Improved “Partial Sums”-based Square Attack on AES

Michael Tunstall

Department of Computer Science, University of Bristol, Merchant Venturers Building, Woodland Road, Bristol, U.K.

Keywords:

Cryptanalysis, Square Attack, Advanced Encryption Standard.

Abstract:

The Square attack as a means of attacking reduced round variants of AES was described in the initial descrip-

tion of the Rijndael block cipher. This attack can be applied to AES, with a relatively small number of chosen

plaintext-ciphertext pairs, reduced to less than six rounds in the case of AES-128 and seven rounds otherwise

and several extensions to this attack have been described in the literature. In this paper we describe new vari-

ants of these attacks that have a smaller time complexity than those present in the literature. Speciﬁcally, we

demonstrate that the quantity of chosen plaintext-ciphertext pairs can be halved producing the same reduction

in the time complexity. We also demonstrate that the time complexity can be halved again for attacks applied

to AES-128 and reduced by a smaller factor for attacks applied to AES-192. This is achieved by eliminating

hypotheses on-the-ﬂy when bytes in consecutive subkeys are related because of the key schedule.

1 INTRODUCTION

The Advanced Encryption Standard (AES) (FIPS

PUB 197, 2001) was standardized in 2001 from a

proposal by Daemen and Rijmen (Daemen and Rij-

men, 1998). It has since been analyzed with regard

to numerous attacks ranging from purely theoretical

cryptanalysis to attacks that require some extra infor-

mation, e.g from some side channel (Mangard et al.,

2007), to succeed.

In Daemen and Rijmen’s AES proposal an at-

tack is described that is referred to as the Square at-

tack (Daemen and Rijmen, 1998). This attack was

so-called since it was ﬁrst presented in the descrip-

tion of the block cipher Square (Daemen et al., 1997).

The Square attack is based on a particular property

arising from the structure of AES. That is, for a set of

256 plaintexts where each byte at an arbitrary index is

a distinct value and all the other bytes are equal, the

XOR sum of the 256 intermediate states after three

rounds of AES will be zero.

Some optimizations to this attack have been pro-

posed in the literature. Ferguson et al. proposed a

way of conducting the Square attack referred to as the

“partial sums” method (Ferguson et al., 2001). This

allowed the Square attack to be conducted with a rel-

atively low time complexity for reduced round vari-

ants of AES. The time complexity of these attacks

was further reduced following an observation made

by Lucks. He noted that given a known last subkey in

AES-192 then information on previous subkeys can

be derived.

Recent cryptanalytical attacks have predomi-

nantly been focused on other properties, such as im-

possible differentials (Bahrak and Aref, 2008; Lu

et al., 2008; Zhang et al., 2007). The use of impos-

sible differentials is related to the Square attack but

allows an attacker to overcome variants of AES with

more rounds. Recently, a marginal attack on AES

has also been proposed that is based on the use of

bicliques (Bogdanov et al., 2011). However, for suit-

ably reduced round variants of AES the “partial sums”

method proposed by Ferguson et al. is currently the

most efﬁcient chosen plaintext attack.

In this paper we describe how the attacks pro-

posed by Ferguson et al. and Lucks can be im-

proved. Speciﬁcally, we show that the number of cho-

sen plaintext-ciphertext pairs required to conduct the

Square attack can be halved and therefore halve the

time complexity of the attack. Moreover, we demon-

strate that the time complexity of the Square attack

can be halved again when applied to AES-128, and

reduced to a lesser extent for AES-192, by exploiting

relationships between key bytes as they are derived.

In this paper we restrict ourselves to attacks that re-

quire a relatively small number of chosen plaintext-

ciphertext pairs. The attacks proposed by Ferguson

et al., based on the Square attack, that require around

2

128

chosen plaintext-ciphertext pairs are beyond the

cope of this paper (Ferguson et al., 2001).

25

Tunstall M..

Improved “Partial Sums”-based Square Attack on AES.

DOI: 10.5220/0003990300250034

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 25-34

ISBN: 978-989-8565-24-2

Copyright

c

2012 SCITEPRESS (Science and Technology Publications, Lda.)

This paper is organized as follows. In Section 2 we

deﬁne the notation we use to describe AES. In Sec-

tion 3 we describe the property that the Square attack

is based on. In Section 4 we describe how the Square

attack can be applied to AES-128, and in Section 5

we describe how the Square can be applied to AES-

192 and AES-256. We summarize our contribution

and conclude in Section 6.

2 PRELIMINARIES

In this paper, multiplications in F

2

8

are considered to

be polynomial multiplications modulo the irreducible

polynomial x

8

+ x

4

+ x

3

+ x + 1. It should be clear

from the context when a mathematical expression

contains integer multiplication.

2.1 The Advanced Encryption Standard

Algorithm 1: The AES encryption function.

Input: The 128-bit plaintext block P and 128,

192 or 256-bit secret key K, with N set

to 10, 12, 14 respectively.

Output: The 128-bit ciphertext block C.

X ←

AddRoundKey

(P,K) ;

for i ← 1 to N do

X ←

SubBytes

(X) ;

X ←

ShiftRows

(X) ;

if i 6= N then

X ←

MixColumns

(X) ;

end

X ←

AddRoundKey

(X,K) ;

end

C ← X ;

return C

The structure of the Advanced Encryption Standard

(AES) , as used to perform encryption, is illustrated

in Algorithm 1. In discussing the AES we consider

that all intermediate variables of the encryption op-

eration variables are arranged in a 4 × 4 array of

bytes, referred to as the state matrix. For example,

the 128-bit plaintext P = (p

1

, p

2

,..., p

16

), where each

p

i

∈ {1,...,16} is one byte, is arranged in the follow-

ing fashion

p

1

p

5

p

9

p

13

p

2

p

6

p

10

p

14

p

3

p

7

p

11

p

15

p

4

p

8

p

12

p

16

.

The encryption itself is conducted by the repeated use

of a round function that comprises the following op-

erations executed in sequence:

The

AddRoundKey

operation XORs each byte of

the array with a byte from a corresponding subkey.

In each instance of the

AddRoundKey

a fresh 16-byte

subkey is used from the subkey bytes generated by the

key schedule. We describe how this is done in more

detail for the different variants of AES in Section 2.2.

The

SubBytes

operation is the only nonlinear step

of the block cipher, consisting of a substitution table

applied to each byte of the state. This replaces each

byte of the state matrix by its multiplicative inverse,

followed by an afﬁne mapping. In the remainder of

this paper we will refer to the function S as this sub-

stitution table and S

−1

as its inverse.

The

ShiftRows

operation is a byte-wise permuta-

tion of the state that operates on each row.

The

MixColumns

operation operates on the state col-

umn by column. Each column of the state matrix is

considered as a vector where each of its four elements

belong to F

2

8

. A 4×4 matrix M whose elements are

also in F

2

8

is used to map this column into a new vec-

tor. This operation is applied to the four columns of

the state matrix. Here M and its inverse M

−1

are de-

ﬁned as

M =

2 3 1 1

1 2 3 1

1 1 2 3

3 1 1 2

andM

−1

=

14 11 13 9

9 14 11 13

13 9 14 11

11 13 9 14

All the elements in M and M

−1

are elements of F

2

8

expressed in decimal.

In Algorithm 1 we can see that the last round

does not include the execution of a

MixColumns

op-

eration. In all the attacks considered in this pa-

per we will assume that the last round does not in-

clude a

MixColumns

operation. This is important to

note since it has been shown that the presence of a

MixColumns

operation in the last round would affect

the security of AES (Dunkelman and Keller, 2010).

2.2 The Key Schedule

The key schedule generates a series of subkeys from

the secret key. There are three variants of the AES

corresponding to the three possible bit lengths of the

secret key used, i.e. 128, 192 or 256 bits. In Algo-

rithm 2 we show how the subkey bytes are generated

from an initial secret key K. The function S is the sub-

stitution function used in the

SubBytes

operation de-

scribed above. The function f is, for the most part, the

identity function. However, when K is a 256-bit key

and j = 4 then f is the substitution function S. RCON

is a round constant that changes for each loop. We

refer the reader to the AES speciﬁcation for a more

detailed description of the key schedule (FIPS PUB

197, 2001).

SECRYPT2012-InternationalConferenceonSecurityandCryptography

26

Algorithm 2: The AES key schedule function.

Input: X-bit secret key K, with X set to 128,

192 or 256 and N set to 10, 12, 14

respectively, RCON.

Output: W a stream of subkey bytes.

for i ← 0 to X/8− 1 do W[i] ← K[i] ;

for i ← 1 to ⌈(N + 1) · (X/128)

2

⌉ do

for j ← 0 to 3 do

W[i· X + j] ← S(W[i· (X − 1) + j]) ;

end

W[i· X] ← W[i· X] ⊕ RCON ;

for j ← 1 to 3 do

for k ← 0 to X/4 do

W[i·X + 4 j+k] ← W[i(X −1)+4 j

+k] ⊕ f(W[i· X + 4( j − 1) + k]);

end

end

end

return W

For AES-128, knowing one subkey will allow the

original key to be derived. For AES-192 and AES-

256 there will still be some ambiguity and two sub-

keys are required to derive the original key.

3 THE SQUARE ATTACK

If we consider two plaintexts that have a XOR dif-

ference that is non-zero in one byte, then this differ-

ence will expand in a known manner. After one round

the XOR difference between the intermediate states

would show that one column of the state matrix has

a non-zero difference. This property will then propa-

gate to all the bytes in the state matrix after the second

round by the same reasoning. An example where the

difference in two plaintexts is at index one is shown

in Figure 1.

It is therefore impossible that the XOR difference

between two such plaintexts will be zero in any byte

after two rounds. This property will persist until the

next

MixColumns

operation, and is used for impos-

sible differential cryptanalysis since the XOR differ-

ence after two rounds cannot be zero (Biham and

Keller, 1999).

This property is also used to construct an attack

referred to as the Square attack (so-called since it was

ﬁrst presented in the description of the block cipher

Square (Daemen et al., 1997)) and was ﬁrst presented

in the original description of AES (Daemen and Rij-

men, 1998). We consider 256 distinct plaintexts that

are equal in ﬁfteen bytes. After computing two rounds

of AES the property described above will be valid be-

tween all possible pairs, i.e. across all 256 intermedi-

ate states the bytes at each index will contain one of

each possible value. The XOR sum of the 256 bytes at

each index will therefore be equal to zero. There will

not be one instance of each possible value across the

256 bytes at each index after the next

MixColumns

operation. However, the XOR sum of the bytes at

each index will still be zero after the

MixColumns

op-

eration, and this property will remain true until the

next

SubBytes

operation. In the remainder of this

paper we will refer to a set of 256 chosen plaintext-

ciphertext pairs where the 256 distinct plaintexts that

are equal in ﬁfteen bytes as a δ-set.

4 APPLYING THE SQUARE

ATTACK TO AES-128

Attacks based on the Square attack applicable to

AES-128 are presented in this section.

4.1 Analyzing Four-round AES

An attack based on the property described in Sec-

tion 3 was originally detailed by Daemen and Rijmen

in their AES proposal (Daemen and Rijmen, 1998).

If we consider one δ-set, the XOR sum of the inter-

mediate states at the end of the third round is equal

to zero. For a four-round variant of AES an attacker

can use this observation to validate hypotheses on the

last subkey byte-by-byte, where an attacker checks

that the XOR sum of the input to the ﬁnal round is

equal to zero. For each byte this will return the cor-

rect subkey byte and one additional incorrect hypoth-

esis per byte with a probability of 255/256. That is,

any random sequence of byte will have an XOR sum

equal to zero with a probability of 1/256 and there

are 255 such sequences. This will result in an ex-

pected total number of key hypotheses for the last

subkey of

1+

255

256

16

≈ 2

16

, since the length of the

lists of hypotheses are mutually independent. One

can determine the key if one repeats the analysis, i.e.

one takes 2

9

chosen plaintexts and conducts the above

analysis twice. This would have a time complexity of

2

9

one-round decryptions (2

7

encryptions of a four-

round AES).

Biham and Keller observed the sum of a sequence

of random bytes can be computed by only consider-

ing one example of values that occur with an odd-

numbered frequency. Since values that occur with

Improved"PartialSums"-basedSquareAttackonAES

27

Plaintext

ζ 0 0 0

0 0 0 0

0 0 0 0

0 0 0 0

→

First Round

2

θ 0 0 0

3

θ 0 0 0

θ 0 0 0

θ 0 0 0

→

Second Round

2

α β γ

3

δ

3

α

2

β γ δ

α

3

β

2

γ δ

α β

3

γ

2

δ

Figure 1: Propagation of a one-byte difference across two rounds of AES. A structure in this difference is imposed by the

MixColumns

operation (see Section 2.1).

an even-numbered frequency will have no effect on

the XOR sum across all 256 intermediate values (Bi-

ham and Keller, 1999). Given 256 bytes taken from

the same index from a δ-set, one can remove all val-

ues that occur with an even-numbered frequency and

keep one example of those that occur with an odd-

numbered frequency.

We deﬁne Z as the number of instances of a given

value that occur in a sequence of 256 bytes. The prob-

ability of observing a given value n times is

Pr(Z = n) =

256

n

256

−n

1−

1

256

256−n

(1)

for 1 ≤ n ≤ 256. The probability of observing an

odd number of a given value is therefore Pr(X =

1)+Pr(X = 3) + ...+Pr(X = 255) = 0.43, and there-

fore the number of values that need to be treated de-

creases to 256 × 0.43 = 110. The analysis given by

Biham and Keller stops here and we provide a more

precise analysis below.

We deﬁne Y as the number of distinct values that

occur in a sequence of 256 bytes. The probability of

observing m distinct values is

Pr(Y = m) =

256

(m)

256

m

256

256

, (2)

for 1 ≤ m ≤ 256. We deﬁne r

(m)

= r(r − 1) . . . (r −

m+ 1) and

n

i

as a function that returns the Stirling

numbers of the second kind. That is, the number of

ways of partitioning n elements into i non-empty sets.

The expectation of x is simply

∑

256

i=1

i Pr(Y = i) = 162.

For a sequence of 256 bytes that consist of m dis-

tinct values, the probability distribution will be some-

what similar to that deﬁned by Biham and Keller.

Again we deﬁne Z as the number of instances of a

given value that occur in a sequence of 256 bytes.

The probability of observing observing a given value

n times given that there are m distinct values is

Pr(Z = n|Y = m) =

256

n

m

−n

1−

1

m

256−n

(3)

for 1 ≤ m, n ≤ 256. Again, the probability of ob-

serving an odd number of a given value is therefore

Pr(X = 1|Y = m) + Pr(X = 3|Y = m) + . . . +Pr(X =

255|Y = m) for a given m. We deﬁne A as the number

of distinct values that occur with an odd-numbered

frequency. Then the expectation of A will be:

E(A) =

256

∑

i=1

i Pr(Y = i)

127

∑

j=0

Pr(Z = (2 j+1)|Y = i) ≈ 78

(4)

That is, the sum of the number of distinct val-

ues occurring with an odd-numbered frequency

i

∑

127

j=0

Pr(X = (2 j + 1)|Y = i)

multiplied by the

probability of it occurring. This would reduce the

time complexity of an attack requiring two δ-sets to

156 one-rounddecryptions (approximately 2

5

encryp-

tions of a four-round AES).

4.2 Analyzing Five-round AES

An extension to the above attack was also ﬁrst pre-

sented in the original description of AES (Daemen

and Rijmen, 1998). This attack allowed an extra

round to be analyzed with an increase in the time com-

plexity. Rather than analyzing the ﬁnal subkey byte-

by-byte, one analyzes the penultimate subkey.

In order to do this one is obliged to guess 32 bits

of the ﬁnal subkey to determine one column of the

state matrix before the XOR with the penultimate sub-

key. One can then compute the

MixColumns

opera-

tion on this column, and validate hypotheses on a byte

of a subkey equivalent to the penultimate subkey (one

could compute the

MixColumns

operation on the de-

rived subkey to determine the penultimate subkey). A

valid byte would allow the property described in Sec-

tion 3 to be observed. Each evaluation reduces the

potential key space of ﬁve bytes being analyzed by

a factor of 256, and one would need to conduct this

analysis ﬁve times to determine 32 bits of the ﬁnal

subkey (Daemen and Rijmen, 1998).

If we deﬁne each of the 2

32

partial decryptions as

having a time complexity equivalent to a quarter of a

round, analyzing ﬁve sets of 256 ciphertexts to deter-

mine 32 bits of the last subkey and eight bits of the

“penultimate” subkey, can be computed with an ef-

fort equivalent to 2

40

/4 one-round AES decryptions

for one δ-set. Given this is a quarter of the work re-

quired for one set of 256 acquisitions, the total com-

plexity to determine a key using ﬁve δ-sets would be

SECRYPT2012-InternationalConferenceonSecurityandCryptography

28

5 · 2

40

one-round AES decryptions, or equivalent to

2

40

ﬁve-round AES encryption operations.

The cryptanalysis cannot be signiﬁcantly im-

proved by following the reasoning given in Sec-

tion 4.1. That is, if one partially decrypts a δ-set using

hypotheses on 32 bits of the last subkey, one can then

form hypotheses on individual bytes of the penulti-

mate subkey using one example of distinct values that

occur with an odd-numbered frequency. One could

follow this reasoning with the 32-bit values taken

from the ciphertexts. However, over 256 acquisitions

the probability of observing a value that occurs with

an even-numbered frequency will be too low to have

any signiﬁcant impact on the time complexity of an

attack.

Ferguson et al. present a way of conducting

this attack that is referred to as the “partial sums”

method (Ferguson et al., 2001). They observe that

conducting the attack involves computing

∑

i

S

−1

(S

0

(c

i,0

⊕ k

0

) ⊕ S

1

(c

i,1

⊕ k

1

)⊕

S

2

(c

i,2

⊕ k

2

) ⊕ S

3

(c

i,3

⊕ k

3

) ⊕ k

4

),

(5)

where S

λ

, for λ ∈ {0, . . . , 3}, are bijective look-up ta-

bles that consist of the function S and a multiplica-

tion by a ﬁeld element from F

2

8

. These are evaluated

efﬁciently by associating a “partial sum” x

k

to each

ciphertext where x

k

is deﬁned as

x

k

←

k

∑

j=0

S

j

(c

j

⊕ k

j

) . (6)

This gives a map from (c

0

,c

1

,c

2

,c

3

) 7→

(x

k

,x

k+1

,...,c

3

). In order to conduct an

attack one can compute (x

1

,c

2

,c

3

), i.e.

((S

0

(c

0

⊕ k

0

) ⊕ S

1

(c

1

⊕ k

1

)),c

2

,c

3

), for all the

ciphertexts in a δ-set for all possible values of k

0

and

k

1

. This will take 2

24

executions of the function S

resulting in 2

24

values for (x

1

,c

2

,c

3

). This continues

by computing (x

2

,c

3

) for all possible values of k

2

that also requires a 2

24

executions of the function S

resulting in 2

32

values for (x

2

,c

3

). Computing the 2

40

values for x

3

for all values of k

3

will require a further

2

40

executions of the function S. The last step will

require 2

48

executions of the function S

−1

. Using

the estimate provided by Ferguson et al., that the

time complexity of one AES encryption is equivalent

to 2

8

executions of the function S (Ferguson et al.,

2001), implementing the attack described above will

have a time complexity equivalent to approximately

2

40

ﬁve-round AES encryption operations. This has

the same time complexity as the straightforward

approach described previously. The method reported

by Ferguson et al. can only be applied when groups

of δ-sets are treated together (see Section 4.3).

The above analyses assume that one only consid-

ers one byte of the subkey that is equivalent to the

penultimate subkey. However, if we consider more

bytes of the penultimate subkey then fewer δ-sets are

required. An attacker guesses 32 bits of the last sub-

key which allows an attacker to validate hypotheses

on four bytes of a subkey that is equivalent to the

penultimate subkey. For one guess of 32 bits of the

ﬁnal subkey one would expect a hypothesis for any

byte of the subkey that is equivalent to the penulti-

mate subkey to produce an XOR sum equal to zero

with a probability equal to 1/2

8

. Given that there are

four such bytes the probability that four bytes of this

subkey will produce four sequences with XOR sums

equal to zero is 1/2

32

. Therefore, in order to deter-

mine 32 bits of the last subkey and 32 bits of a subkey

equivalent to the penultimate subkey one would ex-

pect to need two δ-sets. This would reduce the time

complexity of the attack detailed by Daemen and Ri-

jmen (Daemen and Rijmen, 1998) to approximately

2

39

ﬁve-round AES encryption operations.

The analysis of the hypotheses can be further op-

timized if the relationship between the last and penul-

timate subkey are veriﬁed as the attack progresses. If

we consider one δ-set, one can analyze two columns

of the penultimate subkey by guessing eight bytes of

the last subkey (in two sets of four bytes). This will

produce two sets of 2

32

hypotheses with a time com-

plexity equivalent to 2

36

ﬁve-round AES encryption

operations (using the estimations given above). One

can then eliminate hypotheses in each set that are in-

consistent, given that we have hypotheses on eight

bytes of the penultimate key and eight bytes of the

last subkey. However, we note that extra computa-

tion is required to change the hypotheses on the de-

rived values to hypotheses for the penultimate subkey.

That is, the four bytes corresponding to the penulti-

mate subkey are multiplied by M as described in Sec-

tion 2.1. This can be efﬁciently computed by consid-

ering the input vector as a 32-bit word and the matrix

multiplication conducted using 32-bit operations. We

estimate the complexity of this to be approximately

equivalent to (5), which is equivalent to 1/2

6

ﬁve-

round AES encryption operations. Operating on these

2

32

valueswill require the equivalentof 2

26

ﬁve-round

AES encryption operations, which is negligible com-

pared to the generation of the hypotheses.

From the AES key schedule we can see that any

subkey byte can be computed from two speciﬁc bytes

in either the previous or following subkey. From

the two sets of hypotheses generated, as described

above, there will be three cases where known rela-

tionships between these sets of hypotheses can be ver-

iﬁed. Given that the probability that all three bytes

Improved"PartialSums"-basedSquareAttackonAES

29

of a given hypotheses can be veriﬁed will be 1/2

24

,

one would expect that the two sets of 2

32

hypotheses

can be reduced to one set of 2

40

hypotheses. A third

set of 2

32

hypotheses can then be generated for one

of the remaining columns of the penultimate subkey

and four bytes of the last subkey. There will be a fur-

ther four bytes of the last subkey that are generated

by bytes for which there are already hypotheses, and

an element from the set of of 2

40

hypotheses will val-

idate a hypothesis from the new set of 2

32

hypotheses

with a probability of 1/2

32

. One would therefore ex-

pect to combine these two sets to produce a set of 2

40

hypotheses for 96 bits of the penultimate and 96 bits

of the last subkey. A set of 2

32

hypotheses can then be

generated for the ﬁnal column of the penultimate sub-

key and four bytes of the ﬁnal subkey. At this point

on can verify whether an entire subkey can be gener-

ated from the penultimate subkey. For each of the 2

32

hypotheses generated, hypotheses in the set of 2

40

hy-

potheses for 96 bits of the penultimate and 96 bits of

the last subkey will produce valid keys with a prob-

ability of 1/(2

8

)

9

= 1/2

72

(since there will be nine

bytes in the last subkey that will not have been veri-

ﬁed previously). One would, therefore, expect to gen-

erate two hypotheses from the two sets of hypotheses.

One that is correct and one that fulﬁlls the criteria by

chance.

The time complexity of the entire attack will be

2

38

ﬁve-round AES encryption operations and require

2

40

hypotheses to be stored in memory. If a second

δ-set is included the time complexity will increase,

but the memory requirements will become negligi-

ble. The time complexity does not double since an

attacker only requires sufﬁcient information to de-

termine which of the two remaining hypotheses are

false. This should be possible with work equivalent

to 2

36

ﬁve-round AES encryptions, i.e. the generation

of hypotheses of 32-bits of the ﬁnal and 32 bits of the

penultimate subkeys. These attack are summarized in

Table 1.

Table 1: Summary of the Square Attack on Five-round

AES-128.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

40

2

38

2

2 1 2

38

1

4.3 Analyzing an Extra Round

The attack described above applied to a ﬁve-round

AES can be extended to attack a six-round AES. In

order to permit an extra round to be analyzed a set

of 2

32

plaintexts are chosen that give all the possible

ciphertexts that differ at indexes 1,6,11, and 16. An

attacker will then seek to choose the 256 plaintext-

ciphertext pairs that produce intermediate states that

differ in only one byte after one round, i.e. the input

required to attack a ﬁve-round AES, as shown in Fig-

ure 2.

The simplest way of achieving this would be to

choose 256 32-bit values for the ﬁrst column of the

intermediate state that differ in one byte. These 32-bit

values can be deciphered for a given hypothesis for

four bytes of the ﬁrst subkey (speciﬁcally the bytes

at indexes 1,6,11, and 16). This will produce 256

plaintexts that produce a δ-set after one round that can

be analyzed using the attack described in Section 4.2,

each of which will provide one hypothesis for the se-

cret key given the hypotheses for 32 bits of the ﬁrst

subkey. This would increase the time complexity of

an attack by a factor of 2

32

, but allow an extra round

to be analyzed.

Ferguson et al. observed that all 2

32

can be used as

a set of acquisitions to conduct the Square attack (Fer-

guson et al., 2001). That is, a set of 2

32

distinct plain-

texts differing at, for example, indexes 1,6,11, and

16 described above can be viewed as 2

24

δ-sets. This

remains true after the ﬁrst round but an attacker can-

not distinguish individual δ-sets after the ﬁrst round

without knowing four bytes of the ﬁrst subkey. How-

ever, an attacker can treat all 2

32

acquisitions together,

i.e. the attack described in the previous section work

in the same manner but with a set of 2

32

, rather than

2

8

, acquisitions. We refer to a set of 2

32

plaintext-

ciphertext pairs that are equivalent to 2

24

δ-sets as a

∆-set.

An attack would proceed in the same manner as

described in Section 4.2. Using the same notation

the computation of the sets of (x

1

,c

2

,c

3

) will require

2

48

executions of the function S. This would result

in 2

32

triples (x

1

,c

2

,c

3

). However, a maximum of

2

24

values distinct values are possible. As described

in Section 4.1, one only needs to keep one example

of the triplets that occur with an odd-numbered fre-

quency. Likewise, this will produce at most 2

16

values

for (x

2

,c

3

) per key hypothesis, and at most 2

8

val-

ues for x

3

per key hypothesis. The time complexity

of the entire analysis requires 2

50

executions of the

function S for all four 32-bit sets for the ﬁnal subkey,

which given our estimate given above corresponds to

2

42

AES encryptions operations. This is increased to

2

44

where ﬁve ∆-sets are required to determine the

key.

Given that only two ∆-sets are required to deter-

mine the key, see Section 4.2, one the complexity

using the “partial sums” method can be reduced to

2

43

. This is not immediately apparent since evalu-

SECRYPT2012-InternationalConferenceonSecurityandCryptography

30

Plaintext

• 0 0 0

0 • 0 0

0 0 • 0

0 0 0 •

→

AddRoundKey

• 0 0 0

0 • 0 0

0 0 • 0

0 0 0 •

→

SubBytes

• 0 0 0

0 • 0 0

0 0 • 0

0 0 0 •

→

ShiftRow

• 0 0 0

• 0 0 0

• 0 0 0

• 0 0 0

→

MixColumn

• 0 0 0

0 0 0 0

0 0 0 0

0 0 0 0

Figure 2: Propagation of a four-byte difference across one round of AES, where • represents a non-zero difference.

ating (5) will reduce the number of key hypotheses

for {k

0

,k

1

,k

2

,k

3

,k

4

} by a factor of 256. Intuitively,

one would expect that the same effort would be re-

quired to analyze one ∆-set four times, resulting in

an attack with the same time complexity as that pro-

posed by Ferguson et al. We note that evaluating (5)

once for a given ∆-set will requires 2

48

executions of

the function S. A second evaluation of an instance

of (5) with k

4

replaced with a different key byte from

the penultimate subkey will require 2

40

executions of

the function S. This is because S

λ

(c

i,λ

⊕ k

λ

), for one

λ ∈ {0,...,3}, will already have been computed for

all i (we note that this will involve carefully choos-

ing the order in which the ﬁrst instance of (5) is eval-

uated). This same reasoning applies for a third and

fourth evaluation of (5) that will result in an 8-tuple

consisting of four bytes of the last subkey and four

bytes of the penultimate subkey. The overall com-

plexity of evaluating (5) four times for one ∆-set is,

therefore, approximately 2

48

executions of the func-

tion S. The time complexity of the repeating this for

all four 32-bit sets for the ﬁnal subkey requires 2

50

ex-

ecutions of the function S, which given our estimate

given above corresponds to 2

42

AES encryptions op-

erations. This is increased to 2

43

where two ∆-sets are

required to determine the key.

We can reduce the time complexity further if we

exploit the relationships between key bytes in adja-

cent subkeys. That is, one can generate 8-tuples of

key byte values using the “partial sums” sums tech-

nique proposed by Ferguson et al. and use the at-

tack described in in Section 4.2 to reduce the number

of key hypotheses. Given one set of 2

32

plaintext-

ciphertext pairs an attack with a time complexity

equivalent to 2

42

six-round AES encryption opera-

tions and require that 2

40

key hypotheses are stored

in memory. Again, more acquisitions can be used to

reduce the memory requirements at the cost of an in-

creased time complexity. This is summarized in Ta-

ble 2.

Table 2: Summary of the Square Attack on Five-round

AES-128.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

40

2

42

2

2 1 2

42

1

5 APPLYING THE SQUARE

ATTACK TO AES-192 AND

AES-256

In this section we describe how the attacks described

in Section 4 are applicable to AES-192 and AES-256.

5.1 Analyzing Five-round AES

Attacking a ﬁve-round AES-192 will function using

a time complexity equivalent to 2

39

AES encryption

operations using the attack described in Section 4.2

based on the attack proposed by Ferguson et al. (Fer-

guson et al., 2001). That is, two δ-sets would be sufﬁ-

cient to determine the last two subkeys of a ﬁve-round

instance of AES-192 or AES-256.

An attack on an instance of AES-256 cannot be

made more efﬁcient by analyzing two consecutive

subkeys since there are no direct relationships. How-

ever, one can exploit the relationships between two

consecutive subkeys when attacking an AES-192.

This would follow a similar technique to that pre-

sented in Section 4.2. If one acquires a δ-set, one

can analyze two columns of the penultimate subkey

by guessing eight bytes of the last subkey (in two

sets of four bytes). This will produce two sets of 2

32

hypotheses with a time complexity equivalent to 2

36

ﬁve-round AES encryption operations. One can then

eliminate hypotheses in each set that are inconsistent,

since we would have hypotheses on eight bytes of the

penultimate key and eight bytes of the last subkey.

Given the key schedule, one would expect that the

two sets of 2

32

hypotheses can be reduced to one set

of 2

48

hypotheses. A third set of 2

32

hypotheses can

then be generated for one of the remaining columns

of the penultimate subkey and four bytes of the last

subkey. One would expect that this would produce

Improved"PartialSums"-basedSquareAttackonAES

31

2

64

hypotheses with the relevant subkeys. This is be-

cause, in each case, there are two key bytes in the

penultimate key that can each be derived from bytes

the last subkey.

As previously, the memory requirements of the

above attack can be reduced by acquiring more δ-sets

at the cost of an increase in the time complexity. How-

ever, one would only need to analyse half the informa-

tion present in a second δ-set to reduce the hypotheses

to a trivial amount. The details of the square attack ap-

plied to ﬁve-round AES-192 and AES-256 are shown

in Table 3 and 4 respectively.

Table 3: Summary of the Square Attack on Five-round

AES-192.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

64

2

38

2

64

2 1 2

38.5

2

16

Table 4: Summary of the Square Attack on Five-round

AES-256.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

128

2

38

2

128

2 1 2

39

1

5.2 Analyzing Six-round AES

The attacks on ﬁve rounds of AES-192 and AES-256

can be extended by assuming that an attacker knows

the last subkey. The time complexity of the ﬁve-round

attack does increases by a factor of 2

128

when it is

applied to a six round variants of AES-256. How-

ever, Lucks observed that knowledge of the last sub-

key would allow an attacker to directly derive bytes

in previous subkeys when attacking AES-192 (Lucks,

2000). That is, 64 bits of the penultimate subkey and

32 bits of the antepenultimate subkey, as shown in

Figure 3.

Following the reasoning in Section 4.2, a compu-

tational effort equivalent to 2

22

(i.e. a factor of 2

16

less than the standard attack) six-round AES-192 en-

cryption operations to treat each δ-set. As previously,

two δ-sets would be sufﬁcient to determine the penul-

timate and antepenultimate subkeys.

One can reduce this to one set if one uses the re-

lationships between two consecutive subkey as de-

scribed in Section 5.1. Since much of the subkeys are

already known the memory requirementsare much re-

duced. The details of the square attack applied to ﬁve-

round AES-192 and AES-256 are shown in Table 5

and 6 respectively.

Table 5: Summary of the Square Attack on Six-round AES-

192 using δ-sets..

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

16

2

150

2

8

2 1 2

151

1

Table 6: Summary of the Square Attack on Six-round AES-

256 using δ-sets..

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

128

2

166

2

128

2 1 2

167

1

We can also note that introducing an extra round

before, and acquiring ∆-sets will lead to a more efﬁ-

cient attack. This involves conducting the ﬁve-round

attack described in Section 5.1 on a six-round AES

using ∆-sets rather than δ-sets. The details of the

square attack applied to six-round AES-192 and AES-

256 using ∆-sets are shown in Table 7 and 8 respec-

tively.

Table 7: Summary of the Square Attack on Six-round AES-

192 using ∆-sets.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

64

2

42

2

64

2 1 2

42.5

2

16

Table 8: Summary of the Square Attack on Five-round

AES-256 using ∆-sets.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

128

2

42

2

128

2 1 2

43

1

Table 9: Summary of the Square Attack on Seven-round

AES-192.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

16

2

153

2

8

2 1 2

154

1

Table 10: Summary of the Square Attack on Seven-round

AES-256.

Number Memory Time Remaining

of δ-sets Complexity Hypotheses

1 2

128

2

170

2

128

2 1 2

171

1

SECRYPT2012-InternationalConferenceonSecurityandCryptography

32

7-th Subkey

• • • •

• • • •

• • • •

• • • •

→

6-th Subkey

◦ ◦ 0 0

◦ ◦ 0 0

◦ ◦ 0 0

◦ ◦ 0 0

→

5-th Subkey

0 0 0 ◦

0 0 0 ◦

0 0 0 ◦

0 0 0 ◦

Figure 3: The known information from the last subkey, where • represents a known value and ◦ represents a derived value.

Table 11: Summary of attacks presented in this paper.

Rounds Key Length Memory Acquisitions Complexity

(Daemen and Rijmen, 1998) 4 128 – 2

9

2

6

(Biham and Keller, 1999) (corrected) 4 128 – 2

9

2

5

(Daemen and Rijmen, 1998) 5 generic – 2

11

2

40

This paper 5 128 – 2

8

2

38

This paper 5 192 – 2· 2

8

2

38.5

This paper 5 256 – 2· 2

8

2

39

(Daemen and Rijmen, 1998) 6 generic – 5· 2

32

2

72

(Ferguson et al., 2001) 6 generic 2

32

6· 2

32

2

44

This paper 6 128 2

40

2

32

2

42

This paper 6 192 – 2· 2

32

2

42.5

This paper 6 256 – 2· 2

32

2

43

(Lucks, 2000) 7 192 2

32

2

32

2

176

Ferguson et al. (Ferguson et al., 2001) 7 192 2

32

19· 2

32

2

155

This paper 7 192 – 2· 2

32

2

154

(Lucks, 2000) 7 256 2

32

2

32

2

192

(Ferguson et al., 2001) 7 256 2

32

21· 2

32

2

172

This paper 7 256 – 2· 2

32

2

171

5.3 Analyzing an Extra Round

As described in Section 4.3, an extra round can be

added where an attacker uses ∆-sets (Ferguson et al.,

2001). Given that a large amount of the penultimate

subkey is known the “partial sums” method of con-

ducting the Square attack can be further optimized.

We recall that the attack requires that (5) is evaluated

as described in Section 4.2. Note that the attack does

not proceed exactly as the six-round attack given in

Section 5.2 as the relationships between the bytes of

the subkeys will be different.

If, for example, an attacker wishes to evaluate (5)

and knows (k

0

,k

1

) these values can be evaluated be-

fore the unknown (k

2

,k

3

). Generating 2

24

values for

(x

1

,c

2

,c

3

) will require 2

33

executions of the function

S. Then 2

16

values for (x

2

,c

3

) per hypotheses for k

2

can be generated with 2

32

executions of the function

S, and continue as per the attack described in Sec-

tion 4.3. The time complexity of the entire analysis

will be 2

34

evaluations of the function S. That is, 2

36

executions of the function S for all four 32-bit sets for

the ﬁnal subkey, which corresponds to 2

28

AES en-

cryptions operations.

6 CONCLUSIONS

In this paper we have demonstrated that the “partial

sums” method of conducting the Square attack can be

improved by analyzing more information per δ-set (or

∆-set). This allows the time complexity of attacks to

be halved. For AES-128 the time complexity can be

halved again, and reduced by a smaller amount for

AES-192, by eliminating key hypotheses on-the-ﬂy.

In Table 11 we present a summary of the attacks

presented in this paper alongside similar attacks in the

literature. The memory requirements are the number

of state matrices, or equivalent, that need to be stored

in memory. The number of acquisitions are the num-

ber of chosen plaintexts enciphered with an unknown

key, where the number is given in multiples of 2

8

or

2

32

so that it is clear how many δ or ∆-sets are re-

quired to conduct the attack. The time complexity

is expressed as the computational effort required to

compute that many AES encryption operations.

In this paper we have focused on attacks that re-

quire relatively few chosen plaintext-ciphertext pairs.

Ferguson et al. also proposed a Square attack appli-

cable to seven rounds of a AES-128 and eight rounds

for AES-192 and AES-256. However, this attack re-

Improved"PartialSums"-basedSquareAttackonAES

33

quires approximately 2

128

chosen plaintext-ciphertext

pairs and is beyond the scope of this paper although

one would expect the proposed strategy to aid in the

analysis.

ACKNOWLEDGEMENTS

The author would like to thank Martijn Stam for help-

ful discussions. The work described in this paper

has been supported in part the European Commis-

sion through the ICT Programme under Contract ICT-

2007-216676 ECRYPT II and the EPSRC via grant

EP/I005226/1.

REFERENCES

Bahrak, B. and Aref, M. R. (2008). Impossible differen-

tial attack on seven-round AES-128. IET Information

Security Journal, 2(2):28–32.

Biham, E. and Keller, N. (1999). Cryptanalysis of

reduced variants of Rijndael. unpublished.

http://www.madchat.fr/crypto/codebreakers/35-

ebiham.pdf.

Bogdanov, A., Khovratovich, D., and Rechberger, C.

(2011). Biclique cryptanalysis of the full AES. In

Lee, D. H. and Wang, X., editors, ASIACRYPT 2011,

volume 7073 of LNCS, pages 344–371. Springer.

Daemen, J., Knudsen, L., and Rijmen, V. (1997). The block

cipher Square. In Biham, E., editor, FSE '97, volume

1267 of LNCS, pages 149–165. Springer.

Daemen, J. and Rijmen, V. (1998). AES proposal: Rijn-

dael. In AES Round 1 Technical Evaluation CD-1:

Documentation. NIST. http://www.nist.gov/aes.

Dunkelman, O. and Keller, N. (2010). The effects of the

omission of last round’s MixColumns on AES. Infor-

mation Processing Letters, 110(8–9):304–308.

Ferguson, N., Kelsey, J., Lucks, S., Schneier, B., Stay,

M., Wagner, D., and Whiting, D. (2001). Improved

cryptanalysis of Rijndael. In Schneier, B., editor,

FSE 2000, volume 1978 of LNCS, pages 213–230.

Springer.

FIPS PUB 197 (2001). Advanced encryption standard

(AES). Federal Information Processing Standards

Publication 197, National Institute of Standards and

Technology (NIST), Gaithersburg, MD, USA.

Lu, J., Dunkelman, O., Keller, N., and Kim, J. (2008). New

impossible differential attacks on AES. In Chowd-

hury, D. R., Rijmen, V., and Das, A., editors, IN-

DOCRYPT 2008, volume 5365 of LNCS, pages 279–

293. Springer.

Lucks, S. (2000). Attacking seven rounds

of Rijndael under 196-bit and 256-bit

keys. In AES Candidate Conference 2000.

http://csrc.nist.gov/encryption/aes/round2/conf3/aes3

conf.htm.

Mangard, S., Oswald, E., and Popp, T. (2007). Power Anal-

ysis Attacks: Revealing the Secrets of Smart Cards.

Springer-Verlag.

Zhang, W., Wu, W., and Feng, D. (2007). New results on

impossible differential cryptanalysis of reduced AES.

In Nam, K.-H. and Rhee, G., editors, ICISC 2007, vol-

ume 4817 of LNCS, pages 239–250. Springer.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

34
