Verifying Privacy by Little Interaction and No Process Equivalence

Denis Butin

∗1

and Giampaolo Bella

School of Computing, Dublin City University, Dublin, Ireland

Dipartimento di Matematica e Informatica, Universit`a di Catania, Catania, Italy

Software Technology Research Laboratory, De Montfort University, Leicester, U.K.

Keywords:

e-Voting, Privacy, Inductive Method.

Abstract:

While machine-assisted veriﬁcation of classical security goals such as conﬁdentiality and authentication is

well-established, it is less mature for recent ones. Electronic voting protocols claim properties such as voter

privacy. The most common modelling involves indistinguishability, and is speciﬁed via trace equivalence in

cryptographic extensions of process calculi. However, it has shown restrictions. We describe a novel model,

based on unlinkability between two pieces of information. Specifying it as an extension to the Inductive

Method allows us to establish voter privacy without the need for approximation or session bounding. The two

models and their latest speciﬁcations are contrasted.

1 INTRODUCTION

Formal analysis of security protocols is even more

relevant as electronic voting (e-voting) starts being

used for ofﬁcial elections across the world. The

novel properties claimed by such protocols require

new models and tools, especially when computer-

aided analysis is desired. A key objective of e-voting

protocols, called voter privacy or ballot secrecy, states

that the way a particular voter voted is not known

to the adversary. While the vote itself obviously be-

comes public in the ﬁnal stage, it is the link between

voter and ballot that must remain conﬁdential. Other

goals than voter privacy are also commonly studied

for e-voting protocols, but we focus on voter privacy

in this work.

The most notable efforts in the area, which are

rather recent, are based upon a widely-accepted

model, process equivalence. These have advanced

computer-aided analysis of e-voting protocols signif-

icantly, albeit all existing tools face some limitations.

The general idea of using equivalences in process cal-

culi was presented as early as in 1996 (Schneider and

Sidiropoulos, 1996), concurrently with the Inductive

Method’s inception (Paulson, 1998). This position

paper makes the point that also the latter can be used

proﬁtably to verify e-voting protocols without inher-

ent limitations about size and features, hence offering

∗

Research supported by the SFI grant 08/RFP/

CMS1347.

a valuable parallel means of analysis. The analyst gets

strong assistance in his task — for examplein keeping

a clear picture of the various scenarios that the execu-

tion of the protocol may entail, over which the goals

must be assessed.

However, interaction is only signiﬁcant during

proof development, that is, when a line of reasoning

is being investigated for the ﬁrst time. With automatic

tools, this effort usually results in the implementation

of extended analysis routines that can later be invoked

and run fully automatically. Similarly, although theo-

rem proving remains interactive, vast portions of the

proof scripts can be re-used with minor adaptations

over new case studies, when these require the same

line of reasoning. For example, once conﬁdential-

ity proofs were developed (Paulson, 1998), the cor-

responding scripts received negligible modiﬁcations

throughout subsequent applications. We argue that

this feature of interactive tools has not been empha-

sised properly so far. Therefore, the effort of develop-

ing a proof for an innovative property could be com-

parable to that of expanding an automatic tool for the

same reason. Proof reuse could be the right balance

between automation and interaction.

After recalling the main existing efforts, our de-

bate starts by comparing them with the mechanization

of our model in the Inductive Method.

251

Butin D. and Bella G..

Verifying Privacy by Little Interaction and No Process Equivalence.

DOI: 10.5220/0004043502510256

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 251-256

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

2 EXISTING MODEL AND

TOOLS FOR PRIVACY

ANALYSIS

Most existing papers on formal privacy modelling in

the context of e-voting are based on the following in-

distinguishability criterion: it must not be possible to

distinguish between a situation in which the honest

voter V

voted x and the honest voter V

voted y, and

one in which the converse is true. A cryptographic

extension of a process calculus is then used, often the

applied pi calculus. Two main tools build upon this

model.

ProVerif. The automatic ProVerif tool (Blanchet,

1998) uses an algorithm based on Horn clauses. It

is able to efﬁciently check an under-approximation

of (i.e., a stronger equivalence than) observational

equivalence between processes in the applied pi cal-

culus for an unbounded number of sessions (Blanchet

et al., 2008). Because of the approximation, it lacks

in precision and may producefalse negatives— spuri-

ous attacks may be found. Supplementary equational

theories for broader cryptographic primitives support

are easy to add, but this may lead to non-termination

in some cases. ProVerif was used to analyse — for

a ﬁxed number of voters — voter privacy in the Fu-

jioka, Okamoto and Ohta (FOO) (Fujioka et al., 1993)

protocol in (Delaune et al., 2009). FOO involves two

election ofﬁcials and uses blind signatures as well as

bit commitments. The bisimulation reasoning was

done by hand.

AKiSs. More recently, the focus in the process

equivalence approach has shifted from trying to prove

observational equivalence to checking a weaker kind

of equivalence: trace equivalence (≈

). In (Chadha

et al., 2012), a new cryptographic process calcu-

lus is introduced alongside a novel procedure for

checking equivalence. Speciﬁcally, under- and over-

approximations of ≈

are introduced, the ﬁne-grained

trace equivalence ≈

and the coarse trace equiva-

lence ≈

. Over-approximation can prove protocols

correct, and under-approximation can rule out ﬂawed

protocols. The calculus supports a broad variety of

cryptographic primitives: all those that can be mod-

elled in an optimally reducing convergent rewrite sys-

tem. The procedure is limited to a bounded number of

protocol sessions. For a class of processes called de-

terminate, there is a coincidence between ≈

, ≈

and

observational equivalence. Automation is provided

by the AKiSs tool. The work also includes an analysis

of voter privacy in FOO. However, since the model of

FOO does not yield a determinate process, observa-

tional equivalence cannot be proved by this approach

and the approximation ≈

must be checked instead.

3 DISCUSSION

Precision. Since ProVerif systematically uses

under-approximations, it is not precise in general.

While it will not deem a ﬂawed protocol correct,

it may fail to validate a correct protocol due to the

detection of a false attack. For AKiSs, precision

depends on the class of the process modelling the

protocol. Those which can be modelled using

determinate processes can be checked directly for

observational equivalence and ≈

because of their

coincidence with ≈

in that class. On the other hand,

some e-voting protocols, particularly those using

phases like FOO, must be under-approximatedby ≈

because they do not lead to determinate processes. In

that case, as for ProVerif, the risk of spurious attack

detection subsists. Unlinkability in the Inductive

Method is treated by inductive theorem proving, so

there can be no false positives. When unlinkability

cannot be established, attacks are not given explicitly

but examination of the remaining subgoal allows

the user to trace back the ﬂaw to the problematic

protocol step. This interactivity gives greater insight

into the protocol’s intricacies but requires more effort

than the aforementioned tools. Another aspect of

precision is session bounding. While the Inductive

Method and ProVerif both support unlimited protocol

sessions, the computational cost of AKiSs blows up

exponentially when more sessions are interleaved.

Automation vs. Interaction. AKiSs is fully auto-

mated. Voter privacyin ProVerif was checked by hand

in (Kremer and Ryan, 2005). An automatic veriﬁ-

cation in ProVerif was presented in (Delaune et al.,

2008), but a translation algorithm is involved and its

correctness is not formally proven. In (Delaune et al.,

2009), a ProVerif privacy proof for a ﬁxed number of

voters is partially automated. The Inductive Method is

mechanized in Isabelle/HOL, an interactive theorem-

prover. As noted above, this requires user interac-

tion at proof development time, whereas ProVerif and

AKiSs require it at tool development time.

Termination. Termination is guaranteed neither in

ProVerif nor AKiSs. While ProVerif features a res-

olution method that ensures termination for a spe-

ciﬁc syntactic transformation of protocol models, this

method is limited to secrecy and authentication prop-

erties(Blanchet and Podelski, 2005). Since the Induc-

SECRYPT2012-InternationalConferenceonSecurityandCryptography

252

tive Method is based on induction, there is no termi-

nation issue.

Supported Cryptographic Primitives. Associa-

tive/commutative (A/C) operators are currently sup-

ported by none of the tools, despite their usefulness

for the modelling of protocols using exponentiation

or XOR. Blind signatures, which are commonly used

in e-voting protocols, are supported by all three tools

compared in this paper. AKiSs supports a larger vari-

ety of cryptographic primitives than ProVerif and the

current version of the Inductive Method. In (Chadha

et al., 2012), Chadha et al. conjecture that all those

which can be modelled in a rewrite system with a

speciﬁc convergence propertyare supported. Notably,

trapdoor commitments can be modelled. By contrast,

supporting new cryptographic primitives in the In-

ductive Method requires modelling them through ad-

ditional rules using existing primitives or changing

the underlying framework. The latter option requires

more work since speciﬁc assumptions about the inter-

action of operators are made in the theory Message,

which is always imported. On the other hand, major

modiﬁcations have been performed successfully, for

instance in (Martina and Paulson, 2011), demonstrat-

ing the ﬂexibility of the approach. New cryptographic

primitives can be added easily to the applied pi calcu-

lus by devising new equational theories, but the re-

sulting model may be beyond the scope of the tool’s

automatic analysis (Delaune et al., 2010).

Efﬁciency. The Authors of (Chadha et al., 2012)

state that the automated analysis of privacy for FOO

requires a few minutes on a modern laptop. Load-

ing and verifying all FOO theories in Isabelle/HOL

takes a similar time. However, our FOO theory also

establishes other useful security guarantees about the

protocol. Another metric is the respective human ef-

fort necessary to formalise protocols and their goals

before the actual analysis. This aspect remains to be

quantiﬁed.

Synthesis. Table 1 summarises the comparison but

does not aim for exhaustiveness. The “large set” of

cryptographic primitives supported by AKiSs is the

set of those that can be modelled in an optimally re-

ducing convergent rewrite system.

4 OUTLINE OF VOTER PRIVACY

IN THE INDUCTIVE METHOD

The Inductive Method. The Inductive Method

(Bella, 2007; Paulson, 1998), speciﬁed in the inter-

active theorem-prover Isabelle/HOL, has never been

applied to e-voting protocols until now. It models pro-

tocol steps and a Dolev-Yao adversary’s actions as in-

ductive rules. At its core are inductively deﬁned mes-

sage operators. Initially supported message compo-

nents are agent names, guessable integers (numbers),

nonces, hashes and ciphertexts. The parts operator

takes as input a message and returns the set of all its

components, including encrypted ones for which the

key is not available. It is normally used to denote all

elements appearing in network trafﬁc. analz bears

close resemblance to parts, but takes into account

cryptography. Only ciphertext for which the corre-

sponding decryption key is available yields the em-

bedded plaintext. As opposed to parts and analz, the

synth operator speciﬁes message building rather than

message deconstruction. Taking into account avail-

able cryptographic keys, it inductively deﬁnes the set

of messages that can be built from an initial message

set. Ciphertexts and message hashes can be generated

from available messages. Agent names and guessable

numbers can be synthesised ex nihilo.

Cryptographic keys in Isabelle have the type key.

In the case of asymmetric keys, for encryption, key

pairs are modelled by priEK and pubEK. For signa-

tures, priSK and pubSK. The invKey function turns an

asymmetric key into its associated reciprocal key, e.g.

invKey(priEK A) = pubEK A.

Not only is the number of agents unbounded: ev-

ery agent is also able to interleave any number of

protocol sessions. Since proofs are carried out in-

ductively, susceptibility to replay attacks is taken into

account. Agents can be either the Server (a trusted

agent which knows all shared keys and is never com-

promised), a friendly agent or the Spy, who embodies

the threat model.

Three message events are available. The Says

event models the sending of a message between

agents. For instance, Says A B {Nonce Na} means

that agent A sends agentB a message consisting solely

of the nonce Na. It is realistic to assume that not

all messages reach their destination, hence message

sending does not imply message reception in gen-

eral. However, a sent message can be delivered as

intended; this is modelled by the Gets events, which

precisely represents the reception of a message by an

agent. The Notes event models the addition of a mes-

sage to an agent’s knowledge, for later use. It can be

seen as a private recording of information.

Every protocol step is modelled as an inductive

rule, with preconditions and a postcondition. The pro-

tocol model is the set of all admissible traces built

from those steps. The empty trace is also allowed,

VerifyingPrivacybyLittleInteractionandNoProcessEquivalence

253

Table 1: Synthesis of characteristics of mechanized FOO privacy analyses.

ProVerif AKiSs Inductive Method

Precision Precise for determinate

processes, else under-

approximation

Under-approximation Precise for generalised as-

sociation synthesis

Operation Partial automation Full automation Interactive proving

Unbounded sessions Yes No Yes

Systematic termination No No Yes

Supported cryptographic

primitives

Usual + blind signa-

tures, bit commitments,

proxy re-encryption

Large set conjectured Usual + blind signatures,

bit commitments

and modelled by the Nil event. Furthermore, a Fake

event accounts for message forgery by the Spy, who

builds and sends everything she can from components

extracted from network trafﬁc:

| Fake:

[[evsf ∈ bankerb gets;

X ∈ synth (analz (knows Spy evsf))]]

=⇒ Says Spy B X # evsf ∈ bankerb gets

Extensions for e-Voting Protocols. The following

extensions are protocol independent. Blind signatures

can be modelled as an inductive rule using symmetric

cryptography and agent knowledge:

| Unblinding:

[[evsb ∈ foo;

Crypt (priSK V) BSBody ∈ analz (spies evsb);

BSBody = Crypt b (Crypt c (Nonce N)); b ∈ symKeys;

Key b ∈ analz (spies evsb)]]

=⇒ Notes Spy (Crypt (priSK V) (Crypt c (Nonce N)))

# evsb ∈ foo

New operators are added to the Inductive Method

to make the treatment of voter privacy possible. One

is analzplus: by building upon the traditional mes-

sage set analyzer analz, it is empowered with an ex-

ternal message set from which extra decryption keys

can be derived. This helps to deﬁne aanalz, whereby

the attacker extracts all meaningful associations from

protocol events and traces:

primrec aanalz :: agent => event list => msg set set

where

aanalz Nil: aanalz A [] = {}

| aanalz Cons:

aanalz A (ev # evs) =

(if A = Spy then

(case ev of

Says A

′

B X ⇒

(if A

′

∈ bad then aanalz Spy evs

else if isAnms X

then insert ({Agent B} ∪ (analzplus {X}

(analz(knows Spy evs)))) (aanalz Spy evs)

else insert ({Agent B} ∪ {Agent A

′

} ∪

(analzplus {X} (analz(knows Spy evs))))

(aanalz Spy evs))

| Gets A

′

X ⇒ aanalz Spy evs

| Notes A

′

X ⇒ aanalz Spy evs)

else aanalz A evs)

For instance, considering the event Says A B X

where A is uncompromised and evs is a generic pro-

tocol trace,

aanalz (Spy Says A B X # evs) = insert

(Agent A ∪ Agent B ∪ analzplus X (analz (knows Spy evs)))

(aanalz Spy evs)

The association synthesiser asynth builds new as-

sociations out of existing ones that share a common

element. The common element should not be one

of the election ofﬁcials’ names since those appear in

all protocol runs and are therefore linked to all voter

identities. It is deﬁned as follows:

inductive set

asynth :: msg set set ⇒ msg set set

for as :: msg set set

where

asynth Build [intro]:

[[a1 ∈ as; a2 ∈ as; m ∈ a1; m ∈ a2;

m 6= Agent Adm; m 6= Agent Col]]

=⇒ a1 ∪ a2 ∈ asynth as

Associations arising from a generic trace of the

protocol model are examined using these operators.

In particular, the set asynth(aanalz Spy evs) for-

malises all possible associations that the attacker can

build out of active observation of the trace evs. Un-

linkability of two pieces of information can then be

speciﬁed by stating that they cannot belong to any as-

sociation in this set at the same time.

Verifying Privacy for FOO. We now focus on the

case study of the FOO protocol. The main privacy

theorem is stated as follows: whenever the ﬁrst step of

the protocol was performed by a regular honest voter,

any association containing her vote cannot also con-

tain her name.

theorem foo V privacy asynth:

[[Says V Adm {|Agent V,

Crypt (priSK V) (Crypt b (Crypt c (Nonce Nv)))|} ∈ set evs;

a ∈ (asynth (aanalz Spy evs));

SECRYPT2012-InternationalConferenceonSecurityandCryptography

254

Nonce Nv ∈ a; V /∈ bad; V 6= Adm; V 6= Col; evs ∈ foo]]

=⇒ Agent V /∈ a

Although this statement is protocol-dependent, it

is simple enough be adapted to any e-voting proto-

col — precisely as the current literature shows with

the conﬁdentiality goal. No honesty assumptions are

made about the election ofﬁcials Administrator and

Collector.

The proof involvescase-splitsabout possibleasso-

ciations arising from each protocol step, and a num-

ber of lemmas specifying possible associations, such

as the following one:

lemma aanalz PR:

[[a ∈ aanalz Spy evs; Crypt P R ∈ a; evs ∈ foo]] =⇒

(Agent Col /∈ a ∨

(Agent V ∈ a −→ V ∈ bad ∨ V = Col) ∨

(Nonce Nv /∈ parts {R})) ∧

((Nonce Nv /∈ a) ∨

(Key (invKey P) ∈ analz (spies evs) ∧

Agent V /∈ parts {R}))

This lemma establishes properties of association

sets from the protocol model that contain at least one

ciphertext. It states that if a nonce appears as an

atomic component of the body of the ciphertext, then

either the name of the election ofﬁcial Collector does

not appear in the association, or all agent names ap-

pearing in it are either dishonest agents or the Collec-

tor.

Specifying and verifying the unlinkability model

involved substantial effort. About 20 subsidiary lem-

mas had to be proved beforehand. Many of them, like

the one just mentioned, analz PR, establish properties

of association sets. Remarkably, the generic nature of

the proof has great potential for reuse over other pro-

tocols. Also, its redundant parts may be programmed

as ML tactics for greater automation. In cases where

unlinkability does not hold, the subgoal that cannot

be proven indicates which protocol step can lead to

an attack.

5 CONCLUSIONS

We shed a different light on voter privacy by seeing

it as unlinkability property between two pieces of in-

formation. The feasibility of this model is shown by

a speciﬁcation in the Inductive Method and a suc-

cessful privacy proof for a classic e-voting proto-

col. While the process equivalence model is show-

ing steady progress through new trace equivalence

approximations, our machine-assisted analysis is pre-

cise for an unbounded number of sessions, and sup-

ports proof reuse. Its interactive nature also provides

broader protocol understanding to the analyst. Since

process equivalence-based methods are not currently

able to deal with all protocols, it seems worthwhile to

investigate alternative approaches like this one.

A submission of our Isabelle theories to the online

Archive of Formal Proofs (Klein et al., 2012) is being

prepared.

Future Work. Demonstrating the ﬂexibility and

reusability of our speciﬁcation through additional ex-

amples is our main next task. The proofs must be

adapted to a generalised association synthesiser. We

then intend to analyse protocols that cannot be han-

dled in current implementations of the indistinguisha-

bility model, such as e-passport protocols, and in-

vestigate the speciﬁcation of associative/commutative

operators. Finally, we plan to model other privacy-

type properties, such as coercion resistance.

REFERENCES

Bella, G. (2007). Formal Correctness of Security Protocols.

Information Security and Cryptography. Springer.

Blanchet, B. (1998). An efﬁcient cryptographic proto-

col veriﬁer based on Prolog rules. In Proc. of the

14th IEEE Computer Security Foundations Workshop

(CSFW’01), pages 82–96. IEEE Press.

Blanchet, B., Abadi, M., and Fournet, C. (2008). Auto-

mated veriﬁcation of selected equivalences for secu-

rity protocols. Journal of Logic and Algebraic Pro-

gramming, 75(1):3–51.

Blanchet, B. and Podelski, A. (2005). Veriﬁcation of

cryptographic protocols: tagging enforces termina-

tion. Theoretical Computer Science, 333(1-2):67–90.

Special issue FoSSaCS’03.

Chadha, R., Ciobˆac˘a, S¸., and Kremer, S. (2012). Auto-

mated veriﬁcation of equivalence properties of cryp-

tographic protocols. In Programming Languages and

Systems —Proceedings of the 21th European Sympo-

sium on Programming (ESOP’12), Lecture Notes in

Computer Science. Springer. To appear.

Delaune, S., Kremer, S., and Ryan, M. (2009). Verifying

privacy-type properties of electronic voting protocols.

Journal of Computer Security, 17(4):435–487.

Delaune, S., Kremer, S., and Ryan, M. D. (2010). Verifying

privacy-type properties of electronic voting protocols:

A taster. In Towards Trustworthy Elections – New Di-

rections in Electronic Voting, volume 6000 of Lecture

Notes in Computer Science, pages 289–309. Springer.

Delaune, S., Ryan, M., and Smyth, B. (2008). Automatic

veriﬁcation of privacy properties in the applied pi cal-

culus. Syntax, 263/2008:263278.

Fujioka, A., Okamoto, T., and Ohta, K. (1993). A practical

secret voting scheme for large scale elections. In Pro-

ceedings of the Workshop on the Theory and Applica-

tion of Cryptographic Techniques: Advances in Cryp-

tology, ASIACRYPT ’a92, pages 244–251. Springer-

Verlag.

VerifyingPrivacybyLittleInteractionandNoProcessEquivalence

255

Klein, G., Nipkow, T., and Paulson, L. (2012). In The

Archive of Formal Proofs.

http://afp.sf.net

Kremer, S. and Ryan, M. (2005). Analysis of an elec-

tronic voting protocol in the applied pi calculus. In

In Proc. 14th European Symposium On Programming

(ESOP05), volume 3444 of LNCS, pages 186–200.

Springer.

Martina, J. E. and Paulson, L. C. (2011). Verifying

multicast-based security protocols using the inductive

method. In Workshop on Formal Methods and Cryp-

tography (CryptoForma 2011).

Paulson, L. C. (1998). The inductive approach to verifying

cryptographic protocols. Journal of Computer Secu-

rity, 6:85–128.

Schneider, S. and Sidiropoulos, A. (1996). CSP and

anonymity. In In European Symposium on Research in

Computer Security, pages 198–218. Springer-Verlag.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

256
