Web Usage Mining for Automatic Link Generation

Olatz Arbelaitz, Ibai Gurrutxaga, Aizea Lojo, Javier Muguerza,

Jes´us M. P´erez and I˜nigo Perona

Dept. of Computer Architecture and Technology, University of the Basque Country UPV-EHU,

M. Lardizabal, 1, 20018 Donostia, Spain

Abstract. During the last decades, the information in the web has increased dras-

tically but larger quantities of data do not provide perse added value for web visi-

tors; there is a need for more efﬁcient access to the required information and adap-

tation to user preferences or needs. The use of machine learning techniques to

build user proﬁles allows to take into account users’ real preferences. We present

in this work a preliminary system, based on the collaborative ﬁltering approach,

to identify and generate interesting links for the users while they are navigating.

The system uses only web navigation logs stored in any web server (according

to the Common Log Format) and extracts information from them combining un-

supervised and supervised classiﬁcation techniques and frequent pattern mining

techniques. It also includes a generalization procedure in the data preprocess-

ing phase and in this work we analyze its effect on the ﬁnal performance of the

whole system. We also analyze the effect of the cold start (0 day problem) in the

proposed system. The experiments show that the proposed generalization option

improves the results of the designed system, which performs efﬁciently w.r.t. a

web-accessible database and is even able to deal with the cold start problem.

1 Introduction

During the last decades, the information on the web has increased drastically and this

often makes the amount of information intractable for users. As a consequence, the need

for web sites to be useful and efﬁcient for users has become specially important; there

is a need for faster access to the required information and adaptation to user preferences

or needs. That is, Web Personalization becomes essential. Web Personalization [20] can

be deﬁned as the dynamic adaptation of the presentation, the navigation schema and the

contents of the Web, based on the preferences, abilities or requirements of the user.

Nowadays, as Brusilovsky et al. describe in [2], many research projects focus on this

area, mostly in the context of e-Commerce [2] and e-learning [9].

Within this context, the current paper presents the design of a complete and generic

system that can adapt the web pages to new users’ navigation preferences proposing

automatically generated links that they will probably be using in a short future.

Our research is contextualized in Web Usage Mining [17]: the application of ma-

chine learning techniques to the web usage data. This process requires a data acquisi-

tion and preprocessing phase which is not straightforward because it requires different

steps such as fusion of data from multiple log ﬁles, cleaning, user identiﬁcation, session

Arbelaitz O., Gurrutxaga I., Lojo A., Muguerza J., M. Pérez J. and Perona I..

Web Usage Mining for Automatic Link Generation.

DOI: 10.5220/0004090400710080

In Proceedings of the 10th International Workshop on Modelling, Simulation, Veriﬁcation and Validation of Enterprise Information Systems and 1st

International Workshop on Web Intelligence (WEBI-2012), pages 71-80

ISBN: 978-989-8565-14-3

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

identiﬁcation, path completion processes, etc. Machine learning techniques are mainly

applied in the pattern discovery and analysis phase to ﬁnd sets of web users with com-

mon web-related characteristics and the corresponding patterns or user proﬁles. And

ﬁnally, the patterns discovered during the previous steps are used in the exploitation

phase to adapt the system and make the navigation more comfortable for new users.

The most widely explored application of web access patterns’ prediction in the web

research community has been web page prefetching [3,1,16]. Common characteristics

of many of the systems are the use of clustering and/or Markov models to predict the

next link to be accessed, but, the URL access order can also be taken into account using

sequence alignment methods [4] for the clustering process or sequential pattern mining

algorithms [22] when generating user proﬁles.

We built a system based on the collaborative ﬁltering approach that takes as input

the minimum information stored in a web server (web server log ﬁles stored in Common

Log Format –CLF [5]) and combines unsupervised and supervised machine learning

techniques and frequent pattern mining techniques to build user proﬁles and propose

links drawn from those proﬁles to new users. That is, the proﬁles are built without

any effort from the user. We speciﬁcally analyze in this work how a generalization

process applied to the URLs inﬂuences the performance of the system. To evaluate our

system we performed experiments in a web-accessible database composed of server log

information captured in the NASA [18,19], with 30K examples, but the system could

be integrated in any web environment and applied to larger databases.

We developed the described system and performed experiments to try to answer

the following research question: is it possible to automatically generate and propose to

users links that they will be using in the future? Are the machine learning techniques

we use and their combination adequate for our aim? Is it always interesting to work

with generalized URLs or is it worth maintaining the speciﬁcity of the URLs in some

stages? And ﬁnally, is the designed system able to deal with the cold start problem?

The paper proceeds describing in Section 2 the intuition of the system from the user

point of view. In Section 3 we describe the database we used in the process and Section

4 is devoted to describing the system we designed. The paper continues in Section 5

where we describe some results of the performed experiments. Finally, we summarize

in Section 6 the conclusions and further work.

2 Proposed System: Intuition

We have designed a system able to dynamically proposelinks to the user who is navigat-

ing in the web. The system uses navigation logs to automatically generate user proﬁles

in a batch process, and use them later to automatically propose links to new users. In

this kind of systems the proposal of a large amount of links to the user would probably

distract her/him and wouldn’t be very helpful. As a consequence, our system proposes

a small amount of useful links so that the user is not confused. This means, in machine

learning terms, that high precision values will be preferable to high recall values.

The evaluation of this kind of systems is complex. We are adapting the presenta-

tion of the web data so that after a new user started navigating, proposals of links that

she/he will likely be using are done. The best validation strategy would be to perform

an user study but that was impossible at this point. As a consequence, we measured the

efﬁciency of the system as the percentage of the proposed links over the proposed ones.

The system has been evaluated using part of the data (2/3) to build it (training) and

the rest (1/3) for testing it. The results showed that we were able to successfully predict

links. For example in our context where the median of the length of the user navigation

sequences is 8 clicks, once the user started navigating (after he/she has done for example

4 clicks) we propose his/her in average 4 new links. More or less one of them will not

appear in the user navigation sequence, in average 1.5 of them will belong to the set of

clicks already performed by the user, and, the rest 1.5 will be used by the user in the

future.

The system would make the user navigation more efﬁcient since it would be propos-

ing the links that he/she will probably use and he/she could faster and more comfortably

reach his/her objectives.

3 Database

In this work we have used a database from The Internet Trafﬁc Archive [11] concretely

NASA-HTTP (National Aeronautics and Space Administration) database [18,19]. The

data contained in this database belongs to web server logs of user requests. The server

was located at NASA Kennedy Space Center in Florida and logs were collected during

two periods of time. The ﬁrst set of logs was collected from 00:00:00 July 1, 1995

until 23:59:59 July 31, 1995, a total of 31 days. The second log was collected from

00:00:00 August 1, 1995 until 23:59:59 August 31, 1995, a total of other 31 days. The

complete database contains 3,461,612 requests. The contained information is similar to

the standardized text ﬁle format, i.e. Common Log Format [5] which is the minimum

information saved on a web server. Therefore, the system proposed in this work will use

the minimal possible amount of information and, as a consequence, it will be applicable

to the information collected in any web server.

4 Proposed System: Description

The work presented in this paper is a Web Usage Mining [21] application and as every

web usage mining process it can be divided into three main steps: data acquisition and

preprocessing [6], pattern discovery and analysis, and, exploitation. The data acquisi-

tion phase has not been part of our work. We have designed the system starting from

the data preprocessing step up to the exploitation phase.

4.1 Data Preprocessing

We preprocessed the log ﬁles ﬁltering out erroneous requests, image requests, etc. to

take into account for experimentation only the requests related to user clicks. We per-

formed the user identiﬁcation based on IP addresses and as an heuristic to identify

sessions within a users’ activity, we ﬁxed the expire time of each session to 30 minutes

of inactivity [14]. Among the obtained sessions, we selected the most relevant ones, i.e.,

the ones with higher level of activity (6 or more clicks). After applying the whole data

pre-processing stages to NASA-HTTP database, the size of the database was reduced

to 346,715 HTML requests and 31,778 sessions composed of at least 6 clicks where a

total of 1,591 different URLs are visited.

We represented the information corresponding to each of the sessions as a sequence

of clicks preformed in different URLs. Other data representation, where other kinds

of characteristics such as navigation times, number of clicks per session, length of the

longest path form the home page, average times per link, etc. of the users are extracted,

could have been used but, in this case, we focus on thenavigationpatterns: on the visited

URLs and the order of these visits.

4.2 Generalization of the Structure

Our aim in this work is to model users based on the identiﬁcation of general navigation

patterns. In this context, having too speciﬁc paths in the used data (it is very probable

that navigation paths of different users, or the same user in different moments, won’t be

exactly the same) will make complicated to draw conclusions from the output of ma-

chine learning algorithms. As an example, NASA database has 1,591 different URLs

and each one is accessed, in average, in 41.3 different sessions out of the 31,778 ap-

pearing in the database (we removed the outliers, the ones out of 90% percentile). This

means that it will be difﬁcult to ﬁnd similar click sequences in different sessions. For

that reason, we added a generalization procedure to the URL representation whose aim

is to represent them a higher level of abstraction. Depending on the parameters of the

procedure the average amount of different sessions a URL appears is increased up to a

60%, making it easier to ﬁnd common patterns.

The ﬁrst approach to the generalization step consists on erasing a fraction of the

URL segments (parts separated by ’/’ appearing in the URL) from the right end of the

path to diminish the URL’s speciﬁcity. For each one of the visited URLs, we obtained

the length of the generalized URL based on next expression:

max {M inNSegment, (1 − α) ∗ NSegments} (1)

Where NSegments represents the number of segments appearing in the URL and α

and M inN Se gment are parameters that can vary depending on the structure of the

site. M inNSegment represents the minimum number of segments, starting from the

root, an URL can have after the generalization step, whereas, α represents the fraction

of the URL that will be erased in the generalized version. This generalization process

will allow us to work with a more general structure of the site avoiding the confusion

that too speciﬁc zones could generate. A study of the generalized structure of NASA

database, instantiating M inNSegment = 3, showed that the URL structure saturates

with values greater than 0.5 for α, that is, the structure has 367 URLS when α = 0.5

and it is only reduced to 330 when α = 0.9. As a consequence, we used 3 values of α

to evaluate the system: 0 (not generalization), 0.25 and 0.5.

4.3 Pattern Discovery and Analysis

This is the stage in charge of modeling users and producing user proﬁles taking as input

the user click sequences. In this context unsupervised machine learning techniques have

shown to be adequate to discover user proﬁles [20].

We used the PAM (Partitioning Around Medoids) [15] clustering algorithm in order

to group into the same cluster users that show similar navigation patterns according to

click sequences and a sequence Alignment Method (Edit Distance [10,4]) as a metric

to compare sequences. PAM requires as input an estimate on the maximum number of

clusters to provide as output (k parameter). Since we didn’t have prior knowledge of the

structure of the data, in NASA database, in this preliminary approach we ﬁxed k to 100.

As a consequence, we might be somehow obliging the clustering algorithm to assign

patterns to a cluster even if their distance to the rest of the patterns in the same cluster

is big. We have avoided the noise this could produce by removing in each cluster the

patterns with distance 1 (maximum distance) to every other pattern.

The outcome of the clustering process is a set of groups of user sessions that show

similar behavior. But we intend to model those users or to discover the associated nav-

igation patterns or proﬁles for each one of the discovered groups, that is, to ﬁnd the

common click sequences appearing across the sessions in a cluster. In this step we used

SPADE (Sequential PAttern Discovery using Equivalence classes) [22], an efﬁcient al-

gorithm for mining frequent sequences, to extract the most common click sequences

of the cluster. The application of SPADE provides for each cluster, a set of URLs that

are likely to be visited for the sessions belonging to it. The number of the proposed

URLs depends on parameters related to SPADE algorithm such as minimum support

or minimum number of sessions in the cluster containing that URL, and maximum al-

lowed number of sequences per cluster. We performed several experiments, and, ﬁnally,

a ﬁxed value for the minimum support, 0.5, showed to be a good option.

Although for the clustering and exploitation stages we experimented with general-

ized and not generalized URLs, if we would use generalized URLs at this stage, the

system wouldn’t be able to propose real URLs to the user, and, as a consequence, the it

would require an extra stage in order to be useful for the ﬁnal user. Thereby, we applied

the SPADE algorithm using the original URLs appearing in the user click sequence.

The reader could probably easily conclude from the previous paragraphs that the

pattern discovery and analysis phase is a batch process and its outcome will be used in

the exploitation phase in real time. As a consequence, increasing the size of the input

database wouldn’t increase the cost of the process in the exploitation phase.

4.4 Exploitation

This is the part that needs to be done in real time. Up to now, we have identiﬁed groups

of users with similar navigation patterns and the URLs that are most likely to be vis-

ited, or most common paths, for each of the groups. At this point we need to use that

information to automatically propose links to new users navigating in the web. As a ﬁrst

approach, we propose the use of k-NN (1-NN) [7] learning approach to calculate the

distance (average linkage distance based on Edit distance [10]) of the click sequence

of the new users to the clusters generated in the previous phase. This distance can be

calculated at any stage of the navigation process, that is, from the ﬁrst click of the new

user to more advanced navigation points. Our hypothesis is that the navigation pattern

of that user will be similar to the user proﬁle of its nearest cluster. As a consequence the

system will propose to the new user the outcome of SPADE, the set of links that models

the users in that cluster.

5 Experiments: Results and Analysis

In order to evaluate the performance of the whole process, we applied the Hold-out

method dividing the NASA database into two parts. One for training or generating the

model, that is, for generating the clusters and extracting proﬁles. And another one for

testing or using it in exploitation, that is, for evaluating to what extent the links gener-

ated by the system would come along with the navigation performed in those sessions.

To simulate a real situation we based the division of the database on temporal criteria:

we used the oldest examples (66% of the database, 21,185 user sessions) for training

and the latest ones (33%, 10,595 user sessions), for testing. In the training database, the

total number of requests is 235,155 (1,419 different URLs accessed) and the median of

the number of clicks per session 8. The test database seems to have similar characteris-

tics. Although it is smaller, the total number of requests is 111,605, the median of the

number of clicks per session is still 8.

We applied to the training data the combination of PAM with different values for α

generalization parameter so that the sessions with similar navigation characteristics are

clustered into the same group. Then we generated with SPADE the navigation proﬁle

of each group of users or set of links that they will probably use. These proﬁles will

be compared to the click sequence of the users in the test examples to evaluate the

performance of the system.

To validate the system, we used the test examples as described in the exploitation

phase and then we compared the automatically generated links with the real click se-

quences of the users. We performed this comparison taking into account the 0-day prob-

lem. That is, although in the used database we have the complete navigation sequence

of the test sessions, in real executions, when a user starts navigating, only her ﬁrst few

clicks will be available to be used for deciding the corresponding proﬁle and proposing

new links according to it. We have simulated the real situation using 10% (just one click

out of 8), 25% and 50% of the user navigation sequence in the test examples to select

the nearest cluster or proﬁle. We also performed the experiments for the complete test

sequences (100%) as an upper bound.

We computed statistics based on results for each one of the new users. We compared

the number of proposed links that are really used in the test examples (hits) and the

number of proposals that are not used (misses) and calculated precision (precision).

Note that this could be seen as a lower bound because, although not appearing in the

user navigation sequence, the proposed links could be useful for her/him. Unluckily

their usefulness could only be evaluated in a experiment using the user feedback.

An ideal system would maintain precision and recall as high as possible. But we

focus on precision because, as we mentioned before, in this kind of systems, proposing

a large amount of links would distract the user and proposing a small amount of links,

we can not expect to guess the whole navigation path of new users.

We calculated the precision (Pr) taking into account only the clicks in the test se-

quence that have not been used to select the nearest proﬁle; that is, taking into account

the remaining 90%, 75% or 50%. Moreover, we calculated an upper bound for the pre-

cision (PrUp) taking into account the whole test sequence.

As a summary, we evaluated the system’s performance for the next conﬁgurations:

– PAM clustering algorithm applied to click sequences with different generalization

options for the URLs: 0 (CL000), 0.25 (CL025), 0.5 (CL050).

– 1-NN with different generalizationoptions for theURLs: 0 (NN000),0.25 (NN025),

0.5 (NN050).

– Prediction at different stages of the navigation: 10%, 25% and 50% and 100% (as

an upper bound).

– Real precision (Pr) and upper bound for precision (PrUp).

Table 1 and Figure 1 summarize the mentioned results. In Table 1 precision values

are shown for the different percentages of the test sequences we used to identify the

proﬁle of the new user (columns) and the different conﬁgurations we evaluated (rows).

In Figure 1 we can observe the trends of the precision (Pr and PrUp) for the different

conﬁgurationswe evaluated,while the percentages of the test sequences used to identify

the proﬁle of the new user increase (X Axe).

Table 1. Summary of precision values.

Option 10% 25% 50% 100%

CL000-NN000-Pr 39.7 42.0 35.1

CL025-NN000-Pr

40.0 42.2 35.4

CL025-NN025-Pr

39.3 42.4 35.6

CL050-NN000-Pr

47.2 46.7 39.1

CL050-NN050-Pr

56.2 51.7 43.8

CL000-NN000-PrUp 52.9 63.0 69.6 73.5

CL025-NN000-PrUp

53.4 64.3 70.0 73.8

CL025-NN025-PrUp

52.9 64.4 70.1 73.7

CL050-NN000-PrUp

60.9 68.5 72.3 73.5

CL050-NN050-PrUp

69.5 72.2 75.5 76.1

The ﬁrst conclusion we can draw form the results is that even if the values of the

measured parameters vary depending on the selected option, all conﬁgurations are able

to predict a certain percentage of the links a new user will be visiting. That is, we de-

signed a general system that, without any effort from the users, is able to automatically

generate link proposals that will be helpful to make more comfortable and efﬁcient

the navigation of new users in the web. And as a consequence, we can claim that the

machine learning techniques we use and their combination seem to be adequate.

Furthermore, from the comparison of the achieved values we can conclude that,

as expected, independently of the approach used to calculate precision, generalization

helps in the ﬁrst step of the process and moreover the generated user proﬁles seem to be

Fig.1. Precision values achieved with different conﬁgurations of the system.

more adequate for bigger values of α parameter (0.5). Furthermore, although its effect

is smaller, the use of generalization also seems to be important in exploitation, when

the most similar proﬁle to a new user is being selected. It is again the α = 0.5 option the

one obtaining the best results. Independently of the percentages of the user navigation

known in exploitation (10%, 25%, 50% or 100%) the best precision values are the ones

obtained for CL050-NN050-Pr and CL050-NN050-PrUp.

Those are the options obtaining the highest precision values and their average dif-

ference with the rest of the options was in a range of about 12%. We calculated recall

values for the different options and the differences were smaller than for precision; the

difference of the values obtained for CL050-NN050-Pr and CL050-NN050-PrUp were

only around 5.3% smaller if compared to the best recall value obtained.

It can also be observed that precision values for Pr option are more than half of the

precision values achieved for PrUp option. From this data we can conclude that more

than half of the hits belong to URLs our system has proposed and come along with the

clicks the user will be doing in the future.

If we center the analysis in the 0-day problem, we realize that as it could be ex-

pected, the trends of the curves change for the Pr and PrUp. In the case of PrUp the

quality of results logically increases when longer has the user been navigating. In both

cases the values are still acceptable at very early stages of the navigation. When just

10% (one click in average) of the user navigation sequence is known, good precision

values (Pr = 56.2 and PrUp = 69,5) are obtained. That is, the system is able to deal with

the 0-day problem. However, in the case of Pr the quality of results decreases when

longer has the user been navigating. This could also be expected because when longer

this sequence is, the amount of URLs the user did not select yet becomes smaller.

6 Conclusions and Further Work

We designed a system that, without disturbing the users, based just on server log infor-

mation and machine learning techniques, identiﬁes different groups of users, builds the

corresponding proﬁles, and automatically generates useful link proposals for new users

so that their navigation becomes more efﬁcient. This work has been done for NASA-

HTTP database [18,19], but could be extended to any other environment since it has

been built using the minimum information stored in any web server (in Common Log

Format). We preprocessed the data to identify users and sessions on the one hand, and

prepared it so that it could be used with machine learning algorithms. We then proposed

a generalization step and applied PAM clustering algorithm to the training data to dis-

cover groups of users with similar interests or navigation patterns. Once the groups of

users were identiﬁed, we used SPADE algorithm to discover the proﬁles associated to

each of the clusters, or, the links that will be proposed to new users. We evaluated dif-

ferent conﬁgurationsof the system and how it deals with the 0-day problem. To perform

this evaluation, we used a Hold-out strategy: we divided the database into two parts one

for training and the other one for testing.

We evaluated to what extent the system is able to predict the links a new user will be

using. The validation results showed that the discovered patterns made sense and that

they could be used to ease the navigation of future users by proposing or underlying

links that they will probably use. This happens even if the prediction is made at very

early stages of their navigation (10%). Results showed that the proposed generalization

is appropriate for both, the clustering stage and ﬁnding the nearest proﬁle of a new user

during the exploitation phase. Moreover, greater levels of generalization seem to work

better (the best results are achieved with CL050-NN050).

So, we could conclude that, using adequate machine learning techniques, we have

been able to design a generic system that based only on web server log information

and without any effort from the users, is able to propose adaptations to make easier

and more efﬁcient the navigation of new users. Since at this point we haven’t used any

domain speciﬁc information, this system would be useful for any web site collecting

server log information.

This is an ongoing work that needs to be improved in many senses. First, it should

be applied to more recent data. Regarding to the evaluation, on the one hand, cross-

validation should be used to assess precision more accurately, and, on the other hand,

ideally an user study should be performed in a real web environment where links can be

proposed to new users and the effect of those links in their navigation can be assessed.

Moreover, regarding to the system architecture, on the one hand, a wider analysis of the

parameters is required, and, on the other hand,the stage of the selection of the nearest

proﬁle for a new user needs more reﬁnement. Finally, further improvements could be

done using web structure information and content information of the selected web page

for improving the results of the system.

Acknowledgements

This work was funded by the University of the Basque Country, general funding for

research groups, ALDAPA (GIU10/02); by the Science and Education Department of

the Spanish Government, ModelAccess (TIN2010-15549 project); by the Diputaci´on

Foral de Gipuzkoa, Zer4You (DG10/5); and by the Basque Government’s SAIOTEK

program, Datacc (S-PE11UN097).

References

1. Anitha, A. A new web usage mining approach for next page access prediction. International

Journal of Computer Applications, 8(11):7–10, 2010.

2. Brusilovsky P., Kobsa A. and Nejdl W. The Adaptive Web: Methods and Strategies of Web

Personalization LNCS 4321, Springer, 2007.

3. Chen X., Zhang X. A popularity-based prediction model for web prefetching. Computer,

36(3):63–70, 2003.

4. Chordia B.S., Adhiya K.P. Grouping Web Access Sequences Using Sequence Alignment

Method. In Indian Journal of Computer Science and Engineering (IJCSE), Vol. 2(3), (2011)

5. The Common Log Format http://www.w3.org/Daemon/User/Conﬁg/Logging.html

#common-logﬁle-format

6. Cooley R., Mobasher B. and Srivastava J. Data preparation for mining world wide web

browsing patterns. Knowledge and Information Systems, 1(1), 1999.

7. Dasarathy B.V. Nearest Neighbor (NN) Norms: NN Pattern Classiﬁcation Techniques IEEE

Computer Society Press, Silver Spring, MD, 1991.

8. Desikan P., Srivastava J., Kumar V. and Tan P.N. Hyperlink Analysis - Techniques and

Applications. Army High Performance Computing Center Technical Report, 2002.

9. Garc´ıa E., Romero C., Ventura S. and De Castro C. An architecture for making recommen-

dations to courseware authors using association rule mining and collaborative ﬁltering. User

Modeling User and Adapted Interaction, 19(1-2), pages 99–132, 2009.

10. Gusﬁeld D. Algorithms on strings, trees, and sequences. Cambridge University Press, 1997.

11. The Internet Trafﬁc Archive. http://ita.ee.lbl.gov/. ACM SIGCOMM.

12. Jain A.K., Dubes R.C. Algorithms for Clustering Data. Prentice-Hall, Upper Saddle River,

NJ, USA, 1988.

13. Kosala R. and Blockeel H. Web Mining Research: A Survey. ACM SIGKDD Explorations

Newsletter, 2(1), pages 1–15, 2000.

14. Liu B. Web Data Mining. Exploring Hyperlinks, Contents, and Usage Data. Springer, 2007.

15. Liu L. and

Ozsu M.T. Encyclopedia of Database Systems. In: PAM (Partitioning Around

Medoids). Springer US, 2009.

16. Makkar P., Gulati P. and Sharma A. A novel approach for predicting user behavior for

improving web performance. International Journal on Computer Science and Engineering

(IJCSE), 2(4):1233–1236, 2010.

17. Mobasher B. Web Usage Mining. In: Web Data Mining: Exploring Hyperlinks, Contents

and Usage Data. Springer, Berlin, 2006.

18. NASA-HTTP logs. HTTP requests to the NASA Kennedy Space Center WWW server.

http://ita.ee.lbl.gov/html/contrib/NASA-HTTP.html, in Florida, 1995.

19. National Aeronautics and Space Administration. http://www.nasa.gov/, 2010.

20. Pierrakos D., Paliouras G., Papatheodorou C. and Spyropoulos C.D. Web Usage Mining as a

Tool for Personalization: A Survey User Modeling and User Adapted Interaction, 13:311–

372, 2003.

21. Srivastava J., Desikan P. and Kumar V. Web Mining - Concepts, Applications & Research

Directions. In Foundations and Advances in Data Mining. Springer, Berlin, 2005.

22. Zaki M.J. SPADE: An Efﬁcient Algorithm for Mining Frequent Sequences. Machine Learn-

ing, 42:31–60, 2001.
