PSO-based Linear SVM Classifier Selection for Credit Risk

Evaluation Modeling Process

Paulius Danenas and Gintautas Garsva

Department of Informatics, Kaunas Faculty, Vilnius University, Muitines St. 8, LT- 44280 Kaunas, Lithuania

Keywords: Support Vector Machines, Linear SVM, Particle Swarm Optimization, Credit Risk, Evaluation, Bankruptcy,

Machine Learning

Abstract: A research on credit risk evaluation modelling using linear Support Vector Machines (SVM) classifiers is

proposed in this paper. The classifier selection is automated using Particle Swarm Optimization technique.

Sliding window approach is applied for testing classifier performance, together with other techniques such

as discriminant analysis based scoring for evaluation of financial instances and correlation-based feature

selection. The developed classifier is applied and tested on real bankruptcy data showing promising results.

1 INTRODUCTION

Credit risk evaluation is defined as one of the most

important domains in financial sector as it shows the

ability to regenerate income by lending money; yet,

calculation of the possibility to get back the money

invested is the most critical problem. Machine

learning and artificial intelligence techniques are

novel and state-of-the-art methods which help to

develop tools for this problem by overcoming the

drawbacks of statistical tools and deriving more

robust and accurate solutions.

Discriminant analysis was one of the first

techniques applied in credit evaluation (Altman,

1968). Support Vector Machines (SVM) classifiers

gained a lot of attention as they showed abilities to

get classification results comparable to Neural

Networks but avoiding their main difficulties such as

local minimas. Selection of hyperparameters is a

sophisticated task thus various metaheuristic and

evolutionary techniques have been adopted for

solving this task including swarm intelligence

techniques such as Ant colony Optimization (Zhou

et al, 2007). Particle Swarm Optimization (abbr.

PSO) has previously been applied for SVM

optimization in credit risk domain – personal credit

scoring (Xuchuan et. al, 2007), financial distress

prediction (Chen et al., 2010; Wang, 2010),

consumer credit scoring analysis (Yun et al., 2011).

Linear SVM (LIBLINEAR) has also been tested to

show competitive results to original C-SVC

classifier (Danenas et. al, 2010; Danenas et al,

2011), which proved that they can be a good

alternative in terms of both complexity and speed.

According to these aspects, linear SVM and PSO are

selected for model development. The research

presented in this paper proposes a hybrid method

based on linear Support Vector Machines

classification and Particle Swarm Optimization. The

proposed method is also tested in “sliding window”

approach manner, which means that it can be useful

to identify more general trends. Moreover, proposed

approach might be useful while trying to improve

the performance of these methods by identifying the

most relevant financial attributes and developing a

new classifier based on that particular technique.

2 USED METHODS

Support Vector Machines (SVM). SVM solves

following quadratic minimization problem:

),(

min

111

jiji

Kyy xx

ααα

∑∑∑

===

+−

lll

subject to

Ciy i

ii ≤≤∀=

∑

αα

0:,0

where the number of training examples is denoted

by l, training vectors

, 1,..,i

Ri l

∈

and a vector

∈

such as

[1;1]iy

∈

−

. α is avector of l values

where each component α

corresponds to a training

example (x

, y

). If training vectors x

are not linearly

338

Danenas P. and Garsva G..

PSO-based Linear SVM Classiﬁer Selection for Credit Risk Evaluation Modeling Process.

DOI: 10.5220/0004006403380341

In Proceedings of the 14th International Conference on Enterprise Information Systems (ICEIS-2012), pages 338-341

ISBN: 978-989-8565-10-5

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

separable, they are mapped into a higher (maybe

infinite) dimensional space by the kernel function

(, ) () ()

xx x x

φφ

≡

Fan et al. (Fan et al., 2008) proposed a family of

linear SVM and logistic regression classifiers for

large-scale SVM classification which do not use

kernel functions for transformation into other

dimensional space; although with less flexibility, it

can perform effectively especially using large

amounts of data. The formulations of the algorithms

by are given in the paper of Fan et al.; four of them

(L2-regularized L1-loss SVC, L2-regularized L2-

loss SVC, L2-regularized logistic regression, L1-

regularized L2-loss SVC) are used in the

experiment. These classifiers are formulated as

minimization problems, but they all share the

concept of cost parameter C and bias usage. This

proposes a possibility for heuristic selection of

classifiers themselves.

Particle Swarm Optimization (PSO). The PSO

algorithm, introduced by Kennedy and Eberhart, is

based on behavior of flock of birds which search for

food randomly in some area, knowing only the

distance from the food. Thus all the particles have

one fitness PSO is expressed in terms of particles

(birds) and searched target described by fitness

value; the location of each particle is determined by

velocity describing its flying direction and distance.

Two extreme values are tracked by each particle -

the optimal solution found by the particle itself

(pbest), and the optimal solution found by the whole

swarm (gbest). Unmodified PSO algorithm is used

in this research, thus its details are not presented in

this paper, but can be found in other sources, such as

(Kennedy et al., 2001).

2.1 PSO Approach for Linear SVM

Optimization

A classification technique based on Particle Swarm

Optimization and linear SVM combination, namely

PSO-LinSVM is proposed in this paper. Each

particle P = <p

> is represented as follows:

– integer value, that represents the algorithm

used for classification:

0 - L2-regularized logistic regression

1 – L2-regularized L2-loss SVC

2 – L1-regularized L2-loss SVC

3 - L2-regularized L1-loss SVC

– real value, cost parameter C

–real value, which represents bias term

The fitness function is defined as maximization of

sum of TPR values:

∑

)(

TPRfitnessf

where N

is the number of classes. Most of the

authors (Wang, Chin et al.) choose accuracy for

fitness evaluation; however, in case of imbalanced

learning, accuracy is not the best option, so sum of

TP rate values is selected for this case, which allows

selection of classifier that balances between

identification of both “majority” and “minority”

classes. These evaluations are obtained by

performing k-fold cross-validation training; k is

considered to be quite small (k = 5 is used for the

experiment), considering the amount of data used in

research. The optimal solution can be obtained only

in case of perfect classification; as this happens very

rarely, the main goal is to find best satisfactory

solution.

2.2 Sliding Window Testing Approach

This research adopts techniques used earlier by

Danenas et al. (Danenas et al., 2010; Danenas et al.,

2011), extending it with PSO application for

classifier optimization step. Thus the modified

algorithm is defined as follows:

Evaluate each financial entry manually or by

using expert techniques to compute bankruptcy

classes (discriminant models used in banking are

sued in this research).

Apply data preprocessing steps – elimination of

unevaluated instances, data imputation and

standardization.

Perform the following steps for each

],1[ knm

−

∈

, where n is the total number of

periods, k is the number of periods are used for

forecasting:

Feature selection;

Classifier and parameter selection, using

Particle Swarm Optimization;

Train classifier using data from first m periods.

Apply hold-out testing using data from period

∈

pkmmp ];,1[

Note, that feature selection step is important for 2

reasons:

1. Quality and complexity - data dimensionality

reduction;

2. Ratio importance - a new classifier based on

other evaluator but using a set of statistically

significant attributes obtained from the data is

developed.

The output of each iteration in experimental stage

is the trained classifier and the list of selected

PSO-basedLinearSVMClassifierSelectionforCreditRiskEvaluationModelingProcess

339

attributes for each period.

3 EXPERIMENT RESULTS

3.1 Data used in the Experiment

The dataset that was applied for the experiment

consists of entries from 785 USA Transportation,

Communications, Electric, Gas, And Sanitary

Services companies with their 1999-2008 yearly

financial records (balance and income statement)

from financial EDGAR database.

Each instance has 51 financial attributes (indices

used in financial analysis). “Risky” and “Non-

Risky” classes were formed using Zmijewski’s

scoring technique widely used in banking.

Table 1: Main characteristics of datasets used in

experiments.

Year

Entries labeled as

Total entries

No of selected

attributes

Bankrupt 1

years after

Bankrupt >1

year after

Risky (R)

Not risky

(NR)

1999 376 166 542 11 - -

2000 423 192 615 8 0 0

2001 383 226 609 13 2 1

2002 376 239 615 11 1 0

2003 417 220 637 9 0 0

2004 460 194 654 9 1 1

2005 478 173 651 8 1 4

2006 375 118 493 8 0 1

2007 367 112 479 11 0 6

2008 38 12 50 8 - -

Total 3693 1652 5345 5 13

Note that ratios in original Zmijewski were not used

in order to avoid linear dependence between

variables. Main characteristics of the datasets

formed for the experiment are presented in Table 1.

It also shows financial ratios which were considered

relevant by feature selection procedure; the number

of such features is larger than the ones which are

considered in original evaluator.

3.2 Computational Results

Correlation-based feature subset selection (Hall,

2001) algorithm with Tabu search for search in

attribute subsets was applied for feature selection.

The search space for PSO was set

]50;0[

∈

]1;0[

∈

bias

, as well as the number of

run iterations was set to 10. PSO was configured to

run with 20 particles and inertia rate of 0.8. Velocity

for p

was set to 3, for p

was set to 0.2.

Table 2 presents the results obtained by PSO-

LinSVM classifier: classifier parameters, obtained

by PSO, classification accuracy together with True

Positive and F-Measure rates for each class. It is

clear that classification accuracy did not show stable

increase while providing the classifier with more

data each year. While performing testing procedure

with first year data, accuracy decreased to 80% in

2004 although next year it returned to 83.8% was

relatively stable, and later in fell to 82%; similar

trends might be identified while analyzing testing

results obtained with Year 2 and Year 3 data. It is

important to note that instances marked as “risky”

were identified better.

Table 2: Experimental classification results.

Training period 2000 2001 2002 2003 2004 2005 2006 2007

Linear classifier

L1-SVM

(dual)

L2-SVM

(dual)

L2-SVM

(dual)

L2-RLR

L2-SVM

(primal)

L2-SVM

(dual)

L2-SVM

(dual)

L2-

SVM

(primal)

C 15,3157 47,8343 24,7346 29,0490 22,3727 38,0860 6,5322 48,0734

Bias 1,000 0,196 0,749 0,797 0,873 0,838 0,436 0,508

Accuracy 77,941 78,409 80,220 83,689 80,640 83,806 82,887 82,000

Year 1

R 0,969 0,952 0,981 0,987 0,952 0,957 0,970 0,974

NR 0,461 0,521 0,464 0,482 0,412 0,462 0,385 0,333

F-Measure

R 0,846 0,843 0,867 0,895 0,878 0,900 0,896 0,892

NR 0,609 0,653 0,618 0,637 0,535 0,579 0,520 0,471

Year 2

Accuracy 80,032 77,080 84,146 83,232 83,806 84,742 82,000 -

R 0,979 0,947 0,985 0,990 0,957 0,959 0,974 -

NR 0,521 0,436 0,503 0,407 0,462 0,496 0,333 -

F-Measure

R 0,857 0,844 0,897 0,896 0,900 0,905 0,892 -

NR 0,670 0,568 0,653 0,567 0,579 0,611 0,471 -

Year 3

Accuracy 77,237 80,488 83,384 86,032 84,124 84,000 - -

R 0,966 0,952 0,987 0,987 0,967 0,974 - -

NR 0,405 0,456 0,418 0,462 0,444 0,417 - -

F-Measure

R 0,848 0,873 0,897 0,915 0,902 0,902 - -

NR 0,551 0,582 0,576 0,615 0,575 0,556 - -

verage testing accuracy 78,403 78,660 82,583 84,318 82,857 84,183 82,444 82

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

340

4 CONCLUSIONS AND FUTURE

DEVELOPMENT

This paper presents an approach for credit risk

evaluation using linear SVM classifiers, selected and

optimized by Particle Swarm Optimization,

combined with sliding window testing technique and

feature selection using correlation analysis. Linear

SVM classifiers perform well when applied to large

scale problems; this is one of the main reasons why

they were selected as classification technique. The

developed classifiers were applied for real-world

dataset, combined with widely applied Zmijewski

technique as an evaluator and basis for output

formation. Analysis of experimental results shows

that the performance still needs to be improved to be

more stable and reliable. Particle Swarm

Optimization topology has not been investigated in

this research, thus further steps will involve more

detailed investigation into PSO performance.

Imbalanced learning is another field where

significant improvements might lead to increase in

overall performance; this procedure is especially

important if labelling is done automatically (as, in

our case, using Zmijewski’s model), as this might

lead to highly imbalanced datasets. Notably,

misidentification of bankrupt company might cost

more to the creditor than the misdentification of

“healthy” one, thus this problem is especially

important if there are much less bankrupt companies

or companies with high risk than companies which

belong to another classes.

REFERENCES

Altman, E., 1968. Financial ratios, discriminant analysis

and the prediction of corporate bankruptcy. In The

Journal of Finance, Vol. 23 (4), pp.589–-609.

American Finance Association; Blackwell Publishing

Chen, C.-Y., Chen, M.-Y., Hsieh C.-H., 2010. A Financial

Distress Prediction System Construction based on

Particles Swarm Optimization and Support Vector

Machines. In Proceedings of 2010 International

Conference on E-business, Management and

Economics (IPEDR), Vol.3, IACSIT Press, Hong

Kong pp. 165-169.

Danenas P., Garsva G., 2010. Credit risk evaluation using

SVM-based classifier. In Lecture notes in Business

Information Processing, Heidelberg: Springer-Verlag

Vol. 57, Part 1, 2010, pp. 7-12, Springer.

Danenas P., Garsva G., Gudas S., 2011. Credit Risk

Evaluation Model Development Using Support Vector

Based Classifiers. In Proceedings of the International

Conference on Computational Science (ICCS 2011),

Vol. 4, pp. 1699-1707, Procedia Computer Science.

Fan, R., Chang, K., Hsieh, C., Wang, X., Lin, C., 2008.

LIBLINEAR: A library for large linear classification,

In The Journal of Machine Learning Research, Vol. 9,

pp.1871–4.

Hall, M.A. Correlation-based Feature Subset Selection for

Machine Learning. Hamilton, New Zealand (1998)

JSwarm-PSO: Swarm optimization package,

http://jswarm-pso.sourceforge.net/

Kennedy, J., Eberhart, R. C., Shi, Y. Swarm intelligence.

Morgan Kaufmann Publishers, 2001.

Weka 3: Data Mining Software in Java,

http://www.cs.waikato.ac.nz/ml/weka/

Wang X., 2010. Corporate Financial Warning Model

Based on PSO and SVM. In 2010 2nd International

Conference on Information Engineering and

Computer Science (ICIECS), Wuhan, pp.1-5.

Xuchuan, J.M.Y., 2007. Construction and Application of

PSO-SVM Model for Personal Credit Scoring. Proc.

of the 7th international conference on Computational

Science, ICCS ’07, Part IV, pp. 158-161.

Yun, L., Cao Q.-Y.; Zhang H., 2011. Application of the

PSO-SVM Model for Credit Scoring. Proceedings of

Seventh International Conference on Computational

Intelligence and Security (CIS), pp.47-51.

Zhou J., Zhang A., Bai T., 2008. Client Classification on

Credit Risk Using Rough Set Theory and ACO-Based

Support Vector Machine. In: Proceedings of Wireless

Communications, Networking and Mobile Computing

(WiCOM '08), pp.1-4

Zmijewski, M,, 1984. Methodological Issues Related to

the Estimation of Financial Distress Prediction

Models. In Journal of Accounting Research, Vol. 22,

pp. 59–82.

PSO-basedLinearSVMClassifierSelectionforCreditRiskEvaluationModelingProcess

341
