GRANULES OF WORDS FROM FUZZY RELATIONS AND
SPECTRAL CLUSTERING
Patrícia F. Castro
1
and Geraldo B. Xexéo
1,2
1
Departamento de Engenharia de Sistemas e Computação, COPPE/UFRJ, Rio de Janeiro, Brazil
2
Departamento de Ciência da Computação, IM/UFRJ, Rio de Janeiro, Brazil
Keywords: Granular Computing, Fuzzy Relation, Spectral Clustering.
Abstract: Conventional information retrieval systems have proven ineffective in dealing with information overload.
One possible solution is to incorporate some features that allow users of these systems to custom handle this
information. In order to enable systems of this kind, some of the characteristics of present-day systems
should be reviewed. Among other features, all documents are described with the same level of detail. We
believe that the redrafting of document models is the starting point for reform of these systems. The
paradigm of granular computing has proven to be very suitable for the treatment of complex problems and
can produce significant results in large-scale environments such as the Web. This paper explores the
granulation process of words with a view to its application in the subsequent improvement in document
representation. We use fuzzy relations and spectral clustering in this process and present some result.
1 INTRODUCTION
Possible solutions for the information overload
problem involve processes such as information
retrieval, filtering, and extraction, as well as
classification, clustering, and summarizing of
documents, with the aim of assisting people to
locate, in a more efficient way, the documents that
meet their information needs. These needs can be
defined as discovering or deriving new information,
finding patterns in such information or separating
the information that is useful from that which is not.
(Yao, 2002) says that the incorporation of these
features in current information retrieval systems give
rise to the emergence of a new generation of such a
system: the information retrieval support systems.
In order to enable systems of this kind, some of
the characteristics of present-day systems should be
reviewed and re-engineered. These systems use
document representation schema that are very
simple, as well as a retrieval method that is also
quite simple. All the documents are described with
the same level of detail. The representation and
retrieval method are the same, regardless of the
user’s characteristics. The structure and semantics of
information, as contained in the document and in the
collection, are not taken into consideration.
A paradigm that arises from the treatment of
information, known as granular computing, has
attracted the attention of many researchers.
According to (Yao, 2007), granular computing
gathers a set of theories, methodologies, techniques,
and tools, that employ granules to solve complex
problems. According to (Predycz, 2005), the
granules permeate any human task. Humans are
constantly abstracting and formulating concepts
from these granules, processing these concepts and
returning the results of such treatment. To give an
example, we can make an analogy with the human
capability of dealing with images. At no given
moment do we consider the pixels individually. All
the time we build groupings of these pixels using
some semantics capable of conveying notions of
texture, colour, etc. Similarly, when analyzing text,
the words are not considered individually.
Groupings of these words, representing some
semantics, convey their contents.
Moreover, humans can perceive the real world
through many levels of granularity (abstraction) and
can easily alternate between these various levels.
Consequently, people abstract and consider only
that which serves a specific purpose and ignore that
which is irrelevant (Yao and Zhong, 2002); (Hobbs,
1985); (Yao, 2007a). By being able to focus on
different levels of granularity, different levels of
knowledge can be obtained as well as a deeper
683
F. Castro P. and B. Xexéo G..
GRANULES OF WORDS FROM FUZZY RELATIONS AND SPECTRAL CLUSTERING.
DOI: 10.5220/0003934706830688
In Proceedings of the 8th International Conference on Web Information Systems and Technologies (WEBIST-2012), pages 683-688
ISBN: 978-989-8565-08-2
Copyright
c
2012 SCITEPRESS (Science and Technology Publications, Lda.)
understanding of the structure that is inherent to
each type of knowledge.
Granular reasoning is, therefore, essential for
human intelligence and, according to (Zhong, 2008),
it can have a significant impact on problem-solving
methodologies, especially in large-scale
environments such as the Web.
The granulation process is based on the
decomposition of objects according to some kind of
relationship whereby these objects stay together.
The process is inherently fuzzy, vague and
imprecise. This paper explores this process, through
the use of fuzzy relations. Based on this kind of
relationship we use a spectral clustering algorithm in
the creation of the granules and present some results.
2 RELATED WORKS
Alternative techniques for creating document models
have aroused the interest of many researchers. Some
approaches are based on the same vector model (Liu,
1994) and others suggest alternative ways. (Doan et
al., 2005) proposes the modeling of texts based on
the theory of fuzzy sets. (Khalled, 2006) presents a
new paradigm for mining documents that can exploit
the semantic features of documents. (Ingersen et al.,
2008) is based on the cognitive aspects of
information retrieval in its proposal. (Fishbein,
2008), proposes a scheme based on Holographic
Reduced Representations (HRR) to encode both the
semantic structure and syntactic structure of
documents. Finally, similar to the proposal presented
in this paper, (Lin, 2007) employs granular
computing concepts in the treatment of the problem.
The granules are formed by sets of keywords with
frequent co-occurrence. In this context, other
techniques have been proposed. Latent Semantic
Analysis (LSA) (Dumais, 1997) uses principal
component analysis to find groups of words that co-
occur. Topic models (Steyvers, 2007) is a statistical
model for discovering abstract topics in document
collections. Analysis of formal concepts (Ganter,
2005) also uses the evaluation of objects and their
relationships in order to identify concepts or topics
of interest.We present a new method for the analysis
of co-occurrence of words. We also use an algorithm
that proves very effective for capturing this type of
relationship between words to form granules. We
believe this is the greatest contribution of this work.
3 WORD GRANULATION
Granulation means forming aggregates of
indiscernible objects. The indiscernibility between
these objects can be treated by a similarity function.
There are two terms used to denote the main types of
similarity between words (Kozima, 1993) (Rapp,
2002): paradigmatic similarity and syntagmatic
similarity. Despite this distinction, it is relatively
rare in published works, and some studies (Kozima,
1993) refer to the first type as semantic similarity,
and to the second (Rapp, 2002) as relatedness
similarity. The focus of our work is essentially on
the second kind. Both types are computed using
different methods and are used in a wide variety of
applications. Relatedness similarity is generally
measured by employing some statistical or algebraic
tool. In this paper we present a fuzzy approach for
the analysis of this similarity.
4 FUZZY RELATION
In this section we present a brief review of the
theory of fuzzy relations (Chakrabarti, 2003);
(Haruechaiyasak, 2002); (Zadeh, 1993) used in the
assessment of the similarity between words and the
subsequent creation of granules.
Definition 1. A fuzzy relation between two finite
sets X = {x
1
, ...., x
u
} and Y = {y
1
, ...., y
v
} is
formally defined as a fuzzy binary relation f: X × Y
J[0,1], where u and v represent the number of
elements in X and Y, respectively.
Definition 2. Given a set of index terms, T = {t
1
,
..., t
i
} and a set of documents, D = {d
1
, ..., d
j
}, each
t
i
is represented by a fuzzy set h(t
i
) of documents;
h(t
i
) = {F(t
i
,d
j
) | d
j
D}, where F(t
i
,d
j
) is the
membership degree of t
i
in d
j
.
Definition 3. The fuzzy relationship between
words is based on the evaluation of co-occurrence
of t
i
and t
j
in the set D and can be defined as
follows:
RT (t
i
,t
j
) =
 (
(
,

)
,(
,
)
 (
(
,

)
,(
,
)
(1)
A simplification of the fuzzy RT relation based on
co-occurrence of words is given as follows:
r
i,j
=
,


,
(2)
where
r
i,j
represents the fuzzy RT relation between
WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies
684
words i and j
n
i,j
is the number of documents containing both
the i
th
and j
th
words
n
i
is the number of documents containing the i
th
word
n
j
is the number of documents containing the j
th
word
5 SPECTRAL CLUSTERING
The spectral clustering technique is characterized
by exploring the similarity between all pairs of
objects. This technique has proven to be much
more effective than more traditional techniques
such as the k-means method, for example, which
considers only the similarity of the objects to the
central elements of their groups (Ng, 2001).
Given n data points x
1
... x
n
, the spectral
clustering algorithm constructs a similarity matrix S
R
n x n
, where S
i,j
0 reflects the relationship
between x
i
and x
j
. It then uses similarity information
to group x
1
... x
n
into k clusters. There are several
variants of spectral clustering. Here we consider the
commonly used normalized spectral clustering (von
Luxburg, 2006).
6 EVALUATION
We have created two distinct corpora. The first
corpus contains 200 articles on computational
intelligence selected from Google Scholar. These
articles are related to 10 distinct subjects:
cognition, fuzzy systems, genetic algorithms,
neural networks, data mining, knowledge
management, machine learning, pattern
recognition, optimization and logic. For the second
corpus, 160 articles on text mining/information
retrieval were selected from the same site. In this
case, eight subjects were used: clustering, latent
semantic analysis, information retrieval, ontology,
semantics, fuzzy relations, concept extraction and
topic models. Each corpus was subjected to a pre-
processing step where stopwords and words not
classified as nouns were removed through
application of a tagger available in
http://dragon.ischool.drexel.edu/. Next, we
analyzed the fuzzy correlation between these
words, by applying equation 2, presented in section
4. Words and their correlations were subjected to
the spectral clustering algorithm with
implementation available over
http://www.mathworks.com/matlabcentral/fileexch
ange /26354-spectral-clustering-algorithms.
The implementation requires information about
the value of k. Initially, we adopted k values of 10
and 8 for the first and second corpus, respectively.
The justification for this lies in the fact that we
have chosen 10 subjects and, therefore, based on
this choice, we can control the groups generated. In
a second evaluation, we reduced these values by
half: 5 and 4, in each corpus, respectively. The aim
was to examine the clustering algorithm’s ability to
make generalizations of the words contained in
their groups. The algorithm parameters were kept
at their default values. Tables 1, 2, 3 and 4 present
the most significant words found in each of the
clusters generated in each of the scenarios
described above.
Table 1: The 10 clusters/granules of corpus 1.
GRANULE
SUBJECT
KEYWORDS
1
machine learning
computer, aspect, behavior,
intelligence, paradigm,
years
2
----
exploration, benchmark,
architecture, variation,
characteristic, interaction,
fact
3
neural network
extension, importance,
neuron, goal, stability,
property, choice
4
knowledge
management
storage, knowledge,
capability, management,
path, business
5
Cognition
representation, theory, life,
language, cognition
6
pattern recognition
conclusion, input,
classification, region,
element, application
7
genetic algorithm
population, fitness,
optimum, member,
algorithm, convergence,
solution
8
----
importance, performance,
definition, statistics,
measurement
9
data mining
attention, data, concept,
generalization, addition,
relationship
10
----
extraction, example,
relations, variable, analysis,
satisfaction
Aiming to establish a comparison with a well-
known approach, we submit on the same basis, an
algorithm for latent semantic analysis (LSA). Tables
5 and 6 represent the degree of similarity between
the granules generated with the technique proposed
in this work and the concepts (granules) obtained
with LSA. The contents of each cell in the table
represent the percentage of similarity between the
GRANULESOFWORDSFROMFUZZYRELATIONSANDSPECTRALCLUSTERING
685
granules and concepts. To facilitate the analysis, we
highlighted the cells with the greatest similarity
measures.
Table 2: The 5 clusters/granules of corpus 1.
GRANULE
SUBJECT
KEYWORDS
1
genetic
algorithm /
optimization
exploration, performance,
fitness, operator, member,
algorithm, convergence,
solution, population, optimum,
crossover
2
neural networks
extension, input, example,
property, regression, analysis,
neuron, procedure, realization,
synthesis, vector, coefficient,
manner, applicability
3
data mining /
knowledge
management
user, technique, topic, storage,
knowledge, management,
capability, information,
methodology, data, business,
database
4
cognition /
logic
behavior, theory, life, paradigm,
language, computer, principle,
aspect, manipulation,
intelligence
5
cognition
protocol, difference, relations,
complexity, analysis, problem,
role, system, cognition, method,
application
Table 3: The 8 clusters/granules of corpus 2.
GRANULE
SUBJECT
KEYWORDS
01
semantic
evolution, entity, library,
management, language,
technology, ontology, domain,
description, semantics
02
latent
semantic
analysis
subspace, combination, detection,
decomposition, association,
retrieval, matrix, effectiveness,
vector, collection
03 clustering
example, prototype, constraint,
tendency, algorithm, objective,
possibility, principle, data,
problem,
04
information
retrieval
period, kind, property, relations,
decomposition, retrieval,
information, expansion, criterion,
construction
05
concept
extraction
extension, representation,
evaluation, concept, strategy,
selection, explanation, logic,
interpretation, identification, text,
baseline
06 ontology
mechanism, classifier, correlation,
thesaurus, creation, ontology,
context, integration, recognition,
source, module.
07
fuzzy
relations
membership, co-occurrence, set,
binary
08 topic models
probability, language, processing,
mixture, model, generator
Table 4: The 4 clusters/granules of corpus 2.
GRANULE
SUBJECT
KEYWORDS
01
semantic/
ontology
development, evolution, entity,
library, management, language,
version, technology, ontology,
methodology, domain,
description, semantics, input,
mechanism, classifier,
correlation, thesaurus, creation,
ontology, context, integration,
identification, recognition,
source, module.
02
latent semantic
analysis/
concept
extraction
item, user, basis, subspace,
combination, detection,
decomposition, association,
retrieval, matrix, effectiveness,
vector, collection, method,
extension, representation,
evaluation, concept, strategy,
selection, explanation, addition,
logic, interpretation,
identification, text, baseline
03
clustering/
information
retrieval
example, prototype, constraint,
tendency, algorithm, objective,
possibility, finding, principle,
data, problem, difficulty, period,
user, minimum, kind, property,
relations, decomposition,
retrieval, information,
expansion, criterion, method,
construction
04 topic models
probabilistic, language,
processing, mixture, model,
generative
7 RESULTS
Looking through Tables 1 and 3, the proposed
technique combines words significant enough to
present the topics in each corpus. In corpus 1, for
computational intelligence, 7 topics are easily
identified from the words associated with their
clusters/granules. In corpus 2, on text mining /
information retrieval, we achieved better results,
because the eight subjects that make up the corpus
are easily identified. The results presented in Tables
2 and 4 show that the technique performs well
against the ability of granule generalization
contained in the corpus.
With respect to corpus 1 which was tested, we
give special emphasis to the grouping of words that
describe the topics of genetic
algorithms/optimization and data mining/ knowledge
management. Such topics are strongly related. The
proposed technique shows consistency since it
captures these relationships by grouping the words
contained in their respective documents. LSA
identified 13 clusters of words for corpus 1 text and
10 clusters for corpus 2.
WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies
686
Table 5: Equivalence between granules and concepts for corpus 1.
G
R
A
N
U
L
E
LSA
1 2 3 4 5 6 7 8 9 10 11 12 13
1
0.39 0.53 0.50 0.49 0.45 0.42
0.92 0.42 0.42 0.45 0.51 0.32 0.56
2
0.96 0.41 0.55 0.43 0.45 0.60 0.42 0.56 0.38 0.44 0.32 0.45 0.34
3
0.46 0.67 0.43 0.40 0.45 0.56 0.50
0.89 0.42 0.34 0.23 0.56 0.42
4
0.58 0.67 0.76 0.40 0.40 0.54 0.45 0.78 0.23 0.34 0.56 0.56 0.92
5
0.34 0.45 0.76 0.23 0.40 0.54 0.45 0.78
0.95 0.34 0.56 0.56 0.23
6
0.39 0.34 0.50 0.87 0.45 0.42 0.67 0.42 0.42 0.67 0.51 0.68 0.45
7
0.46 0.24 0.43 0.46 0.45 0.56
0.78 0.45 0.42 0.34 0.25 0.56 0.42
8
0.78 0.85 0.36 0.32 0.45 0.60 0.42 0.15 0.38 0.44 0.47 0.45 0.39
9
0.39 0.34 0.36
0.87 0.45 0.42 0.67 0.47 0.68 0.67 0.51 0.68 0.76
10
0.45 0,48 0.50 0.35 0.47 0.42 0.67 0.42 0.65 0.67 0.90 0.68 0.45
Table 6: Equivalence between granules and concepts for corpus 2.
G
R
A
N
U
L
E
LSA
1 2 3 4 5 6 7 8 9 10
1
0.39 0.53
0.96 0.49 0.32 0.42 0.51 0.42 0.42 0.45
2
0.43 0.41 0.32 0.43 0.45 0.60 0.42 0.96 0.38 0.44
3
0.46 0.67 0.23
0.88 0.68 0.56 0.50 0.47 0.42 0.34
4
0.58 0.67 0.56 0.40 0.56 0.57 0.45 0.78 0.23 0.87
5
0.34 0.45 0.56 0.23 0.56 0.54 0.45 0.78
0.95 0.34
6
0.39 0.34 0.51 0.33 0.68 0.82 0.67 0.42 0.42 0.67
7
0.46 0.24 0.25 0.46 0.56 0.56
0.89 0.45 0.42 0.34
8
0.78 0.92 0.47 0.32 0.45 0.60 0.42 0.15 0.38 0.44
Despite the greater number of groups, we can see
that in all groups of words created with the
technique presented in this work, both corpus are
defined by an LSA equivalence. Thus, we
understand that the techniques are equivalent in
terms of effectiveness. Although not measured in
terms of processing time for each technique, we
observed that the technique proposed here
performs better than LSA.
8 CONCLUSIONS
The paper explored the granulation process based
on fuzzy relations of co-occurrence and spectral
clustering. The methodology was presented and
some preliminary results were shown. These
results demonstrate the real applicability of the
proposal. Our next step will be to explore the
ability of this technique in the generalization and
specialization of granules. This feature will allow
the construction of building ontologies with these
granules. We also intend to study a way to allow
GRANULESOFWORDSFROMFUZZYRELATIONSANDSPECTRALCLUSTERING
687
overlap between the granules produced. The
clustering algorithm used does not allow this
overlap and we understand that this feature will
produce granules much more significant than
those produced with the current method. We
believe the introduction of such features will
enable the representation of documents whose
handling is closer to the human way of dealing
with granules, as described in the introduction.
ACKNOWLEDGEMENTS
The authors would like to thank the financial
support of CNPq, CAPES, FAPERJ and
Fundação Coppetec.
REFERENCES
Chakrabarti, S. 2003. Mining the Web: Discovering
Knowledge from Hypertext Data. s.l. : Morgan
Kaufmann, 2003.
Doan, S, Ha, S and Horiguchi, S. 2005. A Fuzzy-Based
Approach for text Representation in Text
Categorization. 14th IEEE International Conference
on Fuzzy Systems. 05 2005, pp. 1008-1013. ISBN: 0-
7803-9159-4.
Dumais, S and Landauer, T. 1997. A Solution to Plato´s
Problem: The Latent Semantic Analysis Theory of
Acquisition, Induction, and Representation of
Knowledge. Psychological Review. 1997. Vols. 104,
No.2, pp. 211-240.
Fishbein, J. 2008. Integrating Structure and Meaning
Using Holographic Reduced Representation to
Improve Automatic Text Classification. Master
Thesis. University of Waterloo : s.n., 2008.
Ganter, B, Stumme, G and Wille, R. 2005. Formal
Concept Analysis: Foudations and Applications.
Lecture Notes in Artificial Intelligence. s.l. :
Springer-Verlag, 2005. ISBN 3-540-27891-5.
Haruechaiyasak, C, Shyu, M and Chen, ML. 2002. Web
Classification Based on Fuzzy Association.
Proceedings of the 25th Annual International
Computer Software and Applications Conference
(COMPSAC´02). 2002.
Hobbs, J. 1985. Granularity. Proceeding of the Nineth
International Joint Conference on Artificial
Intelligence. 1985, pp. 423-435.
Ingersen, P, Skov, B and Larsen, B. 2008. Inter and
Intra-document Context Applied in
Polyrepresentation for Best Match IR. Information
Processing and Management: an International
Journal. 2008, Vol. 44, pp. 1673-1683.
Khalled, S. 2006. A Semantic Graph Model for Text
Representation and Matching in Document Mining.
PhD Thesis. University of Waterloo. Canadá : s.n.,
2006.
Kozima, T. 1993. Similarity Between Words Computed
by Spreading Activation on an English Dictionary.
Proceedings of the 6th Conference of the European
Chapter of the ACL. 1993, pp. 232-239.
Lin, T. 2007. Granular Computing and Modeling the
Human Thoughts in Web Documents. Lecture Notes
in Artificial Intelligence. Proceedings of the 12th
International Fuzzy Systems Association World
Congress on Foubdations of Fuzzy Logig and Soft
Computing. Cancun, Mexico : s.n., 2007. pp. 263-
270. ISBN: 978-3-540-72917-4.
Liu, G. 1994. The Semantic Vector Space Model
(SVSM): A Text Representation and Searching
Techmique System Sciences. Information Systems:
Collaboration Technology Organizational Systems
and Technology. Proceedings of the Twenty-Seventh
Hawaii International Conference. 1994, Vol. IV, pp.
928-937.
Ng, A and Jordan, M. 2001. On Spectral Clustering:
Analysis and an Algorithm. Advances in Neural
Information Processing Systems. 2001, Vol. 14.
Predycz, W. 2005. Knowledge-Based Clustering. From
Data to Information Granules. Hoboken, New
Jersey : John Wiley & Sons, 2005.
Rapp, R. 2002. The Computation of Word Associations:
Comparing Syntagmatic and Paradigmatic
Approaches. Proceedings of COLING-02. 2002.
Steyvers, M and Griffiths, T. 2007. Probabilistic Topic
Models. [book auth.] T Landauer, et al. Latent
Semantic Analysis: A Road to Meaning. s.l. :
Laurence Erlbaum, 2007.
von Luxburg, U. 2006. A tutorial on Spectral Clustering.
Technical Report 149 : Max Planck Institute for
Biological Cybernetics, 2006.
Yao, Y. 2007a. A Ten-year Review of Granular
Computing. Proceedings of IEEE International
Conference on Granular Computing. 2007a, pp.
734-739.
Yao, Y and Zhong, Y. 2002. Granular Computing using
Information Tables. [book auth.] T Y Lin, Y Yao
and L A Zadeh. Data Mining, Rough Sets and
Granular Computing. Heidelberg : Physica, 2002,
pp. 102-124.
Yao, Y. 2002. Information Retrieval Support Systems.
The 2002 IEEE World Congress on Computational
Intelligence, Honolulu, Hawai, USA. 2002, pp. 773-
778.
—. 2007. The Art of Granular Computing. LNAI 4585.
s.l. : Springer, 2007, pp. 101-102.
Zadeh, L. 1993. Fuzzy Sets. Readings in Fuzzy Sets for
Intelligent Systems. 1993.
Zhong, N, et al. 2008. Towards Granular Reasoning on
the Web. Proceedings of the 2008 Workshop on New
Forms of Reasoning for Semantic Web: Scalable,
Tolerant and Dynamic (NEFORD 2008), the 3rd
Asian Semantic Web Conference (ASWC2008).
2008.
WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies
688
