String Searching in Referentially Compressed Genomes

Sebastian Wandelt and Ulf Leser

Humboldt-Universit

at zu Berlin, Knowledge Management in Bioinformatics, Rudower Chaussee 25, 12489 Berlin, Germany

Keywords:

Genome Compression, Referential Compression, String Search.

Abstract:

Background: Improved sequencing techniques have led to large amounts of biological sequence data. One

of the challenges in managing sequence data is efﬁcient storage. Recently, referential compression schemes,

storing only the differences between a to-be-compressed input and a known reference sequence, gained a lot

of interest in this ﬁeld. However, so far sequences always have to be decompressed prior to an analysis. There

is a need for algorithms working on compressed data directly, avoiding costly decompression.

Summary: In our work, we address this problem by proposing an algorithm for exact string search over com-

pressed data. The algorithm works directly on referentially compressed genome sequences, without needing

an index for each genome and only using partial decompression.

Results: Our string search algorithm for referentially compressed genomes performs exact string matching for

large sets of genomes faster than using an index structure, e.g. sufﬁx trees, for each genome, especially for

short queries. We think that this is an important step towards space and runtime efﬁcient management of large

biological data sets.

1 INTRODUCTION

The development of novel high-throughput DNA se-

quencing techniques has led to an ever increasing

ﬂood of data. Current techniques, usually summa-

rized under the term second generation sequencing

(SGS), are able to produce roughly the same amount

of data in about a week at a current cost of roughly

2000 USD. Is is predicted, that third generation se-

quencing deliver a further speed-up, reducing the

time and price for sequencing a human genome from

weeks to days and from thousands to under a hun-

dred USD, respectively (Schadt et al., 2010). As a

concrete example, the UK-based Wellcome Trust Se-

quencing Center recently reported that its throughput

in terms of DNA sequences has risen from 100KB/

day in the times of the human genome project to cur-

rently 1TB/day (Chiang et al., 2011).

A human genome consists of 23 chromosomes.

Each chromosome is a sequence of 50.000.000

and 250.000.000 nucleotides: A(denin), C(ytosin),

G(uanin), or T(hymin). In order to store a complete

genome of a human being, one needs more than 3 GB

(uncompressed). Sequence compression is one key

technology to cope with the increasing ﬂood of DNA

sequences (Pennisi, 2011).

Substitutional or statistic compression schemes

can reduce the space requirements by up to 6:1 (one

base is encoded with up to 1.3 Bit) (Antoniou et al.,

2010; Pratas and Pinho, 2011). However, in many

projects only genomes from one species are consid-

ered. This means that projects often deal with hun-

dreds of highly similar genomes; for instance, two

randomly selected human genomes are identical to

an estimated 99.9%. This observation is exploited

by so-called referential compression schemes, which

only encode the differences of an input sequence with

respect to a pre-selected reference sequence. Using

space-efﬁcient encoding of differences and clever al-

gorithms for ﬁnding long stretches of DNA without

differences, the best current referential compression

algorithm we are aware of reports a compression rates

of up to 500:1 (Deorowicz and Grabowski, 2011),

yielding 4 − 8 MB per genome.

In the future, many research facilities will need

to manage and analyze large sets of genomes. We

think that these genomes have to be referentially com-

pressed, in order to overcome the I/O- and storage

bottlenecks of todays computing systems in bioinfor-

matics(Kahn, 2011).

One important type of analysis is string search, i.e.

ﬁnding matching parts of the sequence with respect to

a given query. In this paper, we discuss string search-

ing on large sets of genomes G: Given an input query

Wandelt S. and Leser U..

String Searching in Referentially Compressed Genomes.

DOI: 10.5220/0004143400950102

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2012), pages 95-102

ISBN: 978-989-8565-29-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Rough storage requirements for approximate string search over 1000 genomes.

Element index-based index-less Referential search

Compressed genomes 6 GB 6 GB 6 GB

Index compressed genomes 3+ TB 0 GB 0 GB

Uncompressed reference sequence 0 GB 0 GB 3 GB

Index for reference sequence 0 GB 0 GB 7 GB

Sum 3+ TB 6 GB 16 GB

string q, the task is to ﬁnd all matches of q in each

genome in G.

The traditional approach is to perform the search

on each genome in G using an index. However, since

these indices are often bigger than the uncompressed

input, this naive approach seems to be not feasible.

For instance, the raw data of 1000 uncompressed

genomes already needs 3 TB. Having an index struc-

ture, e.g. a compressed sufﬁx tree, for each genome

will increase the data size further by factors of 3-5 or

more(Vlimki et al., 2009). Therefore, we think that

using one index structures for each referentially com-

pressed genome is not feasible in large-scale projects.

Another approach is to decompress all strings in

G, and perform index-less string search.

In this paper, we propose a third solution: search-

ing within compressed sequences. All input se-

quences were referentially compressed with respect

to a reference sequence, and for the compression one

usually needs an index structure for that reference.

Our idea is to use the existing index structure of the

reference for a string search algorithm on all com-

pressed genomes in G. Since all genomes in G were

referentially compressed with respect to the reference,

large substrings of the reference will occur in the

genomes in G as well, interrupted by SNPs and longer

variations. Therefore, our referential search algorithm

solves the string matching problem as follows: 1) It

ﬁnds all exact matches in the reference sequence us-

ing an index of the reference only and 2) it uses these

matches for identifying all exact matches in genomes

in G.

The space requirements for all three approaches

are compared in Table 1. We report on the run times

of different approaches in detail below.

The remaining part of the paper is structured as

follows. In Section 2, we discuss related work on

compression of genome sequences. We introduce a

general referential compression algorithm in Section

3 and propose a string search algorithm of referen-

tially compressed sequences in Section 4. A prelim-

inary evaluation is given in Section 5. The paper is

concluded with Section 6.

2 RELATED WORK

The increasing number of (re-)sequenced genomes

has lead to many compression algorithms. We only

review losless compression schemes here. In gen-

eral, these compression algorithms can be separated

into bit-manipulating, dictionary-based, statistical,

and referential approaches:

• Bit Manipulation algorithms exploit encodings

of two or more symbols into one byte (Vey, 2009;

Bharti et al., 2011; Mishra et al., 2010).

• Dictionary-based or substitutional algorithms re-

place long repeated substrings by references to a

dictionary built at runtime (Kuruppu et al., 2012;

Antoniou et al., 2010; Kaipa et al., 2010).

• Statistical or entropy encoding algorithms derive

a probabilistic model from the input. Based on

partial matches of subsets of the input, this model

predicts the next symbols in the sequence. High

compression rates are possible if the model al-

ways indicates high probabilities for the next sym-

bol, i.e. if the prediction is reliable(Duc Cao et al.,

2007; Pratas and Pinho, 2011).

• Referential or reference-based approaches are

similar to dictionary-based techniques, as they

replace long substrings with references. How-

ever, these references point to external sequences,

which are not part of the to-be-compressed input

data (Brandon et al., 2009; Kuruppu et al., 2010;

Pande and Matani, 2011; Grabowski and Deorow-

icz, 2011).

There is additional work on read compression, e.g.

(Bhola et al., 2011) and (Wan et al., 2011). The main

problem in read compression is the compression of

quality scores, e.g. (Chen et al., 2011). However, for

the compression of whole genome sequences, quality

scores are, so far, not important. This might change

in the near future.

There has been a lot of research focused on ef-

ﬁcient string search in collections of string. Standard

techniques are Boyer-Moore(Boyer and Moore, 1977)

and the use of sufﬁx trees(Ukkonen, 1995). There ex-

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

Figure 1: Example for relative compression.

ists also work on managing and searching genomic se-

quences in large databases, e.g. (Altschul et al., 1990;

Kent, 2002; Hunt et al., 2002). However, to the best of

our knowledge there exists no work on string search

over referentially compressed genomic sequences.

3 REFERENTIAL COMPRESSION

AND DECOMPRESSION

We denote strings with s,t. The length of a string s is

denoted with |s| and the substring starting at position i

with length n is denoted s(i,n). s(i) is an abbreviation

for s(i,1). All positions in a string are zero-based,

i.e. the ﬁrst character is accessed by s(0). The con-

catenation of two strings s and t is denoted with s ◦t.

Although a genome can be encoded with four charac-

ters, i.e. A,C,G, and T, we allow arbitrary symbols.

For instance, symbol N is often used to indicate an

unknown base. Given two strings s and t, the longest

preﬁx-sufﬁx match of s in t, is the longest string t

such that t = t

◦t

and s(0,|t

|) = t

In referential compression, one or more data se-

quences are compressed with respect to a reference

sequence, by only encoding differences between the

input and the reference. This yields loss-less com-

pression, i.e. based on the reference sequence and

the difference description it is possible to recover the

data sequences. A referential compression algorithm

needs to generate a set of referential matches with

respect to the reference. The output of our referen-

tial compression algorithm is a ﬁle of compression

blocks, such that each block is one of the following:

• Referential Block Re f B(i, j): The data sequence

matches the reference sequence at position i for j

characters

• Raw Block RawB(s): A string s is encoded raw

(for instance if there is no good matching refer-

ence block).

Consider the reference sequence:

re f erence = AGACATACCTACATAC

together with the data sequence

input = ACCTACACCCTAGACACC,

as shown in Figure 1. One compression of input with

respect to re f erence is

comp = (Re f B(6,7), RawB(CCCT ),Re f B(0,5),

RawB(CC)).

The ﬁrst seven symbols of input match the sym-

bols 6 to 12 and are encoded as a referential block

Re f B(6, 7), followed by a raw block, RawB(CCCT ).

The raw block is followed by another referential

block, Re f B(0, 5), indicating that the input matches

the ﬁrst six symbols of the reference sequence. The

last compression block is a raw block, RawB(CC).

Altogether, the input sequence is encoded with ﬁve

compression blocks.

The compression ratio is dominated by the syn-

tactical representation of referential blocks, especially

the efﬁcient encoding of integer values, and the num-

ber and length of referential matches. In the remain-

ing part of the paper, we do not discuss efﬁcient en-

codings of compression schemes further, since there

exists plenty of research on that topic already, for in-

stance (Brandon et al., 2009) and (Daily et al., 2010).

To efﬁciently ﬁnd referential blocks, we use sufﬁx

trees for the reference sequence. The sufﬁx trees of

a reference sequence allows us to ﬁnd longest preﬁx-

sufﬁx matches of parts of the data sequences with re-

spect to the the reference genome.

In the following, we present our compression al-

gorithm for genome sequences in detail. Algorithms

do not show range checks for the sake of readability.

StringSearchinginReferentiallyCompressedGenomes

Algorithm 1 assumes one data sequence in Input (as a

string of symbols). The input string is traversed from

left to right, and depending on the current symbols

in the input and in the reference block, different sub-

routines are executed. The function FIND-MATCH

is used to ﬁnd the longest preﬁx-sufﬁx match of the

current input position with respect to the reference. If

the match is shorter than MIN symbols, or starts with

a non-base symbol, the function ENCODE-RAW is

used for raw encoding of the next input symbols. Oth-

erwise, the function ENCODE-REF is used for refer-

ential encoding of the next input symbols.

Algorithm 1: Compression Algorithm.

!th

1: P

← 0

2: P

raw

← 0

3: while P

<| In | do

4: (p,l)=FIND-MATCH

5: if l < MIN or Input(P

) /∈ {A,C, G,T } then

6: l =ENCODE-RAW(MIN-1)

7: else

8: Add RefB(p,l) to output

9: end if

10: P

= P

+ l

11: end while

Matches are required to have at least MIN charac-

ters, in order to avoid spurious matches. Our experi-

ments have shown that the mere length of genomes,

e.g. human genomes, causes a lot of unrelated

matches with less than 20-25 characters. Further-

more, the compression gain is very small for such

short matches, while ﬁnding them is expensive (each

of them needs one index-lookup). The encoding of a

raw sequence in Algorithm 2 is straight-forward: the

string Raws is ﬁlled with symbols from the input until

a normal base is found or a length-constraint is vio-

lated. In the end, Raw(Raws) is added to the output.

Algorithm 2: ENCODE-RAW(l) Function.

!th

1: Raws ← ””

2: while |Raws| < l or Input(P

) /∈ {A,C,G,T } do

3: Raws ← Raws ◦ Input[P

];

4: P

← P

+ 1;

5: end while

6: Add RawB(Raws) to output

We show the compression process for the com-

pression of (see Figure 1)

In = ACCTACACCCTAGACACC

with respect to the reference sequence

Re f = AGACATACCTACATAC.

Lets assume that MIN = 5. First, the longest

match for the start of In is looked up in Re f and

(6,7) is returned (for matching ACCTACA in the ref-

erence). Re f B(6,7) is added to the output. After-

wards the input position P

is 7, and the algorithm

tries to ﬁnd a new match for CCCTA.... The longest

local match is (7,2), which is shorter than ﬁve, and

therefore RawB(CCCT ) is added to the output. After-

wards the input position P

is 11, and the algorithm

tries to ﬁnd a new match for AGAC.... The result of

FIND-MATCH is (0,5), such that Re f B(0,5) is added

to the output. Next, the remaining string CC is added

as a raw block RawB(CC) to the output.

Decompression of the referentially encoded input

sequences is straightforward. Basically, all compres-

sion blocks are unfolded according to their deﬁnition

(raw or referential block). For decompression of data

sequences we do not need the compressed sufﬁx trees

any longer, but only the reference sequence.

4 STRING SEARCH ALGORITHM

There exists plenty of work on string search algo-

rithms for (not compressed) strings. Usually, an in-

dex structure is computed, for instance, a sufﬁx tree.

These index structures allow for fast access to sub-

strings.

However, in our case, it is not feasible to have

index structures over all compressed genome se-

quences. For the sake of efﬁciency and for minimiz-

ing storage requirements, we want to avoid comput-

ing these index structures (which are usually orders

of magnitudes bigger than the data sequences, see

Table 1). Thus, we have an index structure for the

reference sequence only. In the following, we show

how the index structure for the reference sequence can

be used to efﬁciently ﬁnd matches over referentially

(w.r.t. that reference) compressed sequences.

Assume that we want to search for the query q =

ACC in the input Input from the example above. The

situation is depicted in Figure 2. Matches for the

query ACC can be inside a compression block or be

overlapping more than one block. More formally, if

a string s is a subset of another (referentially com-

pressed) string t, s must either:

1. be a substring of one referential block (actually

the dereferenced referential block),

2. be a substring of one raw block, or

3. be an string overlapping two or more compression

blocks.

Since this list contains all possible cases, we can

ﬁnd all matches for a query q by solving each sub

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

Figure 2: Example for search of ACC.

problem. The ﬁrst kind of substrings is easy to ﬁnd,

since we have an index on the reference sequence.

The second kind of substrings can be found by search-

ing the raw blocks. The overlapping substrings can be

found by thoughtful investigation and partial decom-

pression of subsequences next to the beginning and

end of each block. All three steps are explained be-

low. The list of compression entries for our example

Entries = (Re f B(6,7), RawB(CCCT ),Re f B(0,5),

RawB(CC)).

The set of relative match entries is

RelMatchEntries = {Re f B(6,7), Re f B(0,5)}.

The set of raw entries is

RawEntries = {RawB(CCCT ),RawB(CC)}.

4.1 Finding Matches inside Referential

Blocks

Given the matches for q from the reference se-

quence, we can conclude matches inside relative

match entries immediately. Let Re f Matches =

{(i, j) | Re f erence(i, j) = q}, which can be easily

computed by using the sufﬁx tree for Re f erence.

In order to ﬁnd all positions of q occurring inside

referential blocks, we need to ﬁnd all intervals in

Re f Matches which are included in at least one in-

terval of RelMatchEntries. In our example, the re-

sult would be the set {Re f B(6,7)}, since we have

Re f erence(6,3) = ACC and the string interval (6, 7)

includes the string interval (6,2).

Intervals could be naively computed by pairwise

comparison of each block in RelMatchEntries with

each block in Re f Matches. However, this is ex-

penisve, especially if we have many data sequences

and therefore many sets of RMEntries which need

to be checked against one Re f Matches set. A bet-

ter approach is to order the reference matches in

Re f Matches by position of the match, e.g. this yields

((0,5),(6,7)). This allows us to use binary search in

order to ﬁnd matching subintervals. The complete al-

gorithm is sketched in Algorithm 3.

In our example, we have identiﬁed the block

Match(6,7) as the only referential block containing

Algorithm 3: Referential Blocks Algorithm.

1: Result ←

2: for all E ∈ RelMatchEntries do

3: Perfom binary search on sorted Re f Matches

for sub intervals of E, result is I

4: Result ← Result ∪ I

5: end for

the substring for ACC. The position of q inside a refer-

ential block can be obtained by subtracting the begin-

ning of the reference match (in our example 6) from

the position of the relative match entry (also 6, which

yields position 0).

4.2 Finding Matches inside Raw Blocks

The next class of potential matches are all complete

matches in raw blocks. By construction of our com-

pression algorithm, raw blocks usually

• are very short (less than MIN symbols) or

• contain only non-base symbols, e.g. N.

Therefore, direct substring search for occurrences

of q is efﬁcient here. Since the query never contains

any N symbols, matches in raw blocks are easy to

ﬁnd.

In our example, we have to check all raw blocks in

RawEntries for containing the query ACC, Neither of

the two raw entries, RawB(CCCT ) and RawB(CC),

contains ACC. Thus, after the second step we still

have yet only found one (out of the three) occurrences

of ACC in the input sequence.

4.3 Finding Overlapping Matches

The most difﬁcult task is to ﬁnd matches overlapping

two or more compression blocks. We partially de-

compress one substring for each overlapping area of

compression blocks. We apply the following steps for

each compression block B:

1. Decompress the last |q| − 1 characters of B into

string temp

2. Further decompress the following compression

entries until |temp| = 2 ∗ |q| − 2

StringSearchinginReferentiallyCompressedGenomes

The rationale is that an exact match starting in

B must match 1 ≤ x ≤ |q| − 1 symbols in B and

then |q| − x symbols in the next compression blocks.

Therefore, it is sufﬁcient to partially decompress only

2 ∗ |q| − 2 symbols in totel. If the partially decom-

pressed string temp contains q, then the compressed

input sequence contains q as well. The position can

be easily computed from the match inside the string

temp and the position of the ﬁrst compression block.

In our example, we have four compression entries

and need to decompress three overlapping strings:

• Overlap after Re f B(6,7): CA ◦CC = CACC,

• Overlap after RawB(CCCT ): CT ◦ AG = CTAG,

• Overlap after Re f B(0,5): CA ◦CC = CACC.

The string CACC contains the query ACC and

therefore we have found two additional matches (one

starting at the end of the ﬁrst compression block

and one starting at the end of the third compression

block). The matching position inside the input can be

computed from the matching position inside the over-

lap string, yielding 6 and 15.

Combining the above results we obtain the fol-

lowing three positions as matches for the query ACC:

{0,6,15}.

5 EVALUATION

In the following section, we evaluate our proposed

compression and string search using different set-

tings. All experiments have been run on an Acer As-

pire 5950G with 16 GB RAM and eight Intel Core

i7-2670QM, on Fedora 16 (64-Bit, Linux kernel 3.1).

All size measures are in byte, e.g. 1 MB means

1,000,000 bytes.

As test data we have used HG19H(Kent et al.,

2002) as a reference and the Korean genome(Ahn

et al., 2009) as input. The Korean genome contains,

besides bases and N-symbols additional characters for

indicating base probabilities. In related work it is

common practice to replace all occurrences of these

additional characters by N, which yields lossy com-

pression. However, we have chosen to encode the

original sequence, in order to obtain lossless com-

pression. Our compression rate could be further im-

proved, if these additional symbols were replaced

by N. The compression time for a complete human

genome was 29 seconds. To the best of our knowl-

edge this is almost one order of magnitude faster than

the best existing approach for referential compres-

sion. Since our algorithms can be easily parallelized,

we think that the performance of our simple compres-

sion algorithm can be improved further.

Figure 3: Compression ratio.

In Figure 3, the compression ratio is shown for

several data sequences (different chromosomes). The

compression ratio (size of the compressed output di-

vided by the size of the input) is roughly indepen-

dent of the size of the input, and is around 0.50 per-

cent. This means that we achieve a 20-fold com-

pression. The average length of referential blocks

is shown in Figure 4. It can be seen that the aver-

age length of referential blocks is also roughly inde-

pendent of the input chromosome and in average at

630 symbols/referential block. This coincides with

the background knowledge that around 99.9 percent

of two human genomes are equal.

Figure 4: Average length of ref. blocks.

Further analysis of the compression blocks

showed that the average length of raw blocks is 17

symbols. 54 percent of the blocks in a compressed

ﬁle are referential blocks and the remaining 46 per-

cent are raw blocks.

In order to evaluate our string search algorithm,

we have measured the run time for string search for

several queries. The result for a query string of length

12 is shown in Figure 5. The time needed for string

search grows linear with the length of the input se-

quence. This is due to the (linear) traversal of all com-

pression blocks during the search phase.

We ran experiments with different query lengths:

6, 12, 24, 48, and 96. Longer queries seem to slow

down the string search a little bit (order of few ms

comparing length 12 with length 96). Our investi-

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

100

Figure 5: Answering times for Q12.

gation show that this is caused by the implementa-

tion of compressed sufﬁx trees we have used: for

longer queries, the library spends more time to lookup

matches in the reference sequence.

Since, to the best of our knowledge, there ex-

ists no related work on string search over referen-

tially compressed genome sequences, we have imple-

mented the following competitors ourself for evalua-

tion purposes:

1. Naive search: First we completely decompress

the compressed input sequence into main mem-

ory and then search in-memory without an in-

dex, using bit-parallel string matching (Peltola

and Tarhio, 2003).

2. Index-based search: We use an existing sufﬁx tree

for the uncompressed input sequence, in order

to ﬁnd string matches.

Figure 6: Answering times for Q12.

The results are shown in Figure 6. It can be seen

that the naive approach is the slowest one, using al-

most 2 seconds to lookup the test string in the input

chromosome (150 MB). Therefore, we think that de-

compression is no solution for string matching with

respect to compressed ﬁles. The approach using suf-

ﬁx trees is superior to our new approach, taking 106

ms compared to 125 ms. However, there are concerns:

1. The sufﬁx tree of the index has to be created be-

forehand/ofﬂine. The additional time, we mea-

sured 10-40 seconds per chromosome for our test

genome, should be taken into account.

2. The sufﬁx tree uses a lot of space. We measured

roughly an increase of factor 2-4 for our test chro-

mosomes. This means, that the index structure is

even bigger than the original uncompressed ﬁle.

Since sufﬁx trees, or alternative index structures,

have to be created for each(!) input sequence, we

think that the small time overhead of our proposed ap-

proach is clearly acceptable. No extra data structures

have to be computed and stored ofﬂine. All we use

is the compressed ﬁle and the (one) index structure of

the reference sequence.

6 CONCLUSIONS AND FUTURE

WORK

One of the challenges in managing sequence data is

efﬁcient storage and retrieval over compressed data.

In this paper, we addressed this problem by propos-

ing an algorithm for string search, which works di-

rectly on referentially compressed genome sequences.

Our evaluation shows that we can achieve similar run

times as if we had an index structure for each com-

pressed sequence. The ability to search biological se-

quences directly in a compressed structure opens new

ways for managing data in research groups. For in-

stance, a main-memory genome database, where all

genomes can be hold in RAM.

One important open challenge is approximate

string searching over referentially compressed se-

quences. We think that our search scheme can be ex-

tended in order to ﬁnd approximate matches as well.

Scientiﬁc workﬂows have gained increased inter-

est during the last years in biology. The integration

of referential compression and string searching into

these workﬂows is one further open challenge.

REFERENCES

Ahn, S.-M., Kim, T.-H., Lee, S., Kim, D., et al. (2009).

The ﬁrst Korean genome sequence and analysis: Full

genome sequencing for a socio-ethnic group. Genome

Research, 19(9):1622–1629.

Altschul, S. F., Gish, W., Miller, W., Myers, E. W., and

Lipman, D. J. (1990). Basic local alignment search

tool. Journal of molecular biology, 215(3):403–410.

Antoniou, D., Theodoridis, E., and Tsakalidis, A. (2010).

Compressing biological sequences using self adjust-

ing data structures. In Information Technology and

Applications in Biomedicine.

StringSearchinginReferentiallyCompressedGenomes

101

Bharti, R. K., Verma, A., and Singh, R. (2011). A biological

sequence compression based on cross chromosomal

similarities using variable length lut. International

Journal of Biometrics and Bioinformatics, 4:217–223.

Bhola, V., Bopardikar, A. S., Narayanan, R., Lee, K., and

Ahn, T. (2011). No-reference compression of genomic

data stored in fastq format. In BIBM, pages 147–150.

Boyer, R. S. and Moore, J. S. (1977). A fast string searching

algorithm. Commun. ACM, 20(10):762–772.

Brandon, M. C., Wallace, D. C., and Baldi, P. (2009). Data

structures and compression algorithms for genomic

sequence data. Bioinformatics, 25(14):1731–1738.

Chen, W., Lu, Y., Lai, F., Chien, Y., and Hwu, W. (2011).

Integrating human genome database into electronic

health record with sequence alignment and compres-

sion mechanism. J Med Syst.

Chiang, G.-T., Clapham, P., Qi, G., Sale, K., and Coates, G.

(2011). Implementing a genomic data management

system using iRODS in the Wellcome Trust Sanger

Institute. BMC Bioinformatics, 12(1):361+.

Daily, K., Rigor, P., Christley, S., Xie, X., and Baldi, P.

(2010). Data structures and compression algorithms

for high-throughput sequencing technologies. BMC

bioinformatics, 11(1):514+.

Deorowicz, S. and Grabowski, S. (2011). Robust Rela-

tive Compression of Genomes with Random Access.

Bioinformatics.

Duc Cao, M., Dix, T. I., Allison, L., and Mears, C. (2007).

A simple statistical algorithm for biological sequence

compression. In Proceedings of the 2007 Data Com-

pression Conference, pages 43–52, Washington, DC,

USA. IEEE Computer Society.

Grabowski, S. and Deorowicz, S. (2011). Engineering rela-

tive compression of genomes. CoRR, abs/1103.2351.

Hunt, E., Atkinson, M. P., and Irving, R. W. (2002).

Database indexing for large dna and protein sequence

collections. The VLDB Journal, 11(3):256–271.

Kahn, S. D. (2011). On the future of genomic data. Science,

331(6018):728–729.

Kaipa, K. K., Bopardikar, A. S., Abhilash, S., Venkatara-

man, P., Lee, K., Ahn, T., and Narayanan, R.

(2010). Algorithm for dna sequence compression

based on prediction of mismatch bases and repeat lo-

cation. In Bioinformatics and Biomedicine Workshops

(BIBMW).

Kent, W. J. (2002). BLATThe BLAST-Like Alignment

Tool. Genome Research, 12(4):656–664.

Kent, W. J., Sugnet, C. W., Furey, T. S., Roskin, K. M.,

Pringle, T. H., Zahler, A. M., and Haussler, D. (2002).

The human genome browser at UCSC. Genome Res,

12(6):996–1006.

Kuruppu, S., Beresford-Smith, B., Conway, T., and Zobel,

J. (2012). Iterative dictionary construction for com-

pression of large dna data sets. IEEE/ACM Trans.

Comput. Biol. Bioinformatics, 9(1):137–149.

Kuruppu, S., Puglisi, S. J., and Zobel, J. (2010). Relative

lempel-ziv compression of genomes for large-scale

storage and retrieval. In Proceedings of the 17th inter-

national conference on String processing and infor-

mation retrieval, SPIRE’10, pages 201–206, Berlin,

Heidelberg. Springer-Verlag.

Mishra, K. N., Aaggarwal, D. A., Abdelhadi, D. E., and

Srivastava, D. P. C. (2010). An efﬁcient horizontal

and vertical method for online dna sequence compres-

sion. International Journal of Computer Applications,

3(1):39–46. Published By Foundation of Computer

Science.

Pande, P. and Matani, D. (2011). Compressing the human

genome against a reference. Technical report, Stony

Brook University.

Peltola, H. and Tarhio, J. (2003). Alternative algorithms for

bit-parallel string matching. In SPIRE, pages 80–94.

Pennisi, E. (2011). Will Computers Crash Genomics? Sci-

ence, 331(6018):666–668.

Pratas, D. and Pinho, A. J. (2011). Compressing the hu-

man genome using exclusively markov models. In

Rocha, M. P., Rodrguez, J. M. C., Fdez-Riverola, F.,

and Valencia, A., editors, PACBB, volume 93 of Ad-

vances in Intelligent and Soft Computing, pages 213–

220. Springer.

Schadt, E. E., Turner, S., and Kasarskis, A. (2010). A win-

dow into third-generation sequencing. Human molec-

ular genetics, 19(R2):R227–R240.

Ukkonen, E. (1995). On-Line Construction of Sufﬁx Trees.

Algorithmica, 14(3):249–260.

Vey, G. (2009). Differential direct coding: a compression

algorithm for nucleotide sequence data. The Journal

of Biological Database and Curation, 2009.

Vlimki, N., Mkinen, V., Gerlach, W., and Dixit, K. (2009).

Engineering a compressed sufﬁx tree implementation.

ACM Journal of Experimental Algorithmics, 14.

Wan, R., Anh, V. N., and Asai, K. (2011). Transforma-

tions for the compression of fastq quality scores of

next generation sequencing data. Bioinformatics.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

102
