Fault Tolerance through Interaction and Mutual Cooperation

in Hierarchical Multi-Agent Systems

Rade Stanković

and Maja Štula

Communications, Media and Technology (CMT), Siemens d.d., Put Brodarice 6, 21000, Split, Croatia

Department of Electronics, Faculty of Electrical Engineering,

Mechanical Engineering and Naval Architecture in Split (FESB), R. Boškovića 32, 21000, Split, Croatia

Keywords: Fault Tolerance, Failure Handling, Multi-Agent Systems, Intelligent Agents, Agent Hierarchy.

Abstract: Multi-Agent Systems (MASs) are well suited for development of complex, distributed systems. In its

essence MAS is a distributed system that consists of multiple agents working together to solve common

problems. Failure handling is an important property of large scale MAS because the failure rate grows with

both the number of the hosts, deployed agents and the duration of agent’s task execution. Numerous

approaches have been introduced to deal with some aspects of the failure handling. However, absence of

centralized control and large number of individual intelligent components makes it difficult to detect and to

treat errors. Risk of uncontrollable fault propagation is high and can seriously impact the performance of the

system. Although existing research has been extensive, it still needs to attend the MAS failure handling

problem in all its aspects, which makes this topic very interesting. We propose a concept of agent

interaction that enables any hierarchical MAS to become fault tolerant, regardless of the used agent

framework.

1 INTRODUCTION

Employment of intelligent agents in distributed

systems incorporates concepts from both Artificial

Intelligence (AI) and Comuter Science (CS). From

the Computer Science perspective agent can be

described as a peace of code, that when executed has

data and state (Tanenbaum and Steen, 2002). From

the Artificial Intelligence point of view, agents are

defined as executable software entities with varying

degrees of intelligence, autonomy and ability to

communicate to each other in order to solve

common problems (Bellifemine et al., 2007);

(Rudowsky, 2004). Agent oriented paradigm is the

appropriate practice for modelling, design and

implementation of complex and distributed software

systems (Jennings, 2001). Agents execute inside

execution environment or agent framework that

controls agent’s life cycle and provides necessary

mechanism for agent’s execution. Agent is capable

of flexible, autonomous action in that environment

in order to meet its designer objectives (Bellifemine

et al., 2007); (Wooldridge, 1997).

When single agent is incapable of solving a

problem, due to its limited capability or knowledge,

agents join together forming distributed loosely

coupled network to solve their problems. Such

community is called Multi – agent system (Sycara,

1998). In MAS task is decomposed, sub-tasks are

divided among agents, and agents interact with each

other. MAS is applicable in a wide range of

problems, such as information retrieval

(Punithavathi and Duraiswamy, 2010), mobile

telecommunication networks (Jurasovic et al., 2009),

power supply management (Yang et al., 2006)

(Zhang et al., 2004), space exploration and other

(Rudowsky, 2004).

Agents and their resources may become

unavailable due to the machine crashes,

communication breakdowns, process failures, and

numerous other hardware and software failures

(Fedoruk and Deters, 2002). Significant part of the

research effort regarding MAS failure handling is

oriented towards increasing the robustness and

failure resistance of agents themselves (Mitrović et

al., 2010). In today’s connected world where quality

of service is of extreme importance and level of

service is formally defined through Service Level

Agreements (SLA) (Anon, 2002), a system is called

a high – assurance system, when heterogeneous and

337

Stankovi

c R. and Štula M..

Fault Tolerance through Interaction and Mutual Cooperation in Hierarchical Multi-Agent Systems.

DOI: 10.5220/0004182003370344

In Proceedings of the 5th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2013), pages 337-344

ISBN: 978-989-8565-38-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

changing requirement levels of the Quality of

Service (QoS) are satisfied (Ahmad et al., 2001)

(Ahmad et al., 2003). High assurance of service in

distributed multi – agent systems is a key feature for

its successful deployment.

Despite considerable efforts spent on developing

multi – agent systems, actual number of deployed

systems is not nearly as large; one of the main

reasons for that are failure handling issues, which

make MASs very brittle (Briot and Ghédira, 2003).

Techniques used in traditional distributed

architectures are often static, require special

infrastructural support and restrict functionality of

agent frameworks (Kumar and Cohen, 2000). When

a fault occurs in MAS, interactions between the

agents may cause the fault to spread throughout the

system in unpredictable ways (Almeida, et al.,

2006). This is extremely undesirable in critical

applications, where the occurrence of a fault may

cause the loss of lives, delays in the products

manufacturing process (business loses) or

suboptimal resource utilization.

In this paper, we introduce our solution to

building reliable MAS. It is based on the agent

interaction that enables fault tolerance in the

hierarchical MAS regardless of an agent framework

used; unlike other solutions that are framework

dependent (Almeida et al., 2006), (Faci et al., 2006),

(Helsinger et al., 2004). We introduce special class

of agents, called Arbiters, that help ordinary working

agents recover in case of faults. Our approach relies

on agent communication and cooperation to enable

successful fault recovery.

The remainder of this paper is organized as

follows. In Section 2 we provide an overview of the

related work. Section 3 describes our approach to

building the fault tolerant multi – agent system.

Section 4 shows comparative simulation results.

Finally, Section 5 summarizes our approach and on-

going work.

2 RELATED WORK

Research on the agent based failure handling has

been extensive; it can be classified to a failure

handling by individual agents within an agent

framework and a failure handling by an agent

framework (Figure 1). In this overview we will

show different researchers approaches used to tackle

failures in agent based systems, their key features

and weaknesses.

Failure handling by individual agents within the

agent framework is reported in the following works.

Kumar et al. propose fault tolerance (FT)

architecture based on agent brokers. (Kumar et al.,

2000). Approach arranges brokers in hierarchical

teams, which are then used for communication and

coordination among agents. Fault tolerance mostly

concentrates on the fault tolerance of brokerage team

and not on individual agents doing actual work.

Proposed architecture requires extra computing for

the management of brokerage layers.

Proxy based approach is proposed by Fedoruk et

al., in which a proxy transparently handles the

replication group based on predefined policies

(Fedoruk and Deters, 2002). The proxy is nothing

more than a computational entity, which provides

interface to a set of agent replicas. This approach

suffers from the centralized bottle neck by proxy

itself and only concentrates on replicating agents of

a multi - agent system. It is more costly in terms of

forming replication groups of all the agents in a

multi - agent system. The approach also lacks

reusability in particular concerning the replication

control.

Xu et al. address fault detection techniques

proposed in (Xu and Deteis, 2005), (Dellarocas and

Klein, 1999) by sending periodic events to agents

inspecting their state. Separate query language to

inspect agent state and action language to recover

agent in error are used. This kind of exception

handling requires periodic probing and is quite an

overhead on the system. Agent recovery is vaguely

described.

Varghese at al. propose an agent based approach

that handles single node failures for parallel

summation algorithms in computer clusters.

(Varghese et al., 2010) (McKee and Varghese,

2010). The agents intercommunicate across

computing nodes, when they detect failure they

move away from the faulty node notifying other

agents to stay away from the problematic node.

Solution is narrowly specialized and highly

dependent on accurate prediction; in case of

unpredicted failure calculations must be done again.

Failure handling by the agent framework is

focused on maintaining highly available MAS that

can withstand numerous agent, hardware and

network failures is reported in the following works.

First we will look at researches focused on ensuring

failure handling using agent replication. The

simplified idea behind these techniques is to keep

multiple copies of an agent, distributed across a

number of nodes. In case the original agent fails, one

of the copies automatically takes over its task

execution process. Approaches evolve on how to

define critical agents that should be replicated to

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

338

minimize usage of system resources. FATMAS

methodology introducing guidelines for the analysis

and the design of fault – tolerant MAS is proposed

by Mellouli et al. (Mellouli et al., 2004). Moreover,

it provides guidelines for an agent and task

replication, which enables reduction in the

replication cost. However, the approach addresses to

closed MAS; agent criticality is defined at design

time, meaning replication is static. Almeida et al.

(Almeida et al., 2006), (Marin, 2003) report the

implementation of the Dynamic Agent Replication

Extension (DARX), a failure handling agent

framework. In this model, failure handling is

performed by replicating those agents that are

critical to the system and whose future plans could

inﬂuence other agents in the system. Agent’s

criticality is dynamically evaluated by revising

agent’s plans and roles. Faci et al. introduced agent

framework based on DARX named DimaX (Faci et

al., 2006). It uses interdependence graphs for

evaluating the significance of every agent in the

system, and uses DARX to accordingly maintain an

optimum number of replicas (process known as

adaptive replication). The system also employs host

monitors, low-level agents that try to perform early

detection of failures and inform all interested parties

about the problem in a timely manner. This would,

for example, allow an agent and its replicas to leave

the troubling environment, or to move important

data from it. At the basis of the monitoring is a

heartbeat technique, used by the agents in the system

to indicate their valid operational status to each

other. When determining agent criticality, no

guarantee is given that the agent is truly critical, it

can only seem critical to the system; monitoring

technique provides extra communication overhead.

In the MAS fault handling research focus is not

only the agents. Helsinger et al. propose Java-based

architecture for the construction of large-scale

distributed agent based applications named Cougaar

(Helsinger et al., 2004). Cougaar is designed to be

continuously available and degrades gracefully when

its components get disconnected or damaged. Agent

is viewed as a set of problem solving behaviours

interacting via traditional blackboards with standard

publish/subscribe semantics. If an agent is unable to

contact a member of its community it can send a

health alert message to a health monitor agent,

which is responsible for the recovery of agents.

Recovery can be done in two ways; either by

retrieving an appropriate community state needed to

pursue the problem solving or by rejoining the failed

agent to its community which has begun a new

problem solving stage. Approach is adaptable,

however lacks compliance to the standard and is

extremely complex; no guarantee is given that the

MAS will correctly pursue its goals after agent

failures e.g. failures can cause deadlocks and other

problems.

Khan et al. propose approach based on

decentralized architecture (Khan et al., 2005).

Virtual agent cluster (VAC) is an abstraction which

provides scalable transparency among all the

distributed machines over which the agent platform

is deployed. It enables seamless agent migration and

communication between different machines in the

virtual cluster. This approach introduces load

balancing and agent platform fault tolerance in

distributed MAS, meaning even if one machine in

platform is operational, MAS is stable and the agents

can execute. Agent states are preserved using

persistence which is resource costly; after agents are

restored, they rejoin community which can have

different state then when the agent failed. This issue

is not resolved.

Failure handling by agent framework offers fault

handling features of certain quality and is applicable

for some fault scenarios, but at the same time it

neglects some other features of agent framework and

introduces large degree of complexity. As a

consequence interoperability between heterogeneous

multi – agent systems is difficult if not impossible to

realize (D. Mitrović et al., 2011); (Suguri et al., 2002).

Figure 1: Failure handling classification.

3 COOPERATIVE FAULT

TOLERANCE

We propose cooperative fault tolerance (CFT)

solution that can easily be included into any existing

agent framework. Unlike other approaches, we do

not base our solution on replication (Mellouli et al.,

2004), (Deters et al., 2002), (Almeida et al., 2006)

FaultTolerancethroughInteractionandMutualCooperationinHierarchicalMulti-AgentSystems

339

or complex framework implementation (Faci et al.,

2006), (Helsinger et al., 2004); instead our approach

uses agent cooperation to enable fault tolerance in

the hierarchical MAS. Agents in the MAS can

organize differently to solve problems (Mladenović,

2011). Our solution focuses on the hierarchical

MAS. Hierarchy is crucial part of many complex

systems (Ravasz et al., 2003). It is an arrangement of

items (objects, names, values, categories, etc.) in

which the items are represented as being “above,”

“below,” or “at the same level” as other items. This

type of organization prevails in big complex systems

like companies, governments, cosmology, religions

and technical systems (Ravasz et al., 2003) (Torrel

et al., 2007). Organization of MAS can be displayed

with a graph; graph consists of two types of

information: vertices (nodes) and edges (connections

that display node interaction) (Wilson, 1990).

Hierarchy can be represented with a tree graph; a

tree is an undirected graph in which any two vertices

are connected by exactly one simple path. In other

words, any connected graph without cycles is a tree

(Wilson, 1990).

Our solution divides agents into two categories:

worker agents (Workers) and arbiter agents

(Arbiters). Workers represent typical agents in a

MAS that solves different user tasks (Bellifemine et

al., 2007) (Rudowsky, 2004). Worker does

everything in its power to solve the given task; if it

is incapable of solving the problem due to its limited

capability or knowledge, it organizes into hierarchies

and communicates with other agents to solve it.

Arbiters are committed to solving failures that occur

when Worker agent/s fail. To maximize resource

utilization initially only few instances of Arbiters

exist. Main instance is called “Distributor” which

receives initial error notification from Worker agents

and forwards those to the specific Arbiter dedicated

to resolve that specific agent failure. Each arbiter is

dedicated to solving a single problem. Distributor is

also in charge of maintaining optimal number of

Arbiters. If there are more failures than free Arbiter

agents, it creates additional agents. Once the failures

are resolved Distributor disposes of additional

arbiter agents, maintaining original number of

arbiters in a failure free system. In case of the

Distributor failure, first Arbiter that registers its

failure notifies other Arbiters via multicast message

and takes it place. New Distributor then builds up

the list of available Arbiters and their tasks,

completing the transition process. Only agent that is

not protected by our approach is the root agent

which can be protected by the basic replication

approach. For example, let us define hierarchical

MAS as the graph G = {r, w, x, y, z} where vertices

are related in such a way that the r is the root node;

w, x are its child nodes and y, z nodes are the

children of x (Figure 2).

Figure 2: MAS hierarchy structure.

Let us define set of attributes that accurately

describe node tasks with the list of ordered triple:

(<'name1', 'task1', 'solution1'>, <'name2', 'task2',

'solution2'>...). For agent represented by node x

original attribute (task) received from its parent is

defined as



. Original task is defined as

set T={atrX

,atrX

}; atrX

and represents task

that agent x has to do itself. atrX

and atrX

represent tasks forwarded to agents y and z

respectively. Algorithm that splits task into subtasks

can be defined as function f:T→S that is invertible,

meaning there is a function  with domain  and

range, with the property: f





if and only

if g





=t; this is important so that agent can check

consistency when recreated. Tasks and sub tasks

have hierarchical organization.

Relation , which binds set of sub tasks into the

original task (Johnson, 2009) exists. To prove that 

binds set of sub task into the complex task we

define relation as: R:



atrX

,atrX



→

<atrX

,atrX

;atrX

orig

;R>. This relation can

be displayed via hierarchical cone, where the base of

the cone is formed by sub tasks while the tip of the

cone represents main task atrX

orig

. If sub task level

is definedLevel (atrX

), then we can write

Level



atrX



< Level atrX

orig

 ∀ atrX

, meaning

that the task cannot be part of the sub task. This

principle defines absolute measure of difference

between levels in complex systems. Basic operations

on the nodes of the graph (insert, delete) are defined

as:

Insert(y, tasklist

(<'name1','task1','solution1'>,

<'name2','task2','solution2'>...),

This command inserts node y. If the node does

not exist, it creates the node with appropriate

attributes. First attribute in the list represents

original task. If the node exists, new attributes

overwrite old ones and connection is made to the

parent node x.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

340

Delete(y, tasklist, x)

This command deletes mentioned attributes and

relation between node y and its parent x. If no

attributes are mentioned, only relationship between

nodes is removed. If no attributes are mentioned and

parent node is mentioned, then node y is deleted

with all its attributes and relation to its parent.

In the case of error Arbiters are used to repair

agents in error. Let us suppose that the agent x fails

and its child agent y detects that while returning a

result of its task. Arbiter Ar is assigned to solve the

problem, it collects information about agents aware

of agent x and their attributes. Now Arbiter Ar has

all data necessary to recreate agent x.

We can define attributes that Arbiter Ar collected

as atrAr={atrX

orig

,atrX

}. Worker x is

recreated with agents sub tasks mapped to the

appropriate existing child agents. Sub task that is

missing is atrX

and agent assigns it to itself.

Because of this, recreated node x will reuse result of

child Workers y and z; only sub task atrX

will be

redone, if it was completed, if it was not completed,

it will be only executed once so no impact on

performance will occur. Operations that Arbiter can

do (find, recreate, notify) are defined as:

Find





This is a multicast message to which all agents in

relation to Worker x will answer. Arbiter a will

collect the list of Workers x was related to, its

original tasks and sub tasks and forwarded it to its

children.

Recreate(x,tasklist

(<'name1','task1','solution1'>,

<'name2','task2','solution2'>...),

agentlist(r,y,z))

This command recreates node x as a child node

of r and as a parent node of nodes y and z with set of

attributes that accurately describe the node tasks.

First attribute in the attribute list represents original

task, first node in the node list represents parent

node.

Notify(x)

This is multicast message that notifies all agents

in relation to x that the Worker x is recreated and

running. Timing of the error can be a crucial factor

that diminishes benefits of this approach. Let us get

back to Figure 2 and suppose that Workers y and z

finished their task and returned result to their parent

node; x finishes its calculation and fails at exact that

time. If we do not do anything, Workers x, y and z

would be recreated and all tasks redone. To tackle

this problem we propose result parsing mechanism.

After task is completed result is passed up in the

hierarchy. Each agent in the hierarchy has a memory

buffer in which it stores results received from its

children, grandchildren and so on. Result parsing has

its benefits in following scenarios: providing extra

tolerance to multiple failures in the same branch of

the execution tree and quick recovery of the parent

whose children completed work without extra

calculation. When agent y and z finish and report

their results, data is stored in their parent x but also

grandparent r and if needed further up the hierarchy.

With result parsing if Worker x fails after its

children reported the results there is no problem,

since y and z results are stored in Worker r. Worker

r notices that x is in error and notifies Arbiter agent.

Worker x is restored as before but in the restore

command are also results from workers y and z.

Worker x then combines result from Workers y and

z, does its task and returns result to its parent r.

Parsing operation is defined as:

Parse(x,tasklist

(<'name1','task1','solution1'>),

, y)

Worker x uses this command to parse data from

node y forward up the hierarchy.

4 TESTING AND EVALUATION

In this section we evaluate viability of CFT solution

in comparison to the basic no fault tolerant scenario

and to the active replication DARX like framework.

Simulations where created using NetLogo, a multi –

agent programmable modelling environment, used

for simulating natural and social phenomena.

NetLogo is particularly well suited for modelling

complex systems developing over time. Modellers

can give instructions to hundreds or thousands of

"agents" all operating independently (Wilensky,

1999). This makes it possible to explore the

connection between the micro – level behaviour of

individuals and the macro – level patterns that

emerge from their interaction.

Simulations were comprised in such a way that

they test solutions through the whole working

envelope by varying task complexity and error

probability; the more complex the task the longer

simulation will run (e.g. length 80 means that

simulation will divide task into sub tasks for 80

consecutive steps, task complexity is greater and

total number of agent increases. Simulation lasts for

much longer than length of division, until final result

FaultTolerancethroughInteractionandMutualCooperationinHierarchicalMulti-AgentSystems

341

Figure 3: Basic no FT solution, data for various simulation length and error probability.

Figure 4: DARX like replication solution, data for various simulation length and error probability.

Figure 5: CFT solution, data for various simulation length and error probability.

is returned to the user). For every solution baseline

information was obtained by running the simulation

with no errors for various task sizes.

For each algorithm/complexity pair ten

simulation runs where performed; average values for

each run are presented. Numerous parameters where

monitored, but the focus of our tests were on the

total message count (network load) and total number

of calculations done (CPU load). Those parameters

where selected as they represent most significantly

load on the system.

Total number of messages exchanged in the

system is sum of real messages needed for normal

task execution and helper ones needed for failed task

recreation, fault tolerance and replication if it is

used. Total number of calculations done by the

system is sum of normal calculations done by

agents, extra calculation done when node fails and

extra calculation done by replicated nodes if

replication is used.

For the no FT solution (Figure 3) situation is

quite straightforward; number of messages and

calculations grow as the number of agents needed to

solve the task grows; as the error probability

increases, so does the number of messages and

calculations. This is the most efficient scenario when

there are no errors in the system, but even the

slightest error probability sky rockets number of

extra messages and calculation, stressing importance

of the fault tolerant solution.

Results for replication solution are shown in

Figure 4; we simulated DARX like active replication

mode using available sources (Almeida et al., 2006),

(Marin, 2003) for reference to make the simulation

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

342

results more accurate. It is important to notice that

the message and calculation count has only the slight

increase regardless of error probability, remaining

pretty much the same throughout the increase of task

complexity. This solution excels over the basic no

FT solution in all except “no error” scenario.

Proposed CFT solution results are shown on

Figure 5. Our solution excels over the no FT

solution. In no error scenario our solution has a

bigger message count than no FT scenario because

of extra parsing messages, while number of

calculations is the same meaning our approach does

not waste processor time; As the error probability

increases our solution achieves on average five times

less number of calculations, for all group sizes than

no FT scenario. Our message count results are

comparable to the DARX like active replication

solution (slightly better for all but the largest task

complexity). Comparing number of calculations our

solution excels over results achieved by active

replication solution, number of calculations are two

times lower for all group sizes and error

probabilities.

5 CONCLUSIONS

Multi-Agent Systems are well suited for

development of complex, distributed systems;

therefore usage of the MAS is expected to grow in

the future. Fault tolerance is an important property

of large scale MAS which enables successful

application of the system. In recent years a lot of

research has been done addressing specific aspects

of fault tolerance, however none of the proposed

solutions gives a complete coverage of the problem

leaving a lot of opened areas for new approaches and

improvements. After extensive overview of the

available FT solutions in section 3 we proposed a

novel solution for creating fault tolerant MAS.

Proposed solution can be used as a set of

implementation guidelines that enable its application

to any agent framework, providing that agents form

hierarchies when solving problems. Our approach

enables: easy substitution of agent in error by

replacement agent, preservation of child agent’s

data so no extra work is necessary. This enables

MAS to recover quickly and without wasting

valuable system resources, ensuring that agents

continue to pursue their goals fast and correctly.

In section 4 we provided extensive simulation

and compared results between our solution, basic no

FT scenario and active replication solution. We

focused on the two main parameters that represent

most significantly load on the system, calculation

count (CPU load) and message count (network

load). Simulation results show advantages of our

solution and proves that our solution enables

performance light FT for hierarchical MAS

regardless of agent framework. We should point out

the fact that our solution is easy to implement in any

existing or future MAS regardless of framework in

use while most of other FT solutions have high

degree of complexity and are often related to

specific agent framework. This means that

complexity and ease of use should be important

factor in any future comparisons.

Further research is directed to free our solution

from its limited usage to MAS that form hierarchies

while solving problems. This would enable the

solution to be used in any type of MAS. Basic idea

behind this direction is to use peer-to-peer (P2P)

communication between unrelated agents in the MAS,

so agents can save their state among their peers. In the

case of error Arbiters can recreate agent in error with

the help of data stored at its peers. To successfully

improve current solution we must overcome number

of challenges. Most prominent of them is the optimal

usage of P2P communication so the system would not

suffer performance degradation due to the intensive

messaging. Second challenge is to develop viable

incentive model that will encourage agents to give up

part of their resources for unrelated peers pursuing

unrelated goals. Third challenge is to ensure that the

solution has distinct advantage over other FT

solutions in parameters that we see as relevant in the

MAS now (CPU load, network load, overall

complexity and ease of use) and others that we may

include in the future.

REFERENCES

Ahmad, H. F., Sun, G. and Mori, K., 2001. Autonomous

Information Provision to Achieve Reliability for Users

and Providers. s.l., IEEE Proc. of the Fifth International

Symposium on ADS (ISADS01), pp.65-72.

Ahmad, H. F., Sun, G. and Mori, K., 2003. Dynamic

Information Allocation Through Mobile Agents to

Achieve Load Balancing in Evolving Environment. s.l.,

IEEE Proc. of the Sixth International Symposium on

ADS (ISADS03), pp.25-33.

Almeida, A. d. L., Aknine, S., Briot, J.-. P. and Malenfant,

J., 2006. Plan-based replication for fault-tolerant

multi-agent systems. s.l., Proceedings of the 20th IEEE

International Parallel and Distributed Processing

Symposium.

Anon., 2002. SLA Information Zone. [Online] Available

at: http://www.sla-zone.co.uk/ [Accessed June 2011].

FaultTolerancethroughInteractionandMutualCooperationinHierarchicalMulti-AgentSystems

343

Bellifemine, F. L., Caire, G. and Greenwood, D., 2007.

Developing multi-agent systems with JADE. s.l., John

Wiley & Sons, Inc..

Briot, J.-P. and Ghédira, K., 2003. Déploiement des

systemes multi-agents. s.l., Revue des Sciences et T

echnologies de l’Information, hors série/JFSMA 2003.

D.Mitrović, Ivanović, M., Budimac, Z. and Vidaković, M.,

2011. An overview of agent mobility in heterogeneous

environments. s.l., Proceedings Of The Workshop On

Applications Of Software AgentS.

Dellarocas, M. and Klein, C., 1999. Exception Handling in

Agent Systems. s.l., Proceedings of the Third

International Conference on Autonomous Agents,

Seattle, WA.

Faci, N., Guessoum, Z. and Marin, O., 2006. DimaX: a fault-

tolerant multi-agent platform. s.l., In Proceedings of the

2006 international workshop on Software engineering for

large-scale multi-agent systems, pp. 13- 20.

Fedoruk, A. and Deters, R., 2002. Improving fault-

tolerance by replicating agents. s.l., In Proc. AAMAS-

02, pp. 737-744, Bologna.

Helsinger, A., Thome, M. and Wright, T., 2004. Cougaar:

a scalable, distributed multi-agent architecture. s.l., In

Preccedings of International Conference on Systems,

Man and Cybernetics pp. 1910–1917.

Jennings, N. R., 2001. An agent based approach for

building complex software systems. s.l.,

Communication of the ACM, 44(4) pp. 35-41.

Johnson, J., 2009. Hypernetworks of Complex Systems;

Lecture Notes of the Institute for Computer Sciences,

Social Informatics and Telecommunications

Engineering. Complex Sciences, 4(pp. 364-375).

Jurasovic, K., Kusek, M. and Jezic, G., 2009. Multi-agent

service deployment in telecommunication networks.

s.l., In Agent and multi-agent systems: technologies

and applications, LCNS Springer Berlin / Heidelberg,

pp. 560 — 569,.

Khan, Z. et al., 2005. Decentralized architecture for fault

tolerant multi agent system. s.l., In Proc. of Autonomous

Decentralized Systems (ISADS), pp. 167-174..

Kumar, S. and Cohen, P., 2000. Towards fault-tolerant

multi-agent system architecture. s.l., In proceedings of

the fourth international conference on Autonomous

agents, pp459 – 466.

Kumar, S., Cohen, P. R. and Levesque, H. J., 2000. The

adaptive agent architecture: Achieving fault-tolerance

using persistent broker teams. s.l., In Proceedings of

the 4th International Conference on Multi-Agent

Systems, Boston, MA.

Marin, O., 2003. The DARX Framework: Adapting Fault

Tolerance For Agent Systems. s.l.:THÈSE DE

DOCTORAT DE L’UNIVERSITÉ DU HAVRE.

McKee, B. and Varghese, G., 2010. Exploring Carrier Agents

in Swarm-Array Computing. s.l., Scalable Computing:

Practice and Experience, Volume 11, pp. 53–62.

Mellouli, S., Moulin, B. and Mineau, G., 2004. Towards a

modelling methodology for fault-tolerant multi-agent

systems. s.l., In Informatica Journal 28, pp. 31–40.

Mitrović, D., Budimac, Z. and Vidaković, M., 2010.

Improving Fault-Tolerance of Distributed Multi-Agent

Systems with Mobile Network-Management Agents.

s.l., Proceedings of the International Multiconference

on Computer Science and Information Technology pp.

217–222.

Mladenović, S., 2011. Interoperability in hierarchical and

heterogeneous systems. s.l.:Doctoral thesis, Faculty of

Electrical Engineering, Mechanical Engineering and

Naval Architecture in Split.

Punithavathi, R. and Duraiswamy, K., 2010. A fault tolerant

mobile agent information retrieval system. s.l., In

Journal of computer science, Vol. 6, pp. 553 - 556.

Ravasz, E. and Barabási, A. L., 2003. Hierarchical

organization in complex networks. 67(2).

Rudowsky, I., 2004. Intelligent Agents. New York,

Proceedings of the Americas Conference on

Information Systems, New York.

Suguri, H., Kodama, E., Miyazaki, M. and Kaji, I., 2002.

Assuring Interoperability between Heterogeneous

Multi-Agent Systems with a Gateway Agent. s.l.,

Proceedings of the 7th IEEE International Symposium

on High Assurance Systems Engineering.

Sycara, K. P., 1998. Multiagent Systems. s.l., AI

Magazine, American Association for Artificial

Intelligence.

Tanenbaum, A. S. and Steen, M. v., 2002. Distributed

Systems: Principles and Paradigms. Upper Saddle

River, New Jersey 07458: Prentice Hall.

Torrel, J.-.C., Lattaud, C. and Heudin, J. -. C., 2007.

Complex Stellar Dynamics using a hierarchical

multi-agent mode. Erice, Italy, Modelling and

simulation in science, Proceedings of the 6th

International Workshop on Data Analysis in

Astronomy pp.307-312.

Varghese, B., McKee, G. and Alexandrov, V., 2010.

Handling single node failures using agents in

computer clusters. s.l., International Symposium on

Performance Evaluation of Computer and

Telecommunication Systems (SPECTS).

Wilensky, U., 1999. NetLogo Home Page. [Online]

Available at: http://ccl.northwestern.edu/netlogo/

[Accessed 06 May 2012].

Wilson, R. J., 1990. Graphs and heir use. s.l.:New

Mathematical Library.

Wooldridge, M., 1997. Agent based Software Engineering.

s.l., IEE Proceedings of Software Engineering 144, pp:

26-37.

Xu, P. and Deteis, R., 2005. Fault Management in Multi

Agent Systems. s.l., In Proceedings of Symposium on

Applications and the Internet.

Yang, Z. et al., 2006. A multi-agent framework for power

system automation. s.l., In International journal of

innovations in energy systems and power, Vol. 1, No. 1.

Zhang, Z., McCalley, J. D., Vishwanathan, V. and

Honavar, V., 2004. Multiagent system solutions for

distributed computing, communications, and data

integration needs in the power industry. s.l., In

Proceedings of the General Meeting of the IEEE

Power Engineering Society, IEEE Press, pp. 45 - 49.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

344
