AUTOMATIC ASSESSMENT OF SHORT FREE TEXT ANSWERS

Fátima Rodrigues

and Lília Araújo

GECAD – Knowledge Engineering and Decision-Support Research Center,

Institute of Engineering, Polytechnic of Porto (ISEP/IPP), Rua Dr. António Bernardino de Almeida, Porto, Portugal

Keywords: Computer Assisted Assessment, Part of Speech Tagging, Computerized Grading.

Abstract: Assessment plays a central role in any educational process, because it is a common way to evaluate the

students’ knowledge regarding the concepts related to learning objectives. Computer assisted assessment is

a research branch established to study how computers can be used to automatically evaluate students’

answers. Computer assisted assessment systems developed so far, are based on a multitude of different

techniques, such as Latent Semantic Analysis, Natural Language Processing and Artificial Intelligence,

among others. These approaches require a reasonable corpus to start with, and depending on the domain, the

corpus may require regular updates. In this paper we address the assessment of short free text answers by

developing a system that captures the way the teacher evaluates the answer. For that, the system first

classifies the teacher question by type. Then concerning the type of question, the system permits the teacher

define scores associated with subparts of the answer. Finally, the system performs the assessment based on

these sub scores. For certain types of questions, paraphrases of answers are also considered in an attempt to

obtain a more precise assessment. The system was trained and tested on exams manually graded by a

History teacher. Based on the results obtained, we show that there is a good correlation between the

evaluation of the instructor and the evaluation performed by our system.

1 INTRODUCTION

The correction of questions in an evaluation process

involving a large number of free text answers

presents teachers with three major problems. Firstly

this procedure is very time expensive, as teachers

dedicate approximately 30% of their time to exam

correction (Mason and Grove-Stephenson, 2002). In

addition to this, it is very difficult to ensure an

equitable application of evaluation criteria. This is

due not only to the subjective nature of the

assessment of free text responses, but also to the

lengthy evaluation process. Teachers must be highly

concentrated for long periods of time, and therefore

assessment is subject to variations of level of

concentration and of mood of the human being. This

can lead to different evaluation grades for answers

with similar quality, thus creating inequities in the

assessment process that could be even more

pronounced if the evaluation is conducted by

different evaluators. Moreover, such task involves

human labour that cannot be reused.

In this paper we will describe the various

functionalities added to an application in order to

perform automatic assessment of short free text

answers. Firstly we classify the teacher’s

questions/answers by type; then a spell checker is

applied to the students’ answers to correct

misspelling errors. After that, both teacher and

students’ answers are processed through several text

pre-processing tasks that reduce them to their

canonical form. Such tasks include removing

punctuation and words without any semantic

associated (stop words); word reduction to its radical

(stemming); and a morphological analysis is also

performed to tag each word in the sentence with its

corresponding part of the speech element, such as,

noun, adjective, pronoun, verb, etc. These combined

tasks turn text into a canonical form that is more

manageable.

Student answers (SAs) should be compared with

reference answers (RAs). If there is only one RA for

each question, the assessment will be very limited

and punitive and may fail. To surpass this limitation

we create paraphrases of RAs that will provide

different correct variations of RAs, for the same

question, with a vocabulary more varied and less

restrictive, that will allow a more accurate

Rodrigues F. and Araújo L..

AUTOMATIC ASSESSMENT OF SHORT FREE TEXT ANSWERS.

DOI: 10.5220/0003920800500057

In Proceedings of the 4th International Conference on Computer Supported Education (CSEDU-2012), pages 50-57

ISBN: 978-989-8565-07-5

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

assessment.

With these functionalities, the classroom

assessment application will be consistent in the way

it scores SAs. Moreover it will provide enormous

time savings by reducing the time spent by

evaluators and it will allow students to test their

knowledge at any time, enabling them to adapt their

study according to their progress or individual

limitations.

The remainder of this paper is organized as it

follows: section 2 provides an insight into some

current available systems for automatic assessment.

In section 3, an overview of our system is made in

terms of its main modules. In the next sections, the

classification and pre-processing modules are

described in detail. The following section outlines

the evaluation process applied and presents the

experiments performed and their results. In the last

section, conclusions and future work are presented.

2 CURRENT APPROACHES ON

AUTOMATIC ESSAY GRADING

Computer Assisted Assessment (CAA) of free text

answers is a long-standing problem that has attracted

interest from researchers since the 1960s. CAA

systems can be distinguished by the way they

evaluate essays, either for style or for content, or for

both. Another distinguished dimension is the

approach adopted for assessing style and/or content.

The most important approaches found in existing

CAA systems are Statistical, Latent Semantic

Analysis (LSA) and Natural Language Processing

(NLP). The first CAA systems, which were focused

on statistical approaches, captured only the structural

similarity of texts. The following systems, which

were based on LSA, did more than a simple analysis

of co-occurring terms. In fact, they introduced two

new approaches to the problem: a comparison based

on a corpus, and an algebraic technique which

allowed to identify similarities between two texts

with different words (Thomas et al. 2004). The latest

systems are based on NLP techniques and can do

intelligent analyses that capture the semantic

meaning of free text documents.

It is beyond the scope of this paper to fully cover

the state-of-the-art automated assessment in terms of

current implementations. (Valenti et al., 2003) and

more recently (Perez Martin et al., 2009) do so in

great depth: the former, looks at 10 different

systems, while the latter investigates 22 systems.

The philosophy of the researchers, the type of

assessment, the method of assessing and the format

of the programs are described in the two works

above mentioned. Some comments from the authors

about the efficiency of the systems are supplied as

well. It is important to note, however, that the test

data and metrics used to analyse all the systems are

not consistent, and therefore the results are not

necessarily comparable. This is due to the lack of

reference materials for testing purposes. This field

has no large corpus of essays that can be used as a

standard measure of automated grading systems

(Valenti et al., 2003). With most research projects

marking their own sets of essays and judging

according to their own correlation criteria, it is

difficult to accurately compare systems. For this

reason, it is very difficult to determine which system

and methods are the best.

As mentioned above, the distinction is made

between grading essays based on content and those

based on style. While there are systems that evaluate

primarily based on style, Project Essay Grade (PEG)

(Page, 1994); or on content, Intelligent Essay

Assessor (IEA) (Jerrams-Smith et al., 2001),

Educational Testing Service (ETS I) (Whittington

and Hunt, 1999), Conceptual Rater (C-Rater)

(Burstein et al., 2001), most of the latest systems

aim to grade across both dimensions, Bayesian

Essay Test Scoring sYstem (BETSY) (Rudner and

Liang, 2002), Automark (Mitchell et al., 2002),

Paperless School free-text Marking Engine (PS-ME)

(Mason and Grove-Stephenson, 2002). Another

feature of these systems is that they widely differ in

the methods used. For example, IEA is based on

LSA, whereas E-rater is based on NLP, BETSY uses

Bayesian Networks and PEG works on linguistic

features via proxes. None of these systems is

adequate for our purposes because they only handle

text written in English and require large volumes of

text for learning, particularly those based on LSA

and Artificial Intelligence techniques. Our system is

developed to process short free text answers written

in Portuguese.

3 PROPOSED APPROACH

The system was developed under a modular

approach. It is mainly composed of four modules:

 A classification module that permits the teacher

to classify each question/answer in three main types:

enumeration, specific knowledge and essay. The

enumeration answer has its own structure that

consists of a list of topics separated by commas.

Specific knowledge questions are “Wh questions”

(Who, What, Where, Which, When or How) and

AUTOMATICASSESSMENTOFSHORTFREETEXTANSWERS

may also include definitions. The answers to those

questions are more limited in terms of vocabulary

and should not differ greatly from the RA. Essay

answer is really a text free answer, that can be

affirmative, negative or merely an opinion;

 A pre-processing module that combines various

NLP techniques to convert answers into a canonical

form that is more manageable and easily to interpret

and compare;

 An evaluation module where we calculate the

similarity between SAs and RAs and use various

metrics to compare the system with the teacher´s

evaluation;

 A feedback module that gives personal

comments to students based on missing topics and

topics that are not covered deeply enough in their

responses. The feedback will consist on information

about students’ errors and performance, but also of

adaptive hints for the improvement of his/her

solution. The system also gives feedback to the

teacher on the topics less covered by the class or by

a student. This module will not be described in detail

because it is still under development.

The SAs were collected using the UNI_NET-

Classroom application that provides management

support to school teachers. The input to our system

is a database of answers performed by students that

belong to various classes, about an exam conceived

by a teacher with its corresponding RAs. Thus the

system always has a set of answers concerning the

same question to evaluate, which is beneficial for the

evaluation process, because it rates terms according

to its frequency in the corpus.

3.1 Classification Module

This module is an application with an interface web

that allows the teacher to define the

questions/answers, its type and scorings for the

whole exam. When the teacher inserts a question it

begins with the definition of its type according to the

three types previously described: enumeration,

specific knowledge and essay. Next, the teacher

defines the question and its answer. If it is an answer

to an enumeration question, the teacher defines each

component of the question and the relative scoring

for each component on the answer. If it is a specific

knowledge answer, the teacher defines the

mandatory terms or words that must occur in the

SAs without any changes, or variations, which may

include proper nouns or not. These mandatory terms

are marked by the system with a special tag

<mand>. Finally each mandatory term has its

scoring defined by the teacher, while for an essay

question the teacher only determines whether the

answer is affirmative or not, or if it is free.

This is not an additional process that the teacher

must do in order to this assessment system operates.

Indeed, it takes part of any teacher’s exam

preparation. While preparing an exam, all teachers

must perform its correction and assign the adequate

scoring to the questions, or part of the questions,

according to the importance/difficulty of the issues.

This criteria definition is very important because it

will allow our system to apply exactly the same

assessment criteria as the teacher.

3.2 Pre-processing Module

To increase the performance of the pre-processing

module, a dynamic structure was created. So at the

beginning of this process all the information

concerning an exam, such as, questions/answers

teachers and student’s answers are carried to this

dynamic structure, which turns the information

always accessible and avoids a constant reading

from disk.

The pre-processing of answers is performed

according to the type of question. For enumeration

questions these are decomposed in the various sub

answers. On the specific questions, we look for the

terms that were marked by the teacher as

“mandatory” and these ones will not be processed by

the pre-processing module.

The pre-processing module is composed of a set

of steps which run sequentially in an effort to reduce

each sentence to its canonical form. All the steps,

except the last one, are applied to both the RA and

SAs. The last step, that assigns a list of synonyms to

every pair (word,tag) is only applied to RAs, since

its goal is to make paraphrases of RAs. The order in

which each task is executed has a great influence on

the final form of sentences. So, each step was

implemented in an independent way so that a quick

and easy reorganization and combination of the

different tasks can be performed and compared. The

combination that best fulfils the objectives proposed

is the one that loses less information from the

answers. For example, if the stop-words are

removed, before the spelling checker execution, the

words with errors won’t be considered in the stop-

word process and the sentence will not be placed in

its correct canonical form. After some experiences

we have reached the following pre-processing task

order.

CSEDU2012-4thInternationalConferenceonComputerSupportedEducation

3.2.1 Removal of Punctuation

This first task removes all special characters. Special

characters are those which are not integrated in a

word, such as punctuation. The accentuation of the

words (in this context “accentuation” refers to a

mark or symbol used to write words in certain

languages to indicate the vocal quality to be given to

a particular letter) was maintained so that they

would not be regarded as misspellings.

3.2.2 Correction of Spelling Errors

The corrector used for the misspelling verification

was Jspell (Almeida and Simões, 2007). All the SAs

are verified, and if they have misspelling errors are

corrected. Besides detecting misspellings, the Jspell

tool also suggests the solution. Thus, the words with

misspellings are replaced by the correct ones, so that

answers can be compared. In addition to this, errors

are counted for further evaluation of the answer.

3.2.3 Removal of Stop-words

A stop-word is a word that is considered irrelevant

because it doesn´t affect the semantic meaning of the

sentence. The goal of this task is the removal of all

stop-words that aren’t meaningful for the quotation

of the answer. For example, grammatically speaking,

words like Yes or No are considered stop-words but

they can alter the meaning of an answer, thus

changing the scoring given to it, consequently these

words aren’t removed in this step.

3.2.4 Stemming

In this stage, individual words are reduced to their

canonical form or stem. The canonical form of a

word is the base or lemma of that word. Stemming

will simplify the process of matching words of SAs

to RAs and will also help in the process of locating

synonyms which will be made in the next steps.

3.2.5 Text Tagging

This task assigns to the words not yet marked as

“mandatory” their part of speech tag. This is also

performed by using Jspell. This categorization will

enable us to compare words with the same part of

speech tag.

3.2.6 Synonyms

The list of synonyms of a word depends of their part

of speech tag. A word will have one list of

synonyms associated with each part of speech tag.

The thesaurus is critical to the success of this

operation, so we adopted the synonyms of the

OpenThesaurusPT project (OpenThesaurus, 2010)

that provides synonyms for Portuguese words. It is

used in the process of RA paraphrases generation

developed.

All the synonyms concerning the words and their

part of speech tag, belonging to the RA, are loaded

from a text file to our dynamic structure. This way,

we provide several paraphrases to the same RA, and

the local search is significantly reduced in the

moment of the comparison of answers.

3.2.7 Application Example

After the pre-processing tasks, the canonical form of

a RA is a list of triples

(i,word

<pstag

>[syn

..syn

]...<pstag

>[syn

..syn

],...,

n,word

,<pstag

>[syn

..syn

]...<pstag

>[syn

..syn

])

which contains the order in sentence of the i-th

word, the word, its list of part of speech tags and the

list of synonyms associated with each tag. Some

word/tag may not have a list of synonyms. The

canonical form of SA is simpler than RA, because

their words don´t have a list of synonyms. So the

student canonical form is

(i,word

,<pstag

>,<pstag

>,..., n, word

, <pstag

<pstag

The following example shows the effects of these

operations in a question/answer picked from our

database.

Question: “Caracteriza o Urbanismo Pombalino”

Question translation: “Describe the Pombalino

urbanism”

Original teacher answer: “A Lisboa Pombalina tinha

ruas largas e perpendiculares, sistema de esgotos,

as casas possuíam uma estrutura em gaiola. O

terreiro do Paço passou a chamar-se Praça do

Comércio.”

Teacher answer translation: “The Pombalino Lisbon

had wide and perpendicular streets, sewerage

system, the houses had a cage structure. The yard of

the palace change its name to Praça do Comércio.”

This is an example of an enumeration answer. When

the teacher defines the answer he separates it in its

subcomponents, so the answer is divided in the

following four sub answers:

 “A Lisboa pombalina tinha ruas largas e

perpendiculares” (30%)

 “sistema de esgotos”(30%)

AUTOMATICASSESSMENTOFSHORTFREETEXTANSWERS

 “as casas possuíam uma estrutura em

gaiola”(40%)

 “O terreiro do Paço passou a chamar-se <Praça

do Comércio<mand>>”(10%)

And each subcomponent has its own relative

scoring.

Step 1 - Removal of Punctuation

“A Lisboa pombalina tinha ruas largas e

perpendiculares”

“sistema de esgotos”

“as casas possuíam uma estrutura em gaiola”

“O terreiro do Paço passou a chamar-se <Praça do

Comércio<mand>>”

In this step, in a RA enumeration is not applicable

any action, because in the previous module the

answer has been divided in its subcomponents.

When processing SAs, this step will look for

punctuation signals that will separate the SA in its

subcomponents.

Step 2 - Correction of Spelling Errors

“A Lisboa pombalina tinha ruas largas e

perpendiculares”

“sistema de esgotos”

“as casas possuíam uma estrutura em gaiola”

“O terreiro do Paço passou a chamar-se <Praça do

Comércio<mand>>”

Step 3 - Removal of Stop-Words

“Lisboa pombalina ruas largas perpendiculares”

“sistema esgotos”

“casas possuíam estrutura gaiola”

“terreiro Paço passou chamar <Praça do

Comércio<mand>>”

Step 4 – Stemming

“Lisboa pombalino rua larga perpendicular”

“ sistema esgoto”

“casa possuir estrutura gaiola”

“terreiro Paço passar chamar <Praça do

Comércio<mand>>”

Step 5 – Text Tagging

(1,Lisboa,<np>) (2,pombalino,<adj>)

(3,rua,<nc>,<verb>) (4,larga,<nc>,<adj>,<v>)

(5,perpendicular,<a_nc>) (6,sistema,<nc>)

(7,esgoto,<nc>,<v>)

(8,casa,<nc>,<v>) (9,possuir,<v>) (10,

estrutura,<nc>,<v>) (11, gaiola,<nc>)

(12,terreiro,<a_nc>) (13,Paço,<nc>)

(14,passar,<v>) (15,chamar,<v>) (16,Praça

Comércio,<mand>)

Step 6 – Synonyms

(1,lisboa,<np>) (2,pombalino,<adj>)

(3,rua,<nc>,<verb>) (4,larga,<nc>,<adj>[amplo

espaçoso extenso grande vasto],<v>[abandonar ceder

deixar desistir]) (5,perpendicular,<a_nc>)

(6,sistema,<nc>[arrumação maneira método ordem

processo]) (7,esgoto,<nc>,<v>[ensecar esvaziar

exaurir haurir])

(8,casa,<nc>[lar mansão morada moradia

vivenda],<v> [agregar associar reunir])

(9,possuir,<v>[haver ter])

(10,estrutura,<nc>[arcaboiço arcabouço armação

carcaça esqueleto],<v>) (11, gaiola,<nc>)

(12,terreiro,<a_nc>[eira eirado terraço terrado praça

rossio]) (13,Paço,<nc>) (14,passar,<v>[atravessar

cruzar galgar transpor correr decorrer percorrer])

(15,chamar,<v>[invocar]) (16,Praça Comércio,

<mand>)

The tags used are <np> for proper noun, <adj> for

adjective, <nc> for common noun, <v> for verb,

<a_nc> for adjective or proper noun, and <mand>

for mandatory term marked by the teacher. As

shown in the example, some words have more than

one tag, because the tagger tags each word

regardless the context, and each word/tag may have

its own list of synonyms. In addition to this, the

words are not weighted, because this operation will

be performed next, in the evaluation module.

3.3 Evaluation Module

After the pre-processing module, the evaluation of

students’ responses, based on correct teacher's

answers, takes place. Our first approach was the

application of Vector Space Model (VSM) technique

(Salton et al., 1975). VSM measures how important

a word is to a document (answer) in a collection or

corpus (the exam). VSM is carried out without any

pre-processing task, because this approach does not

assign any value to words that appear in all answers.

VSM calculates the similarity between texts

representing them through vectors. The weight of

each word is obtained from the

tf × idf formula:

(,)

answ

Tot spellerror answ

Score

Tot words answ

−

(1)

Where, tf

is the number of times the term appears in

the answer, D is the total number of answers and df

is the number of answers in which the term appears.

This method assigns high weights to terms that appear

frequently in a small number of answers in the whole

exam.

Once the term weights are determined, all

teacher and students answers are represented by

vectors, and the similarity between them is

calculated using the the cosine measure. This

measure determines the angle between the document

vectors when they are represented in a V-

CSEDU2012-4thInternationalConferenceonComputerSupportedEducation

dimensional Euclidean space, where V is the

vocabulary size. Given two vectors answers (SA and

RA) the similarity is determined by the Eucledian

dot product:

(2)

Where the size of the vectors is based on the weight

of its words:

(3)

And the vectors product is the cross product between

the SA vector and the RA vector.

. w

SA RA RA i SA i

ww w

=×

∑

(4)

where w

RA,i

is the weight of term i in the RA, and is

defined in a similar way as w

SA,i

(that is, tfRA,i × idfi).

The denominator in equation 2, called the

normalization factor, discards the effect of document

lengths on document scores. One can argue whether

this is reasonable or not. In fact, when document

lengths vary greatly, it makes sense to take them into

account. However, in our case, the lengths of the

answers don't vary greatly because we are dealing

with short answers.

Nevertheless, the results obtained with VSM

differed substantially from those given by the

teacher, so we had to make some adjustments to

adapt to our context.

In the specific case of SAs, a word that appears

less frequently may be simply wrong and therefore

should not be valued. In order to get around this, we

first perform all the pre-processing tasks, removal of

punctuation, correction of spelling errors, removal of

stop-words, and stemming. Then, the vector space

model penalizes answers with different words

independently of their meaning. In fact, a student

may write answers using different syntaxes,

keywords and word counts, but the meaning could

be the same as the RA. If there is only one RA for

each question, the assessment will certainly be very

penalizing. So SAs should be compared with various

RAs. In order to do this we compare each SA with

various paraphrases of the RA created in the pre-

processing module.

3.3.1 Matching of Words

At this moment the RA and SAs are in its canonical

form, so the words considered in each answer are

meaningful and their frequencies in the answers are

low, not only because of the pre-processing tasks

applied, but also because we are dealing with short

text answers. The canonical form of the SA is

compared with the canonical form of the RA used to

look for similar words. Each word in the SA is

searched in the RA. If the word doesn't exist in the

RA we search for its tag in RA. After this if tag is

found, the word of SA is searched in the list of

synonyms of the word associated with the tag in the

RA. In other words, the various SA components of

sentences identified by its corresponding part of

speech tag, whose word doesn't match, will be

compared using the list of synonyms of the

corresponding tag in RA in an effort to better match

the SAs. If the word exists in the list of synonyms, it

is replaced, otherwise it is not. The word-matching

algorithm is presented next.

After these changes, we apply the formulas of the

VSM algorithm to calculate the similarity between

the RA and SA. The training set to assign the

weights to words is composed by teacher and

students exams. From the similarity value obtained

the answer score is calculated.

)

The score calculated Score

answer

is combined with the

number of spelling errors to calculate the final

answer score. Each spelling error has a fix value α

defined by the teacher and the penalization is based

on the quotient of number of wrong versus total

words in sentence. The following formula is used to

calculate the final score.

(,)

answ

Tot spellingerror answ

Score

Tot words answ

−

)

3.3.2 Evaluation and Analysis

We have tested our system with a History exam that

has sixteen questions. These questions were marked

up to a hundred points. The three different types of

questions, which include, enumeration, specific



(,)

RA SA

ASA

Sim RA SA

VectorSize VectorSize



()

...

wwwVectorSize +++=

oreQuestMaxScAnsSimilScore

answer

// Word-Matching Algorithm

Input: canonical_RA, canonical_SA

//for each word

in canonical SA

for s = 1,...,m

//if word

doesn’t exists in RA

if !search_word(word

,canonic_RA)

//for each tag word

for j = 1,...,n

//if tag

exists in RA

lstsyn=search_tag(tag

,canonic_RA)

//if word

is synonym of word

if search_synon(word

,lstsyn,synon)

replace(word

,synon)

AUTOMATICASSESSMENTOFSHORTFREETEXTANSWERS

knowledge and essay, were designed so that the

performance of the system can be satisfactorily

evaluated with all-types of short-answer questions.

Table 1 describes the questions exam in terms of RA

length, which gives the number of words in the RA,

the average length of SAs, which presents the

average number of words in all SAs for that

question, as well has, the difference between these

last two columns and the maximum answer score.

Table 1: Length of RA and SAs and score answers.

Question

RA length

(word)

Avg. SAs

length

(word)

Diff.

between

RA length

SA length

Max.

Answer

score

1.1 3 3,81 -0,81 6

1.2 7 11,29 -4,29 7

1.3 11 10,62 0,38 8

1.4 21 16,62 4,38 7

2.1 13 13,48 -0,48 7

4.1 1 1 0 7

4.2 5 1,52 3,48 6

5.1 4 3,48 0,52 7

5.2 13 12,86 0,14 7

6.1 9 1,38 7,62 5

7.1 30 7,76 22,24 6

7.2 22 19,86 2,14 6

7.3 13 6,34 6,66 7

As can be seen by the table, generally SAs are

smaller than RA.

Table 2: Summary of assessment results by question.

Quest.

Avg.

Teacher

scores

Avg.

System

scores

Scores

Diff.

Adjac.

Agreem

Avg.

Teach-Syst

Agreem

1.1 5,35 5,53 -0,18 0,03 0,59

1.2 4,88 3,88 1,00 0,14 0,35

1.3 2,18 1,47 0,71 0,09 0,41

1.4 3,82 2,94 0,88 0,13 0,06

2.1 6 5,94 0,06 0,01 0,06

4.1 2,24 3,18 -0,94 0,13 0,24

4.2 4,59 4,59 0,00 0,00 0,88

5.1 4,47 3,71 0,76 0,11 0,12

5.2 3,53 4,47 -0,94 0,13 0,35

6.1 0,82 2,12 -1,30 0,26 0,41

7.1 1,41 0,53 0,88 0,15 0,71

7.2 3,94 2,24

1,70

0,28 0,29

7.3 5,47 4,29 1,18 0,17 0,12

A History teacher took part in the evaluation

process. All SAs were assessed by the teacher to

determine the level of agreement between teacher's

evaluation and our system. The teacher was asked to

assign scores to answers using the scorings of the

answer, that is, if the answer has a maximum score

of 7 points, the teacher may score the question

between 0 and 7. Table 2 summarizes the results

collected in our experiments.

Average teacher scores and average system

scores is the mean of scores given by the teacher and

the system by answer, the third column presents the

difference between these last two scores. The

adjacent agreement is calculated by the following

formula:

(7)

The average teacher-system agreement rate for a

question is the number of times where teacher and

system agree, divided by the total number of SAs.

As illustrated in Table 2, the maximum

difference between system scores and the teacher’s

scores is 1.70 points in a question scored in 6 points,

which gives an agreement of 0.28. The average

teacher-system agreement rate measure tends to

decrease as the complexity of short-answer question

type increases. Another important pattern that may

be deduced from the data is that, as the average

answer length increases, the average teacher-system

agreement rate decreases.

In general, in the cases where system and

teacher’s scores don’t match, the teacher usually

assigns a higher score than the system. This is due to

the fact that the SA is too abstract, or the SA is much

smaller than the RA. In these cases, our system’s

score is lower than expected, because its precision is

based on the matching of words, and some SAs are

in a format where no matches can be found in the

RA, even though teacher evaluation indicates that

the student understands the learning concepts.

Therefore, experts assess such answers with a higher

score, thereby increasing the differences between

system and teacher assessments.

To evaluate the results obtained in this study, the

Pearson correlation was used (Noorbehbahani and

Kardan, 2011). Pearson correlation measures the

standard correlation, that is, how much the average

teacher scores (X) are associated with the system

scores (Y). Equation 8 is applied to calculate this

correlation.

(8)

We have obtained a promising correlation result of

0.78 which shows a reasonable correlation between

our system assessment and the teacher’s assessment,

but this can be improved.

Another analysis of the errors of our system

show that the errors fall into two categories: false

reanswer scomax.

scores systavg. scoresteach avg.

Agr Adjac.

|| −

)()(

),(

YtandDevSXtandDevS

YXCovariance

YXnCorrelatio

CSEDU2012-4thInternationalConferenceonComputerSupportedEducation

negatives (FN) and false positives (FP). A FN occurs

when an answer gets lower score than it deserves. A

FP occurs when the system assigns more marks to an

answer than it deserves. In case of our system's

evaluation, the number of FN was much higher than

the number of FP. 35% of all errors was FN while

only 25% were FP. The relative ratio of FN can be

explained based on the difficult of anticipating all

the possible paraphrases for an answer. If some

correct possibility is missed, then SA will lead to

FN. The most relevant scenario that accounts for

systems’ FP refers to students that don't know the

answer to the question, but are fortunate enough to

write some words that match with the RA.

4 CONCLUSIONS AND FUTURE

WORK

In this study, we proposed a system for free text

answer assessment. In the proposed approach, each

question has several RAs that are automatically

developed by our system, based on the word and its

part of speech tag. Answers submitted by students

can be compared with several RAs. After the word

matching algorithm that searches for similar words

of SAs in RA is applied, the similarity score is

calculated based on weights of common-words

between the SA and the RA. The system was tested

in the context of History exams, and some

evaluation results were presented. Despite

evaluation results showed a good correlation (0.78)

between average teacher scores and system scores,

we think it is possible to improve system results. We

intend to do that by detecting combined words,

(occurrences of n-grams), and using as RAs, SAs

previously marked by the teacher with the maximum

score. This way the system will be improved in a

continuous manner, when more and more training

examples - RAs are provided, which will permit a

more accurate assessment. Also teachers need to

obtain feedback on their teaching performance, and

students need feedback on their learning

performance, these goals will be achieved through

the development of the feedback module that we

intend to develop next.

REFERENCES

Mason, O., Grove-Stephenson, I., 2002. Automated free

text marking with paperless school. In Proceedings of

the Sixth International Computer Assisted Assessment

Conference, Loughborough University, UK.

Thomas P., Haley D., Roeck A., Petre M., 2004. E–

Assessment using Latent Semantic Analysis in the

Computer Science Domain: A Pilot Study. In

Proceedings of the Workshop on eLearning for

Computational Linguistics and Computational

Linguistics for eLearning, pp. 38-44. Association for

Computational Linguistics.

Valenti S., Neri F., Cucchiarelli A., 2003. An Overview of

Current Research on Automated Essay Grading.

Journal of Information Technology Education.

Perez-Marin D., Pascual-Nieto I., Rodriguez P., 2009.

Computer-assisted assessment of free-text answers.

The Knowledge Engineering Review, 24(4), pp. 353-

374.

Page, E. B., 1994. New computer grading of student prose,

using modern concepts and software. Journal of

Experimental Education, 62(2), pp. 127-142.

Jerrams-Smith J., Soh V., Callear D., 2001. Bridging gaps

in computerized assessment of texts. In Proceedings of

the International Conference on Advanced Learning

Technologies, pp.139-140.

Whittington, D., Hunt, H., 1999. Approaches to the

computerized assessment of free text responses. In

Proceedings of the Sixth International Computer

Assisted Assessment Conference, Loughborough

University, UK.

Burstein J., Leacock C., Swartz R., 2001. Automated

evaluation of essay and short answers. In Proceedings

of the Sixth International Computer Assisted

Assessment Conference, Loughborough University,

UK.

Rudner L. M., Liang T., 2002. Automated essay scoring

using Bayes’ Theorem. The Journal of Technology,

Learning and Assessment, 1(2), pp. 3-21.

Mitchell T., Russel T., Broomhead P., Aldridge N., 2002.

Towards robust computerized marking of free-text

responses. In Proceedings of the Sixth International

Computer Assisted Assessment Conference,

Loughboroug University, UK.

Smith, J., 1998. The book, The publishing company.

London, 2

edition.

Almeida, J. J., Simões A., 2007. Jspellando nas

morfolimpíadas: Sobre a participação do Jspell nas

morfolimpíadas. In Avaliação conjunta: um novo

paradigma no processamento computacional da

língua portuguesa. IST Press.

OpenThesaurus, 2010 http://openthesaurus.caixamagica.

pt/, last access, Feb 2011

Salton G., Wong A., Yang C. S., 1975. A Vector Space

Model for Automatic Indexing. Communications of the

ACM, vol. 18, nr. 11, pp. 613–620.

Noorbehbahani F., Kardan A. A. 2011. The Automatic

assessement of free text answers using a modified

BLEU algorithm. Computers & Education 56, pp.337-

345.

AUTOMATICASSESSMENTOFSHORTFREETEXTANSWERS
