turkey

Bioinformatics Program, Informatics Institute, Middle East Technical University, Ankara, Turkey

Keywords: MicroRNA target prediction, Markov chains.

Abstract: Elucidation of microRNA activity is a crucial step in understanding gene regulation. One key problem in

this effort is how to model the pairwise interaction of microRNAs with their targets. As this interaction is

strongly mediated by their sequences, it is desired to set up a probabilistic model to explain the binding

between a microRNA sequence and the sequence of a putative target. To this end, we introduce a new

model of microRNA-target binding, which transforms an aligned duplex to a new sequence and defines the

likelihood of this sequence using a Variable Length Markov Chain. It offers a complementary representation

of microRNA-mRNA pairs for microRNA target prediction tools or other probabilistic frameworks of

integrative gene regulation analysis. The performance of present model is evaluated by its ability to predict

microRNA-mRNA interaction given a mature microRNA sequence and a putative mRNA binding site. In

regard to classification accuracy, it outperforms a recent method based on support vector machines.

1 INTRODUCTION

MicroRNAs (MiRNAs) are tiny regulators of gene

expression in post-transcriptional level. Many

evidences suggest that they abundantly exist in many

organisms and play pivotal roles in regulation of

several biological processes (Lee et al., 1993);

(Bartel, 2004). Last decade of bioinformatics

research has been strongly influenced by the

discovery of miRNAs. Recent findings about the

complex behaviour of miRNAs have triggered the

application of computational methods to analyse

miRNA functions and activities. Relevant

computational research has been enriched in several

directions like predicting miRNA targets (Alexiou et

al., 2009); (Saito et al., 2010); (Mendes et al., 2009);

(Hammell 2010); (Bartel, 2009), inferring regulatory

modules or networks comprising miRNAs (Yoon

and Micheli, 2005; Liu et al. 2010), identifying

disease-related miRNAs (Lu et al., 2005); (Madden

et al., 2010) or finding functionally related miRNAs

(Yu and He, 2011); (Wang et al., 2010). The studies

have been resulted with various online tools or

standalone programs developed for storage, retrieval

or analysis of miRNA related data.

Despite the enormous number miRNA target

prediction programs, current systems biology can

benefit too little from their result (Barbato et al.,

2009). The reasons for the limitation of available

tools are two-fold. First, it is hard to see a consensus

in their prediction results, which make them

unreliable to use in generation of further hypotheses.

Second, a conventional tool for target prediction can

only reveal a one-to-one relationship between a

miRNA and an mRNA under consideration.

However, we know that the picture is bigger: one

miRNA can regulate many genes and one gene can

be regulated by multiple miRNAs in cooperation,

even with other regulatory factors (Krek et al., 2005;

Lim et al., 2005). An obvious solution to these

problems is to integrate multiple data sources to

infer more reliable and native explanations. The lack

of sufficient data samples will also motivate the use

of probabilistic methods to construct integrative

frameworks to analyse the multi-source data. Since

it is well-known that a miRNA can target an mRNA

in a sequence-specific manner (Bartel, 2004), an

integrative model, whatever its practical purpose is,

should incorporate the sequence information.

Furthermore, such a model of sequence-based

miRNA-mRNA binding should be defined in a

289

gul H., U. Umu S., Yener Tuncel Y. and S. Akkaya M..

A PROBABILISTIC METHOD FOR PREDICTION OF MICRORNA-TARGET INTERACTIONS.

DOI: 10.5220/0003694902890293

In Proceedings of the International Conference on Neural Computation Theory and Applications (NCTA-2011), pages 289-293

ISBN: 978-989-8425-84-3

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

probabilistic way so that it could represent the

degree of this interaction and be easily incorporated

into other data. Recent attempts for integrating

sequence with functional data have largely ignored

this issue and considered the sequence-directed

miRNA-mRNA interaction in a binary way, which is

usually obtained from other target predictors.

In this study, we aim to provide a means of

modelling miRNA and mRNA regulatory

relationship by a probabilistic description over the

sequential content of a putative miRNA-mRNA

duplex. In this respect, our model first performs a

complementary alignment between the mature

miRNA sequence and a putative binding site from

present mRNA. Resulting alignment is represented

by a new sequence over an alphabet of possible

matches or mismatches, where different base paring

rules are taken into account by distinct alphabet

symbols. The probability of new sequence of

miRNA-mRNA duplex is then analysed using a

Variable Length Markov Chain (VLMC) approach.

VLMC (Ron et al., 1996) is a flexible yet powerful

model to analyse a sequential content based on the

order of local arrangements by quantifying the

probability of the occurrence of a specific symbol

after a certain sub-sequence with varying length less

than a predefined maximum. This enables us to

calculate the likelihood of whole sequence by simply

multiplying local probabilities. For miRNA-mRNA

duplex case, the independence of model from global

position information allows the evaluation of

significant local regions which might be enriched in

any part of miRNA-target duplex formation.

Therefore, the order of distinct base pairs and

mismatches are taken into account in addition to

their frequency of appearances. Two VLMC-based

likelihoods of new sequence which are obtained

from positive and negative training sets can reveal

the degree of a potential interaction between two

entities.

Figure 1: Alignment of miRNA sequence (middle) and

mRNA binding site (top) is transformed into a new

sequence of duplex formation (bottom). It is defined over

a new alphabet of eight letters; six for representing all

possible directional base pairings including G-U and U-G

wobbles, one for mismatches and one for spaces in any

other site.

2 METHODS

2.1 miRNA-mRNA Duplex Sequence

Model

MiRNA-mRNA duplex is constructed by

complementary alignment of mature miRNA

sequence with mRNA binding site. Resulting

alignment transformed into a new sequence defined

over an alphabet of symbols representing a distinct

nucleotide pair type including mismatches and

spaces in any other site (Figure 1). The alignment

algorithm employs well-known dynamic

programming algorithm of Smith and Waterman

(1981).

2.2 Markov Chain Model

Markov chains are used to model sequential data in

terms of order of individual symbols but regardless

of their global positions. A simple model to define

the likelihood of a sequence

is to assume a zero-

order Markov Chain and compute the probability by

multiplying the probabilities of each symbols

contained, i.e.,

where P(.) refers to probability, S

is the random

variable representing the letter at position j with s

its realization.

In Markov chain model, the probability is

identical for each position, thus ignoring the order of

amino acids. The model assumes that each position

is independent from the others; the context

information is not taken into account at all. Since the

complex structure of biological sequences is poorly

reflected with this approach, the use of higher order

models has been suggested (Thijs et al., 2001). In

this respect, the likelihood of the sequence can be

defined by an L-order Markov chain, where the

probability of each symbol depends on the preceding

subsequence of a fixed length L<N.

Fixed-order Markov models, although able to

modeling rich sources in an efficient manner, have

critical drawbacks for practical use. The major

problem is that the number of model parameters

grows exponentially, resulting in a very sharp and

discontinuous transition from under-fitted models to

over-fitted models. Therefore, for a trivial model

order, the model suffers from learnability hardness

results, and consequently, the derived model is not

guaranteed to be optimal (Bejerano and Yona, 2001;



5' GGGUGUUAAGACUUGACACAGUACCUCG 3'

.. |.| | .||.| || ||||||.

3' UUGAUA-UGUUGGA-UG----AUGGAGU 5'

eegbebqageadfbqadqqqqbaccbce







sSPSP

)()(

NCTA 2011 - International Conference on Neural Computation Theory and Applications

290

Ben-Gal et al., 2005). Another limitation is that a

fixed length model order ignores the domain specific

nature of biological sequences and, even with an

optimized selection of L value, the model may not

be effective in the detection of significant cut-off

locations in the duplex chain. A more flexible

version of higher order Markov models allows a

variable order, i.e. memory length, that depends on

the preceding subsequence to given position such

that the order of the model becomes a function the

context at each position (Ron et al., 1996). We

further extend the model to take into account the

succeeding subsequence and define the sequence

likelihood as

where L

and L’

are the optimal lengths for

preceding and succeeding subsequences

respectively. The last modification enables

considering the context surrounding the symbol and

provides a better generalization of the model.

2.3 miRNA-mRNA Interaction

Prediction

MiRNA-mRNA interaction prediction can be

considered to be a binary classification problem

where a duplex sequence is required to be assigned

to one of the positive (C=1) or negative (C



classes. Given a sequence

...s

, starting from

the position 1 and ending at the position N, where s

is drawn from the finite alphabet of nucleotide pair

symbols, we deploy a classification rule based on the

likelihood of the

that reports a positive (target

interaction) label if

)1|(

CSP

)1|(

CSP

negative (no interaction) label otherwise. The

conditional probabilities for positive and negative

cases are inferred from corresponding training sets.

3 RESULT

MiRNA target prediction methods have often used

validated data together with some predicted data

either to develop or assess their algorithms in order

not to suffer from small sample size. When an

evaluation of target prediction ability for given

miRNAs and genes is in question, it is reasonable to

ignore the lack of verified binding site information

since they only deal with the binary result. However,

a correct and reliable evaluation of a probabilistic

binding model requires a set of experimentally

verified binding sites, both for positive and negative

cases. In a recent study of Yang et al. (2008), they

collected a number of experimentally validated

positive and negative miRNA-mRNA duplex sets.

The repository contains 233 miRNA-binding site

pairs from drosophila, C. elegans, human, mouse, rat

and zebrafish, where 195 of them are positive

interactions and 38 are negatives. Negative samples

still contain at least six perfect base pairs in seed

region for reliable evaluation of the algorithms. Note

that a positive interaction is referred as targeting

relationship between miRNA and mRNA under

consideration in this context. In the same publication

they propose an algorithm, called miRTif, to predict

the positive or negative interaction of given duplex

based on a powerful machine learning technique

called Support Vector Machines. They reported the

sensitivity (percentage of actual positives correctly

predicted as such), specificity (percentage of actual

negatives correctly predicted as such), accuracy

(percentage of all correctly predicted samples) and

AUC (Area under Receiver Operating

Characteristics Curve) of their predictions based on

10-fold cross validation tests. To make a fair

comparison, we compiled the experiments in a 10-

fold cross validation set-up on the same data set.

Since the selection of arbitrary 10 groups might

produce different results, we run the algorithm

several times for different initial configurations and

took their average. Results of the experiments are

shown in Table 1 in comparison with miRTif.

Table 1: Comparison of present model with miRTif on

miRNA-mRNA interaction prediction.

Method miRTif present method

Sensitivity

83.6% 86.7%

Specificity

73.7% 73.7%

Accuracy

81.9% 84.6%

AUC

0.89 0.94

During this experiment, we treated the miRNA-

mRNA duplex as a sequence over a 8-letter

alphabet, where each directed base pair, including

wobbles, i.e. A-U, U-A, G-C, C-G, G-U and U-G,

was represented by a distinct letter and all

mismatches were unified into one letter. An

additional letter was used for a space in any other

site. Maximum length for Markov chains was set to

5 since longer motifs are quite rare, which may not

contribute to the result, but several significant motifs

could be observed up to 5-letter length. We ignored











Ljjj

jjjj

sSsSPsSsSPSP

)|().|()(

A PROBABILISTIC METHOD FOR PREDICTION OF MICRORNA-TARGET INTERACTIONS

291

the single appearance of any sub-string in positive or

negative set to eliminate the data set bias.

The table demonstrates that new method can

outperform miRTif in all evaluation criteria except

specificity, where they perform equally. The

superiority of present method is quite significant in

terms of ROC statistics. This shows that new method

is not only successful in separation of positive and

negative examples but also able to successfully

quantize the level of certainty in its prediction. This

result is consistent with our intention to release this

model; enabling the sequence to be easily integrated

with other data.

4 CONCLUSIONS

We have introduced a probabilistic method to model

miRNA-target binding and evaluated its

performance on prediction of the interaction when

miRNA sequence and a putative binding site are

given. The accurate results that we obtained from the

experiments suggest that present model is able to

capture compositional properties of a duplex

sequence by additionally considering the effect of

different base pairings, mismatches and gaps with

their arrangements inside the duplex.

The model which we proposed may find

applications in several platforms. First, it can be

used as a post-processing filter for other miRNA

target prediction tools. Many of available algorithms

consider the seed match as a strong evidence for

target identification. Since it is possible to observe

random mRNA matches to seed region without any

interaction, this decision criterion can mislead the

algorithm to produce excessive number of false

positives. Present method is able to reject miRNA-

nontarget duplexes despite a high seed

complementarity, thus it may help to reduce the

number of false positives by reanalysing the binding

site predicted by former tool. Second, it may serve

complementary information which can be deployed

in target prediction algorithms. Conventional

methods perform a window-based linear scan over

the mRNA sequence to identify a putative binding

site which may attain a large binding score based on

a weighted sum of predefined criteria. Output of

proposed model is an obvious complement to other

determinants such as structure, site accessibility or

cross-spices conservation in this scoring scheme.

Third, the model enables the researchers to integrate

sequence data directly with other behavioural data

such as gene expression profiles over a probabilistic

framework. An integrated framework can provide a

comprehensive analysis of miRNA functions

associated with other entities, conditions or diseases.

Machine learning research has been competing in

two directions for intelligent analysis of

heterogeneous data: black-box kernel methods such

as Support Vector Machines and probabilistic

graphical models such as Bayesian Networks. Latter

requires a probabilistic representation of each

contributor in the model. Present scheme can fill a

gap in this respect.

It is anticipated that the participation of

computational models into miRNA research will

increasingly continue in coming years. We believe

that integration of multi-source heterogeneous data

will be a focal point in this research. Our study does

not yield a standalone tool in this context; however,

it provides a different view of miRNA-target

interactions from which future research can

definitely benefit. As a future work, we plan to

analyze the effects of seed and non-seed regions and

the types of different pairings of match and

mismatches in duplex analysis. Our final goal is to

come up with an integrative solution which

combines this sequence-based model with other

behavioural data in order to find functional maps of

miRNAs and their targets.

ACKNOWLEDGEMENTS

This study was supported by the Scientific and

Technological Research Council of Turkey

(TUBITAK) under the Project 110E160.

REFERENCES

Alexiou P., Maragkakis M., Papadopoulos G. L. et al.,

Lost in translation: an assessment and perspective for

computational microRNA target identification.

Bioinformatics 2009; 25:3049-3055.

Barbato C, Arisi I, Frizzo M. E. et al. Computational

Challenges in miRNATarget Predictions: To be or Not

to be a True Target? J Biomed Biotechnol 2009;

2009:803069.

Bartel DP. MicroRNAs: target recognition and regulatory

functions. Cell 2009; 136: 215-233.

Bartel D. P., MicroRNAs: genomics, biogenesis,

mechanism, and function. Cell 2004;116:281-297

Begleiter R., El-Yaniv R., Yona G., On prediction using

variable order Markov models, Journal of Artificial

Intelligence Research 2004, 22:385-421.

Bejerano G., Yona G., 2001. Variations on probabilistic

suffix trees: statistical modeling and prediction of

protein families. Bioinformatics 17, 23-43.

NCTA 2011 - International Conference on Neural Computation Theory and Applications

292

Ben-Gal I., Shani A., Gohr A., Grau J., Arviv S.,

Shmilovici A., Identification of transcription factor

binding sites with variable-order Bayesian networks,

Bioinformatics 2004; 21: 2657-2666.

Buhlman P., Wyner A. J., Variable length Markov chains,

Annals of Statistics 1999; 27: 480-513.

Hammell M., Computational methods to identify miRNA

targets. Semin Cell Dev Biol 2010 Sep;21(7):738-44.

Krek A., Grun D., Poy M. N., Wolf R., Rosenberg L.,

Epstein E. J., MacMenamin P., da Piedade I.,

Gunsalus K. C., Stoffel M., Rajewsky N.,

Combinatorial microRNA target predictions.

Nat.Genet. 2005;37:495-500.

Lee R. C., Feinbaum R. L., Ambros V., The C. Elegans

heterochronic gene lin-4 encodes small RNAs with

antisense complementarity to lin-14. Cell 1993; 75:

843-854.

Liu B., Liu L., Tsykin A et al. Identifying functional

miRNA–mRNA regulatory modules with

correspondence latent dirichlet allocation.

Bioinformatics 2010; 26:3105-3111.

Lu J, Getz G, Miska EA et al. MicroRNA expression

profiles classify human cancers. Nature 2005; 435:

834–838.

Madden SF, Carpenter SB, Jeffery IB et al. Detecting

microRNA activity from gene expression data, BMC

Bioinformatics 2010; 11:257.

Mendes ND, Freitas AT, Sagot MF. Current tools for the

identification of miRNA genes and their targets.

Nucleic Acid Res 2009; 37: 2419-2433.

Ron D., Singer Y., Tishby N., The power of amnesia:

Learning probabilistic automata with variable memory

length, Machine Learning 1996; 25: 117-149.

Saito T, Saetrom P. MicroRNAs - targeting and target

prediction. New Biotechnology 2010; 27: 243-249.

Smith T and Waterman M, “Identification of common

molecular subsequences”, Journal of Molecular

Biology 1981, 147: 195-7.

Thijs G., Lescot M., Marchal K., Ronbauts S., De Moor

B., Rouze P., Moreau Y., A higher order background

model improves the detection of promoter regulatory

elements by Gibbs sampling, Bioinformatics 2001; 17:

1113-1122.

Wang D., Wang J., Lu M., Song F. and Cui Q., Inferring

the human microRNA functional similarity and

functional network based on microRNA-associated

diseases, Bioinformatics 2010, 26(13): 1644-1650.

Yang Y., Wang Y. P., Li, K. B., MiRTif: a support vector

machine-based microRNA target interaction filter.

BMC Bioinformatics 2008; 9:S4.

Yoon S. and Micheli G., Prediction of regulatory modules

comprising microRNAs and target genes,

Bioinformatics 2005; 21: i93-i100.

Yu G. and He Q., Functional similarity analysis of human

virus-encoded miRNAs, Journal of Clinical

Bioinformatics 2011; 1:15.

A PROBABILISTIC METHOD FOR PREDICTION OF MICRORNA-TARGET INTERACTIONS

293
