IMPROVING FLEXIBILITY OF WORKFLOW MANAGEMENT

SYSTEMS VIA A POLICY-ENHANCED COLLABORATIVE

FRAMEWORK

Alfredo Cuzzocrea

and Marco Fisichella

ICAR-CNR and University of Calabria, Cosenza, Italy

L3S Research Center, Hannover, Germany

Keywords:

Workﬂow Management Systems, Process Intelligence, Collaborative Processes.

Abstract:

Workﬂow Management Systems available to date present limitations concerning the ﬂexibility of the resulting

processes, which enlarge the gap between business processes models, humans and their activities. In real-

world scenarios, especially when collaboration among human actors takes place, it is often the case that the

tasks a process consists of appear in many subtle variants according to the actor who has to carry them out.

In this paper we focus on a system which integrates Web platform for collaborative processes, COOPER,

and a policy manager based on Semantic Web technologies, PROTUNE, can enhance process ﬂexibility and

variability to accommodate the needs of different process actors.

1 INTRODUCTION

Workﬂow Management Systems (WfMSs) support

the deﬁnition and execution of business processes by

combining atomic activities, each one characterized

by its own set of input and output resources and pa-

rameters, as well as of actors who are enrolled to carry

them out. The output of an activity is (part of) the in-

put of the activity (or activities) immediately follow-

ing it. The possibility of specifying which actor(s)

have to carry out an activity enforces coordination

among them.

WfMSs available to date present limitations con-

cerning their ﬂexibility, which enlarge the gap be-

tween business processes models, humans and their

activities (Bardram et al., 2006). In real-world sce-

narios it is often the case that the tasks a process con-

sists of appear in many subtle variants according to

the actor who has to carry them out. This is espe-

cially true in all those organizational contexts where

collaboration within teams requires people to coor-

dinate by means of “light-weight” processes that al-

low them to reach a given goal (Bardram et al., 2006;

Nodenot et al., 2004), e.g., the release of some ar-

tifacts. One can think for example to the develop-

ment of team-based projects within a company, but

also to the so-called ”learning-by-doing”, an increas-

ingly diffused form of learning through which indi-

viduals (e.g., students in university, employees in or-

ganizations in different domains, company partners

and customers, etc.) learn by working on a project

and sharing activities with others peers. In all the pre-

vious cases, processes exhibit an explosive number of

alternatives that depend on the speciﬁc needs of the

involved actors. Such alternatives may refer to the

coordination ﬂow of the different tasks, as well as to

the execution of single tasks. Flexibility might be re-

quired for example to enlarge or restrict the user ac-

cess to some services or contents, based on the users’

rights on the company information asset, their matu-

rity level in performing some activities, the evolution

of background knowledge and competencies, and so

on. Such processes therefore escape the ability of be-

ing fully modeled at design time, as it happens for

traditional business processes (Bardram et al., 2006),

and should be ﬂexible enough to be adapted to the

needs of the individual actors. At a larger vision,

ﬂexibility may also be intended as the capability of a

system to automatically discovery (and integrate) new

services/processes via intelligent methodologies (e.g.,

(Cuzzocrea et al., 2011; Cuzzocrea and Fisichella,

2011)).

In this paper we focus on a system based on poli-

cies which can be used to overcome these limitations.

According to (Sloman, 1994)’s well-known deﬁni-

tion, policies are “rules governing the choices in the

behavior of a system”, i.e., statements which describe

which decision the system must take or which actions

701

Cuzzocrea A. and Fisichella M..

IMPROVING FLEXIBILITY OF WORKFLOW MANAGEMENT SYSTEMS VIA A POLICY-ENHANCED COLLABORATIVE FRAMEWORK.

DOI: 10.5220/0003937507010708

In Proceedings of the 8th International Conference on Web Information Systems and Technologies (WEBIST-2012), pages 701-708

ISBN: 978-989-8565-08-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

it must perform according to speciﬁc circumstances.

Policy languages are special-purpose programming

languages which allow to specify policies, whereas

policy engines are software components able to en-

force policies expressed in some policy language.

Process engines and policy engines can be consid-

ered to be complementary tools to enhance process

ﬂexibility: process engines allow one to deﬁne and

execute processes, but they fall short whenever pro-

cess modiﬁcations have to occur during the execution

of the process (Fisichella et al., 2011). On the other

hand, being based on decision making, it appears nat-

ural combining policy and process engines in order to

overcome the limitations mentioned above. Policies

could be for example exploited within a process task

in order to adapt it to the end-users’ speciﬁc needs and

access rights (intra-activity policies). On the other

hand, policies could be exploited at the level of the

overall process in order to determine the activity/ies

to be next performed based on the outcome of the pre-

ceding activity/ies (inter-activity policies).

This paper focus on a system leveraging on both

approaches applied to COOPER (Ceri et al., 2009),

a Web platform for the deﬁnition and execution of

collaborative processes, characterized by a reference

model that ensures process ﬂexibility, effectively sup-

porting the dynamic, user-based management of col-

laboration processes. We in particular investigate

the exploitation of PROTUNE (Coi and Olmedilla,

2008) for the speciﬁcation and management of poli-

cies. PROTUNE is a policy framework based on Se-

mantic Web technologies, that supports the creation

and enforcement of advanced policies, covering not

only traditional access control but also trust negotia-

tion (to automate for example privacy-aware informa-

tion release), and second generation explanation facil-

ities (to improve user awareness about – and control

on – policies).

2 THE PROTUNE POLICY

FRAMEWORK

Policies are encountered in many situations of our

daily life. Especially with the advent of the digi-

tal era, the speciﬁcation of policies has emerged in

many web-related contexts and software systems. E-

mail client ﬁlters are a typical example of policies.

Some of the main application areas where policies

have been lately used are security and privacy as well

as speciﬁc business domains, where they take on the

name of “business rules” (but (Li et al., 2006), (Li

and Wang, 2006) and (Stoller et al., 2007) for other

policies’ application areas). In general, policies are a

well-known approach to protecting security and pri-

vacy of users in the context of the Semantic Web:

policies specify who is allowed to perform which ac-

tion on which object depending on properties of the

requester and of the object as well as parameters of

the action and environmental factors (e.g., time). The

application of suitable policies for protecting services

and sensitive data may determine success or failure of

a new service.

The use of formal policies yields many advantages

compared to conventional approaches: formal poli-

cies are usually dynamic, declarative, have a well-

deﬁned semantics and allow to be reasoned over

(Lloyd, 1987) and (Sloman, 1994). PROTUNE is a

framework for specifying and cooperatively enforcing

security and privacy policies on the Semantic Web.

PROTUNE is based on Datalog and, as such, it is an

LP-based policy language (Coi and Olmedilla, 2008).

A PROTUNE program is basically a set of normal

logic program rules (Lloyd, 1987) A ← L

, . . . , L

where n ≥ 0, A is an atom (called the head of the rule)

and L

, . . . , L

(the body of the rule) are literals, i.e.,

∀i : 0 ≤ i ≤ n L

equals either A

or ∼ A

for some atom

. Rules whose body is empty are called facts.

Given an atom p(t

, . . . , t

) where a ≥ 0, p and a

are called the name and the arity respectively of the

predicate exploited in the atom, whereas t

, . . . , t

are

terms, i.e., either constants or variables.

With respect to Datalog, PROTUNE presents

the following main differences: (i) policy language

– PROTUNE is a policy language and not a lan-

guage for data retrieval; (ii) actions – the evalua-

tion of a literal might require to perform actions;

(iii) objects PROTUNE supports objects, i.e., sets of

(attribute, value) pairs linked to an identiﬁer.

Being PROTUNE a policy language, its applica-

tion scenarios are essentially different than the ones of

Datalog, which is a language for data retrieval: whilst

a Datalog query is meant to retrieve (explicit or im-

plicit) information from a knowledge base, the typical

PROTUNE query is a request by a human or software

agent to access some resource or service. Moreover,

whoever issues a Datalog query is automatically al-

lowed to retrieve the requested information, whereas

in general not everyone issuing a PROTUNE query

is allowed to access the requested resource or service.

For this reason, whilst the process of evaluating a Dat-

alog query is single-step, the process of evaluating a

PROTUNE query involves up to two steps: checking

whether the query can be evaluated and, if this is the

case, actually evaluating it.

The evaluation of a Datalog (and, more generally,

of a Prolog) literal is based on SLDNF-Resolution

(Lloyd, 1987): the evaluation of a negative literal (i.e.,

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

702

of a literal of the form not A, where A is an atom) is

(un)successful if it is (not) the case that the evalua-

tion of the body of all rules whose head matches A

is unsuccessful. The evaluation of a positive literal

(i.e., of a literal of the form A, where A is an atom) is

(un)successful if it is (not) the case that the evaluation

of the body of some rule whose head matches A is suc-

cessful. Only PROTUNE logical literals are evaluated

in such a way, whereas the evaluation of PROTUNE

provisional literals requires to perform an action: the

evaluation of a positive (resp. negative) provisional

literal is successful if the execution of such action is

(resp. is not) successful. The PROTUNE engine uni-

vocally identiﬁes the action to be performed based on

the predicate exploited in the literal. The name and

arity of the predicate are interpreted as an URL point-

ing to a software component (a jar ﬁle). By need

such component is automatically resolved, deployed

and ﬁnally exploited to actually perform the action.

Beside minor things (PROTUNE constants can be

booleans and numbers as well) the biggest difference

between Datalog and PROTUNE with respect to the

built-in data types is that PROTUNE supports objects,

i.e., sets of (attribute, value) pairs linked to an iden-

tiﬁer. Attributes and values can be objects in turn and

attributes can be multi-valued. Objects are referred

to by their identiﬁers, whereas a generic value of the

attribute attr of an object id is denoted by id.attr, ac-

cording to the well-known Java-like dot notation. Fi-

nally, a value val can be deﬁned for the attribute attr

of an object id by asserting the fact id.attr = val.

We conclude by brieﬂy mentioning further fea-

tures of PROTUNE, namely the distributed query

evaluation process and the explanation facility. In

Datalog the evaluation of a query and, more generally,

of a literal is a local process: only the local knowledge

base (i.e., the Datalog program) is inspected in order

to retrieve the requested information. On the contrary,

the author of a PROTUNE policy can state that some

literal has to be evaluated by the requester: if dur-

ing the evaluation of a query Q

issued by a requester

it happens that such literal has to be evaluated, a

counter-query Q

is issued to R

with the request to

evaluate it. Counter-queries can nest to an arbitrary

depth, so that the evaluation of a PROTUNE query

can evolve to a negotiation between the actors in-

volved. In order to make explicit that a literal has to be

evaluated by the requester, the policy author must tag

that literal with an annotation which in PROTUNE’s

jargon is called metarule.

Metarules are also used to support PROTUNE’s

explanation facility: explanation metarules deﬁne

verbalization patterns which are instantiated by the

explanation facility to produce a human-readable de-

scription of the policy. Such description is then ex-

ploited to answer a predeﬁned set of user queries.

So far four kinds of queries are supported: How-to

queries describe which activities the requester has to

carry out in order to get access to a given resource or

service. What-if queries are meant to help requesters

to foresee the evolution of a hypothetical situation. Fi-

nally, Why and Why-not queries merge the description

of the policy with transaction-dependent information

in order to explain the outcome of a transaction which

already occurred.

3 THE COOPER PLATFORM

This Section introduces COOPER, the engine we

chose to use for process deﬁnition and execution. The

choice of COOPER is due to the ﬂexibility that it

is able to support at process level, which is possible

thanks to the easy integration of ”externally” deﬁned

process tasks. The most salient feature of COOPER

is that it allows cooperating team members (i.e., the

platform end-users) to dynamically deﬁne collabora-

tive processes, and easily modify planned processes,

to cope with the evolution of individuals as well as

of the whole team. Giving the end-users the possibil-

ity to deﬁne and modify their processes requires the

system to offer easy-to-use deﬁnition interfaces, able

to guide people in the composition of processes with-

out requiring any speciﬁc knowledge and expertise on

process design. Guiding inexperienced users requires

that the system be “aware” of the semantics of the do-

main where processes must be executed. Such aware-

ness can be achieved through libraries of pre-deﬁned

activity types, able to reﬂect and support the possible

tasks that users might need to coordinate and execute

in a given context.

Activity types represent the deﬁnition of process

tasks, that are regularly performed by users to col-

laborate, and that can be used within collaborative

processes. Their deﬁnition implies associating the

underlying task with a hypertext front-end, which is

used as user interface for the execution of the activ-

ity. Some atomic activities have a general nature (e.g.,

those related to the management of documents), and

can therefore be adopted in several domains where

collaborative processes are required. Some other ac-

tivities may however be particular for speciﬁc con-

texts and their identiﬁcation requires an investigation

of the addressed domain. Starting from a library of

activity types, the system thus guides the composition

of sound, “well-structured” processes (Kiepuszewski

et al., 2000). In (Ceri et al., 2009) we show how the

offered mechanisms for process deﬁnition guarantee

IMPROVINGFLEXIBILITYOFWORKFLOWMANAGEMENTSYSTEMSVIAAPOLICY-ENHANCED

COLLABORATIVEFRAMEWORK

703

the semantically correct execution and termination of

process instances, and the possibility to easily (ﬂexi-

bly) modify processes even during runtime. Providing

guarantees on the process semantics aims at assisting

the continuous re-deﬁnition or evolution of running

processes by users that in most cases are inexperi-

enced.

Figure 1 shows the architecture of the COOPER

platform, where different modules interoperate and

make use of data and metadata. Process deﬁnition is

performed via a process editor, a Web front-end that

makes use of a predeﬁned activity type library and,

possibly, of existing process/template models. Pro-

cess execution is performed via the COOPER’s col-

laboration environment, which leverages on the hy-

pertext front-ends of the predeﬁned activity types to

allow users to produce and consume process data in

form of resources stored in the resource repository.

Process advancement is then governed by the stored

process deﬁnitions, which are interpreted during pro-

cess execution by a dedicated process engine that con-

tains the necessary application logic to maintain the

running processes’ metadata and, hence, to drive the

activity ﬂow in the collaboration environment.

The COOPER approach overlaps the ideas of pro-

cess model and process instance: each process deﬁni-

tion has only one executing instance or, the other way

around, each process execution has its own process

deﬁnition. A process deﬁnition bears all metadata

(process structure, role assignments, resource assign-

ments) and runtime data (state of the process, states

of activities, execution time stamps) necessary for the

correct execution. This allow us to support process

modiﬁcation operations.

Figure 1 also highlights the competences of the in-

dividual actors in the COOPER platform. The activity

designer identiﬁes and designs the activity types that

are available in the platform. The process designer

then instantiate the activities types and deﬁnes pro-

cess templates. The process designer can also be a

team leader who wants to organize the wok of his/her

team. The users then perform the actual work. Users

can also play the role of process designers. They are

indeed enabled to deﬁne new processes by extending

templates, or by composing new models from scratch.

They are in any case allowed to modify template-

based process deﬁnitions during runtime, after the

process has been launched, with the only limit of not

violating the template constraints that the process may

hold by deﬁnition.

Based on this architecture, COOPER can be ex-

tended by delegating external modules (from now on

handlers) to process given activities. Each handler

is responsible for activities of a given type. Policies

with the same type have the same input/output pa-

rameters. As soon as COOPER starts processing a

new activity, it checks its type and, if some handler is

available for activities of that type, it hands the activ-

ity over to such handler. Input parameters and con-

text information (like the current user) are provided

by COOPER to the handler and return parameters are

provided back from the handler to COOPER. To some

extent, control on the workﬂow itself can be delegated

to handlers, since they can provide COOPER with the

activities to be started after they return.

Such extension point (Birsan, 2005) of COOPER

will be exploited for the approaches presented in Sec-

tion 5 and Section 6.

Figure 1: The architecture of the COOPER platform (Ceri

et al., 2009).

4 APPLICATION SCENARIOS

To better understand our approach, we will consider

two simple scenarios that require the collaboration of

multiple actors.

4.1 Scenario I

Imagine a team leader wants to suggest to team com-

ponents some events e.g., conferences to attend. Team

components select one conference and search for a

hotel in the event location. Later, they ask the orga-

nization treasurer for the monetary availability. The

process is composed by three activities: (i) an activ-

ity is related to the team leader who has to suggest a

listing of conferences to attend; (ii) an activity associ-

ated to the employee, who must select the conference

and book a hotel; and (iii) an activity associated to

the treasurer, who has to check the cash and allocate,

if available, the amount request. The treasurer will

conclude the activity with a conﬁrmation or negation

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

704

Figure 2: Example of Mashup encapsulated within the pro-

cess ﬂow according to the deﬁnition of an activity supported

by four components.

message sent to the employee.

Suppose that the deﬁnition of this process requires

the inclusion of an activity for the process of booking

the hotel and that such activity can be supported by

four components as shown in Figure 2. We suppose

these four components are already registered in the

platform: the service “Find a Conference” supplying

the list of the conferences indexed by DBWorld, the

service “Hotel Retrieve” supplying a list of hotels for

a given place of interest, the Flickr.NET component to

display the images for a given hotel, and Google Maps

to show the directions to a given address or point of

interest. When the team leader selects a conference

from the conference listing component, the hotel list-

ing will be updated and will display all the hotels in

that area, the image displayer will show an image of

the selected hotel while the map will display its loca-

tion. In other words, the way the employees’ activity

is performed depends on the outcome of the ﬁrst one

(namely, which conference the team leader opted for).

In such a scenario, policies can help to adapt the ﬁrst

activity to the end user’s need or right, e.g. some team

leader could select only conferences which will be or-

ganized in places within the same continent or below

a kilometric distance threshold from his/her own com-

pany location.

4.2 Scenario II

Imagine a team working in a business project that re-

quires the involvement of professionals from differ-

ent ﬁelds. A ﬁrst version project proposal must be ap-

proved by the team leader at certain point of time. Af-

ter that, there must be: (i) a proper description of the

necessary technical work; (ii) a description of the ma-

terial and people involved; (iii) a description of costs;

and (iv) a description of the marketing planning. After

these activities, a new activity is assigned to the team

leader to review all the documentation to continue the

project development.

Suppose that the deﬁnition of the activity is a

mashup utilizing Google Docs API

, allowing doc-

ument editing and versioning control. The same ac-

tivity can be reused for the four activities previously

listed if the necessary actions are the same; however

each activity refers to a very speciﬁc group of team

members. So it is up to the team leader to approve the

proposal in the ﬁrst instance. Afterwards the process

will split into four different parallel sub-processes.

Continuing in each activity, developers would doc-

ument the technical issues, technicians and personal

would describe the necessary material and people,

treasurer would calculate the ﬁnances and the market-

ing members would describe market strategies. Once

each team has ﬁnished each respective assignment,

the workﬂow joints back together to an approval ac-

tivity for the team leader. Notice that whether the four

parallel activities are performed depends on the out-

come of the ﬁrst one (namely, whether the team leader

approved the proposal).

5 INTER-ACTIVITY POLICIES

As we argued in Section 4, in many real-world work-

ﬂows it is often the case that: (i) the way an activ-

ity is performed and (ii) whether an activity is at all

performed depends on the outcome of the activity/ies

previously performed. Furthermore, the possibility to

select which next activity will be executed based on

some conditions or output from previous activity/ies

has been previously solved by other process engine,

but in this Section we concentrate our treatment about

how to solve this problem exploiting the policies, such

that we demonstrate to provide a complete process en-

gine based on policies.

The exchange of input parameters and return val-

ues described in Section 3 is a suitable mechanism

provided by COOPER to determine the way an ac-

tivity has to be performed based on the outcome

of the one(s) previously performed: with respect to

the scenario described in Section 4.1, the activity of

the employees could be modeled as a parameterized

COOPER activity whose execution depends on the

value of a parameter which is meant to represent the

list of conferences to attend. The instantiation of this

parameter could be provided by the COOPER activity

modeling the team leader’s activity.

On the other hand, as we mentioned in Sec-

tion 1, COOPER does not natively provide any

means to identify whether an activity should be per-

formed based on the outcome of the activity/ies pre-

http://code.google.com/apis/documents/overview.html

IMPROVINGFLEXIBILITYOFWORKFLOWMANAGEMENTSYSTEMSVIAAPOLICY-ENHANCED

COLLABORATIVEFRAMEWORK

705

Figure 3: Extension of COOPER by means of inter-activity

policies.

viously performed. For this reason we decided to

exploit COOPER’s extension mechanism described

in Section refsec:cooper in order to add branches to

COOPER workﬂows: we deﬁned a new activity type

(namely, branch activity) and an handler for them

(namely, branch-activity handler or BA-handler).

Fig. 3 shows how a generic branch activity is pro-

cessed by COOPER extended with our BA-handler.

According to COOPER’s generic extension mecha-

nism (see Section 3), as soon as a branch activity

comes in (1), it is redirected to the BA-handler, to-

gether with input parameters and context informa-

tion (2). The BA-handler acts as a mediator and for-

wards such information to the PROTUNE engine (3).

The PROTUNE Engine uses (among else) such infor-

mation in order to answer the BA-handler’s question

about the upcoming activity (4), which is eventually

forwarded back to COOPER (5).

A generic inter-activity policy is a set of rules like

the following.

allow(getNextActivity(Activity)) ←

conditions()

Against query getNextActivity(Activity) issued by

the BA-handler, the PROTUNE engine instantiates

the variable Activity with the identiﬁer of the activ-

ity to be performed next. Conditions have to be ful-

ﬁlled in order for the given instantiation to take place.

As described in Section 2, the PROTUNE policy lan-

guage allows to deﬁne expressive condition involving,

among else, properties of the current user, activity and

environmental properties (e.g., time).

6 INTRA-ACTIVITY POLICIES

As we argued in Section 1 and Section 4, in real-world

scenarios it is often the case that the atomic activities a

business process consists of differ according to the ac-

tor who has to carry them out. Therefore it is needed:

(i) providing workﬂow designers with the ability to

specify variants in the deﬁnition of an activity; and

(ii) enforcing at run-time the right variant according

to the actor who is carrying it out.

A trivial solution would be adopting the approach

we discussed in Section 5 to this case as well: each

variant of an activity could be modeled as an activity

itself and we could identify the right variant at run-

time by resorting to inter-activity policies. Although

this solution is in principle feasible, it has at least a

couple of drawbacks: it is unnatural and (hence) user-

unfriendly.

For this reason it makes sense trying to identify

a different mechanism to specify and enforce ﬁne-

grained activity tuning. We chose to use the Mash-Up

technology.

A mashup combines services coming from hetero-

geneous sources not initially conceived to coexist to-

gether. Especially if supported by an easy-to-use de-

velopment tool, the mashup paradigm can favor the

on-the-ﬂy construction of applications that quickly al-

low users to have insights and make decisions based

on the resulting combined data. Within the COOPER

framework, mashups can certainly facilitate the def-

inition and integration of new activity types by ac-

tivity designers. However, the most tangible advan-

tage is that they can enable process designers to cre-

ate on-the-ﬂy new activity types during process deﬁ-

nition, as well as process actors to easily customize

already deﬁned activities during process execution.

As explained in the following, after its deﬁnition, the

mashup can be integrated as an activity in a process.

A process will be able to incorporate one or more

mashups, even different versions of a same mashup.

To achieve the goal of integrating mashups within

process deﬁnition, we extend the activity type library,

as deﬁned in COOPER, with a new type, the container

activity (CA), based on two main concepts: (1) as

any other activity type, it exposes some properties that

are required for its integration within a process (e.g.,

start and end time, enrolled process actors, etc.), and

that must be set during process deﬁnition; (2) it is a

generic container, aimed at encapsulating externally

deﬁned web resources.

Moreover, a CA can be associated with several

mashups, even different versions of a same mashup,

each of them associated with a particular policy to be

satisﬁed. While deﬁning a process, one or more CAs

can be used when the ready-to-use activity types do

not match the requirements of some user activities.

The process designer can then deﬁne a new service

in a mashup wise (see next) and encapsulate it within

the container. To enable the integration of this new

service within the process ﬂow, s/he can character-

ize the output resource to be produced. Leveraging

the template-based paradigm and the ﬂexibility of

COOPER, the encapsulation of the actual application

supporting the activity execution can even be delayed

at run-time: the process designer just conﬁgures the

container properties that are necessary for process en-

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

706

Figure 4: Extension of COOPER by means of intra-activity

policies.

actment, e.g., the enrolled user, the resources to be

produced as activity output, and so on. The actual

mashup for the activity execution can be deﬁned and

encapsulated during the process execution by the en-

rolled actor.

Fig. 4 shows how a generic container activity

is processed by COOPER extended with our CA-

handler. According to COOPER’s generic extension

mechanism (see Section 3), as soon as a container ac-

tivity comes in (1), it is redirected to the CA-handler,

together with input parameters and context informa-

tion (2). The CA-handler forwards such information

to the PROTUNE engine (3). The PROTUNE Engine

uses (among else) such information in order to an-

swer the CA-handler’s question about which mash-

up should be used (4). Differently than the BA-

handler described in Section 5, the CA-handler does

not limit itself to forwarding such information back

to COOPER, but is responsible for: (i) retrieving the

mash-up based on the information provided by the

PROTUNE engine; (ii) coordinating the interaction

of such mash-up with the user; and in particular (iii)

identifying when the user completed the mash-up ac-

tivity (5). At this point the control is returned to

COOPER (6).

A generic intra-activity policy is a set of rules like

the following.

allow(getMashUp(MashUp)) ←

conditions()

Against query getMashU p(MashU p) issued by the

CA-handler, the PROTUNE engine instantiates the

variable MashU p with the identiﬁer of the mash-up

to be provided to the user. Again, Conditions have to

be fulﬁlled in order for the given instantiation to take

place.

7 CONCLUSIONS

In this paper, we have presented an integrated frame-

work where the deﬁnition of collaborative processes

is augmented through policies aimed at enhancing

process ﬂexibility to enlarge or restrict the user ac-

cess to services or contents. Collaborative processes

are highly characterized by the need of adapting the

process ﬂow and the execution of single tasks to

the variability of the needs, access rights and back-

ground of the involved actors. To respond to this

need, the COOPER platform has been speciﬁcally

conceived to empower end-users to self-deﬁne and

modify processes through an easy-to-use Web envi-

ronment. However, COOPER still shows some lim-

its, especially related to the customization of task in-

stances targeting individual process actors. This paper

has shown how such limits can be overcome thanks to

the adoption of the PROTUNE policy manager, still

ensuring the full interoperability with COOPER as to

easy the global integration task.

An initial prototype has allowed us to prove the

feasibility of the concepts illustrated in this paper.

Our future work is devoted to fully implementing the

integration, and to testing its effectiveness and efﬁ-

ciency. This activity will also imply the deﬁnition

of a library of pre-deﬁned and reusable policies, ex-

pressing frequent rules for adaptation and/or access

restriction, as well as of policy-enhanced process tem-

plates covering the most frequent collaboration re-

quirements.

ACKNOWLEDGEMENTS

This research has been co-funded by the Euro-

pean Commission within the eContentplus targeted

project OpenScout, grant ECP 2008 EDU 428016

(http://www.openscout.net).

REFERENCES

Bardram, J. E., Bunde-Pedersen, J., and Søgaard, M.

(2006). Support for activity-based computing in a per-

sonal computing operating system. In Grinter, R. E.,

Rodden, T., Aoki, P. M., Cutrell, E., Jeffries, R., and

Olson, G. M., editors, CHI, pages 211–220. ACM.

Birsan, D. (2005). On plug-ins and extensible architectures.

ACM Queue, 3(2):40–46.

Ceri, S., Daniel, F., Matera, M., and Rafﬁo, A. (2009).

Providing ﬂexible process support to project-centered

learning. IEEE Trans. Knowl. Data Eng., 21(6):894–

909.

Coi, J. L. D. and Olmedilla, D. (2008). A review of trust

management, security and privacy policy languages.

In SECRYPT, pages 483–490.

Cuzzocrea, A., De Coi, J.L., Fisichella, M., and Matera, M.

(2011). Graph-based matching of composite OWL-S

services. In DASFAA Workshops, pages 28–39.

IMPROVINGFLEXIBILITYOFWORKFLOWMANAGEMENTSYSTEMSVIAAPOLICY-ENHANCED

COLLABORATIVEFRAMEWORK

707

Cuzzocrea, A. and Fisichella, M. (2011). Discover-

ing semantic Web services via advanced graph-based

matching. In IEEE SMC, pages 608–615.

Fisichella, M. and Matera, M. (2011). Process ﬂexibility

through customizable activities: A mashup-based ap-

proach. In ICDE Workshops, pages 226–231.

Kiepuszewski, B., ter Hofstede, A. H. M., and Bussler, C.

(2000). On structured workﬂow modelling. In Wan-

gler, B. and Bergman, L., editors, CAiSE, volume

1789 of Lecture Notes in Computer Science, pages

431–445. Springer.

Li, N., Tripunitara, M. V., and Wang, Q. (2006). Resiliency

policies in access control. In ACM Conference on

Computer and Communications Security, pages 113–

123.

Li, N. and Wang, Q. (2006). Beyond separation of duty: an

algebra for specifying high-level security policies. In

ACM Conference on Computer and Communications

Security, pages 356–369.

Lloyd, J. W. (1987). Foundations of Logic Programming,

2nd Edition. Springer.

Nodenot, T., Marquesuza

a, C., Laforcade, P., and Sal-

laberry, C. (2004). Model based engineering of learn-

ing situations for adaptive web based educational sys-

tems. In Feldman, S. I., Uretsky, M., Najork, M., and

Wills, C. E., editors, WWW (Alternate Track Papers &

Posters), pages 94–103. ACM.

Sloman, M. (1994). Policy driven management for dis-

tributed systems. J. Network Syst. Manage., 2(4).

Stoller, S. D., Yang, P., Ramakrishnan, C. R., and Gofman,

M. I. (2007). Efﬁcient policy analysis for administra-

tive role based access control. In ACM Conference on

Computer and Communications Security, pages 445–

455.

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

708
