INTERNALLY DRIVEN Q-LEARNING
Convergence and Generalization Results
Eduardo Alonso
1
, Esther Mondragón
2
and Niclas Kjäll-Ohlsson
1
1
Department of Computing, City University London, London EC1V 0HB, U.K.
2
Division of Psychology and Language Sciences, University College London, London WC1H 0AP, U.K.
Keywords: Q-learning, IDQ-learning, Internal Drives, Convergence, Generalization.
Abstract: We present an approach to solving the reinforcement learning problem in which agents are provided with
internal drives against which they evaluate the value of the states according to a similarity function. We
extend Q-learning by substituting internally driven values for ad hoc rewards. The resulting algorithm,
Internally Driven Q-learning (IDQ-learning), is experimentally proved to convergence to optimality and to
generalize well. These results are preliminary yet encouraging: IDQ-learning is more psychologically
plausible than Q-learning, and it devolves control and thus autonomy to agents that are otherwise at the
mercy of the environment (i.e., of the designer).
1 INTRODUCTION
Traditionally, the reinforcement learning problem is
presented as follows: An agent exists in an
environment described by some set of possible
states, where it can perform a number of actions.
Each time it performs an action in some state the
agent receives a real-valued reward that indicates the
immediate value of this state-action transition. This
generates a sequence of states, actions and
immediate rewards. The agent’s task is to learn a
control policy, which maximizes the expected sum
of rewards, typically with future rewards discounted
exponentially by their delay (Sutton & Barto, 1998).
It is therefore a working premise that the agent
does not know anything about the environment or
itself. Rewards are dictated by the environment not
part of the environment and thus defined separated
from outcomes. As a consequence only estate-action
values are learned. In addition, learning is
completely depended on the reward structure: If the
reward changes, a new policy has to be relearned.
Let’s emphasize this point: The only information
available to the agent about a state is the amount of
reward it predicts; it does not know why the new
state is good or bad. Thus the agent is completely
dependent on the environment to provide the correct
reward values in order to guide its behaviour. The
agent has no way of reasoning about the states in
terms of its internal needs, because it has no internal
needs other than reward maximization.
In this paper, we propose to redefine the value of
an outcome as a function of the agent's motivational
state. Because different states can be of different
importance to the agent it is the responsibility of the
agent to encode its own state signal. This proposal
contradicts reinforcement learning where the value
of an outcome is provided explicitly and separately
from the actual outcome in the form of a reward.
Allegedly the most popular reinforcement
learning algorithm is Q-learning, an off-policy
algorithm where the optimal expected long-term
return is locally and immediately available for each
state-action pair. A one-step-ahead search computes
the long-term optimal actions without having to
know anything about possible successor states and
their values. Under certain assumptions, Q-learning
has been proved to converge with probability 1 to
the optimal policy (Watkins & Dayan, 1992). In
large state spaces, Q-learning has been successfully
combined with function approximators.
In the next section, a variation of Q-learning, the
Internally Driven Q-learning algorithm (IDQ-
learning henceforth), based on the idea described
above is presented. We show that IDQ-learning
converges to the optimal policy and that it
generalizes well in subsequent sections.
491
Alonso E., Mondragón E. and Kjäll-Ohlsson N..
INTERNALLY DRIVEN Q-LEARNING - Convergence and Generalization Results.
DOI: 10.5220/0003736404910494
In Proceedings of the 4th International Conference on Agents and Artificial Intelligence (ICAART-2012), pages 491-494
ISBN: 978-989-8425-95-9
Copyright
c
 2012 SCITEPRESS (Science and Technology Publications, Lda.)

2 IDQ-LEARNING
2.1 States
A state is formally defined as a vector of elements
where each element represents some modality along
with a value. Significantly, elements can be shared
across states.
S
i
= s
1
,...,s
n
{}
Mod.S
i
= 0,1,....,n
{}
VS
i
= 0,max− str ength
[]
(1)
2.2 Similarity Function
In order to compare states with internal drives and
among themselves a similarity function is
introduced. This function should return a value
between 0 and 1 when comparing two states, where
0 is no similarity and 1 denotes equality. The
Gaussian function is a good match for the purpose.
Let the modality strength of state S
i
represent the
mean μ of a normal distribution ND with standard
deviation σ, and let VS
j
and VS
i
represent the value
of state S
j
and S
i
respectively. The probability of
state S
i
occurring in ND is given by:
PVS
i
()
=
1
σ 2 π
e
− VS
i
− μ
()
2
2 σ
2
(2)
The same applies to P(VS
j
). This leads to the
definition of the similarity function:
si m S
i
,S
j
()
=
PVS
i
()
PVS
j
()
IS
i
,S
j
()
(3)
where
IS
i
,S
j
()
=
1 if Mod.
S
i
= Mod.
S
j
0 if Mod.S
i
≠ Mod.S
j
⎧
⎨
⎩
(4)
Thus the similarity function is bell-shaped,
continuous, and insensitive to the sign of the
difference between the values of two states.
2.3 Internal Drives
For the purpose of deriving outcome values the
internal drives (ID) of an agent are defined as a
vector of states along with a category indicator for
each element denoting whether the state is aversive
or appetitive:
ID
i
= s
1
,...,s
n
{}
Mod.S
i
= 0,1,....,n
{}
VS
i
= 0,max− str engt h
[]
CatS
i
= aversive,appetitive
{}
aversive =−1
appetitive= 1
(5)
The asymptotic value of an outcome is thus set in
the following way:
λ S
i
()
= max ∀S
j
∈ ID: si m S
i
,S
j
()
()
× Cat.S
j
(6)
The value of an outcome is the maximum
similarity when compared to all internal drives. This
departure from traditional reinforcement learning is
significant since: (a) in our proposal, states have
intrinsic values defined as their similitude with
internal drives –they are not given by the
environment in an ad hoc manner; (b) rewards are
not defined on state-action pairs –they define the
states. As a consequence, the agents are in control,
they are now cognitive agents.
2.4 The IDQ-learning Algorithm
The IDQ-learning learning is similar to the Q-
learning algorithm. Its pseudo code reads as follows:
1. Initialize Q(s, a) according to
λ
(s)
2. Repeat (for each episode)
3. Initialize s
4. Repeat (for each step of the episode)
5. Choose a from s using a policy derived from Q
6. Take action a, observe s’
7.
Q(s,a)← Q(s,a) + αλ (s)+ γ max
a'
Q(
′
s ,
′
a ) − Q(s,a)
[]
8. s
←
s’
9. until s is terminal
The three main novelties refer to steps 1, 6 and 7,
specifically: the initial Q value is not arbitrary
(typically 0, for lack of any information about the
states); since r is now a defining characteristic of s’,
namely λ(s), in step 6 there is no need to observe r;
accordingly in step 7, λ(s) takes the place of r in Q-
learning. Because states have been defined as
compounds of elements, step 7 above applies to the
summation of the values of corresponding elements,
forming what we call the state’s expectance memory
(EM) –we haven’t made it explicit in the pseudo
code to avoid over-indexing.
This framework makes explicit the two main
conditions for the transfer of information,
contingency and contiguity: agents make predictions
ICAART 2012 - International Conference on Agents and Artificial Intelligence
492

on the value of states to come but, unlike in Q-
learning, such values as well as the values of
immediate rewards are defined as their probability of
occurrence (of the values themselves not of the
states). Moreover, generalization follows directly:
agents do not need to have experienced previously a
state in order to value it. As long as it shares
elements with an ID or with a previously
experienced state, it inherits a value.
3 EXPERIMENTS
In the next sub-sections we show experimentally
how IDQ-learning converges to an optimal policy
and how it generalizes in a traditional Grid-world
domain.
The following parameters were set for the IDQ
agent:
σ = 0.2 (the sensitivity of the similarity
function),
α = 0.1 (learning rate of CS), ε = 0.8
(choose the greedy response in 80% of the cases),
and
γ = 0.9 (reward discounting).
3.1 Convergence
Convergence is measured by recording the average
absolute fluctuation (AAF) for expectance memory
per episode. This is done by accumulating the
absolute differences diff
abs
between the values of the
expectance memory and their values after an update
has been carried out. Additionally the number of
steps to reach the goal, episode
length
, is recorded. The
AAF is thus given by diff
abs
/ episode
length
. For IDQ
there can be several updates of the expectance
memory. This is because of the consideration of
states as compounds, where each element of the
compound enters into separate associations from the
others. It is therefore necessary to record the number
of updates per episode step numerrors
episodestep
as
well. The average absolute fluctuation per episode
for IDQ is given by
(diff
abs
/numerrors
episodestep
)/episode
length
.
The optimal policy is the shortest path from any
spatial location to the goal. Table 1 shows a
summary of results for convergence experiments,
where MPC stands for Maximum Policy Cost for
learning period and OFPE stands for Optimal Policy
Found after n Epochs.
Table 1: Convergence: MPC and OPFE per Grid type.
Grid MPC OPFE
3×3
13 15
5×5
71 13
10×10
626 843
As expected, the algorithm converges to the
optimal results.
3.2 Generalization
Generalization in the Grid-world means how the
consideration of states as compounds can help the
transfer of learning between similar situations. When
an element X at two different locations signals the
same outcome, there is said to be a sharing of
associations between the two locations. In Figure 1
element X enters into an association with the
outcome state G. This association is strengthened at
two locations. Additionally, both elements A and B
enter into an association with G separately. In this
situation it is said that element X is generalized from
location (2,3) to location (3,2) and vice versa. There
is thus a sharing of element X between the states at
location (2,3) and at location (3,2). An algorithm
which manages to gain a savings effect from this
type of sharing is said to be able to generalize. This
generalization and sharing effect should be
manifested in faster convergence to the optimal
policy if the algorithm is successful in using the
redundant association to its benefit.
Figure 1: Generalization in the Grid world by means of
sharing of elements across states.
Generalization experiments were designed in two
phases (see Figure 2). In Phase 1 the agent is trained
with an initial Grid-world layout, and in Phase 2 this
initial Grid-world layout is changed. The G in the
lower right corner of each Grid-world layout
represents the goal state and is the same for all
layouts, for all experiments and phases. Phase 1 has
the same elements as Phase 2 for all locations,
unless otherwise stated. All experiments aim to test
whether Phase 2 will converge faster to the optimal
policy through generalization with Phase 1. Two
groups are employed for each experiment. In Group
1 there is supposed to be generalization from Phase
1 to Phase 2 due to an environment change, which
leaves an aspect of the environment layout intact,
but changes another. Group 2, on the other hand,
INTERNALLY DRIVEN Q-LEARNING - Convergence and Generalization Results
493

changes the environment, but leaves no aspect of
Phase 1 similar in Phase 2. If convergence is faster
in Phase 2 of Group 1 than in Phase 2 of Group 2, it
can be seen as an indicator of generalization.
Figure 2: Generalization experiment in the 10×10 Grid-
world, Group 1 top, Group 2 bottom.
To test generalization means to test whether IDQ
finds the optimal policy faster in Phase 2 of Group 1
than in Group 2 (by the test statistic OPR). The
independent variable is the difference in
Table 2 shows a sample mean OPR of 496.375
for Group 1 and 1059.75 for Group 2. The respective
variances for Group 1 and Group 2 are 15107.69643,
134965.0714. It is assumed that the data is normally
distributed for all eight samples in both groups. In
order to check whether the heterogeneity of variance
is significant at the .05 level, an F Max test is
performed. In Table 2 the f value is reported to be
0.009841503. The degrees of freedom for the
numerator is (n
1
– 1) = 7, and (n
2
– 1) = 7 for the
denominator. According to the f distribution this
gives a critical value of 3.79 at the .05 level of
significance, which the f value does not exceed, so
the heterogeneity of variance is not significant. A
one-tailed t-test is therefore performed (it is
expected that the difference between Group 2 and
Group 1 is positive). Table 2 presents a t-value of
4.397315147. At (n
1
+ n
2
– 2) = 14 degrees of
freedom, this gives a critical value of 1.761 at the
.05 level of significance. The t-value well exceeds
the critical value at the .05 level, and also at the .01
level (critical value: 2.624), as well as at the .001
level (critical value: 3.787). It is therefore concluded
that IDQ generalizes.
Table 2: IDQ in a 10×10 Grid-world (s. stands for sample
and sq. for squares).
Sample OPR
Group 1
Phase2
OPR
Group 2
Phase 2
1
2
3
4
5
6
7
8
455
772
564
389
470
428
475
418
1379
1787
768
715
1066
736
993
1034
x
S
S
2
MAX
MIN
sum of s. sq.
sq. of sum of s.
n
F Max test
t
496.375
122.91336
15107.693
772
389
2 076 859
15 768 841
8
0.009841503
4.397315147
1059.75
367.3759266
134 965.0714
1787
715
9 929 316
71 876 484
8
REFERENCES
Sutton, R. S., and Barto, A. G., 1998. Reinforcement
Learning: An Introduction. The MIT Press,
Cambridge, MA.
Watkins, C. J. C. H., and Dayan, P., 1992. Q-learning.
Machine Learning, 8, 279-292.
ICAART 2012 - International Conference on Agents and Artificial Intelligence
494
