A COMPARATIVE STUDY OF IMPLEMENTED COLLISION

DETECTION STRATEGIES

F´elix Paulano, Juan J. Jim´enez, Rub´en Pulido and Carlos J. Ogayar

Departamento de Inform´atica, University of Ja´en, Ja´en, Spain

Keywords:

Collision Detection, Spatial Decomposition, Bounding Hierarchy, Strategies Comparative.

Abstract:

Many computer interactive environments require to calculate collision detections between geometrical models,

usually triangle meshes. In this paper, a comparative study of some collision detection strategies is realized.

For this purpose, the compared algorithms have been implemented. Some of these algorithms also allow

realizing other procedures, such as calculating distances or overlapping triangles. Hence, the main features

of each algorithm have been explained. The compared strategies have been tested considering, in addition

to the runtime, the pre-processing time and the memory usage. Finally, the results have been compared in

order to extract the beneﬁts and constraints of each strategy, and proposing some possible applications for

each strategy.

1 INTRODUCTION

Interactive environments require methods that allow

performing collision detection tests between geo-

metrical models, usually triangle meshes (Lin and

Gottschalk, 1998; Bergen, 2003). Since interaction

must be in real time, it is necessary to utilize methods

that resolve the collision detection quickly. In addi-

tion, the methods must be robustso that the interactive

environment remains consistent.

Once the collision is detected, the interactive en-

vironment must give a response (Geiger, 2000). For

that, it is important not only to detect the collision, but

also to calculate a detailed collision. This involves

calculating some collision parameters, such us over-

lapping triangles, distances, and nearest points. These

calculations must be also calculated quickly in order

to keep a real time interaction.

In the literature, there are several approaches that

allow performing some of that calculations. Each ap-

proach has their advantages and disadvantages, hence

the use of one method depends on each situation. In

the present paper, we describe strategies to calculate a

detailed collision between two triangle meshes. These

strategies are implemented in order to test and com-

pare them. These tests allow extracting the main ben-

eﬁts and constraints of each strategy.

The following section deals with the proposed

strategies. Then, we will explain the implementations

and makea comparison between the differentstrategi-

es. Later, a possible GPU implementation of the pro-

posed strategies is studied. Finally, the beneﬁts and

constraints of each strategy are shown and some ap-

plications or each approach are suggested.

2 PROPOSED STRATEGIES

In order to perform a collision detection, we have

proved different strategies and determined their posi-

tive and negative points. On the one hand, we pretend

to calculate the collision detection. On the other hand,

we want to identify other features that allow us to im-

plement a correct response to a collision.

2.1 Spatial Decompositions

Hierarchical space decompositions allow increasing

the efﬁciency of the collision detection. This is be-

cause spatial decompositions permit to reduce the

space where the collision detection is performed. In

order to check a collision, the two spatial decompo-

sitions are compared recursively. Each recursive step

tests whether two nodes A and B, one from each hier-

archy, collide. If A and B do not collide, the collision

test ends. Otherwise, the collision test is performed

recursively to their children. If A or B are both leaf

nodes, the collision detection test is performed to the

triangles that are inside the leaf nodes. When down

485

Paulano F., J. Jiménez J., Pulido R. and J. Ogayar C..

A COMPARATIVE STUDY OF IMPLEMENTED COLLISION DETECTION STRATEGIES.

DOI: 10.5220/0003930604850490

In Proceedings of the International Conference on Computer Graphics Theory and Applications (GRAPP-2012), pages 485-490

ISBN: 978-989-8565-02-0

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

the hierarchy, some different strategies can be chosen.

For example, if A and B do not collide, we can test A

with each of the children of B, B with each of the chil-

dren of A, or each of the children of A with each of

the children of B. This choice modiﬁes the efﬁciency

of the method and depends on each case.

In order to perform the triangle-triangle collision

test, we have used the point in solid algorithm by

Feito (Feito and Torres, 1997). This method allows

performing a point in solid test without any complex

calculation, such as solving a system of equations. In

addition, this method is robust because it can work

with non-manifold polyhedra.

The octree (Chen and Huang, 1988) is one of the

most used hierarchical data structures. This structure

starts from a cuboid that contains all the triangles,

usually a bounding box. In general, the root box is

homogeneously divided into eight new boxes. The

subdivision stops when a preﬁxed level is reached or

a box contains less triangles than a threshold. There

are variations in the octree that can improve its per-

formance. One of the most used proposes a change

in the subdivision method of the boxes. Instead of di-

viding homogeneously each box, the dividing point is

selected so that it increases the efﬁciency.

The tetra-tree (Jim´enez et al., 2006) is a hierar-

chical data structure that divides the entire space into

eight equal parts named tetra-cones. In the follow-

ing levels of the hierarchy, each tetra-cone is homo-

geneously divided into four new tetra-cones. Due to

the adjustment obtained by bounding tetrahedra as-

sociated with each tetra-cone (Jim´enez and Segura,

2008), the tetra-tree ﬁts the mesh better that other ap-

proaches, such as the octree. In addition, the tetra-

tree allows classifying triangles quickly and robustly

because it is based on barycentric coordinates. In the

same way as the octree, the subdivision stops when a

preﬁxed level is reached or a tetra-cone contains less

triangles than a threshold.

2.2 Convex Hull

Convex objects enable the application of speciﬁc al-

gorithms in order to detect a collision. In general,

these algorithms are more efﬁcient because they take

advantage of the convex object features. We consid-

ered to build the convex hull of the objects in order to

apply speciﬁc algorithms, such us the GJK algorithm

(Gilbert et al., 1987) or some of its variants (Cameron,

1997). The quick hull method was chosen to build the

convex hull. Nevertheless, the main disadvantage is

that the convex hulls do not ﬁt the mesh properly in

most cases, hence the obtained results are not exact.

2.3 Bounding Volume Hierarchies

As an alternative to spatial decompositions and con-

vex hulls, we propose to use bounding volume hierar-

chies (Gottschalk et al., 1996; Klosowski et al., 1998).

Unlike the spatial decompositions, bounding volumes

do not ﬁll all the space and their nodes can overlap

between them.

In (Larsen et al., 1999), swept sphere hierarchies are

used to perform collision detections, identify over-

lapping triangles, determine nearest points, and cal-

culate distances. They used three different types of

swept volumes: a sphere, a cylinder with hemispher-

ical caps, and a rounded box. These volumes depend

on the swept primitive used: a point, a segment, and a

rectangle. The algorithm efﬁciency depends on the

volume used. The sphere allows building the data

structure quickly, but the rounded box ﬁts the mesh

better.

This algorithm utilizes a bounding volume traver-

sal tree (BVTT) in order to perform a query. Each

node of the BVTT represents a single collision test

between two bounding volumes. Hence, the BVTT

is traversed to perform a collision detection. In or-

der to improve query performance, this method uses a

priority directed search when the BVTT is being tra-

versed. Moreover, temporal coherence is also taken

into account. This method is implemented in the PQP

library.

In (Ehmann and Lin, 2001), they present an ap-

proach to detect collisions and calculate distances

based on convex surface decomposition. Moreover,

This method has three main steps. First, the model

is decomposed into convex parts. In order to achieve

that, a method based on graph search is used. Second,

a bounding volume hierarchy is constructed based on

the previous decomposition. They proposed a top-

down approach in which each node of the hierarchy

bounds all the geometry in its child nodes. For that

reason, the primitives are divided recursively in order

to obtain new convex patches.

Once the hierarchy is constructed, queries can

be executed. In order to perform queries between

pairs of convex polyhedra, the method uses a distance

minimization algorithm based on Voronoi marching

(Ehmann and Lin, 2000). Queries are accelerated us-

ing spatial and temporal coherence. This method re-

quires 2-manifold meshes and their triangles must be

sorted counter-clockwise. This algorithm is imple-

mented in the SWIFT++ library.

GRAPP 2012 - International Conference on Computer Graphics Theory and Applications

486

Table 1: Features implemented by each method. Tetra-tree and Octree utilize the Feito- Torres algorithm.

Feito GJK PQP SWIFT++

Collision X X X X

Overlapping triangles X X

Distance X X X

Tolerance X X

Contact features X

Table 2: Pre-processing time (s) and size (MB) of the spatial decompositions.

Tetra-tree Octree

Vertices Triangles Pre-processing Size Pre-processing Size

Horse 3582 7172 0,427 0,0351 0,496 0,0399

Skull 20002 40000 2,49 0,2608 4,329 0,261

Bunny 35947 69451 4,544 0,4211 8,744 0,3254

Armadillo 172974 345944 28,184 2,0322 44,579 1,6549

Dragon 437645 869928 70,25 4,8031 104,68 2,1975

Buddha 543652 1085634 84,704 5,5607 138,542 4,8717

3 IMPLEMENTATION AND

RESULTS

In order to check their performance, the described

strategies have been implemented under the same

conditions. In order to developed this, we have used

the same programming language (C++) and the same

compiler (gcc). The implemented data structures are

the octree and the tetra-tree. The Feito’s algorithm has

been used to check the intersection between triangles.

In addition, qhull, PQP, and SWIFT++ libraries have

been used.

Spatial decompositions, as well as the Feito and

Torres algorithm have been implemented without the

use of any library. Moreover, we have not used any

optimization, nor have considered spatial or tempo-

ral coherence. That means that the implementation is

less optimized than other approaches which are based

on a library. Hence, the obtained results should not

be as good as the implemented libraries. In order

to implement the convex hull, the qhull library has

been utilized. This library implements the quickhull

algorithm and is one of the most used libraries. Nev-

ertheless, the collision detection based on the qhull

implementation has not been tested because the re-

sults obtained are not as accurate as the rest of ap-

proaches, hence the obtained results should not be

compared with them. The PQP library, that is writ-

ten in C++, can work with any model composed of

triangles. Hence, it is not necessary that the mesh is

closed or 2-manifold. This library allows detecting

collisions and overlapping triangles, calculating dis-

tances and nearest points, and determining if two

models are closer than a given threshold. The

SWIFT++ library is implemented in C++ and is di-

vided into two parts. The main part allow performing

intersection, calculating exact and approximate dis-

tances, and resolving contact determination queries

between two or more objects. These objects must

be convex and closed. However, the other part of

the library enables the conversion of non-convex and

opened models into convex hierarchies that can be

processed by the main part of the library. This library

can not work with non-2-manifold models or that con-

tain counter clockwise triangles. The features of the

algorithms are summarized in table 1.

3.1 Results

We have performed some tests to measure the efﬁ-

ciency of the proposed strategies. These tests were

done with six models with a polygonal complexity in

the range from 7172 to 1085634 triangles (table 2).

Some of the models used(ﬁgure 1) have holes and are

not-2-manifold, therefore we can test the robustness

of each strategy. The measured parameters have been

the pre-processing time, the size of the data struc-

tures, and the time to determine the collision detec-

tion and to calculate the overlapping triangles. These

tests were performed on a 2,8 GHz Intel i7 PC with 4

GB of RAM.

Firstly, we have developed some tests to measure

the spatial decomposition performance. Both data

structures have been built under the same conditions:

A COMPARATIVE STUDY OF IMPLEMENTED COLLISION DETECTION STRATEGIES

487

Table 3: Pre-processing time (s) and size (MB) of the proposed strategies.

Convex Hull PQP SWIFT++

Models Pre-processing Size Pre-processing Size Pre-processing Size

Horse 0,202 0,0252 0,045 2,8726 0,599 2,9544

Skull 3,8 0,6182 0,265 16,0216 8,094 20,6092

Bunny 4,3 0,2916 0,47 27,818 8,148 31,6224

Armadillo 15,7 0,3662 2,552 138,5654 380,121 162,3651

Dragon 42,5 0,4613 6,678 348,9311 Not 2-manifold Not 2-manifold

Buddha 130,4 1,1556 8,327 435,5262 Not 2-manifold Not 2-manifold

Table 4: Colision detection (C.D.) and overlapping triangles (O.T.) calculation (s) between object A and B using the proposed

strategies.

Octree Tetra-tree PQP Swift++

Model A Model B C.D. O.T. C.D. O.T. C.D. O.T. Collision

Buddha Horse 0,5807 0,6236 0,2161 0,409 0,0034 0,0104 Not-2-Manifold

Buddha Skull 1,8118 2,2317 0,2787 1,712 0,0076 0,017 Not-2-Manifold

Buddha Bunny 1,2058 1,7777 0,2481 1,1735 0,0102 0,041 Not-2-Manifold

Buddha Armadillo 2,026 4,5383 0,875 3,447 0,0106 0,4625 Not-2-Manifold

Dragon Horse 0,4144 0,3593 0,1444 0,307 0,0014 0,0043 Not-2-Manifold

Dragon Skull 0,8103 1,7643 0,2064 1,1583 0,0034 0,009 Not-2-Manifold

Dragon Bunny 0,6852 1,4197 0,2195 0,8823 0,0045 0,0145 Not-2-Manifold

Dragon Armadillo 1,1456 3,622 0,573 2,69 0,0087 0,0313 Not-2-Manifold

Armadillo Horse 0,0923 0,32 0,0892 0,22 0,0013 0,004 ≈ 0

Armadillo Skull 0,2605 1,5928 0,1108 1,184 0,0026 0,0054 ≈ 0

Armadillo Bunny 0,234 1,483 0,1673 0,9248 0,0033 0,009 ≈ 0

Armadillo Armadillo 0,588 3,3435 0,4418 3,207 0,0037 0,016 ≈ 0

same level and maximun threshold of triangles per

node. Nevertheless, it should be noted that the oc-

tree performs 8 subdivisions in each node and the

tretra-tree performs only 4, hence the number of oc-

tree nodes is higher. The results are shown in table 2.

In general, the tetra-tree has less pre-processing time,

but it needs more memory space.

The pre-processing time and size of the proposed

bounding volumes hierarchies have been measured.

Moreover, the convex hull has also been tested. The

size of each structure has been measured theoretically

because the real size depends on each machine and

compiler. Therefore, the calculated size is approxi-

mate.

In the case of spatial decompositions, size has

been calculated based on the theoretical size of each

node. In order to achieve this, the number of nodes

and their associated triangles have been measured. It

was considered that each node in the tetra-tree re-

quires 88 bytes: 16 bytes for children nodes (4 bytes

for each child pointer) and 72 bytes for tetra-cone ver-

tices (24 bytes per vertex). Since the centroid is a

common vertex for all the tetra-cones, it only needs to

store 3 vertices per tetra-cone. Additionally, the root

node requires 340 bytes: 4 bytes for the origin pointer,

8 bytes for the pointers to the lists of vertices and

triangles (4 bytes per pointer), 8 bytes for the num-

ber of vertices and triangles (4 bytes per number), 32

bytes for the eight initial tetra-cones (4 bytes for each

tetra-cone pointer), and 576 bytes for the vertices of

the initial tetra-cones (3 vertices per tetra-cone and

24 bytes per vertex). The octree requires 80 bytes per

node: 32 bytes for children nodes (4 bytes for each

children pointer) and 48 for the structure (2 vertices

and 3 coordinates per vertex). In this case, the root

node requires 72 bytes: 8 bytes for the pointers to the

lists of vertices and triangles, 8 bytes for the number

of vertices and triangles, 32 bytes for the initial oc-

tants (4 bytes for each octant), and 24 bytes for the

initial structure. In addition, both spatial decomposi-

tions need 4 bytes for each classiﬁed triangle.

PQP allows knowing the size of each structure at

runtime, hence this procedure has been used to calcu-

late the approximate size of the structure associated

with each model. It has not been possible to reach the

size of the data structures used by SWIFT++. How-

ever, this library allows exporting the hierarchies to a

ﬁle in order to facilitate reuse. We have used the size

of this ﬁle to approximate the size of the hierarchical

structure.

GRAPP 2012 - International Conference on Computer Graphics Theory and Applications

488

Figure 1: Models used for testing. From left to right and from top to bottom: horse, skull, bunny, armadillo, dragon and

buddha.

The results are shown in table 3. PQP is the op-

tion that requires less pre-processingtime, but it needs

a large amount of memory space. SWIFT++ also take

a long time and a lot of memory to build its struc-

ture. Moreover, it can not work with all of the pro-

posed models. The convex hull size is small because

its structure is very simple.

Table 4 shows the performance of each method to

calculate a collision detection and overlapping trian-

gles. SWIFT++ is the fastest method we are tested,

but it can not work with all the proposed models be-

cause some of them are non-2-manifold. Moreover,

it does not allow determining overlapping triangles.

PQP has a reasonable good performance and its main

advantage is that can work with all the proposed mod-

els. The spatial decomposition based methods do not

have good results. In both cases, spatial decomposi-

tions have been built under the same conditions as in

table 2.

Some tests to measure the performance of the

tetra-tree in an interactive environment are realized

in (Jim´enez et al., 2011). Models of different sizes

are used in order to perform these tests. Their results

show, in the same way as ours, that the tetra-tree re-

quire less pre-processing time that the octree, but it

needs a little more space in memory. The tests show

that the tetra-tree has some advantages with respect

to other approaches. Some of the main beneﬁts are

that the tetra-tree enables the selection of inaccessible

parts without the use of extra algorithms and enable

an accurate level of detail.

3.2 GPU Optimization

Some of the proposed strategies obtain good results,

hence they can be applied to real-time interactive en-

vironments. However, some complex applications,

such us haptic interaction or complex deformations,

may require higher performance. In haptic interac-

tion, the refresh rate is 1Khz (Lin and Otaduy, 2008),

hence the collision detection should be calculated in

less than one millisecond. In order to achieve that, the

approaches shown could be improved and optimized

by using the GPU.

Spatial decompositions are not easily adaptable to

be used in parallel algorithms. However, in (Jim´enez

et al., 2009) a novel algorithm is presented. This algo-

rithm allows building and utilizing spatial decomposi-

tions in GPU. For that, they propose to use the geom-

etry shader. Each execution unit classiﬁes a triangle

in a certain level, regardless of others. They propose

to use a n-sized texture for each level of the hierarchy,

where n is the number of triangles. Hence, the mesh

should be processed l times, where l is the level of the

hierarchy, in order to classify the mesh. In addition,

they propose to pre-calculate the spatial decomposi-

tion volume and codify it through a 2D texture.

The other libraries used do not have a GPU im-

plementation. However, in (Srungarapu et al., 2011)

the authors present a method to construct a convex

hull in GPU that could be adapted to build it in 3D.

This could be used in order to improvethe convex hull

strategy. Moreover, it would be interesting to consider

a GPU implementation of the other proposed strate-

gies.

4 CONCLUSIONS

In this work, we have presented some strategies to de-

tect collisions in interactive environments. Moreover,

some of the exposed methods allow performing other

A COMPARATIVE STUDY OF IMPLEMENTED COLLISION DETECTION STRATEGIES

489

interesting calculations, such us distances or nearest

points. On the one hand, SWIFT++ is the faster li-

brary we tested, but it requires a lot of pre-processing

time. On the other hand, PQP does not require much

pre-processing time and it is quite efﬁcient at calcu-

lating collisions. Therefore, the use of each library

depends on the needs of each particular problem.

Since the octree and the tetra-tree has been im-

plemented without the use of any library, both spatial

decompositions, along with the Feito’s algorithm, can

be utilized to develop interactive systems that require

to implement extra functionality. Due to its robust-

ness, PQP is a good option in systems that work with

meshes that could be topologically not correct. This

is the case of systems that work with reconstructed

meshes, such us surgery simulators with medical im-

ages and scanner data. Moreover, PQP could be

a good solution for visualization applications, since

meshes used in such applications do not need to be

topologically correct. Finally, the SWIFT++ library

is suitable for real time environments that require a

good performance but that can ensure that the topol-

ogy of the models is correct. For that reason, this

library could be used for working with solid mod-

els which have been generated by mathematical and

boolean operations that conserve their topology. In

addition, this library could also be used in machining

simulation. In all three approaches, the implemented

systems must support a pre-processing step in which

construct the data-structures.

ACKNOWLEDGEMENTS

This work has been partially supported by the

Ministerio de Ciencia e Innovaci´on and the Euro-

pean Union (via ERDF funds) through the research

project TIN2011-25259 and by the University of Ja´en

through the research project UJA2010/13/08 spon-

sored by Caja Rural de Ja´en.

REFERENCES

Bergen, G. V. D. (2003). Collision Detection in Interactive

3D Environments. Elsevier.

Cameron, S. (1997). Enhancing gjk: computing mini-

mum and penetration distances between convex poly-

hedra. In Robotics and Automation, 1997. Proceend-

ings., 1997 IEEE Inter, pages 3112–3117.

Chen, H. and Huang, T. (1988). A survey of construction

and manipulation of octrees. Computer Vision, Graph-

ics, and Image Processing, 43:409–431.

Ehmann, S. and Lin, M. (2000). Accelerated proxim-

ity queries between convex polyhedra by multi-level

voronoi marching. In Intelligent Robots and Systems,

2000. (IROS 2000). Proceedings. 2000 IEEE/RSJ In-

ternational Conference on, volume 3, pages 2101 –

2106.

Ehmann, S. and Lin, M. (2001). Accurate and fast prox-

imity queries between polyhedra using convex sur-

face decomposition. Computer Graphics Forum,

20(3):500–511.

Feito, F. and Torres, J. (1997). Inclusion test for general

polyhedral. Computers & Graphics, 21(1):23–30.

Geiger, B. (2000). Real-time collision detection and re-

sponse for complex environments. In Computer

Graphics International, 2000. Proceedings, pages 105

– 113.

Gilbert, E., Johnson, D., and Keerthi, S. (1987). A fast pro-

cedure for computing the distance between complex

objects in three space. In Robotics and Automation.

Proceedings. 1987 IEEE International Conference on,

volume 4, pages 1883–1889.

Gottschalk, S., Lin, M., and Manocha, D. (1996). Obbtree:

a hierarchical structure for rapid interference detec-

tion. In Proceedings of the 23rd annual conference on

Computer graphics and interactive techniques, SIG-

GRAPH ’96, pages 171–180. ACM.

Jim´enez, J., Feito, F., Segura, R., and Og´ayar, C. (2006).

Particle oriented collision detection using simplicial

coverings and tetra-trees. Computer Graphics Forum,

25:53–68.

Jim´enez, J. and Segura, R. (2008). Collision detection be-

tween complex polyhedra. Computers & Graphics,

4(32).

Jim´enez, J. J., Feito, F. R., and Segura, R. J. (2011). Tetra-

trees properties in graphic interaction. Graphical

Models, 73(5):182 – 201.

Jim´enez, J. J., Mart´ınez, A., and Feito, F. R. (2009). Dise˜no

de descomposiciones espaciales jer´arquicas para mal-

las de tri´angulos utilizando geometry shaders. de-

sign of hierarchical space decompositions for triangle

meshes using geometry shaders. In CEIG09. Spanish

conference on Computer Graphics, pages 95–104.

Klosowski, J., Held, M., Mitchell, J., Sowizral, H., and

Zikan, K. (1998). Efﬁcient collision detection using

bounding volume hierarchies of k-dops. Visualiza-

tion and Computer Graphics, IEEE Transactions on,

4(1):21–36.

Larsen, E., Gottschalk, S., Lin, M., and Manocha, D.

(1999). Fast proximity queries with swept sphere vol-

umes. Technical report, Department of Computer Sci-

ence, UNC Chapel Hill.

Lin, M. and Gottschalk, S. (1998). Collision detection be-

tween geometric models: A survey. In In Proc. of IMA

Conference on Mathematics of Surfaces, pages 37–56.

Lin, M. and Otaduy, M. (2008). Haptic Rendering: Foun-

dations, Algorithms and Applications. A. K. Peters

Ltd.

Srungarapu, S., Reddy, D., Kothapalli, K., and Narayanan,

P. (2011). Fast two dimensional convex hull on the

gpu. In Advanced Information Networking and Appli-

cations (WAINA), 2011 IEEE Workshops of Interna-

tional Conference on, pages 7–12.

GRAPP 2012 - International Conference on Computer Graphics Theory and Applications

490
