Securing In-vehicle Communication and Redeﬁning the Role of

Automotive Immobilizer

Constantinos Patsakis

and Kleanthis Dellios

Universitat Rovira i Virgili Department of Computer Engineering and Maths, UNESCO Chair in Data Privacy,

Av. Pasos Catalans 26 43007 Tarragona, Catalonia, Spain

Department of Informatics, University of Piraeus, Piraeus, Greece

Keywords:

Immobilizer, In-vehicle Communication, Security, Authentication.

Abstract:

Automotive conventional anti-theft devices fail to prevent from unauthorized actions against vehicles. In-

formation technologies and evolved microelectronics are currently being developed and widely adopted in

controlling many mechanical parts of the vehicles. One of the most common means of restricting access

to unauthorized drivers is immobilizer. In current work we discuss some common vulnerability issues that

vehicles and immobilizer technology confronts, leading us to propose a redeﬁnition of its role in vehicle se-

curity and the physical vehicle environment. Our proposal meets current trends of IT and computer science in

embedding systems in vehicles and if properly implemented, may provide more secure vehicles.

1 INTRODUCTION

Automotive industry is one of the largest economies

and vehicles nowadays are improvedin their function-

ality, performance, safety and comfort (Naver et al.,

2009)(Fuhs, 2009). A vehicle is consisted of many

embedded systems working together and communi-

cating each other (Bonnick, 2001) creating an elec-

tronic environment that makes the vehicle operate as

a platform entity. For this, CAN, LIN and MOST net-

works are being used. In addition, the vehicle is eas-

ier to be controlled and modiﬁed due to the different

needs of a vehicle environment (Naver et al., 2009).

Because of many vehicle act of threats in past, immo-

bilizer technology (Heisler, 2002) has been invented

and added as a security mechanism in modern vehi-

cles. Its function is to prevent an engine from being

ignited without the presence of the correct key. After

their adoption, a signiﬁcant decrease in vehicle thefts

was observed, but in the past few years vehicle acts of

threats have been increased again (ETP, 2004). Even

if immobilizers deterred many thieves, several vulner-

abilities in vehicles have become known, resulting to

making them unable to protect a vehicle from being

stolen (HS NewsWire, 2010). Thus, there is obvi-

ously a need for development of a new vehicle secu-

rity mechanism.

The growing trend towards “computerizing” vehi-

cles, by adding extra services that are offered by inde-

pendent devices connected to the vehicle’s infrastruc-

ture extend the attack layer making it prone to new

more computerized attacks, like (Checkoway et al.,

2011) or (Bailey, 2010). On the light of the recent re-

search on vehicle security and current theft trends, big

organizations and security ﬁrms are trying to make

people aware of the dangers and ﬁnd more secure so-

lutions. Two very good examples are the US Depart-

ment of Transportation, which recently issued a Re-

quest for Information and McAfee which issued an

information bulletin (McAfee, 2011; FBO, 2011). It

becomes apparent that not only vehicles become the

next hacking platform, after smart-phones, but they

can be attacked in cyber warfare situation, leading to

huge problems.

The industrial approach towards in-vehicle com-

munication is quite different from VANETs. In

VANETs, correctly, the whole communication is

governed by many cryptographic and authentication

mechanisms, in order to secure the vehicle from out-

sider attacks. In the case of in-vehicle communica-

tion, the approach is quite different. Even though we

are aware that a car that is about to be stolen will be

attacked on its hardware infrastructure and communi-

cation systems, we haven’t taken the proper counter-

measures.

This work is an attempt to redesign the conven-

tional security system, which is primarily designed

to maximize the vehicle’s performance and passen-

221

Patsakis C. and Dellios K..

Securing In-vehicle Communication and Redeﬁning the Role of Automotive Immobilizer.

DOI: 10.5220/0004024302210226

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 221-226

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

ger safety and vehicle’s security as well. In this pro-

posal, a more networked vehicle (Heisler, 2002) is be-

ing illustrated, where vehicle’s control modules are

being authenticated, on a new control unit, primary

acting as a Trusted Third Party (TTP). In the proposed

model, immobilizer is not circumvented but is being

redeﬁned, cooperating with the TTP module in the

same centralized architecture creating an even more

secure environment, more robust against many cur-

rent attacks. This work has the following structure.

In the following section we present the Immobilizer

and general automative systems. Afterwards, we dis-

cuss current industrial standards and the security of

the communications that they offer, whlile present-

ing some common vulnerabilities that current immo-

bilizer technology confronts and vehicles vulnerabil-

ity issues of IT interest. Then we present our proposal

to vehicle security along with the possible protocol

structure for its implementation. Finally, we summa-

rize, giving some remarks for future work.

2 PRESENT IMMOBILIZER AND

AUTOMOTIVE SYSTEMS

Vehicle has evolved into a complex device, as it is a

mechanic machine controlled by numerous electronic

units. This is achieved by the usage of power elec-

tronics, transforming the vehicle into an embedded

platform, capable of controlling in large scale the me-

chanical systems of the vehicle and ensure its accurate

function in real-time and continuity of tasks (Naver

et al., 2009).

The role of automotive electronics is a major one,

as they allow the vehicle control with great tolerance

along with calibration stability (Bonnick, 2001). In

addition, they create an embedded environment with

many variable setups for a vehicle, electronics and

motor as well. Micro-controllers are the main form of

controlling an electronic vehicle system and they are

the fundamental core of vehicle’s computerised plat-

form. Another major electronic control unit is the ve-

hicle immobilizer, which is based on RFID Technol-

ogy and cryptographic techniques. Until nowadays

all vehicles are being equipped with an immobilizer

unit that functions as the security system of the vehi-

cle. The general principle is that immobilizer control

module, needs to receive a transmitted signal from the

factory’s original keys of the vehicle owner in order

to be activated. This is usually achieved by ﬁtting an

RFID chip inside the owner’s keys. Unless the cor-

rect electronic signal is provided to the system by the

ignition key, or a unique transponder or coded plug,

the vehicle will not start and the engine will no be

ignited(Naver et al., 2009; Bonnick, 2001; Heisler,

2002; Lemke et al., 2006).

As a result, when immobilizer operates, the vehi-

cle’s engine is not allowed to be ignited without ﬁrst

receiving the correct signal from the person trying to

start it (Naver et al., 2009; Bonnick, 2001; Heisler,

2002; Lemke et al., 2006). More generic from an IT

view, the immobilizer as a security mechanism will

not allow the system to be functional until the very

moment that the “certiﬁed user”, owner of the vehi-

cle’s keys, has been authenticated. Immobilizers over

the last years are tending to use more and more the

so called “rolling codes”, instead of “ﬁxed codes”. In

the past, each time the key was used with the same

transponder code, making vehicle vulnerable to re-

play attacks. In the case of rolling codes, a stream

cipher is being used, so that each time the key is used,

the transponder code changes. Sadly, as it has been

shown by Nohl (Nohl, 2010) in many cases the en-

cryption algorithms are poorly designed or poorly im-

plemented, making vehicles easy to be stolen.

Finally, the immobilizer was invented, embed-

ded in vehicles and became a “standard” vehi-

cle part/module, when insurance companies con-

fronted insurance issues, due to the state that vehi-

cles were stolen. It became a necessity that vehi-

cles, should have such an embedded security mecha-

nism that could confront such acts of threat and ob-

tain a more secure physical layer, as it was stated

by the spokesperson for AUTOSAR S. Bnzel (ee-

times, 2011). Apart from the creation of immobilizer,

new standards of communication channels were also

adopted both for sensors and control units and elec-

tronic automated on-vehicle diagnostics were added.

3 CURRENT STANDARDS AND

VULNERABILITIES

The industrial standards that modern vehicles con-

form to, are a very good critirion of the supplied se-

curity of the information shared between vehicle’s

components. One of the wider adopted industrial

standards in automotive industry is AUTOSAR (AU-

TOSAR), a framework for developing hardware com-

ponents allowing their communication and interoper-

ability. Currently, AUTOSAR is on the forth version,

which was originaly released at the end of 2009. It

is worth to notice that it is the ﬁrst version of the

standard refering to encryption, using the so-called

Crypto Service Manager and the Crypto Abstraction

Library. The aim of these two modules is to give

an API to the manufacturers, which can be easily ac-

cessed from vehicle’s software. In the standard there

SECRYPT2012-InternationalConferenceonSecurityandCryptography

222

is no deﬁnition of which cryptographicalgorithms can

be used, apart from MD5 and SHA which someone

can infer from the text, what key lengths are sup-

ported, how passwords are generated (in case of pub-

lic key algorithms). So we may deduce that all the

previous versions are lacking the software support of

standard encryption mechanismsfrom the framework.

Cars that are more than 1-2 years old, the encryption

of data and the use of authentication mechanisms was

left on the manufacturers and whether they cooperate

to encrypt the messages by the same way or leave it

plaintext. In the new standard, despite the new addi-

tions and the disclosure of possible attack, data en-

cryption has not become the default policy for data

communication, while there is no referece for authen-

tication with the rest of the system.

Two very common standards that are being used

in vehicle hardware communication, are CAN (Con-

troller Area Network) (CAN) and LIN(Local Inter-

connect Network) (LIN). CAN was introduced by R.

Bosch in 1983, yet it is now covered by ISO 11898.

CAN was originaly designed for automotive applica-

tions, but nowadays it has been widely adopted in the

industry for device automation. On the other hand

LINs are being used for smaller in vehicle systems

and CANs’ subnetworks. Both of these industry stan-

dards are low level protocols and are used as the main

backbone for the communication of the hardware in

the vehicle. Unfortunately, due to their nature, none

of them supports encryption, making them prone to

many attacks, as previously stated.

First types of attack in vehicles where methods

such as breaking and entry, hotwiring, tampering or

even towing and commonly used tools, in order to

connect the battery source to the ignition, the so called

Slim Jim tool to open locks and other formally known

or unknown ways (Auto theft info, 2009; Car theft,

2009). As technology is evolving, all these ways have

also evolved as well, so vehicles nowadays can be

threatened through computerized attacks.

AUTOSAR highlighted vehicle security issues, as

there is major necessity for secure programming of

the Electronic Contol Units (ECUs), but still can be

programmable only by authorized entities, the elec-

tronic immobilizer must always protect the vehicle

from unauthorized driving via speciﬁc sets of crypto-

graphic techniques. Furthermore, ECU software con-

fronts the problem of existence of unstructured mul-

tiple unused functions or variants of data and also the

secure diagnosis services.

As immobilizer units, RFID modules and generic

anti-theft mechanisms vary in the way that each au-

tomotive vendor designs them for each vehicle, their

application is based on speciﬁc set of cryptographic

routines and services. A very good example of pen-

etrating into these vehicles’ security mechanisms by

exploiting cryptographic primitives is the attacks on

Keeloq algorithm, where a practical key recovery at-

tack (Indesteege et al., 2008; Biham et al., 2007;

Eisenbarth et al., 2008). Another important work by

has proven that the encryption in RFID chipsets used

in vehicles can be cracked without requiring direct

contact, bypassing the security measures of a vehicle

or even of the same immobilizer system (Bono et al.,

2009).

Another vulnerability issue stems from an after-

market product named RFID Zapper. It is an elec-

tronic device that has the capability of permanently

deactivating passive RFID chips without damaging

the chip that is being attacked. Since immobilizers are

based on RFID authentication, it is possible to launch

a DoS on them using proper hardware (RZ, 2010).

Another research revealed vehicle insecurity

through remote exploitation and long dinstance vehi-

cle control. Vulnerabilities where located in the OBD-

II diagnostic port of the vehicles, via the infotain-

ment system of the vehicle (accessories attacks such

as Disk/Mp3 players, USB ports and iPod) and are

indirect physical access methods. They also achieved

short-range wireless access to the vehicles via Blue-

tooth, Remote Keyless Entry, RFIDs, WiFi, and Ded-

icated Short-Range Communications (DSRC). Also

important vulnerability issues where shown through

long-range wireless access attacks exploiting broad-

cast channels and addressable channels (Koscher

et al., 2010),(Checkoway et al., 2011). In another at-

tack scenario (Rouf et al. ,2010), researchers were

able to to track cars and mislead drivers of potential

problems in their vehicles, using as entry point the

wireless tire pressusure monitoring system that mod-

ern cars have, which lack encryption mechanisms.

4 THE PROPOSAL

The ﬁrst step is to redeﬁne the immobilizer system,

creating a safer environment for all the electronic

modules and the vehicle as an entity. Current immo-

bilizers have in IT terms, an “Accept all” policy to-

wards almost all modules of a vehicle, because only

immobilizer and the vehicle keys are the parts that are

being authenticated and not the vehicle as an entity.

Comparing to IT, no other security policy is applied

or exists for the vehicle components. Therefore, there

is a great need of adopting a “Deny all” policy to-

wards all mechanical and peripheral parts of a vehicle

could result to more secure vehicles and less acts of

thefts. In order to implement this kind of IT security

SecuringIn-vehicleCommunicationandRedefiningtheRoleofAutomotiveImmobilizer

223

policy, we introduce a Trusted Third Party (TTP) that

authenticates each vehicle’s module. The TTP can be

installed on the MCU of the vehicle so that all net-

work trafﬁc can parsed from it.

Module categorization is crucial to this security

model for the vehicle’s functionality. The categoriza-

tion is being implemented because a vehicle has many

ECUs and safe usage of the vehicle and safety of the

user might be affected. The categorization of the au-

tomotive modules should be based on the peripheral

topology and are divided in Primary and Secondary

systems. Every time that a malfunction is discov-

ered in a Secondary module the fully usage of the

vehicle must not be affected and the vehicle’s me-

chanical usability should not be suspended, yet the

secondary module will only be deactivated and any

packet trafﬁc from it shall be blocked, as this might

be caused by an attacker. On the other hand, if a Mas-

ter Module is not authenticated, then it will trigger

in this case the Immobilizer to halt any vehicle us-

age. The necessity of this categorization is because

vehicles are designed for long-term use and their parts

suffer a lot from pressure, usage, collisions, resulting

to many minor or serious malfunctions through the

pass of time. It is therefore a functionality issue for

example to let the vehicle moving, even if the MP3

player is broken or even if the power windows are not

working. In another case, the vehicle should not al-

low any further use if its steering wheel confront an

electrical/electronic problem.

Moreover, the vehicle is provided with a built-in

database for different user proﬁles e.g. driver, co-

driver, vehicle technicians/mechanics, parental con-

trol for children/elder person, other persons. Each

proﬁle provides the driver/user with a different setup

and use of the vehicle. So that a technician/mechanic

cannot drive the car for more the 20km, or with

parental control we may allow a young driver use the

car in a certain radius away from home or restrict the

use of the vehicle in certain areas. Moreover, we may

allow a driver use the vehicle in pre-assigned routes,

or even enable some functionalities like mp3 player,

GPS, A/C for certain drivers. Of course each user

may be authenticated either by biometrics or by keys,

e-keys etc. It is obvious that this categorization goes

beyond offering advanced infotainment experience on

the vehicle. The scope of this categorization is to pro-

vide different access level to possible users of the ve-

hicle.

The difﬁcult part is the upgrade of today’s vehi-

cle’s component/modulein order to be easily software

or ﬁrmware, updated and/or upgraded, only by au-

thorized resellers/sources via the TTP. Immobilizer in

this security model acquires a more crucial role for

the vehicle, as it can be triggered by more events that

were not covered up to now and its role becomes more

crucial as its function is needed for triggering the en-

gine’s shut down in case of a malfunction or violation

is detected.

The TTP will control all primary modules. The

detection, identiﬁcation and authentication of all

modules will be made by the TTP. Identically, the pri-

mary modules will control all secondary modules at-

tached to them. Between Primary modules and TTP

there will be a ﬁrewall in order to protect TTP from

attacks launched by unauthorized modules or mali-

ciously injected code on authorized modules. Be-

tween TTP and ICM there will be two party commu-

nications and an application ﬁrewall. The TTP must

be designed in a way that sensors can adapted and

linked with in the future, so as to implement further

security checks in tampering vehicle body-train and

motor engine or for future improvements of the secu-

rity system. During the process of initialization we

have a mutual identiﬁcation of all modules with TTP.

Moreover, vehicle’s users will be identiﬁed and au-

thenticated automatically through the different access

levels that are stored in system proﬁles. System pro-

ﬁles are responsible to enabling and disabling primary

and secondary modules for a given period of time or

use, if authentication is successfully completed. In

case that a severe malfunction is detected in primary

modules, TTP triggers immobilizer with a shut down

message. Secondary modules are deactivated and in-

coming data is blocked.

The structure protocol that we propose is very

close to SSL with mutual authentication, when it

comes to vehicle initialization, and Kerberos like,

whenever a module wants to access another module.

Whenever the vehicle is turned on, the following ex-

change of messages is made with each module. The

Immobilizer sends a iniatilize authethication message

to the module. The module sends the Immobilizer the

ciphers supported, data compression methods, ran-

dom data (RD

) and the access list.

Firstly, the Immobilizer examines the privileges

of the module and whether the access requested is

legitimate, depending on the rights of the user that

has been authenticated, the requested access will be

granted. In case of full restriction, the communication

is terminated. If the module has the rights to make

a request, the Immobilizer replies with the selected

ciphers, data compression methods, an assigned ses-

sion Id and some random data (RD

). The immobi-

lizer appends its certiﬁcate and, a chain of certiﬁcates

beginning with the certiﬁcate of the certiﬁcate author-

ity (CA), if it is not assigned from a root authority.

The module chetacks the Immobilizer certiﬁcate and

SECRYPT2012-InternationalConferenceonSecurityandCryptography

224

sends its own, followed by a chain of certiﬁcates be-

ginning with the certiﬁcate of the CA, if not assigned

from a root authority. Immobilizer checks them and

replies using a mutually generated key K, from RD

and RD

, encrypting the list of the keys that are going

to be used, the period of their validity and the list of

allowed access. The module replies with an encrypted

hash of the previous messages with key K. The server

replies with an encrypted hash of all previous mes-

sages with key K.

Immobilizer acts as a ticketing server,issuing tick-

ets to each module for communication with other

modules, which are valid only for a random period,

subject to exchanged messages, in order to prevent at-

tacks on static period of time and to control the com-

munication and the access of each module. To allow

communication of module

with module

, the follow-

ing procedure is followed. module

sends a nonce

and request for communication with module

, for ac-

cess list AC, encrypted with key K

. The immobilizer

checks whether module

has the right to communi-

cate module

and using AC. In this case, it creates a

random number T, the tickets to be exchanged, a ran-

dom number r, and key K

1,2

. Then it sends module

the message E(r, T, module

, K

1,2

, AC)

encrypted

with key K

. module

, decrypts the message us-

ing Pub

and K

and if it is available for use on

that period responds with H(r, T) encrypted with

key K

. Immobilizer sends to module

the message

E(nonce, T, K

1,2

)

encrypted with key K

. module

decrypts the message using Pub

and K

and obtains

T and K

1,2

. module

sends module

messages en-

crypted with key K

1,2

, appending each time the cur-

rent value of T at the end. module

decrypts the mes-

sages using key K

1,2

and checks the requests against

AC, if any of them exceeds them, then module

issues

an alarm. For each received message value T is de-

creased. K

is the key that immobilizer has issued to

module

, Pr

is the private key of the Immobilizer and

Pub

is the public key of the Immobilizer.

In order to circumvent these measures one might

try to install a “new” Immobilizer system, trying to

initialize the ignition of the engine with his prefered

policies. To protect the vehicle from such attacks, we

must change the policy of the modules. Therefore, on

initial conﬁguration of the vehicle, the modues access

from Internet the ﬁrst hardware proﬁle and store the

Immobilezer’s “ﬁngerprint”. In case the Immobilizer

changes, the modules temporarily authenticate it, de-

manding access to the Internet in order to check for

the afforementioned update in the proﬁle of the ve-

hicle, issuing an alert in case the proﬁle is does not

contain such alternation. Moreover, storing the ﬁn-

gerprint of the immobilizer prevents any disclosure of

important keys from possible future hardware attacks.

5 CONCLUSIONS

When we are stepping from IPv4 to IPv6 and from

http to default https on many web servers in order to

provide advanced security to end users, it is at least

irresponsible to leave such vital and widely used parts

of our everyday lives, without further modiﬁcations

on network layer. It is not coinsidencial that even af-

ter making immobilizers a default security system in

most of the vehicles, especially in cars, they are still

being stolen. This fact is proving that conventional

anti-theft vehicle systems fail to prevent unauthorized

usage. It is obvious that new methods should be de-

veloped to enhance current security status.

The scope of this work is to propose a way to

improve vehicle’s physical layer security by combin-

ing automotive vendors technology and information

technology knowledge. In this proposal, the role of

immobilizer is redeﬁned and is being used as a trig-

ger mechanism, while an advanced TTP undertakes

the complete role of the security mechanism. Fire-

walls are applied in order to prevent electronic at-

tacks on the vehicle from multimedia applications,

vehicles ports or even unauthenticated and malicious

hardware. Moreover, the in-vecicle communication is

encrypted and provides authentication methods to its

modules. The proposed security model can also pro-

vide different proﬁles database for the authenticated

user, preventing malicious attacks and acts of threat

against the vehicle from privilege escalation of po-

tential drivers/users. The illustrated protocol is only

given to provide a general idea of the proposed struc-

ture and how different and more secure it can prove

to be, compared to the current solutions for in-vehicle

communication.

Based on current proposal, many extensions may

be implemented. One may extend user authentica-

tion using biometrics measures instead of portable,

but easy to lose credentials such as keys, e-keys etc.

Moreover each vehicle can have a proﬁle on the man-

ufacturer or on a trusted company which is updated

every time a part is changed. This way, plugging de-

vices in order to compromise vehicle’s security can be

traced and prevented. The TTP can be designed to al-

low Internet or 3G connection so that any kind of sud-

den or strange changes on the vehicle’s proﬁle may

instantly trigger alerts, enabling further security and

proactive measures to be taken, even on road, without

affecting vehicle’s stability and driver’s safety.

SecuringIn-vehicleCommunicationandRedefiningtheRoleofAutomotiveImmobilizer

225

DISCLAIMER AND

ACKNOWLEDGMENTS

Constantinos Patsakis is with the UNESCO Chair in

Data Privacy, but he is solely responsible for the views

expressed in this paper, which do not necessarily re-

ﬂect the position of UNESCO nor commit that organi-

zation. This work was partly supported by the Span-

ish Government through project CONSOLIDER IN-

GENIO 2010 CSD2007-00004 “ARES”.

REFERENCES

Auto theft info, http://www.auto-theft.info/Statistics.htm

D. Bailey, “War Texting: Identifying and Interacting with

Devices on the Telephone Network”, Black Hat, USA

2010.

E. Biham, O. Dunkelman, S. Indesteege, N. Keller, B. Pre-

neel, “How to Steal Cars - A Practical Attack on

KeeLoq”, Crypto 2007.

A. W. M. Bonnick, “Automotive Computer Controlled Sys-

tems, Diagnostic tools and techniques”, Butterworth-

Heinemann, 2001.

S. Bono, M. Green, A. Stubbleﬁeld, A. Juels, A. Rubin,

M. Szydlo, “Security Analysis of a Cryptographically-

Enabled RFID Device”, USENIX Security, July 31-

August 5, 2007.

Car theft, http://www.car-theft.org/theft-methods

S. Checkoway, D. McCoy, B. Kantor, D. Anderson, H.

Shacham, S. Savage, K. Koscher, A. Czeskis, F. Roes-

ner, T. Kohno, “Comprehensive Experimental Analy-

ses of Automotive Attack Surfaces”, USENIX Secu-

rity, August 1012, 2011.

EE Times, http://www.eetimes.com/design/automotive-

design/4213069/AUTOSAR-architecture-expands-sa

fety-and-security-applications?pageNumber=0

T. Eisenbarth, T. Kasper, A. Moradi, C. Paar1, M.

Salmasizadeh and M. T. M. Shalmani, “Physical

Cryptanalysis of KeeLoq Code Hopping Applica-

tions”. Ruhr University of Bochum, Germany http://

eprint.iacr.org/2008/058.

Electronic Theft Prevention, The Immobilizer Project, re-

port from Larmtjanst, Swedish insurance Federation

Company, 2004.

Federal Business Opportunities, Cyber security and Safety

of Motor Vehicles Equipped with Electronic Control

Systems, Solicitation Number: DTRT57-11-SS-

00007 https://www.fbo.gov/index?s=opportunity

&mode=form&id=40c0c2730b334df090dba322a61e

956f&tab=core& cview=0

A. E. Fuhs, “Hybrid Vehicles and the Future of Personal

Trensportation”, CRC Press, Taylor & Francis Group,

2009.

H. Heisler, “Andvanced Vehicle Technology”, 2nd ed.

Butterworth-Heinemann, 2002.

Homeland Security News Wire, http://www.homeland se-

curitynewswire.com/ car- immobilizers- no- longer-

problem-car-thieves.

S. Indesteege , N. Keller , O. Dunkelman , E. Biham ,

B. Preneel, “A practical attack on KeeLoq”, EURO-

CRYPT’08 Proceedings of the theory and applications

of cryptographic techniques 27th annual international

conference on Advances in cryptology, 2008.

K. Koscher, A. Czeskis, F. Roesner, S. Patel, T. Kohno, S.

Checkoway, D. McCoy, B. Kantor, D. Anderson, H.

Shacham, S. Savage, “Experimental Security Analy-

sis of a Modern Automobile”, IEEE Symposium on

Security and Privacy, Oakland, CA, May 16-19, 2010.

K. Lemke, C. Paar, M. Wolf, “Embedded security in cars,

securing current and future automotive it applica-

tions”, Springer-Verlag, 2006.

McAfee, “Caution: Malware Ahead”, http://

www.mcafee.com/ us/ resources/ reports/ rp-caution-

malware-ahead.pdf

N. Naver, F. Simonot-Lion, “Automotive Embedded Sys-

tems Handbook”, Industrial Information Technology,

CRC Press, Taylor and Francis Group, 2009.

K. Nohl, “Car Immobilizer Security”, escar 2010, Bremen,

November 2010.

RFID-Zapper project: https://events.ccc.de/congress/2005/

static/r/f/i/RFID-Zapper(EN) 77f3.html

Automotive Open System Architecture, AUTOSAR,

http://www.autosar.org/

LIN Overview, “Lin Concept”, LIN Administration,

http://www.lin-subbus.org/index.php?pid=5&lang=en

&sid=7978e50790ccd16bb12bf6307eae5a74

Bosch speciﬁcation of CAN-bus, http://www.semicon

ductors.bosch.de/media/pdf/canliteratur/can2spec.pdf

I. Rouf, R. Miller, H. Mustafa, T. Taylor, S. Oh, W. Xu, M.

Gruteser, W. Trappe, and I. Seskar , ”Security and Pri-

vacy Vulnerabilities of In-Car Wireless Networks: A

Tire Pressure Monitoring System Case Study,” in Pro-

ceedings of the 19th USENIX Security Symposium,

Washington DC, August 11-13, 2010

SECRYPT2012-InternationalConferenceonSecurityandCryptography

226
