Are Use Case Modeling Features Underutilized?

A Lightweight Survey that Raises Concerns

Mohamed El-Attar

, Khaldoun Halawani

Mustafa Alsaleh

and Mahmood Niazi

1, 2, 3

Department of Information and Computer Science,

King Fahd University of Petroleum and Minerals, Dhahran, Saudi Arabia

School of Computing and Mathematics, Keele University, ST5 5BG, Keele, U.K.

Faculty of Computing, Riphah International University, Islamabad, Pakistan

Keywords: Use Case Modeling, Notation Usage, Authoring Techniques, Reuse Mechanisms.

Abstract: Use case modeling is a very popular technique for eliciting, specifying and validating functional

requirements. Use case modeling possesses a very rich notational set that allows its users to accurately

specify a large variety of aspects about the underlying system’s requirements. Many authoring techniques

and templates were introduced to accurately describe a system’s functional requirements. Although a

relatively simple modeling technique, the literature has repeatedly reported on its misuse, leading to the

development of end systems that do not satisfy the intended requirements. To this end, we have conducted a

survey of use case models available online to shed light on the level of utilization of the use case modeling

notation and how they are described, which can be symptomatic of how well do requirements engineers

utilize the use case modeling technique and its modeling capabilities. In our survey we have collected and

analysed 105 use case models. The results show an underutilization of the use case modeling notation and

improper authoring techniques, which raises concern over the quality of the end systems.

1 INTRODUCTION

Modelers create use case models to accurately

describe the functional requirements of a system

(Booch, 2005; OMG, 2009). If modelers voluntarily

restrict themselves from using the various use case

modeling features then this will result in the

development of use case models that do not

accurately represent the underlying functional

requirements. Mal-practice of use case modeling is

particularly worrying in use case-driven

development methodologies, where the quality of

use case models has a significant impact on other

development activities downstream.

The literature repeatedly reports on cases of use

case modeling mal-practice (Anda and Sjøberg,

2002; Anda et al., 2001; Berenbach 2004; Bittner

and Spence, 2004; Cockburn 2000; Lilly, 1999;

Overgraad and Palmkvist 2005). Consequently, a

great deal of research has been devoted to guide and

improve use case modeling efforts (Anda and

Sjøberg, 2002; Berenbach 2004; Bittner and Spence,

2004; 2001; Cockburn 2000). However, has the

application of the use case modeling technique

improved? To date, the overwhelming majority of

use case models produced and being produced are of

poor quality, which is evidenced by the significant

subset of software development projects that fail due

to requirements related issues, including low quality

use case models. The position argued by the authors

of this paper is that the continuing trend of poor

quality use case models produced is due to a

significant underutilization of use case modeling

features. To support this position, a lightweight

survey of 105 publicly available use case models

was conducted. The collected use case modelled

were analysed to determine their utilization of the

complete set of use case modeling features.

2 USE CASE MODELING

FEATURES

System boundary is an important notation since it

explicitly indicates which entities are part of the end

system and which are external to the system under

development. Failure to include system boundary

may lead to confusion as to which entities will need

203

El-Attar M., Halawani K., Alsaleh M. and Niazi M..

Are Use Case Modeling Features Underutilized? - A Lightweight Survey that Raises Concerns.

DOI: 10.5220/0004095102030206

In Proceedings of the 7th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2012), pages 203-206

ISBN: 978-989-8565-13-6

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

to be implemented (Lilly, 1999). As such,

developers may implement functionality that is not

required, which is a waste of resources.

Abstraction in use case models serves as a reuse

mechanism in a similar was as in object-oriented

programs (Bittner and Spence, 2004). For use cases,

abstraction is used to state common yet incomplete

behaviour. This incomplete behaviour should be

completed by a specializing use case. For actors,

abstraction can be used to specify a generalized

actor role that is common amongst other actors, but

one that itself is also incomplete and thus needs to

be realized by a specializing actor. The extend,

include, use case generalization and actor

generalization relationships are reuse mechanisms in

use case modeling (Bittner and Spence, 2002;

Overgraad and Palmkvist, 2005).

The textual description of use cases is the heart of

any use case model. A use case model that only

includes a diagram would be quite vague about the

details of the underlying functional requirements.

Failure to include use case descriptions will require its

readers to guess the details of the underlying

functional requirements, which is likely to be

incorrect or inaccurate (Anda and Sjøberg, 2002;

Cockburn 2000). The use of templates to describe use

cases greatly improves quality in use case models.

3 DATA COLLECTION,

RESULTS AND DISCUSSION

The search excluded use case models created solely

for educational purposes. Therefore, use case models

that were used in tutorials and example use case

diagrams in books, journals and conference

proceedings were ignored. Use case models that

were created using the old notational set of use case

modeling were also ignored, for example use case

diagrams that used the now outdated <<uses>>

stereotype. The search also excluded use case

models created by University students as part of a

training exercise on use case modeling itself. The

student use case models that were considered were

those that were built as part of a development project

whereby the use case models were created with the

intention to develop an end product. Such use case

models are usually developed as part of a student’s

senior graduation project. Upon executing this

search, 105 use case models were elicited.

The data collected is categorized according to its

source from the use case model, i.e. if it is a

diagrammatic element or is it an element from the

textual descriptions. Detailed categorization of the

information collected is shown in Tables 1-3.

Links to access each use case models is available

in an Excel sheet which can be located at (El-Attar,

2012) The data collected is shown in Tables 1-3.

Table 1 shows the data collected for all 105 use case

models. Table 2 shows the data collected only for

the 65 industrial use case models. Finally, Table 3

shows the data collected only for the 40 student-

developed use case models.

Table 1: All use case models.

All Use Case Models Percentage Used

Diagrammatic Elements

System boundary 45.76%

Actors 100.00%

Abstract actors 14.29%

Use cases 100.00%

Abstract use cases 6.67%

Extension points 2.86%

Relationships

Extend 27.62%

Extend with a condition 1.90%

Include 38.10%

Use case generalization 12.38%

Actor generalization 13.33%

Reuse

54.29%

Association 96.19%

Bi-directional 65.71%

Directed 32.38%

Combination 1.90%

Cardinality 2.86%

Textual Descriptions

Present

48.57%

General characteristics

Bullet points 45.18%

Free-flow form 58.82%

Template 27.45%

Components

Basic flow 100.00%

Alternative flow 47.06%

Preconditions 41.18%

Postconditions 33.33%

Special requirements 13.73%

Table 2: Real-world use case models.

Real-World Use Case Models Percentage Used

Diagrammatic Elements

System boundary 44.62%

Actors 100.00%

Abstract actors 13.85%

Use cases 100.00%

Abstract use cases 9.23%

Extension points 1.54%

Relationships

Extend 26.15%

Extend with a condition 0.00%

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

204

Table 2: Real-world use case models (Cont.)

Include 44.62%

Use case generalization 13.85%

Actor generalization 12.31%

Reuse

60.00%

Association 98.46%

Bi-directional 65.71%

Directed 32.38%

Combination 1.54%

Cardinality 2.86%

Textual Descriptions

Present

50.77%

General characteristics

Bullet points 24.24%

Free-flow form 75.76%

Template 27.27%

Components

Basic flow 100.00%

Alternative flow 51.52%

Preconditions 42.42%

Postconditions 30.30%

Special requirements 15.15%

Table 3: Student use case models.

Student Use Case Models Percentage Used

Diagrammatic Elements

System boundary 45.00%

Actors 100.00%

Abstract actors 15.00%

Use cases 100.00%

Abstract use cases 2.58%

Extension points 5.00%

Relationships

Extend 30.00%

Extend with a condition 5.00%

Include 27.50%

Use case generalization 10.00%

Actor generalization 15.00%

Reuse

45.00%

Association 92.50%

Bi-directional 62.50%

Directed 32.50%

Combination 5.00%

Cardinality 2.50%

Textual Descriptions

Present

45.00%

General characteristics

Bullet points 44.44%

Free-flow form 55.56%

Template 27.78%

Components

Basic flow 100.00%

Alternative flow 38.89%

Preconditions 38.89%

Postconditions 38.89%

Special requirements 11.11%

Upon analysing the data collected and shown in

Tables 1-3, a number of concerns are raised about

how use case modeling is practiced. Further concern

is raised as some trends of use case modeling

practice in industrial settings is found to match

trends of use case modeling practice in academic

settings. The following is a list of concerns raised

after analysing the data collected:

• The system boundary was absent in more than

half of the use case models. Further analysis

shows that students are just as likely as

practitioners to overlook the depiction of the

system boundary.

• The level of use of abstract actors is low at

approximately 14%. This percentage was found

to be approximately the same between students

and practitioners.

• The level of use of abstract use cases were

found also to be low. However, practitioners

were much more likely to introduce abstract use

cases than students.

• The level of use case of extension points in use

cases was found to be very low at

approximately 3%, with students being much

more likely to use it than practitioners.

• Only 5% of student use case diagrams used the

extend relationship while specifying a condition.

Meanwhile, no use case diagrams developed by

practitioners were found to this notational

feature.

• While the use of the include relationship was

high, it was found the practitioners were twice

more likely to use this relationship than

students.

• The use of actor and use case generalization

relationships were found to be equally low in

use case diagrams developed by students and

practitioners.

• Almost half of the use case models did not

promote reuse using the various use case

modeling relationships, with practitioners

slightly more likely to use these relationships

than students.

• The actor generalization relationship was found

in few diagrams than abstract actors. This

means that in some use case diagrams there

were abstract actors that were not specialized.

• There are some use case diagrams created by

practitioners and students that were found not to

contain a single association relationship.

• Practitioners and students were twice as likely

to use the bi-directional association relationship

as they are to use the directed association

AreUseCaseModelingFeaturesUnderutilized?-ALightweightSurveythatRaisesConcerns

205

relationship. However, very few diagrams by

practitioners and students were found to contain

both types of association relationships, which

might be indicative that the modelers may not

know the difference between the two types of

association relationships. Therefore, decisions

of whether or not to add an arrow head to an

association relationship notation were perhaps

arbitrary.

• Specifying cardinality at an association

relationship end was a very rare practice which

occurred in less than 3% of all diagrams.

• Although Tables 1-3 show that almost half of

the use case models did not include textual

descriptions. This statistic is likely to be

misleading since it may be possible that the

textual descriptions were available at a different

source which we were unable to access.

However, there is also likelihood that a subset

of the use case models actually does not include

textual descriptions of the use cases.

• It was found that students are much more likely

to describe their use cases in bullet-point form

while practitioners are much more likely to

describe their use cases in free-flow text form.

• The utilization of a template to describe use

cases was equally low in practitioner and

student use case models.

• More than half the use case descriptions did not

specify alternative flows, preconditions and

postconditions.

• Very few textual descriptions included the

relative constraints imposed in non-functional

requirements, i.e. very few included a ‘Special

Requirements’ section.

4 CONCLUSIONS AND FUTURE

WORK

Use case modeling is constantly increasing in

popularity. The results of this survey show that the

majority of use case modeling features is

underutilized or misused. Given the current trends in

use case modeling practice, there is great concern

that software development teams will continually

develop low quality systems. We argue that more

care should be taken while teaching use case

modeling in academic and industrial settings. Care

should be given in the form of exposing students to

the various use case modeling features and

explaining how they should properly use them. In

industry, current certifications by well-established

organizations should conduct a more thorough

examination of the use case modeling skills of

analysts.

This study is considered preliminary since it

assesses quality in use case models based on its

utilization of use case modeling features. A more

thorough study would certainly be desirable which

will carefully analyse modeling decisions made in

each use case models and while referring with the

authors of each use case model. This comprehensive

study is planned for future work.

ACKNOWLEDGEMENTS

The authors would like to acknowledge the support

provided by the Deanship of Scientific Research

(DSR) at King Fahd University of Petroleum &

Minerals (KFUPM) for funding this work through

project No. IN111028.

REFERENCES

Anda, B., and Sjøberg, D. I. K., “ Towards an Inspection

Technique for Use Case Models,” in Proc. 14

Int’l

Conf. on Software Eng. and Knowledge Eng., 2002,

pp. 127-134.

Anda, B., Sjøberg, D. and Jørgensen, M. “Quality and

Understandability in Use Case Models,” in Proc. 15th

European Conf. Object-Oriented Programming, J.

Lindskov Knudsen, ed., 2001, pp. 402-428.

Berenbach, B., “The Evaluation of Large, Complex UML

Analysis and Design Models,” in Proc. 26th Int’l

Conf. on Software Eng., pp. 2004, pp. 232-241.

Bittner, K. and Spence, I., Use Case Modeling. Addison-

Wesley, 2002.

Booch, G., Rumbaugh, J., and Jacobson, I., The Unified

Modeling Language User Guide, Second Edition.

Addison-Wesley, 2005.

Cockburn, A., Writing Effective Use Cases. Addison-

Wesley, 2000.

El-Attar, M., “Data Files Containing References to Use

Case Models”, [online] Available at: http://faculty.

kfupm.edu.sa/ICS/melattar/UseCaseStats.html,

[Accessed 6 April 2012].

Lilly, S., “Use Case Pitfalls: Top 10 Problems from Real

Projects Using Use Cases,” Proc. of Technology of

Object-Oriented Languages and Systems, 1999.

Object Management Group (OMG), 2009. OMG Unified

Modeling Language (OMG UML) Superstructure.

<http://www.omg.org/spec/UML/2.2/Superstructure/P

DF> [Accessed: 19 October 2011]

Overgraad, G. and Palmkvist, K., Use Cases Patterns and

Blueprints. Addison-Wesley, 2005.

ENASE2012-7thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

206
