Hash Algorithms for 8051-based Sensornodes

Manuel Koschuch, Matthias Hudler and Michael Kr¨uger

Competence Centre for IT-Security, FH Campus Wien, University of Applied Science,

Favoritenstrasse 226, 1100 Vienna, Austria

Keywords:

Efﬁcient Implementation, Hash Algorithms, Sensor Networks, Sensor Nodes, SHA-1, SHA-3, Tiger Hash.

Abstract:

Wireless Sensors Networks are still an emerging technology. Their special architecture allows for unique ap-

plications that would be impossible, or at least very difﬁcult, to implement using other technologies. But the

wireless data transmission between the single nodes poses new challenges from a security point of view: the

single messages have to be secured against eavesdropping and manipulation, as well as the individual nodes

have to be secured against capture and extraction of their secret key. Cryptographic hash functions are an inte-

gral part of most cryptographic network protocols, whether they are used for signatures or message integrity.

In this position paper, we describe a preliminary performance evaluation of three very different hash-functions

on a Texas Instruments CC2530 sensor node, based on an 8051 microcontroller: Tiger, representing a hash

designed for 64-bit architectures, the current standard SHA-1, and Grøstl, a SHA-3 ﬁnalist. Our preliminary

results indicate that even without any major optimizations hash algorithms that were clearly not designed to

run on constrained devices can be adapted to these environments with quite acceptable results, thereby giving

designers of sensor network security protocols new implementation options.

1 INTRODUCTION

Wireless Sensor Networks (WSNs) are an ever emerg-

ing ﬁeld of technology. The usage of a huge number

of tiny sensor nodes, distributed across a large area

and communicating their sensor readings in a per-

hop fashion to a centralized base-station for process-

ing allows for efﬁcient measurement of environmental

conditions, power plant or factory surveillance, traf-

ﬁc monitoring, or new applications in personal health

care and ubiquitous computing.

But the distributed nature of WSNs also requires

the implementation of security measures against

eavesdropping on or manipulating the communication

over the air interface. Single sensor nodes can also

very easily and almost undetectable be removed from

the network, so that an attacker can try to read out

any secret keys stored in the node. Traditional ap-

proaches using asymmetric cryptography are usually

assumed to be too resource intensive for the small, 8-

Bit sensor nodes, while symmetric cryptography has

the drawback of lacking authentication and the neces-

sity to distribute the same key across a (potentially

large) number of nodes.

But regardless of the actual cryptographic techni-

que used, cryptographic hash-functions play a major

role in almost every implementation of a secure com-

munication scheme. Whether they are used for sig-

nature generation, key derivation, or HMAC calcula-

tions, an efﬁcient and secure way of hashing usually

quite small amounts of data is needed.

There is already a huge number of publications

dealing with security protocols for WSNs, some of

them also heavily relying on hash-functions. But

when it comes to evaluating the performance of dif-

ferent hashes on small, constrained devices like 8-bit

microcontrollers, or whether there are viable alterna-

tives to the ubiquitous SHA-1, there is a much lower

number of research results available.

In this position paper we try to make a ﬁrst, delib-

erately rough, approach of trying to compare the per-

formance of different hash-functions, also some that

have never been designed with embedded devices in

mind, on a Texas Instruments CC2530 Sensor node,

using an 8051 microcontroller with 32MHz clock fre-

quency. Our goal is to determine whether is is sen-

sible to also consider non-standard, but nevertheless

secure hash-functions when designing a custom secu-

rity protocol for a WSN, or if the existing standards

also satisfy the special requirements of embedded de-

vices.

The remainder of this position paper is structured

Koschuch M., Hudler M. and Krüger M..

Hash Algorithms for 8051-based Sensornodes.

DOI: 10.5220/0004062400650068

In Proceedings of the International Conference on Data Communication Networking, e-Business and Optical Communication Systems (DCNET-2012),

pages 65-68

ISBN: 978-989-8565-23-5

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

as follows: in Section 2 we give an overview of the

properties of a hash-function that are required to con-

sider that function secure as well as a short descrip-

tion of the functions selected for this ﬁrst test. Sec-

tion 3 details our modiﬁcations to the hash functions

to make them work on the target device and ﬁrst re-

sults, while ﬁnally Section 4 describes the next steps

planned.

2 HASH FUNCTIONS

A general hash-function has the property of mapping

arbitrary length input to ﬁxed length output, and do-

ing so efﬁciently. So the ﬁrst two properties of every

hash-function are

• Compression and

• Efﬁciency

These two properties do not sufﬁce for a crypto-

graphic hash-function, where in addition the follow-

ing characteristics must hold:

• Preimage Resistance

• Second-Preimage Resistance and

• Collision Resistance

For the following discussion, let H(x) = y denote

the hash-function H applied to the arbitrary length in-

put x, resulting in the ﬁxed length output y.

Preimage resistance means that given y it should

be unfeasible to determine x.

Second-Preimage resistance means that given the

tuple (x,y) it should be infeasible to ﬁnd x

′

6= x such

that H(x

′

) = y.

Finally, collision resistance as the strongest prop-

erty requires that it should be infeasible to ﬁnd x and

′

with x 6= x

′

such that H(x) = H(x

′

The strongest attack against a given hash-function

with n-bit output length is to ﬁnd two distinct values

yielding the same hash, which, due to the birthday

paradox, results in an effort of 2

n/2

. With 2

being

the approximate practical complexity limit today, this

translates into a minimal output length of the hash-

function of 160 bit.

SHA-1 fulﬁlls this requirement, as well as all the

ﬁnal candidates of the SHA-3 competition. For the

purpose of this work, we selected three different hash-

functions and discussed a fourth one.

2.1 Tiger

The Tiger hash-function (Anderson and Biham, 1996)

was designed for 64-bit processors, and serves as

more or less a “worst-case” design for an 8-bit mi-

crocontroller. It consists of (at least) 3 passes, with 8

rounds each, utilizing 4 S-Boxes with a combined size

of 8 Kbytes. It operates on 64-byte input blocks and

generates a 192-bit digest. Internally only additions,

subtractions, multiplications and xor’s of 64-bit val-

ues are used, in addition to the S-Box lookups. This

structure allows for a very efﬁcient implementation

on machines which are able to handle 64 bit natively,

but poses a huge challenge when ported to an 8-bit

microcontroller.

We chose this algorithm mainly as a “proof-of-

concept” to ﬁnd out whether porting of such a hash-

function with clearly different design goals in mind

results in at least decent performance or is even pos-

sible at all.

2.2 SHA-1

The Secure-Hash-Algorithm (SHA) family is still

(since 1995, 1993 when one also counts SHA-0) the

current standard for hash algorithms. Currently there

are basically 2 different versions used, SHA-1 with

an output size of 160 bit, and SHA-2 with an output

size of 224, 256, 384 or 512 bit, respectively (NIST,

2002).

Currently there are no known published attacks

against full SHA-2, yet there do exists attacks against

SHA-1 (Manuel, 2011). In this work, we use a SHA-

1 implementation as representation for the still most

widely deployed hash-function.

SHA-1 takes 64-byte input blocks, and produces

a 160-bit message digest. It is designed with 32-bit

machines in mind and consists of 80 rounds, with the

round function changing every 20 rounds. Internally,

only logical operations and circular shifts are used.

2.3 AES-based Hashes

The usual approach of designing a hash-function is to

use some function block with compression property,

whose output looks as random as possible, and repeat-

edly apply this function to the input until all message

blocks are processed. Since a block cipher can also

be seen as a compression function (given n-bit block

size and a k-bit key, the cipher maps this (n + k)-bit

Input to an n-bit output), using the current standard

for symmetric cryptography as a hash bulding block

seems like a natural choice.

The problem when simply using the Advanced

Encryption Standard (AES) with the standard con-

struction of a hash-function lies in its block-size:

while Rijndael, the underlying algorithm for AES,

supports larger blocks, AES is ﬁxed to 128-bit block

DCNET2012-InternationalConferenceonDataCommunicationNetworking

size. This results in a 128-bit digest, too small to be

considered secure against simple brute-force attacks.

In (Bos et al., 2011) several techniques to increase

this digest are proposed, some of them we are cur-

rently evaluating on the sensor node. Using an AES-

based hash would allow the usage of the existing AES

co-processor on the node, in this way hopefully mit-

igating the additional complexity required to extend

the digest size.

2.4 SHA-3

The 6-year long competition to ﬁnd the new standard

hash algorithm SHA-3 is expected to be ﬁnished by

the end of 2012. Currently, there are ﬁve ﬁnalists left:

BLAKE (Jean-Philippe Aumasson and Luca Henzen

and Willi Meier Raphael C.-W. Phan, 2010), Grøstl

(Gauravaram,P. and Knudsen, L. R. and Matusiewicz,

K. and Mendel, F. and Rechberger, C. and Schlffer,

M. and and Thomsen, S. S., 2011), JH (Wu, H., 2011),

Keccak (Bertoni, G. and Daemen, J. and Peeters, M.

and Assche, G. v., 2011), and Skein (Ferguson, N. and

Lucks, S. and Whiting, B. S. D. and Bellare, M. and

Kohno, T. and Walker, J. C. J., 2008). All of these

functions have a digest size of at least 224 bits.

We chose Grøstl as an example candidate for a

ﬁrst comparison, although an evaluation of the re-

maining 4 candidates is also planned. Grøstl operates

on a 64-byte input, producing a 256 or 512-bit mes-

sage digest. Internally, it’s structure is very similar to

AES, even using the same S-Box as deﬁned for Rijn-

dael, and also using similar approaches operating on

a two-dimensional state. The individual round opera-

tions are repeated 10 or 14 times, for 256 or 512 bit

digest size, respectively.

3 IMPLEMENTATION AND

PRELIMINARY RESULTS

Tiger, SHA-1 and Grøstl-256 were implemented

on a Texas Instruments Zig-Bee compliant CC2530

Sensornode, featuring an 8051 microcontroller core

clocked at 32MHz. As compiler, the IAR C compiler

for 8051, version 8.10.1, was used.

As a ﬁrst test, no assembler optimizations were

performed, the code was entirely written in C.

In the case of SHA-1, the reference implementa-

tion given in RFC3174 (Eastlake, D. and Jones, P.,

2001) was slightly modiﬁed, some functions were ex-

changed by macros for better speed.

Tiger was entirely ported to 32-bit datatypes that

are supported in IAR declaring them as long long.

All basic operation on the 64-bit values from the the

Tiger reference implementations were rewritten to op-

erations on 32-bit datatypes. We also performed an

additional split and tried to use 16-bit datataypes in-

stead, but due to the resulting increase in codesize, the

16-bit version ran slower then the 32-bit one.

For Grøstl we also used the reference implementa-

tion from the project homepage. Again, slight modiﬁ-

cations were performed to adapt the code to the 8051

platform.

We then used the Tiger reference test vectors as

input to all three hash-functionsand timed the number

of cycles needed for processing a single block (that

is, 64 Bytes or 512 Bits, respectively, for all hash-

functions analyzed). Table 1 gives an overview of our

results, while Table 2 compares the code sizes for the

three implementations.

Our results show that, barring any optimizations

but the most obvious ones, even a hash-function de-

signed for 64-bit machines like Tiger can achieve

acceptable performance on an 8051 microcontroller.

The bad results for Grøstl are surprising yet will be

optimized during the next steps, at least on an AT-

mega163 Grøstl has already been shown to perform

very favorably. Again, our focus in this ﬁrst round

was only on a comparison of unoptimized versions of

the algorithms, ported straightforward from the refer-

ence implementations.

Table 1: Number of cycles per 64-byte input block.

Hash cycles/block

Tiger 193,944

SHA-1 561,589

Grøstl-256 2,813,496

Table 2: Code size after compilation , optimized for speed.

Hash Code Size in kB

Tiger 85.332

SHA-1 58.936

Grøstl-256 89.880

4 OUTLOOK

We performed a preliminary performance analysis of

three hash functions from different domains (one de-

signed for 64-bit machines, the current standard, and

one SHA-3 ﬁnalist) on a TI CC2530 sensor node, us-

ing an 8051 microcontroller. Our main goal was to

answer the question whether a more or less arbitrarily

selected, secure cryptographic hash-function can be

implemented on a sensor node, heavily constrained

in terms of available memory and processing power,

HashAlgorithmsfor8051-basedSensornodes

without extensive optimizations and still achieve ac-

ceptable performance.

The ﬁrst results are promising, although there is

still a lot of work to be done: in addition to imple-

menting the remaining four SHA-3 ﬁnalists, we cur-

rently investigate the use of the sensornodes’ AES co-

processor to implement and speed up AES-based hash

constructions, with the ﬁnal goals of identifying an ef-

ﬁcient, secure cryptographic hash-functionapart from

SHA-1 that can be used as a primitive building block

of a security framework for wireless sensor networks

and giving a general indication how much effort has

to be put into optimizing a chosen hash-function for

constrained environments.

REFERENCES

Anderson, R. and Biham, E. (1996). Tiger: A fast new hash

function. In Fast Software Encryption, Third Interna-

tional Workshop Proceedings, pages 89–97. Springer-

Verlag.

Bertoni, G. and Daemen, J. and Peeters, M. and Assche,

G. v. (2011). The keccak reference.

Bos, J. W.,

Ozen, O., and Stam, M. (2011). Efﬁcient hash-

ing using the aes instruction set. In Proceedings of

the 13th international conference on Cryptographic

hardware and embedded systems, CHES'11, Lecture

Notes in Computer Science, pages 507–522. Springer-

Verlag.

Eastlake, D. and Jones, P. (2001). Rfc3174 - us secure hash

algorithm 1 (sha1).

Ferguson, N. and Lucks, S. and Whiting, B. S. D. and Bel-

lare, M. and Kohno, T. and Walker, J. C. J. (2008).

The skein hash function family.

Gauravaram, P. and Knudsen, L. R. and Matusiewicz, K.

and Mendel, F. and Rechberger, C. and Schlffer, M.

and and Thomsen, S. S. (2011). Grøstl - a sha-3 can-

didate.

Jean-Philippe Aumasson and Luca Henzen and Willi Meier

Raphael C.-W. Phan (2010). Sha-3 proposal blake.

Manuel, S. (2011). Classiﬁcation and generation of distur-

bance vectors for collision attacks against sha-1. Des.

Codes Cryptography, 59(1-3):247–263.

NIST (2002). Secure hash signature standard (shs) (ﬁps pub

180-2). Technical report, National Institute of Stan-

dards and Technology.

Wu, H. (2011). The hash function jh.

DCNET2012-InternationalConferenceonDataCommunicationNetworking
