Handling Exceptions in Multi Agent Systems using Learning Agents

Mounira Bouzahzah

and Ramdane Maamri

LIRE Laboratory, Science and Technologie Institute, University Center of Mila, Mila, Algeria

LIRE Laboratory, Computer Science departement, Mentouri University, Constantine, Algeria

Keywords: Exception Handling, Learning Agents, Q Learning Algorithm, Reinforcement Learning, Hierarchical Plans.

Abstract: In this paper we address the problem of exception handling in multi agent systems and we propose an

approach based learning agents to provide fault tolerance in multi agent systems. In reality, agents systems

are used as a perfect solution to design recent applications that are characterized by being decentralized and

dispersed. These systems are subject of errors that occur during execution and that may cause system’s

failure; Exceptions are the main cause of the system’s errors. Researchers in fault tolerance field use

handling exceptions technique to provide error-prone systems. Through this work, we propose an approach

for handling exception using learning agents; this approach assures the most efficient handler for each

exception mainly in case of the existence of many handlers and allows the adaptation of decision according

to the environment changes. The learning agent is given the capacity to learn about new exceptions from the

extern.

1 INTRODUCTION

A critical challenge for fault tolerance researcher is

to provide robust multi agent systems in terms of

effectiveness and errors-prone.

Several approaches are proposed to deal with

exceptions in multi agent systems, some solutions

are based on the use of additional agents such as

(Hagg, 1996), (Anand and Robert, 2000) and

(Bouzahzah and Maamri, 2012).

(Platon, 2007) proposes the idea to give the

system’s agents the ability to handle the exception

by themselves. Other solutions use frameworks to

handle exceptions in multi agent systems such as

(Souchon and Christophe, 2002) and (Klein and

Dellarocas, 1999).

Our Approach assures exceptions handling in

multi agent systems using a learning agent that

applies a reinforcement learning algorithm (Rejeb,

2005) called the Q learning algorithm (Hoet and

Sabouret, 2009). this algorithm joins each

undesirable state of the agent (error detected) with

its efficient handler that is decided using agent

previous experiences.

This paper is organized as follows: the second

section reviews the limitation of some existing

approaches proposed to deal with the problem of

exceptions in multi agent systems. The next section

gives a detailed idea concerning agent’s

representation, error detection and the

communication protocol. The forth section defines

the learning’s concepts and describes how learning

agent is used to handle exceptions. The last section

concludes this paper and gives indications

concerning our future works.

2 EXISTING APPROACHES

AND THEIR LIMITATIONS

Several approaches are proposed to solve the

problem of errors in multi agent systems. Some

approaches are based on decentralized solutions,

which use of controlling agents to monitor the

system’s agents and to handle exceptions such as:

(Hagg, 1996) That describes an approach based

sentinels. Sentinels are guardian agents introduced in

the multi agent system application in order to

provide a fault tolerance layer for the system. These

guardian agents protect the system from failing in

undesirable states. They have the authority to react

to faults. (Anand and Robert, 2000) Introduce the

concept of the supervisor which has the role of a

handler for a group of system’s agents. He defines

two types of exceptions: the internal exceptions that

423

Bouzahzah M. and Maamri R..

Handling Exceptions in Multi Agent Systems using Learning Agents.

DOI: 10.5220/0004263304230426

In Proceedings of the 5th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2013), pages 423-426

ISBN: 978-989-8565-38-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

are treated by the agent itself and the external ones

handled by the supervisor which has a global access

to the agents that it supervises.

These approaches are costly in terms of

computation and communication and they cause

point of failure since controlling agents, also, are

subjects of fault. There are other approaches that

treat the exception using a centralized solution. In

this case, a framework is created to handle the

different exceptions that occur in the system:

The SaGE system described in (Souchon and

Christophe, 2002) and (Kchir, 2010) gives more

important to agents’ communications in terms in

request/ response. An exception is treated by

handlers that try to solve the problem locally, but if

it is not the case the request will be returned toward

the agent asking for it. Complex services that

invocate other agents to solve a request use a

concertation function. The approach proposed in

(Klein and Dellarocas, 1999) uses a separate system

called the exception handling service; this service is

viewed as a coordination doctor that knows about

the different cases to handle exception; exceptions,

In this case, are considered as illness.

These two approaches are effective in term of

decreasing the charges; but they are not able to

recognize if an exception has being handle in

previous times or not which cause a great waste of

time, and they cannot deal with new exceptions that

are not existing in their knowledge bases.

The next sections describe our new approach that

tries to use learning agents to have the opportunity to

handle exception according to thier experiences.

3 AGENT EXECUTION MODEL

AND ERROR DETECTION

This section allows the definition of the agent’s

model used by the approach proposed.

3.1 Agent’s Model and Plans

Representation. We use hierarchical plans

(Bradley and Edmund, 1999) to model the agent’s

activities. The hierarchical plans representation

allows specifying different combinations of

alternatives to accomplish a given goal with a

particular context. A hierarchical plan identifies

promising classes of long-term activities, and

incrementally refines these classes to eventually

converge in specific actions.

The aim of our work is to develop a simple and a

formal model that represents the agent’s activities

and allows error detection in order to solve the

problem of failure in multi-agent systems.

Definition:

A hierarchical plan P is defined in our model by a

tuple (Pre (P), In (P), Post (p), type (P), sub plans

(P), Order (P)):

 Pre (p): set of conditions and data needed for the

execution.

 In (p): set of conditions that must be verified

during the execution.

 Post (P): denote the set of conditions verified and

the data provided at the end of the execution.

 The type of plan P type (P) can be: a simple plan

(action), OR plan which is a hierarchical plan that is

accomplished by carrying out one of its sub plans,

AND plan is also a hierarchical plan that is

accomplished by carrying out its entire sub plans.

 Sub plans: is a set of plans. In case of simple

plans the set of sub plans is empty.

 Order (P) represents the order of execution of

plan P.

3.2 The Error Detection

To determine that an error occurs at one point of

time, we have to define to a new concept that is the

execution.

Definition:

An execution of a plan P is an instance of

decomposition and ordering of its sub plans'

executions. The set E (P) represents the possible

executions of a plan P.

An execution e of P is recursively defined as a

tuple <D (e), ts, tf, V (Pre (e), In (e), Post (e))>:

 ts, tf are positive, non zero real numbers

representing the start and finish times of execution e,

and t

< t

 D (e) is the set of sub plans executions

representing the decomposition of plan P under this

execution e.

 V (Pre (e), In (e), Post (e)): a Boolean function

that verify the previous conditions. It returns true if

the execution succeeds and returns false if an error

occurs.

The agent has to compare the expected conditions

that appear in his hierarchical plan with the real

conditions that occur at the moment of execution; if

all the conditions are verified then the action is

executed with success otherwise an exception is

detected.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

424

3.3 The Communication Protocol

The agent has to communicate the learning agent

and the other system’s agents using messages. The

general model of messages in our approach has the

following structure:

M=<Send, Recept, C>

 M represents the message or the communication

protocol.

 Send represents the code that identifies the agent

who sends the message and who is searching for a

handler for the detected exception.

 Recept identifies the learning agent.

 C represents the content of the message that may

design an exception.

The content of the message, in our work, represents

the current state of the agent that may be the

expected value of conditions and the resulting

conditions.

C=< (Pre (P), In (P), Post (p)), (Pre (e), In (e), Post

(e))>

4 LEARNING AGENT AND

EXCEPTION HANDLING

In reality, two types of learning can be used in multi-

agent systems:

 Individual learning occurs independently of other

agents. It is taken into consideration only when all

the elements of the learning process are executed by

the same agent and requires no interaction with other

agents.

 Multi-agent learning requires the presence of

other agents and their interaction (Watkins,1989).

We consider the first type of learning in our model

since we choose to have a centralized solution in

order to decrease the charges. So, the learning agent

is the one concerned by solving the exception

signaled.

4.1 The Learning Models

The learning models are classified into two main

categories:

 Unconscious learning or reinforcement learning

that occurs when the agent does not know what he is

learning. It is a mechanism that operates

automatically and continuously.

 The conscious learning takes place when the

agents are able to reflect on their actions and their

consequences (Brenner, 2005).

We are interesting to have a learning agent that can

learn automatically and continuously, thus, we

choose reinforcement learning model and we apply

the Q learning algorithm known by being simple and

gives clear results.

4.2 Q Learning Algorithm

and Exception

Handling. Q-learning is a reinforcement learning

technique that works by learning an action-value

function that gives the expected utility of taking a

given action in a given state and following a fixed

policy thereafter. One of the strengths of Q-learning

is that it is able to compare the expected utility of

the available actions without requiring a model of

the environment (Qlearning, Wikipedia).

Concerning our approach the learning agent uses

the Q learning algorithm in order to join the couple

(exception, handler) and a value Q (exception,

handler) that represents the reward or the

effectiveness of the handler to solve this exception.

So, this algorithm is based on the use of a function

whose value is:

Q: S x A R

 S is the set of the agent s states in other words it

represents the set of errors or exception detected.

When the learning agent receives the message

concerning the exception it chooses the handlers that

can be associated within this exception.

 A represents the set of actions or handlers

proposed to solve errors.

 Q(s, a) this value represents the reward when

using the handler a to solve the exception s.

The agent can move from exception state to a

normal one. Each state provides the agent a reward

(a real or natural number). The goal of the agent is to

maximize the reward. It does this by learning which

action is optimal for each state. So, the best handler

for an exception is the one whose reward is the

maximum.

Before learning has started, the learning agent

is initialized by some handlers and the function Q

returns a fixed value, chosen by the designer. Then,

each time the agent is given a reward (the error is

solved) new values are calculated for each

combination of a state s from S, and action a from A.

The core of the algorithm is a simple value

iteration update. It assumes the old value and makes

a correction based on the new information. The

HandlingExceptionsinMultiAgentSystemsusingLearningAgents

425

update of t h e reward value is done according to the

following formula:



s, a



←



1∝ ts, a





s, a





∝t



s, a



r  γmaxQ









The goal of the Q learning algorithm is to build the

reward function Q for each couple (s,a) according to

the result given after the use of the handler a. αt has

a value in [0,1] it refers to the learning rate.

 is the actuel lisation factor, it allows the learning

agent to determinr the best reward. If the agent

needs immediate rewards so the actual lisation factor

must be near 0.

4.3 The Learning Agent’s Memory

The learning agent has to remember the historical

value of rewards for each handler in order to choose

the best handler in case where an exception appears

for the second time.

As we show in the previous paragraphs the Q

learning algorithm builds its decisions depending on

its perception of the system. But in our approach we

need a decision that depends also on the agent’s

historical experiences. As a solution we propose to

use the learning agent memory that includes the past

decisions about handlers. According to this idea the

agent will be able to recognize an action that has

appears in the past and choose its best handler.

In case where the exception has reward =0 using all

the available handlers. We give the learning agent

the authority to ask for new solutions from the

extern designer. The knowledge base will be

extended and the new added solution will be treated

as the initial ones.

5 CONCLUSIONS AND FUTURE

WORK

Throughout this paper, we have proposed an

effective approach for fault tolerance in multi-agent

systems based on learning agent. We use a formal

model for agent activities representation called

hierarchical plans. It allows the detection of errors in

a simple and automatic way. We choose Q learning

algorithm to handle exceptions. Learning agent has

the opportunity to handle exceptions according to his

experiences; to choose the most effective handler in

case where may handlers exist, and we give the

agent the ability to learn from the extern in case of

new exceptions.

Finally, we are interested in validating this work

through a simulation that can provide real results on

the effectiveness of this approach and compare it

with other approaches.

REFERENCES

Anand T. and Robert M., 2000. Exception Handling in

Agent Oriented Systems, Springer-Verlag,

Bouzahzah M. And Maamri R., 2012. A Proposed

Architecture for a Fault Tolerant Multi Agents System

Using Extern Agents, 6th International Conference,

K.E.S.-A.M.S.T.A, proceedings Springer LNAI 7327pp

282-289,

Bradley J. C., Edmund H. D., 1999. Identifying and

Resolving Conflicts among Agents with Hierarchical

Plans, American Association for Artificial Intelligence.

Brenner T., 2005. Handbook of Computational Economics

Vol: 2. Agent-Based Computational Economics,

(Handbooks in Economics Series),

Hagg S., 1996. A Sentinel Approach to Fault Handling in

Multi-Agent Systems. In: Proceedings of the Second

Australian Workshop on Distributed AI, Cairns,

Australia.

Hoet S., and Sabouret N., 2009. Apprentissage par

Reforcement d’acte de Communication Dans un

Contexte Multi agents”, RJCIA.

Kchir S., 2010. Gestion des Exceptions dans un Système

Multi Agents avec Replication, Master2, Laboratoire

d’Informatique, de Robotique et de Micro-

electronique, Montpellier.

Klein M., Dellarocas C., 1999. Exception Handling in

Agent Systems, Antonymous agents, USA.

REJEB L., 2005. Simulation Multi agents des Modèles

Economiques Vers des Systèmes Multi Agent

Adaptatif’’, Reims Champagne-Ardennes University.

Platon E., 2007. Modeling Exception Management in

Multi Agent Systems, Doctorate thesis, department of

informatics, the graduate university for advanced

studies.

Souchon F., Christophe D., Christelle U., Sylvain V.,and

Jacques F., 2002. SaGE: une proposition pour la

gestion des exceptions dans les system multi agents,

Internal repport-LIRMM-02205,

Q-learning –Wikipedia, the free encyclopaedia:

http://en.wikipedia.org/wiki/Q-learning

Watkins C. J. C. H., 1989. Learning from delayed

rewards, PhD thesis, Cambridge University,

Cambridge, United Kingdom.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

426
