Tampering with Java Card Exceptions

The Exception Proves the Rule

Guillaume Barbu

1,2

, Philippe Hoogvorst

and Guillaume Duc

Institut Mines-T´el´ecom / T´el´ecom ParisTech, CNRS LTCI, D´epartement COMELEC,

46 rue Barrault, 75634 Paris Cedex 13, France

Oberthur Technologies, Innovation Group,

Parc Scientiﬁque Unitec 1 - Porte 2, 4 all´ee du Doyen George Brus, 33600 Pessac, France

Keywords:

Java Card, Java Exceptions, Software Attacks, Fault Attacks, Combined Attacks.

Abstract:

Many publications have studied the various issues concerning Java Cards security regarding software and/or

hardware attacks. However, it is surprising to notice that the particular case of exception-related mechanisms

has not been tackled yet in the literature. In this article, we ﬁll this gap by proposing several attacks against

Java Card platforms based on both exception handling and exception throwing. In addition, this study allows

us to point out that a weakness known by the web-oriented Java community for more than a decade still passes

the different steps of the state-of-the-art Java Card application deployment process (namely conversion and

veriﬁcation). This appears all the more important as the Java Card 3 Connected Edition speciﬁcations have

started to bridge the gap between the two worlds that are Java Cards and Java web services.

1 INTRODUCTION

The Java Card technology is, as of today, the world’s

leading technology in the smart card ﬁeld. This lead-

ership comes from the outstanding cost reduction in

terms of application deployment it allows. The fa-

mous write once, run everywhere motto of the Java

technology is therefore a key factor for this success.

As part of the Java language, the notion of excep-

tion appears important. As per (Chen, 2000), ”an ex-

ception is an event that disrupts the normal ﬂow of

instructions during the execution of a program”. In-

deed, exceptions are originally meant to handle errors

that might occur during the program execution. These

errors may come from the Java Card Virtual Machine

(JCVM) when internal errors occurs (a null pointer, or

an access out of the boundsof an array for instance) or

from the application itself. The latter case has lead to

an evolution of the use of exceptions. Many applica-

tions actually use this mechanism as a programmatic

trick to redirect the instruction ﬂow to speciﬁc treat-

ments in various occasions.

Another important factor, and especially in the

smart card ﬁeld, is the inherent security of the system.

This security is mainly achieved by the Java Card

language and the Java Card Runtime Environment

(JCRE) security properties. The strongly-typed prop-

erty of the Java Card language for instance ensures

that no pointer arithmetic is used in a Java Card ap-

plication and that objects behave according to a given

contract deﬁned by their Java class, superclasses and

interfaces. The JCRE enforces other security rules,

ensuring, for instance, the isolation between the dif-

ferent applications running on the platform. The com-

plete list of these requirement can be found in the

speciﬁcations (Gosling et al., 2005; Lindholm and

Yellin, 1999; Sun Microsystems Inc., 2009b; Sun Mi-

crosystems Inc., 2009c).

The Java Card 3 Connected Edition has brought

the Java Card platform really close to standard ones,

introducing notions and facilities related to standard

Java applications and web services in particular. The

literature on the security of Java and web services is

relatively vast and several studies, security breaches

and security guidelines have been published (Dean

et al., 1996; Ladue, 1997; Princeton University, De-

partment of Computer Science, Secure Internet Pro-

gramming Group, ; Last Stage of Delirium Research

Group, 2002; Cholakov and Milev, 2005; Hubert

et al., 2010; Long et al., 2011; Oaks, 2001; The

Open Web Application Security Project (OWASP),

2012a; The Open Web Application Security Project

(OWASP), 2012b; Mehta and Sollins, 1998; McGraw

and Felten, 2000; Caromel and Vayssi`ere, 2001; Gut-

terman and Malkhi, 2005; Livshits and Lam, 2005).

It appears then all the more interesting to reconsider

Barbu G., Hoogvorst P. and Duc G..

Tampering with Java Card Exceptions - The Exception Proves the Rule.

DOI: 10.5220/0004018600550063

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 55-63

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

these studies in the Java Card context. In this article,

we focus our study on the security of the exception-

related mechanisms of the Java Card platform. This

concern comes from the observation that attackers of-

ten try to avoid an exception throwing, but rarely to

take advantage of it.

This article is organized as follows. Section 2 in-

troduces more precisely the notion of exception and

the related mechanisms. In Section 3, we present sev-

eral new attacks against Java Card platforms taking

advantage of the exception-related mechanisms. Sec-

tion 4 analyses those attacks and outlines their conse-

quences. Finally Section 5 concludes this article.

2 EXCEPTIONS IN JAVA CARD

PLATFORMS

This section aims at introducing the notion of excep-

tion, the evolution of its use in a program and the re-

lated mechanisms on Java Card platforms, namely ex-

ception throwing and exception handling. Although

we get relatively speciﬁc concerning certain proper-

ties, we do not intend to give an exhaustive descrip-

tion of the ins and outs of exceptions. Readers wish-

ing to learn more should deﬁnitely refer to (Chen,

2000, §6), (Gosling et al., 2005, §11) and (Lindholm

and Yellin, 1999, §2.16).

2.1 The Role of Exceptions

As previously stated, exceptions are initially meant

to handle errors during the execution of a program.

In the following, we show that if this original pur-

pose is still in use today, exceptions have been totally

integrated in application’s programming and are now

widely used for more than ”just” handling errors.

Handling Abnormal Conditions. On one hand, we

ﬁnd the traditional usage of exceptions, that is to say

error handling. In this scope, an exception is created

when an abnormal behaviour is detected, when the

execution of a program is deemed unsuccessful, or

when the system detects that pursuing the execution

will lead it to halt abruptly for instance. The excep-

tion handler is then in charge of handling the abnor-

mal conditions that have led to the exception raising,

and in the worst case to properly halt the system.

Handling Particular Conditions. On the other

hand, in certain modern programs, exceptions are

used as a way to break the control ﬂow of an appli-

cation and not necessarily because an abnormal con-

dition has occurred. For instance, an exception may

be raised by a program when a given condition is sat-

isﬁed or not, regardless of the potential consequences

of this condition. The aim of such exception is only

to force a jump and execute speciﬁc lines of code that

are deﬁned as the exception handler.

Good Practices. Several references (Long et al.,

2011; Oaks, 2001; The Open Web Application Secu-

rity Project (OWASP), 2012a; The Open Web Appli-

cation Security Project (OWASP), 2012b) detail the

importance of properly handling any exception that

might occur during the execution of a program. Con-

cerning the Java language, it is particularly important

to segregate the different exception types (classes) in

different catch-blocks in order to handle each and ev-

ery exception type in an appropriate way. Further-

more, it is also generally advised not to transmit too

much information within the exception, as it could be

useful to an attacker

2.2 The Syntax of Exception Handling

Java, as several programming languages, deﬁnes a

syntax associated to exception handling. For that pur-

pose, the Java language allows the deﬁnition of try-

catch-blocks.

Listing 1: Exception syntax in Java and Java Card.

try {

/ / Code oper ating a s e n s i t i v e

/ / proc ess t h at w i l l ra is e an

/ / e xcept io n i f deemed uns uc ce ss fu l .

. . .

} catch ( ExceptionType1 et1 ) {

/ / The oper at ion has f a i l e d i n a

/ / s p e c i fi c way , handle i t

/ / acco rd ingly .

. . .

} catch ( ExceptionType2 et2 ) {

/ / The oper at ion has f a i l e d i n

/ / another s p e c i f i c way , handle i t

/ / acco rd ingly .

. . .

} f i nally {

/ / Code execu ted whether an

/ / e xcept io n has been thrown or not ,

/ / caught or not .

. . .

}

As described in Listing 1, the programmer has to

The typical example of such a situation is that of an at-

tacker sending SQL requests to a database server and gain-

ing information on the structure of tables thanks to the mes-

sage contained in the returned exceptions.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

write the code that is likely to raise an exception in-

side a try-block and the code that will be executed

when a certain type of exception is raised in different

catch-blocks. In addition, the ﬁnally-block allows to

deﬁne a code portion that will be executed whether an

exception was raised or not, caught or not.

2.3 The Exception Handler Table in

Java Card Binaries

In the binary format, either .CLASS ﬁles for standard

Java binaries or .CAP ﬁles for Java Card binaries, ex-

ception handlers are represented for each method into

a so-called handler table. In a .CAP ﬁle, for instance,

this table is represented in the method component as

speciﬁed in (Sun Microsystems, 2006) and described

below:

method_component {

u1 tag

u2 size

u1 handler_count

exception_handler_info

exception_handlers[handler_count]

method_info methods[]

}

exception_handler_info {

u2 start_offset

u2 bitfield {

bit[1] stop_bit

bit[15] active_length

}

u2 handler_offset

u2 catch_type_index

}

According to the speciﬁcations, the handlers

should be sorted according to their starting offset in

the method’s bytecode. For each handler, the excep-

tion handler table speciﬁes the start- and end-offset of

the handler in the method’s bytecode array, as well as

the subtype of Throwable it handles.

Therefore, when an exception is thrown at some point

during the execution of an application, the JCVM is

responsible for searching the appropriate exception

handler in the table, if any. The exception handler

searching is typically done as presented in Algorithm

The present section has introduced the notions and

mechanisms related to exceptions and their handling

on Java Card platforms. The purpose of the following

section is to emphasize how various attacks on these

mechanisms can expose the platform, the hosted ap-

plications or sensitive data.

Algorithm 1: Exception Handler Searching.

input : E the exception being handled

input : H the exception handler table

output: -

1 while more handler left in H do

2 handler ← next handler;

3 if jpc is covered by handler offsets then

4 if handler match E’s type then

5 jump to handler;

6 end loop;

7 end

8 end

9 end

10 forward exception to previous frame;

3 SOFTWARE, FAULT AND

COMBINED ATTACKS: ON THE

SECURITY OF EXCEPTIONS

AND EXCEPTION HANDLING

Most of time, attackers only care about exceptions

because they wish to avoid the particular conditions

leading to an exception throwing. In this section we

start by introducing the notion of Fault Attack and de-

scribing two previous works taking advantage of an

exception throwing to mount an attack. Subsequently,

we expose the results of our study on the security of

exception-related mechanisms. This consists in the

description of new attacks grounded on both excep-

tion handling and exception throwing.

3.1 Previous Works

The case of exceptions has not been much investi-

gated in the literature related to Java Card security.

However we can outline the work of Barbu et al. pre-

sented at CARDIS 2010 (Barbu et al., 2010). On

the other hand, the standard Java security ﬁeld has

shown much more interest for exceptions (Dean et al.,

1996; Ladue, 1997; Princeton University, Department

of Computer Science, Secure Internet Programming

Group, ; Last Stage of Delirium Research Group,

2002; Cholakov and Milev, 2005; Hubert et al., 2010;

Long et al., 2011; Oaks, 2001; The Open Web Appli-

cation Security Project (OWASP), 2012a; The Open

Web Application Security Project (OWASP), 2012b).

We brieﬂy describe in particular here the work of

Dean et al. presented as soon as 1996 at the IEEE

Symposium on Security and Privacy (Dean et al.,

1996). But let us ﬁrst brieﬂy introduce the notion of

Fault Attacks and recall the widely used fault models.

TamperingwithJavaCardExceptions-TheExceptionProvestheRule

3.1.1 Fault Attacks on Smart Cards

Fault Attacks aim at disturbing the execution of an

application. Since the ﬁrst published attack based on

an optical fault injection (Skorobogatov and Ander-

son, 2002), several means have been studied to pro-

voke errors in Integrated Circuit. Today, the principal

means to disrupt a component like a smart card are

light beams and electromagnetic pulses (Quisquater

and Samyde, 2002). In ﬁne, the disturbance could

lead to obtain a faulty output or to execute the applica-

tion with granted privileges (Giraud and Thiebeauld,

2004; Bar-El et al., 2006). Attested fault models con-

sist for instance in stucking a byte to 0x00, 0xFF or a

random value, or in disrupting the native code fetch-

ing and thus jumping one or several instructions.

Such facilities have been mainly used against embed-

ded cryptosystems, but they actually are a threat to

any function implemented on embedded devices. The

idea of combining such physical attacks with mali-

cious applications was introduced in (Barbu, 2009).

These Combined Attacks allow for instance to dis-

obey certain rules stated by the Java Card speciﬁca-

tions. The fault injection aims at disrupting mech-

anism enforcing these rules and the malicious ap-

plication exploits the provoked breach. Since then,

many Combined Attacks have been published to at-

tack several vital points of a Java Card such as the

APDU buffer, the application ﬁrewall or the operand

stack for instance (V´etillard and Ferrari, 2010; Barbu

et al., 2010; Barbu et al., 2011; Barbu and Thiebeauld,

2011; Barbu et al., 2012b; Barbu et al., 2012a).

3.1.2 Using an Exception to Attack a Java Card

In (Barbu et al., 2010), the authors propose an at-

tack on a Java Card 3 platform allowing to read and

modify the bytecode array of an on-card application.

This is achieved thanks to a type confusion involv-

ing the newly introduced java.lang.Class class of the

Java Card 3 Application Programming Interface (Sun

Microsystems Inc., 2009a). In this work, the authors

explain that the java.lang.ClassCastExceptionthrown

by the virtual machine when an incorrect typecasting

is executed can be used by an attacker. The aim is

then to detect the execution of the exception throwing

by monitoring the power consumption of the card in

order to determine the precise moment when to apply

the laser pulse to disrupt the virtual machine’s execu-

tion during its type checking.

3.1.3 Using an Exception against a Java Client

In (Dean et al., 1996), the authors describe how

the exception throwing can lead to security breaches

allowing a privilege escalation on the client-side

through a web browser (Netscape Navigator for in-

stance) executing a Java applet. The article is based

on the fact that the incomplete execution of a class

constructor may lead to an object instance partially

initialized. In particular, they exhibit the example of

the abstract class ClassLoader from Sun’s Java Run-

time Environment (JRE). They provide a custom class

loader extending this abstract class (cf. Listing 2).

Listing 2: The incomplete class loader.

cla ss CL extends ClassLoader {

CL( ) {

try { super ( ) ; }

catch ( Exception e ) {}

}

The partial initialization of the class loader leads

to a type confusion and eventually to a privilege el-

evation for the attacker’s application. The attack

described in this work is then completely based on

the exception throwing. This breach was then con-

cealed with updates of both the Netscape Navigator

and the Java Development Kit, respectively with ver-

sions 2.02 and 1.02.

3.2 Attacks on the Exception Handler

Research

In the following, we propose several ways an attacker

can take beneﬁts from the Algorithm 1, searching the

proper handler for a given exception. We describe ﬁrst

a new attack based on a fault injection that can be

either combined with a malicious application or not

depending on the attack scenario. Then we introduce

a software-only attack using an incorrect handler table

within a .CAP ﬁle.

3.2.1 Jumping in the Wrong Exception Handler

In the attack presented here, we consider a fault injec-

tion targeting one of the conditional branch instruc-

tions of Algorithm 1 (i.e. lines 3 or 4). The physical

perturbation consists in jumping a given (set of) in-

struction(s) by disrupting the code fetching in the im-

plementation of this algorithm in the Java Card Vir-

tual Machine. Such a fault model is widely accepted

in the literature (Skorobogatov and Anderson, 2002;

Giraud and Thiebeauld, 2004; Bar-El et al., 2006) and

was put into practice in (Barbu et al., 2010) against the

checkcast

implementation.

Provided the attacker meets success with the fault

injection, she can then force the jump in an excep-

tion handler that was meant for another type of ex-

SECRYPT2012-InternationalConferenceonSecurityandCryptography

ception, or for the same type of exception but at a

different time (i.e. covering another part of the code).

The following code sample (Listing 3) is deﬁnitely

far-fetched, but is a perfect illustration of the type of

code likely to be targeted by such an attack.

Listing 3: Attacked code example.

try {

/ / MyOwnPIN . check method throws a

/ / TryAgainException when an in v a l i d

/ / PIN i s sub mi tted .

i f (myOwnPin . check ( submitted , 0 , 4 ) ) {

exec ut ePrivilege Me thod ( ) ;

}

} catch ( N ul lP oi nt er Ex ce pt ion npe ) {

/ / myOwnPin is not y et i n i t i a l i z e d ,

/ / do i t and re tu rn

myOwnPin = new MyOwnPIN( TRY LIMIT ,

PIN SIZE ) ;

myOwnPin . update (PIN ARRAY, PIN OFFSET ,

PIN LENGTH ) ;

return PIN NOT INIT ;

} catch ( TryAgainException t ae ) {

proc essInva lidP INSubm ittedEv ent ( ) ;

return INVALID PIN ;

}

In this particular case, a successful perturbation

allows to reinitialize the PIN object, by executing the

code in the catch(NullPointerException)-block. An

attacker reaching a good fault injection repeatabil-

ity is then likely to brute-force the PIN, although

it is supposed to be protected by a counter limit-

ing the number of tries and decremented within the

MyOwnPIN.check method. Note that in the general

case, by forcing a jump in the wrong handler, the at-

tacker always creates a type confusion between the

actual exception type and the exception type that is

caught. The consequences of the execution of the

wrong catch-block are on the other hand totally de-

pendent on the application.

3.2.2 Handler Table Corruption

As described in Section 2.3, the .CAP ﬁle contains a

handler table deﬁning where to jump when a given

exception occurs at a given offset in the bytecode ar-

ray. We explore here the possibility for an attacker to

achieve the same kind of attack as just described by

the mean of a sole .CAP ﬁle manipulation.

When an exception is thrown, Algorithm 1 leads

to jump at the offset deﬁned within the handler table.

It is therefore obvious that corrupting the handler ta-

ble will eventually result in a jump at an incorrect off-

set in the bytecode array. However, before being able

to execute the application on-card, the attacker would

most likely have to make it pass the bytecode veriﬁ-

cation. It is then necessary to study how the bytecode

veriﬁer ensures the correctness of the handler table.

The rules used by the veriﬁer can be deduced from

the rules deﬁned in the JCVM speciﬁcation. These

rules are the following:

• handlers are sorted according to their start-offset,

• handlers do not ”partially intersect”, i.e. they are

either disjoint or nested,

• handlers point to valid offsets in the current

method,

• the stop-bit deﬁnes when to stop searching for

other handlers.

We then tested several modiﬁcations of the handler ta-

ble versus both the Java Card converter and the byte-

code veriﬁer present in the JCDK 3.0.4. It turns out

that only one manipulation was not rejected. This

manipulation consists in the manipulation of the end-

offset of a try-block so that it englobes the handler of

the associated ﬁnally-block. This is depicted in the

.JCA ﬁle obtained from the conversion of the applet

(after the .CLASS ﬁle has been modiﬁed) in Listing 4.

Note that a modiﬁcation of the bit-stop of the ﬁnally

handler was also necessary.

Consequently, when an exception is thrown within

the try-block, it is handled by the ﬁnally-block which

in turn re-throws the exception. This exception is sub-

sequently handled by the same ﬁnally-block again,

etc... As a matter of fact, the applet is stuck in an inﬁ-

nite exception throw-and-catch loop. Indeed a binary

ﬁle manipulation can allow to break the inﬁnite loop

by using a counter incremented in the loop and con-

ditioning the exception throwing. Also, the ﬁnally-

block can be manipulated in order to use the local

variable created by the compiler to store the excep-

tion before throwing it at the end of the block. We

believe this last point should be very tricky to handle

for the bytecode veriﬁer, although we have not been

able to ﬁnd any explicit breach.

3.3 Attacks on Exception Throwing

In this section, we focus our interest on the exception

throwing itself. We can therefore isolate two differ-

ent kind of attacks whether we intend to force an ill-

behaviour of this mechanism or simply to bypass it.

The following introduces attacks in both categories.

3.3.1 Throwing a Non-throwable

In (Barbu et al., 2011), the authors studied the pos-

sible impacts of a perturbation of the values pushed

onto the operand stack of a Java Card platform. Some

TamperingwithJavaCardExceptions-TheExceptionProvestheRule

Listing 4: JCA ﬁle after modiﬁcation.

. method public t es tE x ce p ti o n ( )V 8 {

. s ta ck 2; . l o c a l s 2;

L0 : a c o n st n u ll ;

a st o r e 1 ;

L1 : aload 1 ;

aload 1 ;

inv o k e vi r t ual 11;

/ / e qual s ( Ljava / lang / Object ; ) Z

pop ;

new 12;

/ / java / lang / Object

dup ;

invo kespe ci al 3;

/ / java / lang / Object . ()V

a st o r e 1 ;

goto L4 ;

L2 : a s to r e 2 ;

/ / l oca l va ri ab le cre at ed by the

/ / compiler to s t or e t he

/ / e xc epti on .

L3 : new 12;

/ / java / lang / Object

dup ;

invo kespe ci al 3;

/ / java / lang / Object . ()V

a st o r e 1 ;

aload 2 ;

athrow ;

L4 : return ;

. excepti onTable {

/ / s ta r t b l oc k , end block ,

/ / hand ler bl ock , c a tc h t y pe i n d ex

L1 , L4 , L2 , 0;

/ / handler cove rs f i n a l l y −block ’ s

/ / athrow !

L2 , L3 , L2 , 0;

}

of their use cases are based on the attacker’s instanti-

ating as many objects of a given class C as possible in

order to enhance the probability that a random error

affecting an object’s reference transform it into one of

the reference of an instance of class C .

We tackle here an issue that was not treated in their

article: the perturbation of a thrown exception’s refer-

ence. The possible consequences are twofold depend-

ing on the nature of class C :

1. C extends the API’s class Throwable. Then the

execution will continue in the wrong exception

handler, provoking, for sure, a type confusion be-

tween the two exception classes and potentially

bypassing some exception-dependent operations,

including security-related ones.

2. C does not extend Throwable. In this case,

the JCVM should not ﬁnd an exception handler

matching the type of the exception. The exception

should therefore not be caught and cause the sys-

tem to halt. However, considering a malicious ap-

plication, the attacker may have created a ﬁnally-

block taking this possibility into account, which

would at least provoke a type confusion between

two object instances.

Indeed, in the latter case, even jumping in the ﬁnally-

block is not obvious on all platforms. The ﬁnally-

block being meant to handle any kind of exceptions,

it is associated in the application’s binary ﬁle to a

type referred to as ANY in the speciﬁcations. Yet, ev-

ery platform is responsible for testing that the object

thrown can be casted to the type Throwable before

jumping in the ﬁnally handler.

3.3.2 Prevent Exception Throwing

Another interesting option from an attacker’s point

of view is simply to prevent the throwing of an ex-

ception. In the context of Java Cards, this can be

achieved on two different circonstances, by two dif-

ferent means.

The ﬁrst one concerns the case where the excep-

tion is thrown by the JCRE. The typical example for

such a situation is when an application invokes a vir-

tual method on an object that turns out to be null. As

per the speciﬁcations, the JCRE then throws a Null-

PointerException. The code responsible for the ex-

ception raising is obviously part of the JCRE/JCVM

implementation, we can therefore expect it to be writ-

ten in native language (i.e. in the card’s assembly lan-

guage). Therefore, an attacker willing to skip the ex-

ception throwing will have to disrupt the execution of

nativecode, which is generally done by perturbing the

fetch of the code either in the ROM or the NVM.

The second one concerns the case where the ex-

ception is thrown by a Java Card application. In this

case, it is the bytecode instruction athrow which is re-

sponsible for the exception throwing. An attacker can

then work two different attack angles. The ﬁrst one is

the same as previously stated. Since the athrow is also

a part of the JCVM implementation, a similar attack

on the appropriate code fetching shall allow to bypass

the execution throwing. The second angle consists in

an attack of the bytecode instruction reading in the ap-

plication’s bytecode array. This bytecode is basically

a byte read and processed by the JCVM’s interpreter.

A fault attack stucking this byte to 0 will then force

the execution of the nop instruction, on platforms us-

ing the standard instruction set, and therefore bypass

the exception throwing. This is one of the basic ex-

amples introducing mutant application in (S´er´e et al.,

2010).

SECRYPT2012-InternationalConferenceonSecurityandCryptography

3.3.3 The Incomplete Object Initialization on

Java Card

We explore here the possibility to somehow adapt

the incomplete object initialization attack described

in Section 3.1 on a Java Card. The point is that ac-

cording to the 2

edition of the Java Virtual Machine

speciﬁcation, the class ﬁle veriﬁcation process should

prevent such a situation from occurring, as it speci-

ﬁes:

”A valid instruction sequence must not have

an uninitialized object on the operand stack or

in a local variable during a backwards branch,

or in a local variable in code protected by an

exception handler or a ﬁnally clause.” (Lind-

holm and Yellin, 1999, §4.9.4)

In addition, the 3

edition of the Java Language spec-

iﬁcation speciﬁes that during an object initialization

calling a superclass construcor:

”If that constructor invocation completes

abruptly, then this procedure [object initializa-

tion] completes abruptly for the same reason.”

(Gosling et al., 2005, §12.5)

The possibility to load an application containing the

code depicted in Listing 2 is then subject to question

on recent platforms.

Is it Possible to Load such an Application on a

Java Card? We consider then the following con-

structor method, for a class extending a super-class

whose constructor throws a particular exception, say

MyException in our case (Listing 5).

Listing 5: Potential incomplete initialization.

try {

super ( ) ; / / throws MyException

authRequired = true ;

}

catch ( MyException me) {

/ / I n i t i a l i z a t i o n i s not complete . . .

/ / authRequired = f al se , the

/ / d e fa u l t value f or boolean .

}

The fact is that trying to compile this code with

the Java compiler provided with the Java Develop-

ment Kit version 1.6.0 18-b07 result in the following

error:

call to super must be first statement in

constructor.

We then assume that this error is due to the restrictions

quoted above since the call to the superclass’s con-

structor is indeed the ﬁrst statement in our construc-

tor. Getting a valid class actually representing this

constructor requires then the compilation of a slightly

different piece of code and a little .CLASS ﬁle tweak-

ing. The content of the two .CLASS ﬁles is given in

Listings 6 and 7.

Listing 6: Original constructor class.

public void ()

throws MyException {

/ / Call super c ons tr uc to r

aload 0

invo kespe ci al void MySClass. ()

try− b l o ck s t a r t ( app . MyException ) 4 :

aload 0

i nv o k e vir t ual void MyClass . notSuper ( )

aload 0

ico n st 1

p u t f i e l d boolean MyClass . authRequired

try−block end ( app . MyException ) 13 :

goto l ab el 17

ex ce pt ion h an dl er ( app . MyException ) 16 :

a st o re 1

labe l 17 :

return

}

Listing 7: Tweaked constructor class.

public void () {

try− b l o ck s t a r t ( app . MyException ) 0 :

/ / Call super c ons tr uc to r

aload 0

i nv o k e vir t ual void MySClass. ()

aload 0

ico n st 1

p u t f i e l d boolean MyClass . authRequired

try−block end ( app . MyException ) 9 :

goto l ab el 13

ex ce pt ion h an dl er ( app . MyException ) 12 :

a st o re 1

labe l 13 :

return

}

Afterward, we successfully pass both the Java

Card converter and bytecode veriﬁer that are provided

with the most recent Oracle’s development kit (Java

Card Classic Edition 3.0.4 Development Kit). These

two operations yields a veriﬁed .CAP ﬁle, ready to be

loaded and installed on-card, proving that the veri-

ﬁer does not reject classes with potential incompletely

initialized objects. We can therefore be pretty conﬁ-

dent on the success of the loading of an application

with the same behaviour on a Java Card 3 Connected

Edition endowed with an on-card bytecode veriﬁer al-

though the lack of publicly available cards prevents us

from testing it.

TamperingwithJavaCardExceptions-TheExceptionProvestheRule

4 CONSEQUENCES AND

ANALYSIS

The previous section has shown that several possibil-

ities are offered to a potential attacker to take advan-

tage of the exception-related mechanisms of the sys-

tem. We intend here to analyse the consequences of

such attacks if they were to be achieved on the ﬁeld.

4.1 Consequences

The consequences of the potential attacks described

in the previous section are various indeed. Concern-

ing the incomplete object initialization, the assets that

might be targeted by such attacks are still to be pre-

cisely identiﬁed. Unlike standard Java, the Java Card

3 Connected Edition does not support user-deﬁned

class loaders, nor the Object.ﬁnalize() method evoked

in (Hubert et al., 2010) to extend Dean et al.’s work

(Dean et al., 1996). Consequently, this seminal work

cannot be transferred in the Java Card world as is.

Furthermore, applications taking advantage of all the

facilities offered by the Java Card 3 Connected Edi-

tion standard are not really widespread yet. How-

ever the example of the original attack is explicit and

should encourage every developer to keep this threat

in mind.

Regarding the other attacks we have introduced

in this article, the consequences can be divided into

two categories. On one hand, the consequences of a

type confusion covers the access to private ﬁelds or to

data out of the bounds of an array, the jump of access

control checks, or even self-modifying applications in

certain contexts. Type confusion is indeed the core of

several attacks against Java and Java Card platforms

(Govindavajhala and Appel, 2003; Witteman, 2003;

Mostowski and Poll, 2008; S´er´e et al., 2009; Barbu

et al., 2010). On the other hand, the execution ﬂow

disruption has been less studied but can lead to criti-

cal consequences. First, since it can be used to pro-

voke a type confusion, the same results can be ex-

pected. Second, preventing an exception from being

thrown can have even more dangerous consequences.

We can consider for instance the case of an access

across the application ﬁrewall enforced by the JCRE

that would not throw a SecurityException, although it

has been duely detected, which is an example given

in (V´etillard and Ferrari, 2010).

4.2 The Exception Proves the Rule

We outline in this work the potential weakness intro-

duction coming with the evolution of a system. For

instance, the integration of the Java Card in the web

ecosystem is a topic of interest from a security point

of view.

Although the Java Card platform can deﬁnitely

be considered as an inherently secured platform, it

is still potentially vulnerable to attacks. Both soft-

ware and combined attacks are then likely to threaten

the integrity of the platform and to a certain extent of

other applications. The implementors of the embed-

ded JCREs, as well as application developers must

therefore take this kind of threat into account when

coding and comply to the security guidelines. The

various attacks we have introduced along this arti-

cle against exception-related mechanisms allows us to

highlight this state of fact.

5 CONCLUSIONS

In this article, we have given an overview of the po-

tential attacks that can be built upon, and around, the

exception-related mechanisms of the Java Card tech-

nology. In particular we have exposed that attacks on

these mechanisms are likely to bypass certain opera-

tions contained in catch-blocks and to break the type

safety property of the Java Card Virtual Machine. In

addition, this study has allowed us to exhibit a resid-

ual weakness regarding the incomplete initialization

of objects which had already been pointed out in the

standard Java web applet context with serious conse-

quences on the client side executing the applet. This

leads to conclude on the necessity of establishing a

link between the various security ﬁelds. This neces-

sity is all the more urgent with the introduction of the

Java Card 3 Connected Edition, bridging the gap be-

tween the Java Card world and the Java web-related

world.

REFERENCES

Bar-El, H., Choukri, H., Naccache, D., Tunstall, M., and

Whelan, C. (2006). The Sorcerer’s Apprentice Guide

to Fault Attacks. IEEE, 94(2):370–382.

Barbu, G. (2009). Fault Attacks on Java Card 3 Virtual Ma-

chine. In e-Smart’09.

Barbu, G., Duc, G., and Hoogvorst, P. (2011). Java Card

Operand Stack: Fault Attacks, Combined Attacks and

Countermeasures. In (Prouff, 2011), pages 297–313.

Barbu, G., Giraud, C., and Guerin, V. (2012a). Embedded

Eavesdropping on Java Card. In Proceedings of the

IFIP International Information Security and Privacy

Conference 2012 – SEC 2012. Springer Verlag. to be

published.

Barbu, G., Hoogvorst, P., and Duc, G. (2012b).

Application-Replay Attack on Java Cards: When the

SECRYPT2012-InternationalConferenceonSecurityandCryptography

Garbage Collector Gets Confused. In Barthe, G. and

Livshits, B., editors, International Symposium on En-

gineering Secure Software and Systems – ESSoS 2012,

Lecture Notes in Computer Science. Springer.

Barbu, G. and Thiebeauld, H. (2011). Synchronized Attacks

on Multithreaded Systems - Application to Java Card

3.0 -. In (Prouff, 2011), pages 18–33.

Barbu, G., Thiebeauld, H., and Guerin, V. (2010). Attacks

on Java Card 3.0 Combining Fault and Logical At-

tacks. In (Gollmann and Lanet, 2010), pages 148–163.

Caromel, D. and Vayssi`ere, J. (2001). Reﬂection on MOPs,

Components, and Java Security. In Proceedings

of the Engineering C of Object-Oriented Programs

(ECOOP), volume 2072 of LNCS. Springer-Verlag.

Chen, Z. (2000). Java Card Technology for Smart Cards,

Architecture and Programmer’s Guide. Addison-

Wesley.

Cholakov, N. and Milev, D. (2005). The Evolution of the

Java Security Model. In Proceedings of the Inter-

national Conference on Computer Systems and Tech-

nologies (CompSysTech’2005).

Dean, D., Felten, E. W., and Wallach, D. S. (1996). Java

Security: From HotJava to Netscape and Beyond. In

Proceedings of the IEEE Symposium on Security and

Privacy.

Giraud, C. and Thiebeauld, H. (2004). A Survey on Fault

Attacks. In Quisquater, J.-J., Paradinas, P., Deswarte,

Y., and Kalam, A. E., editors, Smart Card Research

and Advanced Applications VI – CARDIS 2004, pages

159–176. Kluwer Academic Publishers.

Gollmann, D. and Lanet, J.-L., editors (2010). volume 6035

of Lecture Notes in Computer Science. Springer.

Gosling, J., Joy, B., Steele, G., and Bracha, G. (2005). The

Java Language Speciﬁcation. Addiosn-Wesley, 3rd

edition.

Govindavajhala, S. and Appel, A. (2003). Using Memory

Errors to Attack a Virtual Machine. In IEEE Sympo-

sium on Security and Privacy, pages 154–165. IEEE

Computer Society.

Gutterman, Z. and Malkhi, D. (2005). Hold Your Sessions:

An Attack on Java Session-Id Generation. In Proceed-

ings of the Cryptographer’s Track at the RSA Confer-

ence (CT-RSA), LNCS. Springer.

Hubert, L., Jensen, T., Monfort, V., and Pichardie, D.

(2010). Enforcing Secure Object Initialization in

Java. In Proceedings of the European Symposium on

Research in Computer Securiy, ESORICS’10, pages

101–115. Springer-Verlag.

Ladue, M. D. (1997). When Java was One: Threats from

Hostile Bytecode. In Proceedings of the 20th National

Information Systems Security Conference, pages 104–

115.

Last Stage of Delirium Research Group (2002). Java

and Java Virtual Machine Security Vulnerabilities and

their Exploitation Techniques. In BlackHat Confer-

ence.

Lindholm, T. and Yellin, F. (1999). Java Virtual Machine

Speciﬁcation. Addison-Wesley, Inc., 2nd edition.

Livshits, B. and Lam, M. S. (2005). Finding Security Vul-

nerabilities in Java Applications with Static Analysis.

Technical report, USENIX.

Long, F., Mohlndra, D., Seacord, R. C., Sutherland, D. F.,

and Svoboda, D. (2011). The CERT Oracle Secure

Coding Standard for Java. Carnegie Mellon Software

Engineering Institue (SEI) series. Addison-Wesley.

McGraw, G. and Felten, E. W. (2000). Getting Down to

Business with Mobile Code. John Wiley & Sons.

Mehta, N. V. and Sollins, K. R. (1998). Expanding and Ex-

tending the Security Features of Java. In Proceedings

of the 7th USENIX Security Symposium.

Mostowski, W. and Poll, E. (2008). Malicious Code on

Java Card Smartcards: Attacks and Countermeasures.

In Grimaud, G. and Standaert, F.-X., editors, Smart

Card Research and Advanced Applications, 8th Inter-

national Conference – CARDIS 2008, volume 5189

of Lecture Notes in Computer Science, pages 1–16.

Springer.

Oaks, S. (2001). Java Security. O’Reilly, second edition.

Princeton University, Department of Computer Science, Se-

cure Internet Programming Group. Reports on Secu-

rity Flaws in Commercial Available Softwares.

Prouff, E., editor (2011). volume 7079 of Lecture Notes in

Computer Science. Springer.

Quisquater, J.-J. and Samyde, D. (2002). Eddy Current for

Magnetic Analysis with Active Sensor. In e-Smart

2002.

S´er´e, A. A. K., Iguchi-Cartigny, J., and Lanet, J.-L. (2009).

Automatic Detection of Fault Attack and Countermea-

sures. In Proceedings of the 4th Workshop on Embed-

ded Systems Security, WESS ’09, pages 1–7.

S´er´e, A. A. K., Iguchi-Cartigny, J., and Lanet, J.-L. (2010).

Checking the Paths to Identify Mutant Application on

Embedded Systems. In FGIT, pages 459–468.

Skorobogatov, S. and Anderson, R. (2002). Optical Fault

Induction Attack. In Kaliski Jr., B., Koc¸, C¸ ., and Paar,

C., editors, Cryptographic Hardware and Embedded

Systems – CHES 2002, volume 2523 of Lecture Notes

in Computer Science, pages 2–12. Springer.

Sun Microsystems (2006). Virtual Machine Speciﬁcation –

Java Card

Plateform, Version 2.2.2.

Sun Microsystems Inc. (2009a). Application Programming

Interface, Java Card Platform, Version 3.0.1 Con-

nected Edition.

Sun Microsystems Inc. (2009b). Runtime Environment

Speciﬁcation, Java Card Platform, Version 3.0.1 Con-

nected Edition.

Sun Microsystems Inc. (2009c). Virtual Machine Speciﬁca-

tion – Java Card Plateform, Version 3.0.1.

The Open Web Application Security Project (OWASP)

(2012a). Information Leakage.

The Open Web Application Security Project (OWASP)

(2012b). Uncaught Exceptions.

V´etillard, E. and Ferrari, A. (2010). Combined Attacks and

Countermeasures. In (Gollmann and Lanet, 2010),

pages 133–147.

Witteman, M. (2003). Java Card Security. In Information

Security Bulletin, volume 8, pages 291–298.

TamperingwithJavaCardExceptions-TheExceptionProvestheRule
