A Video Copy Detection System based on Human Visual System

Yu Bai

, Li Zhuo

, YingDi Zhao

and Xiaoqin Song

Singal & Information Processing Laboratory, Beijing University of Technology, Beijing, China

College of Electronic and Information Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing, China

Keywords: Itti Attention Model, K Neighbor Search, Near-duplicate Detection, Surfgram.

Abstract: The technology of near-duplicate video detection is currently a research hot spot in the field of multimedia

information processing. It has great value in the areas such as large scale video information indexing and

and robustness, in the meanwhile improving the processing speed of video copy detection. In this respect, a

HVS(Human Visual System)-based video copy detection system is proposed in this paper.This system

utilizes the visual attention model to extract the region of interest(ROI) in keyframes, which extracts the

Surfgram feature only from the information in ROI, rather than all of the information in the keyframe, thus

effectively reducing the amount of the data to process. The experimental results have shown that the

proposed algorithm can effectively improve the speed of detection and perform good robustness against

brightness changes, contrast changes, frame drops and Gaussian noise.

1 INTRODUCTION

With the rapid development of multimedia

technology,videos are widely used in business,

entertainment and many other fields.The

management of these data becomes a challenging

task(Wang, 2010).Online users can download,

upload and modify the videos in convenience,which

also broughts many problems.Such as illegal

modification of the online video(near duplicate

video).To protect intellectual property rights, it’s

important to detect these near duplicate videos.

Nowadays most of the domestic and international

researches focus on finding a variety of complex

feature extraction method to improve the detecion

accuracy. However, in practical, the more important

problem is how to significantly improve the speed of

the detection system while maintaining high

detection accuracy and robustness at the same time.

Currently the mainstream technology of video

copy detection is the content-based video copy

detection methods. Content-based video copy

detection technology can be grouped into two

categories: global feature-based methods and local

feature-based methods.

Global feature-based methods extract frame-level

signatures to model the information distributed in

spatial and color dimensions. The keyframe is

divided into 64 regions of the same size and for each

region Y component is further extracted as the video

features (Wu, 2006). But this method is unable to

resist strong size transformation attack. The OM

(Ordinal Measures) feature is applied to image copy

detection (Kim, 2003). However, though it is robust

against global changes, local changes will disrupt

the relative relationship between the image blocks,

which makes this method fail to work.

In comparison to the global feature-based

methods, local feature-based method has stronger

robustness. However, the time consumption and

computational complexity is unacceptably high for

the practical application. For example, Douze

presented a video copy detection system based on

local features (Douze, 2008), in which the local

descriptors are over 400 in each frame. In a 4-minute

video with fast changing scenes, the keyframe may

be more than 400 and the local descriptors may be

more than 160K, which would result in high

computational cost on keyframes matching and poor

real-time performance.

In order to improve detection efficiency,we

propose a novel system based on human visual in

this paper.Unlike existing video copy detection

systems, the proposed method only deals with

ROI(region of interest) in keyframes and then

extracts features to determine video similarity,

which can effectively reduce the complexity of the

792

Bai Y., Zhuo L., Zhao Y. and Song X..

A Video Copy Detection System based on Human Visual System.

DOI: 10.5220/0004292107920795

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 792-795

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

algorithm while ensuring the robustness.

2 VIDEO COPY DETECTION

SYSTEM BASED ON HVS

The architecture of our approach contains two

processes: feature extraction and similarity

comparison. First keyframes are extracted, and then

visual attention model is employed to extract ROI,

followed by a Surfgram feature extraction to

represent the video content which can effectively

reduce the amount of data to process. In the video

similarity comparison, this paper uses BID+ (bit-

difference) approximate nearest neighbor search

algorithm to improve the matching speed. The

following sections will describe the preprocessing

steps in detail.

2.1 Video Feature Extraction

As the information of video data is very large, it is

critical to decide which video features should be

used to represent the video content. In order to

improve the speed of the copy detection system,

keyframes are used to represent video content.

2.1.1 Keyframe Extraction

In order to reduce data redundancy, we first extract

the keyframes and employ the method of abrupt shot

change detection (Hou, 2009). Then we extract

keyframes between the consecutive abrupt shots

uniformly, specifically, a keyframe is extracted from

about every 30 to 100 frames in our experiments.

2.1.2 the ROI Extraction

It has been found that the HVS has some certain

selectivity. This selectivity in HVS indicates the eye

movements and form the focus of attention or

ROI.VAM (Visual Attention Model) is based on the

HVS. Therefore, the visual attention model can be

used to extract ROI and reduce the amount of

information to be processed.The most classic VAM

is Itti Model proposed by Laurent Itti (Itti, 1998). Itti

model extracted from the input image with many

features, such as intensity, color, direction, forming

conspicuity maps of features. The saliency map is a

linear combination of three conspicuity maps.

Conspicuity maps are based on the center-surround

differences.For this reason, the region beyond a

certain threshold T in saliency map is regarded as

the ROI. We use T=0.6 as the threshold.After the

extraction of keyframes,ROI further reduces the

amount of data and improve the processing speed.

2.1.3 Surfgram Feature Extraction

In this paper, we propose Surfgram feature to

represent the content of ROI because the feature is

fast and robust. SURF(Speeded Up Robust Features)

is several times faster than SIFT and can be robust

against brightness changes, contrast changes,

Gaussian noise (Bay, 2008).Therefore, we extract

SURF from ROI and generate a frame-level

histogram of visual codewords based on SURF to

construct the Surfgram feature.

As there are a lot of feature points in an image,

SURF features are of large amount of data.

Therefore, Surfgram feature is adopted only to

represent the content of ROI. The extraction steps

are as follows:

 ExtractingSURFfeaturesfromROI.

 Using the K-means clustering approach to

partition SURF features into 200 clusters.

 Computing the histogram of the features. The

number of the SURF features in class 1 to class n

is counted to obtain the histogram of SURF

features, which is the Surfgram feature.

2.2 Surfgram Features Matching and

Scoring

When comparing the similarity of Surfgrams from

the query video and reference video, if the similarity

between them is greater than a certain threshold,

then the query video is identified as a near-duplicate

of the reference video. In order to speed up feature

comparison, we use the BID+ for Approximate

Nearest Neighbor to index all features (Cui,

2005).We define the similarity measure score as

follows:

score











(1)

where q



is the matched query frame, n is the total

number of matched query frames, Q



is the total

number of keyframs in reference video, D



is the

distance between the query frame and matched

frame in the reference video.

3 EXPERIMENTAL RESULTS

To evaluate the performance of the proposed

AVideoCopyDetectionSystembasedonHumanVisualSystem

793

algorithm, a database of 50 videos (collected from

TRECVID2011) is created. Videos in the database

were attacked to generate query videos.Table 1

shows the attacks and their parameter values, where

U is the average luminance value and G(0,u) is

Gaussian function.

Table 1: Attack parameter values used in this paper.

Attacks Effect

Parameter

values

Brightness

Output=Input+A U

A=0.35

Contrast

Output=U+(Input-

U)(1+P)

P=0.7

Frame drops(f)

f% of the frames are

randomly dropped

f=30

Noise Output=Input+G(0,u) u=20

PIP position:top left scale:16.6%

Ratio compression scale:20%

Table 2 shows the experimental results.Our

experimental results have shown that the proposed

algorithm performs good robustness against

brightness changes, contrast changes, frame drops

and Gaussian noise. Fig.1(a) is one of the keyframes

in query video and Fig1.(b) is the result. Although

they have slightly different contents,they are both

extracted from the same video.

(a) (b)

Figure 1: Example of query clip and result. (a) original

image.(b)Contrast attack.(c)ROI of (a).(d) ROI of (b).

Table 2: Results of the proposed algorithm.

Attacks

Accuracy rate(the number of correct/total

number)

Brightness 76%

Contrast 78%

Frame drops 82%

Noise 92%

PIP 50%

Ratio 52%

The reason of the good performance is mainly

resulted from the SURF feature which is robust

against brightness changes, contrast changes, frame

drops and Gaussian noise.

The attacks for which our method shows less

ideal performance are PIP and Ratio.Fig.2(b) and

Fig.2(d) shows that ROI of parts of the keyframes

are very different.And this increases the differences

of Surfgram features.

Feature extraction is the most time-consuming

computation part.The time cost of feature extraction

depends not only on the single feature extraction

time, but also depends on the number of the features.

SURF feature is faster than SIFT (Apostol, 2010). In

addition, we use Itti model to extract ROI, which

reduce the number of features. The number of

features in the first video of the database with Itti

Model is 7261. While the total number of features is

40092 without Itti Model (Apostol, 2010). The

average time cost to extract Surfgram features from

keyframe in this paper is 554.3ms, while the average

time (Apostol, 2010) is 1367.1ms, which is as 2.46

times the duration as our proposed

algorithm.Therefore, the proposed algorithm

performs much better in the aspect of time cost

compared to the algorithm (Apostol, 2010).

(a) (b)

Figure 2: Comparison of ROI. (a) original image.(b)ROI

of the original image.(c)Ratio transform of the original

image.(d)ROI of the ratio image.

4 CONCLUSIONS

In this paper, we propose a video copy detection

algorithm based on HVS. Experimental results have

shown that the proposed algorithm is very fast and

robust against brightness, contrast change, frame

drops and Gaussian noise attack, but sensitive to PIP

and ratio attack. In the future work, we will focus on

the robustness of Itti Model and Surfgram features.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

794

ACKNOWLEDGEMENTS

The work in this paper is supported by Program for

New Century Excellent Talents in University

(No.NCET-11-0892), Doctoral Fund of the Ministry

of Education, the National Natural Science

Foundation of China (No.61003289,No.61100212) ,

the Natural Science Foundation of Beijing (No.

4102008), the Excellent Science Program for the

Returned Overseas Chinese Scholars of Ministry of

Human Resources and Social Security of China,

Scientific Research Foundation for the Returned

Overseas Chinese Scholars of MOE, Youth Top-

notch Talent Training Program of Beijing Municipal

University, the Fundamental Research Funds for the

Central Universities (No.NS2012045).

REFERENCES

Meng Wang., 2009. Unified Video Annotation Via Multi-

Graph Learning. IEEE Transactions on Circuits and

Systems for Video Technology.

Wu Ming-Ni., Lin Chia-Chen., Chang Chin-Chen., 2006.

A Robust Content based Copy Detection Scheem.

Fundamenta Informaticae.

Kim, C., 2003. Content-based Image Copy Detection.

Singal Processing: Image Communication.

M, Douze., A, Gaidon., H, Jegon., M, Marszatke., and C,

Schmid., 2008. Inria-Learrs Video copy detection

system. In TRECVID.

Y, Hou., H, Z, Hou., 2009. Shot segmentation method

based on intensity histogram frame difference.

Computer Engineering and Applications.

L, Itti., C, Koch., Emst Niebur., 1998. A Model of

Saliency-Based Visual Attention for Rapid

Scene.Analysis. IEEE transactions on pattern analysis

and machine intelligence.

Bay, H., Tuytelaars, T., Van Gool, L., 2008. Speeded-Up

Robust Features(SURF). Computer Vision and Image

Understanding.

B, Cui et al., 2005. Exploring bit difference for

approximate KNN search in high dimensional

databases. Proceedings of the 16th Australasian

database conference.

N, Apostol., H, Matthew., S, John R., 2010. Design and

evaluation of an effective and efficient video copy

detection system. 2010 IEEE International Conference

on Multimedia and Expo.

AVideoCopyDetectionSystembasedonHumanVisualSystem

795
