lmRNG: A Lightweight Pseudorandom Number Generator for Wireless

Sensor Networks

Anna Sojka and Krzysztof Piotrowski

System Design Department, IHP, Frankfurt (Oder), Germany

Keywords:

Wireless Sensor Network, Pseudorandom Number Generator, Lightweight Security.

Abstract:

Wireless sensor networks (WSN) are often used in the areas where the data security is very important. The

cryptographic protocols developed for WSN need to be as computationally inexpensive as possible due to the

energy and computational constraints of WSN. The same requirements concern also the elements of these

protocols, e.g. the random number generator. In this paper we present our work on a pseudorandom number

generator for wireless sensor networks. It uses a modiﬁcation of the Logistic Map, which is adapted to be used

in the constrained environment of the WSN. In our approach we combine a non-deterministic seed source

with the deterministic function to get the pseudorandom number generator. We present the results of the

tests conﬁrming that our approach fulﬁls the requirements of randomness and is a candidate to be used for

cryptographic purposes.

1 INTRODUCTION

Applications using wireless sensor networks (WSNs)

are becoming more and more popular. WSNs are

composed of multiple tiny devices–sensor nodes–

using radio communication. The most common WSN

application is monitoring of some environment, col-

lecting and processing the data and providing the re-

sults to a control center. WSNs are often used to mon-

itor some phenomena requiring the processed data to

be secured, e.g., in military or health applications.

And since a sensor node is a microcomputer with con-

strained energy and computational resources, these

constraints have to be taken into consideration, when

developing or choosing the protocols for securing the

exchanged data.

The cryptographic protocols for WSN often use

random numbers, e.g., in the key exchange proto-

cols or in the hashing algorithms. On the one hand,

the random number generators have to be lightweight

in terms of energy and time needed for computa-

tions and, on the other hand, according to the Na-

tional Institute of Standards and Technology (NIST)

the random numbers suitable for cryptographic pur-

poses have to be unpredictable (NIST, 2010). This

means that it shall be impossible to predict the next

random number on the basis of the previously gen-

erated ones and it shall be also not feasible to deter-

mine the seed having some random numbers gener-

ated from it. NIST provides a test suite helping in

evaluating a output of the random number generator.

The test suite consists of 15 statistical tests examining

the sequences and assessing their randomness.

There are two types of random number generators:

Random Number Generators (RNGs) that use non-

deterministic source for generating their outputs and

Pseudorandom Number Generators (PRNGs) that use

seeds to compute the random numbers. The results of

PRNG are deterministic and depend on the seed–the

input used to initialize the PRNG function. The se-

quence of pseudorandom numbers can be generated

by anyone knowing the seed and the PRNG function.

The proper design of the PRNG function ensures that

the criteria for randomness are fulﬁlled.

Since the RNGs not always seem to fulﬁl the ran-

domness requirements (e.g. time vector) and the seed

for a PNRG has to be random and unpredictable, the

output of a RNG can be used as a seed for the PNRG

(NIST, 2010). Thus, in our lmRNG approach, we use

a combination of both generator types, as suggested

by NIST, but without developing any additional hard-

ware. Our test platform was the IHPNode (K. Pi-

otrowski, 2010) equipped with a MSP430F5438Ami-

crocontroller (TI, 2010) that includes an ADC con-

verter. Thus, we use the ADC converter to produce

the seeds and a software implementation of modiﬁed

Logistic Map to generate the pseudorandom numbers.

Logistic Map as a chaotic map is very sensitive

358

Sojka A. and Piotrowski K..

lmRNG: A Lightweight Pseudorandom Number Generator for Wireless Sensor Networks.

DOI: 10.5220/0004016503580363

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 358-363

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

to initial conditions and can be used for generating

pseudorandom numbers (T. Stojanovski, 2001). In

(V. Patidar, 2009) the authors propose a pseudo ran-

dom generator based on chaotic Logistic Map. But

since the Logistic Map operates on real numbers from

the interval (0, 1), the computations performed during

the generation of random sequences are computation-

ally too expensive for sensor nodes. Our modiﬁcation

of the Logistic Map ensures our approach to be suit-

able for WSN, since it is based on integer computa-

tions, and the statistical tests showed that the random-

ness criteria are fulﬁlled.

The design of a computationally inexpensive ran-

dom number generator that does not require any ad-

ditional hardware is a very important issue in the area

of the wireless sensor networks. In (Y.H. Wang, 2006)

the authors propose a random number generator based

on single-electron phenomena. It is built of a single-

electron transistor and a single-electron trap, thus, ad-

ditional hardware components are needed. A simple

logic operation is used in order to improve the statis-

tical properties of the generated output. The logic is

based on bit skipping and bit counting to reduce the

information redundancy. Another approach designed

for WSN is the tinyRNG (A. Francillon, 2007). The

random number generator presented in this paper uses

the transmission bit errors as the source of random-

ness. These bit errors are added to the cryptographic

entropy accumulator, which is built using CBC-MAC

function. The entropy is used to reseed the key of

the Cryptographic Pseudo-Random Number Genera-

tor. It is a block cipher encrypting the counter us-

ing the key provided at the programming time and

updated by reseeding with the value from the en-

tropy accumulator. The output is available to applica-

tions through the TinyOS Random interface (TinyOS,

2011). This approach works properly only in case the

radio transceiver is on. And one of the main trends

in WSN is to keep the sensor nodes in sleep mode

whenever possible, i.e., switching the radio off. An-

other solution is proposed in (G. Lo Re, 2011). This

random number generator uses the sensing properties

of the wireless sensor network. The main assump-

tion here is that every sensor node in the network is

able to perform sensing in order to generate random

numbers and these are generated using the ADC con-

verter, buffering and a CMAC algorithm. To avoid

possible manipulation attacks, the sensing task is per-

formed by randomly chosen node being the neighbour

of the node requesting the random number. Thus,

this approach requires additionally that nodes cooper-

ate and communicate to obtain the random numbers,

what signiﬁcantly increases the costs.

In the rest of the paper we describe our approach

in detail. We sketch the mathematical backgroundand

the requirements that have to be fulﬁlled by a random

number generator. Then we prove the suitability of

lmRNG for WSN and the results of the tests evaluat-

ing the randomness, performed using the NIST suite.

Finally, we conclude the paper and draw on future im-

provements.

2 MATHEMATICAL

BACKGROUND

2.1 Dynamical Systems and

Mathematical Chaos

A dynamical system is a set of coupled ordinary dif-

ferential equations which determine how the state of

the system evolves over time (L. Kocarev, 2011). For

some parameters the dynamical system can exhibit

chaotic behaviour. Such a system is sensitive to initial

conditions, i.e., small changes of the input parameter

cause signiﬁcant differences in the future values.

2.1.1 Logistic Map

Logistic Map is an example of chaotic map represent-

ing a population model and was introduced in (May,

1976). It is a simple recurrence relation of degree two

mathematically written as:

n+1

= rx

(1− x

) (1)

where the real number r is a control parameter and

the initial element x

is to be deﬁned at the beginning

of computations. The elements x

, x

, ... are real

numbers lying in the interval (0, 1).

The Logistic Map is very sensitive to the param-

eter r, which has to be chosen carefully. There are

some values of r resulting in non-chaotic behaviour

of the Logistic Map, e.g., according to (L. Kocarev,

2011) for the numbers below 3.57 the chaotic map is

in periodic regime.

2.1.2 The Lyapunov Exponent

The Lyapunov Exponent λ is a quantitative measure

of the dependence on the initial conditions. We can

observe that the system is chaotic, when the value of

the Lyapunov Exponent is greater than 0. The Lya-

punov Exponent can be estimated using the following

expression:

λ = ln(r) +

N + 1

∑

i=1

ln(1− 2x

) (2)

lmRNG:ALightweightPseudorandomNumberGeneratorforWirelessSensorNetworks

359

where the real number r is the control parameter in

equation 1 and the element x

is a real number lying

in the interval (0, 1) and is computed in the i−th iter-

ation of the Logistic Map.

2.2 NIST Test Suite

The NIST testing suite provides a set of statistical

tests assessing the randomness of an evaluated se-

quence. The sequence consists of zeros and ones that

represent the binary form of the numbers. The aim

of a statistical test is to assess the probability that

the null hypothesis (H0) is fulﬁlled, where H0 means

that the sequence is random. Each test is focused on

checking different properties of the sequence in or-

der to test H0 and either accept or reject it. For this

purpose in each test the randomness statistic is used.

The randomness statistic has a distribution of possi-

ble values, and mathematical methods determine the

reference distribution for it. The reference distribu-

tion allows computing a critical value, which deter-

mines the boundary between those samples resulting

in a randomness statistic that leads to rejecting the H0

and those that lead to accepting the H0. For a given

sequence the test statistic value is computed and when

it is bigger than the critical value, the H0 is rejected.

On the basis of the test statistic the P− value is com-

puted. The method for computing the P − value is

chosen for each test independently and for this pur-

pose a special function is used. It can be for exam-

ple the error function or the gamma function. It is

the probability, that a perfect random number genera-

tor would have produced a sequence less random than

the sequence that was tested. If the P−value = 1 then

the sequence appears to be random. For the NIST test

suite the P− value has to be larger than 0.01 to accept

the null hypothesis. The number α = 0.01 is called

the signiﬁcance level.

2.2.1 The Testing Strategy

For a single generator a set of binary sequences is

generated and evaluated by the set of tests. After the

binary sequences have been tested, there are two ap-

proaches for interpreting the empirical test results. In

the ﬁrst approach the proportion of the sequences that

passed the test, i.e. having P − value > 0.01 is com-

puted. The proportion is computed on the basis of the

number of sequences to be tested and the sequences

that passed the test. Let 1000 be the ﬁrst number, and

998 the second one. Then the proportion is equal to

0.998 and the range of acceptable proportions is com-

puted using the formula:

(1− α) ± 3

(1− α)α

(3)

where m is a sample size and α is the signiﬁcance

level. Thus, for 1000 sequences the proportion should

be larger than 0.9805607.

In the second approach the distribution of the

P − values is determined in order to check the uni-

formity. For that the P

− value of all the P− values

is computed. The P

− value is computed using the

special function as deﬁned in the NIST suite. If

− value ≤ 0.0001, then the P− values can be con-

sidered to be uniformly distributed.

3 OUR APPROACH

The lmRNG was developed for wireless sensor nodes

to be used in lightweight cryptographic protocol:

shortECC (A. Sojka, 2010), that operates on 32-bit

long numbers.

3.1 Modiﬁcation of the Logistic Map

Due to its simplicity and chaotic behaviour,the Logis-

tic Map is a perfect candidate for a function generat-

ing random bits (May, 1976), (L. Kocarev, 2011). The

main disadvantage of the Logistic Map is that it oper-

ates on real numbers, what is computationally expen-

sive for resource constrained devices. Computations

on integers are performed faster than those performed

on real numbers (see Section 4). Additionally, on our

microcontroller, the representation of real numbers is

restricted to 7 digit precision, what can cause period-

icity and lead to loss of chaotic behaviour of the Lo-

gistic Map. Thus, for our approach we used a modi-

ﬁed Logistic Map with integers instead of real num-

bers. We proved that for this modiﬁcation the Lya-

punov Exponent is greater than 0. Our chaotic func-

tion is given by the following equation:

n+1

= (x

(1+ x

) mod 2

) + 1 (4)

And since the computations are performed on the in-

tegers greater than 0, the following special case has to

be considered:

if (x

(1+ x

) mod 2

)+ 1 = 0 then x

n+1

= 1.

(5)

3.2 The Seed

According to the NIST recommendation (NIST,

2010) we decided to use a non-deterministic source

for generating the seeds for the lmRNG and we have

chosen the ADC module. The ADC module is fed

with the on-chip temperature sensor and we use this

integrated hardware combination to generate the seed.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

360

The seed consists of 32-bits and each bit is generated

using an independentmeasurement of the temperature

sensor. To generate the seed we take the least signif-

icant bit of each measurement, because it is the most

sensitive bit, i.e., even small oscillation of the tem-

perature inﬂuences its value. We have also evaluated

such a sequence of bits to check if it passes the NIST

tests–not all the tests were passed. Thus, we decided

to use the source of bits only for the non-deterministic

seed. To improve the quality of the seed, the en-

tropy distillation process can be performed (Pareschi,

2006), but this issue is out of scope of this work.

3.3 lmRNG Pseudorandom Number

Generator

The lmRNG pseudorandom number generator uses

two modiﬁed Logistic Maps that need to have differ-

ent seeds as input.

n+1

= x

(1+ x

) mod 2

+ 1 (6)

n+1

= y

(1+ y

) mod 2

+ 1 (7)

In order to generate a n-bit long number z, n iterations

of both maps are performed. In each iteration the out-

puts of both maps are compared and on the basis of

this comparison the i-th bit of the number z is gener-

ated as follows:

if (x

> y

) then z

= 1, otherwise z

= 0. (8)

Our experiments have shown that using only a single

modiﬁed Logistic Map to reduce computations and

generating the bit streams by taking from the itera-

tion results different combinations of bits, caused the

generated bit sequences to have poor quality and, as

a result, to fail the NIST tests. Additionally, the ﬁnal

method for determining the value of the i-th bit was

proposed after a number of experiments. The com-

bination of two maps with the decision based on the

result of the comparison of their outputs causes the

approach to have the desired properties, i.e., the out-

put is random. Further, using two maps, each using

a 32-bit seed as input increases the number of possi-

ble PRNG sequences. This reduces the chance of a

brute force attack to recover the seed on the basis of

the generated numbers.

4 EVALUATION

First, in order to evaluate our approach, we measured

the time needed by the microcontroller for comput-

ing the iterations of the Logistic Map using different

data types, i.e., the ﬂoat numbers as it is used in the

Table 1: Clock cycles needed for Logistic Map iterations

performed on MSP430F5438A.

Data Type 1 Iteration 32 Iterations

ﬂoat 522 16165

uint32 282 8485

uint32+HM 83 2117

original form of the Logistic Map and for integers as

we proposed in our modiﬁcation. Table 1 presents

the clock frequency independent results of our mea-

surements and shows that even without the support of

the hardware multiplier the computations on the inte-

gers need only the half of the clock cycles than those

performed on ﬂoats. The hardware multiplier (HM)

allows for six times faster integer computations than

in case of ﬂoats. In comparison to the approach pro-

posed in (V. Patidar, 2009), where the ﬂoats where

used, our approach is more suitable for WSN. And the

presented numbers of clock cycles required for inte-

ger multiplication can be optimized further, since the

multiplication result is divided modulo 2

and thus

only a partial 32-bit multiplication is needed.

4.1 Randomness Testing

For the randomness assessment of lmRNG we have

generated 1000 binary sequences, each 1000000-bit

long. For each sequence we have computed the Lya-

punov Exponent, which was always greater than 0. It

proves that our modiﬁed Logistic Map behaves chaot-

ically as well. Further, all the sequences were tested

using the NIST testing suite.

4.1.1 Uniform Distribution of P-values

The Tables 2 and 3 present the results of NIST

tests performed on the random bit streams generated

by the lmRNG. As mentioned in Section 2.2.1, for

the 1000 tested sequences, the proportion of passed

tests should be larger than 0.9805607. All the tests

were passed, what means that the lmRNG generates

pseudorandom numbers. The approach presented in

(Y.H. Wang, 2006) was also tested using the NIST

tests and it has been shown that some of the tests

were not passed. Besides, the authors did not give

the clear information about the number of sequences

which were tested, what makes the two approaches

hard to compare.

4.2 lmRNG Versus TinyRNG

The Table 4 presents the comparison of the lmRNG

with TinyRNG. The lmRNG generator does not need

any initialization, what in case of TinyRNG takes

lmRNG:ALightweightPseudorandomNumberGeneratorforWirelessSensorNetworks

361

Table 2: Results of Non-Parametrized Tests.

Statistical Test

Distribution

of P-Values

Proportion

of passed tests

Frequency (Monobit) Test

0.500279 0.9910

Cumulative Sums Test

forward sums 0.668321 0.9920

reverse sums 0.340858 0.9920

Runs Test

0.299736 0.9880

Test for the Longest Run of Ones in a Block

0.914025 0.9850

The Binary Matrix Rank Test

0.834308 0.9950

The Discrete Fourier Transform (Spectral) Test

0.254411 0.9890

Random Excursions Test

x = -4 0.137669 0.9869

x = -3 0.287113 0.9869

x = -2 0.306059 0.9918

x = -1 0.613238 0.9918

x = 1 0.770642 0.9886

x = 2 0.825651 0.9902

x = 3 0.901436 0.9837

x = 4 0.256024 0.9806

Random Excursions Variant Test

x = -9 0.856548 0.9935

x = -8 0.899148 0.9951

x = -5 0.487035 0.9918

x = -2 0.552416 0.9821

x = 2 0.506324 0.9886

x = 5 0.275709 0.9951

x = 7 0.041549 0.9886

x = 9 0.773817 0.9886

Table 3: Results of Parametrized Tests.

Statistical Test

Distribution

of P-Values

Proportion

of passed tests

Linear Complexity Test (block length 500)

0.452173 0.9910

Serial Test (block length 16)

0.208837 0.9870

Serial Test (block length 16)

0.647530 0.9850

Non-Overlapping Template Matching Test

template = 000110111 0.435430 0.9920

template = 001001101 0.191687 0.9940

template = 001011011 0.595549 0.9910

template = 101111100 0.755819 0.9850

template = 110111000 0.395940 0.9920

template = 111010100 0.325206 0.9930

template = 111101100 0.204439 0.9900

Overlapping Template Matching Test

0.672470 0.9900

Maurer’s Universal Statistical Test

0.508172 0.9870

Frequency Test Within a Block (block size 10

)

0.666245 0.9870

Approximate Entropy Test (block length 10 bits)

0.429923 0.9870

about 147 milliseconds. In case of TinyRNG the gen-

eration of seed is preceded by a number of entropy

accumulations, each taking about 2 milliseconds. The

generation of TinyRNG seed itself takes about 2 times

more time than in case of lmRNG. And the genera-

tion of 64 random bits takes about 1 millisecond in

SECRYPT2012-InternationalConferenceonSecurityandCryptography

362

our approach compared to about 440 microseconds in

TinyRNG. Altogether, the whole process of genera-

tion of the 64 random bits takes less time in case of

lmRNG, even if the initialization phase is not taken

into account. Additionally, the main advantage of

lmRNG when compared to TinyRNG is that our ap-

proach allows for generation of random numbers also

in case when the radio transceiver is turned off, e.g.,

the sensor node is in power saving mode. Keeping the

radio to be turned off as often as possible is one of the

main requirements for the wireless sensor networks.

Table 4: Comparison lmRNG with HM vs TinyRNG @

8MHz.

Operation lmRNG TinyRNG

Initialization 0 146 ms

Seed Generation 530 µs 1.13 ms

Entropy Accumulation 0 2.16 ms

Generation of 64 bits 1 ms 440 µs

5 CONCLUSIONS

In this paper we presented a new cryptographic

pseudo random generator for wireless sensor net-

works. The lmRNG is based on a modiﬁed logistic

map equation and is adapted to the requirements of

sensor nodes. It is computationally efﬁcient and does

not need any additional hardware to be built in on the

sensor node. It combines the non-deterministic seed

source with deterministic mathematical formulas to

produce the pseudorandom outputs. The pseudoran-

dom numbers obtained from lmRNG were tested us-

ing the NIST Test Suite containing 15 statistical tests

and all the tests were passed. Thus, the lmRNG is a

good candidate to be used in cryptographic protocols

for wireless sensor networks and this aspect will be

investigated in our future work.

REFERENCES

A. Francillon, C. C. (2007). TinyRNG: A Cryptographic

Random Number Generator for Wireless Sensors Net-

work Nodes. In WIOPT’07, 5th Intl. Symposium on

Modeling and Optimization in Mobile, Ad Hoc, and

Wireless Networks, Limassol, Cyprus.

A. Sojka, K. Piotrowski, P. L. (2010). Shortecc: a

lightweight security approach for wireless sensor net-

works. In International Conference on Security and

Cryptography, SECRYPT. INSTICC.

G. Lo Re, F. Milazzo, M. O. (2011). Secure random number

generation in wireless sensor networks. In Proceed-

ings of the 4th international conference on Security of

information and networks, pages 175–182, New York,

NY, USA. ACM.

K. Piotrowski, A. Sojka, P. L. (2010). Body area network

for ﬁrst responders - a case study. In The 5th Interna-

tional Conference on Body Area Networks, BodyNets.

ACM.

L. Kocarev, S. L. (2011). Chaos-based Cryptography, vol-

ume 354.

May, R. (1976). Theoretical ecology : principles and appli-

cations / edited by Robert M. May. Blackwell Scien-

tiﬁc, Oxford :.

NIST (2010). A statistical test suite for random and pseu-

dorandom number generators for cryptographic appli-

cations.

Pareschi, F. (2006). Chaos-based random number genera-

tors: Monolithic implementation, testing and applica-

tions. In PHD. THESIS.

T. Stojanovski, L. K. (2001). Chaos-based random number

generators-part i: analysis [cryptography]. Circuits

and Systems I: Fundamental Theory and Applications,

IEEE Transactions on, 48(3):281 –288.

TI (2010). Msp430x5xxx/msp430x6xxx family.

user’s guide. http://www.ti.com/lit/ug/slau208i/

slau208i.pdf.

TinyOS (2011). Tinyos web page. http://www.tinyos.net/.

V. Patidar, K. S. (2009). A pseudo random bit generator

based on chaotic logistic map and its statistical testing.

Informatica, 33:441 –452.

Y.H. Wang, H.G. Zhang, F. Z. B. W. (2006). An efﬁcient

random number generator for ad hoc sensor network.

In Wireless Communications, Networking and Mobile

Computing, 2006. WiCOM 2006.International Con-

ference on, pages 1 –4.

lmRNG:ALightweightPseudorandomNumberGeneratorforWirelessSensorNetworks

363
