Free Composition Instead of Language Dictatorship

Lodewijk Bergmans, Steven te Brinke, Christoph Bockisch and Mehmet Aks¸it

University of Twente, Enschede, The Netherlands

Keywords:

Language Design, Language Engineering, Software Composition, Free Composition.

Abstract:

Historically, programming languages have been—benevolent—dictators: reducing all possible semantics to

speciﬁc ones offered by a few built-in language constructs. Over the years, some programming languages

have freed the programmers from the restrictions to use only built-in libraries, built-in data types, and built-

in type-checking rules. Even though—arguably—such freedom could lead to anarchy, or people shooting

themselves in the foot, the contrary tends to be the case: a language that does not allow for extensibility is

depriving software engineers of the ability to construct proper abstractions and to structure software in the

most optimal way. Therefore the software becomes less structured and maintainable than would be possible

if the software engineer could express the behavior of the program with the most appropriate abstractions.

The idea proposed by this paper is to move composition from built-in language constructs to programmable,

ﬁrst-class abstractions in a language. We discuss several prototypes of the Co-op language, which show that it

is possible, with a relatively simple model, to express a wide range of compositions as ﬁrst-class concepts.

1 MOTIVATION

The software engineering discipline faces many chal-

lenges; one of the important challenges is to cope with

the changes that need to be incorporated into software

systems during their lifetime. A particular difﬁculty is

that small, local changes in the requirements of a sys-

tem, often lead to non-local changes in the software.

This is caused by the fact that the structure of the im-

plementation tends to be signiﬁcantly different from

the structure of the problem domain.

Another software engineering challenge is manag-

ing the complexity of software (Royce, 2009). We are

building increasingly large software systems. Such

systems encompass a substantial amount of inherent

complexity; partially in the problem domain and par-

tially in the solution domain. However, the realization

of these systems also introduces a large amount of ac-

cidental complexity (Brooks, 1987), while going from

the conceptual solution to a realization model.

A key argument adopted in this paper, and previ-

ously coined, e.g., by Brooks (Brooks, 1987), is that

the limited ability of realization models to accurately

represent the concepts and their interdependencies in

a conceptual solution is the main cause of accidental

complexity. As a result, the complexity of realizations

is typically substantially larger than the complexity of

the conceptual solution.

In software engineering, a key strategy for deal-

ing with change and managing complexity is “divide

and conquer”: achieve separation of concerns (Dijk-

stra, 1976) by dividing a solution into building blocks

and delivering working systems by expressing proper

compositions of these building blocks. The history

of programming and design shows a steady move-

ment towards supporting higher-level abstractions of

building blocks and more advanced ways of express-

ing such compositions. For example, object-oriented

and aspect-oriented programming are largely moti-

vated by the need for improved modularity and sepa-

ration of concerns; recent trends in software engineer-

ing, such as Model-Driven Engineering (MDE) and

Domain-Speciﬁc Languages (DSLs), all aim at of-

fering an appropriate abstraction level for expressing

particular types of problems: to this extent, they of-

fer (a) dedicated (possibly graphical) syntax, (b) ded-

icated data types and operators, or (c) dedicated ab-

stractions and corresponding composition techniques,

to achieve better modularity and separation of con-

cerns for speciﬁc domains.

The message of this paper is that there is sub-

stantial beneﬁt in offering languages where abstrac-

tions and composition techniques are not hard-wired;

rather they should be easy to introduce on demand by

software engineers when new kinds of compositions

are identiﬁed.

388

Bergmans L., te Brinke S., Bockisch C. and Ak¸sit M..

Free Composition Instead of Language Dictatorship.

DOI: 10.5220/0004082603880393

In Proceedings of the 7th International Conference on Software Paradigm Trends (ICSOFT-2012), pages 388-393

ISBN: 978-989-8565-19-8

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

This paper is an extension of a paper previously

presented at the workshop on Reﬂection, AOP and

Meta-Data for Software Evolution (RAM-SE) 2011.

Sections 6.2 and 6.3 summarize our publications in

the workshop on Free Composition (FREECO) at

ECOOP 2011 (Te Brinke et al., 2011a) respectively

at Onward! 2011 (Te Brinke et al., 2011b).

2 COMPOSITION MECHANISMS

Programming languages

offer explicit and implicit

means to express composition of abstractions, which

means that the characteristics of a new abstraction

are expressed in terms of the characteristics of one

or more existing abstractions (and possibly additional

speciﬁcations). For example, function composition in

functional programming, such as f (g()), expresses

that—the behavior of— f and g are composed by

using the result of g as an argument of f . Simi-

larly, function invocation, such as the call to q in

p(){p

;q(); p

} is used to deﬁne part of the behavior

of a procedure p in terms of the behavior of q. In this

sense, the function invocation expresses that the be-

havior of p is a composition of the behavior of p

, q()

and p

. Another example is object aggregation (also

referred to as object composition): this expresses how

a new object structure is deﬁned as, e.g., the union of

other object structures.

In typical object-oriented languages, the follow-

ing composition mechanisms are available: behav-

ior composition through message passing (cf. func-

tion invocation), object aggregation, and inheritance.

Compositions can be binary (such as function invoca-

tion and single inheritance) or n-ary (such as multiple

inheritance or pointcut-advice composition in AOP).

Composition is not necessarily implemented di-

rectly by language constructs; for example, many de-

sign patterns describe how a set of objects interact to

create a coherent new behavior: a composition of the

participating objects. This composition is typically

realized by a set of code snippets distributed over the

participating objects, which must be re-implemented

for every design pattern instantiation, it affects the

traceability of the patterns in the code, and is hard to

maintain.

Whenever we talk about languages in this paper, this

should be interpreted broadly to any means of specifying

machine-executable behavior.

3 PROBLEM ANALYSIS

New composition mechanisms are introduced all the

time. For example, Taivalsaari (Taivalsaari, 1996) de-

scribes a taxonomy for inheritance mechanisms, from

which—in theory—hundreds of variants for inheri-

tance can be derived. More recently, many propos-

als have been made for aspect-oriented languages and

models: a survey report (Brichau et al., 2005) con-

tains 45 different proposals, where in most cases the

composition techniques are unique. Similarly, there

is an indeﬁnite amount of design patterns that essen-

tially express a composition of several objects.

In general, it can be safely assumed that for each

of these proposed composition mechanisms, there is

a sound argumentation why that mechanism works

better—at least for a certain class of applications, or

within a certain context. The fundamental reason is

that the application of each composition mechanism

involves a certain trade-off, which makes it particu-

larly suitable in certain contexts, but less so in others.

Hence, a language that dictates a ﬁxed set of compo-

sition techniques, with no opportunity to extend that

set, will inherently restrain the software engineer: he

or she is not able to choose the most appropriate com-

position mechanism, with the best possible trade-offs,

and the most natural mapping from a conceptual so-

lution to the implementation. Among the negative re-

sults caused by such dictatorship

are:

Lack of Traceability since the intended composi-

tion has to be replaced with an alternative, typi-

cally involving additional ‘glue code’.

Lack of Maintainability because the glue code is

usually speciﬁc to the context, and has to be added

in multiple locations, where it is also tangled with

the functionality.

Increased Accidental Complexity because straight-

forward compositions at the conceptual level have

to be realized by more complicated code that in-

troduces additional dependencies.

4 SCOPE AND ASSUMPTIONS

By now the strategy that we propose in this paper may

be obvious; we want to free composition from lan-

guages where it is limited to a few composition mech-

anisms, and instead propose language facilities where

the appropriate mechanisms can be deﬁned, applied,

and reused. Before explaining this approach in more

There are in fact also positive sides; e.g. less choice

makes both decisions and comprehension easier—albeit at

substantial costs.

FreeCompositionInsteadofLanguageDictatorship

389

detail, we ﬁrst discuss the scope of our solution ap-

proach and some of the assumptions we make. This

discussion should also help to distinguish our work

from various areas of related work.

Although not essential to the general idea, in the

remainder of this paper we focus on object-based lan-

guages, which support encapsulation and message-

invocation. In this context, composition refers to com-

position of the behavior of objects.

Our approach is not based on full reﬂection: al-

though that is a very powerful technique, reﬂection-

based solutions tend to be very hard to organize and

manage and, hence, are not suitable from a scalability

point-of-view. In particular, building fully reﬂective

solutions that are also composable and extensible, re-

quires a substantial amount of effort and discipline for

the involved software engineers. However, we do pro-

pose to adopt limited reﬂection (where only speciﬁc

elements of a language are exposed for reﬂection).

We would like to point out that our approach can well

be implemented, using reﬂection, as a speciﬁc Meta-

Object protocol (MOP) (Kiczales et al., 1991).

We also aim for solutions that are not

transformation-based, such as most Model-Driven

Engineering (MDE) tools and external Domain-

Speciﬁc Languages (DSLs). Although implementing

composition operators as transformations is in prin-

ciple a possibility, this suffers from several issues.

In particular, if multiple composition operators are

to be integrated within a larger solution: (1) it is

hard to exchange data between the model (or DSL)

world and the rest of the system, (2) it is hard to add

additional DSLs without running into all kinds of

integration issues, and (3) it requires additional tool

support to develop at the model level.

5 GENERAL APPROACH

In the general approach of ﬁrst-class composition op-

erators (Co-op), composition operators are objects

which operate on compositions. Composition oper-

ators can (cooperatively) inﬂuence the behavior of a

composition. As we will discuss, this approach is

sufﬁciently powerful to express common composition

mechanisms such as inheritance, delegation, and de-

sign patterns. Key characteristics of a language adopt-

ing the Co-op approach are the following:

• Only one primitive composition operator is pro-

vided by the language, which is sending a mes-

sage. Other composition operators such as inheri-

tance are not manifested in the language’s syntax.

• New composition operators can be deﬁned and

added to a system (a key characteristic of Co-op).

• Composition operators are ﬁrst-class entities in

the language: we believe this is an essential fea-

ture for a scalable approach (see also composabil-

ity (3) below). This also means that the appli-

cation of composition operators can be as simple

as object instantiation, and composition operators

can be managed as regular libraries.

• Composability (1): it is possible to freely apply

multiple composition operators within the same

application.

• Composability (2): it is possible to combine mul-

tiple composition operators in the same context,

i.e. apply them to the same objects. Neverthe-

less, in some cases the semantics of those oper-

ators may be such that a combined usage is not

desirable.

• Composability (3): composition operators can be

used in the deﬁnition of other composition opera-

tors (as long as this does not cause inﬁnite recur-

sion).

• Inherent dependencies or constraints among com-

position operators are expressible, such as ex-

clusion, relative ordering, and overriding among

composition operators.

While the syntax for a message send is embodied in a

language that follows our approach, the semantics of

where a message is delivered is not ﬁxed, but deter-

mined by the composition operators in Co-op: Com-

position is performed at message sends, by rewriting

the message’s properties. A message send is, by itself,

undirected; i.e., when the program sends a message,

it speciﬁes property values such as the message name

or initial argument values; since all message proper-

ties may be rewritten by composition operators, e.g.,

the ﬁrst argument value is not necessarily the receiver

of the message.

Figure 1 shows the composition infrastructure

schematically. In Co-op, we have chosen to use the

terms module and module instance to refer to con-

cepts that are comparable to (object-based) classes

and objects, with the distinction that they may also

specify composition operators. In the middle left, a

module instance (object) performs a message send.

The reiﬁed message is evaluated by the active set

of bindings, deﬁned by Co-op modules. Finally, the

evaluation of a message send typically leads to the in-

vocation of one (or more) operation(s) on a module

instance. The key characteristic is that all possible

behavior involves message dispatch; hence manipu-

lating message dispatch can be used to express a truly

wide range of behavioral compositions.

Composition operators are modules (classes) that

can specify one or more of the following three addi-

tional members to deﬁne how messages are eventually

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

390

module

source

module instance

jhgjhg hgjh jh

jhvhjij jo

g uhiuh

jh uhuhh

kjkj]

jj ijii

jj jj

oko oko

ko jj8g

88hh

ijio ijij

message send

instance of

module

source

module instance

jhgjhg hgjh

jhvhjij jo

g uhiuh

jh uhuhh

kjkj]

jj ijii

jj jj

oko oko

ko jj8g

88hh

ijio ijij

instance of

module

source

module

source

bindings defined by

final (default) dispatch

constraints:

conditions:

binding

Figure 1: Overview: composition in Co-op.

bound to concrete operations; this in turn expresses

the semantics of a particular composition technique:

1. Conditions deﬁne boolean predicates that refer to

message properties and to ﬁelds or methods de-

ﬁned in the class.

2. Bindings deﬁne the conditions to specify which

messages are selected to participate in the rewrit-

ing of a message, and assign new values to mes-

sage properties when they are applicable; hence

they bind source messages to new target mes-

sages. The target messages may be directly ex-

ecutable, or may be manipulated once more by

other bindings.

3. Constraints deﬁne relations between composition

operators with bindings that are applicable at the

same message send. Relations are, for example,

the order of evaluation and the prevention of eval-

uating one operator. This can express exclusion,

ordering, and overriding of compositions.

6 EVIDENCE: IMPLEMENTING

THE CO-OP IDEA IN A

LANGUAGE

As a proof-of-concept, we have partially realized

these ideas in three language implementations of Co-

op as object-oriented, dynamically typed languages.

See the SourceForge project Co-op at co-op.sf.net.

In this section, we will present these three implemen-

tations.

6.1 The Co-op/I Language

For Co-op/I (Bergmans et al., 2011; Havinga et al.,

2010a), we have deﬁned an operational semantics and

implemented an interpreter for it in Java. Co-op/I

faithfully realizes the execution approach described

in the previous section and exposes all method invo-

cations as message sends.

In this prototype language we have been able to

realize many different composition operators such as

aspects, delegation, traits, different forms of inher-

itance (Havinga et al., 2010a), and several design

patterns (including the Memoization, Observer and

State patterns (Havinga et al., 2010b)). Of the differ-

ent alternative semantics for inheritance presented by

Taivalsaari (Taivalsaari, 1996), we have implemented

all, except for those with ordered multiple inheritance,

due to a limitation in the Co-op/I implementation, not

in the concept. In our examples, we have been able to

reuse the implementation of lower-level composition

operators by combining them to more complex ones,

again by means of Co-op/I composition operators.

6.2 The Co-op/II Language

As a successor of Co-op/I, we designed a second pro-

totype of a Co-op language and execution environ-

ment, Co-op/II (Te Brinke et al., 2011a). In this pro-

totype, additional to function calls, also data accesses

are reiﬁed as messages being sent and composition

operators can reason about and inﬂuence such mes-

sages.

Composition techniques such as inheritance do

not only control the composition of behavior, but also

the composition of data. For example, access modi-

ﬁers control from where data ﬁelds can be accessed:

e.g., only from methods deﬁned in the same class as

the ﬁeld declaration or also from methods deﬁned in

classes inheriting from the class declaring the ﬁeld.

Most (OO) programming languages have built-in

language constructs to manipulate the way that data

is—or can be—accessed. A few examples are:

• Access modiﬁers in Java, C++ and C# are public,

protected, and private. A language like C++ adds

a friend keyword to express yet another form of

access rights on data (as well as behavior). Note

that there is a wide range of possible access mod-

iﬁers, when including the notion of package-level

protection, or the distinction between class-level

and instance-level protection.

FreeCompositionInsteadofLanguageDictatorship

391

• The Java, C++, and C# keyword static controls

whether all instances of a class share a ﬁeld, or

each has its own copy.

• The keywords ﬁnal in Java, const in C++, and

readonly in C# declare special semantics to the

usage of a variable (i.e., the variable may be as-

signed only once).

In general, examples of modiﬁed composition seman-

tics, which Co-op/II facilitates in addition to those

supported already by Co-op/I, are: access modiﬁers

(static, synchronized, ﬁnal, and so forth) and also

more conceptual constructs such as automatic con-

versions, checking of validity constraints, persistence,

transactions, and expressing roles.

Co-op/II provides a more declarative language for

deﬁning composition operators than Co-op/I. This al-

lows reasoning about composition operators to, for

example, provide optimizations and check their cor-

rectness. Identifying the precise amount of reasoning

that can be done is still future work.

6.3 The Co-op/III Language

At the moment, we are working on yet another Co-op

implementation, Co-op/III (Te Brinke et al., 2011b).

In addition to the request-reply model of method invo-

cation and data access, supported already by Co-op/I

and Co-op/II, this language has a focus on control-

ﬂow-related semantics of compositions. By this, we

mean inter-procedural constructs such as exception

handling, co-routines, and around advice with pro-

ceed in AOP, as well as intra-procedural control struc-

tures such as conditionals and loops.

This will allow deﬁning, e.g., different seman-

tics for exception handling such as adding support

to retry—or even resume—the operation that caused

an exception. At the same time, e.g., loop constructs

with different semantics can be deﬁned in Co-op/III,

such as evaluating the loop condition before, after or

even during the loop (Dahl et al., 1972).

The current implementation of Co-op/III will also

unify operators (such as addition, subtraction, and

string concatenation) with method invocations. Thus,

all operators are message sends that can be inﬂuenced

by the programmer.

6.4 Discussion

While our implementations of the Co-op languages

demonstrate that it is in principle possible to make

a language sufﬁciently powerful to deﬁne at least a

wide range of composition mechanisms, some ques-

tions remain. For example, the following issues must

be addressed to make this approach ready for practi-

cal use: the language must be made more complete

to support, e.g., ordered multiple inheritance; the ex-

ecution performance of Co-op programs must be op-

timized; and inter-operation with other programming

languages should be supported.

Optimizations are necessary because the dynamic

evaluation of composition operators adds an overhead

to each message send in the program. To compensate,

the Co-op/II and Co-op/III prototypes already aim at a

high degree of declarativity in the deﬁnition of condi-

tions, bindings and constraints. Thus, their effects on

a message can be partially evaluated before runtime.

However, it is still an open topic to actually imple-

ment and evaluate such optimizations for Co-op.

Language interoperability is important to use the

large body of existing libraries. This is supported

by main-stream languages, e.g., the Java Native In-

terface allows to use C/C++ libraries from Java and

vice versa. To support such interoperability, ways for

communicating between the dynamically-typed Co-

op world and the statically-typed world of Java or

C++ must be researched. A bridge to another dynam-

ically typed language, e.g. Smalltalk, may be simpler,

but still not trivial: also Smalltalk has a notion of type

hierarchies and assignment compatibility while Co-op

composes the behavior.

7 IMPLEMENTATION

STRATEGIES

Facilities for message rewriting can also be offered in

other ways, most obviously through a reﬂective lan-

guage, as a meta-object protocol (MOP). As already

explained in Section 4, the Co-op model and a MOP

approach are not contradictory, and a MOP approach

is one way to implement the Co-op ideas. How-

ever, the advantage of deﬁning a language is that it

can offer the programmer dedicated abstractions for,

e.g., the conditions, bindings and constraints. This

can make the speciﬁcation more declarative, which

makes composition operators, themselves, more com-

posable. Such declarativeness furthermore enables

analyses for better IDE support or performance op-

timization.

Various OO programming languages (e.g. SELF

(Ungar and Smith, 1987) and Smalltalk (Goldberg

and Robson, 1983)) aim at offering a simple core lan-

guage on which to build complex abstractions. How-

ever, to the best of our knowledge, these languages

either do not offer the ability to deﬁne tailored compo-

sition semantics or do so by opening up the language

in a generic way through reﬂection, as discussed in

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

392

the previous paragraph.

Another conceivable approach is to implement

composition operators by means of code transfor-

mations. They can be implemented in terms of a

compile-time MOP (Sheard and Jones, 2002), which

means that the transformations can be deﬁned in the

same language as the application code. But still trans-

formations cannot be freely composed because they,

generally, make assumptions on the code structure;

this may have been modiﬁed by a previously applied

transformation.

8 CONCLUSIONS

The message of this paper is that, when implementing

an application, dedicated abstractions that ﬁt the prob-

lem domain are needed; and since programs, in gen-

eral, combine multiple problem domains in unfore-

seeable ways, programming languages must not hard-

wire abstractions and composition mechanisms, but

must allow developers to tailor them to their needs.

For this purpose, we propose the Co-op approach

to integrate facilities into programming languages that

allow developers to implement their own composition

mechanisms according to their domain’s abstractions.

They should be implemented as composition opera-

tors which are ﬁrst class objects in the programming

language such that they can be composed, themselves,

by means of custom composition operators. By dis-

cussing the Co-op language prototypes that allow nor-

mal application objects to act as composition opera-

tors by means of message rewriting, we have shown

that realizing these ideas is feasible.

While the Co-op approach—allowing program-

mers to deﬁne their own composition operators as

ﬁrst-class objects—is quite powerful, it also bears

more complexity. This complexity needs not be ex-

posed to the day-to-day programmer, though, because

the implementation of composition operators can be

provided by a few, well-trained experts through li-

braries. The common programmer simply uses such a

library, instantiating composition operators as needed.

Nevertheless, it is subject to future studies to research

the impact of our proposed programming model in

practice.

ACKNOWLEDGEMENTS

We would like to thank Wilke Havinga and Havva

ulay G

urb

uz for their contributions to Co-op. This

research work was partially funded through the

ENOFES project (STW 11850).

REFERENCES

Bergmans, L. M. J., Havinga, W. K., and Aks¸it, M. (2011).

First-class compositions–deﬁning and composing ob-

ject and aspect compositions with ﬁrst-class operators.

Transactions on Aspect-Oriented Software Develop-

ment.

Brichau, J., Haupt, M., Leidenfrost, N., Rashid, A.,

Bergmans, L., et al. (2005). Report describing sur-

vey of aspect languages and models. Technical Re-

port AOSD-Europe Deliverable D12, AOSD-Europe-

VUB-01, Vrije Universiteit Brussel.

Te Brinke, S., Bergmans, L. M. J., and Bockisch, C. M.

(2011a). The keyword revolution: Promoting lan-

guage constructs for data access to ﬁrst class citi-

zens. In Proc. 1st Int. Workshop on Free Composition,

FREECO ’11, New York, NY, USA. ACM.

Te Brinke, S., Bockisch, C. M., and Bergmans, L. M. J.

(2011b). Reuse of continuation-based control-ﬂow ab-

stractions. In Proc. 2nd Workshop on Free Composi-

tion @ Onward! 2011, FREECO-Onward! ’11, pages

13–18, New York, NY, USA. ACM.

Brooks, F. (1987). No silver bullet: Essence and accidents

of software engineering. IEEE computer, 20(4):10–

19.

Dahl, O. J., Dijkstra, E. W., and Hoare, C. A. R., editors

(1972). Structured Programming. Academic Press

Ltd., London, UK.

Dijkstra, E. W. (1976). A discipline of programming.

Prentice-Hall, Englewood Cliffs, New Jersey.

Goldberg, A. and Robson, D. (1983). Smalltalk-80: the lan-

guage and its implementation. Addison-Wesley Long-

man Publishing Co., Inc. Boston, MA, USA.

Havinga, W. K., Bergmans, L. M. J., and Aks¸it, M. (2010a).

A model for composable composition operators: Ex-

pressing object and aspect compositions with ﬁrst-

class operators. In Proc. 9th Int. Conf. on Aspect-

Oriented Software Development, pages 145–156, New

York. ACM.

Havinga, W. K., Bockisch, C. M., and Bergmans, L. M. J.

(2010b). A case for custom, composable composition

operators. In Proc. 1st Int. Workshop on Composition:

Objects, Aspects, Components, Services and Product

Lines, volume 564 of Workshop Proceedings, pages

45–50. CEUR-WS.

Kiczales, G., des Rivieres, J., and Bobrow, D. G. (1991).

The Art of the Metaobject Protocol. MIT Press, Cam-

bridge, Massachusetts.

Royce, W. (2009). Improving software economics-top 10

principles of achieving agility at scale. White paper,

IBM Rational.

Sheard, T. and Jones, S. P. (2002). Template meta-

programming for Haskell. SIGPLAN Not., 37:60–75.

Taivalsaari, A. (1996). On the notion of inheritance. ACM

Comput. Surv., 28(3):438–479.

Ungar, D. and Smith, R. B. (1987). Self: The power of

simplicity. SIGPLAN Not., 22:227–242.

FreeCompositionInsteadofLanguageDictatorship

393
