Vision-based Hand Pose Estimation

A Mixed Bottom-up and Top-down Approach

∗

Davide Periquito, Jacinto C. Nascimento, Alexandre Bernardino and Jo˜ao Sequeira

ISR - Instituto Superior T´ecnico, Universidade T´ecnica de Lisboa, Av. Rovisco Pais, Lisbon, Portugal

Keywords:

Pose Estimation, Geometric Moments, Hammoude Metric, Simulation.

Abstract:

Tracking a human hand position and orientation in image sequences is nowadays possible with local search

methods, given that a good initialization is provided and that the hand pose and appearance have small

frame-to-frame changes. However, if the target moves too quickly or disappears from the ﬁeld of view, re-

initialization of the tracker is necessary. Fully automatic initialization is a very challenging problem due to

multiple factors, including the difﬁculty in identifying landmarks on individual ﬁngers and reconstructing the

hand pose from their position. In this paper, we propose an appearance based approach to generate candidates

for hand postures given a single image. The method is based on matching hand silhouettes to a previously

trained database, therefore circumventing the need for explicit geometric pose reconstruction. A dense sam-

pling of the hand appearance space is obtained through a simulation environment and the corresponding sil-

houettes stored in a database. In run time, the acquired silhouettes are efﬁciently retrieved from the database

using a mixture of bottom-up and top-down processes. We assess the performance of our approach in a series

of simulations, evaluating the inﬂuence of the bottom-up and top-down processes in terms of estimation error

and computation time, and show promising results obtained with real sequences.

1 INTRODUCTION

Human Computer Interaction (HCI) is an active re-

search topic in computer vision community, where

the main goal is to create an easier interface by tak-

ing direct advantage of natural human skills. To man-

age this kind of interface it is necessary to achieve

precise motion measurement of various human parts

(Erol et al., 2005). In this context the hand can be

seen as an interaction device with large complexity,

over 27 Degrees of Freedom (DOF), forming a very

effective and general purpose interactive tool for HCI

(Rehg and Kanade, 1994). Hand interaction enables a

large number of advanced applications, such as sur-

gical simulations, robot interaction, virtual or aug-

mented environment interactions, among others.

To be useful in practice, HCI should embrace

a tracking algorithm capable of achieving: (i) self-

starting; (ii) accuracy for long sequences; (iii) in-

dependence regarding the activity; (iv) robustness to

drift and occlusions; (vi) computational efﬁciency;

and (vii) ability to operate with mobile cameras.

∗

This work was supported by the FCT projects

[PEst-OE/EEI/LA0009/2011] and VISTA [PTDC/EIAEIA/

105062/2008].

Background subtraction techniques are not recom-

mended because tracking may have to accomplished

in environments with moving background (Ramanan

et al., 2007a) (Zhiguo and Yan, 2010). The focus of

this paper is related with the automatic initialization

of the tracker in one of the most challenging problems

in HCI: human hand detection and tracking.

A number of 3D object trackers rely on Particle

Filters (PF), representing a distribution of weighted

hypotheses of object pose (Brandao et al., 2011).

However particle ﬁlters still suffer from initializa-

tion problems and recovering after occlusions. Even

small deviations from the assumed motion models can

cause tracking failure. When a particle ﬁlter starts

or is to be reinitialized, particles are often distributed

randomly in a high dimensional search space. Even

with a great number of particles, it turns out to be dif-

ﬁcult and time consuming to initialize the tracker.

In this paper, we present a method to address this

problem by jointly using bottom-up and top-down

schemes. The algorithm initially builds a training set

with known postures. In run time the observed im-

age is matched against the trained set of hypotheses

using two matching metrics with different computa-

tional costs and precisions: ﬁrst, the geometric mo-

ments (bottom-up) are able to perform a fast ﬁltering

566

Periquito D., Nascimento J., Bernardino A. and Sequeira J..

Vision-based Hand Pose Estimation - A Mixed Bottom-up and Top-down Approach.

DOI: 10.5220/0004295805660573

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 566-573

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

on the training set. Second, the Hammoude metric

(top-down) allows to obtain a more reliable posture

hypothesis. With this strategy, a very quick bottom-

up approach ﬁlters out most of the pose candidates

so that the more computational intensive top-down

process only has to evaluate a reduced number of hy-

potheses.

The idea of combining bottom-up and top-down

approaches has been successfully exploited in other

applications. For instance, in (Ramanan et al., 2007a),

two different methods are used to build models for

person detection. First a bottom-up approach searches

for body part candidates in the image, which are then

clustered to ﬁnd and identify assemblies of parts that

might be people. Simultaneously, a top-down ap-

proach is used to ﬁnd people by projecting the pre-

vious assembled parts in the image plane.

We believe that the combination of the bottom-

up and top-down processes above mentioned, is the

key for the efﬁciency and reliability of detection and

tracking algorithms. In one hand, the amount of im-

age information to process is huge and thus requires

top-down constraints given by models. However,

matching the models to the image must be guided by

bottom-up processes for efﬁciency. We evaluate our

method and study the trade-off between the bottom-

up and top-down processes in a series of simulations.

Our paper is organized as follows. Section 2 de-

scribes related work. In Section 3 we describe the

method’s architecture, which is divided in to the fol-

lowing major components: (i) the machine learn-

ing part (ofﬂine) and (ii) the matching strategy be-

tween the observed image and the generated hypothe-

ses (online). In Section 3 some experiments concern-

ing realistic scenarios is presented. Finally, Section

4 presents the conclusions of the paper and provides

directions for further research work.

2 RELATED WORK

A large number of works have been made avail-

able concerning human motion analysis, although

with different focus and classiﬁcation methods. In

(Gavrila, 1999) the division is made into 2D and 3D

approaches in which the 2D approaches are further

sub-branched in methods that take advantageof an ex-

plicit use of shape models, and others that do not use

any kind of model (i. e. Image Descriptors). In recent

works (e.g. (Borenstein and Ullman, 2008), (Bran-

dao et al., 2011)), various directions in research have

emerged, such as combining top-down and bottom-up

models, PF algorithms for tracking human body parts,

and model-free approaches. Many of these newtrends

cannot be placed within the classiﬁcations mentioned

above. So, a more generic approach is proposed in

(Poppe, 2007), where the main division is made ac-

cording to model-based (or generative) and model-

free (or discriminative) approaches. The estimation

process step consists is computing the pose parame-

ters that minimizes the error between observation and

the projection of the human body model. Two classes

of estimators are possible to identify: top-down and

bottom-up (Poppe, 2007). Top-down approach con-

sists in matching a projection of the human body

model with the observed image, while in Bottom-up

approaches individual body parts are found and then

assembled into a human body image. In more recent

works (Brandao et al., 2011), (Ramanan et al., 2007b)

these two are combined for better performance

2.1 Bottom-up Estimation

Bottom-up approaches are typically used to ﬁnd body

parts and then used to assemble them into a full hu-

man body; these parts are normally described as 2D

templates. The main problems associated with the

bottom-up process are normally the quantity of false

positives marked as limb-like regions in an image.

Another drawback is the need of part detectors for

most body parts since missing information is likely

to result in less accurate pose estimation.

In (Micilotta et al., 2006), the ﬁrst step is to ﬁnd a

person in the image, so body parts are learned by the

trackers and a possible assembly is found by applying

RANdom SAmple Consensus (RANSAC). Heuristics

are used to remove unlikely poses, and a prior pose

determines the likelihood function of the assembly.

2.2 Top-down Estimation

Top-down approaches match a projection of the hu-

man body with the image observation. In order to

achieve fast solutions, a local search is performed

in the neighbourhood of an initial pose estimation

(Gavrila, 1999). According to (Gavrila and Davis,

1996) a hierarchical classiﬁcation is possible in order

to achieve better performance for initial positioning.

This way, they ﬁrst build the torso and head and then

the rest of the limbs of the model.

The main constraint presented in top-down ap-

proaches is the initialization in the ﬁrst frame which

leads to a manually starting requirement. Other is-

sues are the computational effort of rendering the hu-

man body model and the calculation of the distance

between the rendered model and the image observa-

tion.

Top-downapproaches also present some problems

Vision-basedHandPoseEstimation-AMixedBottom-upandTop-downApproach

567

with (self) occlusions. Therefore, the errors are prop-

agated through body parts. An inaccurate estimation

for the head part, for example, will cause big orienta-

tion errors of lower body parts. To cope with some of

these issues other techniques were used (i.e. by apply-

ing gradient descent on the cost function (Delamarre

and Faugeras, 2001)).

2.3 Combining Bottom-up and

Top-down Estimation

By combining pure top-down and bottom-up ap-

proaches, the drawbacks of both can be targeted. First

the top-down initialization can be addressed by us-

ing bottom-up methods to provide ﬁrst frame infor-

mation. The computational cost to render the hu-

man body model can be drastically reduced when us-

ing bottom-up approaches to generate a small num-

ber of hypotheses, to be then tested with the top-

down models. Second, bottom-up false positives can

be removed by projecting them into the image, us-

ing top-downapproaches to reconﬁrm if the produced

hypothesis is correct. Top-down approaches may be

implemented in order to work as a part detector for

bottom-up estimation.

This integration is made in (Kyrki, 2005) by using

the correspondence between interest points (texture)

in the set and tracking with optical ﬂow estimation

along contours, using the Kalman Filter (KF). In (Ra-

manan et al., 2007b) both approaches are also inte-

grated, in order to address the problem of tracking

multiple limbs of the human body. In the bottom-

up part the detection is made by a rectangular con-

tour template, which identiﬁes possible body limb hy-

potheses, whereas the top-down approach looks for

possibilities to assemble the human body model with

the detected rectangles. The model is built taking

into consideration the constrain that limbs keep cer-

tain poses between each other.

In (Okuma et al., 2004) a mixed approach is also

applied for 2D tracking. The bottom-up layer is

achieved by implementing the Adaboost Algorithm

for object detection (in this case hockey players) and

to deal with new instances in the image. On the Top-

down method a ”mixture particle ﬁlter” (MPF) is ap-

plied in order to track multiple players. Therefore the

Adaboost is trained to detect players and combined

with the MPF to construct their distribution.

3 ALGORITHM

In this paper we combine bottom-up and top-down

processes for the detection of speciﬁc gestures and

pose estimation of a human hand. The top-down pro-

cess in encoded in templates of the hand silhouette

for a dense discretization of the pose space. Because

exhaustive template matching of all possible pose hy-

potheses is very expensive, the bottom-up process

performs a fast moment-based ﬁltering of color blobs

in the image that are likely to contain hands on cer-

tain poses. The candidates are then ranked by quality

so that the top-down process can concentrate its re-

sources on the most promising ones. The steps of the

approach are next described in detail.

3.1 General Approach

This section describes the procedure of the proposed

framework. The creation of the top-down models

comprise a training stage with the following steps:

• Computation of the quaternions necessary to gen-

erate training hand pose hypotheses images (see

Fig. 1, most-left column). A total of 23900 im-

ages are used.

• Hand pose hypothesis are then generated in the

OpenRAVE simulator (Diankov, 2008) with an

existing humanoid 3D model. A total of 23500

images are used for training, (Fig. 1, top of the

2nd column).

• The images are segmented (i.e. the silhouettes or

contours are obtained) and corrected in perspec-

tive to simulate frontal views (Fig. 1, top of the

3rd column).

• The geometric moments of the contours are com-

puted.

• The silhouettes are stored in a database, together

with both the binary masks and the geometric mo-

ments. Also the ground truth poses (i.e quater-

nions) are stored.

The previous items are fulﬁlled in ofﬂine fashion.

It follows the online test step, which performs the

matching between the acquired hand silhouette (i.e

test image) and the pre-trained database of canonical

pose hypotheses described above. In run-time, each

acquired image silhouette is also pre-processed as in

the training stage (i.e. through the color segmenta-

tion process, perspective correction and binarization).

A total of 400 images are used for testing (bottom

of the Fig. 1). Then, the geometric moments of the

newly acquired mask are used to rank the training set

in descending order of match quality. We ﬁlter the

top 1000 hypotheses candidates (Fig. 1, 4th column)

that is the output of the bottom-up step of the frame-

work. It follows the top-down procedure which al-

lows a more precise match using Hammoude metric

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

568

Figure 1: Algorithm architecture: an overview (see text in Section 3.1).

(Nascimento and Marques, 2008) also known as the

Jaccard distance (Hammoude, 1988). The top-down

is applied over the top ranked candidates in order to

provide for a ﬁnal decision (Fig. 1, most-right col-

umn).

3.2 Training Images Generation

To generate hypotheses on OpenRAVE we place a vir-

tual camera on the simulated model looking at the 3D

hand model. By moving the camera around at a con-

stant distance to the hand we create a virtual sphere

path (see Fig. 2 for an illustration). To represent the

orientation of the camera we use a quaternion repre-

sentation. Uniform samples (see Fig. 3) on the ori-

entation sphere are generated by drawing quaternions

from a Gaussian distribution. For each sample a dif-

ference of 5

◦

(degrees) is guaranteed in the genera-

tion process. The camera rotation matrix is given by

(Shoemake, 1995):

M = 2





− y

− z

xy+ wz xz− wy

xy− wz

− x

− z

yz+ wz

xz+ wy yz− wz

− x

− y





(1)

using the restriction w

= 1 for a quater-

nion q = [w,(x,y,z)].

Figure 2: Virtual sphere path for acquiring the training set.

The center of each hexagon corresponds to different camera

position.

3.3 Segmentation and Localization

One of the most important steps in the algorithm is

the hand segmentation. To accomplish this, we use

the HSV color space, which allows better luminosity

invariance. For the image segmentation a Histogram

Backprojection algorithm is used (Swain and Ballard,

1991), resulting in a histogram of the likelihood of

each pixel constituting the hand. Basically, this algo-

rithm assumes that a color histogram is known before

hand. The algorithm tries to localize in the image do-

main, the colors of the object being looked for. There-

fore, a salience map is created, i.e. a probability map

Vision-basedHandPoseEstimation-AMixedBottom-upandTop-downApproach

569

Figure 3: Some image samples generated with the Open-

RAVE.

for the presence of the object for each and every pixel

on the image. The histogram indicates the probability

of occurrence for the hand colors.

After the ﬁltering process the result is a segmented

hand, though with some noise. To clean up the image

we make some image processing, by ﬁlling the holes

inside the hand and removing out border objects. Sub-

sequently we obtain a binary image with a segmented

hand. This method is identical for the training set im-

ages and for the images which we want to determine

the position – the observed (test) images.

For better matching, the hand centroid (x

) is

placed in the center of the image, though for this pro-

cedure the hand has to be rotated according to the dis-

placement made before. The Homography for pro-

jecting and rotating points in an equivalent pan-tilt

camera are (Brandao et al., 2011):

+ c

− s

(2)

+ c

− s

(3)

where c

stand for cos(p), sin(p), cos(t),

sin(t), respectively, (x

) represent the pixels af-

ter the rotation, p and t are the equivalent pan-tilt

camera angles, meaning that the previous (x

) are

now centered in the camera. To compute the pan and

tilt (p,t) angles the translation of the image must be

known, so:

p = arctan(x

) (4)

t = arctan(y

) (5)

ending with a segmented hand centered with the cam-

era and projected according to the movement made.

These changes of perspective introduce error in the

process though it is still acceptable.

Since we are working in a 2D image plane the Z

coordinate can be interpreted as an area normalization

factor that will be used in the matching metrics.

3.4 Pose Estimation

In order to obtain a faster algorithm, we try to com-

pute all the information needed for the estimation in

ofﬂine mode. This is accomplished by calculating the

geometric moments for the training set (bottom-up),

granting us a good ﬁlter (of the training set) in real

time application. The Hammoude metric (top-down)

will be applied next, since it provides high accuracy

but takes longer to compute.

3.4.1 Geometric Moments and their Match

To obtain fast descriptors of hand characteristics, pos-

ture and shape, we use geometric moments. These

can be made invariant to position and scale by center-

ing and normalizing by area:

∑

(x− x

)

(y− y

)

I(x,y)

p+q

(6)

where u

stands for the moment of order p + q, M

for hand area and I(x, y) for image pixel. According

to our studies, it is essential to keep the moments of

order higher than 4

, since the higher the order the

more discriminative characteristics we get. In con-

trast, lowerorders describe the hand position and area,

which we want to be invariant.

To get the matching distance between trained and

observed images, a Mahalanobis-likedistance is used:

d =

∑

p,q

( ˜n

− n

)

var(n

)

(7)

˜n

is the moment calculated in an observed image,

the moment trained in the train set hypotheses and

var(n

) is the variance of the moment in the training

set. By minimizing the function we have the most

likely hypothesis.

3.4.2 Hammoude Metric

To evaluate with higher precision the match between

the observed silhouettes and the one in the database,

we use the Hammoude metric (Nascimento and Mar-

ques, 2008; Hammoude, 1988) that is deﬁned as fol-

lows

HMD

) =

#((R

∪ R

) \ (R

∩ R

))

#(R

∪ R

)

(8)

where R

represents the image region delimited by

the contour y

(similarly for R

), ♯ denotes the num-

ber of pixels within the region by the expression in

parenthesis, and \ denotes the minus operation be-

tween the sets. We then convert this value to a likeli-

hood, p(y

), by:

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

570

p(y

) = 1− d

HMD

) (9)

4 RESULTS

In this section, we experimentally validate the perfor-

mance of the top-down/bottom-up architecture for the

hand pose estimation. We ﬁrst access the performance

of each component individually. Then we experimen-

tally illustrate the performance of the overall system.

4.1 Top-down vs Bottom-up

We start by illustrating the performance of the

bottom-up component. To do so, we use a previously

generated training set (23500 frames), and use a given

test hand pose image. We compute the geometric mo-

ments (see eq. (6)) for that observed image and rank

accordingly (see eq. (7)). We repeat this procedure

for all images in the test set (i.e. 400 frames). Fig. 4

shows the cumulative rank of the geometric moments

in which the bars represent the probability of hitting

the correct hypotheses (i.e. hand poses). From this

example, we see that the accuracy to ﬁrst choose the

correct hypothesis is 38% (left most bar in the his-

togram). The accuracy of 90% is reached for the top

23 matched hypothesis.

To compare the obtained results with the top-down

component, we follow the same procedure (i.e. build-

ing the rank of the database for each test image).

Fig. 5 shows the achieved results for the cumulative

ranks. The performance accuracy is now 52% for the

ﬁrst choice. Also, it is illustrated that a faster conver-

gence is achieved, where only 10 hypotheses sufﬁce

for achieving 90% accuracy. This allows us to con-

clude that the top-down mechanism deﬁnitively im-

proves the quality of the detection with respect to the

bottom-up method alone.

4.2 Pose Estimation

To assess the performance of the full hand pose esti-

mation process, we ﬁrst study how can we select the

proper number of candidates provided by the bottom-

up process. We have experimented numbers of candi-

dates in the set R = {1, 10, 100,1000, 10000, 23500}.

Say that, in Fig. 1 - 4th column, we vary the num-

ber of hypotheses in the range R. We then assess the

performance of the hand pose estimation by using the

top-down approach over that number of candidates.

The error metric used, is the orientation error de-

ﬁned as

ε = 2arccos(p· q) (10)

0 10 20 30 40 50

0.2

0.4

0.6

0.8

Top Geometric Moments

% Sucess rate

Figure 4: Accumulative rank for geometric moments.

0 5 10 15 20 25 30 35 40 45 50

0.2

0.4

0.6

0.8

Top Hammoude Metric

% Success rate

Figure 5: Accumulative rank for Hammoude Metric.

where p· q stands for the inner product between two

quaternions. The error in eq. (10) is computed be-

tween the know ground truth hand pose of the test

image and the angle of maximum likelihood training

image detected by the top-down process. Finally, the

average of the orientation errors ε

is taken to assess

the overall performance on the test set.

Table 1 shows the average of the orientation er-

ror ε

(in degrees) and the time to compute the pose

estimation. As we can see, the time spent has a signif-

icant impact when the number of top samples grows.

For online applications this is of paramount impor-

tance, where the time should be as low as possible

Notice that, the orientation error regarding the ground

truth is remarkably under 8%, being the best value

achieved for 1000 candidate moments. However, the

error value achieved for 100 frames is quite similar,

thus being possible to use less than 1000 frames. This

allows us to conclude that the geometric moments are,

indeed, an important ﬁltering step in order to efﬁ-

ciently reduce the training set to just 4%. Moreover,

the integration of top-down provides higher accuracy

(as already detailed in Section 4.1) where a small ori-

entation error is obtained. Recall that, (see Section

3.2) a discretization of 5 degrees is used, meaning

that the top-down procedure exhibits remarkable ac-

The time results shown in Table 1 were obtained in a

non-optimized Matlab code. This could be drastically re-

duced using a C++ base programming or by optimizing the

algorithm in order to take advantage of GPU and/or by us-

ing multi-core computation.

Vision-basedHandPoseEstimation-AMixedBottom-upandTop-downApproach

571

Table 1: Mean and standard deviation (in parenthesis of the

cell) order statistics of the orientation error ε

(in degrees)

and time spent ((s)-seconds, (ms)-milliseconds) for the hand

pose estimation. The experiment is repeated for the top can-

didates moments deﬁned in the range R.

# Cand. Mom Time ε

(

◦

)

1 25.2 (0) (ms) 17.8 (34.6)

10 4.21 (0.06) (s) 7.34 (15.4)

100 5.99 (0.98) (s) 5.86 (3.06)

1000 11.90 (2.74) (s) 5.77 (3.00)

10000 69.07 (5.33) (s) 5.77 (3.00)

23500 122 (8.11) (s) 6.06 (3.50)

curacy.

From Table 1 we observe that the error at the bot-

tom line grows. The reason for this is the great num-

ber of possibilities available, many ambiguous, result-

ing in very small differences for classiﬁcation. This

leads to an effect similar to overﬁtting.

0 10 20 30 40 50

0.2

0.4

0.6

0.8

Hypotheses Candidates

% Success rate

Figure 6: Accumulative rank using top 1000 candidate hy-

potheses.

Fig. 6 shows the accumulative rank when combin-

ing the bottom-up and top-down procedures. It can be

seen that an accuracy of 90% is promptly reached us-

ing only 10 hypotheses candidates.

As a ﬁnal experiment we evaluated several se-

quences in real settings. The goal is to recover the

pose of a real human hand using the model learned

with the OpenRAVE. We present the results of a se-

quence containing 50 frames. Fig. 7 shows some

snapshots of the sequence as well as the recovered

poses. We may notice some small differences be-

tween the shape of the hand (1st and 3rd rows of

the Fig.7) and the corresponding poses (2nd and 4th

rows). This happens due to the model particularities

in the generation process using the OpenRAVE (see

illustrations in Fig. 3) that is a bit different from the

human hand.

We should stress that the presence of shadows and

poor illumination in real settings can jeopardize the

silhouette recovery, leading to the incorrect hypothe-

sis given by the geometric moments and misleading

pose recovery. Although, the segmentation used in

our scenario sufﬁces for a correct estimation, this is

Figure 7: Six snapshots of the sequence (top) poses recov-

ered by the algorithm (bottom).

an issue to take into consideration for other environ-

ments.

5 CONCLUSIONS

In this paper we proposed a 3D hand posture estima-

tion framework. The architecture combines bottom-

up and top-down approaches, providing an efﬁcient

tool for hand orientation detection. The algorithm

presented is twofold. First, the bottom-up allows for

an efﬁcient reduction over the training set, having a

signiﬁcant impact on computationaltime. Second, the

use of the top-down process provides an improved es-

timation accuracy. Fusing these two methods we can

achieve faster performance and reliable estimation, in

both synthetic and real environments.

We conclude that this method generates a good

hypothesis estimator which is crucial for a fully au-

tomatic initialization. In future work we will focus

on the integration of this proposed methodology in a

full tracking framework (e.g. a particle ﬁlter architec-

ture) and the addition of new hand postures for more

general applications.

REFERENCES

Borenstein, E. and Ullman, S. (2008). Combined top-

down/bottom-up segmentation. IEEE transactions on

pattern analysis and machine intelligence, 30:12:4–

18.

Brandao, M., Bernardino, A., and Santos-Victor, J. (2011).

Image driven generation of pose hypotheses for 3d

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

572

model-based tracking. In 12th IAPR Conference on

Machine Vision Applications. MVA 2011.

Delamarre, Q. and Faugeras, O. (2001). 3d articulated mod-

els and multi-view tracking with physical forces.

Diankov, R. (2008). Openrave: A planning architecture for

autonomous robotics. Robotics Institute, Pittsburgh,

PA, Tech. Rep., (July).

Erol, A., Bebis, G., Nicolescu, M., Boyle, R. D., and

Twombly, X. (2005). A review on vision-based full

dof hand motion estimation. In (CVPR’05)Computer

Society Conference on Computer Vision and Pattern

Recognition.

Gavrila, D. M. (1999). The visual analysis of human move-

ment: A survey. Computer Vision and Image Under-

standing, 73:82–98.

Gavrila, D. M. and Davis, L. S. (1996). Tracking of hu-

mans in action: a 3-d model-based approach. In In

Proc. ARPA Image Understanding Workshop, pages

737–746.

Hammoude, A. (1988). Computer-assited Endocar-

dial Border Identiﬁcation from a Sequence of Two-

dimensional Echocardiographic Images. PhD thesis,

University Washington.

Kyrki, V. (2005). Integration of model-based and model-

free cues for visual object tracking in 3cd. In Proc.

of the IEEE Int. Conf on Robotics and Automation

(ICRA’05), pages 1554–1560.

Micilotta, A. S., Ong, E., and Bowden, R. (2006). Real-

time upper body detection and 3d pose estimation in

monoscopic images. In In European Conference on

Computer Vision, pages 139–150.

Nascimento, J. C. and Marques, J. S. (2008). Robust shape

tracking with multiple models in ultrasound images.

IEEE Transactions on image processing, vol. 17, no.

Okuma, K., Taleghani, A., Freitas, N. D., Freitas, O. D., Lit-

tle, J. J., and Lowe, D. G. (2004). A boosted particle

ﬁlter: Multitarget detection and tracking. In In ECCV,

pages 28–39.

Poppe, R. (2007). Vision-based human motion analysis: An

overview. Computer Vision and image Understanding,

108:1–17.

Ramanan, D., Forsyth, D. A., and Zisserman, A. (2007a).

Tracking people by learning their appearance. Pattern

Analysis and Machine Intelligence, IEEE Transaction

on.

Ramanan, D., Forsyth, D. A., and Zisserman, A. (2007b).

Tracking people by learning their appearance. Pattern

Analysis and Machine Intelligence, IEEE Transaction

on.

Rehg, J. M. and Kanade, T. (1994). Visual tracking of

high dof articulated structures: an application to hu-

man hand tracking. In Lecture Notes in Computer Sci-

ence, 1994, Volume 801/1994, pp. 35-46. Springer.

Shoemake, K. (1995). Animating rotation with quaternion

curves. In SIGGRAPH ’85 Proceedings of the 12th

annual conference on Computer graphics and inter-

active techniques, pages 245–254. ACM New York,

NY, USA.

Swain, M. J. and Ballard, D. H. (1991). Color indexing. Int.

Journal od Comp. Vision, 7(1):11–32.

Zhiguo, L. V. and Yan, L. I. (2010). Efﬁcient 3d hand

posture estimation with self-occlusion from multiview

images. In 2010 Second International Conference on

Intelligent Human-Machine Systems and Cybernetics.

IEEE.

Vision-basedHandPoseEstimation-AMixedBottom-upandTop-downApproach

573
