Dynamic Agent Prioritisation with Penalties in Distributed Local Search

Amina Sambo-Magaji, In

es Arana and Hatem Ahriz

School of Computing Science and Digital Media, Robert Gordon University, Aberdeen, U.K.

Keywords:

Distributed Problems Solving, Local Search, Distributed Constraint Satisfaction, Heuristics.

Abstract:

Distributed Constraint Satisfaction Problems (DisCSPs) solving techniques solve problems which are dis-

tributed over a number of agents.The distribution of the problem is required due to privacy, security or cost

issues and, therefore centralised problem solving is inappropriate. Distributed local search is a framework that

solves large combinatorial and optimization problems. For large problems it is often faster than distributed

systematic search methods. However, local search techniques are unable to detect unsolvability and have the

propensity of getting stuck at local optima. Several strategies such as weights on constraints, penalties on

values and probability have been used to escape local optima. In this paper, we present an approach for escap-

ing local optima called Dynamic Agent Prioritisation and Penalties (DynAPP) which combines penalties on

variable values and dynamic variable prioritisation for the resolution of distributed constraint satisfaction prob-

lems. Empirical evaluation with instances of random, meeting scheduling and graph colouring problems have

shown that this approach solved more problems in less time at the phase transition when compared with some

state of the art algorithms. Further evaluation of the DynAPP approach on iteration-bounded optimisation

problems showed that DynAPP is competitive.

1 INTRODUCTION

Constraint Satisfaction Problems (CSPs) are prob-

lems which can be expressed by a set of variables, the

set of possible values each variable can be assigned

and a set of constraints that restrict the values vari-

ables can be assigned simultaneously (Dechter, 2003).

Distributed Constraint Satisfaction Problems (DisC-

SPs)(Yokoo et al., 1998) are CSPs where the problem

is dispersed over a number of agents which have to

cooperate to solve the problem while having limited

knowledge about the overall problem. It is often as-

sumed that each agent is responsible for the assign-

ment of one variable only and this will be also as-

sumed in this paper. A solution to a DisCSP is found

when an assignment of values to all the variables is

found which satisﬁes all existing constraints (Rossi

et al., 2006).

Systematic (backtracking) and local (iterative)

search are two types of approaches for solving DisC-

SPs. Systematic algorithms are complete but slow for

large problems when compared to local search, which

is incomplete. Local search algorithms start with an

initial random instantiation of values to all the vari-

ables and, in successive iterations, these values are

changed to repeatedly reduce the number of constraint

violations until a solution is found. Local search has

the propensity of getting stuck at local optima - a

point where the currently proposed assignment (that is

not a solution) cannot be further improved by chang-

ing the value of any single variable. A Quasi Lo-

cal Optima is a weaker form of local optima in lo-

cal search where an “unsatisﬁed” agent (with at least

one constraint violation) and all its neighbours have

no single improvement on their current assignment

(Zhang et al., 2002).

In this paper, we present Dynamic Agent Priori-

tisation and Penalties (DynAPP) a new approach for

escaping local optima which combines dynamic vari-

able prioritisation with penalties on variable values

for escaping local optima hence, avoiding search stag-

nation. An empirical evaluation with instances of ran-

dom, meeting scheduling and graph colouring prob-

lems showed that, at the phase transition, DynAPP

solved more problems in less time compared with

state of the art algorithms. Evaluation of DynAPP on

iteration-bounded optimisation problems showed that

DynAPP is competitive.

The remainder of this document is structured as

follows: section 2 describes related work; DynAPP

is explained in section 3; an empirical evaluation of

DynAPP is presented in section 4; ﬁnally, conclusions

are drawn section 5.

276

Sambo-Magaji A., Arana I. and Ahriz H..

Dynamic Agent Prioritisation with Penalties in Distributed Local Search.

DOI: 10.5220/0004259202760281

In Proceedings of the 5th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2013), pages 276-281

ISBN: 978-989-8565-38-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

2 RELATED WORK

A number of strategies have been implemented to

escape and avoid local optima in distributed search

which has resulted in several algorithms. The Dis-

tributed Breakout Algorithm (DBA)(Yokoo and Hi-

rayama, 1996) is a hill climbing algorithm that in-

creases the weight of violated constraints in order to

raise the importance of constraints that are violated

at local optima, thus forcing the search to focus on

their resolution. The original algorithm has been stud-

ied extensively and a number of improved versions

proposed. Multi-DB (Hirayama and Yokoo, 2002) is

an extension of DBA for Complex Local Problems -

i.e. DisCSPs with more than one variable per agent.

Multi-DB was then improved in (Eisenberg, 2003) by

increasing constraint weights only at global optima

with the new algorithm being called DisBO. (Basharu

et al., 2007b) proposed DisBO-wd an improvement

on DisBO where constraint weights are decayed over

time. Thus, at each step, the constraint weight is in-

creased if the constraint is violated and it is decayed if

the constraint is satisﬁed. SingleDBWD (Lee, 2010)

is a version of DisBO-wd for DisCSP with one vari-

able per agent.

Another DisCSP algorithm is Distributed Stochas-

tic algorithm (DSA)(Zhang et al., 2002), a random-

ized local search algorithm that uses probability, to

decide whether to maintain its current assignment or

to change its value at local optima. A hybrid of DSA

and DBA was proposed in Distributed Probabilistic

Protocol (DPP) (Smith and Mailler, 2010) where the

weights of constraints violated at local optima are in-

creased and agents ﬁnd better assignments by the use

of probability distributions.

The Stochastic Distributed Penalty Driven

Search(StochDisPeL) (Basharu et al., 2006) is an

iterative search algorithm for solving DisCSPs where

agents escape local optima by modifying the cost

landscape by imposing penalties on domain values.

Whenever an agent detects a deadlock (quasi-local

optima), StochDisPeL either imposes a temporary

penalty (with probability p) to perturb the solution or

increases the incremental penalty (with probability

1 − p) to learn about the bad value combination.

Incremental penalties are small and remain imposed

until they are reset while temporary penalties are

discarded immediately after they are used. The

penalties on values approach has been shown to

outperform the weights on constraints approach of

escaping local optima (Basharu et al., 2007a).

Asynchronous Weak Commitment Search

(AWCS) (Yokoo, 1995) is a complete asynchronous

backtracking algorithm that dynamically prioritises

agents. An agent searches for values in its domain

that satisfy all constraints with higher priority neigh-

bours, and from these values it selects the value that

minimises constraint violations with lower priority

neighbours. When an agent does not ﬁnd a consistent

assignment, the agent sends messages called no-good

to notify its neighbours and then increases its priority

by 1. The use of priority changes the importance of

satisfaction of an Agent.

3 DynAPP: DYNAMIC AGENT

PRIORITISATION AND

PENALTIES

We propose Dynamic Agent Prioritisation and Penal-

ties (DynAPP) [Algorithms 1-4] - a new algorithm

that combines two strategies: penalties on values and

agent prioritisation. At local optima, the priority of

inconsistent agents (whose current variable assign-

ment leads to constraint violations) is increased and,

at the same time, a diversiﬁcation of the search is

encouraged by penalising values which lead to con-

straint violations.

In DynAPP, variables are initialised with random

values and all agent priority values are set to their

agent ID. It should be noted that the lower the agent

ID, the higher the actual priority of the agent. An

agent then sends its initial variable assignment to its

neighbours. Each agent takes turns to update their

AgentView (their knowledge of the current variable

assignments) with the messages received and selects

a value for its variable that minimises the following

cost function:

c(d

) = viol(d

) + p(d

) i ∈ [1..|domain|]

where d

is the ith value in the domain, viol(d

) is

the number of constraints violated if d

is selected

and p(d

) is the incremental penalty imposed on d

When a temporary penalty is imposed, the penalty is

used to select another improving value and immedi-

ately reset. A QLO is detected when an AgentsView

does not change in two consecutive iterations. At

QLO, an agent (like StochDisPeL

) imposes a tem-

porary penalty (with probability p) or it increases the

incremental penalty (with probability 1 − p) and also

changes its priority value to the priority of the highest

priority neighbour with whom it shares a constraint

violation thus elevating itself among its neighbours.

The neighbour with the highest priority then reduces

Further details on how penalties are imposed can be

found in (Basharu et al., 2006).

DynamicAgentPrioritisationwithPenaltiesinDistributedLocalSearch

277

its priority by 1. This dynamically reorders the struc-

ture of its higher and lower level priority neighbour-

hood.

Algorithm 1: Dynamic Agent Prioritisation and

Penalties (DynAPP): Agent.

1 random initialisation

2 penaltyRequest ← null

3 priority ← agentID

4 repeat

5 while an agent is active do

6 accept messages and update AgentView and

penaltyRequest

7 if cost function is distorted then reset all incremental

penalties end if

8 if penaltyRequest ! = null then

9 processRequest()

10 else

11 if current value is consistent then

12 reset all incremental penalties

13 else

14 chooseValue()

15 end if

16 end if

17 sendMessage(penaltyRequest, priority)

18 end while

19 until termination condition

Algorithm 2: Procedure processRequest().

1 for all the messages received

2 if penaltyRequest ← IncreaseIncPenalty then

3 increase incremental penalty on current value

4 else

5 penaltyRequest ← ImposeTemporaryPenalty

6 impose temporary penalty on current value

7 end if

8 end for

9 select value minimising cost function

10 reset all Temporary penalties

When an incremental penalty is imposed (Al-

gorithm 3 line 10), an agent informs neighbours

with lower priority to also increase their incremen-

tal penalty on current values; similarly, when a tem-

porary penalty is imposed (Algorithm 3 line 7), an

agent requests further temporary penalty impositions

on current values to lower priority neighbours with

whom it shares a constraint violation. When there

is no penaltyRequest, all neighbours are informed of

the current value and priority (Algorithm 4 line1,11) .

Messages are processed by agents as described in Al-

gorithm 2, increasing or imposing an incremental or

temporary penalty respectively. An agent then selects

the value minimising the cost function and continues

this process until consistent values are found or the

maximum number of iterations is reached.

Algorithm 3: Procedure chooseValue().

1 if agentView(t) ! = agentView(t-1) then

2 select value minimising cost function

3 return

4 end if

5 r= random value in [0...1]

6 if r < p then

7 impose temporary penalty on current value

8 penaltyRequest ← ImposeTemporaryPenalty

9 else

10 increase incremental penalty on current value

11 penaltyRequest ← IncreaseIncPenalty

12 end if

13 for all neighbours violating constraint with currentVar

14 if priority[neighbour] > priority[currentVar]

15 priority[currentVar] = priority[neighbour]

16 end if

17 end for

18 priority[neighbour] = priority[neighbour]-1

19 select value minimising cost function

Algorithm 4: Procedure

sendMessage(penaltyRequest, priority).

1 send message(id, value, priority, null) to all neighbours

with > priority

2 if penaltyRequest = IncreaseIncPenalty then

3 send message(id, value, priority, penaltyRequest) to

all neighbours

4 with < priority

5 else if penaltyRequest = ImposeTemporaryPenalty then

6 send message(id, value, priority,

ImposeTemporaryPenalty) to

7 neighbours with < priority & violating constraints

with Self

8 send message(id, value, priorityValue, null) to

neighbours with <

9 priority not violating constraints with Self

10 else

11 send message(id, value, priority, null) to neighbours

with< priority

12 end if

For example, Figure 1 represents the simplistic

problem of allocating timeslots for 5 student vivas.

Representing this as a DisCSP, A, B, C, D, E are the

variables (students) and their domains (timeslots) D

are D

= {1,2}, D

={1,2}, D

={1,3}, D

={1,3},

E={2,3}. There are 5 constraints in the problem and

(i ∈ [A..E]) represents contraint violations and P

(i ∈ [A..E]) represents penalties imposed on each do-

main values. Initially, the priorities for {A,B,C,D,E}

are 4,2,3,1,5 respectively, a lower number implies

higher priority. Each agents keeps account of its

higher priority neighbour (HPN) and lower priority

neighbour (LPN). A has no LPN and {B} as HPN,

C has {B,D} as HPN and {E} as LPN and so on.

If for A=1, B=1, C=1, D=3, E=3, C detects a local

optimum, C changes its priority to 2 (i.e. that of B

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

278

Figure 1: A simple DisCSP.

which is the highest HPN it has a constraint violation

with. B reduces its priority to 3. C now has HPN

{D} and LPN {B,E}. C then imposes a penalty (as-

suming an incremental penalty which is 1) on value 1

and informs its new LPN {B,E} to also impose an in-

cremental penatly on their current assignment 1, 3 re-

spectively. Each agent then selects values with lower

violation C=3, D=1, E=2, A=2, B=2 which solves the

problem.

4 EMPIRICAL EVALUATION

Several problem instances of random problems, graph

colouring problems and meeting scheduling problems

of were used to compare DynAPP with StochDis-

pel and SingleDBWD. The percentage of problems

solved and the number of messages were recorded.

The ratio of number of iterations vs constraint vio-

lations were evaluated to further verify the algorithm

that solves the most problems early and was allowed

to run for a maximum 100n iterations, where n is

the number of variables,nodes or meetings. Statistical

signiﬁcance was calculated using the wilcoxon test.

Random Problems. We evaluated DynAPP with a

variety of random problems with binary constraints

and present results (see Figure 2) with the follow-

ing problem-sizes and densities {80-0.1, 90-0.09,100-

0.08, 110-0.07, 120-0.06, 130-0.062, 140-0.057, 150-

0.054, 160-0.051, 170-0.047, 180-0.045, 190-0.042,

200-0.04} with a tightness of 0.4 (phase transition)

and domain size of 10. Median values for 100 prob-

lems are presented which show that DynAPP solved

the most problems and had the least number of mes-

sages. From 140 variables, SingleDBWD solved less

than 40% of the problems. Note: When an algorithm

did not solve a problem, the messages “wasted” in that

problem were not counted towards the median num-

ber of messages.

When evaluating the algorithm by number of iter-

ations vs constraint violations (see Table 1), DynAPP

solved some problems as early as at the 50th cycle

while StochDisPeL and SingleDBWD had not solved

Table 1: Iterations vs. Violations: Random Problems.

StochDisPel DynAPP SingleDBWD

N. M % M % M %

Itrs viols sol viols sol viols sol

10 16 0 15 0 41 0

50 8 0 8 1 15 0

100 6 0 5 4 10 0

500 2 22 3 29 4 0

1000 1 38 2 49 4 2

1500 1 57 1 69 3 15

2000 1 63 1 84 2 29

any problem. At the 2000th iteration, with a median

constraint violation of 1 for both StochDisPeL and

DynAPP, DynAPP solved 84% of the problems as op-

posed to 63% by StochDisPeL. SingleDBWD solved

only 29% of the problems. The differences in perfor-

mance between DynAPP and the other algorithms is

statistically signiﬁcant.

Figure 2: Random Problems.

Graph Colouring. 3-Colour distributed graph

colouring problems were solved with n nodes, n ∈

{100, 110, 120, 130, 140, 150, 160, 170, 180, 190,

200} with degree between 4.3 ≤ degree ≤ 5.3. The

results, shown in Figure 3, are for the different graph

sizes at degree 4.9. DynAPP solved the most prob-

lems and had the least number of messages. DynAPP

solved 3 problems as early as at the 50th cycle while

StochDisPel solved 1 and SingleDBWD did not solve

any problem as seen in Table 2. At the 2000th itera-

tion, DynAPP solved 93% of the problems as opposed

DynamicAgentPrioritisationwithPenaltiesinDistributedLocalSearch

279

to 68% by StochDisPel. SingleDBWD solved only

49% of the problems. These performance differences

are statistically signiﬁcant.

Table 2: Iterations vs. Violations:Graph Colouring Prob-

lems.

StochDisPel DynAPP SingleDBWD

N. M % M % M %

Itrs viols sol viols sol viols sol

10 30 0 28 0 84 0

50 14 1 12 3 33 0

100 10 2 8 10 21 0

500 4 32 4 57 8 13

1000 4 50 2 70 6 32

1500 3 57 1 69 3 42

2000 2 68 1 93 6 49

Figure 3: Graph Colouring Problems.

Meeting Scheduling. We also conducted experi-

ments with meeting scheduling problems. A distance

chart between locations is randomly generated so that

the distance between two locations is assigned a value

between 0 and the maximum possible distance indi-

cating the travelling time required. We present results

for 60 ≤ meetings ≤ 140, with a maximum possible

distance (md) of 3 and constraint density (d) between

0.1 and 0.25. The results, presented in Figure 4, are

median messages and percentage of problems solved

over 100 runs, and show DynAPP’s performance was

better than that of the other two algorithms. These

performance differences are statistically signiﬁcant.

When comparing the number of iterations versus

Table 3: Iterations Vs Violations:Meeting Scheduling Prob-

lems.

StochDisPeL DynAPP SingleDBWD

N. M % M % M %

Itrs viols sol viols sol viols sol

10 3 6 3 12 45 0

50 2 55 1 72 3 12

100 1 84 1 86 1 40

500 1 91 0 100 1 75

1000 1 98 * * 1 82

1400 0 100 * * 1 87

constraint violations, Table 3 shows that at the ﬁrst 10

iterations, 12% of the problems were already solved

by DynAPP while StochDisPeL solved 6% and Sin-

gleDBWD didnot solve any problem. At 500 itera-

tions, DynAPP had solved all the problems, StochDis-

PeL was able to solve all after 1400 iterations and Sin-

gleDBWD solved only 87% of the problems. These

performance differences are statistically signiﬁcant.

Figure 4: Meeting Scheduling Problems.

5 SUMMARY AND

CONCLUSIONS

In this paper, we have presented Dynamic Agent Pri-

oritisation and Penalties (DynAPP), a distributed lo-

cal search algorithm for solving DisCSP that com-

bines two existing heuristics (penalties on values and

agent priority) for escaping local optima. DynAPP

signiﬁcantly improves the performance of distributed

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

280

local search. Penalties on values is a ﬁne-grained

heuristic that detects a set of nogood values often

found at local optima while prioritisation changes the

importance of agents.

Empirical results show that DynAPP used less

messages and solved more problems on a wide range

of random, graph colouring and meeting scheduling

problems. We also evaluated DynAPP, SingleDBWD

and StochDisPeL to determine the algorithm that op-

timizes the number of constraints violated given re-

stricted resources (maximum number of iterations).

DynAPP was found to perform best by solving the

most number of problems at given iteration inter-

vals. We intend to extend our cooperative approach

for solving DisCSP with complex local problems, i.e.

where agents are responsible for more than one vari-

able.

REFERENCES

Basharu, M., Arana, I., and Ahriz, H. (2006). Stochdispel:

exploiting randomisation in dispel. In Proceedings of

7th International Workshop on Distributed Constraint

Reasoning, DCR2006, pages 117–131.

Basharu, M., Arana, I., and Ahriz, H. (2007a). Escaping

local optima: constraint weights vs. value penalties.

In 27th SGAI International Conference on Artiﬁcial

Intelligence, AI-07, pages 51–64. Springer.

Basharu, M., Arana, I., and Ahriz, H. (2007b). Solving

coarse-grained discsps with multi-dispel and disbo-

wd. Intelligent Agent Technology, IEEE / WIC / ACM

International Conference on, 0:335–341.

Dechter, R. (2003). Constraint Processing. Morgan Kauf-

mann Publishers Inc., San Francisco, CA, USA.

Eisenberg, C. (2003). Distributed Constraint Satisfaction

For Coordinating And Integrating A Large-Scale, Het-

erogeneous Enterprise. Phd. thesis no. 2817, Swiss

Federal Institute of Technology (EPFL), Lausanne

(Switzerland).

Hirayama, K. and Yokoo, M. (2002). Local search for dis-

tributed sat with complex local problems. In Proceed-

ings of the ﬁrst international joint conference on Au-

tonomous agents and multiagent systems: part 3, AA-

MAS ’02, pages 1199–1206, New York, NY, USA.

ACM.

Lee, D. A. J. (2010). Hybrid algorithms for distributed con-

straint satisfaction. PhD thesis, School of Computing,

The Robert Gordon University, Aberdeen.

Rossi, F., Beek, P. v., and Walsh, T. (2006). Handbook

of Constraint Programming (Foundations of Artiﬁcial

Intelligence). Elsevier Science Inc., New York, NY,

USA.

Smith, M. and Mailler, R. (2010). Improving the efﬁciency

of the distributed stochastic algorithm. In Proceedings

of the 9th International Conference on Autonomous

Agents and Multiagent Systems: volume 1 - Volume

1, AAMAS ’10, pages 1417–1418, Richland, SC. In-

ternational Foundation for Autonomous Agents and

Multiagent Systems.

Yokoo, M. (1995). Asynchronous weak-commitment

search for solving distributed constraint satisfaction

problems. In Proceedings of the First International

Conference on Principles and Practice of Constraint

Programming, pages 88–102, London, UK. Springer-

Verlag.

Yokoo, M., Durfee, E. H., Ishida, T., and Kuwabara, K.

(1998). The distributed constraint satisfaction prob-

lem: Formalization and algorithms. IEEE Trans. on

Knowl. and Data Eng., 10:673–685.

Yokoo, M. and Hirayama, K. (1996). Distributed breakout

algorithm for solving distributed constraint satisfac-

tion problems. In Proceedings of ICMAS-96.

Zhang, W., Wang, G., and Wittenburg, L. . (2002). Dis-

tributed stochastic search for constraint satisfaction

and optimization: Parallelism, phase transitions and

performance. In Proceedings of AAAI Workshop on

Probabilistic Approaches in Search.

DynamicAgentPrioritisationwithPenaltiesinDistributedLocalSearch

281
