Handling Inconsistency in Software Requirements

Richa Sharma

and K. K. Biswas

School of Information Technology, IIT Delhi, India

Department of Computer Science, IIT Delhi, India

Keywords: Requirements Specification, Inconsistency, Presupposition, Knowledge Representation, Courteous Logic.

Abstract: Software Requirements expressed in the form of natural language are often informal and possibly vague.

The need for formal representation of the requirements has been explored and addressed in various forms

earlier. Of several recommended approaches, logical representation of requirements has been widely

acknowledged to formalize the requirements languages. In this paper, we present courteous logic based

representations for software requirements. We report the benefits of courteous logic based representations

for handling inconsistencies in software requirements and take into account views of multiple stakeholders

and the presuppositions. We show how courteous logic based representations can be used to ensure

consistency as well as to uncover presuppositions in the requirements.

1 INTRODUCTION

Software Development commences with the phase

comprising requirement engineering activities. Any

software model, whether it is Waterfall model,

Iterative or Agile, commences with tasks centred on

the popularly known requirements phase. The

requirements phase becomes crucial to the success

of the software as this phase only serves as the basis

for subsequent phases of software development. It

would not be incorrect to say that establishing

correct requirements is imperative even in agile

model where developers work in close connection

with the users; there is still need to clearly specify

the requirements so that the requirements are well

understood by the developer. The mode of

expressing the requirements may vary from visual

models to textual use-cases to user scenarios, but the

underlying idea is that the requirements should be a

good representation of the domain under study and

should be well understood and agreed upon by all

the stakeholders. There is no precise definition as to

what is meant by ‘good’ representation but with

reference to features of good software requirements

specification, requirements representations should be

consistent, unambiguous and complete in nature

(IEEE CS, 1998). It is a challenging task to draw

upon the representations satisfying these qualities.

The most common defect that arises in software

requirements representation is that of inconsistency.

The elicited requirements describing the functional

specifications of the behaviour of the information

system or the software application are frequently

incomplete in nature as users might not be able to

express all what they need or the stated requirements

are not well understood by the requirements

engineer. Therefore, the gathered requirements often

need enrichment during analysis for functional

behaviour as well as non-functional properties.

Requirements engineers need to examine these

gathered requirements and to transform this “rough”

sketch of requirements into a correct requirement

specification (Zowghi, 2003). As a result, new

requirements are identified that should be added to

the specification, or some of the previously stated

requirements may need to be deleted to improve the

specification. It becomes a critical task for

requirements engineers to maintain the consistency

of the set of specified requirements.

Our contribution in this paper is to demonstrate

the courteous logic based requirements

representations (requirements specification

hereafter) as a worthwhile approach towards

handling inconsistency in the requirements and the

related issue of identifying presuppositions (Ma et

al., 2009). The use of logic to formalize the

requirements has been acknowledged in earlier

works too as logic offers proof-theoretic framework

facilitating requirements validation and evolution.

We are making use of a form of non-monotonic

Sharma R. and Biswas K..

Handling Inconsistency in Software Requirements.

DOI: 10.5220/0003999500950104

In Proceedings of the 7th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2012), pages 95-104

ISBN: 978-989-8565-13-6

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

logic as requirements evolution becomes non-

monotonic after an initial monotonic phase (Zowghi,

2003).

The rest of the paper is organized as follows. In

section 2, we elaborate the inconsistency concern

that motivated the use of courteous logic. Section 3

describes courteous logic in detail and how it can be

used to address the inconsistency and presupposition

concern in requirements. In section 4, we present an

overview of related work followed by possible

threats to the usage of formal logic by requirements

analysts in section 5. Section 6 finally presents

discussion and conclusion.

2 INCONSISTENCY CONCERN

Several adequate definitions are available

elucidating the inconsistency concern in software

requirements (Tsai et al., 1992), (Gervasi and

Zowghi, 2005). Of the two IEEE interpretations of

inconsistency, namely internal inconsistency and the

Software Requirements Specification not agreeing

with some higher level document (traceability), we

are interested in addressing the former one. Internal

inconsistency arises when the specification of

requirements contains conflicting or contradictory

information about the expected behaviour of the

system. The reason for conflicting information

existence can be attributed to multiple views of the

stakeholders. Internal inconsistency may also arise

when some new requirement is added or an existing

requirement is removed from the requirements

specification. Internal inconsistency may also arise

due to lack of domain knowledge at the

requirements engineer’s end owing to which some

implicit knowledge, referred to as presupposition

that could not find explicit expression in the

requirements set, gets missed in the elicited

requirements. These forms of inconsistency may be

detected or remain undetected at the time of

requirements analysis. It is often a matter of the

domain expertise of the requirements analyst to

detect the inconsistencies in the elicited

requirements. If inconsistency is detected during

requirements phase, then it can be corrected and the

defects which surface later in software development

lifecycle can be contained in requirements phase

only. If undetected, then the problem permeates the

subsequent phases as the programmer might resolve

the concern arbitrarily during implementation. The

undetected inconsistency is an indication that

possibly the analyst has had a presupposition about

the inconsistent information, or possibly it was

overlooked. Presupposition being a linguistic

phenomenon is related to the utterance and the

intuitive meaning of the sentence (Levinson, 2000).

In context of requirements, presuppositions

significantly contribute to both inconsistency and

incompleteness problems.

In order to contain defects in the requirements

phase and effectively manage the concern of

inconsistency, certain degree of formalism is

required in the requirements specification. It is

essential to draw a formal model or representation of

requirements that is a reflection of the expected

observable behaviour of the system. Such a model or

representation would allow identifying implicit or

hidden inconsistency, which is otherwise difficult to

identify as implicit inconsistency arises out of

interpretation or consequence of the requirements.

We can easily identify and take into consideration

the explicit inconsistency arising because of multiple

views of stakeholders, but no such easy approach is

there with implicit inconsistency. We’ll see in next

section how courteous logic expressions address this

requirements representation problem and obligates

the analyst to explicitly specify the presuppositions

too, if any.

3 COURTEOUS LOGIC BASED

SOLUTION

The idea of having requirements representation in a

form that shows the expected observable behaviour

of the system and the need to formalize requirements

specifications led to the use of logical

representations of the requirements. We are more

focused on non-monotonic reasoning for two

reasons. First, to address the problem of

inconsistency and explicit specification of

presuppositions in the requirements; and secondly,

real-world requirements correspond to human way

of thinking and common-sense reasoning which is

non-monotonic in nature. We found courteous logic

based representation (requirements specification

hereafter) suitable for our cause. We have already

shown the adequacy of courteous logic for

requirements specification in (Sharma and Biswas,

2011). Here, we highlight the concern of undetected

inconsistency and the associated concern of

presupposition.

3.1 Courteous Logic

Courteous Logic (Grosof, 1997) is a form of non-

monotonic logic where consequence relation is not

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

monotonic. It is based on prioritization of the rules.

Courteous logical representation (CLP) is an

expressive subclass of ordinary logical

representation (OLP) with which we are familiar

and, it has got procedural attachments for prioritized

conflict handling. First Order Logic beyond Logic

Programming (LP) has not become widely used for

two main reasons: it is pure belief language; it

cannot represent procedural attachments for

querying and actions and, it is logically monotonic;

it can not specify prioritized conflict handling which

are logically non-monotonic. The Courteous Logic

Programming (CLP) extension of LP is equipped

with classical negation and prioritized conflict

handling. CLP features disciplined form of conflict-

handling that guarantees a consistent and unique set

of conclusions. The courteous approach hybridizes

ideas from non-monotonic reasoning with those of

logic programming. CLP provides a method to

resolve conflicts that arise in specifying, updating

and merging rules. Our CLP representations are

based on IBM’s CommonRules, available under free

trial license from IBM alpha works (Grosof, 2004).

In CLP, each rule has an optional rule label,

which is used as a handle for specifying

prioritization information. Each label represents a

logical term, e.g., a logical 0-ary function constant.

The "overrides" predicate is used to specify

prioritization. "overrides (lab1, lab2)" means that

any rule having label "lab1" is higher priority than

any other rule having label "lab2". The scope of

what is conflict is specified by pair-wise mutual

exclusion statements called “mutex's”. E.g., a mutex

(or set of mutex's) might specify that there is at most

one amount of discount granted to any particular

customer. Any literal may be classically negated.

There is an implicit mutex between p and classical-

negation-of-p, for each p, where p is a ground atom,

atom, or predicate.

An example illustrating the power of CLP:

Consider following rules for giving discount to

customer:

 If a customer has Loyal Spending History, then

give him 5% Discount.

 If a customer was Slow to pay last year, then

grant him No Discount.

 Slow Payer rule overrides Steady Spender.

 The amount of discount given to a customer is

unique.

These rules are represented in CLP as following

set of rulebase:

if shopper(?Cust) and

spendingHistory(?Cust, loyal)

then

giveDiscount(percent5, ?Cust);

if slowToPay(?Cust, last1year)

then

giveDiscount(percent0, ?Cust);

overrides(slowPayer, steadySpender);

As discussed above, the two types of customers

are labeled as <steadySpender> and <slowPayer>;

the predicate ‘overrides’ is used to override the

discount attributed to slowpayer over the discount to

be given to steadyspender in case a customer is

found to be both steadySpender and slowPayer.

We found that courteous logic representations are

closer to natural language representation of business

rules in terms of commonly used ‘if - then’ rules

and, can be easily interpreted by both the users and

the developers. An experience with CLP shows that

it is especially useful for creating rule-based systems

by non-technical authors too (Grosof, 1997).

Another advantage of CLP is computational

scalability: inferencing is tractable (worst-case

polynomial time) for a broad expressive case. By

contrast, classical logic inferencing is NP-hard for

this case.

3.2 Identifying Inconsistency and

Presuppositions

In this sub-section, we bring forth the expressive and

the reasoning power of courteous logic and,

demonstrate how it proves effective in identifying

instances of inconsistency and consequent

presupposition through three case-studies in varying

domains.

Example 1 - Representing and Prioritizing

Conflicting Views (Academic Grade Processing):

Consider the specification of students’ grade

approval process where the students’ grades are

approved by the course-coordinator, the department

head and the dean. The expected behaviour of the

system refers to the fact that at any point in time,

approval from department head holds higher priority

over course-coordinator; and approval from dean

higher priority over department head and in turn,

the course coordinator. Often, this observable

behaviour is not captured in its essence in

requirements specification. The use-case of the

academics system that we got to study had a mention

of process-flow only as:

HandlingInconsistencyinSoftwareRequirements

The grades of students once entered in the system

need to be approved by the course-coordinator, the

department head and the dean.

This particular use-case served an excellent example

of inconsistency as well as the presence of

presupposition as this process-flow nowhere

mentions the priority of grade-approval level. In the

absence of validation against explicit expected

behaviour of the real-time system, the software

system can possibly have an inconsistent state of

grades subject to the arbitrary implementation done

by the programmer. The pragmatic presupposition

(Levinson, 2000) associated with this use-case is

that when process-flow describes approval by the

course-coordinator, the department head and the

dean, then it refers to a sequential and prioritized

flow with highest priority of the dean, followed by

department head and then, course-coordinator.

Consequently, programmer needs to take care of

these details and should not take any decision

arbitrarily.

The courteous logic specification of the

requirements as stated in the given use-case

translates to four labelled rules, namely new, cdn,

hod and dean respectively:

<new>

if assignGrades(?Regno, ?Year, ?Sem,

?Group, ?Sub, ?Point)

then valStatus(new, ?Regno, ?Year,

?Sem, ?Group, ?Sub);

<cdn>

if approvedby(?Regno, ?Year, ?Sem,

?Group, ?Sub, ?Point, ?Status,

coordinator)

then valStatus(coordApproved, ?Regno,

?Year, ?Sem, ?Group, ?Sub);

<hod>

if approvedby(?Regno, ?Year, ?Sem,

?Group,?Sub, ?Point, coordApproved,

hod)

then valStatus(hodApproved, ?Regno,

?Year, ?Sem, ?Group, ?Sub);

<dean>

if approvedby(?Regno, ?Year, ?Sem,

?Group,?Sub, ?Point, hodApproved, dean)

then valStatus(deanApproved, ?Regno,

?Year, ?Sem, ?Group, ?Sub);

In the expressions above, ?X represents a variable.

The rule labelled as <new> specifies that when a

student with registration number, ?Regno; year of

study, ?Year; semester and group as ?Sem and

?Group respectively is assigned grades for points,

?Point in subject, ?Sub, then status of his grades

would be new. The rule labelled as <cdn> specifies

that grade status changes to coordapproved on

approval by coordinator. Similarly, the rules labelled

<hod> and, <dean> indicate the grade status on

approvals by the department head and the dean

respectively.

We observed the expected behaviour of the

system by subjecting the courteous logic

representation of this use-case to reasoning engine of

courteous logic. We first collected observation in the

absence of any prioritization rules as that

information was not explicitly mentioned in the

given use-cases. This use-case presented us with the

case of implicit inconsistency present in the

consequences of the above rules. We took three

sample given facts for a student with registration

number 2008CSY2658:

assignGrades(2008CSY2658, 2009,

even, 4, ai, c);

approvedby(2008CSY2658, 2009, even,

4, ai, c, new, coordinator);

approvedby(2008CSY2658, 2009, even,

4, ai, c, new, hod);

Corresponding to these facts and the given labeled

rules, the consequences inferred for grade status of

this student was found to be taking three distinct

values at one point in time:

valStatus(hodApproved, 2008CSY2658,

2009, even, 4, ai);

valStatus(new, 2008CSY2658, 2009,

even, 4, ai);

valStatus(coordApproved,

2008CSY2658, 2009, even, 4, ai);

Since this is not practical for any status term to have

multiple values assigned, it represents an

inconsistent state of the world. For all practical

purposes, we can safely say that above specification

is an inconsistent reflection of the real-world system.

This is an implicit inconsistency, having occurred

owing to the consequences of the requirements

expressed as labelled rules. Since our specification is

an executable model of the real-world, we could

validate the specification against expected behaviour

of the system and, reach the conclusion of

inconsistency at an early stage of software

development. Next, this observation pointed to the

presence of some knowledge which is not yet put

into words, i.e. presupposition. Further investigating

and refining the requirements based on this

observation and enriched knowledge, we added

following rules:

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

overrides(cdn, new);

overrides(hod, new);

overrides(dean, new);

overrides(hod, cdn);

overrides(dean, cdn);

overrides(dean, hod);

MUTEX

valStatus(?Status1, ?Regno,

?Year, ?Sem, ?Group, ?Sub)

AND

valStatus(?Status2, ?Regno,

?Year, ?Sem, ?Group, ?Sub)

GIVEN

notEquals( ?Status1, ?Status2 );

The overrides clause establishes the prioritizing

relationship between the grade approval rules where

the first argument holds higher priority above the

second argument. The MUTEX specifies the scope

of conflict, which is the grade status in our case. The

overrides clause takes care of the possible conflict in

the student’s grade status. Validating the updated

specification against the observable expected

behaviour of the grade approval processing, we

found our specification consistent as the

consequence obtained was the expected one:

valStatus(hodApproved, 2008CSY2658,

2009, even, 4, ai);

The above example illustrates how conflicting

information can be expressed with well-formed

semantics of courteous logic. We present one more

example below that illustrates expressing some

default operation in a domain as well as exceptions

to that processing.

Example 2 – Representing Default and Exceptional

Scenario Processing (Saving and Current Account

Processing):

Consider the account processing part of a bank

customer where he can have more than one account.

Let’s consider that a bank customer can have a

current account and a saving account. The customer

can choose one of these accounts as default account

for any transaction that he wants to carry out. The

usual choice is current account but to keep the use-

case generic, let us assume that customer has marked

one of the accounts as default. The customer is free

to select the other account for some of his

transactions. In that case, the selected account

processing should override the default processing.

The natural language expression for such default

operation and associated exception can be easily

understood by the involved stakeholders as well as

developers. But what is often overlooked by

developers is the implicit interpretation here – the

account chosen for default processing should remain

unaffected in case selection is made for the non-

default account and often, this is uncovered till

testing phase. Such overlooked implicit

interpretation results in implicit internal

inconsistency. Such a defect can be easily detected

during RE phase if we have an executable model or

representation of requirements that can sufficiently

express the domain knowledge.

The courteous logic specification of the

requirements as stated in the given account

processing for deposit and withdrawal transactions

by the customer translates to following rules:

<def>

if deposit(?Txn, ?Client, ?Amount)

nd holds(?Client, ?Acct)

and default(?Acct)

then addAmount(?Client, ?Acct,

?Amount);

<sel>

if deposit(?Txn, ?Client, ?Amount)

and holds(?Client, ?Acct) and

option(?Client, ?Txn, sel, ?Acct)

then addAmount(?Client, ?Acct,

?Amount);

<def>

if withdraw(?Txn, ?Client, ?Amount)

and holds(?Client, ?Acct) and

default(?Acct)

then subAmount(?Client, ?Acct,

?Amount);

<sel>

if withdraw(?Txn, ?Client, ?Amount)

and holds(?Client, ?Acct) and

option(?Client, ?Txn, sel, ?Acct)

then subAmount(?Client, ?Acct,

?Amount);

The rule with label <def> indicates transaction

processing from default account whereas the rule

with label <sel> indicates processing from the

selected account. For deposit type of transaction, the

default rule (the first rule in the above expressions)

indicates that if a client, ?Client is holding an

account, ?Acct marked as default and he initiates a

deposit transaction with a certain amount, ?Amount

then that amount will get credited or added to his

default account. Similar is the case with withdrawal

transaction. The client can choose another account

provided he is holding that account and chooses it

for some transaction as expressed through rule

labeled as <sel>. In this case, any deposit or

withdrawal transaction would affect the selected

account only. To verify that any such transaction

will not affect the default account, we first tested the

rules without any override clause using some sample

HandlingInconsistencyinSoftwareRequirements

data as:

holds(abc, acctabc10);

holds(abc, acctabc11);

default(acctabc10);

deposit(t1, abc, 1000);

deposit(t2, abc, 5000);

withdraw(t3, abc, 2000);

withdraw(t4, abc, 4000);

option(abc, t2, sel, acctabc11);

option(abc, t3, sel, acctabc11);

Corresponding to these facts and the given labeled

rules, the consequences inferred for each of the

transactions t1, t2, t3 and t4 were found to be:

addAmount(abc, acctabc10, 1000);

addAmount(abc, acctabc10, 5000);

addAmount(abc, acctabc11, 5000);

subAmount(abc, acctabc10, 2000);

subAmount(abc, acctabc11, 2000);

subAmount(abc, acctabc10, 4000);

The results obtained indicate that deposit to and

withdrawal from default accounts are adequately

expressed as the behavior of dummy transactions, t1

and t4 is same as the expected behavior. But on

account selecting, both the selected and the default

accounts are getting affected as transactions t2 and

t3 represent the outcome of the requirement

expression. Adding the clause for prioritizing the

selected account and making the default account and

the selected account mutually exclusive so that only

one of these accounts is impacted by some

operation, we got the desired output – one that

matches the expected behavior in real-time scenario:

overrides(sel, def);

MUTEX

addAmount(?Client, ?Acct1, ?Amount)

AND

addAmount(?Client, ?Acct2, ?Amount)

GIVEN

notEquals( ?Acct1, ?Acct2 );

MUTEX

subAmount(?Client, ?Acct1, ?Amount)

AND

subAmount(?Client, ?Acct2, ?Amount)

GIVEN

notEquals( ?Acct1, ?Acct2 );

As elaborated in detail in example 1, the mutex

clause in this case establishes the scope of conflict

over the two accounts and, the override clause

assigns priority to the selected account. This

example highlights two things:

a) The labels used as handle to some rule are not

mere tags that need to be different from each-

other. These can be repeated and reused in

same specification provided their intent is

same wherever used.

b) The expressions without ‘override’ and

‘mutex’ clause were consistent with natural

language specification of the requirements but,

were inconsistent with expected behavior. The

implicit presupposition that only the selected

account should be affected was uncovered at

requirements level owing to the executable

nature of our specification.

Let’s consider one more example to show that

multiple views of stakeholders can also be

conveniently expressed using courteous logic based

requirements specifications.

Example 3 – Representing and Prioritizing Views

of Multiple Stakeholders (Corporate Event

Processing):

Consider a corporate action event announced on a

security. If a client is holding the security on which

event is announced, then that client is eligible to get

the announced benefits of the event. These benefits

can either be in the form of cash or stock or both.

The types of benefits disbursed to the clients vary

from one event type to another; it also depends on

various other factors like base country of the

security on which event is announced, the country of

the customer; client opting for an option etc. Then,

there can be multiple stakeholders having differing

views like one particular stock market has rules that

do not allow client to opt any option announced on

event; whereas, clients from some other market can

opt for event’s announced operations, so on and so

forth. We took a small subset of this large set of

rules and gradually scaled the rules as well as the

data to find that results are consistent with the actual

observable expectations. This particular example

served towards claiming scalability of courteous

logic based requirements specifications. Our

expressions could not only be easily validated

against the real-world expected behavior but also

these were small and compact making them easy to

comprehend and verify against multiple real-world

scenarios as shown below:

<cash>

if event(?EventId, ?Type, ?Security)

and holds(?Client, ?Security) and

opts(?Client, cash)

then distribute(?Client, ?EventId,

cash);

<stock>

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

100

if event(?EventId, ?Type, ?Security)

and holds(?Client, ?Security) and

opts(?Client, stock)

then distribute(?Client, ?EventId,

stock);

<both>

if event(?EventId, ?Type, ?Security)

and holds(?Client, ?Security) and

opts(?Client, both)

then distribute(?Client, ?EventId,

both);

if event(?EventId, dividend,

?Security) and holds(?Client,

?Security) and baseCntry(?Security,

Mkt1)

then distribute(?Client, ?EventId,

stock);

if event(?EventId, dividend,

?Security) and holds(?Client,

?Security) and clientCntry(?Client,

Mkt2)

then distribute(?Client, ?EventId,

nothing);

if event(?EventId, dividend,

?Security) and holds(?Client,

?Security) and baseCntry(?Security,

Mkt1) and clientCntry(?Client, Mkt5)

then distribute(?Client, ?EventId,

cash);

The rule with label as <cash> indicates that if an

event, ?Event of some type, ?Type is announced on a

stock, ?Security and a client, ?Client is holding that

stock and he opt for ‘cash’ option then he will receive

the benefit of event in the form of cash as per the

announced rules of the event. Similarly, use-cases

with stock and both types of disbursements are

represented through rules labelled as ‘stock’ and

‘both’ respectively. These are generic rules. Next, we

have considered a hypothetical scenario where in

stakeholders from stock market, Mkt1 are of the view

that if ‘dividend’ type of event is announced on the

stock belonging to their nation, then all customers

shall get event’s benefits as stock only. This is

represented in the rule labeled as <divMkt1>. The

rule with label <divMk2> indicates that dividend

event announced will not entail any benefits to clients

from stock market Mkt2. The last rule is an exception

to rule <divMkt1> - it says that if client hails from the

stock market, Mkt5 then he is eligible for benefit in

the form of cash rather than stock.

The above-mentioned rules were then verified

against facts from real-world as below:

event(11, dividend, samsung);

event(22, dividend, dell);

baseCntry(dell, US);

holds(abc, samsung);

holds(abc, dell);

holds(xyz, dell);

holds(pqr, dell);

clientCntry(xyz,Mkt2);

clientCntry(pqr, Mkt5);

opts(abc, both);

In the absence of any kind of prioritization amongst

multiple views, we got the validation results as:

distribute(pqr, 22, cash);

distribute(pqr, 22, stock);

distribute(xyz, 22, nothing);

distribute(xyz, 22, stock);

distribute(abc, 11, both);

distribute(abc, 22, both);

distribute(abc, 22, stock);

These results are not in line with what actual

happens in the stock market as one conclusion

indicates no benefit to xyz for event 22; whereas

next conclusion points out stock benefit to the same

client on the same event. When the multiple views

from stakeholders of different stock market were

assigned priorities (that can be easily modified or

updated later on too), the results obtained were as

per the expected benefits disbursed to the client in

stock market abiding terms and conditions:

overrides(divMkt1Mkt5,divMkt2)

overrides(divMkt1Mkt5,divMkt1)

overrides(divMkt1Mkt5,cash)

overrides(divMkt1Mkt5,stock)

overrides(divMkt1Mkt5,both)

and similar rules for rest of the markets including

the generic ones:

overrides(both,stock);

overrides(both,cash);

overrides(stock, cash);

MUTEX

distribute(?Client,?EventId,Value1)

AND

distribute(?Client,?EventId,?Value2)

GIVEN

notEquals( ?Value1, ?Value2 );

Validating the facts gathered earlier against the set

of labeled rules and the prioritized information,

consistent and expected results were obtained as:

HandlingInconsistencyinSoftwareRequirements

101

distribute(abc, 22, stock);

distribute(pqr, 22, cash);

distribute(abc, 11, both);

distribute(xyz, 22, nothing);

3.3 Observations

Courteous logic based representations can

sufficiently express software requirements with

reasoning and inferring mechanism as shown in

(Sharma and Biswas, 2011). We have explored the

inconsistency and presupposition concern in detail in

this paper. The advantage of the courteous logic

based requirements specification lies in following

observations:

1. It supports expressing conflicting information

in a way that is subjected to prioritized

conflict-handling. Any modification to the

priority rules is a matter of changing the

priorities.

2. Adding any information or removing any

information during requirements evolution

ensures consistency of the requirements

specification.

3. Having inference mechanism based FOL, it

allows validating the specifications against the

expected observable behavior of the system.

4. It provides assistance in identifying

presuppositions (tacit knowledge) in the

specified requirements.

5. Earlier detection of defects as well as any

disconnect between the client’s intent and the

requirements analyst’s interpretation.

We also observe that courteous logic based

requirements specifications have the potential to

improve requirements elicitation, management and

evolution. Point 5 leads to further noticing that

earlier detection of problems can considerably

reduce cost and time effort of the project and help in

keeping project schedule on time. Further, courteous

logic based requirements specifications can be

helpful in identifying and preparing test-cases. The

test-cases can be easily mapped to the rules present

in the courteous logic based requirements

specifications. The validation data can serve as the

starting base to test data.

4 RELATED WORK

The use of logic for requirements representation and

resolving inconsistency issue in software

requirements has been acknowledged earlier too and

has found its place in several authors’ work. RML

(Greenspan, Borgida and Mylopoulos, 1986) is one

of the earliest logic-based formal requirements

modeling language. Revamping efforts on RML

gave way to two more related languages –

Conceptual Modeling Language (CML) (Stanley,

1986) and Telos (Mylopoulos et al., 1990). HCLIE

language (Tsai and Weigert, 1991) is a predicate

logic-based requirement representation language. It

makes use of Horn clause logic, augmented with

multiple inheritances and exceptions. HCLIE

handles non-monotonic reasoning by not reporting

any consequence in case any conflict arises.

Description Logic has also been used for

representing requirements in (Zhang and Zhang,

2007). Description logic is an expressive fragment

of predicate logic and is good for capturing ontology

whereas, Horn clause logic is useful for capturing

rules. Ordinary Logic Programming (OLP) lacks in

conflict-handling or non-monotonic reasoning.

Default Logic form of non-monotonic reasoning has

also been used to reason about inconsistencies in

requirements in (Gervasi and Zowghi, 2005). The

computational complexity of default logic is high

and the expressions are not too easy and convenient

to comprehend.

Business rules do present themselves with many

instances of conflicts and presuppositions around

them. Handling business rules along with constraints

and related events as well as the semantics of rules

are of paramount importance in business processes.

To capture business rules successfully, Horn clause

logic needs to be augmented with non-monotonic

reasoning as has been discussed in (Borgida,

Greenspan and Mylopoulos, 1985) and, here we

have presented courteous logic based representations

towards the cause. Syntactical presuppositions have

been addressed in (Ma, Nuseibeh and et.al., 2009).

We have presented logical expressions as a solution

towards addressing semantic and pragmatic

presuppositions. The underlying essence and rational

of requirements and the corresponding contextual

meaning can be understood via some executable

model of requirements. We have presented such a

model in the form of courteous logic based

requirements representation.

5 THREATS TO VALIDATION

The logical expressions do offer a mechanism to

reason with the requirements and resolve relevant

issues. Nevertheless, these formal logical

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

102

expressions might pose usability problems to the

stakeholders as well as those developers who are not

fluent with the formal logic.

Even though the courteous logic representations

are more English-like with less usage of arrows and

symbols, still accepting a new approach is not very

encouraging until its benefits are realized. Secondly,

some amount of training would have to be imparted

to the involved parties in requirements phase in

order to make them understand the syntax and the

querying mechanism. Third, translating the

requirements corpus to the courteous logic

expression would be time-consuming and would

depend on the individual’s expertise and skills.

Automated conversion from natural language to

these representations would certainly be an

advantage but doing that itself poses natural

language parsing challenge.

We still hope that benefits drawn from using

non-monotonic formal representations of

requirements will outweigh the threats.

Requirements of varying domains are of varied

nature and not one kind of model is able to

sufficiently express all the aspects of the system. A

domain which is rule-intensive and has multiple

conflicting views and requirements would certainly

be benefitted by courteous logic based

specifications.

6 CONCLUSIONS

In this paper, we have successfully addressed the

problem of identifying and analyzing the logical

inconsistency in the software requirements using

courteous logic based requirements specifications in

our work. We have shown that these specifications,

being an executable model of the system’s

requirements, not just identify implicit

inconsistencies but also help in identifying and

specifying presuppositions explicitly. The results

from the case-studies are encouraging. Tractable

inferencing and scalability of the representations are

some of the motivating factors towards using

courteous logic based specifications. We have also

demonstrated that fixing the inconsistency by rule-

prioritization does not entail a major change in the

existing requirements specification. This aspect

makes these expressions a suitable choice from

software maintenance point of view. Though the

requirements analysts might not find the idea of

using courteous logic comfortable, but since these

representations are relatively simpler; easy to

comprehend and natural language like, we hope that

with small amount of training these could be well-

taken by the practitioners as well.

We further aim to refine the current proposed

requirements representations and incorporate the

second interpretation of inconsistency – traceability;

and then develop a semantic framework for

automated analysis of requirements. We see our

framework as a foundation towards integrated

framework for semantic software engineering.

REFERENCES

IEEE Computer Society, 1998. IEEE Recommended

Practice for Software Requirements Specification,

IEEE Std 830 – 1998(R2009).

Zowghi, D., 2003. On the Interplay Between Consistency,

Completeness, and Correctness in Requirements

Evolution. In Information and Technology, Vol 45,

Issue 14, 2003, pp 993-1009.

Ma, L., Nuseibeh, B., Piwek, P., Roeck, A.D. and Willis,

A., 2009. On Presuppositions in Requirements. In

Proc International Workshop on Managing

Requirements Knowledge, pp.68–73

Tsai, J. J. P., Weigert, T. and Jang, H.,1992. A Hybrid

Knowledge Representation as a Basis of Requirements

Specifciation and Specification Analysis. In IEEE

Transaction on Software Engg, vol. 18, No 12, 1992,

pp. 1076–1100.

Gervasi, V. and Zowghi, D., 2005. Reasoning about

Inconsistencies in Natural Language Requirements. In

ACM Transactions on Software Engg and

Methodology, Vol 14, No 3, 2005, pp. 277-330.

Levinson, S. C., 2000. Pragmatics, Cambridge University

Press.

Sharma, R. and Biswas, K.K. 2011. Using Courteous

Logic based representatiosn for Requirements

Specifications. In International Workshop on

Managing Requirements Knowledge.

Grosof, B.N., 1997. Courteous Logic Programs:

prioritized conflict handling for rules. IBM Research

Report RC20836, IBM Research Division, T.J. Watson

Research Centre.

Grosof, B.N., 2004. Representing E-Commerce Rules via

situated courteous logic programs in RuleML.

Electronic Commerce Research and Applications, Vol

3, Issue 1, Spring 2004, pp 2-20.

Greenspan, S., Borgida, A. and Mylopoulos, J.,1986. A

Requirements Modleing Language and its logic,

Information Systems, vol 11, no 1, 1986, pp 9-23.

Stanley, M., 1986. CML: A Knowledge Representation

Language with Applications to Requirements

Modeling, M.Sc. Thesis, Dept Comp. Sc., University

of Troronto.

Mylopoulos, J., Borgida, A. and Koubarakis, M.,1990.

Telos: Representing Knowledge about Information

Systems, ACM Transactions on Information Systems,

1990.

HandlingInconsistencyinSoftwareRequirements

103

Tsai, Jeffrey J.-P. and Weigert, T.,1991. HCLIE: a logic-

based requirement language for new software

engineering paradigms, Software Engineering, vol 6,

issue 4, July 1991, pp 137-151.

Zhang, Y. and Zhang W., 2007. Description Logic

Representation for Requirement Specification, Proc

International Confernce on Computational Science

(ICCS 2007), Part II, Springer-Verlag, pp 1147 –

1154.

Borgida, A., Greenspan, S. and Mylopoulos, J., 1985.

Knowledge Representation as the basis for

Requirements Specifications, Computer, vol 18, no 4,

Apr. 1985, pp 82-91..

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

104
