Making Digital Signage Adaptive through a Genetic Algorithm

Utilizing Viewers’ Involuntary Behaviors

Ken Nagao and Issei Fujishiro

Graduate School of Science and Technology, Keio University, Minato, Tokyo, Japan

Keywords:

Digital Signage, Image Processing, Genetic Algorithm, Human Behavior Recognition.

Abstract:

Digital signage has been becoming more popular due to the recent development of underlying hardware tech-

nology and improvement in installing environments. In digital signage, it is important to make the content

more attractive to the viewers by evaluating its current attractiveness on the ﬂy, in order to deliver the message

from the sender more effectively. Most previous works for this evaluation do not take the viewers’ feeling

towards the content into account, and the content is improved manually if needed in an off-line manner. In this

paper, we present a novel method which does not rely on such manual evaluation and automatically makes the

content more adapted to the viewers. To this end, we take advantage of the viewers’ involuntary behaviors in

front of the digital signage for online updates through the usage of a genetic algorithm.

1 INTRODUCTION

Digital signage has been becoming more popular due

to the recent development of underlying hardware

technology and improvements in installing environ-

ments. Digital signage is an electronic display which

shows various messages to the public, and there can

be found many advantages to use the digital signage

compared to the traditional paper signage. Indeed,

digital signage can be controlled in real time, and we

can instantly replace the content. As a new interactive

display device, digital signage has recently attracted

much attention from the ﬁeld of computer vision.

Digital signage has to provide “attractive” content

to the potential viewers in order to deliver the orig-

inal message effectively. Therefore, it is important

to modify the appearance of the content continually.

In general, this modiﬁcation is done by humans be-

cause it is necessary to allow for the subjective mat-

ters as well as aesthetic issues. We herein propose a

method which does not rely on these kinds of man-

ual processes and adaptively improves the content.

The method utilizes a genetic algorithm (GA) to learn

“what content is attractive” and automatically make

the content more attractive to the viewers. In the sys-

tem, “content designs” are regarded as “individuals”

in the GA.

In order to utilize a GA, there must be an eval-

uation mechanism installed in the system. In digi-

tal signage, “evaluation” should be based primarily

on the viewers’ feeling towards the digital signage.

To this end, the proposed method is designed so as

to make use of the viewers’ involuntary behaviors in

front of the digital signage. For example, a viewer

may change his head angle or move his eyes for read-

ing each section of the content. If the section was

convincing he would nod or if it was unacceptable

he would shrug his shoulders. Such involuntary be-

haviors come directly from his emotion, and hence,

if the digital signage system can capture and recog-

nize these behaviors of the viewer, it can automati-

cally learn his actual feeling toward each section of

the content. Moreover, as digital signage is for pedes-

trians, many samples for the evaluation can be col-

lected readily.

In order to empirically evaluate the proposed

method, we have developed a pilot system for dis-

playing academic conference posters. This is because

messages and relationships of each sections in aca-

demic conference posters are clear and easy to deal

with. Figure 1 shows an example of adaptive confer-

ence poster, and the proposed system in actual use can

been seen in Figure 2.

The remainder of this paper is organized as fol-

lows. In section 2, we review related work. Section

3 describes the detailed approach adopted in the pro-

posed system. Finally, Section 4 concludes the paper

with brief remarks on future work.

2 RELATED WORK

So far, direct questions to viewers, such as interviews

or questionnaires, have been commonly used for eval-

Nagao K. and Fujishiro I..

Making Digital Signage Adaptive through a Genetic Algorithm - Utilizing Viewers’ Involuntary Behaviors.

DOI: 10.5220/0004346100540059

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 54-59

ISBN: 978-989-8565-48-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

uating the content of digital signage (Alt et al., 2012).

One major drawback in such direct questions lies in

that much human labor is required for gathering and

analyzing the data. In addition, the viewers do not al-

ways tell their actual feeling with such off-line styles

of questions.

There are many known attempts to recognize hu-

man faces in video (Pantic and Rothkrantz, 2000;

Gutta et al., 2000), and some digital signage systems

have recently started to use a ﬁxed video camera for

evaluating the content from the viewers. However,

those systems mainly gather human attributes which

do not necessarily relate to their feelings, such as

gender, age and viewing time (M¨uller et al., 2009).

These systems cannot distinguish whether the viewer

is watching with negative or positive feeling towards

the content, and evaluations are not sufﬁcient to an-

alyze which section of the content was attractive or

not.

Figure 1: An example of adaptive conference poster. Upper:

An initial design. Lower: An evolved design after several

generations were altered.

Figure 2: A snapshot of the proposed system in actual use.

From the aspect of aesthetics, the question on the

attractiveness of design has been a difﬁcult question

because it involves many subjective issues in psychol-

ogy, statistics and other disciplines. There exist some

research challenges that tackled this problem. For ex-

ample, Singh and Bhattacharya (2010) proposed an

algorithm to improve the aesthetics of web interface

utilizing a GA for evaluating more than ten geometri-

cal features, such as balance and equilibrium, of page

layout. However, the approach does not take user

evaluation into primary account, and they concluded

that it is difﬁcult to deﬁne the cases in which the ap-

proach works well.

Moreover, in the case of digital signage, we have

to take into account the fact that the local tastes to-

ward the content may be different depending on the

place where the digital signage is installed. There are

some known digital signage systems which enable in-

teraction with the viewers, where the viewers can be

provided the content which they want to see, while

the systems have to wait for the explicit interaction

from the viewers. Most pedestrians may walk with

other purposes and just pass over the digital signage,

and therefore it would be inefﬁcient to wait for the

interaction from them. In order to ameliorate these

problems, we will present a novel approach to make

the content more attractive to the viewers by utilizing

their “involuntary behaviors” for evaluating the con-

tent.

3 APPROACH

Figure 3 shows the processing ﬂow of the proposed

method, whose advantages compared to previous

works can be summarized as follows.

In the proposed method, the system automatically

learns “what content is attractive” and modiﬁes the

appearance of the content, so we do not need to an-

alyze the local tastes, search for attractive designs,

nor modify the appearance of the content manually.

In general, GA is useful for solving problems whose

structure is not well understood and for which no ex-

act solution is found. The problem of seeking “what

content is attractive” can be regarded as a typical one

of such problems, and GA has an ability to overwhelm

the manual design.

As for the evaluation, the proposed method utiliz-

ing viewers’involuntary behaviors can make it easy to

collect many useful evaluation samples. Since digital

signage targets the public, a large number of people

can serve as viewers, without waiting for their volun-

tary interaction. In addition, “involuntary behaviors”

are deeply related to their feeling, we can draw reli-

MakingDigitalSignageAdaptivethroughaGeneticAlgorithm-UtilizingViewers'InvoluntaryBehaviors

Figure 3: The processing ﬂow of the proposed method. (a) First, the system requires us to deﬁne what we want to show to

the public and puts up multiple content designs based on the inputs. (b) The system shows each content design in turn, and

when each content design is displayed, the system recognizes involuntary behaviors of the viewers in order to evaluate the

attractiveness of each content design from them. (c) After all content designs are evaluated, they are sorted in an evaluation

order. Then the system breeds new content designs through crossover between highly-ranked content designs and mutation

of the highest-ranked content design. After that, the system shows the new content designs once again for the viewers to

re-evaluate them. Repeating these steps, the system evolutionally produces more attractive content designs. If an acceptable

content design is reached, the evolution terminates.

able evaluation towards the content from them, with-

out any need to check up the validity of the evalua-

tion. “Involuntary behaviors” include gaze-related in-

formation such as head pose and pointing ﬁngers, and

thus the system can understand which section of the

content is attractive.

As shown in Figure 3, the proposed method con-

sists of three steps: (a) preprocessing step for mak-

ing sections from the content of digital signage and

creating the ﬁrst generation of the content design;

(b) evaluation step which uses the viewers’ involun-

tary behaviors; and (c) modiﬁcation step which pro-

duces new generations for making the content more

attractive based on the evaluation. After a modiﬁca-

tion step, the system will gather evaluation to each of

the individual content designs utilizing the viewers’

involuntary behaviors once again. Repeating these

steps, the system evolutionally produces attractive de-

signs of content. If an acceptable content design is

reached, the evolution terminates.

Figure 1 illustrates one example of evolved con-

tent designs. Each of the ﬁgures in the poster was

independently adjusted in terms of size, and we can

easily identify each section and understand the over-

all content.

3.1 Preprocessing Step: Extracting

Sections

First, we have to make it clear what we want to show

to the public. We are required to divide the content

into smaller sections. An academic conference poster

can actually be divided into “title”, “authors”, “sec-

tion titles”, “content of subsections” and “reference

ﬁgures”. Hereafter, we will simply refer to the over-

all design of the content as content design, and small

content sections deﬁned in this step as sections.

Note that there can be found hierarchical relation-

ships among these sections. For example, “title” has

“section titles” as its children, and “section titles” are

siblings. We have to specify these relationships ex-

plicitly in extracting sections from the content.

Each section is required to have two kinds of prop-

erties: content properties and graphical properties.

Content properties are what we want to tell to the pub-

lic in the corresponding section. For example, in the

section of “authors”, content properties are speciﬁed

as the names of the authors. Here, we deﬁne what

values the content properties can take, because there

exist various ways to indicate the message. If it is

“authors”, we make up several patterns of sentences

as the deﬁned values for the content property (Figure

4). On the other hand, graphical properties are about

how to decorate the section, such as font, font color,

frame color and size of the section. These values are

given to each by the system automatically.

Next, the system randomly creates a ﬁxed num-

ber of initial content designs based on pre-deﬁned

sections, giving random property values to graphi-

cal properties and randomly selecting the pre-deﬁned

values for content properties. Note that the system

takes the deﬁned hierarchical relationships between

sections into account for uniﬁed design. Figure 5

shows one example of the created content design with

its underlying hierarchical structure. Such content de-

signs constitute the ﬁrst generation in the GA.

3.2 Evaluation Step: Recognition of

Viewers’ Involuntary Behaviors

In this step, the system gathers the viewers’ evalua-

tion towards the content designs by recognizing their

involuntary behaviors.

3.2.1 Two Behavior Types

In front of digital signage, the viewers behave in var-

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

ious ways. Our system uses Microsoft Kinect

for

recognizing the viewers’ behaviors, and in order to

make these behaviors easy to understand, we deﬁne

two types of behaviors: behaviors indicating viewers’

attention point (attention pointer) and behaviors indi-

cating viewers’ feeling (feeling indicator).

Attention pointers are behaviors such as changing

head angle and pointing gesture. Recognizing these

behaviors and considering the position of the viewer

and the size of digital signage, the system can esti-

mate which section is focused on. In the current sys-

tem, eye location is not recognized due to the limited

resolution of Kinect. There are many known attempts

to utilize eye location for gaze estimation (Valenti et

al., 2012). If digital signage is large, we can estimate

the attention point only from the head angle, but in or-

der to obtain more accurate results we will rely on the

recognition of eye location as hardware technologies

develop.

On the other hand, feeling indicators include ges-

tures such as folding arms, nodding, and shrugging

shoulders. Such behaviors are deeply related to the

viewers’ emotions. Finding relationships between

these behaviors and feelings has been studied exten-

sively. For example, Gunes and Piccardi (2006) cre-

ated a bimodal face and body gesture database for

analyzing human nonverbal behaviors. The system

Figure 4: Examples of sections of the content. Each section

has content properties and graphical properties, and values

are pre-deﬁned for each content property.

Figure 5: Examples of the properties with the hierarchical

structure of the content design created in the preprocessing

step.

can learn the meanings of behaviors referring to the

database, and by combining this information with the

above-mentioned attention pointers, the system can

gather the viewers’ evaluation towards each section

of the content design.

When recognizing these behaviors, several as-

pects of the diversity deserve to be discussed, as vari-

ous kinds of people can serve as the viewers for digital

signage. One aspect is moving speed of viewers. For

example, if the viewer is a child, he behaves quickly,

while old people behave slowly. We have to take into

account the differencein moving speed and categorize

each evaluation. Another aspect is that the meaning of

gestures can be different if the viewers’ cultural back-

grounds are different. For instance, for most cultures,

shaking the head side to side implies negative reply,

while it implies positive reply for some cultures such

as Indian. Thus, taking into account these diversity is

important for correct evaluation. In our system, as we

can capture whether the viewer is a child or an adult,

we change the capturing speed if the viewer is a child.

As for the meaning of gestures, keeping in mind that

previous research on the detailed meaning of gestures

has limited capability because human affection is a

subjective matter as mentioned before, we focus only

on one culture, Japanese, and then classify the mean-

ings of gestures just according to whether the gesture

is positive or negative.

Moreover, we have to consider that the system

has to capture the viewers’ behaviors without making

them aware of it, or their behaviors would be biased.

Viewers’ behaviors should be “involuntary” and come

directly from their actual feelings. Therefore, in addi-

tion to the necessity of hiding the capture device, the

device should not be mounted and capture the view-

ers behaviors in a noncontact way. As the device for

capturing the viewers’ behaviors, our system employs

Kinect, which allows us to capture various behaviors

such as head pose, facial expression and gestures of

multiple viewers involuntarily.

3.2.2 Evaluating the Content Design from Three

Aspects

“Evaluation” is considered to form three points of

view: the overall evaluation of the content design and

the evaluation indicating eye-catching and unconvinc-

ing sections in the content design. Each evaluation

will be used for making the content more attractive

utilizing the GA (see Subsection 3.3 for more details).

The ﬁrst evaluation is an overall evaluation and

used for “selection” in the GA. We deﬁne the evalua-

tion as the total of time duration for which the view-

ers are looking at the content design without nega-

tive feeling. We will refer to this evaluation as overall

MakingDigitalSignageAdaptivethroughaGeneticAlgorithm-UtilizingViewers'InvoluntaryBehaviors

evaluation of the content design.

The second evaluation is the evaluation which in-

dicates eye-catching sections and used for guiding

“mutation” for graphical properties in the GA. We de-

ﬁne the evaluation as the total of time duration for

which the viewers are looking at the section no mat-

ter how they behave. This evaluation indicates how

eye-catching the section is, without reference to its

content properties. We will refer to this evaluation as

eye-catching evaluation of the section.

The third evaluation is the evaluation which in-

dicates unconvincing sections and used for guiding

“mutation” for content properties in the GA. We de-

ﬁne the evaluation as the total of time duration for

which the viewers are looking at the section with neg-

ative feeling. We will refer to this evaluation as un-

convincing evaluation of the section.

In this step, we have to take the content of dig-

ital signage into account. Viewers’ ways of view-

ing will be substantially different between when the

content is an advertisement and when it is a restau-

rant menu, and we have to consider these differences

very carefully. In our system, the content is limited

to academic conference posters, and the viewers will

take two types of approaches for reading the con-

tent: overviewing the whole content and concentrat-

ing on reading a particular section. We have to evalu-

ate the gestures separately according to these two ap-

proaches, and thus when the viewer does not move

his head or he stands close to the digital signage, our

system presumes that he is concentrating on reading

a particular section and the section should be eval-

uated more compared to when they are overviewing

the whole content.

3.3 Modiﬁcation Step: Making the

Content Designs More Attractive

Utilizing GA

After the evaluations, the system sorts them in an

evaluation order using overall evaluation. Then, the

system modiﬁes the content design utilizing the GA.

In this step, we have to consider the following two

points in addition to the relationships between each

section.

The ﬁrst point is that the modiﬁcation of the con-

tent design should not be done instantly because user

experience would be reduced if the system changes its

content design when some other viewersare still look-

ing at it simultaneously. Changing the content lazily

can be one promising solution for this problem, but

it would make the evaluation for individual content

designs vague because each of the content designs

would not be ﬁxed. Thus, in our system, the con-

tent design will switch to another when a ﬁxed time

duration runs over and no viewer is looking at it.

Secondly, we should not change the property val-

ues of each section in an equally-weighted manner,

because the weight of information each section has

can be different. For example, the weight of infor-

mation “title” is much heavier than that of “section

title”, and changing the font color of title extensively

affects the look and feel of the content design more

than changing that of section title. We have to con-

sider the weight of information when modifying the

content design, and thus our system makes the modi-

ﬁcation to the section with heavy information such as

title section more lazily.

The modiﬁcation is performed in two ways:

crossover and mutation. Figure 6 shows examples of

the breeding.

3.3.1 Crossover

Top two ranked content designs are selected for

crossover. In crossover, the system breeds new indi-

viduals by combining property values of each section

in the highest-ranked content design and the second

highest-ranked one. The possibility of values in these

combination is based on each overall evaluation.

In Figure 6, a new content design whose proper-

ties come from the two previous content designs was

bred by the crossover.

3.3.2 Mutation

Mutation is applied to the highest-ranked one. In

this step, the system breeds some new individuals

Figure 6: Examples of crossover and mutation of the de-

signs.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

by changing the property values of each section in

the highest-ranked one. In the system, mutation is

not completely executed at random. We use eye-

catching evaluation and unconvincing evaluation for

the guide of mutation. The section which got the

highest value of eye-catching evaluation is the section

which attracted the viewers most. Therefore, to em-

phasize the section is important for making the con-

tent more attractive, and thus the system randomly

changes its graphical properties. The system does

not need to consider what kind of modiﬁcation should

be done to the graphical properties for attractiveness,

because unattractive individuals will be exterminated

later. The section which got the highest value of

unconvincing evaluation is the section the matter of

which viewers thought unconvincing, and thus chang-

ing the content properties of the section is necessary

for making the content easy to understand, especially

in the case the section was the one which got the high

value of eye-catching evaluation. In the same way

as before, the system does not need to consider what

kind of modiﬁcation should be done to the content

properties for making the section more convincing.

The system randomly selects the value from the pre-

deﬁned values of the content properties. It is because

unconvincing sections will be selected for mutation

later again. Considering these guides from the eval-

uations, the system breeds some new individuals by

mutation in addition to those by crossover. The sys-

tem does not apply mutation to the crossovered con-

tent designs because we cannot identify the guide for

mutation of the crossovered content.

In Figure 6, the section about system overview

was emphasized because it gathered much attention,

and the sentences of the section about system func-

tionalities were replaced with other pre-deﬁned sen-

tence patterns because they were thought to be un-

convincing.

4 CONCLUSIONS

In this paper, we have presented a novel method

which does not rely on manual evaluation and auto-

matically makes the content of digital signage more

adapted to the local tastes. We take advantage of

viewers’ involuntary behaviors in front of the digital

signage for evaluating the attractiveness of the con-

tent, and make the content design more attractive to

the viewers utilizing a genetic algorithm, which is

useful for solving problems for which no exact so-

lution is found. We empirically proved the feasibil-

ity of the method through the development of a pilot

digital signage system for displaying academic con-

ference posters.

The current system is a pilot system and can be

extended in many directions. One major point is how

the system gathers enough evaluations in places with

few people, and/or for short periods. We will seek

the best timing of changing the content design, and

combination of multiple digital signage devices. Be-

sides, we limited the usage of digital signage for only

a particular purpose, but we will be able to generalize

the method more extensively, considering various be-

haviors and modiﬁcations. For example, we can con-

sider the use of eye-catching evaluation and uncon-

vincing evaluation also in crossover of the GA, and

take advantage of hierarchical relationships between

each section of the content design more thoroughly.

ACKNOWLEDGEMENTS

The work is supported in part by a Grant-in-Aid for

the Leading Graduate School Program for “Science

for Development of Super Mature Society” from the

Ministry of Education, Culture, Sports, Science and

Technology in Japan.

REFERENCES

F. Alt, S. Schneegas, A. Schmidt, J. Muller and Nemanja

Memarovic: “How to Evaluate Public Displays,” Proc.

of the 2012 International Symposium on Pervasive

Displays, Article No. 17, 2012.

H. Gunes and M. Piccardi: “A Bimodal Face and Body Ges-

ture Database for Automatic Analysis of Human Non-

verbal Affective Behavior,” Proc. of the 18th Interna-

tional Conference on Pattern Recognition, pp. 1148–

1153, 2006.

S. Gutta, J. R. J. Huang, P. Jonathon and H. Wechsler: “Mix-

ture of Experts for Classiﬁcation of Gender, Ethnic

Origin, and Pose of Human Faces,” IEEE Trans. on

Neural Networks, Vol. 11, No. 4, pp. 948–960, 2000.

J. M¨uller, J. Exeler, M. Buzeck and A. Kr¨uger: “Reﬂec-

tiveSigns: Digital Signs That Adapt to Audience At-

tention,” Proc. of the 7th International Conference on

Pervasive Computing, pp. 17–24, 2009.

M. Pantic and Leon J. M. Rothkrantz: “Automatic Analysis

of Facial Expressions: The State of the Art,” IEEE

Trans. on Pattern Analysis and Machine Intelligence,

Vol. 22, No. 12, pp. 1424–1445, 2000.

N. Singh and S. Bhattacharya: “A GA-based Approach

to Improve Web Page Aesthetics,” Proc. of the First

International Conference on Intelligent Interactive

Technologies and Multimedia, pp. 29–32, 2010.

R. Valenti, N. Sebe and T. Gevers: “Combining Head Pose

and Eye Location Information for Gaze Estimation,”

IEEE Trans. on Image Processing, Vol. 21, No. 2,

pp. 802–815, 2012.

MakingDigitalSignageAdaptivethroughaGeneticAlgorithm-UtilizingViewers'InvoluntaryBehaviors
