SERVICE-BASED APPLICATION DEVELOPMENT ON THE CLOUD

State of the Art and Shortcomings Analysis

∗

Dinh Khoa Nguyen, Yehia Taher, Mike P. Papazoglou and Willem-Jan van den Heuvel

European Research Institute in Service Science (ERISS), Tilburg, The Netherlands

Keywords:

Cloud Application, SaaS, PaaS, IaaS, State-of-the-Art.

Abstract:

Recently, Cloud Computing has become an emerging research topic in response to the shift from product-

oriented economy to service-oriented economy and the move from focusing on software/system development

to addressing business-IT alignment. From IT perspectives, there is a proliferation of methods for cloud

application development. Such methods have clearly shown considerable shortcomings to provide an efﬁcient

solution to deal with major aspects related to cloud applications. One of these major aspects is the multi-

tenancy of the Software-as-a-Service (SaaS) components used to compose Service-Based Applications (SBAs)

on the cloud. Current SaaS offerings are often provided as monolithic one-size-ﬁts-all solutions and give little

or no opportunity for further customization. As a result, monolithic SaaS offerings are more likely to show

failure in meeting the business requirements of several consumers. In this paper, we analyze the state-of-

the-art of the standardization and methodology support for SBA development on the cloud, identify some

shortcomings, and point out the need of a novel approach for breaking down the monolithic stack of cloud

service offerings and providing an effective and ﬂexible solution for SBA designers to select, customize, and

aggregate cloud service offerings coming from different providers (Nguyen et al., 2011).

1 INTRODUCTION

Service-Oriented-Architecture (SOA) (Papazoglou

and van den Heuvel, 2006) is a philosophy of design

that can be informally described as “the software

equivalent of Lego bricks” where a collection of

mix-and-match units (called “services”) - each per-

forming a well-deﬁned task - can reside on different

machines possibly under the control of a different

service provider, and are ready to be used whenever

needed. Enterprises typically use a single software

service to accomplish a speciﬁc business task, such

as billing or inventory control or they may compose

several software services to create a value-added

distributed service-based application (SBA) such as

customized ordering, customer support, procurement,

and logistical support.

However, a serious limitation of SOA is that it

does not make any assumptions regarding service de-

ployment and it leaves it up to the discretion of the

service developer to make this deployment choice,

∗

The research leading to this result has received funding

from the Dutch Jacquard program on Software Engineering

Research via contract 638.001.206 SAPIENSA; and the Eu-

ropean Union’s Seventh Framework Programme FP7/2007-

2013 (4CaaSt) under grant agreement n

258862.

which is a daunting task and often leads to failure.

A dangerous “difﬁcult-to-customize, one-size-ﬁts-all”

philosophy permeates SOA development leading to

brittle implementations where once an application is

deployed it is bound to a particular infrastructure. In

addition, traditional SOA software development con-

centrates on a kind of “big design upfront” where the

prevailing belief is that it is possible to gather all of a

developer’sor customer’s requirements, upfront, prior

to coding a software solution. So despite its promises

SOA has so far failed to deliver promised beneﬁts ex-

cept in rare situations leading yet again to a software

development crisis.

To address these serious shortcomings it is normal

to turn our attention to Cloud Computing as it aim

to provide both the economies of scale of a shared

infrastructure as well as a ﬂexible delivery model

that naturally complements the service orientation of

SOA. Cloud computing is a computing model for en-

abling convenient and on-demand network access to

a shared pool of conﬁgurable and often virtualised

computing resources (e.g., networks, servers, storage,

middleware and applications as services) that can be

rapidly provisioned and released with minimal man-

agement effort or service provider interaction (Arm-

brust et al., 2009). Cloud capabilities are deﬁned and

395

Nguyen D., Taher Y., P. Papazoglou M. and van den Heuvel W..

SERVICE-BASED APPLICATION DEVELOPMENT ON THE CLOUD - State of the Art and Shortcomings Analysis.

DOI: 10.5220/0003902103950400

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CLOSER-2012), pages 395-400

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

provided as services where users of cloud-related ser-

vices are able to focus on what the service provides

them rather than how the services are implemented or

hosted. This begins to explain why the service orien-

tation provided by SOA needs the “cloud” as a natu-

ral deployment medium. In fact, the two concepts can

be paired to support service development and deploy-

ment and their merger can provide complete services-

based solutions. Cloud computing is typically divided

into three levels of hosting service offerings: Software

as a Service (SaaS), Platform as a Service (PaaS), and

Infrastructure as a Service (IaaS). These levels sup-

port the virtualisation and management of different

levels of the computing solution stack.

Having explained the beneﬁt of our “SOA meets

cloud” vision, our contribution in this paper is an ex-

tensive state-of-the-art analysis on the current stan-

dardization and methodology support for SBA devel-

opment on the cloud, which then leads to identifying

some shortcomings of the current support. The rest of

the paper is organized as follows. Section 2 presents

an extensive state-of-the-art evaluation. Section 3

identiﬁes shortcomings of existing support, and then

highlights some research questions and challenges de-

rived from the evaluation of the state-of-the-art. Fi-

nally, Section 4 concludes the paper.

2 STATE-OF-THE-ART

EVALUATION

Current SBA application development on the cloud

usually leads to a vendor lock-in approach, where

the constituting monolithic SaaS components are pre-

dominantly tethered to proprietary platforms and in-

frastructure of a cloud vendor and thus provide lit-

tle or no room for customization, extension and com-

position. That is because SBA developments do not

usually put focus on the deployment environment of

the constituent SaaS components. This limitation can

be addressed by breaking the monolithic SaaS offer-

ings into cloud services (XaaSs) across cloud com-

puting layers, i.e. SaaS, PaaS and IaaS. Following

the SOA principles and techniques, SBA develop-

ers can reuse and combine distributed cross-layered

XaaS functions. A SOA-enabling SBA development

on the cloud results in an amalgamation of on-premise

and external XaaSs that promotes the reusability and

composability of XaaSs across SaaS providers and

PaaS/IaaS cloud vendors. However, cloud comput-

ing is a relatively new research area and only a few

existing work supports our envisioned SBA develop-

ment methodology. Section 2.1 reviews and evaluates

the existing approaches towards a standardized XaaS

representation for supporting the platform-agnostic

vendor-independent SBA development on the cloud.

From the methodological point of view, Section 2.2

presents the related methodologies to develop SBAs

independent from the underlying cloud platform and

infrastructure.

2.1 Standardization Support for SBA

Development on the Cloud

While developing SBA on the cloud, the absence of

standardization across cloud vendors, results in un-

necessary complexity to obtain interoperability, high

switching costs and potential vendor lock-in. The

main concerns of cloud-based SBA development are

how to deal with the standardization and interoper-

ability between different cloud platforms (Tsai et al.,

2010), since cloud computing promises to allow de-

velopers to design and develop elastic and inexpen-

sive applications independent of platforms (Armbrust

et al., 2009). However, current cloud vendors have

different application models, many of which are pro-

prietary, vertically integrated cloud stacks that limit

the customizations of the underlying platform and in-

frastructure resources. There is currently little ef-

fort in supporting tools, techniques, procedures or

standard data formats or service interfaces that could

guarantee data, application and service portability.

In (Monteiro et al., 2011) the vendor lock-in problem

that prevents the interchangeability and interoperabil-

ity between the SaaSs has been addressed and subse-

quently a state-of-the-art in both standardization ef-

forts and on-going projects has been presented. Doc-

ument (Vambenepe, 2009) points out that concerning

the vendor lock-in there are still many unsolved com-

patibility issues beside the API compatibility, such as

the data format, billing, metering, error handling, log-

ging, or cloud management and administration. In

general, the current situation makes it difﬁcult for

SBA developers to migrate data and service compo-

nents from one cloud vendor to another or back to an

in-house IT environment.

The ability to manipulate, integrate and customize

XaaS across different cloud providers for SaaS de-

velopment has been studied in (Keahey et al., 2009)

that has IaaS, application and deployment orchestra-

tors but falls short of proposing a solution for the

problem at hand. The DMTF has published stan-

dards such as the Open Virtualization Format (OVF)

to provide an open packaging and distribution for-

mat for virtual machines, and the Virtualization Man-

agement (VMAN)

speciﬁcations that address the

OVF: http://www.dmtf.org/standards/ovf

VMAN: http://dmtf.org/standards/vman

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

396

management lifecycle of a virtual environment to

help promote interoperable cloud computing service.

The OVF is considered nowadays as a standardized

means for describing single or multiple virtual ma-

chines. Using the OVF allows for specifying either

the technical offering of an IaaS provider or the re-

source requirements of a SaaS or PaaS provider. Sim-

ilar to OVF-based approaches, the Solution Deploy-

ment Descriptor (SDD) template

proposed by OA-

SIS deﬁnes an XML schema to describe the charac-

teristics of an installable unit (IU) of software that

are relevant for core aspects of its deployment, con-

ﬁguration, and maintenance. The beneﬁts of this

work include: the ability to describe software solu-

tion packages for both single and multi-platform het-

erogeneous environments, the ability to describe soft-

ware solution packages independent of the software

installation technology or supplier, and the ability to

provide information necessary to permit full lifecy-

cle maintenance of software solutions. The work

in (Bernstein et al., 2009) targets the interoperability

between the federated clouds by providing a collec-

tion of proposals for “Inter-cloud” protocols and for-

mats. However, this work is still in the early stage

and targets only the interoperability between the data

centers, i.e. only on the infrastructure level.To unlock

the vendor lock-in problem concerning the APIs, the

Open Grid Forum’s Open Cloud Computing Interface

(OCCI) working group has been developing a uniform

API speciﬁcation for remote management of Cloud

Computing infrastructure

. This will allow for the

development of interoperable tools for common tasks

including deployment, autonomic scaling and moni-

toring. The scope of the speciﬁcation will be all high-

level functionality required for the life-cycle manage-

ment of virtual machines (or workloads) running on

virtualization technologies (or containers) supporting

service elasticity.

Approaching the cloud application development

from a different perspective, the Model Driven Engi-

neering (MDE) research community has realized the

beneﬁt of combining MDE techniques with SaaS de-

velopment and suggested combining MDE with cloud

computing (Bruneli`ere et al., 2010). As the arti-

cle describes, there is no consensus on the models,

languages, model transformations and software pro-

cesses for the model-driven development of cloud-

based SaaSs. Following the MDE vision, (Hamdaqa

et al., 2011) proposes a meta-model that allows cloud

users to design applications independent of any plat-

form and build inexpensive elastic applications. From

SDD 1.0: http://docs.oasis-open.org/sdd/v1.0/os/

dd-spec-v1.0-os.html

OCCI: http://occi-wg.org

their point of view, a SaaS application should avoid

the vendor lock-in problem concerning the underly-

ing platforms. This meta-model allows for describing

the capabilities, technical interfaces, and conﬁgura-

tion data for the virtualized infrastructure resources

of the cloud application service. Similarly, (Cai et al.,

2009) presents a different customer-centric cloud ser-

vice model. This model concentrates on aspects such

as the customer subscription, capability, billing, etc.,

yet does not cover other technical aspects of the cloud

services including the technical interfaces of the cloud

services, the elasticity, the required deployment en-

vironment, etc. Other existing models, e.g. (Thrash,

2010), also lack a formal structure and dentitions (re-

ducing their usability and reusability) or are not ex-

plicit and assume tacit knowledge.

In practice, an attempt to provide a template-based

approach for using cloud services is available from

Amazon through their AWS CloudFormation offer-

ing

. This template provides AWS developers with

the ability to specify a collection of AWS cloud re-

sources and the provisioning of these resources in an

orderly and predictable fashion. Nevertheless, this

template works only for AWS cloud platform and in-

frastructure resources and thus lacks interoperability.

In summary, existing approaches mostly target the

infrastructure levels and covers only certain perspec-

tive of standardizations for cloud services, e.g. de-

scription format, APIs, protocol, deﬁnition models,

protocols, SLA, etc. The state of the art analysis has

shown that there is a lack of a uniform representation

for cross-layered XaaSs that uniﬁes all views on an

XaaS, e.g. from the customer view on the APIs and

SLA, to the developers that are responsible for de-

ploying and maintaining that XaaS through the cloud.

2.2 Cloud-based SBA Development

Methodologies

Apart from the standardization supports for the inter-

operability and portability between cloud vendors, we

are also interested in the existing methodologies that

provide guidelines for developing composite SBA ap-

plications on the cloud, some of which are developed

based on the XaaS description standards mentioned in

the previous section 2.1.

La et al. propose in (La and Kim, 2009) a system-

atic process for developing high-quality cloud SaaSs,

taking into considerations the key design criteria for

SaaSs and the essential commonality/variability anal-

ysis to maximize the reusability. Although this ap-

proach claims to develop cloud-based SaaSs, it does

AWS CloudFormation, http://aws.amazon.com/de/

cloudformation/

SERVICE-BASEDAPPLICATIONDEVELOPMENTONTHECLOUD-StateoftheArtandShortcomingsAnalysis

397

not discuss about the cloud support for the deploy-

ment environment of the SaaSs. Maximilien et al. in-

troduces in (Maximilien et al., 2009) a cloud-agnostic

middleware that can sit on top of many PaaS/IaaS of-

ferings and enable a platform-agnostic SaaS develop-

ment. They provide a meta-model for describing SaaS

applications and their needed cloud resources, and

APIs and middleware services for the deployment.

The connection between SOA and cloud computing

has been established by the Service-Oriented Cloud

Computing Architecture (SOCCA) proposed in (Tsai

et al., 2010). Using the SOCCA, developers can build

SBA applications followingan integrated SOA frame-

work. Cloud platform and infrastructure resources

will be discovered by a Cloud Broker Layer and a

Cloud Ontology Mapping Layer for deploying the

SaaS components. The multi-tenancyfeature of cloud

computing is also supported by SOCCA where mul-

tiple instances of SaaS applications or components

can be provided to multiple tenants. Although the

SOCCA is a useful reference architecture for develop-

ing cloud-based SBAs following the SOA paradigm,

a lot of supports are lacking here including a concrete

deﬁnition language for the SaaS components, a map-

ping approach for ﬁnding necessary cloud resources,

and the ability to specify and resolve end-to-end con-

straints of SaaS applications that might affect the un-

derlying cloud resources.

The Cafe application and component templates

in (Mietzner, 2010) are a relevant approach for cloud-

based SaaS development that provides an ad-hoc

composition technique for application components

and cloud resources followingthe Service Component

Architecture (SCA). However, this approach requires

SaaS developers to possess deep technical knowledge

of the application architecture and the physical cloud

deployment environment to select and compose the

right application components and cloud resources.

(Gal´an et al., 2009) uses the OVF to deﬁne a

service deﬁnition language for deploying complex

SaaS applications in federated IaaS clouds. These

SaaS applications consist of a collection of virtual

machines (VMs) with several conﬁguration parame-

ters (e.g., hostnames, IP addresses and other applica-

tion speciﬁc details) for software components (e.g.,

web/application servers, database, operating system)

running on the VMs. The service deﬁnition language

enables also the speciﬁcation of SaaSs’ Key Perfor-

mance Indicators (KPIs) and the elasticity rules that

prescribe what to do in case the KPIs do not meet the

expected levels. (Chapman et al., 2010) extends this

language into a service deﬁnition manifest to serve

as a contract between a SaaS provider and the in-

frastructure provider. In this contract, architectural

constraints and invariants regarding the infrastructure

resource provisioning for an application service are

speciﬁed and can be used for on-demand cloud in-

frastructure provisioning at run-time. KPIs moni-

toring mechanisms are also speciﬁed in the contract

for ensuring the timely scaling of the provisioned

infrastructure resources based on the speciﬁed elas-

ticity rules. Nevertheless, the existing work related

to the OVF targets the infrastructure level only, i.e.,

they allow the speciﬁcation of architecture constraints

for deploying the applications directly on (federated)

data centres but do not cover the holistic picture of

a top-down development of SBAs on the cloud that

can guide developers in selecting, resolving and com-

posing cross-layered XaaS offerings. Using the ser-

vice deﬁnition manifest to specify the structure of a

SaaS application, i.e. the SaaS components and their

required Virtual Execution Environments (VEE), the

Reservoir architecture (Rochwerger and et al., 2009)

can automatically provision the VEE instances that

can run simultaneously without conﬂict on a federated

cloud infrastructure of multiple providers. KPI moni-

toring mechanisms and elasticity rules in the manifest

act as a contract that guarantees the required Service

Level Agreement (SLA) between the SaaS provider

and the Reservoir architecture.

Model-driven approaches are also employed for

the purpose of automating the deployment of com-

plex IaaS services on cloud infrastructure. For in-

stance, (Konstantinou et al., 2009) propose a virtual

appliance model, which treats virtual images as build-

ing blocks for IaaS composite solutions. Virtual ap-

pliances are composed into virtual solution model and

deployment time requirements are then determined in

a cloud-independent manner using a parameterized

deployment plan. In a similar way, (Chieu et al.,

2010) describes a solution-based provisioning mech-

anism using composite appliances to automate the de-

ployment of complex application services on a cloud

infrastructure.

In summary, the state of the art analysis has shown

that there is a need for a methodology that guides

cloud-based SBA developers to make informed de-

cisions for selecting, customizing, and composing

cross-layered XaaS offeringsfrom multiple providers.

The methodologyshould obey the SOA principles and

techniques that promote the reusability, loose cou-

pling and composability of the underlying XaaSs.

3 SHORTCOMINGS OF

EXISTING APPROACHES

This section summarizes the shortcomings we iden-

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

398

Table 1: Summary of existing gaps and innovations needed to address them.

Shortcomings Research Challenges

RQ-1: Lack Of uniform representation of cross-

layered XaaSs

The state of the art analysis has shown that there is a lack of a uniform representation for cross-layered

XaaSs that uniﬁes all views on an XaaS, e.g. from the customer view on the APIs and SLA, to the

developers that are responsible for deploying and maintaining the XaaS through the cloud.

RQ-2: Lack of considering the appealing charac-

teristics of the cloud as a deployment environment

for the SaaSs

Although cloud-based development may beneﬁt from adopting the SOA principles and techniques by

following the SOA developments methodologies, none of these methodologies consider the appealing

characteristics of the cloud as a deployment environment for the SaaSs.

RQ-3: Lack of a concrete deﬁnition language for

SaaS applications

Although there are some useful reference architectures for developing cloud-based SaaSs following

the SOA paradigm, a lot of supports are lacking here including a concrete deﬁnition language for the

SaaS applications and components, a mapping approach for ﬁnding necessary cloud resources, and

the ability to specify and resolve end-to-end constraints of SaaS applications that might affect the

underlying cloud resources.

RQ-4: Lack of controlled support and optimisation

for end-to-end services

The cross-organisational nature of service systems and the potential composition of services across

organisational boundaries requires that services are appropriately designed and effectively managed

end-to-end for operational and performance effectiveness. In service eco-systems end-to-end services

should be conﬁgured or re-conﬁgured according to QoS parameters, service preferences and require-

ments declared either by software developer or contained in the terms of an agreed upon SLA.

RQ-5: Lack of matching service design options

with infrastructure

The volatile requirements of service-based applications place demands that the execution infrastructure

be appropriately conﬁgured in response to application characteristics, end-to-end QoS requirements,

or when further functional optimisation is required. Research is required on virtualisation techniques

for cross correlating service components at the application-level with the most appropriate platforms

and infrastructure.

RQ-6: Lack of achieving scalability in service eco-

systems

Smart Internet service eco-systems require a scalable infrastructure that can be scaledup or down based

on application demand, levels of QoS and availability of resources, dynamically evolving workloads,

while maintaining critical architectural constraints.

RQ-7: Lack of a uniﬁed service/cloud service en-

gineering methodology

This item is the common denominator of all previous open research problems. There is a clear neces-

sity for modern service engineering approaches to infuse cloud computing concepts and functionality

into service-oriented systems. In this way it is possible to take a uniﬁed holistic view of the complete

service-system solution lifecycle that causally connects high-level decisions at the application-level

down to the level of resource virtualisation and provisioning of physical resources.

tiﬁed while evaluating and comparing the different

approaches in the sate-of-the-art. Most of the re-

search activities contributing to the state-of-the-art

described in the previous section concentrate on plat-

form/infrastructure resource provisioning and attempt

to combine and optimize interrelated PaaS and IaaS

resources. However, we observe little research work

on the cloud application (SaaS) level that supports the

development of SBAs by utilizing distributed SaaS

components that are deployed on a federation of elas-

tic and heterogeneous PaaS and IaaS resources. Cur-

rent approaches for cloud-based SBA development

cannot meet this expectation and usually leads to

a vendor lock-in approach, where the constituting

monolithic SaaS components are predominantly teth-

ered to proprietary platforms and infrastructure of a

cloud vendor. This approach fails to follow the true

spirit of SOA that promotes the reuse of loosely cou-

pled services, thus makes it difﬁcult for SBA develop-

ers to migrate the SaaS components from one cloud

vendor to another or back to an in-house IT environ-

ment.

Moreover, existing approaches hardly address

end-to-end non-functional requirements, and are not

closed-feedback loop, thus partitioning service sys-

tems that involve many providers thereby increasing

mean time to resolution of errors. For these method-

ologies scalability, optimal use of resources and con-

tinuous improvement of services are hardly consid-

ered. Further, they do not address the nature of the

execution environment that automates the end-to-end

services and their subsequent operation. None of the

current methodologies considers the appealing char-

acteristics of the cloud as a deployment environment.

This is where our approach differs by addressing the

challenges mentioned in Table 1. This table identi-

ﬁes and summarizes open areas of research priority,

called research questions (RQs), with large potential

for major breakthrough.

4 CONCLUSIONS

This paper provided a survey on existing support for

SBA development on the cloud. As a summary, the

survey has shown that the current cloud solutions are

mainly fraught with the following shortcomings:

• They introduce a monolithic SaaS/PaaS/IaaS

stack architecture where a one-size-ﬁts-all men-

tality prevails. They do not allow developers to

SERVICE-BASEDAPPLICATIONDEVELOPMENTONTHECLOUD-StateoftheArtandShortcomingsAnalysis

399

mix and match functionality and services from

multiple application, platform and infrastructure

providers and conﬁgure it dynamically to address

application needs.

• They introduce rigid service orchestration prac-

tices tied to a speciﬁc resource/infrastructure con-

ﬁguration for the cloud services at the SaaS level.

The above points hamper the (re)-conﬁguration and

customization of cloud applications on demand to

reﬂect evolving inter-organizational collaborations.

There is clearly a need for a SBA development

methodology that allows to mash up services from

a variety of cloud providers to create what has been

termed a cloud ecosystem. This type of integration

allows the tailoring of services to speciﬁc business

needs using a mixture of SaaS, PaaS and IaaS. In

this paper, we have also identiﬁed in Table 1 the re-

search questions and challenges as a roadmap for fu-

ture research towards such a novel SBA development

methodology.

REFERENCES

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R. H., Konwinski, A., Lee, G., Patterson, D. A.,

Rabkin, A., and Zaharia, M. (2009). Above the

clouds: A berkeley view of cloud computing. Tech-

nical report.

Bernstein, D., Ludvigson, E., Sankar, K., Diamond, S., and

Morrow, M. (2009). Blueprint for the intercloud - pro-

tocols and formats for cloud computing interoperabil-

ity. In Proceedings of the 4th ICIW’09. IEEE.

Bruneli`ere, H., Cabot, J., and Fr´ed´eric, J. (2010). Combin-

ing model-driven engineering and cloud computing.

In Proceedings of the 4th edition of Modeling, Design,

and Analysis for the Service Cloud.

Cai, H., Zhang, K., Wang, M., Li, J., Sun, L., and Mao, X.

(2009). Customer centric cloud service model and a

case study on commerce as a service. In Proceedings

of the IEEE CLOUD’09.

Chapman, C., Emmerich, W., M´arquez, F. G., Clayman, S.,

and Galis, A. (2010). Software architecture deﬁnition

for on-demand cloud provisioning. In Proceedings of

the 19th ACM HPDC ’10, pages 61–72, NY, USA.

ACM.

Chieu, T., Mohindra, A., Karve, A., and Segal, A. (2010).

Solution-based deployment of complex application

services on a cloud. In Proceedings of the IEEE

SOLI’10.

Gal´an, F., Sampaio, A., Rodero-Merino, L., Loy, I., Gil, V.,

and Vaquero, L. M. (2009). Service speciﬁcation in

cloud environments based on extensions to open stan-

dards. In Proceedings of the 4th COMSWARE ’09,

pages 19:1–19:12, NY, USA. ACM.

Hamdaqa, M., Livogiannis, T., and Tahvildari, L. (2011). A

reference model for developing cloud applications. In

In proceedings of CLOSER’11.

Keahey, K., Tsugawa, M., Matsunaga, A., and Fortes, J.

(2009). Sky computing. IEEE Internet Computing,

13(5):43–51.

Konstantinou, A. V., Eilam, T., Kalantar, M., Totok, A. A.,

Arnold, W., and Snible, E. (2009). An architecture for

virtual solution composition and deployment in infras-

tructure clouds. In Proceedings of the 3rd workshop

VTDC ’09, pages 9–18, NY, USA. ACM.

La, H. J. and Kim, S. D. (2009). A systematic process for

developing high quality saas cloud services. In Pro-

ceedings of the 1st CloudCom ’09, pages 278–289,

Berlin, Heidelberg. Springer-Verlag.

Maximilien, E. M., Ranabahu, A., Engehausen, R., and An-

derson, L. C. (2009). Toward cloud-agnostic mid-

dlewares. In Proceeding of the 24th ACM SIGPLAN

OOPSLA ’09, pages 619–626, NY, USA. ACM.

Mietzner, R. (2010). A method and implementation to deﬁne

and provision variable composite applications, and its

usage in cloud computing. Dissertation, Universit¨at

Stuttgart, Germany.

Monteiro, A., Pinto, J., Teixeira, C., and Batista, T. (2011).

Cloud interchangeability - redeﬁning expectations. In

Proceedings of CLOSER’11.

Nguyen, D. K., Lelli, F., Taher, Y., Parkin, M., Papazoglou,

M. P., and van den Heuvel, W.-J. (2011). Blueprint

template support for engineering cloud-based ser-

vices. In Proceedings of ServiceWave’11, pages 26–

37.

Papazoglou, M. P. and van den Heuvel, W.-J. (2006).

Service-oriented design and development methodol-

ogy. Int. J. Web Eng. Technol., 2(4):412–442.

Rochwerger, B. and et al. (2009). The reservoir model and

architecture for open federated cloud computing. IBM

Journal of Research and Development, 53(4).

Thrash, R. (2010). Building a cloud computing speciﬁca-

tion: fundamental engineering for optimizing cloud

computing initialtives. CSC Whitepaper.

Tsai, W.-T., Sun, X., and Balasooriya, J. (2010). Service-

oriented cloud computing architecture. In Proceed-

ings of the 7th ITNG’10, pages 684–689. Ieee.

Vambenepe, W. (2009). Reality check on cloud portability.

SD Times.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

400
